Page 1
Register your product and get support at
www.philips.com/welcome
CID3695
EN User manual
ZH-CN Ⴌ߀൱Ҭ
ZH-HK Ԛʹ˫
Page 2
Contents
1 Important 4
Safety 4
Notice 4
6 Play with Bluetooth device 18
Pair the Bluetooth-enabled devices 18
Make a call 19
Answer a call 19
Listen to music from Bluetooth device 19
Adjust Bluetooth settings 20
English
2 Your in-car entertainment system 6
Introduction 6
What’s in the box 6
Install the car audio 7
Overview of the main unit 10
Overview of controls on host car audio 11
3 Get started 12
Turn on 12
Adjust volume 12
Mute 12
Set date and time 12
4 Listen to radio 13
Tune to a radio station 13
Store radio stations in memory 13
Tune to a preset station 14
5 Play 14
Load discs 14
Connect USB device 15
Insert USB or SD/MMC card 15
Play/Pause 15
Skip/search 15
Search within a title/folder 16
Repeat 16
Repeat a section 17
Random play 17
Select audio language 17
Select audio mode 17
Select subtitle language 17
Rotate pictures 17
Zoom 18
Select slide show duration 18
7 Use map 20
Upgrade the map 20
8 Adjust sound settings 21
Select preset equalizer 21
Adjust fader/balance 21
Set Dynamic Bass Boost (DBB) 21
9 Adjust system settings 22
Display system setup menu 22
Adjust general settings 22
Adjust sound settings 23
Adjust video settings 23
Adjust Bluetooth settings 24
Adjust language settings 24
Adjust volume settings 25
Adjust DVD rating 25
10 Adjust car settings 27
11 Play from rear displays 27
12 Others 29
Listen to other devices 29
Reset 29
Replace fuse 29
OnStar 29
13 Product information 30
14 Troubleshooting 32
About Bluetooth device 32
15 Glossary 34
EN
3
Page 3
1 Important
Safety
Read and understand all instructions •
before you use the apparatus. If damage
is caused by failure to follow instructions,
the warranty does not apply.
Use of controls or adjustments or •
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
This unit is designed for negative ground •
(earth) 12 V DC operation only.
To reduce the risk of traffic accident, do •
no watch video during driving.
To ensure safe driving, adjust the volume •
to a safe and comfortable level.
Improper fuses can cause damage or •
fire. When you need to change the fuse,
consult a professional.
Use only the supplied mounting hardware •
for a safe and secure installation.
To avoid short circuit, do not expose the •
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation •
slots or other openings on the apparatus.
Never place any objects other than discs •
into the disc tray/slot.
Visible and invisible laser radiation when •
open. Avoid exposure to beam.
Risk of damage to the screen! Never •
touch, push, rub or strike the screen with
any object.
Never use solvents such as benzene, •
thinner, cleaners available commercially,
or anti-static sprays intended for discs.
Clean the apparatus with soft, damp •
cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the apparatus.
The apparatus shall not be exposed to •
dripping or splashing.
Do not place any sources of danger on •
the apparatus (e.g. liquid filled objects,
lighted candles).
This product complies with the radio
inter ference requirements of the European
Community.
This apparatus includes this label:
Notice
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
4
EN
Page 4
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed of with normal household
waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment
and human health.
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
DivX®, DivX Certified® and associated logos
are trademarks of DivX, Inc. and are used
under license.
ABOUT DIVX VIDEO: DivX
video format created by DivX, Inc. This is an
official DivX Cer tified
video. Visit divx.com for more information and
software tools to convert your files into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certified
in order to play purchased DivX Video-onDemand (VOD) movies. To obtain your
registration code, locate the DivX VOD
section in your device setup menu. Go to vod.
divx.com for more information on how to
complete your registration.
Covered by one or more of the following
U.S. patents: 7,295,673; 7,460,668; 7,515,710;
7,519,274
The Bluetooth
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Philips
is under license.
®
device must be registered
®
word mark and logos are
®
is a digital
®
device that plays DivX
Manufactured under license from Dolby
Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Other trademarks and trade names are those
of their respective owners.
2010 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specifications are subject to change without
notice. Trademarks are the proper ty of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
English
EN
5
Page 5
2 Your in-car
entertainment
system
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the car entertainment system, you can:
quickly find routes through the navigation •
system
enjoy audio/video/JPEG pictures from•
DVD, VCD or CD•
USB devices•
SD/SDHC/MMC cards •
External devices•
listen to FM or AM (MW) radio•
play audio from Bluetooth-enabled •
devices
make/answer phone calls with Bluetooth-•
enabled devices
What’s in the box
ড়Ḑ
ֱׂ
䇈ᯢк
ᅝ㺙ᣛ
ᓩ
6
EN
Page 6
Install the car audio
Note
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
This unit is designed for negative ground •
(earth) 12 V DC operation only.
Always install this unit in the car dashboard. •
Other locations can be dangerous as the rear
of the unit heats up during use.
To avoid short-circuit: before you connect, •
ensure that the ignition is off.
Ensure that you connect the yellow and red •
power supply leads after all other leads are
connected.
Ensure that all loose leads are insulated with •
electrical tape.
Ensure that the leads do not get caught under •
screws orin parts that will move (e.g. seat rail).
Ensure that all ground (earth) leads are run to •
a common ground (earth) point.
Use only the supplied mounting hardware for a •
safe and secure installation.
Improper fuses can cause damage or fire. •
When you need to change the fuse, consult a
professional.
Note on the power supply lead (yellow)
When you connect other devices to this •
system, ensure that the rating of the car
circuit is higher than the total fuse value
of all the connected devices.
As different cars have different requirements, •
you might need to connect CID3695
differently from the user manual’s instructions.
Consult a professional mechanic to connect.
Connect parking brake cable and
reverse driving cable to a rear view
backup camera
Note
Check your local driving regulations on •
whether it is legally required to install the
rear view backup camera. These connections
require a professional mechanic to install.
This car audio video system allows you to
connect to the rear view backup camera. You
can view the things that happens behind your
car in the display, especially you are driving a
big vehicle. This helps protecting your bumper
and anything it might contact.
English
Notes on speaker connection
Never connect speaker wires to the •
metal body or chassis of the car.
Never connect speaker wires with stripes •
to one another.
Connect wires
Caution
Make sure that all loose leads are insulated •
with electrical tape.
EN
7
Page 7
1 Check the car’s wirings carefully, then
Q
connect the in-car system as follows.
*UHHQ
<HOORZ %OXH
86%
ՄᜰᜰᮓᣘЍ
&$0(5$9,'(
<HOORZ
&$0(5$
&$0(5$%
ՄᜰΌၶၶຬ
&$0(5$*1'
ՄᜰΌၶڔጦ
WRFDUERG\VKHOO
WRSRVLWLYHSROHRIUHYHUVLQJ
ODPSVSRZHUVXSSO\
*HDUER[
FRQQHFWVFUHHQXQLW
&$1%2;
Connect GPS antenna
To receive signal from satellites, connect the
supplied GPS antenna to the system and your
car.
1 Connect the supplied GPS antenna to the
in-car system.
5DGLRDQWHQQD
2SWLRQDO
79DQWHQ
5HG
:KLWH
5HG
%URZQ
$PSOLILHU
ᣌңᜰᮓᣘЍ
$8;,19,'(2
<HOORZ
$9V\VWHP
2$17
5$',
᭶ܬጦ
*36DQWHQQD
([WHQVLRQFDEOH
&00%%86
Մԯࢮ᭶ᮓᣘі
5($5287/
ՄԯԲ᭶ᮓᣘі
5($52875
&$1%2;
᭶ᣘі
68%:
ՄԲ᭶ᮓᣘі
5($55
Մࢮ᭶ᮓᣘі
5($5/
҅Բ᭶ᮓᣘі
ᣌңᜰᮓᣘі
$8;2879,'(2
$8;2879,'(2
<HOORZ
)52175
҅ࢮ᭶ᮓᣘі
)5217/
$8;,1/
$8;,15
ᣌңᜰᮓᣘі
5($5B76
ᣌңԲ᭶ᮓᣘЍ
ᣌңࢮ᭶ᮓᣘЍ
5HG
%ODFN
:KLWH
<HOORZ
$8;
:KLWH
2 Stick the other end of the GPS antenna to
a metal surface of the car.
Mount in the dashboard
Note
Check wire connections before you mount the •
main unit into a car.
For proper operation of the DVD player, the •
chassis must be mounted within 20 degree
horizontal. Ensure that the unit is mounted
within this limitation.
8
EN
Page 8
Caution
Keep the connection of the car battery if •
there is an on-board drive or navigation
computer. Otherwise, the computer may lose
its memory.
To avoid shor t circuit, ensure the bare wires •
do not touch each other and disconnect the
negative terminal of the car battery.
1 Fix the supplied rubber cushion with the
mounting bolt.
2 Slide the unit into the dashboard.
3 Fix the main unit with four screws.
English
4 Reconnect the negative terminal of the
car battery.
EN
9
Page 9
Overview of the main unit
a
b
a
Built-in microphone. •
b
SD/SDHC card slot.•
c MAP
GPS map card slot.•
c
10
EN
Page 10
Overview of controls on host
i
car audio
English
a
b
c
d
e
f
g
h
RADIO
BAND
CD
a
Turn on or off the in-car system. •
Adjust volume.•
b
Search forward.•
Skip to the previous track.•
c RADIO BAND
Switch to the radio source.•
Select radio band.•
d CD
Switch to the disc source.•
e TONE
Access the sound settings.•
f AUX
Switch to the AUX source.•
g
Mute or restore sound.•
h BACK
Go back to the previous menu.•
i Control knob
Skip to the previous/next track or chapter.•
AUX
1
2
TONE
BACK
q
p
FAV
3
j INFO
k
l
m CONFIG
n AS
o FAV
p
q 1-6
4
CONFIG
INFO
Adjust the screen brightness.•
Turn off the display screen.•
Eject the disc.•
Set the time.•
Access the host car audio setup •
menu.
Search for radio station •
automatically.
Display the list of preset radio •
stations.
Search backward.•
Skip to the nex t track.•
Select the preset number.•
5
6
AS
o
n
m
l
k
j
EN
11
Page 11
3 Get started
Caution
Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
Mute
1
During play, tap to turn off sound.
To restore sound, tap •
again.
Turn on
Caution
Risk of road accidents! Never watch video or •
adjust settings while you drive.
1 Press on the host car audio to turn on
CID3695.
The available OSD (On-Screen »
Display) languages are displayed.
2 Tap a language to select.
The OSD language is changed to the »
selected language immediately.
To turn off CID3695, press •
car audio.
Adjust volume
on the host
Set date and time
1
Tap to display the main menu.
2 Tap [Settings].
3 Tap [Time].
The date/time setup menu is displayed. »
Set date
1 Tap [Date].
2 Tap on the displayed date.
A submenu is displayed. »
1
Turn button on the host car audio
to increase or reduce volume.
12
EN
Page 12
4 Listen to radio
3 Tap or to set year, month and day.
Set clock mode
1 Tap [Clock mode].
2 Tap on [12Hr] or [24Hr] to select clock
mode.
Set time
1 Tap [Time].
2 Tap on the displayed time.
A submenu is displayed. »
Tune to a radio station
Tap to display the home menu.
1
2 Tap [Radio].
Band and frequency information is »
displayed.
3 Tap on FM or AM to select band:
FM band options: • FM1, FM2, FM3
AM band options: • AM1, AM2
4 Briefly tap or to tune to a radio
station by step.
Tap •
or for more than 1
second to tune to a radio station
automatically.
Store radio stations in
memory
English
3 Tap or to set hour and minute.
Tip
When date/time is set, tap • to return to the
main menu.
You can store up to 6 stations in each band.
Store stations manually
1 Tune to a station.
2 Tap .
3 Tap [Save].
EN
13
Page 13
4 Tap one of the channels 01 to 06 to save
the selected band.
5 Play
Make sure that the disc or device contains
playable music or video.
Note
Store stations automatically
You can search for a station with intro search,
which broadcasts a 10-second preview of each
detected radio station.
1 Select band.
2 Tap .
3 Tap [Search].
Auto search starts. The six strongest »
stations of the selected band are saved
in preset channels 1-6 automatically.
Tune to a preset station
Tap [Radio].
1
2 Select band.
3 Tap one of the preset channels (01 to 06)
to select a preset station.
For CDs recorded in multiple sessions, only •
the first session is played.
Does not suppor t MP3 Pro audio format. •
It may not suppor t and display special •
characters track name (ID3) or album name
properly.
It cannot play some WMA is protected by •
Digital Rights Management (DRM).
The system does not display or play the folders •
or files that exceed the supporting limit.
Warning
To reduce the risk of tr affic accident, do not •
watch video during driving.
Load discs
1
Inser t a disc into the disc slot with the
label side facing up.
Play starts automatically. »
14
EN
To eject the disc, press • on the
host car audio.
The in-car system returns to the »
previous source or [Radio] mode
automatically.
Page 14
Connect USB device
Insert the USB storage device to the USB
socket.
Play starts automatically. »
2 Press the card until you hear a click
sound.
The card is now disengaged. »
3 Remove the card.
Play/Pause
Inser t a disc, USB or SD/SDHC card.
1
Play starts automatically. »
English
Remove the USB device
1 Switch to another (non-USB) source.
2 Remove the USB storage device.
Insert USB or SD/MMC card
Open the card slot cover.
1
2 Inser t the SD or SDHC card into the card
slot.
Play starts automatically. »
Remove the SD/MMC card
1 Switch to another source.
For DVD movie, if a menu appears, tap »
a menu option to play.
2 To pause, tap .
To resume play, tap •
Skip/search
Tap to return to playlist menu.
1
2 Tap one of below icons to select folder/
file:
.
• : To display all available audio
folders/track.
•
: To display all available picture
folders/files.
•
: To display all available video
folders/files
3 Tap or to select a folder/track.
4 Tap to star t playing.
EN
15
Page 15
Search within a title/folder
For audio files:
1 Tap .
The search screen is displayed. »
2 Tap to display the 2nd menu.
2 Tap the numbers to input track/file
number, then tap
To clear the previous input, tap •
To clear all input, tap •
For video files:
1 Tap anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2 Tap , and then tap .
3 Tap to search by chapter/track or
to search by time.
4 Tap the numbers to input track/file
number or time, then tap
To clear all input, tap •
Repeat
During play, you can select different repeat play
modes.
For DVD/VCD movie disc:
1 Tap anywhere except for the upper left
corner to display menu on the screen, if
necessary.
.
.
.
.
.
3 Tap to select:
• [Repeat chapter]: play the current
chapter repeatedly.
• [Repeat title]: play all chapters in the
title repeatedly.
• [Repeat off]: cancel repeat play.
For VCD karaoke:
1 Tap to select:
• [Repeat one]: play the current track
repeatedly.
• [Repeat all]: play all tracks
repeatedly.
• [Repeat off]: cancel repeat play.
For MP3/WMA files:
1 During play, tap to select:
•
-1: play the current track
repeatedly.
•
-Folder: play all the tracks in the
current folder repeatedly.
•
(in grey color): cancel repeat play.
16
EN
Page 16
Repeat a section
Select audio language
You can repeat a specific section of video file
(repeat A-B).
1 During play, tap anywhere except for the
upper left corner to display menu on the
screen, if necessary.
2 Tap to display the 2nd menu, if
necessary.
3 Tap repeatedly to select:
• [Repeat A-]: the star t of the section
to repeat.
• [Repeat A-B]: the end of the section
to repeat.
The selected section plays •
repeatedly.
4 To exit A-B repeat mode, tap
repeatedly until [Repeat A-B off ] is
displayed.
Random play
You can play audio tracks/files in random order.
1 During play, tap repeatedly to turn
random play on or off.
For video discs that contain two or more audio
channels.
1 During play, tap anywhere except for the
upper left corner to display menu on the
screen, if necessary.
2 Tap to display the 2nd menu.
3 Tap repeatedly.
The audio channel information is »
displayed on the upper line of the
screen.
Select audio mode
When you play VCDs, you can select an audio
mode (R/L/Stereo).
1 During play, tap anywhere except for the
upper left corner to display menu on the
screen.
2 Tap repeatedly until the audio mode
is selected.
Select subtitle language
English
• is highlighted: star t random play.
•
turns gray: cancel random play.
For VCD:
• [Shuffle on]: star t random play.
• [Shuffle off]: cancel random play.
For DVD or DivX discs that contain two or
more subtitle languages.
1 During play, tap anywhere except for the
upper left corner to display menu on the
screen, if necessary.
2 Tap to display the 2nd menu
3 Tap repeatedly to select a language.
The selected language is displayed. »
Rotate pictures
1
When you view pictures, tap anywhere
except for the upper left corner to display
menu on the screen, if necessary.
EN
17
Page 17
6 Play with
Bluetooth
2 Tap repeatedly to rotate the picture.
Zoom
You can zoom in pictures for a close view.
1 During picture viewing, tap anywhere
except for the upper left corner to display
menu on the screen, if necessary.
2 Tap repeatedly to zoom in the picture.
3 Tap , , or to pan through the
enlarged picture.
Select slide show duration
Tap anywhere except for the upper left
1
corner to display menu on the screen, if
necessary.
2 Tap repeatedly to select:
• Fast: 3 seconds
• Normal: 5 seconds
• Slow: 8 seconds
device
With this in-car system, you can:
make or answer phone calls through a •
Bluetooth-enabled phone.
listen to music from a Bluetooth-enabled •
device.
Pair the Bluetooth-enabled
devices
To connect your Bluetooth device to the in-car
system, you need to pair the device to the incar system. Pairing needs only to be done once.
You can pair up to eight devices.
Note
The operational range between this unit and a •
Bluetooth device is approximately 10 meters
(30 feet).
Before you connect a Bluetooth device to this •
unit, familiarize yourself with the Bluetooth
capabilities of the device.
Compatibility with all Bluetooth devices is not •
guaranteed.
Any obstacle between this unit and a •
Bluetooth device can reduce the operational
range.
Keep this unit away from any other electronic •
device that may cause interference.
1 Turn on the Bluetooth function on your
Bluetooth device.
2 Search for CID3695 with your Bluetooth
device.
3 Select “CID3695” in the pairing list.
4 Enter default password “0000”.
if pairing succeeds. phone call record is »
displayed.
18
EN
Page 18
Disconnect Bluetooth devices
To disconnect one device, tap (red).
»
(green) is displayed.
Tip
When the Bluetooth device is out of the •
operational range, the Bluetooth connection
will disconnect.
If you want to reconnect the device to the •
unit, place it within the operational range.
If you do not want to reconnect the device •
to the unit automatically, tap > [Auto
connect] > [Off]. For details, see the “Adjust
Bluetooth settings” section.
Make a call
Answer a call
By default, the in-car system answers all
incoming calls automatically.
1 If there is incoming call, [Incoming call...]
flashes on the screen. Speak into the
microphone.
2 When conversation ends, tap (red)
to terminate the call.
English
Pair the phone with the unit.
1
2 Tap to display the main menu.
3 Tap [Bluetooth].
The Bluetooth menu is displayed. »
4 Tap or to select the paired phone,
then tap
.
5 Tap or to search for phone number,
ortap
to dial number directly, then tap
to dial.
Tip
To answer calls manually, set • [Auto answer]
to [Off ].
Switch phone call to the mobile
If you do not want your passenger to hear
your incoming call, you can switch the call to
your mobile phone.
1 During the call, tap .
The voice is switched back to the »
mobile phone.
Listen to music from
Bluetooth device
If the connected Bluetooth device supports
Advanced Audio Distribution Profile (A2DP),
you can listen to the music stored in the device
through the in-car system.
1 Pair the phone with the in-car system.
2 Tap to return to the main menu.
3 Tap [Bluetooth].
EN
19
Page 19
The Bluetooth menu is displayed. »
4 Start to play music stored in the device.
If the device supports Audio Video •
Remote Control Profile (AVRCP)
profile, you can use controls on the
in-car system to play music stored in the
device.
1 Tap .
2 Tap to star t play.
Adjust Bluetooth settings
In Bluetooth menu, tap .
1
The option menu is displayed. »
7 Use map
Note
You may need to upgrade the map (sold •
separ ately) before using it (see “ Upgrade the
map” section).
1 In the main menu, tap [Navigation].
The navigation menu is displayed in a »
few seconds.
2 See the map manual to operate the
navigation tool.
Upgrade the map
1
Turn off the car audio system.
2 Open the MAP card slot cover.
3 Press the map card (sold separately) until
you hear a click sound.
4 Take out the card and bring it to the
authorized service center for upgrade.
2 Tap an option to adjust settings.
Tip
You can also adjust Bluetooth settings in the •
“Settings” menu.
20
EN
5 Inser t the upgraded map card back into
the map card slot.
6 Turn on the in-car system.
The map upgrades in a few minutes. »
Page 20
8 Adjust sound
The speakers and subwoofer setup »
menu is displayed.
settings
Select preset equalizer
Tap anywhere except for the upper left
1
corner to display menu on the screen, if
necessary.
2 Tap .
The equalizer setup menu is displayed. »
3 Tap or to select a preset equalizer.
4 Tap or to adjust these settings:
• [Bass] bass range: -14 to +14
• [Mid] middle range: -14 to +14.
• [Treb] treble range: -14 to +14
• [LPH] low pass filter range: 60, 80,
100, 200.
• [MPF] middle pass filter range: 500,
1K, 1.5K, 2.5K.
• [HPF] high pass filter range:10K,
12.5K, 15K, 17.5K.
5 To restore default settings, tap .
6 To exit, tap .
4 Tap or to adjust subwoofer volume.
• [Sub] subwoofer volume: 0 to 24.
5 Tap F, R, L, or R to adjust fader/balance
value.
• [Fade] fader range: +24 to -24. (F =
front speaker, R = rear speaker)
• [Balance] balance range: -24 to +24.
(L = left speaker, R = right speaker)
6 Tap to exit.
Set Dynamic Bass Boost
(DBB)
Tap to turn on or off the Dynamic
1
Bass Boost.
• [DBB] on: The
• [DBB] off (default): The
dims.
icon illuminates.
icon
English
Adjust fader/balance
You can also adjust the speakers balance and
subwoofer volume.
1 Tap anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2 Tap .
3 Tap .
EN
21
Page 21
9 Adjust system
settings
Display system setup menu
Tap to display the main menu.
1
2 Tap [Settings].
The settings menu is displayed. »
Tip
When the setup is complete, tap • to return
to the main menu.
Adjust general settings
1
Tap [General].
2 Tap or to highlight an option.
3 Tap on the option to display and change
the settings.
General
settings
Options Description
[Radio
region]
[Radio
range]
[Blackout] [off] Turn off the
[Dimmer
Mode]
[Key color] [Red] Button backlight
[Beep] [On] Turn on the
[USA], [S.
Amer-1],
[Arabia],
[China],[S.
Amer-2],
[Europe],
[Korea],
[OIRT]
[Local] Only stations with
[Distance] Stations with
[10s] Turn on the
[20s] Turn on the
[Night] Select this mode
[Dusk] Select this mode
[Normal] Set screen dimmer
[Bright] Select this
[Blue] Button backlight
Select one that
matches your
location.
strong signals are
broadcast.
strong and
weak signals are
broadcast.
screen saver.
screen saver
automatically 10
seconds after last
operation.
screen saver
automatically 20
seconds after last
operation.
at night.
at dusk.
to normal mode.
mode in bright
environment.
turns red.
turns blue.
beep sound. Each
time you press a
button, the unit
beeps.
22
EN
Page 22
[Off] Turn off the beep
sound.
[WallPaper] [Blue] Change
background color
to blue.
[Black] Change
background color
to black.
[Red] Change
background color
to red.
[F1] Select F1 picture
as wall paper.
[Calibration] Calibrate the
touch screen.
4 Tap to exit.
[DRC] [On] Makes loud sound level
softer and soft sound
level louder so that you
can watch the DVD
movies at a low volume,
without disturbing others
[Off] The DRC function is off.
3 Tap to exit.
Adjust video settings
Tap [Video].
1
English
Adjust sound settings
Tap [Sound].
1
2 Tap an option repeatedly to select:
Sound
settings
[Sub
woofer]
[Sub
woofer
filter]
[DBB] [On] The Dynamic Bass Boost
Options Description
[On] Turn on the subwoofer.
[Off] Turn off the subwoofer.
[80Hz] Select subwoofer filter
criteria.
[120Hz]
[160Hz]
(DBB) function is on.
[Off] The DBB function is off.
2 Tap an option repeatedly to select:
Video
settings
[Aspect
ratio]
[Video
input]
Options Description
[Full] For widescreen
display.
[Normal] For normal display.
[Auto] The correct format
is set automatically.
Select this option
if you are not sure
which format should
be selected.
[NTSC] For users in the
United States,
Canada, Japan,
Mexico, the
Philippines, South
Korea, and Taiwan,
select this option.
EN
23
Page 23
[PAL] For users in China,
India, Singapore, the
western European
countries (except
France), and
Australia, select this
option.
[Secam] For users in France,
Russia and other
countries, select this
option.
[Rear
camera]
[Parking] [On] Disable video view
[DivX
registration
code]
[Normal] When you drive in
reverse, the rear
view is displayed
normally.
[Mirror] When you drive in
reverse, the rear
view is displayed in
mirror.
during driving.
[Off] Enable video view
during driving.
View code for DivX
registration.
3 Tap to exit.
Bluetooth
settings
[Bluetooth] [On] Turn on the
[Auto
connect]
[Auto
answer]
[Pairing
code]
Options Description
Bluetooth function.
[Off] Turn off the
Bluetooth function.
[On] If the paired device is
within the effective
range, the unit
reconnects to paired
device automatically.
[Off] Need to reconnect
manually.
[On] Answer phone call
automatically.
[Off] Answer phone call
manually.
View code for pairing
the unit with other
Bluetooth devices.
3 Tap to exit.
Adjust language settings
1
Tap [Language].
Adjust Bluetooth settings
1
Tap [Bluetooth].
2 Tap an option repeatedly to select an
option.
24
EN
2 Tap an option repeatedly to select an
option.
Language
settings
[OSD] [English] Select on-screen-
Options Description
display language.
ࡩᇓ໗]
[
ْᇓ໗]
[
Page 24
[DVD
audio]
[DVD
subtitle]
[Disc
menu]
[English] Select DVD audio
language. Options
available depend on
DVD disc.
[
ࡩᇓ໗
[ْᇓ໗
[English] Select DVD subtitle
[
ࡩᇓ໗]
ْᇓ໗]
[
[Off] Turn off subtitle
[English] Select DVD menu
ࡩᇓ໗]
[
ْᇓ໗]
[
]
]
language. Options
available depend on
DVD disc.
language display.
language. Options
available depend on
DVD disc.
3 Tap to exit.
Adjust volume settings
You can set different volume for different
modes.
1 Tap [Volume].
The volume setting menu is displayed. »
2 Tap on a source.
• [DVD]
• [USB]
• [SDHC]
• [Radio]
• [Bluetooth]
• [AV-IN1]
• [Navigation]
3 Tap or to assign a value: 0 to 12.
When you switch to the source, the »
volume increases automatically.
4 Tap to exit.
Adjust DVD rating
Tap [DVD rating].
1
2 Tap an option repeatedly to select:
DVD rating Options Description
[Set
password]
[Rating
level]
[Kid
safe]
[G] Acceptable for general
[PG] Parental guidance
[PG-13] Unsuitable for children
[PG-R] Recommend parents
[R] Restricted.
[NC-17] Unsuitable for children
[Adult] Acceptable for adults
Set password to
restrict the play of
discs. The default
password is 0000.
Acceptable for
children.
viewers.
suggested.
under age 13.
to restrict children
under 17 to view.
Recommend parent to
guide children under
17 to view.
under age 17.
only.
English
EN
25
Page 25
[Load
factory]
3 Tap to exit.
Restore default
settings.
26
EN
Page 26
10 Adjust car
11 Play from rear
settings
1 In the main menu, tap [Car setting].
The car setting menu is displayed. »
2 Select an item, and then change the
settings.
Tip
The car setting menu varies with car •
configurations.
Follow the on-screen indication and refer to •
the car’s user guide.
displays
When you connect rear displays to the in-car
system, you can choose either to show the
same image as the main unit or to show the
selected source on Rear displays.
1 Make sure that your in-car system is
connected to rear displays successfully.
2 Play a disc, or play from SDHC, USB, or
AV-IN1 on the main unit.
The audio and video are synchronized »
to rear displays automatically.
Note
In AV-IN1 mode, rear zone audio output is •
off. Only the normal speaker/pre-out output
is provided.
3 When you listen to the radio, or use the
Bluetooth and navigation functions, tap
[Rear Zone], and then tap [Disc], [USB]
or [SDHC] to select a source for rear
displays.
English
EN
27
Page 27
USB USB
AV IN 1
4 To exit, tap [Front Zone].
28
EN
AV IN 1
USB
Page 28
12 Others
Replace fuse
Listen to other devices
Make sure that the external device is
1
connected to the in-car system (see
“Connect wires” section).
2 Tap to display the main menu.
3 Tap [AV-IN1].
4 Play the connected device (see the
instructions manual of the device).
Reset
To reset the car audio system to its default
setting:
1 Open the MAP card slot cover.
2 Press the RESET button by using a ball-
point pen or similar tool.
All settings are erased except clock. »
If the system does not power on, the fuse may
be damaged and need replacement.
1 Take out the unit from dashboard.
2 Check the electric connection.
3 Buy a fuse that matches the voltage of the
damaged fuse (15A)
4 Replace the fuse.
OnStar
If the car has OnStar and you subscribe to the
OnStar services, you can use OnStar functions
and services with this in-car system.
See the OnStar owner’s guide for more
information about the functions and services
that OnStar provides.
English
EN
29
Page 29
13 Product
information
Screen size 8 inches (16:9)
Display resolution 800 x 480 dots
Contrast ratio 500
Brightness 450 cd/m2
Note
Product information is subject to change •
without prior notice.
General
Power supply 12 V DC (11 V - 16 V),
negative ground
Fuse 15 A
Suitable speaker
impedance
Maximum power
output
Continuous power
output
Pre-Amp output
voltage
Aux-in level
Dimensions
(W x H x D)
Main unit
Screen unit
Weight (main unit
+ screen unit) 2.5 kg
Disc player
System DVD / CD audio /
Frequency response 20 Hz - 20k Hz
Signal/noise ratio >75dB
Total harmonic
distortion
Channel separation >55dB
Video signal format NTSC only
Video output 1 +/- 0.2V
LCD
4 - 8
50 W x 4 channels
22 W x 4 channels (4
10% T.H.D.)
2.0 V ( CD play mode; 1
kHz, 0 dB, 10 k
500 mV
230 x 132 x 158 mm
227.0 x 193.0 x 106.7 mm
MP3 system
Less than 1%
load)
Bluetooth
Communication
system
Output Bluetooth Standard Power
Maximum
communication
range
Frequency band 2.4 GHz band (2.4000
Compatible
Bluetooth
profiles
Supported
codecs
Receive
Trans mit
Compatible USB devices:
USB flash memory (USB 2.0 or USB1.1)•
USB flash players (USB 2.0 or USB1.1)•
Memory cards (SD / MMC / SDHC)•
Supported formats:
USB or memory file format: FAT16, •
FAT32
MP3 bit rate (data rate): 32-320 Kbps and •
variable bit rate
WMA v9 or earlier•
Directory nesting up to a maximum of 8 •
levels
Number of albums/ folders: maximum 99•
Number of tracks/titles: maximum 999•
ID3 tag V2.0 to V2.4•
File name in Unicode UTF8 (maximum •
length: 128 bytes)
Bluetooth Standard
version 2.0
Class 2
Line of sight approx. 8m
GHz - 2.4835 GHz)
Hands-Free Profile (HFP)
Handset Profile (HSP)
Advanced Audio
Distribution Profile
(A2DP)
Audio Video Remote
Control Profile (AVRCP)
SBC (Sub Band Codec)
SBC (Sub Band Codec)
30
EN
Page 30
Supported MP3 disc format:
ISO9660, Joliet•
Maximum title number: 512 (depending •
on file name length)
Maximum album number: 255•
Supported sampling frequencies: 32 kHz, •
44.1kHz, 48 kHz
Supported Bit-rates: 32-320 Kbps and •
variable bit rate
Supported video formats:
DVD•
Divx Home theater•
Xvid•
Note
To ensure a better playback , it is recommended
that:
the image size is not larger than 640 X 480 •
pixels.
the frame rate is 20 fps. •
the data rate is not higher than 500 kbps. •
English
EN
31
Page 31
14 Troubleshooting
Warning
Never remove the casing of this apparatus. •
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/welcome). When you contact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
Car engine has not been star ted. Start •
the car engine.
Connections is incorrect. •
Fuse has been damaged. Replace fuse. •
No sound
Volume is too low. Adjust volume. •
Speaker connections is incorrect. •
Disc does not play
Disc is upside down. Ensure the printed •
side is upwards.
Disc is dirty. Clean the disc with a •
clean, soft, lint-free cloth. Wipe the disc
outwards from the center.
Disc is defective. Try another disc. •
incompatible disc is used. Try another •
disc.
Disc rating exceeds the restrict setting. •
Change the rating settings to lower one.
Disc region code is not compatible with •
the unit. Use disc with proper region
code.
No image
Parking brake wire connection is •
incorrect. Check the parking wiring.
Image flashes or distorted
Video DVD settings do not match with •
the DVD. Adjust video DVD settings.
Video connection is improper. Check the •
connections.
Noise in broadcasts.
Signals are too weak. Select other •
stations with stronger signals.
Check the connection of the car antenna. •
Change broadcast from stereo to mono. •
Preset stations lost.
Battery cable is not correctly connected. •
Connect the battery cable to the terminal
that is always live.
Fuse is broken
The Fuse type is incorrect. Replace it with •
a 15A fuse.
Speaker wire or power wire is grounded. •
Check the connections.
Display show ERR-12
USB/SD/MMC data error. Check the USB •
device or SD/MMC card.
About Bluetooth device
Music playback is unavailable on the system
even after successful Bluetooth connection.
The device cannot be used with the •
system to play music.
The audio quality is poor after connection
with a Bluetooth-enabled device.
The Bluetooth reception is poor. Move •
the device closer to the system or
remove any obstacle between the device
and the system.
Cannot connect with the system.
The device does not suppor t the profiles •
required for the system.
The Bluetooth function of the device is •
not enabled. Refer to the user manual of
the device for how to enable the function.
32
EN
Page 32
The system is not in the pairing mode. •
The system is already connected with •
another Bluetooth-enabled device.
Disconnect that device or all other
connected devices and then try again.
The paired mobile phone connects and
disconnects constantly.
The Bluetooth reception is poor. Move •
the mobile phone closer to the system or
remove any obstacle between the mobile
phone and the system.
Some mobile phones may connect and •
disconnect constantly when you make
or end calls. This does not indicate any
malfunction of the system.
For some mobile phones, the Bluetooth •
connection may be deactivated
automatically as a power-saving feature.
This does not indicate any malfunction of
the system.
English
EN
33
Page 33
15 Glossary
B
Bite rate
The max data transfer through the USB por t.
Bluetooth
Bluetooth
that is meant to allow mobile devices to share
information and applications without the
worry of cables or interface incompatibilities.
The name refers to a Viking King who unified
Denmark. Operate at 2.4GHz. For more
information, see www.bluetooth.com.
M
MMC
MultimediaCard. A type of memory card with
a flash memory.
MP3
A file format with a sound data compression
system. MP3 is the abbreviation of Motion
Picture Exper ts Group 1 (or MPEG-1) Audio
Layer 3. With the MP3 format, one CD-R or
CD-RW can contain about 10 times more
data than a regular CD.
®
is a shor t-rang wireless protocol
SDHC
Secure Digital High Capacity (SDHC) is a
type of flash memory card based on the SDA
2.00 specification. The SDA 2.00 specification
enables SD cards to reach higher capacities
from 4GB to 32GB, and growing.
W
WMA (Windows Media Audio)
An audio format owned by Microsoft, is a
part of Microsoft Windows Media technology.
Includes Microsoft Digital Rights Management
tools, Windows Media Video encoding
technology, and Windows Media Audio
encoding technology.
R
Region code
A system that allows discs to be played only
in the region designated. This unit only plays
discs that have compatible region codes. You
can find the region code of your unit on the
product label. Some discs are compatible with
more than one region (or ALL regions.)
S
SD
Secure Digital. A type of memory card with a
flash memory.
34
EN
Page 34
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
CID3695_00_UM_V1.2
Loading...
