Philips CT0699SLV, CT0699BLK User Manual
Discover Your Phone
Headphone jack
Left side key
Navigation key
Left soft key
Dial key
Charger jack /
Earplug jack/
Data transfer port
Philips continuously strives to improve its
products. Therefore, Philips reserves the right to
revise this user guide or withdraw it at any time
without prior notice. Philips provides this user
guide “as is” and does not accept, except as
required by applicable law, liability for any
error, omission or discrepancy between this user
P699_EN 8/23/07, 5:17 PM1
Back of phone:
Camera lens
262K color
main screen
Right soft key
Power Supply key
Right side key
Number keys
Microphone
guide and the product described. The device is
meant to be connected to GSM/GPRS network.
How to ...
Power On/Off Long press the power supply
key
Make a call In idle mode, press the
number keys, then press the
dial key
End a call During a call, press the right
soft key
Answer a call Press the dial key
Reject a call Press the power supply key
Access the In idle mode, press the left
Main menu soft key
Access the In idle mode, press the right
SIM switch soft key
Access the Tools In idle mode, press the up
menu key
Show the phone In idle mode, press the down
book list key
Access the In idle mode, press the left
Audio Player key
Access the SMS In idle mode, press the right
menu key
Show Call Logs In idle mode, press the dial
key
Access the In idle mode, press the right
preview side key
window of the
Camera
Take photos In the preview window of
the camera, press the right
side key
Adjust ring volume In idle mode, press the left
side key
Mute ring tone When the phone rings, press
the left side key
Reject a call When the phone rings,
press the right soft key or
long press the left side key
Adjust During a call, press the left
earpiece volume side key
P699_EN 8/23/07, 5:17 PM2
Switch to silent In idle mode, long press [*]
mode key
Switch SIM card In idle mode, long press [0]
key
Keypad Lock In idle mode, long press [#]
key
Keypad Unlock In keypad lock mode, first
press the right soft key then
press [#] key
Tap the following icons to access the corresponding
function menu:
Write MessageMain menu Audio Player
dial Fun&Games
1
Softkeys
The left and right keys are located at the top of the
keypad area. Pressing the soft keys allows you to
select the option displayed on the screen directly
above them, including options during a call. The
functions of the soft keys change according to the
current context.
Main Menu
You can access the different features of your phone
from the main menu. The following table
summarizes the structure of the Main menu, what
the icons represent and the page number on which
you can obtain more information regarding the
menu functions.
The instructions in this user guide focuses on
keyboard operations. For touch screen operations,
please refer to the instructions on the screen.
2
P699_EN 8/23/07, 5:17 PM3
Phone Book
Page 15
Fun & Games Services
Page 18 Page 19
Call History Messages User Profiles
Page 23 Page 25 Page 33
Settings Multimedia Tools
Page 34 Page 42 Page 49
In idle mode, press the left soft key “Menu” to access
the main menu and press the navigate keys to
browse the icons and lists, or press 1-9 number keys
to access the options and functions directly. Press
the left soft key to select and access the
corresponding options of the selected item on the
list. Press the right soft key to back or return to the
previous menu.
How to use this manual
This user manual strives to provide you with concise
and complete information regarding your Philips
699 phone. It includes the following:
Discover your phone This section presents an
overview of your mobile
phone and information on the
most commonly used features.
Chapter 1: Information on how to set
Getting started up your mobile phone for
the first time, such as
installation of SIM card,
battery, etc.
P699_EN 8/23/07, 5:17 PM4
Chapter 2: How to make and answer call,
Main features as well as some frequently used
call functions.
Chapter 3: How to enter text using the
Text entry alphanumeric keypad.
Chapter 4 to 12: Description of the main
features of this phone.
Other sections Icons & Symbols, Precautions,
Troubleshooting, Philips
Authentic Accessories, SAR
information (if available at the
time of publication, otherwise
included as a separate
document), and finally the
Limited Warranty information.
3
Table of contents
1.Getting Started .......................................... 7
Inserting the SIM card and Memory card .. 7
Power on the phone .......................................9
Power off the phone .......................................9
Charging the battery .......................................9
2.Calling ........................................................ 11
Make a call ...................................................... 11
Make an international call ........................... 11
Receive/Mute/End a call............................... 11
Call Handsfree ............................................... 12
Adjust speaker/earpiece volume ............... 12
Call option ...................................................... 12
Make a second call ........................................ 13
Answer a second call ................................... 13
3.Input Method ............................................ 14
General outline ............................................. 14
Keypad functions........................................... 14
4
P699_EN 8/23/07, 5:17 PM5
4.Phone Book ..............................................15
5.Fun & Games ............................................ 18
Games ............................................................. 18
Game Setting ................................................. 18
6.Services ......................................................19
STK .................................................................. 19
WAP ................................................................ 19
Data Account ................................................. 21
7.Call History .............................................. 23
Missed Calls ................................................... 23
Dialed Calls .................................................... 23
Received Calls ............................................... 23
Delete Call Log ............................................. 23
Call Time ......................................................... 24
Call Cost ......................................................... 24
SMS Counter ................................................. 24
GPRS Counter ............................................... 24
8.Messages .................................................... 25
SMS .................................................................. 25
MMS ................................................................. 28
Voice Mail Server .......................................... 31
Broadcast Message ....................................... 32
9.User Profiles .............................................33
10. Settings ................................................... 34
Pen Calibration .............................................. 34
SIM switch ...................................................... 34
Phone Setup ................................................... 34
Call Setup ....................................................... 36
Network Setup.............................................. 38
Security Setup ................................................ 39
Restore Factory Settings ............................. 40
Default Encoding Type ................................. 41
Sound Effect ................................................... 41
11.Multimedia ..............................................42
Camera ............................................................ 42
ImageViewer .................................................. 43
P699_EN 8/23/07, 5:17 PM6
eBook .............................................................. 43
Video Recorder ............................................. 43
Video Player ................................................... 44
Audio Player ................................................... 45
Sound Recorder ............................................ 46
Melody Compose ......................................... 46
File Manager ................................................... 47
12.Tools ......................................................... 49
Calendar ......................................................... 50
To Do List ....................................................... 50
Alarm ............................................................... 50
Calculator ....................................................... 50
Units Converter ............................................ 51
Currency Converter .................................... 51
World Clock .................................................. 51
Health .............................................................. 51
Dictionary ....................................................... 52
Shortcuts ........................................................ 52
5
Webcam ........................................................ 53
Icons & Symbols .......................................... 54
Precautions .................................................. 56
Troubleshooting ..........................................60
Philips Authentic Accessories ...................62
Trademark Declaration ............................. 63
Limited warranty ........................................ 64
Specific Absorption Rate Information .... 67
Declaration of conformity ........................ 68
6
P699_EN 8/23/07, 5:17 PM7
1.Getting Started
Please read the safety instructions in the
“Precautions” section before use.
Before you start using your phone, you must insert
a valid SIM card supplied by your GSM operator
or retailer. The SIM card contains your subscription
information, your mobile phone number, and a
small quantity of memory in which you can store
phone numbers and messages. The SIM card can
be removed from your mobile phone and inserted
into any other GSM/GPRS mobile phone to be
read (a new mobile phone will automatically read
the SIM card).
To prevent losing or damaging the data stored on
the SIM card, you should avoid touching the
metallic area on the card and keep the SIM card
away from electricity or magnets. If the SIM card
is damaged, you will not be able to access the GSM/
GPRS network and use the mobile telephone.
Before removing the SIM card you must switch
off the mobile phone. Do not insert or remove
the SIM card while the phone is connected to an
external power source, as this could damage the
SIM card.
Inserting the SIM card and Memory card
Remove the back cover and battery
Make sure that the phone is powered off. You need
to remove the back cover and battery of your phone
before you can insert the SIM card. Use your finger
to lift the battery up from its slot.
Getting Started
P699_EN 8/23/07, 5:17 PM8
7
You may lose all your personal settings if you
remove the battery when the phone is switched on.
Insert the SIM card
Make sure that the clipped corner of the SIM card
is facing the correct direction, and the metallic
contacts are facing downwards. Slide the SIM card
into the card slot until it stops.
When you remove your SIM card the first time,
make sure that you smoothen the edges, otherwise you may have difficulty sliding in the card.
Insert the Memory card
Make sure that the memory card is facing the correct
direction, and the metallic contacts are facing
downwards. Slide your memory card cover to the
right, lift up the card cover and insert the memory
card into the card slot. Then push down the card
cover and slide memory card cover to the left to
lock the memory card into place.
8
P699_EN 8/23/07, 5:17 PM9
Getting Started
Replace the battery and the back cover
With the metallic contacts facing downwards, press the
battery down into its slot until it locks into place. Note
that the hinge should be at the bottom of the phone.
Press down the back cover until it locks into place.
When inserting the battery, be careful not to
damage the metallic connectors of the SIM card
slot.
Power on the phone
To power on the phone, long press the power supply
key. Enter the PIN code if required (the 4 to 8 digit
secret code of your SIM card). It is preconfigured
and provided to you by your network operator or
retailer.
If you enter an incorrect PIN code 3 times in
succession, your SIM card will be blocked. To
unblock it, you must obtain the PUK code from
your network operator.
Power off the phone
At all times, you can long press the power supply
key to power off the phone.
Charging the battery
Your phone is powered by a rechargeable battery.
The new battery is partially charged. A sound alert
will be emitted to warn you when the battery level
becomes low.
We recommend that you do not remove the
battery when the phone is powered on as you may
lose all your personal settings as a result. If you
do remove it, the date and time settings are only
memorized for a short while. As such, you may
need to reset the information after you have
installed the battery back again.
Getting Started
P699_EN 8/23/07, 5:17 PM10
9
Plug the charger into an electrical outlet.
Plug the charger connector into the bottom of
the phone (with the arrow pointing upward).
The battery symbol indicates the state of charge.
If the phone is charging while power off, a charge
indicator will appear on the screen. If the battery
is completely flat, it might take some time after
you have begun charging before the charge
indicator appears on the screen.
When the battery level icon indicates that the
battery is full and does not flash anymore, this
means that the battery is fully charged. When
charging while power off , there will still be an
indication on the screen that the charging is
complete. This process usually takes over 2.5
hours. The mobile phone and charger will become
warm during charging and this is normal .
When charging is complete, unplug the charge
connector from the electrical outlet and the
mobile phone.
Charging must be performed in a well-ventilated
area at a temperature between -10°C and +45°C.
The factory-supplied charger must be used.
Using an unapproved charger could be dangerous.
Moreover, this breaches the provisions of the
repair warranty and violates the mobile phone’s
certification.
If the mobile phone automatically shuts down
or indicates Battery is low, you should immediately
charge the battery. If the battery has not been
entirely used up before charging, the mobile
phone will automatically reduce the recharging
duration.
If you do not intend to use your phone for
several days, we recommend that you remove the
battery.
10
P699_EN 8/23/07, 5:17 PM11
Getting Started
2.Calling
Make a call
You can make a call only when the network name
appears on the screen.
From idle mode
1. In idle mode, you can press the number keys to
enter the phone numbers, or tap
enter the dial screen, then tap the on-screen
numbers to enter the phone number. To correct
an error, press the right soft key.
2. Press the dial key or tap
3. To end a call, press the right soft key or the power
supply key.
From Phone Book
1. In idle mode, you can press the down key to
display the phone book list.
2. Select a contact from the phone book list.
3. Press the dial key to dial the number you have
selected.
or to
to dial.
4. To end a call, press the right soft key or the power
supply key.
Make an international call
1. Press [*] key until “+” appears on the screen.
2. Enter the country code.
3. Enter the area code (normally without the 0 in
front), followed by the phone number.
4. Press the dial key or tap
to dial.
Receive/Mute/End a call
Receive a call: Press the dial key.
Mute a call: Press the right soft key, power supply
key or long press the left side key.
End a call: Press the power supply key.
The phone will not ring when it is in silent mode.
The phone will not be able to receive calls when
it is in mass storage mode.
Calling
P699_EN 8/23/07, 5:17 PM12
11
Call Handsfree
For your comfort and safety, move the phone away
from your ear when calling in handsfree mode.
To activate handsfree during a call, press the left
soft key Option, then select H-Free and press the
left soft key again; To deactivate handsfree during a
call, press the left soft key Option menu, then select
H-Free and press the left soft key again.
Adjust speaker/earpiece volume
During a call, you can press the left side key to
adjust volume.
Call option
There are several options available during a call.
You can press the left soft key Option to enter the
call option menu. The call option menu is only
available during a call.
Functions such as call waiting, call divert, and
conference call require network support. Please
contact your network provider.
In the call option menu, you can carry out the
following operations:
Hold: Put a call on hold or retrieve a call that has
been put on hold.
H-Free: During a call, press the left soft key
Option, then select H-Free and press the left soft
key again to activate it; To deactivate handsfree,
press the left soft key Option, then select H-Free
and press the left soft key again.
New Call: Dial a new call.
Phone Book: Enter the phone book list.
SMS: Enter the Messages menu.
Sound Recorder: Record voice memos.
In some countries, recording of telephone
conversation is subject to legislation. If you
intend to record the conversation, we advise that
you notify the caller and only do so when they
agree. You should also ensure confidentiality of
the recordings.
Mute: Stop the transmission of your voice to the
other party.
DTMF: Deactivate or activate DTMF sound.
12
P699_EN 8/23/07, 5:17 PM13
Calling
Make a second call (Network dependent)
Dial a second call (Network dependent)
You can make a second call by putting the current
call on hold:
1. During a call with Party A, you can enter Party
B’s number using the keypad or select New Call.
2. Press the dial key to dial Party B’s number. Party
A will be put on hold automatically.
3. You can also select Phone Book to access the Phone
Book list, then select the contact you wish to
call.
Switch calls (Network dependent)
When you have one active call and one call on hold,
you can press the left soft key Option, then select
Swap to switch between the 2 calls; or select End
Single or End All to end the call.
Answer a second call (Network dependent)
If you have activated Call Waiting, you will be alerted
when there is a second incoming call. You can:
1. Press the dial key to answer the second call. The
current call will be put on hold automatically.
2. Press the right soft key to reject the second call,
then press the left soft key Option, and select
Retrieve to continue with your current call.
3. When there is one active call and one call on
hold, you can press the left soft key Option to
carry out the following operations:
Swap Conference Transfer
End Single End All Phone Book
SMS Sound Recorder Mute
DTMF
Calling
P699_EN 8/23/07, 5:17 PM14
13
3.Input Method
General outline
This mobile phone supports English input and
provides the following input methods: Multitap ABC,
Multitap abc, Numeric, Smart ABC, Smart abc.
The available input method is dependent on the
language display.
Keypad functions
The keypad functions are as follows:
Left soft key: Generally used for confirmation
Right soft key: To return or delete.
Navigation keys (up/down and left/right keys):
Generally used to move the cursor or candidate
characters.
Right Navigation key: Enter a blank space.
[#] key: Switch between the different input
methods.
[*] key: Display the symbols list.
Smart ABC and Smart abc input methods do not
support handwriting input.
Tap on the screen to move the cursor position.
Tap to display symbols list.
Tap to input a blank space.
Tap to delete a letter or character.
Tap to hide a letter or character; tap
to display a letter or character.
Tap to switch between English (ABC or abc)
input methods.
14
P699_EN 8/23/07, 5:17 PM15
Input Method
4.Phone Book
Press the down key in idle mode to display the
phone book list.
This phone is able to store up to 500 phone book
records. The number of records you can store on
the SIM card is dependent on the capacity of your
SIM card.
Search: View all the entries stored in the phone
book.
Search Entry: Search for an entry in the phone
book by name.
Add New Entry: Add a new record to the phone
book. You can store the number “To SIM” or
“To Phone”. If the new record is added “To
Phone”, apart from Name, Numbers, Home
Number, Office Number, Fax Number, you can
also add the following information:
Company Name: Enter company name.
E-mail Address: Enter email address.
Birthday: Enter the contact’s birthday.
Associate Picture: Set a personalized picture for
the current phone entry. You can either select a
preset picture from your mobile phone or select
a picture from the File Manager.
Associate Video: Set a personalized video for the
current phone entry. You can either select a preset
video from your mobile phone or select a video
clip from the File Manager.
Associate Sound: Set a personalized ring tone for
the current phone entry. You can press the left/
right keys to select a personalized ring tone from
the mobile phone.
You can select an audio file from the File
Manager\User Profile as the associate sound.
Caller Group: You can assign the contacts in the
phone book into different groups.
Copy All: Select “From SIM to Phone” to copy all
the entries from your SIM card to your mobile
phone, or select “From Phone to SIM” to copy
all the entries from your mobile phone to your
SIM card.
When you copy telephone number entries from
your mobile phone to your SIM card, only the
Name, Number and Caller Group will be copied.
Phone Book
P699_EN 8/23/07, 5:17 PM16
15
Delete: Select “From SIM” or “From Phone” to
respectively delete all the entries in the SIM card
or the onboard phonebook. You can also select
“One By One” to delete telephone number
individually.
To delete all the entries from the SIM card or
phone, you need to enter a password. The default
password is “0000”.
Caller Group: The phone supports incoming caller
group function. You can select a group from the
caller group list to view and edit the details. The
caller group options include group name, ringtone
of the incoming call, associate picture of the
incoming call, associate movie of the incoming
call, add a member to the group and delete a
member from the group.
You can add or delete a member from the caller
group only if the corresponding member’s record
is stored in the onboard phone book.
Extra Number: You can set the following
numbers:
Owner Number: Edit and set up one owner
number and the corresponding name.
Service Dial Number: SIM card dependent. This
service is currently available in Europe only.
SOS Number: You can edit and set up to five
groups of SOS Number.
Settings:
Memory Status: You can view the total memory
capacity and the used memory space of the phone
book on both the mobile phone and the SIM
card.
Preferred Storage: You can set the preferred
storage location of the telephone numbers - to
“SIM” or “Phone”. You can also choose the
storage location when you add a new phone entry.
Fields: Select “On” or “Off” to show or hide the
various fields such as Home Number, Company
Name, Email Address, Office Number, Fax
Number, Associate Picture Associate Sound and
Caller Group.
Caller Picture: Select an appropriate picture for
the current phone entry from the File Manager.
Caller Ring Tone: Select a caller ring tone from the
preset ring tones in your mobile phone or from
the music files sent by others and stored in User
Profiles.
Caller Video: Select a video clip for the current
phone entry from the File Manager.
16
P699_EN 8/23/07, 5:17 PM17
Phone Book
You can select a contact from the phonebook list
and press the left soft key Options to carry out the
following operations:
Dial: Press the left soft key to dial the current
number.
Send SMS: Send a short message to the current
phone entry.
IP Dial: Set up an IP dial number. When you
choose IP Dial, the IP number will be
automatically added before the telephone
number you wish to dial.
Send MMS: Send an MMS message to the
selected contact.
View: View details of the selected contact. If the
information in the entry exceeds one screen
length, you can use the up/down keys to scroll.
If the selected contact is saved on the SIM card,
then you can only view the Name, Number and
Caller Group of the contact.
Edit: Edit and revise the information of the
selected contact.
Delete: Delete the selected contact.
Copy: Copy the selected contact to another
location, such as the phone or SIM card.
Move: Move the selected contact to another
location. If the selected contact is stored in the
SIM card, then it will be moved to the mobile
phone and vice-versa.
You can tap to dial the selected telephone
number under “option” view directly. If there is
more than one telephone number in the entry,
select the desired number, then press the dial key
to dial the number.
Phone Book
P699_EN 8/23/07, 5:17 PM18
17
5.Fun & Games
Games
You can play three different games: ColorBalls,
Memory and Puzzle. For each game, you can begin
with Start Game or Game Help, or you can view
Best Grades and Game Level.
Start Game: Starts a new session of the selected
game.
Resume: Opens the game you have played but not
finished last time.
Game Level: You may be asked to select a level for
the game. The options are: Easy Normal and Hard
(Only in Smash).
Best Grades: You can view the best score for each
type of game and at each level.
Game Help: You can view instructions on how to
play the games and how to use the keys in the games.
Press the left soft key to pause or continue.
Press the right soft key Back to exit.
Game Setting
Set Game Audio and Game Vibration to On or Off.
Move the cursor to the option by pressing the up/
down keys or left side key, and set the corresponding
effect with the left/right keys.
18
P699_EN 8/23/07, 5:17 PM19
Fun & Games
6.Services
STK
You can use the value-added services provided by
your network operator.
Your mobile phone supports STK functions. This
service is provided by your network operator. If your
SIM card and network operator cannot support this
service, then you will not be able to see this function
in the menu. For more information, please contact
your network operator.
The options in the STK menu differs according
to the network operator.
WA P
Your mobile phone supports Wireless Application
Protocol (WAP) service. You can access a wide
variety of WAP services such as news, weather
reports, flight information etc. These services are
specially designed for mobile phones and
maintained by the WAP service providers.
Network support is necessary for access to WAP
services. Please contact your network provider and/
or the service provider of the desired service. Your
service provider will also provide you with
instructions on how to use this service.
1.Homepage
Enter the home page and use this menu to connect
your phone to the network and load the home page
of the wireless web service provider. Homepage is
set in Settings\Edit Profile.
2.Bookmarks
Display the bookmark list. Press the up/down keys
or the left side key to select one bookmark, then
press the left soft key Option to access the following:
Goto: Connect to the selected bookmark.
Edit: Edit the Title and Address of the bookmark.
Delete: Delete the selected bookmark.
Delete All: Delete all the bookmarks.
Add Bookmark: Edit the title and address of a new
bookmark.
Services
P699_EN 8/23/07, 5:17 PM20
19
If the bookmark is empty, you need to enter the
URL address of the website before connecting to
it. For example, if you want to add sina website
to the bookmark, you need to enter:
wap.sina.com.
3.Recent Pages
Display the recent pages. Select a recent entry and
connect to the page directly.
4. Enter Address
Manually enter the URL address of a website and
connect to it.
If you want to connect to sina website, you need
to enter: wap.sina.com.
5.Service Inbox
Select Service Inbox to view the service messages
you have received.
Your mobile phone can receive service messages sent
by your service provider. For example, service
messages may consist of notifications on news
briefings, or a line of text message, or a WAP service
address.
6.Settings
Select Settings to configure the settings for online
browsing.
Edit Profile: You can edit these options: Rename
Profile, Homepage, Data Account, Connection
Type, Username and Password. After editing and
saving the list, select Activate Profile to activate it.
Browser Options: Set Timeout and Show Images
options.
Service Message Settings: Set to accept or not to
a accept WAP service messages.
Clear Cache: Data or services that you have visited
will be saved in the cache memory of your mobile
phone. Please promptly clear these temporary
files that record your online data.
Clear Cookies: Data or services that you have
visited will be saved in the cookies of your mobile
phone. Please clear these temporary files that
record your online data.
Trusted Certificates: Display the trusted certificate.
If you try to access, or successfully accessed
confidential information that require a password
(such as a bank account), please remember to
clear your mobile phone's cache memory.
20
P699_EN 8/23/07, 5:17 PM21
Services
Loading...
