Philips CEM3000/51 User guide

Download

www.philips.com/welcome

CEM3000

EN User manual

RU Руководство пользователя

Contents

1 Important 4

Safety 4 Notice 4

7 Adjust sound 18

Adjust volume 18 Mute 18 Turn DBB and subwoofer on/off 18 Select preset equalizer 18 Turn on/off max sound 18 Other sound settings 18

English

2 Your car audio system 6

Introduction 6 What’s in the box 6 Overview of the main unit 7 Overview of the remote control 8

3 Get started 10

Install the car audio 10 Attach the front panel 10 Install remote control battery 10 Turn on 11 Select country/region 11 Set clock 11

4 Listen to radio 11

Tune to a radio station 11 Store radio stations in memory 12 Tune to a preset station 12

5 Play with RDS 12

Turn on RDS 12 Select program type 12 Select alternate frequencies 13 Receive trafﬁc announcement 13 Set RDS clock 13

8 Adjust system settings 19

Select anti-shock setting 19 Turn beep sound on/off 19 Select blackout setting 19 Turn demo mode on/off 19 LCD Color 19 Reset 20

9 Additional information 21

Detach the front panel 21 Replace fuse 21 Remove the unit 21

10 Product information 22

11 Troubleshooting 23

12 Glossary 24

6 Play audio ﬁles 14

Play a disc 14 Play from USB 15 Search for an MP3/WMA track 15 View play information 15 Repeat play 15 Shufﬂe play 16 Intro play 16 Play from iPod/iPhone 16 Connect external sound source 17

1 Important

Safety

Read and understand all instructions • before you use your apparatus. If damage is caused by failure to follow instructions, the warranty does not apply. This apparatus is designed for negative • ground (earth) 12 V DC operation only. To ensure safe driving, adjust the volume • to a safe and comfortable level. Improper fuses can cause damage or • ﬁre. When you need to change the fuse, consult a professional. Use only the supplied mounting hardware • for a safe and secure installation. To avoid short circuit, do not expose the • apparatus, remote control or remote control batteries to rain or water. Never insert objects into the ventilation • slots or other openings on the apparatus. Clean the apparatus and frame with a • soft, damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the apparatus. Never place any objects other than discs • into the apparatus. Never use solvents such as benzene, • thinner, cleaners available commercially, or anti-static sprays intended for discs. Visible and invisible laser radiation when • open. Avoid exposure to beam. Risk of damage to the apparatus screen! • Never touch, push, rub or strike the screen with any object.

Caution

Use of controls or adjustments or • performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Do not place any sources of danger on • the apparatus (e.g. liquid ﬁlled objects, lighted candles).

Notice

The making of unauthorized copies of copy-protected material, including computer programs, ﬁles, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offence. This equipment should not be used for such purposes.

Windows Media and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

“Made for iPod” means that an electronic accessory has been designed to connect speciﬁcally to iPod and has been cer tiﬁed by the developer to meet Apple performance standards. “Works with iPhone” means that an electronic accessory has been designed to connect speciﬁcally to iPhone and has been certiﬁed by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

The apparatus shall not be exposed to • dripping or splashing.

This apparatus includes this label:

Recycling

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When you see the crossed-out wheel bin symbol attached to a product, it means the product is covered by the European Directive 2002/96/EC:

Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products. The correct disposal of your old product helps prevent potentially negative consequences on the environment and human health. Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed of with normal household waste. Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment. Any changes or modiﬁcations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. 2010 © Koninklijke Philips Electronics N.V. All rights reserved. Speciﬁcations are subject to change without notice. Trademarks are the proper ty of Koninklijke Philips Electronics N.V. or their respective owners. Philips reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly.

English

This product complies with the radio inter ference requirements of the European Community.

2 Your car audio

system

Congratulations on your purchase, and welcome to Philips! To fully beneﬁt from the support that Philips offers, register your product at www.philips.com/welcome.

Introduction

d Trim plat e e Carrying case for front panel f Sleeve g Rubber cushion h Screws x 4 pcs i Standard ISO connector j Disassembly tools x 2 pcs k User manual l Quick start guide

With the in-car audio system, you can enjoy your drive while listening to:

FM or AM (MW) radio• Audio from CD or MP3 disc• Audio from USB devices• Audio from iPod/iPhone• Audio from other external devices•

The unit supports the following media format:

What’s in the box

Check and identify the contents of your package:

a Main unit b Remote control c Front panel

dec

lki

Overview of the main unit

English

a DBB/SUB-W

Turn on or off Dynamic Bass Boost • (DBB) sound. Turn on or off subwoofer.•

Unlock the panel.•

c BAND/

Select tuner band.• Return to previous menu.•

Turn the unit on or off.• Conﬁrm selection.• Mute or unmute sound.• Rotate to adjust settings.•

Enter iPod/iPhone control mode.•

Eject disc.•

Connector for USB and iPod/iPhone.•

h MP3 LINK

Connect external audio device.•

i +SONG/FOLDER -

Select preset radio station.• Search for track/folder.• Access manual store.•

j OPTIONS/CLOCK

Access option menu.• View clock.•

Tune for radio station.• Skip/search for track.• Fast forward/backward playback.•

l DISP/

In FM/USB mode, press and hold to • select LCD color. In tuner or iPod/iPhone mode, press • brieﬂy to display station info or iPod/ iPhnoe info. In iPod/iPhone mode, press and hold • to access music search mode.

m MENU

Access system menu.•

 6281'

Select MAX Sound audio setting.•

o EQ AUDIO

Select equalizer (EQ) setting.• Access audio setting menu.•

p SOURCE

Select audio source.•

q RESET

Restore default settings.•

r Disc slot

Overview of the remote control

%$1'

92/

621*

)2/'(5

35(6(7

a PRESET +/-

Select preset radio station.• Access manual store.•

b OPTIONS

Access option menu.•

Star t play.• Pause or resume play.•

d AUDIO

Access audio setting menu.•

Tune to a radio station• Skip track.• Fast backward/forward playback•

f OK

Conﬁrm selection.•

g MENU

Access system menu.•

/PWR/

Turn the unit on or off.• Mute or restore volume.•

i VOLUME +/-

Adjust volume.•

j BAND/

Select tuner band.• Return to previous/top menu. •

k SOURCE

Select audio source.•

Enter iPod/iPhone control mode.•

 6281'

Select MAX Sound audio setting.•

n EQ

Select equalizer (EQ) setting.•

o DBB

Turn on or off Dynamic Bass Boost • (DBB) sound.

p SONG

Search for track.•

q FOLDER

Search for folder.•

r DISP/

s CLOCK

View clock.•

English

3 Get started

Caution

Use the controls only as stated in this user • manual.

Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of your apparatus. The model number and serial number are on the bottom of your apparatus. Write the numbers here: Model No. __________________________ Serial No. ___________________________

Install the car audio

Please refer to the “Installation guide” in Quick start guide.

Attach the front panel

Install remote control battery

Caution

Risk of explosion! Keep batteries away from • heat, sunshine or ﬁre. Never discard batteries in ﬁre. Risk of decreased bat ter y life! Never mix • different brands or types of batteries.

•

Risk of produc t damage! When the remote control is not used for long periods, remove the batteries. Perchlorate Material - special handling may • apply. See www.dtsc.ca.gov/hazardouswaste/ perchlorate.

For ﬁrst-time use:

1 Remove the protective tab to activate the

remote control battery.

1 Attach the trim plate.

2 Inser t the right side of the panel in the

chassis until it is correctly engaged.

3 Press the left side of the panel until the

mechanism locks it into place.

To replace the remote control battery:

1 Open the battery compartment. 2 Inser t one CR2025 battery with correct

polarity (+/-) as indicated.

3 Close the battery compar tment.

Turn on

4 Listen to radio

1 Press to turn on the unit.

To turn off the unit, press • 3 seconds.

for over

Select country/region

Note

Select correct country/region for this unit, • otherwise the unit can not work properly.

1 Press to turn on the unit.

» [SELECT OPERATING REGION] is

displayed.

2 Rotate to select an option:

[USA] (United States)• [Latin] (Latin America)• [Europe] (Western Europe)• [ASIA] (Asia Paciﬁc)• [Mid-East ] (Middle East)• [Russia] (Russia)•

3 Press to conﬁrm.

Set clock

1 Press MENU. 2 Press / repeatedly until [CLK SET]

displays.

3 Rotate encoder clockwise to set hour. 4 Press to conﬁrm. 5 Rotate encoder anti-clockwise to set

minute.

6 Press to conﬁrm.

View clock

1 Press and hold OPTIONS repeatedly

until the clock is displayed.

Tune to a radio station

1 Press SOURCE repeatedly to select radio

mode.

2 Press BAND/ to select band: [FM1],

[FM2], [FM3], [AW1] or [AW2] .

3 Press or to tune to a radio station

manually.

The radio station is broadcast. » To search for a radio station »

automatically, press 3 seconds.

or for over

Select tuner region

You can select suitable country/region of the radio.

1 Press SOURCE to select Radio mode. 2 Press MENU. 3 Press / repeatedly until [AREA]

displays.

4 Rotate to select:

• [USA] (United States)

• [LATIN] (Latin America)

• [Europe] (Western Europe)

• [OIRT] (Russia)

Select tuner sensitivity

To receive more radio stations or only stations with strong signal, you can adjust the tuner sensitivity.

1 Press OPTIONS repeatedly to select

[LOCAL SEEK].

2 Rotate to select a setting:

• [LOCAL SEEK ON]: Only stations with strong signal can be broadcast.

• [LOCAL SEEK OFF]: Stations with strong and weak signals can be broadcast.

English

Store radio stations in memory

5 Play with RDS

You can store up to 6 stations in each band.

Store stations automatically

1 Press OPTIONS repeatedly until

[AUTO-STORE] displays.

2 Press to conﬁrm.

The six strongest stations of the » selected band are saved in preset channel automatically.

Store stations manually

1 Tune to a station that you want to store. 2 Press and hold +/PRESET or -/RRESET to

enter storing mode.

The preset number on LCD screen » blinks..

3 Press +/PRESET or -/RRESET to select

storing location.

4 Press to conﬁrm.

The station is saved in the selected » channel.

The preset number on LCD screen » lights up and remains on.

Tune to a preset station

1 Press BAND/ to select band. 2 Press +/PRESET or -/RRESET to select

the preset station.

The RDS (Radio Data System) function operates only in areas with FM stations broadcasting RDS signals. If you tune to an RDS station, an RDS icon and information about the presenter, station or program is displayed.

Turn on RDS

Note

The default setting for RDS is off. •

1 Press MENU. 2 Press / repeatedly until [RDS]

displays.

3 Rotate to select RDS ON:

The RDS function is turned on. »

Select program type

Before tuning to RDS stations, you can select program type and let the unit search only for programs of the selected category.

1 Press OPTIONS until [PTY] displays. 2 Press to conﬁrm. 3 Rotate to select a type, then press

to conﬁrm.

Item Program type Description

1 NEWS News services 2 AFFAIRS Politics and current

affairs

3 INFO Special information

programs 4 SPORT Sports 5 EDUCATE Education and

advanced training

6 DRAMA Radio plays and

literature

7 CULTURE Culture, religion and

society 8 SCIENCE Science 9 VARIED Entertainment

programs 10 POP M Pop music 11 ROCK M Rock music 12 EASY M Light music 13 LIGHT M Light classical music 14 CLASSICS Classical music 15 OTHER M Special music

programs 16 WEATHER Weather 17 FINANCE Finance 18 CHILDREN Children’s programs 19 SOCIAL Social Affairs 20 RELIGION Religion 21 PHONE IN Phone In 22 TRAVEL Trave l 23 LEISURE Leisure 24 JAZZ Jazz Music 25 COUNTRY Country Music 26 NATION M National Music 27 OLDIES Oldies Music 28 FOLK M Folk Music 29 DOCUMENT Documentary 30 TEST Alarm Test 31 ALARM Alarm

Set region for AF tuning

You can deﬁne AF tuning region:

[REG ON]

[REG OFF]

Only stations in current region can be tuned to automatically.

All stations can be tuned to automatically.

1 Press MENU. 2 Press / repeatedly until [REG]

displays.

3 Rotate to select a setting.

Receive trafﬁc announcement

If you do not want to miss trafﬁc announcement when enjoying music, turn on the TA (Trafﬁc Announcement) function.

1 Press OPTIONS. 2 Press / repeatedly until [TA]

displays.

3 Rotate to select a setting:

• [TA ON]: When there is trafﬁc announcement, the unit switches to the tuner mode (regardless of the current mode) and begins to broadcast the trafﬁc conditions. When the trafﬁc announcement is over, it returns to the previous mode.

• [TA OFF]: Trafﬁc announcement does not cut in.

English

Select alternate frequencies

If the radio signal is poor, turn on AF (Alternate Frequency) to search for another station with stronger signal.

1 Press OPTIONS. 2 Press / repeatedly until [AF] displays. 3 Rotate to select a setting:

• [AF ON]: Turn on the AF mode.

• [AF OFF]: Turn off the AF mode.

Set RDS clock

You can use time signal that is broadcast together with the RDS signal to set the clock of the unit automatically.

1 Press MENU. 2 Press / repeatedly until [CT]

displays.

3 Rotate to select a setting:

• [CT ON]: Turn on the RDS clock. Time shown on the unit synchronizes with that on the RDS station.

• [CT OFF]: Turn off the RDS clock.

Tip

The accuracy of the transmitted time depends • on the RDS station that transmits the time signal.

6 Play audio files

Note

Ensure that the disc or device contains playable • ﬁles.

Play a disc

Note

You cannot play CDs encoded with copyright • protection technologies.

You can play commercially available audio CDs and these discs:

CD-Recordables (CD-R)• CD-Re-writables (CD-RW)• MP3 CDs• WMA CDs•

Note

Ensure that the disc contains playable content. •

1 Inser t a CD with the printed side facing

up.

Play starts automatically. »

To pause CD play, press • To resume CD play, press• To skip to the previous/next track, press •

or . To search backward/forward rapidly • within the current track, press for 3 seconds.

Remove the CD

To take out the CD, press

Tip

If the disc is blocked in the disc compartment, • press and hold until the disc comes out.

again.

on the front panel.

Play from USB

Note

Ensure that the USB device contains playable • music.

Insert the USB device

1 Slide the USB socket cover marked

to the lef t.

2 Inser t the USB device into the USB

socket.

The unit starts playing from the USB » device automatically.

1 Press +SONG.

The name of the current track displays. »

2 Rotate to select another track in current

folder

3 Press to conﬁrm.

Search in other folder

1 Press FOLDER -.

The name of the current folder » displays.

2 Rotate to navigate through all folders. 3 Press to access the selected folder. 4 Rotate to select a track in the folder. 5 Press to start play.

Tip

To go back to upper level of a folder, press • .

View play information

1 During playing, press DISP repeatedly to

view:

Track number and elapsed play time• Artist • Album • Title • Folder • File •

English

Remove the USB device

1 Press to turn off the unit. 2 Remove the USB device.

Search for an MP3/WMA track

Search within the current folder

Repeat play

1 During play, press OPTIONS repeatedly

until [REPEAT] displays.

2 Rotate to select a setting.

• [REPEAT ALL]: play all tracks repeatedly.

• [REPEAT TRK]: play current track repeatedly.

• [REPEAT FLD]: play all tracks in the current folder repeatedly.

Shufﬂe play

You can play the tracks in random order:

1 During play, press OPTIONS repeatedly

until [RANDOM] displays.

2 Rotate to select a setting:

• [RANDOM OFF]: Turn off random

play.

• [RANDOM FLD]: star t random play

for all tracks in the current folder.

• [RANDOM ALL]: start random play

for all tracks.

Intro play

You can play the ﬁrst 10 seconds of each track.

1 During play, press OPTIONS repeatedly

until [INTRO] displays.

2 Rotate to select a setting:

• [INTRO OFF]: Cancel intro play and

start normal play.

• [INTRO FLD]: Start introl play in the

current folder.

• [INTRO ALL]: Play the ﬁrst 10

seconds of each track.

iPod nano (3rd generation, 4GB only)• iPod nano (3rd generation, 8GB only)• iPod nano (4th generation)• iPod nano (5th generation)• iPod classic (1st generation)• iPod classic (2nd generation)• iPod touch (1st generation)• iPod touch (2nd generation)• iPod touch (3rd generation)• iPod video (30GB, 80GB only)• Works with iPhone • iPhone 3G• iPhone 3GS• iPhone 4•

Connect iPod/iPhone

1 Slide the USB socket cover marked

to the lef t.

2 Inser t USB adaptor on one end of iPod/

iPhone cable to the USB socket on the main unit.

3 Inser t the other end of the iPod/iPhone

cable to the iPod/iPhone socket.

The unit starts playing from the USB » device automatically.

Play from iPod/iPhone

You can enjoy audio from iPod/iPhone through this unit.

Compatible iPod/iPhone

Apple iPod and iPhone models with a 30-pin dock connector: Made for.

iPod nano (2nd generation)•

Control music playback on iPod/ iPhone

1 Ensure that the iPod/iPhone is connected

correctly.

2 Press SOURCE to select iPod USB mode. 3 Press repeatedly to toggle between the

two control modes:

• iPod control mode: Use the buttons/

touch screen on iPod/iPhone to control the music.

• Audio control mode: Use the

control buttons on car audio to control the music.

To control playback under audio control mode:

To pause/resume play, press• To skip to a track, press • To search during play, press and • hold

/ , then release to resume normal play. To navigate the menu, press • , rotate to select, then press to conﬁrm.

/ .

Connect external sound source

1 Connect the external sound source to

MP3 LINK socket with a 3.5 mm cable.

2 Press SOURCE repeatedly until [MP3

LINK] is displayed.

3 Operate the external component (refer

to the instructions supplied with the external component).

English

Search for an MP3/WMA track

1 Press SOURCE repeatedly to select iPod

mode.

2 Press BAND/ to browse iPod/iPhone

menu.

3 Rotate to select the Artist search mode,

and press

to conﬁrm.

4 Press DISP/ to search alphabetically. 5 Rotate to select desired ar tist, then

press

to conﬁrm.

6 Rotate to select desired song in current

album.

7 Press to start play.

Note

User cannot control the music via iPod/iPhone • under audio control mode.

7 Adjust sound

Adjust volume

1 Turn clockwise/anticlockwise to

increase/decrease volume.

• [POP] (pop)

• [USER] (user)

• [TECHNO] (techno)

• [ROCK] (rock)

• [CLASSIC] (cla ssi c)

• [JAZZ] (jazz)

Turn on/off max sound

Mute

You can turn off the sound of your audio.

1 During play, press .

To resume sound, press •

again.

Turn DBB and subwoofer on/ off

1 Press DBB, then the current setting is

displayed:

» [DBB ON] : The Dynamic Bass Boost

(DBB) function is on.

» [DBB OFF] : The DBB function is off.

2 Press DBB again to change the DBB

setting.

3 Press and hold DBB to access subwoofer

settings:

» [SUBWOOFER ON]: The subwoofer

function is on.

» [SUBWOOFER OFF]: The subwoofer

function is off.

Select preset equalizer

1 Press EQ/Audio.

Current Equalizer setting is displayed. »

2 Press EQ/Audio again to select a preset

EQ setting:

• [OPTIMAL] (optimal)

• [FLAT] (ﬂat)

1 Press

 6281'

The current setting displays »

» [MAX ON]: The maximum sound

(max sound) function is on.

» [MAX OFF]: The maximum sound

function is off.

Other sound settings

You can also adjust the preset EQ/Audio settings.

1 Press EQ/Audio for 3 seconds. 2 Press / repeatedly to select the item

to be adjusted:

• [BASS LEVEL] range: -7 to +7

• [BASS CFQ] (bass center frequency) range: 60, 80, 100, 200.

• [MIDDLE LEVEL] range:-7 to +7

• [MIDDLE CFQ] (middle center frequency) range: 0.5k, 1.0k, 1.5k,

2.5k.

• [TREBLE LEVEL] range: -7 to +7

• [TREBLE CFQ] (treble center frequency) range: 10.0k, 12.5k, 15.0k,

17.5 k .

• [BALANCE] range: 12L to 12R. (L= left speaker, R = right speaker)

• [FADER] range: 12R to 12F. (R = rear speaker, F = front speaker)

• [SUBWOOFER] range:0 to 12.

• [RESUME]: Resume the preset EQ value to factory default value.

3 Rotate to select a value.

8 Adjust system

settings

Select anti-shock setting

You can select anti-shock setting according to the stability of your car and the condition of the road.

1 Press MENU. 2 Press / repeatedly until [ESP]

displays.

3 Turn to select a setting:

• [ESP 10S]: when the road is smooth and there are few bumps.

• [ESP 40S]: when the road is bumpy and unstable.

Turn beep sound on/off

Each time you press a button, the unit beeps. You can turn on or off this beep sound.

1 Press MENU. 2 Press / repeatedly until [BEEP]

displays.

3 Rotate to select a setting:

• [BEEP ON]: Turn on the beep sound.

• [BEEP OFF]: Turn off the beep sound.

Select blackout setting

You can set the screen to turn off automatically after the unit is idle for 10 or 20 seconds.

1 Press MENU. 2 Press / repeatedly until [BLKOUT]

displays.

3 Rotate to select a setting:

• [BKO 10 S] : Turn off the screen automatically 10 seconds after last operation.

• [BKO 20 S] : Turn off the screen automatically 20 seconds after last operation.

• [BKO OFF] : Never turn off the screen.

Turn demo mode on/off

1 Press MENU. 2 Press / repeatedly until [DEMO]

displays.

3 Rotate to select a setting:

• [DEMO ON] : Turn on the demo mode. When the unit is idle for more than 10 seconds, all functions are displayed.

• [DEMO OFF] : Turn off the demo mode.

LCD Color

You can change LCD background color.

1 Press MENU. 2 Press / repeatedly until [LCD

COLOR] displays.

3 Rotate to select a setting:

• [DEFAULT] (default set ting)

• [COLOR SCAN] (color scan)

• [WHITE] (white)

• [GREEN 1] (green 1)

• [GREEN 2] (green 2)

• [GREEN 3] (green 3)

• [AMBER] (amber)

• [PINK 1] (pink 1)

• [PINK 2] (pink 2)

• [PURPLE 1] (purple 1)

• [PURPLE 2] (purple 2)

• [BLUE 1] (blue 1)

• [BLUE 2] (blue 2)

• [USER COLOR] (user color)

English

Turn demo mode on/off

1 Press MENU. 2 Press / repeatedly until [LCD

COLOR] displays.

3 Press . 4 Rotate to select [USER COLOR]. 5 Press to conﬁrm. 6 Rotate to adjust color of the LCD.

R(red)/G(green)/B(blue)

7 Press to exit user color setting mode.

Reset

You can reset the unit to its default setting.

1 Detach the front panel. 2 Press the reset button by using a ball-

point pen or a similar tool.

Preset adjustments such as preset » channels and sound adjustments are erased.

9 Additional

information

Detach the front panel

You can detach the front panel to deter theft.

1 Press to release the panel. 2 Push the left side of the panel rightward.

3 Pull the panel towards you to disengage it

from the chassis.

4 Store the panel in the supplied carry case

to protect it from dir t or damage.

English

Note

If the new fuse gets damaged again, there may • be an internal malfunction. Consult your Philips dealer.

Remove the unit

You can remove the unit from the dashboard.

1 Detach the front panel. 2 Pull out the unit by using the disassembly

tools.

Replace fuse

If the fuse is damaged,

1 Check the electric connection. 2 Buy a fuse that matches the voltage of the

damaged fuse.

3 Replace the fuse.

10 Product

information

Note

Product information is subject to change • without prior notice.

Power supply 12 V DC (11 V - 16 V),

negative ground Fuse 15 A Suitable speaker

impedance Maximum power

output Continuous power

output Pre-Amp output

voltage Aux-in level Dimensions

(W x H x D) 188 x 58 x 201 mm Weight 1.47 kg

Radio

Frequency range

- FM

Frequency range

- AM(MW) Usable sensitivity

- FM Usable sensitivity

- AM(MW) (S/N = 20 dB)

4 - 8

50 W x 4 channels

24 W x 4 RMS

(4 10% T.H.D.)

2.5 V

500 mV

65.0 - 74.0 MHz

87.5 - 108.0 MHz (100kHz per step in auto search and 50kHz per step in manual search)

522 - 1620 KHz (9 kHz) 530 - 1710 kHz (10 kHz)

8 μV

30 μV

Compatible USB devices:

USB ﬂash memory: USB 1.1 host with • inter face reading all speed suppor t (1.1,

2.0) USB ﬂash players: USB 1.1 host with • inter face reading all speed suppor t (1.1,

2.0)

Supported formats:

USB or memory ﬁle format: FAT16, • FAT32 MP3 bit rate (data rate): 32-320 Kbps and • variable bit rate WMA V4, V7, V8, V9 (L1, L2)• ISO9660, Joliet• Maximum title number: 512 (depending • on ﬁle name length) Maximum album number: 255• Supported sampling frequencies: 2 kHz, •

44.1 kHz, 48 kHz Supported Bit-rates: 2~256 (kbps), • variable bit rates Directory nesting up to a maximum of 8 • levels Number of albums/ folders: CD • maximum 99, USB maximum 199 Number of tracks/titles: maximum 999• ID3 tag v2.0 or later• File name in Unicode UTF8 (maximum • length 64 by tes)

Unsupported formats:

Empty albums: an empty album is an • album that does not contain MP3/WMA ﬁles, and is not be shown in the display. Unsupported ﬁle formats are skipped. For • example, Word documents (.doc) or MP3 ﬁles with extension .dlf are ignored and not played. AAC, WAV, PCM audio ﬁles• DRM protected WMA ﬁles (.wav, .m4a, • .m4p, .mp4, .aac) WMA ﬁles in Lossless format•

11 Troubleshooting

Caution

Never remove the casing of this apparatus. •

The CD skips tracks

Ensure that the CD is not damaged or • dirty. Ensure that random mode is deactivated. •

Disc cannot be ejected

Press and hold • .

English

To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www. philips.com/support). When you contact Philips, ensure that your apparatus is nearby and the model number and serial number are available.

No power or no sound.

Car engine is not on. Turn the car engine • on. Cable is not correctly connected. Check • connections. Fuse is burnt. Replace fuse. • Volume is too low. Adjust volume. • If the above solutions cannot help, press • the RESET button. Ensure that the track played is of a • compatible format.

Noise in broadcasts.

Signals are too weak. Select other • stations with stronger signals. Check the connection of the car antenna. • Change broadcast from Stereo to mono. •

Preset stations lost.

Battery cable is not correctly connected. • Connect the battery cable to the terminal that is always live.

Display show ERR-12

USB data error. Check the USB device. •

Cannot play disc

Ensure that the disc label is inser ted with • the printed side facing up. Wipe the disc with ﬁbre cleaning cloth • from the centre to the edge in a straight line. This disc may be defective. Play another • disc. Ensure that the CD is a ﬁnalised CD/ • CD-R/CD-RW. Ensure that the CD is not encoded with • copyright protection technologies.

12 Glossary

MP3

A ﬁle format with a sound data compression system. MP3 is the abbreviation of Motion Picture Exper ts Group 1 (or MPEG-1) Audio Layer 3. With the MP3 format, one CD-R or CD-RW can contain about 10 times more data than a regular CD.

WMA (Windows Media Audio)

An audio format owned by Microsoft, is a part of Microsoft Windows Media technology. Includes Microsoft Digital Rights Management tools, Windows Media Video encoding technology, and Windows Media Audio encoding technology.

Document order number: CEM3000_51_UM_V1.0

Philips CEM3000/51 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual
