Compact Fluorescent Lamps Integrated

Philips Lamps and Gear Catalogue 2009/20106.2

Compact Fluorescent Lamps Integrated

Compact Fluorescent Lamps Integrated (CFL-I)

Energy savers to safeguard the world

Philips compact uorescent lamps with integral control gear

Philips invented compact uorescent energy savers (CFL-I) a quarter of a

century ago. Since then, continuous development has produced better light

quality, longer, more reliable life, lower mercury content and an increasingly

compact design. In addition, the range available has greatly expanded to meet

virtually all existing applications and even created new ones.

Today, compact uorescent lamps are increasingly used both indoors and

outdoors, summer and winter, for decorative and display purposes as well as for

providing easily-installed low-cost amenity lighting.

The first Philips energy savers were designed to replace ordinary incandescent filament lamps,

to combat rising energy costs following an oil crisis. Now, the need for CFL-I lamps is even

more fundamental - they also play a major role in combating climate change due to CO

emissions. So when you upgrade clients’ lighting from incandescent to CFL-I, you are doing

much more than simply reducing their lighting costs. You are playing your part in sustaining

precious resources, safeguarding the world for all our grandchildren to enjoy. All the benefits of

CFL-I are obtained simply by changing the lamp! Like incandescent lamps, they run direct from

the mains using a standard lamp cap. They produce the same amount of high-quality light as the

lamp they replace. But there the resemblance with incandescent lamps ends

• Compact fluorescent lamps can cut energy consumption by as much as 80%, saving a fortune

on energy bills and drastically reducing CO2 greenhouse gas emissions.

• Compact fluorescent lamps last between six and fifteen times longer than incandescent

lamps, saving you expensive relamping maintenance and the inconvenience of failed lamps.

• Compact fluorescents produce less heat than incandescent lamps, reducing discomfort as

well as airconditioning bills.

• Unlike incandescent lamps, many compact fluorescents are available in a choice of light

colour temperatures.

Compact Fluorescent Lamps Integrated

Note: Not all Compact fluorescent lamps with integral control gear are suitable for use with

external electronic devices.

6.3OEM Catalogue 2009/2010

MASTER PL-Electronic

MASTER PL-E 15W E27

Product Description

●

Non-covered energy-saving MASTER lamps for professional use

Product Features

●

Lightweight, superior long-life alternative to incandescent lamps

●

The perfect choice for end users that demand the best performance

and reliability

●

Average lifetime fifteen times longer than an incandescent lamp

●

European energy efficiency labelling class A for the complete range

●

Very good lumen maintenance throughout the lifetime of the lamp

●

Complete range equipped with the unique Philips bridged burner

technology (Mercury)

●

Verylowmercurycontent(≤2mg)

Product Benefits

●

Highest energy efficiency resulting in one-fifth the energy

consumption of an incandescent lamp for the same light output

●

Smallest dimensions ensuring optimal physical fit

●

Highest reliability throughout life which is especially beneficial where

lighting is required for longer periods of time and / or where lamp

replacement is difficult

●

The unique bridged burner results in an excellent run-up time with

very high initial light output and better thermal performance

●

Green product as best environmental choice in the CFL portfolio

●

Lifetime independent of switching on-off

●

Lowest total cost of ownership

Application

●

Designed to replace incandescent lamps in most professional and

semi-professional applications

●

Mainly indoor (e.g. hotels, restaurants, offices)

●

For outdoor applications 3 types (15, 20, 23 W) will remain available

also in Amalgam with the benefit of virtually constant light output

(>90%) over the recommended temperature

●

Enclosed fixtures are required for outdoor applications

●

Suitable for emergency lighting with DC supply

●

Not suitable for dimming and electronic devices

www.philips.com/OEM

OEM Catalogue 2009/20106.4

D D

MASTER PL-E B22

D D

MASTER PL-Electronic

Type CMax DMax FMax

MASTER PL-Electronic 8W/827 B22 230-240V 1CT 117.4 28.0 40.3

MASTER PL-Electronic 11W/827 B22 230-240V 1CT 139.4 28.0 40.3

MASTER PL-Electronic 14W/827 B22 230-240V 1CT 161.4 28.0 40.3

MASTER PL-E E14

MASTER PL-E E27

Type CMax DMax FMax

MASTER PL-Electronic 5W/827 E14 230-240V 1CT 117.2 28.0 40.3

MASTER PL-Electronic 8W/827 E14 230-240V 1CT 122.2 28.0 40.3

MASTER PL-Electronic 11W/827 E14 230-240V 1CT 144.2 28.0 40.3

Type CMax DMax FMax

MASTER PL-Electronic 5W/827 E27 230-240V 1CT 114.2 28.0 40.3

MASTER PL-Electronic 8W/827/865 E27 230-240V 1CT 119.2 28.0 40.3

MASTER PL-Electronic 11W/827/865 E27 230-240V 1CT 141.2 28.0 40.3

MASTER PL-Electronic 14W/827865 E27 230-240V 1CT 163.2 28.0 40.3

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.5

MASTER PL-Electronic

Technical data

Type Voltage

(V)

MASTER PL-Electronic 5W/827 E14/E27 230-240V 1CT 230-240 5 A No 15000

MASTER PL-Electronic 8W/827 E14/E27/B22 230-240V 1CT 230-240 8 A No 15000

MASTER PL-Electronic 8W/865 E27 230-240V 1CT 230-240 8 A No 12000

MASTER PL-Electronic 11W/827 E14/E27/B22 230-240V 1CT 230-240 11 A No 15000

MASTER PL-Electronic 11W/865 E27 230-240V 1CT 230-240 11 A No 12000

MASTER PL-Electronic 14W/827 E27/B22 230-240V 1CT 230-240 14 A No 15000

MASTER PL-Electronic 14W/865 E27 230-240V 1CT 230-240 14 A No 12000

MASTER PL-Electronic 15W/827 E27/B22 230-240V 1CT 230-240 15 A No 15000

MASTER PL-Electronic 15W/865 E27 230-240V 1CT 230-240 15 A No 12000

MASTER PL-Electronic 20W/827 E27/B22 230-240V 1CT 230-240 20 A No 15000

MASTER PL-Electronic 20W/840/865 E27 230-240V 1CT 230-240 20 A No 12000

MASTER PL-Electronic 23W/827 E27/B22 230-240V 1CT 230-240 23 A No 15000

MASTER PL-Electronic 23W/840/865 E27 230-240V 1CT 230-240 23 A No 12000

MASTER PL-Electronic 27W/827 E27 230-240V 1CT 230-240 27 A No 15000

MASTER PL-Electronic 27W/865 E27 230-240V 1CT 230-240 27 A No 12000

MASTER PL-Electronic 33W/827 E27 230-240V 1CT 230-240 33 A No 15000

MASTER PL-Electronic 33W/865 E27 230-240V 1CT 230-240 33 A No 12000

Rated

Lamp

Wattage

Energy

Efficiency

Label

Dimmable Life to

failures

50%

(hrs)

Light data

Type Luminous

flux

lamp

(lm)

MASTER PL-Electronic 5W/827 E14/E27 230-240V 1CT 230 46 Warm White 2700 82 470 428

MASTER PL-Electronic 8W/827 E14/E27/B22 230-240V 1CT 400 50 Warm White 2700 82 467 424

MASTER PL-Electronic 8W/865 E27 230-240V 1CT 380 48 Cool Daylight 6500 77 315 340

MASTER PL-Electronic 11W/827 E14/E27/B22 230-240V 1CT 600 55 Warm White 2700 82 466 422

MASTER PL-Electronic 11W/865 E27 230-240V 1CT 575 52 Cool Daylight 6500 77 315 340

MASTER PL-Electronic 14W/827 E27/B22 230-240V 1CT 900 64 Warm White 2700 82 466 422

MASTER PL-Electronic 14W/865 E27 230-240V 1CT 855 61 Cool Daylight 6500 77 315 340

MASTER PL-Electronic 15W/827 E27/B22 230-240V 1CT 875 56 Warm White 2700 82 457 416

MASTER PL-Electronic 15W/865 E27 230-240V 1CT 825 52.8 Cool Daylight 6500 76 315 340

MASTER PL-Electronic 20W/827 E27/B22 230-240V 1CT 1200 60 Warm White 2700 82 457 416

MASTER PL-Electronic 20W/840 E27 230-240V 1CT 1175 58.8 Cool White 4000 80 382 389

MASTER PL-Electronic 20W/865 E27 230-240V 1CT 1175 57.5 Cool Daylight 6500 76 315 340

MASTER PL-Electronic 23W/827 E27/B22 230-240V 1CT 1500 63 Warm White 2700 82 457 416

MASTER PL-Electronic 23W/840 E27 230-240V 1CT 1400 59.4 Cool White 4000 80 382 389

MASTER PL-Electronic 23W/865 E27 230-240V 1CT 1400 59.4 Cool Daylight 6500 76 315 340

MASTER PL-Electronic 27W/827 E27 230-240V 1CT 1800 62 Warm White 2700 82 457 416

MASTER PL-Electronic 27W/865 E27 230-240V 1CT 1700 58.6 Cool Daylight 6500 76 315 340

MASTER PL-Electronic 33W/827 E27 230-240V 1CT 2250 65.2 Warm White 2700 82 457 416

MASTER PL-Electronic 33W/865 E27 230-240V 1CT 2150 64.5 Cool Daylight 6500 76 315 340

Luminous

Efficacy

Lamp

(lm/W)

Colour

Designation

Colour

Temperature

Colour

Rendering

(K)

Index

(Ra)

Chromaticity

Coordinate X

Chromaticity

Coordinate Y

OEM Catalogue 2009/20106.6

MASTER PL-Electronic

Ordering and packing data

Type ILCOS EAN code

1 piece

MASTER PL-Electronic 5W/827 E14 230-240V 1CT FBT-5/27/1b-230/240-E14 8711500263568 60 gr 10 18.5 cm x 7.8 cm x 14.3 cm 8711500263575 263568 25

MASTER PL-Electronic 5W/827 E27 230-240V 1CT FBT-5/27/1b-230/240-E27 8711500263537 60 gr 10 18.5 cm x 7.8 cm x 14.3 cm 8711500263551 263537 25

MASTER PL-Electronic 8W/827 B22 230-240V 1CT FBT-8/27/1b-230/240-B22 8711500263636 60 gr 10 18.5 cm x 7.8 cm x 14.3 cm 8711500263643 263636 25

MASTER PL-Electronic 8W/827 E14 230-240V 1CT FBT-8/27/1b-230/240-E14 8711500263667 60 gr 10 18.5 cm x 7.8 cm x 14.3 cm 8711500263674 263667 25

MASTER PL-Electronic 8W/827 E27 230-240V 1CT FBT-8/27/1b-230/240-E27 8711500263582 60 gr 10 18.5 cm x 7.8 cm x 14.3 cm 8711500263599 263582 25

MASTER PL-Electronic 8W/865 E27 230-240V 1CT FBT-8/65/2a-230/240-E27 8711500263605 60 gr 10 18.5 cm x 7.8 cm x 14.3 cm 8711500263612 263605 25

MASTER PL-Electronic 11W/827 B22 230-240V 1CT FBT-11/27/1b-230/240-B22 8711500263759 71 gr 10 18.5 cm x 7.8 cm x 16.4 cm 8711500263766 263759 25

MASTER PL-Electronic 11W/827 E14 230-240V 1CT FBT-11/27/1b-230/240-E14 8711500263773 63 gr 10 18.5 cm x 7.8 cm x 16.4 cm 8727900213737 263773 25

MASTER PL-Electronic 11W/827 E27 230-240V 1CT FBT-11/27/1b-230/240-E27 8711500263681 71 gr 10 18.5 cm x 7.8 cm x 16.4 cm 8711500263698 263681 25

MASTER PL-Electronic 11W/865 E27 230-240V 1CT FBT-11/65/2a-230/240-E27 8711500263735 71 gr 10 18.5 cm x 7.8 cm x 16.4 cm 8711500263742 263735 25

MASTER PL-Electronic 14W/827 B22 230-240V 1CT FBT-14/27/1b-230/240-B22 8711500263841 76 gr 10 18.5 cm x 7.8 cm x 18.5 cm 8711500263858 263841 25

MASTER PL-Electronic 14W/827 E27 230-240V 1CT FBT-14/27/1b-230/240-E27 8711500263797 76 gr 10 18.5 cm x 7.8 cm x 18.5 cm 8711500263803 263797 25

MASTER PL-Electronic 14W/865 E27 230-240V 1CT FBT-14/65/2a-230/240-E27 8711500263810 76 gr 10 18.5 cm x 7.8 cm x 18.5 cm 8711500263827 263810 25

MASTER PL-Electronic 15W/827 B22 230-240V 1CT FBT 15/27/1b-230/240-b22 8711500752055 84 gr 6 16 cm x 11 cm x 14.7 cm 8711500714817 752055 10

MASTER PL-Electronic 15W/827 E27 230-240V 1CT FBT 15/27/1b-230/240-E27 8711500751423 84 gr 6 16 cm x 11 cm x 14.7 cm 8711500761392 751423 10

MASTER PL-Electronic 15W/865 E27 230-240V 1CT FBT 15/65/2a-230/240-E27 8711500869203 84 gr 6 16 cm x 11 cm x 14.7 cm 8711500869210 869203 10

MASTER PL-Electronic 20W/827 B22 230-240V 1CT FBT 15/27/1b-230/240-B22 8711500752062 91 gr 6 16 cm x 11 cm x 15.8 cm 8711500714824 752062 10

MASTER PL-Electronic 20W/827 E27 230-240V 1CT FBT 20/27/1b-230/240-E27 8711500751430 91 gr 6 16 cm x 11 cm x 15.8 cm 8711500761408 751430 10

MASTER PL-Electronic 20W/840 E27 230-240V 1CT FBT 20/40/1b-230/240-E27 8711500873590 91 gr 6 16 cm x 11 cm x 15.8 cm 8711500873606 873590 10

MASTER PL-Electronic 20W/865 E27 230-240V 1CT FBT 20/65/2a-230/240-E27 8711500712226 91 gr 6 16 cm x 11 cm x 15.8 cm 8711500764836 712226 10

MASTER PL-Electronic 23W/827 B22 230-240V 1CT FBT 23/27/1b-230/240-B22 8711500752079 98 gr 6 16 cm x 11 cm x 17.3 cm 8711500714862 752079 10

MASTER PL-Electronic 23W/827 E27 230-240V 1CT FBT 23/27/1b-230/240-E27 8711500751447 98 gr 6 16 cm x 11 cm x 17.3 cm 8711500761415 751447 10

MASTER PL-Electronic 23W/840 E27 230-240V 1CT FBT 23/40/1b-230/240-E27 8711500873613 98 gr 6 16 cm x 11 cm x 17.3 cm 8711500873682 873613 10

MASTER PL-Electronic 23W/865 E27 230-240V 1CT FBT 23/65/2a-230/240-E27 8711500712233 98 gr 6 16 cm x 11 cm x 17.3 cm 8711500764850 712233 10

MASTER PL-Electronic 27W/827 E27 230-240V 1CT FBT 27/27/1b-230/240-E27 8711500543851 121 gr 6 16 cm x 11 cm x 19.5 cm 8711500543608 543851 10

MASTER PL-Electronic 27W/865 E27 230-240V 1CT FBT 27/65/2a-230/240-E27 8711500543899 121 gr 6 16 cm x 11 cm x 19.5 cm 8711500543615 543899 10

MASTER PL-Electronic 33W/827 E27 230-240V 1CT FBT 35/27/1b-230/240-E27 8711500659996 125 gr 6 16 cm x 11 cm x 21.5 cm 8727900210378 659996 10

MASTER PL-Electronic 33W/865 E27 230-240V 1CT FBT 35/65/2a-230/240-E27 8727900210354 125 gr 6 16 cm x 11 cm x 21.5 cm 8727900210361 210354 10

Weight Qty bulk

packing

Dimensions bulk packing EAN code

bulk packing

8711500

EOC

Compact Fluorescent Lamps Integrated

Cap Base

E14

E27

B22

OEM Catalogue 2009/2010 6.7

MASTER PL-Electronic Dimmable

MASTER PL-E Dimmable 20W E27

Product Description

●

Non-covered energy-saving MASTER lamp of adjustable light output,

applicable for use with standard wall dimmers in professional

applications

Product Features

●

Long-life alternative to incandescent lamps

●

Dimmable down to 10-15% of nominal light output

●

The perfect choice for end users that demand the best performance

and reliability

●

Average lifetime fifteen times longer than an incandescent lamp

●

Equipped with the unique Philips bridged burner technology

●

Very good lumen maintenance throughout lamp life

●

Verylowmercurycontent(≤2mg)

●

European energy efficiency label A

Product Benefits

●

Extra ambience creation when using MASTER PL-Electronic

Dimmable lamp in dimmable mode

●

Highest energy efficiency resulting in one-fifth the energy

consumption of an incandescent lamp for the same rated light

output

●

Additional energy saving effect in dimming mode

●

Highest reliability throughout life which is especially beneficial where

lighting is required for longer periods of time and / or where lamp

replacement is difficult

●

The unique bridged burner results in an excellent run-up time with

very high initial light output and better thermal performance

●

Lifetime independent of switching on-off

●

Green product as best environmental choice in the CFL portfolio

●

Lowest total cost of ownership

Applications

●

Designed to replace incandescent lamps in most professional and

semi-professional applications, especially those equipped with triac

dimmers

●

Mainly indoor (e.g. hotels, restaurants, offices)

●

Enclosed fixtures are required for outdoor application

www.philips.com/OEM

OEM Catalogue 2009/20106.8

MASTER PL-E Dimmable E27

MASTER PL-Electronic Dimmable

Type CMax DMax FMax

MASTER PL-Electronic Dimmable 20W/827 E27 1CT 147.2 39.8 48.0

Type CMax DMax FMax

MASTER PL-Electronic Dimmable 20W/827 B22 1CT 145.7 39.8 48.0

MASTER PL-E Dimmable B22

Technical data

Type Voltage

(V)

MASTER PL-Electronic Dimmable 20W/827 E27/B22 1CT 230-240 20 A Yes 15000

Rated

Lamp

Wattage

Energy

Efficiency

Label

Dimmable Life to

50%

failures

(hrs)

Light data

Type Luminous

flux

lamp

(lm)

MASTER PL-Electronic Dimmable 20W/827 E27/B22 1CT 1200 60 Warm White 2700 82 460 425

Luminous

Efficacy

Lamp

(lm/W)

Colour

Designation

Colour

Temperature

Colour

Rendering

(K)

Index

(Ra)

Chromaticity

Coordinate X

Chromaticity

Coordinate Y

Compact Fluorescent Lamps Integrated

Ordering and packing data

Type ILCOS EAN code

1 piece

MASTER PL-Electronic Dimmable 20W/827 B22 1CT FBT-20/27/1b-230/240-B22 8711500660596 91 gr 6 16 cm x 11 cm x 15.8 cm 8711500660534 660596 10

MASTER PL-Electronic Dimmable 20W/827 E27 1CT FBT-20/27/1b-230/240-E27 8711500660213 91 gr 6 16 cm x 11 cm x 15.8 cm 8711500660220 660213 10

Weight Qty bulk

packing

Dimensions bulk packing EAN code

bulk packing

8711500

Cap Base

E27

B22

OEM Catalogue 2009/2010 6.9

EOC

Tornado Mini Decorative

YEARS*

More and brighter light, smallest in size

•

New premium range in 5W, 8W and 12W

•

20% more and brighter light and is 25% smaller in size when

compared to the Genie range

•

Perfect decorative fit for small and open luminaires

Up to 80% energy saving

•

The new Tornado Mini range can replace 25W up to 60W

incandescent bulbs for instant energy savings of up to 80%

Long Life: 8 years

•

Up to 8 times longer life when compared to normal incandescent

lamps

•

1 year guarantee

•

Safety fuse and flicker-free start

Best environmental choice

•

The Tornado Mini range is fully RoHS compliant, conforming to the

most strict environmental leglislation in the world

Tornado Mini

Applications

•

The Tornado Mini range is widely used to replace incandescent light

bulbs in all kinds of applications, especially where intensive light

output is required

•

Enclosed luminaires are required for outdoor use

•

Not suitable for dimmers, electronic switches or remote controls

Type C F

Tornado Mini 5W 40 77

Tornado Mini 8W 40 84

Tornado Mini 12W 40 91

Tornado Mini 5W-12W

OEM Catalogue 2009/20106.10

Tornado Mini Decorative

Preferred selection

Product ID Lamp

Wattage

(W)

Cool Daylight

Tornado Mini 5W B22 220-240V 50-60Hz 6500 285 57 80 12 39441115

Tornado Mini 5W E14 220-240V 50-60Hz 6500 285 57 80 12 39447315

Tornado Mini 5W E27 220-240V 50-60Hz 6500 285 57 80 12 39435015

Tornado Mini 8W B22 220-240V 50-60Hz 6500 475 59 80 12 39443515

Tornado Mini 8W E14 220-240V 50-60Hz 6500 475 59 80 12 39449715

Tornado Mini 8W E27 220-240V 50-60Hz 6500 475 59 80 12 39437415

Tornado Mini 12W B22 220-240V 50-60Hz 6500 685 62 80 12 39445915

Tornado Mini 12W E14 220-240V 50-60Hz 6500 685 62 80 12 39451015

Tornado Mini 12W E27 220-240V 50-60Hz 6500 685 62 80 12 39439815

Warm White

Tornado Mini 5W B22 220-240V 50-60Hz 2700 300 60 82 12 39440415

Tornado Mini 5W E14 220-240V 50-60Hz 2700 300 60 82 12 39446615

Tornado Mini 5W E27 220-240V 50-60Hz 2700 300 60 82 12 39434315

Tornado Mini 8W B22 220-240V 50-60Hz 2700 500 62 82 12 39442815

Tornado Mini 8W E14 220-240V 50-60Hz 2700 500 62 82 12 39448015

Tornado Mini 8W E27 220-240V 50-60Hz 2700 500 62 82 12 39436715

Tornado Mini 12W B22 220-240V 50-60Hz 2700 725 65 80 12 39444215

Tornado Mini 12W E14 220-240V 50-60Hz 2700 725 65 82 12 39450315

Tornado Mini 12W E27 220-240V 50-60Hz 2700 725 65 82 12 39438115

Cap/

Base

Lamp

Voltage

Frequency

(V)

(Hz)

Colour

Temp.

Lumen

(K)

Output

(Lm)

Luminous

Efficacy

(Lm/W)

Rendering

Index

(Ra)

Box

quantity

pcs

8710163

Order

Code

Compact Fluorescent Integrated Lamps

OEM Catalogue 2009/2010 6.11

Tornado Decorative

YEARS*

Tornado

More and brighter light, decorative shape

•

Distinct, decorative shape, creating a modern look

•

The spiral shape allows for more and better light distribution,

offering up to 20% more and brighter light compared to Genie

energy savers

Up to 80% energy saving

•

The Tornado range can replace 60W up to 125W incandescent

lamps for energy savings up to 80%

Long Life: 8 years

•

Up to 8 times longer when compared to incandescent lamps

•

1 year guarantee

Best environmental choice

•

The Tornado range is fully RoHS compliant, conforming to the most

strict environmental legislation in the world

Applications

•

The Tornado range is widely used to replace incandescent light bulbs

in all kinds of applications, especially where intensive light output is

required

•

Enclosed luminaires are required for outdoor use

•

Not suitable for dimmers, electronic switches or remote controls

Tornado

Type C F

Tornado 11W 44 700

Tornado 15W 44 1000

Tornado 20W 48 1350

Tornado 23W 48 1550

OEM Catalogue 2009/20106.12

Tornado Decorative

Preferred selection

Product ID Lamp

Wattage

(W)

Cool Daylight

Tornado 11W B22 220-240V 50-60Hz 6500 660 60 80 60W 12 39657615

Tornado 11W E27 220-240V 50-60Hz 6500 660 60 80 60W 12 39653815

Tornado 15W E27 220-240V 50-60Hz 6500 950 60 80 75W 12 39655215

Tornado 15W B22 220-240V 50-60Hz 6500 950 60 80 75W 12 39659015

Tornado 20W E27 220-240V 50-60Hz 6500 1250 63 80 100W 12 39661315

Tornado 20W B22 220-240V 50-60Hz 6500 1250 63 80 100W 12 39665115

Tornado 23W E27 220-240V 50-60Hz 6500 1450 63 80 125W 12 39663715

Tornado 23W B22 220-240V 50-60Hz 6500 1450 63 80 125W 12 39667515

Warm White

Tornado 11W E27 220-240V 50-60Hz 2700 700 64 82 60W 12 39652115

Tornado 11W B22 220-240V 50-60Hz 2700 700 64 82 60W 12 39656915

Tornado 15W E27 220-240V 50-60Hz 2700 1000 63 82 75W 12 39654515

Tornado 15W B22 220-240V 50-60Hz 2700 1000 63 82 75W 12 39658315

Tornado 20W E27 220-240V 50-60Hz 2700 1350 67 82 100W 12 39660615

Tornado 20W B22 220-240V 50-60Hz 2700 1350 67 82 100W 12 39664415

Tornado 23W E27 220-240V 50-60Hz 2700 1550 67 80 125W 12 39662015

Tornado 23W B22 220-240V 50-60Hz 2700 1550 67 82 125W 12 39666815

Cap/

Base

Lamp

Voltage

Frequency

(V)

(Hz)

Colour

Temp.

Luminous

(K)

Flux

(Lm)

Luminous

Efficacy

(Lm/W)

Rendering

Index

(Ra)

Incandescent

Equivalent

Box

quantity

pcs

8710163

Order

Code

Compact Fluorescent Integrated Lamps

OEM Catalogue 2009/2010 6.13

MASTER ECOTONE High Lumen Twister

YEARS*

High Lumen output for professional use

• The MASTER Ecotone High Twister is the perfect energy saving

solutions to replace conventional HPL and ML lamps offering

brighter and better quality of light

Up to 70% energy saving

• The Twister range provides up to 70% energy savings when

compared to ML 160W and 250W and for 20% energy savings and

70% better colour rending when compared to HPL-N 80W and

125W

Long Life: 10 Years

• Long and reliable life of 10000 hrs, with a stable and constant light

output

Best Environmental choice

• Fully RoHS compliant conforming to the most strict environmental

legislation in the world

High Lumen Twister

Applications

• Designed for professional applications in shops, industry and

outdoor

• Enclosed fixtures

• Not suitable for dimmers, electronic switches or electronic devices/

remote controls

• Safe in use, fully compliant to IEC and EMC Standards, HPF > 0.95

www.philips.com/OEM

High Lumen Twister

OEM Catalogue 2009/20106.14

Type C F

High Lumen Twister 45W 204 80

High Lumen Twister 65W 220 80

High Lumen Twister 80W 261 88

Preferred selection

Type Lamp

Wattage

Cool Daylight

MASTER ECOTONE

High Lumen Twister

MASTER ECOTONE

High Lumen Twister

MASTER ECOTONE

High Lumen Twister

MASTER ECOTONE High Lumen Twister

Cap/

Base

(W)

45W E27 220-240V 6500 2850 67 80 ML 160W-HPL-N 80W 6 21266110

65W E27 220-240V 6500 4000 65 80 ML 160W-250W-HPL-N 80W 6 21268510

80W E40 220-240V 6500 5300 66 80 ML 250W-HPL-N 125W 6 15963810

Lamp

Voltage

Colour

(V)

Temp.

(K)

Luminous

Flux

(Lm)

Luminous

Efficacy

(Lm/W)

Colour

Rendering

Index

(Ra)

Equivalent

light

output to

Box

quantity

Order Code

8710163

Cool White

MASTER ECOTONE

High Lumen Twister

MASTER ECOTONE

High Lumen Twister

MASTER ECOTONE

High Lumen Twister

Compact Fluorescent Lamps Integrated

45W E27 220-240V 4000 3000 67 82 ML 160W-HPL-N 80W 6 21265410

65W E27 220-240V 4000 4000 65 82 ML 160W-250W-HPL-N 80W 6 21267810

80W E40 220-240V 4000 5600 70 82 ML 250W-HPL-N 125W 6 15962110

OEM Catalogue 2009/2010 6.15

Genie Compact

YEARS*

Small size, fits any lamp shade in your home

•

The Genie range is the top choice deu to its small and compact size

•

20% smaller when compared to the Essential range, for perfect fit in

small luminaires

•

New lamp cap design for a refined, more sophisticated appearance

with embossed Philips marking

Up to 80% energy saving

•

The Genie range can replace the full incandescent range from 25W

up to 100W for energy saving of up to 80%, whilst maintaining a high

quality of light

Long Life: 8 years

•

Up to 8 times longer when compared to normal incandescent lamps

•

1 year guarantee

•

Safety fuse for instant and flickerfree start

Best environmental choice

•

The Genie range is fully RoHS complaint, conforming to the most

strict environmental legislation in the world

Genie 14W/18W

Applications

•

The Genie range is widely used to replace incandescent light bulbs

in indoor fixtures, table fixtures and other consumer or (semi)

professional applications that require small sized lamps

•

Enclosed luminaires are required for outdoor use

•

Not suitable for dimmers, electronic switches or remote controls

•

Safety fuse for instant and flicker free start

Type C F

Genie 5W 105 37

Genie 8W 105 44

Genie 11W 115 44

Genie 14W 130 44

Genie 18W 133 48

Genie

OEM Catalogue 2009/20106.16

Genie Compact

Preferred selection

Product ID Lamp

Wattage

(W)

Cool Daylight

Genie 5W E27 220-240V 50-60Hz 6500 235 47 80 25W 12 39357534

Genie 5W E14 220-240V 50-60Hz 6500 235 47 80 25W 12 39361234

Genie 5W B22 220-240V 50-60Hz 6500 235 47 80 25W 12 39359934

Genie 8W E27 220-240V 50-60Hz 6500 415 52 80 40W 12 39363634

Genie 8W E14 220-240V 50-60Hz 6500 415 52 80 40W 12 39367434

Genie 8W B22 220-240V 50-60Hz 6500 415 52 80 40W 12 39365034

Genie 11W E14 220-240V 50-60Hz 6500 600 54 80 60W 12 39373534

Genie 11W E27 220-240V 50-60Hz 6500 600 54 80 60W 12 39369834

Genie 11W B22 220-240V 50-60Hz 6500 600 54 80 60W 12 39371134

Genie 14W E27 220-240V 50-60Hz 6500 790 56 80 75W 12 39375934

Genie 14W B22 220-240V 50-60Hz 6500 790 56 80 75W 12 39377334

Genie 18W E27 220-240V 50-60Hz 6500 1040 58 80 100W 12 39379734

Genie 18W B22 220-240V 50-60Hz 6500 1040 58 80 100W 12 39381034

Cap/

Base

Lamp

Voltage

Frequency

(V)

(Hz)

Colour

Temp.

Luminous

Flux

(K)

(Lm)

Efficacy

(Lm/W)

Colour

Rendering

Index

(Ra)

Incandescent

Equivalent

Box

quantity

8710163

Order

Code

Compact Fluorescent Integrated Lamps

Warm White

Genie 5W E27 220-240V 50-60Hz 2700 250 50 82 25W 12 39356834

Genie 5W E14 220-240V 50-60Hz 2700 250 50 82 25W 12 39360534

Genie 5W B22 220-240V 50-60Hz 2700 250 50 82 25W 12 39358234

Genie 8W E27 220-240V 50-60Hz 2700 440 55 82 40W 12 39362934

Genie 8W E14 220-240V 50-60Hz 2700 440 55 82 40W 12 39366734

Genie 8W B22 220-240V 50-60Hz 2700 440 55 82 40W 12 39364334

Genie 11W E14 220-240V 50-60Hz 2700 610 55 82 60W 12 39372834

Genie 11W E27 220-240V 50-60Hz 2700 610 55 82 60W 12 39368134

Genie 11W B22 220-240V 50-60Hz 2700 610 55 82 60W 12 39370434

Genie 14W E27 220-240V 50-60Hz 2700 840 60 82 75W 12 39374234

Genie 14W B22 220-240V 50-60Hz 2700 840 60 82 75W 12 39376634

Genie 18W E27 220-240V 50-60Hz 2700 1100 61 82 100W 12 39378034

Genie 18W B22 220-240V 50-60Hz 2700 1100 61 82 100W 12 39380334

OEM Catalogue 2009/2010 6.17

Genie Long Life

Genie Long Life 18W

YEARS*

Top-level performance, High switches

• Compact high quality energy saver for extra long and reliable

performance

• Frequent turning on/off, up to 15000 times for long life

•

Up to 80% energy saving

• The Genie Long Life range can replace 25W up to 75W

incandescent equivalents for energy savings of up to 80%

Long life: 12 Years

• Up to 12 times longer when compared to incandescent lamp, for

less maintenance and replacements costs

•

1 year guarantee

• Safety fuse and flicker free start

Best environmental choice

• The Genie Long Life range is fully RoHS compliant conforming to

the most strict environmental legislation in the world

Applications

• The Genie Long Life range is widely used to replace incandescent

lamp

• The long lifetime and 15000 switching cycles is ideal for applications

where lamps are frequently switched on/off. Especially suitable for

hotel applications like lobby, rooms, corridors, restaurant

• Enclosed luminaires are required for outdoor use

• Not suitable for dimmers

www.philips.com/OEM

Typ e C F

Genie Long Life E27/B22 5W 105 37

Genie Long Life E27/B22 8W 105 44

Genie Long Life E27/B22 11W 115 44

Genie Long Life E27/B22 14W 130 44

Genie Long Life E27/B22 18W 133 48

Genie Long Life

OEM Catalogue 2009/20106.18

Genie Long Life

Preferred selection

Type Lamp

Wattage

(W)

Cool Daylight

Genie Long Life 5W E27 220-240V 50-60Hz 6500 235 47 80 25W 48 39705415

Genie Long Life 5W B22 220-240V 50-60Hz 6500 235 47 80 25W 48 39713915

Genie Long Life 8W E27 220-240V 50-60Hz 6500 415 52 80 40W 48 39707815

Genie Long Life 8W B22 220-240V 50-60Hz 6500 415 52 80 40W 48 39715315

Genie Long Life 11W E27 220-240V 50-60Hz 6500 600 54 80 60W 48 39709215

Genie Long Life 11W B22 220-240V 50-60Hz 6500 600 54 80 60W 48 39717715

Genie Long Life 14W E27 220-240V 50-60Hz 6500 790 56 80 75W 48 39711515

Genie Long Life 14W B22 220-240V 50-60Hz 6500 790 56 80 75W 48 39719115

Genie Long Life 18W E27 220-240V 50-60Hz 6500 1040 58 80 100W 48 40151515

Genie Long Life 18W B22 220-240V 50-60Hz 6500 1040 58 80 100W 48 40153915

Warm White

Genie Long Life 5W E27 220-240V 50-60Hz 2700 250 50 82 25W 48 39704715

Genie Long Life 5W B22 220-240V 50-60Hz 2700 250 50 82 25W 48 39712215

Genie Long Life 8W E27 220-240V 50-60Hz 2700 440 55 82 40W 48 39706115

Genie Long Life 8W B22 220-240V 50-60Hz 2700 440 55 82 40W 48 39714615

Genie Long Life 11W E27 220-240V 50-60Hz 2700 610 55 82 60W 48 39708515

Genie Long Life 11W B22 220-240V 50-60Hz 2700 610 55 82 60W 48 39716015

Genie Long Life 14W E27 220-240V 50-60Hz 2700 840 60 82 75W 48 39710815

Genie Long Life 14W B22 220-240V 50-60Hz 2700 840 60 82 75W 48 39718415

Genie Long Life 18W E27 220-240V 50-60Hz 2700 1100 61 82 100W 48 40150815

Genie Long Life 18W E27 220-240V 50-60Hz 2700 1100 61 82 100W 48 40152215

Cap/

Base

Lamp

Voltage

Frequency

(V)

(Hz)

Colour

Temp.

Luminous

(K)

(Lm)

Flux

Luminous

Efficacy

(Lm/W)

Colour

Rendering

Index

(Ra)

Incandescent

Equivalent

Box

quantity

pcs

8710163

Order

Code

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.19

MASTER PL-Electronic Polar

MASTER PL-E Polar 15W E27

Product Description

●

Covered energy-saving MASTER lamps for professional use in

outdoor applications

Product Features

●

Long-life alternative to incandescent lamps

●

Amalgam technology enabling excellent, virtually constant lumen

performance in a wide range of ambient temperatures

●

The perfect choice for end users that demand the best performance

and reliability

●

Average lifetime fifteen times longer than an incandescent lamp

●

Very good lumen maintenance throughout the lifetime of the lamp

●

Complete range equipped with the unique Philips bridged burner

technology

●

Verylowmercurycontent(≤2mg)

●

European energy efficiency label A for the complete range

Product Benefits

●

Very good performance in the lower ambient temperature range

(the lamp gives no less than 90% of nominal lumen in temperatures

between –20 and +40 ºC), rendering the lamp especially suitable for

outdoor applications

●

Highest energy efficiency resulting in one-fifth the energy

consumption of an incandescent lamp for the same light output

●

Highest reliability throughout life which is especially beneficial where

lighting is required for longer periods of time and / or where lamp

replacement is difficult

●

Lifetime independent of switching on-off

●

Green product as best environmental choice in the CFL portfolio

●

Lowest total cost of ownership

Applications

●

Designed to replace incandescent lamps in most professional and

semi- professional applications

●

Outdoor (e.g. outdoor hotel lighting, parking lots, restaurant/café

gardens, patios, garden / lawn lighting)

●

Enclosed fixtures are required for outdoor applications

●

Not suitable for dimming and electronic devices

www.philips.com/OEM

OEM Catalogue 2009/20106.20

MASTER PL-E Polar E27

MASTER PL-Electronic Polar

Type CMax DMax FMax

MASTER PL-Electronic Polar 15W/827 E27 1CT 132.0 50.8 48.0

MASTER PL-Electronic Polar 20W/827 E27 1CT 143.0 50.8 48.0

MASTER PL-Electronic Polar 23W/827 E27 1CT 158.0 50.8 48.0

Technical data

Type Voltage

(V)

MASTER PL-Electronic Polar 15W/827 E27 1CT 230-240 15 A No 15000

MASTER PL-Electronic Polar 20W/827 E27 1CT 230-240 20 A No 15000

MASTER PL-Electronic Polar 23W/827 E27 1CT 230-240 23 A No 15000

Rated

Lamp

Wattage

Energy

Efficiency

Label

Dimmable Life to

50%

failures

(hrs)

Light data

Type Luminous

flux

lamp

(lm)

MASTER PL-Electronic Polar 15W/827 E27 1CT 875 56 Warm White 2700 82 457 416

MASTER PL-Electronic Polar 20W/827 E27 1CT 1200 64 Warm White 2700 82 457 416

MASTER PL-Electronic Polar 23W/827 E27 1CT 1485 63 Warm White 2700 82 457 416

Luminous

Efficacy

Lamp

(lm/W)

Colour

Designation

Colour

Temperature

Colour

Rendering

(K)

Index

(Ra)

Chromaticity

Coordinate X

Chromaticity

Coordinate Y

Ordering and packing data

Type ILCOS EAN code

1 piece

MASTER PL-Electronic Polar 15W/827 E27 1CT FBT-15/27/1b-230/240-E27 8711500660459 117 gr 6 18.1 cm x 12.3 cm x 15.8 cm 8711500660527 660459 10

MASTER PL-Electronic Polar 20W/827 E27 1CT FBT-20/27/1b-230/240-E27 8711500660039 130 gr 6 18.1 cm x 12.3 cm x 16 cm 8711500831583 660039 10

MASTER PL-Electronic Polar 23W/827 E27 1CT FBT-23/27/1b-230/270-E27 8711500660053 143 gr 6 18.1 cm x 12.3 cm x 18.4 cm 8711500831606 660053 10

Weight Qty bulk

packing

Dimensions bulk packing EAN code

bulk packing

8711500

Compact Fluorescent Lamps Integrated

EOC

Cap Base

E27

OEM Catalogue 2009/2010 6.21

MASTER PL-Electronic Automatic

MASTER PL-E Automatic 11W/15W E27 Pri

Product Description

●

Covered energy-saving MASTER lamp for (semi-) professional use

with built-in light sensor, switches on when it is dark, switches off in

daylight

Product Features

●

Long-life alternative to incandescent lamps, once connected to mains

electricity it automatically switches on when it is dark and switches

off in daylight

●

The perfect choice for end users that demand the best performance

and reliability

●

Average lifetime fifteen times longer than an incandescent lamp

●

European energy efficiency labelling class A

●

Very good lumen maintenance throughout the lifetime of the lamp

●

Virtually constant light output (>90%) over recommended

temperature range

●

Verylowmercurycontent(≤2mg)

Product Benefits

●

Simplicity of use; once installed it switches on-off automatically at

certain daylight level

●

Highest energy efficiency resulting in one-fifth the energy

consumption of an incandescent lamp for the same light output

●

Highest reliability throughout life which is especially beneficial where

lighting is required for longer periods of time and / or where lamp

replacement is difficult

●

Lifetime independent of switching on-off

●

Green product as best environmental choice in the CFL portfolio

●

Lowest total cost of ownership

MASTER PL-E Automatic E27

Application

●

Designed to replace incandescent lamps in most professional and

semi-professional applications

●

Mainly outdoor (e.g. outdoor hotel lighting, parking lots, restaurant /

café gardens, patios, garden / lawn lighting)

●

Enclosed fixtures are required for outdoor applications

●

Not suitable for dimming and electronic devices

www.philips.com/OEM

Type CMax DMax FMax

MASTER PL-Electronic Automatic 11W/827 E27 1CT 141.0 50.8 48.0

OEM Catalogue 2009/20106.22

MASTER PL-E Automatic B22

MASTER PL-Electronic Automatic

Type CMax DMax FMax

MASTER PL-Electronic Automatic 11W/827 B22 1CT 139.5 50.8 48.0

Technical data

Type Voltage

(V)

MASTER PL-Electronic Automatic 11W/827 E27/B22 1CT 230-240 11 A No 15000

MASTER PL-Electronic Automatic 15W/827 E27/B22 1CT 230-240 15 A No 15000

Rated

Lamp

Wattage

Energy

Efficiency

Label

Dimmable Life to

50%

failures

(hrs)

Light data

Type Luminous

Flux Lamp

(lm)

MASTER PL-Electronic Automatic 11W/827 E27/B22 1CT 600 54 Warm White 2700 82 457 416

MASTER PL-Electronic Automatic 15W/827 E27/B22 1CT 900 60 Warm White 2700 82 457 416

Luminous

Efficacy

Lamp EM

(lm/W)

Colour

Designation

Colour

Temperature

Colour

Rendering

(K)

Index

(Ra)

Chromaticity

Coordinate X

Chromaticity

Coordinate Y

Ordering and packing data

Type ILCOS EAN code

1 piece

MASTER PL-Electronic Automatic 11W/827 B22 1CT FBT-11/27/1b-230/240-B22 8711500260595 117 gr 6 16.4 cm x 11.3 cm x 16.9 cm 260595 10

MASTER PL-Electronic Automatic 11W/827 E27 1CT FBT-11/27/1b-230/240-E27 8711500260588 117 gr 6 16.4 cm x 11.3 cm x 16.9 cm 260588 10

MASTER PL-Electronic Automatic 15W/827 B22 1CT FBT-15/27/1b-230/240-B22 8711500260618 130 gr 6 16.4 cm x 11.3 cm x 16.9 cm 260618 10

MASTER PL-Electronic Automatic 15W/827 E27 1CT FBT-15/27/1b-230/240-E27 8711500260601 130 gr 6 16.4 cm x 11.3 cm x 16.9 cm 260601 10

Weight Qty bulk

packing

Dimensions bulk packing EOC

8711500

Cap Base

Compact Fluorescent Lamps Integrated

E27

B22

OEM Catalogue 2009/2010 6.23

Ambiance Standard Shape

YEARS*

Ambiance Standard Shape

Attractive modern design in a classic shape

• The Ambiance range offers a decorative appeal to complement

elegant, modern light fittings in homes, restaurants and hotels

• An elegant cover for a comfortable low glare light that is soft on the

eyes

• In a familiar standard shape, simular in size to their incandescent

equivalent

Up to 80% energy saving

• The Ambiance range with classic shape is an ideal replacement for

incandescent bulbs of 25W up to 75W, saving up to 80% on energy

consumption

Long Life: 6 Years

• 6000 hrs. Up to 6 times longer when compared to incandescent

lamps

• 1 year guarantee, safety fuse and flicker free start

Best Environmental choice

• The Ambiance Standard range is fully RoHS compliant conforming to

the most strict environmental leglislation in the world

Applications

• Designed for replacement of incandescent lamps in standard shape

for decorative and functional indoor applications

• Enclosed fixtures are required for outdoor applications

• Not suitable for dimming and electronic devices

Ambiance 5W-11W

www.philips.com/OEM

Type C F

5W 106 45

8W 106 45

11W 106 45

OEM Catalogue 2009/20106.24

Ambiance 14W-18W

Ambiance Standard Shape

Type C F

14W 106 50

18W 106 50

Preferred selection

Type Lamp

Wattage

(W)

Cool Daylight

Ambiance 5W E27 50-60Hz 6500 80 190 38 No 40163815

Ambiance 5W B22 50-60Hz 6500 80 190 38 No 40165215

Ambiance 8W E27 50-60Hz 6500 80 380 47 No 40167615

Ambiance 8W B22 50-60Hz 6500 80 380 47 No 40169015

Ambiance 11W E27 50-60Hz 6500 80 540 49 No 40171315

Ambiance 11W B22 50-60Hz 6500 80 540 49 No 40173715

Ambiance 14W E27 50-60Hz 6500 80 780 56 No 40211610

Ambiance 14W B22 50-60Hz 6500 80 780 56 No 40213010

Ambiance 18W E27 50-60Hz 6500 80 1000 56 No 40215410

Ambiance 18W B22 50-60Hz 6500 80 1000 56 No 40217810

Warm White

Ambiance 5W E27 50-60Hz 2700 80 190 38 No 40162115

Ambiance 5W B22 50-60Hz 2700 80 190 38 No 40164515

Ambiance 8W E27 50-60Hz 2700 80 370 46 No 40166915

Ambiance 8W B22 50-60Hz 2700 80 370 46 No 40168315

Ambiance 11W E27 50-60Hz 2700 80 570 51 No 40170615

Ambiance 11W B22 50-60Hz 2700 80 570 51 No 40172015

Ambiance 14W E27 50-60Hz 2700 80 820 59 No 40210910

Ambiance 14W B22 50-60Hz 2700 80 820 59 No 40212310

Ambiance 18W E27 50-60Hz 2700 80 1050 58 No 40214710

Ambiance 18W B22 50-60Hz 2700 80 1050 58 No 40216110

Cap/

Base*

Frequency

(Hz)

Colour

Temperature

Colour

Rendering

(K)

Index

(Ra)

Light

Output

(Lumen)

Efficacy

(Lm/W)

Dimmable Order Code

8710163

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.25

Ambiance Coloured

YEARS*

A choice of very attractive colours

• Coloured decorative energy-saving range is available in four bright

colours: red, green, yellow and blue

• For original lighting effects and decorative ambiances for a multitude

of occasions and applications

Colours that save up to 80% on energy

• The Ambiance Coloured range brings you both colours and energy

savings up to 80%

• Long reliable life up to 6000 hrs which is up to 6 times longer life

compared to normal incandescent lamps

Suitable for many application areas

• Ambiance Coloured energy savers can be used in a wide range

of decorative applications, both outdoor and indoor, e.g. streets,

facades, shopping centres, parties and special celebrations

• Not suitable for dimming and electronic devices

Ambiance Coloured

www.philips.com/OEM

Ambiance Coloured

OEM Catalogue 2009/20106.26

Type C F

Ambiance Coloured 124 44

Ambiance Coloured

Preferred selection

Type Cap/

Base

Ambiance Coloured 11W E27 220-240 A60 50-60 Blue 6 No 15728310

Ambiance Coloured 11W B22 220-240 A60 50-60 Blue 6 No 21019315

Ambiance Coloured 11W E27 220-240 A60 50-60 Green 6 No 15727610

Ambiance Coloured 11W B22 220-240 A60 50-60 Green 6 No 21018615

Ambiance Coloured 11W E27 220-240 A60 50-60 Red 6 No 15725210

Ambiance Coloured 11W B22 220-240 A60 50-60 Red 6 No 21016215

Ambiance Coloured 11W E27 220-240 A60 50-60 Yellow 6 No 15726910

Ambiance Coloured 11W B22 220-240 A60 50-60 Yellow 6 No 21017915

Voltage

(V)

Bulb

Shape

Frequency

(Hz)

Colour Box

quantity

Dimmable Order Code

8710163

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.27

Ambiance Candle Shape

YEARS*

Attractive modern design in a Candle shape

• The Ambiance range offers a high decorative appeal to complement

elegant, modern light fittings in homes, restaurants and hotels

• The elegant covered energy saver creates a comfortable low glare

light that is soft on the eyes

• Available in a familiar Candle shape, simular in size to their

incandescent equivalent

Up to 80% energy saving

• An ideal replacement for incandescent candles of 25W and 40W,

saving up to 80% on energy consumption

Long Life: 6 years

• A long and reliable life of 6000 hrs, which is up to 6 times longer

when compared to incandescent lamps

• 1 year guarantee, safety fuse and flicker free start

Best Environmental choice

• The Ambiance Candle range is fully RoHS compliant conforming to

the most strict environmental legislation in the world

Ambiance Candle

Applications

• Designed for replacement of incandescent lamps in standard shape

in decorative and functional indoor applications

• Enclosed fixtures are required for outdoor applications

• Not suitable for dimming and electronic devices

www.philips.com/OEM

Type C D

Ambiance Candle 5W 117 39

Ambiance Candle 8W 117 39

Ambiance Candle

OEM Catalogue 2009/20106.28

Ambiance Candle Shape

Preferred selection

Type Lamp

Wattage

(W)

Cool Daylight

Ambiance Candle 5W E14 220-240V 50-60Hz 6500 80 180 36 No 40184315

Ambiance Candle 5W E27 220-240V 50-60Hz 6500 80 180 36 No 40175115

Ambiance Candle 5W B22 220-240V 50-60Hz 6500 80 180 36 No 40177515

Ambiance Candle 8W E14 220-240V 50-60Hz 6500 80 350 44 No 40185015

Ambiance Candle 8W E27 220-240V 50-60Hz 6500 80 350 44 No 40181215

Ambiance Candle 8W B22 220-240V 50-60Hz 6500 80 350 44 No 40183615

Cap/

Base

Lamp

Voltage

Frequency

(V)

(Hz)

Colour

Temp.

(K)

Colour

Rendering

Index

Light

Output

(Lumen)

Efficacy

(Lm/W)

Dimmable Order Code

8710163

Warm White

Ambiance Candle 5W E14 220-240V 50-60Hz 2700 82 190 38 No 40178215

Ambiance Candle 5W E27 220-240V 50-60Hz 2700 82 190 38 No 40174415

Ambiance Candle 5W B22 220-240V 50-60Hz 2700 82 190 38 No 40176815

Ambiance Candle 8W E14 220-240V 50-60Hz 2700 82 370 46 No 40179915

Ambiance Candle 8W E27 220-240V 50-60Hz 2700 82 370 46 No 40180515

Ambiance Candle 8W B22 220-240V 50-60Hz 2700 82 370 46 No 40182915

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.29

Essential Economy

YEARS*

Good value for money

• Trusted quality energy savers for best performance

• Choice of light colours

• New lamp cap design for a refined, more sophisticated appearance

with embossed Philips marking

Up to 80% energy saving

• The Essential range can replace the full incandescent range from

40W up to 125W up to 80% energy saving

Long Life: 6 years

• Long reliable life of up to 6000 hrs, which is 6 times longer when

compared to standard incandescent lamps

• 1 year guarantee

• Safety fuse for flicker free start

Best environmental choice

• The Essential range is fully RoHS compliant, conforming to the most

strict environmental legislation in the world

Essential 18W

Applications

• The Essential range is widely used to replace incandescent light

• Enclosed luminaires are required for outdoor use

• Not suitable for dimmers, electronic switches or remote controls

www.philips.com/OEM

Type C F

max. max.

Essential 8W 140 44

Essential 11W 155 44

Essential 14W 170 44

Essential 8W-14W

OEM Catalogue 2009/20106.30

Essential 18W-23W

Essential Economy

Type C F

max. max.

Essential 18W 165 52

Essential 23W 175 52

Preferred selection

Type Lamp

Wattage

(W)

Cool Daylight

Essential 8W E27 220-240V 50-60Hz 6500 440 55 80 40W 12 39591315

Essential 8W B22 220-240V 50-60Hz 6500 440 55 80 40W 12 39593715

Essential 11W E27 220-240V 50-60Hz 6500 620 56 80 60W 12 39595115

Essential 11W B22 220-240V 50-60Hz 6500 620 56 80 60W 12 39597515

Essential 14W E27 220-240V 50-60Hz 6500 820 59 80 75W 12 39599915

Essential 14W B22 220-240V 50-60Hz 6500 820 59 80 75W 12 39601915

Essential 18W E27 220-240V 50-60Hz 6500 1100 61 80 100W 12 39603315

Essential 18W B22 220-240V 50-60Hz 6500 1100 61 80 100W 12 39605715

Essential 23W E27 220-240V 50-60Hz 6500 1420 62 80 125W 12 39607115

Essential 23W B22 220-240V 50-60Hz 6500 1420 62 80 125W 12 39609515

Warm White

Essential 8W E27 220-240V 50-60Hz 2700 460 58 82 40W 12 39590615

Essential 8W B22 220-240V 50-60Hz 2700 460 58 82 40W 12 39592015

Essential 11W E27 220-240V 50-60Hz 2700 650 59 82 60W 12 39594415

Essential 11W B22 220-240V 50-60Hz 2700 650 59 82 60W 12 39596815

Essential 14W E27 220-240V 50-60Hz 2700 860 61 82 75W 12 39598215

Essential 14W B22 220-240V 50-60Hz 2700 860 61 82 75W 12 39600215

Essential 18W E27 220-240V 50-60Hz 2700 1170 65 82 100W 12 39602615

Essential 18W B22 220-240V 50-60Hz 2700 1170 65 82 100W 12 39604015

Essential 23W E27 220-240V 50-60Hz 2700 1460 63 82 125W 12 39606415

Essential 23W B22 220-240V 50-60Hz 2700 1460 63 82 125W 12 39608815

Cap/

Base

Lamp

Voltage

(V)

Frequency

(Hz)

Colour

Temperature

(K)

Luminous

Flux

(Lm)

Luminous

Efficacy

(Lm/W)

Colour

Rendering

Index

(Ra)

Equivalent

light of

ordinary

Incandescent

Box

quantity

8710163

Compact Fluorescent Lamps Integrated

Order

Code

OEM Catalogue 2009/2010 6.31

Essential Long life

YEARS*

Good value for money

• Trusted quality energy savers for long and reliable performance

• Frequent turning on/off up to 15000 times for long life

• Choice of colours

Up to 80% energy saving

• The Essential Long Life range is available in 20W and 23W in high

voltage replacing 100W and 125W incandescent equivalents for up

to 80% energy saving

Long life: 12 Years

• Long and reliable life of 12000 hrs, which is up to 12 times longer

when compared to incandescent lamps

• 1 year guarantee

• Safety fuse and flicker free start

Best Environmental choice

• The Essential Long Life range is fully RoHS compliant conforming to

the most strict environmental legislation in the world

Essential Long Life

Applications

• The Essential Long Life range is widely used to replace incandescent

lamp

• The long life time and 15000 switching cycles is ideal for applications

where lamps are frequently switched on and off

• Enclosed luminaires are required for outdoor use

• Not suitable for dimmers and electronic devices

www.philips.com/OEM

Type C F

max. max.

Essential Long Life 20W 165 52

Essential Long Life 23W 175 52

Essential Long Life

OEM Catalogue 2009/20106.32

Essential Long life

Preferred selection

Type Lamp

Wattage

(W)

Cool Daylight

Essential Long Life 20W E27 220-240V 50-60Hz 6500 1200 62 80 100W 12 39689715

Essential Long Life 20W B22 220-240V 50-60Hz 6500 1200 62 80 100W 12 39693415

Essential Long Life 23W E27 220-240V 50-60Hz 6500 1420 62 80 125W 12 39691015

Essential Long Life 23W B22 220-240V 50-60Hz 6500 1420 62 80 125W 12 39695815

Warm White

Essential Long Life 20W E27 220-240V 50-60Hz 2700 1250 65 82 100W 12 39688015

Essential Long Life 20W B22 220-240V 50-60Hz 2700 1250 65 82 100W 12 39692715

Essential Long Life 23W E27 220-240V 50-60Hz 2700 1460 63 82 125W 12 39690315

Essential Long Life 23W B22 220-240V 50-60Hz 2700 1460 63 82 125W 12 39694115

Cap/

Base

Lamp

Voltage

Frequency

(Hz)

(V)

Colour

Temp.

(K)

Luminous

Flux

(lm)

Luminous

Efficacy

(Lm/w)

Colour

Rendering

Index

(Ra)

Incandescent

Equivalent

Box

quantity

8710163

Order

Code

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.33

PL-Electronic Reector R50

PL E Refl GU10 R50

Product Description

●

Energy-saving lamp approximating the shape of a R50 incandescent

reflector or a GU10-based halogen lamp

Product Features

●

Fluorescent, directional light source

●

Longer-life alternative to halogen or incandescent lamps

●

Average lifetime up to five times longer than a halogen lamp, up to

ten times longer than an incandescent reflector

●

Unlimited on-off switches in most common applications

Product Benefits

●

Saving on energy bills due to lower energy consumption and lower

heat emission compared to incandescent / halogen lamps

●

Replacements less frequent, meaning less maintenance costs

●

Cost of ownership lower than for incandescent / halogen reflectors

Application

●

Designed for incandescent reflector (R50) or GU10-based halogen

replacement in professional (hotels, restaurants, shops) or home

applications

●

Most suitable for places where R50 GU10 is used as general light

source (less suitable for accent lighting applications)

●

Not suitable for dimming and electronic devices

www.philips.com/OEM

Type CMax DMax FMax

PL-Electronic Reector R50 7W WW E14 230-240V 1CT 97.0 50.8 48.1

PL E Refl E14 R50

OEM Catalogue 2009/20106.34

PL E Refl GU10 R50

PL-Electronic Reector R50

Type CMax DMax FMax

PL-Electronic Reector R50 7W WW GU10 230-240V 1CT 82.0 50.0 21.9

Technical data

Type Voltage

(V)

PL-Electronic Reector R50 7W WW E14/GU10 230-240V 1CT 230-240 7 - No 10000

Rated

Lamp

Wattage

Energy

Efficiency

Label

Dimmable Life to

50%

failures

(hrs)

Light data

Type Luminous

flux

lamp

(lm)

PL-Electronic Reector R50 7W WW E14/GU10 230-240V 1CT 160 22 Warm White 2700 82 465 420

Luminous

Efficacy

Lamp

(lm/W)

Colour

Designation

Colour

Temperature

Colour

Rendering

(K)

Index

(Ra)

Chromaticity

Coordinate X

Chromaticity

Coordinate Y

Ordering and packing data

Type ILCOS EAN code

1 piece

PL-Electronic Reector R50 7W WW E14 230-240V 1CT FBT-20/27/1b-230/240-E14 8727900213157 54 gr 10 26.7 cm x 11.2 cm x 10.7 cm 8727900213164 213157 25

PL-Electronic Reector R50 7W WW GU10 230-240V 1CT FBT-20/27/1b-230/240-GU10 8727900213133 54 gr 10 26.7 cm x 11.2 cm x 10.7 cm 8727900213140 213133 25

Weight Qty bulk

packing

Dimensions bulk packing EAN code

bulk packing

8727900

Cap Base

Compact Fluorescent Lamps Integrated

EOC

E14

GU10

OEM Catalogue 2009/2010 6.35

PL-Electronic Reector R80

PL E Refl E27

Product Description

●

Energy-saving lamp approximating the shape of an R80 incandescent

reflector lamp

●

Professional long-life and energy-saving alternative to incandescent

lamps

Product Features

●

High light intensity in a specific direction

●

80% of nominal light output reached within two minutes of switch-

●

Almost constant light output (>80%) over recommended

temperature range (-20 to +55°C), both base-up and base-down

Product Benefits

●

50% energy saving compared with standard incandescent lamps

●

Direct replacement for R80 reflector lamps in numerous

professional applications

●

Light quality and distribution similar to opalised incandescent R80

reflector lamps

●

High reliability, especially important where lighting is used for longer

periods and / or where lamp replacement is difficult

●

Lifetime independent of number of on-off switching cycles

Application

●

Direct replacement for R80 reflector lamps in numerous

professional applications, e.g. hotels and restaurants as well as

horticulture

●

Dimming or electronic control devices cannot be used

www.philips.com/OEM

Type CMax DMax FMax

PL-Electronic Reector R80 20W/827/840 E27 230-240V 1CT 143.0 81 48.1

PL E Refl E27

OEM Catalogue 2009/20106.36

PL-Electronic Reector R80

Technical data

Type Voltage

(V)

PL-Electronic Reector R80 20W/827/840 E27 230-240V 1CT 230-240 20 - No 10000

Light data

Type Luminous

flux

lamp

(lm)

PL-Electronic Reector R80 20W/827 E27 230-240V 1CT 750 36.0 Warm White 2700 82 470 415

PL-Electronic Reector R80 20W/840 E27 230-240V 1CT 750 35.0 Cool White 4000 84 380 680

Ordering and packing data

Type ILCOS EAN code

PL-Electronic Reector R80 20W/827 E27 230-240V 1CT FBT-20/27/1b-230/240-E27 8711500659897 83 gr 6 18 cm x 26.6 cm x 16.5 cm 8711500659910 659897 10

PL-Electronic Reector R80 20W/840 E27 230-240V 1CT FBT-20/27/1b-230/240-E27 8711500831897 117 gr 6 18 cm x 26.6 cm x 16.5 cm 8711500831903 831897 10

Cap Base

Rated

Lamp

Wattage

Luminous

Efficacy

Lamp

(lm/W)

Energy

Efficiency

Colour

Designation

1 piece

Dimmable Life to

Label

Temperature

Weight Qty bulk

Colour

packing

50%

failures

(hrs)

Colour

Rendering

(K)

Dimensions bulk packing EAN code

Index

(Ra)

Chromaticity

Coordinate X

Chromaticity

Coordinate Y

bulk packing

8711500

Compact Fluorescent Lamps Integrated

EOC

E27

OEM Catalogue 2009/2010 6.37

Ambiance Reector

YEARS*

Ambiance Reflector

Energy-saving solution for directional light

• An ideal energy saving replacement for incandescent reflector bulbs

in indoor fixtures that give focused lighting effects

Up to 80% energy saving

• The Reflector range is available in the exact same diameters as their

incandescent equivalent, allowing for immediate saving of up to 80%

on energy consumption

Long Life: 6 Years

• 6000 hrs. Up to 6 times longer when compared to incandescent

lamps

• 1 year guarantee

Best Environmental choice

• The Ambiance Reflector range is fully RoHS compliant conforming

to the most strict environmental leglislation in the world

Applications

• Designed for replacement of incandescent and halogen reflector

lamps in downlighters in home and more professional applications

like shops, restaurants, cafés

• Not suitable for dimming and electronic devices

www.philips.com/OEM

Type C F

8W R60 114 44

11W R63 124 44

14W R80 130 50

18W R80 144 50

Ambiance Reflector

OEM Catalogue 2009/20106.38

Ambiance Reector

Preferred selection

Type Lamp

Watt.

(W)

Cool Daylight

Ambiance Ref. 8W E27 R63 50-60Hz 6500 80 120 265 33 1CT/12 6000 No 40223915

Ambiance Ref. 8W B22 R63 50-60Hz 6500 80 120 265 33 1CT/12 6000 No 40225315

Ambiance Ref. 11W E27 R63 50-60Hz 6500 80 120 365 33 1CT/12 6000 No 40227715

Ambiance Ref. 11W B22 R63 50-60Hz 6500 80 120 365 33 1CT/12 6000 No 40229115

Ambiance Ref. 14W E27 R80 50-60Hz 6500 80 120 585 42 1CT/6 6000 No 40231410

Ambiance Ref. 14W B22 R80 50-60Hz 6500 80 120 585 42 1CT/6 6000 No 40233810

Ambiance Ref. 18W E27 R95 50-60Hz 6500 80 120 800 45 1CT/6 6000 No 40235210

Ambiance Ref. 18W B22 R95 50-60Hz 6500 80 120 800 45 1CT/6 6000 No 40237610

Warm White

Ambiance Ref. 8W E27 R63 50-60Hz 2700 82 120 280 35 1CT/12 6000 No 40222215

Ambiance Ref. 8W B22 R63 50-60Hz 2700 82 120 280 35 1CT/12 6000 No 40224615

Ambiance Ref. 11W E27 R63 50-60Hz 2700 82 120 385 35 1CT/12 6000 No 40226015

Ambiance Ref. 11W B22 R63 50-60Hz 2700 82 120 385 35 1CT/12 6000 No 40228415

Ambiance Ref. 14W E27 R80 50-60Hz 2700 82 120 615 44 1CT/6 6000 No 40230710

Ambiance Ref. 14W B22 R80 50-60Hz 2700 82 120 615 44 1CT/6 6000 No 40232110

Ambiance Ref. 18W E27 R95 50-60Hz 2700 82 120 840 47 1CT/6 6000 No 40234510

Ambiance Ref. 18W B22 R95 50-60Hz 2700 82 120 840 47 1CT/6 6000 No 40236910

Cap/

Base

Bulb

Shape

Freq.

(Hz)

Colour

Temp.

Colour

Rendering

Index

(K)

(Ra)

Beam

Angle

(degrees)

Light

Output

(Lumen)

Efficacy

(Lm/W)

Packaging

Type /

config.

Lifetime

(hrs)

Dim. Order Code

8710163

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.39

Ambiance Reector PAR38

YEARS*

Same size, Wide beam

• Same size as the PAR38 incandescent equivalent, not fit issues in

existing luminaires

• Widebeamangleof120˚

• Hard glass makes the lamps suitable for outdoor use

Up to 80% energy saving

• For savings of up to 80% energy as you can directly replace 80W

and 120W PAR38 incandescent lamps

Long Life: 6 Years

• Reliable life of 6000 hrs, which is up to 6 times longer when

compared to incandescent lamps

• 1 year guarantee

• Constant light output thanks to amalgam technology

Best Environmental choice

• The Ambiance Reflector range is fully RoHS compliant conforming

to the most strict environmental legislation in the world

Ambiance Reflector PAR38

Applications

• Wide range of indoor and outdoor applications like shops, windows

displays, homes, hotels, buildings, statues, exhibitions, parks & gardens

• Not suitable for enclosed fixtures

• Not suitable for dimmers, electronic switches or remote controls

www.philips.com/OEM

Type C D

PAR38 18W 135 122

PAR38 23W 159 122

Ambiance Reflector PAR38

OEM Catalogue 2009/20106.40

Ambiance Reector PAR38

Preferred selection

Type Lamp

Wattage

(W)

Cool Daylight

Ambiance Reector PAR38 18W E27 220-240V 50-60Hz 6500 80 800 46 Available on request

Ambiance Reector PAR38 18W B22 220-240V 50-60Hz 6500 80 800 46 Available on request

Ambiance Reector PAR38 23W E27 220-240V 50-60Hz 6500 80 1000 50 40219210

Ambiance Reector PAR38 23W B22 220-240V 50-60Hz 6500 80 1000 50 40221510

Warm White

Ambiance Reector PAR38 18W E27 220-240V 50-60Hz 2700 82 850 50 Available on request

Ambiance Reector PAR38 18W B22 220-240V 50-60Hz 2700 82 850 50 Available on request

Ambiance Reector PAR38 23W E27 220-240V 50-60Hz 2700 82 1250 54 40218510

Ambiance Reector PAR38 23W B22 220-240V 50-60Hz 2700 82 1250 54 40220810

Cap/

Base

Lamp

Voltage

Frequency

(Hz)

(V)

Colour

Temperature

Colour

Rendering

(K)

(Ra)

Light

Output

(Lumen)

Efficacy

(Lm/W)

Order Code

8710163

Compact Fluorescent Lamps Integrated

OEM Catalogue 2009/2010 6.41

Philips Compact Fluorescent Lamp User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
