Register your product and get support at
www.philips.com/welcome
CD690
CD695
User manual
Contents
1 Important safety instructions 3
2 Your phone 4
What is in the box 4
Overview of the phone 5
Overview of the base station 6
Main menu icons 7
Display icons 7
3 Get started 8
Connect the base station 8
Install the handset 9
Congure your phone (country
dependent) 9
Change the remote access PIN code 10
Charge the handset 10
Check the battery level 11
What is standby mode? 11
Check the signal strength 11
4 Calls 12
Make a call 12
Answer a call 13
End a call 13
Adjust the earpiece/speaker volume 13
Mute the microphone 13
Turn the speaker on or off 13
Make a second call 13
Answer a second call 14
Switch between two calls 14
Make a conference call with the
external callers 14
7 Phonebook 18
View the phonebook 18
Search a record 18
Call from the phonebook 18
Access the phonebook during a call 18
Add a record 19
Edit a record 19
Delete a record 19
Delete all records 19
Set the personalized melody 20
Add a contact to the exception list 20
8 Call log 21
Call list type 21
View the call records 21
Save a call record to the phonebook 21
Return a call 21
Delete a call record 22
Delete all call records 22
9 Redial list 23
View the redial records 23
Redial a call 23
Save a redial record to the phonebook 23
Delete a redial record 23
Delete all redial records 23
10 Phone settings 24
Set the date and time 24
ECO mode 24
Name the handset 24
Set the display language 24
English
5 Intercom and conference calls 15
Make a call to another handset 15
Transfer a call 15
Make a conference call 16
6 Text and numbers 17
Enter text and numbers 17
Switch between uppercase and
lowercase 17
11 Alarm clock 25
Set the alarm 25
Turn off the alarm 25
12 Display settings 26
Set the display 26
EN 1
13 Sound settings 27
Set the handset's ringtone volume 27
Set the handset's ringtone 27
Silent mode 27
Set the key tone 28
Set the docking tone 28
Set the sound prole 28
14 Services 29
Auto conference 29
Call barring 29
Call list type 29
Auto prex 30
Network type 30
Select the recall duration 30
Dial mode 30
First ring 31
Auto clock 31
Register the handsets 31
Unregister the handsets 32
Call services 32
Restore default settings 33
15 Baby monitor 34
Activate/Deactivate the baby monitor 34
Send an alert 34
Set the baby cry level 35
18 Notice 42
Declaration of conformity 42
Use GAP standard compliance 42
Compliance with EMF 42
Disposal of your old product and
batteries 42
19 Frequently asked questions 44
20 Appendix 45
Text and number input tables 45
21 Index 47
16 Telephone answering machine 36
Turn the answering machine on or off 36
Set the answering machine language 36
Set the answer mode 36
Announcements 36
Incoming messages (ICM) 37
Call screening 38
Set the sound quality of the message 39
Set the ring delay 39
Remote access 39
Behavior of the LED display on the
base station 40
17 Technical data 41
2 EN
1 Important safety
instructions
Power requirements
• This product requires an electrical supply of
100-240 volts AC. In case of power failure,
the communication can be lost.
• The voltage on the network is classied
as TNV-3 (Telecommunication Network
Voltages), as dened in the standard EN
60950.
Warning
•
The Electrical network is classied as hazardous. The
only way to power down the charger is to unplug the
power supply from the electrical outlet. Ensure that the
electrical outlet is always easily accessible.
To avoid damage or malfunction
Caution
Use only the power supply listed in the user
•
instructions.
• Use only the batteries listed in the user instructions.
• Risk of explosion if battery is replaced by an incorrect
type.
• Dispose of used batteries according to the instructions.
• Always use the cables provided with the product.
• Do not allow the charging contacts or the battery to
come into contact with metal objects.
• Do not let small metal objects come into contact with
the product. This can deteriorate audio quality and
damage the product.
• Metallic objects may be retained if placed near or on
the handset receiver.
• Do not use the product in places where there are
explosive hazards.
• Do not open the handset, base station or charger as
you could be exposed to high voltages.
• For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
• Handsfree activation could suddenly increase the
volume in the earpiece to a very high level: make sure
the handset is not too close to your ear.
• This equipment is not designed to make emergency
calls when the power fails. An alternative has to be
made available to allow emergency calls.
• Do not allow the product to come into contact with
liquids.
• Do not use any cleaning agents containing alcohol,
ammonia, benzene, or abrasives as these may harm
the set.
• Do not expose the phone to excessive heat caused by
heating equipment or direct sunlight.
• Do not drop your phone or allow objects to fall on
your phone.
• Active mobile phones in the vicinity may cause
interference.
When using the phone as a baby monitor
Caution
Children should be supervised to ensure that they do
•
not play with the appliance.
• Make sure the baby unit and the cord are always out of
reach of the baby (at least 1 metre/3 feet away).
• Keep the parent unit at least 1.5 metres/5 feet away
from the baby unit to prevent acoustic feedback.
• Never place the baby unit inside the baby’s bed or
playpen.
• Never cover the parent unit and the baby unit with
anything (e.g. a towel or blanket). Always make sure the
cooling vents of the baby unit are free.
• Take every precaution to make sure that your baby can
sleep safely .
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• If you place the parent unit next to a transmitter or
other DECT appliance (e.g. a DECT telephone or
wireless router for the internet), the connection with
the baby unit may be lost. Move the baby monitor
further away from the other wireless appliances until
the connection is restored.
• This baby monitor is intended as an aid. It is not a
substitute for responsible and proper adult supervision
and should not be used as such.
About operating and storage temperatures
• Operate in a place where temperature is
always between 0°C to +40°C (up to 90%
relative humidity).
• Store in a place where temperature is
always between -20°C and +45°C (up to
95% relative humidity).
• Battery life may be shorter in low
temperature conditions.
English
EN 3
2 Your phone
Congratulations on your purchase and welcome
to Philips!
To fully benet from the support that Philips
offers, register your product at www.philips.com/
welcome.
What is in the box
Base station (CD690)
Base station (CD695)
Power adapter**
Line cord*
Warranty
User manual
Handset**
Charger**
4 EN
4XLFNVWDUWJXLGH
Quick start guide
Note
* In some countries, you have to connect the line
•
adapter to the line cord, then plug the line cord into
the telephone socket.
Note
** In multi-handset packs, there are additional handsets,
•
chargers and power adapters.
Overview of the phone
a Earpiece
b Loudspeaker
c Battery door
d
• Scroll up on the menu.
• Increase the earpiece/speaker volume.
• Access the phonebook.
e
• Delete text or digits.
• Cancel operation.
f
/
Move the cursor to the left or right in
editing mode.
g
• End the call.
• Exit the menu/operation.
h
• Press to enter a space during text
editing.
• Press and hold to lock the keypad.
i
• Make a predial call.
• Press and hold to enter a pause.
• Switch to upper/lower case during
editing.
j
Mute or unmute the microphone.
k Microphone
l
• Turn the speaker phone on or off.
• Make and receive calls through the
speaker.
m
Press and hold to make an intercom call
(for multi handset version only).
n
• Scroll down on the menu.
• Decrease the earpiece/speaker volume.
• Access the call log.
o
• Make and receive calls.
p
• Access the main menu.
• Conrm selection.
• Enter the options menu.
• Select the function displayed on the
handset screen directly above the key.
English
EN 5
Overview of the base station
CD690
CD695
a
• Find handsets.
• Enter the registration mode.
a Message counter
b
/
Decrease/increase the speaker volume.
c
Skip forward during playback.
d Speaker
e
Turn the answering machine on or off.
f
• Play messages.
• Stop messages playback.
g
• Delete the current playback message.
• Press and hold to delete all old
messages.
h
Skip backward during playback.
i
• Find handsets
• Enter the registration mode.
6 EN
Main menu icons
Display icons
The following is an overview of the menu
options that are available in your CD690/695.
For detailed explanation of the menu options,
see the corresponding sections in this user
manual.
Icon Descriptions
[Phone setup] - Set the date and time,
ECO mode, handset name and display
language.
[Sounds] - Set the ring volume, ring
tone, key tone etc.
[Services] - Set the auto conference,
auto prex, network type, recall time,
auto clock, call services etc.
The services are network and country
dependent.
[Alarm] - Set date and time, alarm, alarm
tone etc.
[Phonebook] - Add, edit, manage
phonebook entries etc.
[Incoming calls] - Displays the call
history of all missed or received calls.
[Display] - Set the brightness, screen
saver etc.
[Baby monitor] - Set the alert to an
external line or other handsets and the
baby cry level.
[Intercom] - Make a call to another
handset This icon is available only in
CD690.
[Answer machine] - Setup, listen to,
delete phone messages, etc. This icon is
available only in CD695.
In standby mode, the icons shown on the main
screen tell you what features are available on
your handset.
Icon Descriptions
When the handset is off the base
station/charger, the bars indicate the
battery level (from full to low).
When the handset is on the base
station/charger, the bars keep scrolling
until charging is complete.
The empty battery icon ashes and you
hear an alert tone.
The battery is low and needs
recharging.
The number of bars indicates the link
status between the handset and base
station. The more bars are shown, the
better the signal strength is.
It is red on the standby screen when
there is a new missed call.
It is red in the incoming call list when
there is an unread missed call.
It is green in the incoming call list when
there is a read missed call.
The alarm is activated.
The speaker is on.
The ringer is off.
Answering machine: it ashes when
there is a new message. It displays when
the telephone answering machine is
turned on.
It ashes when there is a new voice
message.
It remains steadily on when the voice
messages are already viewed in the call
log.
The icon is not shown when there is no
voice message.
The silent mode is activated.
ECO The ECO mode is activated.
English
EN 7
3 Get started
Caution
Make sure that you have read the safety instructions in
•
the 'Important safety instruction' section before you
connect and install your handset.
Connect the base station
Warning
•
Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back or underside of the phone.
• Use only the supplied power adapter to charge the
batteries.
Note
If you subscribe to the digital subscriber line (DSL)
•
high speed internet service through your telephone
line, ensure you install a DSL lter between the
telephone line cord and the power socket.. The lter
prevents noise and caller ID problems caused by DSL
interference. For further information on DSL lters,
contact your DSL service provider.
• The type plate is located on the bottom of the base
station.
Connect each end of the power adapter to:
1
• the DC input jack at the bottom of the
base station;
• the power socket on the wall.
Connect each end of the line cord to:
2
• the telephone socket at the bottom of
the base station;
• the telephone socket on the wall.
Connect each end of the power adapter to
3
(for multi handset versions only):
• the DC input jack at the bottom of the
extra handset charger.
• the power socket on the wall.
8 EN
Install the handset
The batteries are pre-installed in the handset.
Pull the battery tape off from the battery door
before charging.
Caution
Risk of explosion! Keep batteries away from heat,
•
sunshine or re. Never discard batteries in re.
• Use only the supplied batteries.
• Risk of decreased battery life! Never mix different
brands or types of batteries.
Note
Charge the batteries for 8 hours before rst use.
•
• If the handset becomes warm when the batteries are
charging, it is normal.
Congure your phone
(country dependent)
When using your phone for the rst time,
1
you see a welcome message.
Press [OK].
2
Set the country/language
Select your country/language, then press [OK]
to conrm.
» The country/language setting is saved.
Note
The country/language setting option is country
•
dependent. If no welcome message is displayed, it
means the country/language setting is preset for your
country. Then you can set the date and time.
To re-set the language, see the following steps.
Select [Menu] > > [Language], then
1
press [OK] to conrm.
Select a language, then press [OK] to
2
conrm.
» The setting is saved.
English
Warning
•
Check the battery polarity when inser ting in the
battery compar tment. Incorrect polarity may damage
the product.
EN 9
Set the date and time
Select [Menu] > > [Date & time], then
1
press [OK] to conrm.
Select [Set date]/[Set time], then press
2
[OK] to conrm.
Press the numeric buttons to enter the
3
date and time.
Note
•
If the time is in 12-hour format, press to select [AM]
or [PM].
Press [OK] to conrm.
4
Set the date and time format
Select [Menu] > > [Date & time], then
1
press [OK] to conrm.
Select [Date format] or [Time format].
2
Press / to select [DD-MM-YYYY] or
3
[MM-DD-YYYY] as the date display, and
[12 Hours] or [24 Hours] as the time
display. Then press [OK] to conrm.
» The setting is saved.
Note
The date and time format setting is country dependent.
•
Change the remote access PIN code
Note
The default answering machine remote access PIN
•
code is 0000 and it is important to change it to ensure
the security.
Select [Menu] > > [Remote access] >
1
[Change PIN], then press [OK] to conrm.
Enter the old PIN, then press [OK] to
2
conrm.
Enter the new PIN code, then press [OK]
3
to conrm.
Enter the new PIN code again, then press
4
[Save] to conrm.
» The setting is saved.
Charge the handset
Place the handset on the base station to charge
the handset. When the handset is placed
correctly on the base station, you hear a docking
sound.
» The handset starts charging.
Note
Charge the batteries for 8 hours before rst use.
•
• If the handset becomes warm when the batteries are
being charged, it is normal.
10 EN
You can activate or deactivate the docking tone
(see 'Set the docking tone' on page 28).
Your phone is now ready to use.
Check the battery level
Check the signal strength
The battery icon displays the current battery
level.
When the handset is off the base
station/charger, the bars indicate the
battery level (from full to low).
When the handset is on the base
station/charger, the bars ash until
charging is complete.
The empty battery icon ashes. The
battery is low and needs recharging.
If you are on the phone, you hear warning
tones when the batteries are almost empty.
The handset turns off when the batteries are
completely empty.
The number of bars indicates the link
status between the handset and base
station. The more bars are shown, the
better the connection is.
• Make sure the handset is linked to the base
station before you make or receive calls
and carry out the functions and features.
• If you hear warning tones when you are
on the phone, the handset is almost out
of battery or the handset is out of range.
Charge the battery or move the handset
close to the base station.
English
What is standby mode?
Your phone is in standby mode when it is idle.
When the handset is off the charging cradle,
the standby screen displays the date and time.
When the handset is on the charging cradle,
the standby screen displays the time as a screen
saver.
EN 11
4 Calls
Note
When the power fails, the phone cannot access
•
emergency services.
Tip
Check the signal strength before you make a call or
•
when you are in a call (see 'Check the signal strength'
on page 11).
Make a call
Call from the redial list
You can make a call from the redial list (see
'Redial a call' on page 23).
Redial the most recent number
Press [Redial].
1
» The redial list is displayed and the most
recent number is highlighted.
Press .
2
» The most recent number is then dialed
out.
Call from the phonebook
You can make a call from the phonebook list
(see 'Call from the phonebook' on page 18).
You can make a call in these ways:
• Quick call
• Dial before you call
• Redial the most recent number
• Call from the redial list.
• Call from the phonebook list
• Call from the call log
Quick call
Press or .
1
Dial the phone number.
2
» The number is dialed out.
» The duration of your current call is
displayed.
Dial before you call
Dial the phone number
1
• To erase a digit, press [Clear].
• To enter a pause, press and hold
Press or to dial out the call.
2
Call from the call log
You can return a call from the received or
missed call log (see 'Return a call' on page 21).
Note
The call timer displays the talk time of your current call.
•
Note
If you hear warning tones, the handset is almost out
•
of battery or the handset is out of range. Charge the
battery or move the handset nearer to the base station.
.
12 EN
Answer a call
When there is an incoming call, the phone rings
and the LCD backlight ashes. Then you can:
• press
• select [Divert] to send incoming call to
• select [Silent] to turn off the ringer of the
or to answer the call.
the answering machine (only applied to
CD695).
current incoming call.
Adjust the earpiece/speaker volume
English
Press / on the handset to adjust the volume
during a call.
» The earpiece/speaker volume is
adjusted and the phone is back to the
call screen.
Warning
•
When the handset rings or when the handsfree is
activated, keep the handset away from your ear to
avoid ear damage.
Note
The caller ID service is available if you have registered
•
to the caller ID service with your service provider.
Tip
When there is a missed call, a notication message
•
appears.
Turn off the ringer for an incoming call
When the phone rings, press [Silent].
End a call
You can end a call in these ways:
• Press
• Place the handset to the base station or
; or
charging cradle.
Mute the microphone
Press during a call.
1
» The handset displays [Mute on].
» The caller cannot hear you, but you can
still hear his voice.
Press again to unmute the microphone.
2
» You can now communicate with the
caller.
Turn the speaker on or off
Press .
Make a second call
Note
This service is network dependent.
•
Press during a call.
1
» The rst call is put on hold.
Dial the second number.
2
» The number displayed on the screen is
dialed out.
EN 13
Answer a second call
Note
This service is network dependent.
•
When there is a periodical beep to notify you
of an incoming call, you can answer the call in
these ways:
Press and to answer the call.
1
» The rst call is put on hold, and you are
now connected to the second call.
Press and to end the current call and
2
answer the rst call.
Switch between two calls
You can switch your calls in these ways:
• Press
• Press [Option] and select [Switch calls],
and ; or
then press [OK] again to conrm.
» The current call is put on hold, and you
are now connected to the other call.
Make a conference call with the external callers
Note
This service is network dependent. Check with the
•
service provider for additional charges.
When you are connected to two calls, you can
make a conference call in these ways:
• Press
• Press [Option], select [Conference] and
14 EN
, then ; or
then press [OK] again to conrm.
» The two calls are combined and a
conference call is established.
5 Intercom and
conference calls
An intercom call is a call to another handset that
shares the same base station. A conference call
involves a conversation between you, another
handset user and the outside callers.
While you are on the phone
You can go from one handset to another during
a call:
Press and hold .
1
» The current caller is put on hold.
Select a handset number, then press [OK]
2
to conrm.
» Wait for the other side to answer your
call.
English
Make a call to another handset
Note
If the base station only has 2 registered handsets, press
•
and hold
another handset.
• The icon is only available in CD690.
1
2
3
4
If the selected handset is busy, [Busy] is displayed on
•
the handset screen.
or select [Menu] > to make a call to
Press and hold or select [Menu] > .
» The handsets available for intercom are
displayed.
Select a handset number, then press [OK]
to conrm.
» The selected handset rings.
Press on the selected handset.
» The intercom is established.
Press [Cancel] or to cancel or end the
intercom call.
Note
Switch between calls
Press [Extern] to switch between the outside
call and the intercom call.
Transfer a call
Press and hold during a call.
1
» The handsets available for intercom are
displayed.
Select a handset number, then press [OK]
2
to conrm.
Press when the other side answers your
3
call.
» The call is now transferred to the
selected handset.
EN 15
Make a conference call
A 3-way conference call is between you, another
handset user and the outside callers. It requires
two handsets to share the same base station.
During an external call
Press and hold to initiate an internal call.
1
» The handsets available for intercom are
displayed.
» The external caller is put on hold.
Select or enter a handset number, then
2
press [OK] to conrm.
» The selected handset rings.
Press on the selected handset.
3
» The intercom is established.
Press [Conf].
4
» You are now in a 3-way conference
call with an external call and a selected
handset.
Press to end the conference call.
5
Note
•
Press to join an ongoing conference with another
handset if [Services] > [Conference] is set to [Auto].
During the conference call
• Press [Int.] to put the external call on hold
and go back to the internal call.
» The external call is put on hold.
• Press [Conf] to establish the conference
call again.
Note
If a handset hangs up during the conference call, the
•
other handset remains connected to the external call.
16 EN
6 Text and
numbers
You can enter text and numbers for handset
name, phonebook records, and other menu
items.
Enter text and numbers
Press once or several times on the
1
alphanumeric key to enter the selected
character.
Press [Clear] to delete the character. Press
2
/ to move the cursor left and right.
Press to add a space.
3
Tip
For further information on the text and number input,
•
see the chapter 'Appendix'.
Switch between uppercase and lowercase
English
By default, the rst letter of each word in a
sentence is uppercase and the rest is lowercase.
Press
to switch between the uppercase and
lowercase letters.
EN 17
7 Phonebook
This phone has a phonebook that stores up
to 200 records. You can access the phonebook
from the handset. Each record can have a name
up to 14 characters long and a number up to 24
digits long.
There are 2 direct access memories (keys
and
). Depending on your country, keys
and
are preset to the voice mail number and
information service number of your service
provider respectively. When you press and hold
on the key in standby mode , the saved phone
number is dialed automatically.
Scroll the contact list
Press or select [Menu] > > [OK] to
1
access the phonebook list.
Press / to scroll through the
2
phonebook list.
Enter the rst character of a contact
Press or select [Menu] > > [OK] to
1
access the phonebook list.
Press the alphanumerical key that matches
2
the character.
» The rst record that starts with this
character is displayed.
View the phonebook
Note
You can view the phonebook on one handset only
•
each time.
Press or select [Menu] > > [OK] to
1
access the phonebook list.
Press / to scroll through the
2
phonebook entries.
Search a record
You can search the phonebook records in these
ways:
• Scroll the contact list.
• Enter the rst character of the contact.
Call from the phonebook
Press or select [Menu] > > [OK] to
1
access the phonebook list.
Select a contact in the phonebook list.
2
Press to make the call.
3
Access the phonebook during
a call
Press [Option] and select [Phonebook].
1
Press [OK] to conrm.
2
Select a contact, press [Option], then press
3
[View] to view the number.
18 EN
Add a record
Edit a record
Note
If your phonebook memory is full, the handset displays
•
a notication message. Delete some records to add
new ones.
Press or select [Menu] > > [Option]
1
> [Add new], then press [OK] to conrm.
Enter the name, then press [OK] to
2
conrm.
Enter the number, then press [Save] to
3
conrm
» Your new record is saved.
Tip
Press and hold to inser t a pause.
•
• Press to switch between the uppercase and
lowercase letters.
Note
The phonebook overwrites the old number with the
•
new number.
Tip
Press [Clear] to delete the character. Press / to
•
move the cursor left and right.
Press or select [Menu] > > [Option]
1
> [Edit], then press [OK] to conrm.
Edit the name, then press [OK] to conrm.
2
Edit the number, then press [Save] to
3
conrm.
» The record is saved.
Delete a record
Press or select [Menu] > .
1
Select a contact, then select [Option] >
2
[Delete]. Press [OK] to conrm.
» The handset displays a conrmation
request.
Select [OK] to conrm.
3
» The record is deleted.
Delete all records
Press or select [Menu] > .
1
Select a contact, then select [Option] >
2
[Delete all].
Press [OK] to conrm.
3
» The handset displays a conrmation
request.
Press [OK] to conrm.
4
» All records are deleted.
English
EN 19
Set the personalized melody
You can personalize the melody played when
someone in the phonebook calls you.
Note
Make sure you have subscribed to caller identication
•
before you use this feature.
Press or select [Menu] > , then press
1
[OK] to conrm.
Select a contact, then press [Option] >
2
[Select melody].
Press [OK] to set or change the melody
3
for the contact.
Select a melody for the contact, then press
4
[OK] to conrm.
» The melody is set.
Add a contact to the exception list
You can select a contact to the exception
list. When the contact who is added into
the exception list calls you, the phone rings
immediately even though you activate the silent
mode.
Press or select [Menu] > .
1
Select a contact, then select [Option] >
2
[Set exception].
Press [On] to conrm.
3
» The setting is saved.
20 EN
8 Call log
View the call records
The call log stores the call history of all missed or
received calls. The incoming call history includes
the name and number of the caller, call time, and
date. This feature is available if you have registered
to the caller ID service with your service provider.
You can access the call log from the land line or
either of the two mobile phones through the
handset and base station.
Your phone can store up to 50 call records. The
call log icon on the handset and base station
ashes to remind you of any unanswered calls.
If the caller allows the display of his identity, you
can view his name or number. The call records
are displayed in chronological order with the
most recent received call at the top of the list.
Note
Make sure that the number in the call list is valid before
•
you can call back directly from the call list.
The following icon shown on the screen informs
you if you have missed calls.
It is red on the standby screen when
there is a new missed call.
It is red in the incoming call list when
there is an unread missed call.
It is green in the incoming call list
when there is a read missed call.
Press or select [Menu] > , then press
1
[OK] to conrm.
» The incoming call log is displayed.
Select [Incoming calls].
2
Select a record, then select [Option]
3
> [View] > [OK] to view the available
information.
Save a call record to the phonebook
Press or select [Menu] > , then press
1
[OK] to conrm.
» The incoming call log is displayed.
Select [Incoming calls].
2
Select a record, then press [Option].
3
Select [Save number], then press [OK] to
4
conrm.
Enter and edit the name, then press [OK]
5
to conrm.
Enter and edit the number, then press
6
[Save] to conrm.
» The record is saved.
Return a call
English
Call list type
You can view all incoming calls or missed calls
from this menu.
Select the call list type
Select [Menu] > > [Call list type], then
1
press [OK] to conrm.
Select an option, then press [OK] to
2
conrm.
Press or select [Menu] > , then press
1
[OK].
» The incoming call log is displayed.
Select [Incoming calls].
2
Select a record on the list.
3
Press to make the call.
4
EN 21
Delete a call record
Press or select [Menu] > , then press
1
[OK] to conrm.
» The incoming call log is displayed.
Select [Incoming calls].
2
Select a record, then press [Option] to
3
conrm.
Select [Delete], then press [OK] to
4
conrm
» The handset displays a conrmation
requests.
Press [OK] to conrm.
5
» The record is deleted.
Delete all call records
Press or select [Menu] > , then press
1
[OK] to conrm.
» The incoming call log is displayed.
Select [Incoming calls].
2
Select a record, then press [Option].
3
Select [Delete all], then press [OK] to
4
conrm.
» The handset displays a conrmation
request.
Press [OK] to conrm.
5
» All records are deleted.
22 EN
9 Redial list
Delete a redial record
The redial list stores the call history of dialed
calls. It includes the names and/or numbers you
have called. This phone can store up to 20 redial
records.
View the redial records
Press [Redial].
» The dialed calls list is displayed.
Redial a call
Press [Redial].
1
Select the record you want to call. Press .
2
» The number is dialed out.
Save a redial record to the phonebook
Press [Redial] to enter the list of dialed
1
calls.
Select a record, then press [Option] to
2
conrm.
Select [Save number], then press [OK] to
3
conrm.
Enter and edit the name, then press [OK]
4
to conrm.
Enter and edit the number, then press
5
[Save] to conrm.
» The record is saved.
Press [Redial] to enter the list of dialed
1
calls.
Select a record, then press [Option] to
2
conrm.
Select [Delete], then press [OK] to
3
conrm.
» The handset displays a conrmation
request.
Press [OK] to conrm.
4
» The record is deleted.
Delete all redial records
Press [Redial] to enter the list of dialed
1
calls.
Select [Option] > [Delete all], then press
2
[OK] to conrm.
» The handset displays a conrmation
request.
Press [OK] to conrm.
3
» All records are deleted.
English
EN 23
10 Phone settings
Name the handset
You can customize the settings to make it your
own phone.
Set the date and time
For further information, see chapter 'Get
started', sections 'Set the date and time' and
'Set the date and time format'.
ECO mode
The ECO mode reduces the transmission
power of the handset and base station when
you are on a call or when the phone is in
standby mode.
Select [Menu] > > [Eco mode], then
1
press [OK] to conrm.
Select [On]/[Off], and press [OK] to
2
conrm.
» The setting is saved.
» ECO is displayed in standby mode.
The name of the handset can be up to 14
characters. It is displayed on the handset screen
in standby mode.
Select [Menu] > > [Phone name], then
1
press [OK] to conrm.
Enter or edit the name. To erase a character,
2
select [Clear].
Press [Save] to conrm.
3
» The setting is saved.
Set the display language
Note
This feature only applies to models with multiple-
•
language support.
• Languages available vary from country to country.
Select [Menu] > > [Language], then
1
press [OK] to conrm.
Select a language, then press [OK] to
2
conrm.
» The setting is saved.
Note
When ECO is set to [On], the connection range
•
between the handset and the base station can be
reduced.
24 EN
11 Alarm clock
Your phone has a built-in alarm clock. Check the
information below to set your alarm clock.
Set the alarm
Select [Menu] > , then press [OK] to
1
conrm.
Select [On]/[Off], then press [OK] to
2
conrm.
Select [Alarm time], then press [OK] to
3
conrm.
Enter an alarm time, then press [OK] to
4
conrm.
Select [Repetition], then press [OK] to
5
conrm.
Select an alarm occurrence, then press
6
[OK] to conrm.
Select [Alarm tone], then press [OK].
7
Select a tone from options, then press
8
[OK] to conrm.
» The alarm is set and
the screen.
is displayed on
When the alarm rings
• Press[Off] to turn off the alarm.
• Press [Snooze](or any key except [Off] )
to snooze.
» The alarm rings again after 5 minutes.
After you snooze it for 3 times, the
snooze function is off.
English
Tip
Press to switch between [AM]/[PM].
•
Turn off the alarm
Before the alarm rings
Select [Menu] > > [Off], then press [OK] to
conrm.
» The setting is saved.
EN 25
12 Display settings
You can change the brightness of the phone
display during standby mode.
Set the display
Select [Menu] > , then press [OK] to
1
conrm.
Select [Brightness] / [Clock], then press
2
[OK] to conrm.
Select an option, then press [OK] to
3
conrm.
Set the backlight of the LCD screen
You can set the backlight of the LCD screen and
keypad ashing on or off when the phone rings.
Select [Menu] > , then press [OK] to
1
conrm.
Select [Visual alert], then press [OK] to
2
conrm.
Select [Flashing on]/[Flashing off], then
3
press [OK] to conrm.
» The setting is saved.
26 EN
13 Sound settings
Silent mode
You can customize the sound settings of your
phone.
Set the handset's ringtone volume
You can select among 5 ringtone volume levels
or [Off].
Select [Menu] > , then press [OK] to
1
conrm.
Select [Ring volume], then press [OK] to
2
conrm.
Select a volume level, then press [OK] to
3
conrm.
» The setting is saved.
Tip
When you turn the ringtone off, displays on the
•
screen.
You can set your phone to silent mode and
enable it for a specic duration when you do
not want to be disturbed. When the silent mode
is turned on, your phone does not ring or send
any alerts or sound.
Note
•
When you press to nd your handset, or when you
activate the alarm, your phone still sends alert even
when the silent mode is activated.
Select [Menu] > , press [OK] to conrm.
1
Select [Silent mode], then press [OK] to
2
conrm.
Select [On]/[Off], then press [OK] to
3
conrm.
» The setting is saved.
Select [Start & end], then press [OK] to
4
conrm.
Set the time, then press [OK] to conrm.
5
» The setting is saved.
Note
English
Set the handset's ringtone
You can select from 15 ringtones.
Select [Menu] > , press [OK] to conrm.
1
Select [Ring tones], then press [OK] to
2
conrm.
Select a ringtone, then press [OK] to
3
conrm.
» The setting is saved.
•
When the silent mode is set to [On], is displayed.
is displayed during the preset time for the silent
mode.
EN 27
Exclude the contacts from silent mode
You can select the length of ring delay and
set the contacts to be excluded from the
phonebook. Ring delay is the number of rings
that will be muted before the rings become
audible on the phone.
Select [Menu] > > [Silent mode], then
1
press [OK] to conrm.
Select [Exception].
2
Select [On] to activate, or [Off] to
3
deactivate the silent mode, then press [OK]
to conrm.
Select [Ring delay], then select an option.
4
press [OK] to conrm.
5
» The setting is saved.
Note
If [Exception] is set to [On] and [Ring delay] option
•
is selected, the handset rings only after length of ring
delay selected is reached.
• Make sure that the contact under the [Set exception]
option of the phonebook menu is set to [On] before
you can exclude this contact from the silent mode.
Set the docking tone
Docking tone is the sound made when you
place the handset on the base station or charger.
Select [Menu] > , press [OK] to conrm.
1
Select [Docking tone], then press [OK] to
2
conrm.
Select [On]/[Off], then press [OK] to
3
conrm.
» The setting is saved.
Set the sound prole
You can set the sound in the earpiece among 3
different proles.
Select [Menu] > , press [OK] to conrm.
1
Select [My sound], then press [OK] to
2
conrm.
Select your preferred prole, then press
3
[OK] to conrm.
» The setting is saved.
Access the sound prole during a call
Set the key tone
Key tone is the sound made when you press a
key on the handset.
Select [Menu] > , press [OK] to conrm.
1
Select [Key tone], then press [OK] to
2
conrm.
Select [On]/[Off], then press [OK] to
3
conrm.
» The setting is saved.
28 EN
Press [Sound] for once or several times to
1
change the sound prole during a call.
14 Services
The phone supports a number of features that
help you handle and manage the calls.
Auto conference
To join an external call with another handset,
press
.
Activate/Deactivate auto conference
Select [Menu] > > [Conference], then
1
press [OK] to conrm.
Select [Auto]/[Off], then press [OK] to
2
conrm.
» The setting is saved.
Call barring
You can restrict the phone from making specic
outgoing calls.
Select the barring mode
Add new number to the barred list
Select [Menu] > > [Call barring] >
1
[Barring number], then press [OK] to
conrm.
Enter the PIN. The default PIN is 0000.
2
Select a number from the list, then press
3
[OK] to conrm.
» The setting is saved.
Note
The number in the barred list can still be sent as an
•
external line for a baby call.
Change the PIN
Select [Menu] > > [Call barring] >
1
[Change PIN], then press [OK] to conrm.
Enter the old PIN, then press [OK] to
2
conrm.
Enter the new PIN, then press [OK] to
3
conrm.
Enter the new PIN again, then press [Save]
4
to conrm.
» The setting is saved.
English
Select [Menu] > > [Call barring]
1
> [Barring mode] then press [OK] to
conrm.
Enter the PIN. The default PIN is 0000.
2
Select [On]/[Off], then press [OK] to
3
conrm.
» The setting is saved.
Call list type
You can view all incoming calls or missed calls
from this menu.
Select the call list type
Select [Menu] > > [Call list type], then
1
press [OK] to conrm.
Select an option, then press [OK] to
2
conrm.
EN 29
Auto prex
Network type
This feature checks and formats your outgoing
call number before it is dialed out. The prex
number can replace the detect number you
set in the menu. For example, you set 604 as
the detect number and 1250 as the prex.
When you have dialed out a number such as
6043338888, your phone changes the number
to 12503338888 when it dials out.
Note
The maximum length of a detect number is 5 digits. The
•
maximum length of an auto prex number is 10 digits.
Note
This is a country dependent feature.
•
Set auto prex
Select [Menu] > > [Auto prex], then
1
press [OK] to conrm.
Enter the detect number, then press [OK]
2
to conrm.
Enter the prex number, then press [OK]
3
to conrm.
» The setting is saved.
Note
This feature only applies to models with network type
•
support.
Select [Menu] > > [Network type],
1
then press [OK].
Select a network type, then press [OK].
2
» The setting is saved.
Select the recall duration
Make sure that the recall time is set correctly
before you can answer a second call. In normal
case, the phone is already preset for the recall
duration. You can select among 3 options:
[Short], [Medium] and [Long]. The number of
available options varies with different countries.
For details, consult your service provider.
Select [Menu] > > [Recall time], then
1
press [OK] to conrm.
Select an option, then press [OK] to
2
conrm.
» The setting is saved.
Dial mode
Note
•
To enter a pause, press and hold .
Note
If the prex number is set and the detect number is left
•
empty, the prex number is added to all outgoing calls.
Note
The feature is unavailable if the dialed number starts
•
with * and #.
30 EN
Note
This feature only applies to models that support both
•
tone and pulse dial.
Dial mode is the telephone signal used in your
country. The phone supports tone (DTMF) and
pulse (rotary) dial. Consult the service provider
for detailed information.
Set the dial mode
Select [Menu] > > [Dial mode], then
1
press [OK] to conrm.
Select a dial mode, then press [OK] to
2
conrm.
» The setting is saved.
Auto clock
Note
This service is network dependent.
•
• Make sure you have subscribed to the caller ID service
before you use this feature.
English
Note
•
If your phone is in pulse dial mode, press during a
call for temporary tone mode. Digits entered for this
call are then sent out as tone signals.
First ring
If you have subscribed to the caller ID service
with your service provider, your phone can
cancel the rst ring before the caller ID is
displayed on the screen. After the phone is reset,
it can detect automatically if there is a caller
subscription and start to cancel the rst ring. You
can change this setting to suit your preference.
This feature only applies to models with rst
ring support.
Turn the rst ring on/off
Select [Menu] > > [First ring], then
1
press [OK] to conrm.
Select [On]/[Off], press [OK] to conrm.
2
» The setting is saved.
It synchronizes the date and time on your phone
with the public switched telephone network
(PSTN) automatically. For the date to be
synchronized, make sure the current year is set.
Select [Menu] > > [Auto clock], then
1
press [OK] to conrm.
Select [On]/[Off] . Press [OK].
2
» The setting is saved. .
Register the handsets
You can register additional handsets to the base
station. The base station can register up to 5
handsets.
Auto registration
Place the unregistered handset on the base
station.
» The handset detects the base station
and registers automatically.
» Registration is completed in less
than two minutes. The base station
automatically assigns a handset number
to the handset.
Note
To reset the rst ring status, go to the reset menu.
•
EN 31
Manual registration
If auto registration fails, register your handset
manually to the base station.
Select [Menu] > > [Register], then press
1
[OK] to conrm.
Press and hold on the base station for 5
2
seconds.
Press [OK] to conrm.
4
» The handset is unregistered.
Tip
The handset number displays beside the handset name
•
in standby mode.
Note
For models with an answering machine, you hear a
•
conrmation beep.
Enter the system PIN. Press [Clear] to
3
make corrections.
Press [OK] to conrm the PIN.
4
» Registration is completed in less than 2
minutes. The base automatically assigns
a handset number to the handset.
Note
If the PIN is incorrect or no base is found within a
•
certain period, your handset displays a notication
message. Repeat the above procedure if registration
fails.
Note
The preset PIN is 0000. No change can be made on it.
•
Unregister the handsets
If two handsets share the same base station,
1
you can unregister a handset with another
handset.
Select [Menu] > > [Unregister], then
2
press [OK] to conrm.
Select the handset number to be
3
unregistered.
Call services
The call services are network and country
dependent. Contact your service provider for
more information.
Note
For the call services to work properly, make sure that
•
the activation and/or deactivation codes are correctly
entered.
Call forward
You can divert your calls to another phone
number. You can select among 3 options:
• [Call forward]: divert all incoming calls to
another number.
• [Call fwd busy]: divert calls when the line
is busy.
• [Call fwd unans]: divert calls when no one
answers.
Activate/Deactivate call forward
Select [Menu] > > [Call Services] >
1
[Call forward]/[Call fwd busy]/[Call fwd
unans]
Select [Activate]/[Deactivate], then press
2
[OK] to conrm.
Enter the telephone number.
3
» The setting is saved .
32 EN
Edit the activation/deactivation code
You can edit the prex and sufx to the call
forward codes.
Select [Menu] > > [Call Services] >
1
[Call forward]/[Call fwd busy]/[Call fwd
unans], then press [OK] to conrm.
Select [Change code], then press [OK].
2
Then you can either
3
• Select [Activation] > [Prex]/[Sufx],
then press [OK] to conrm; or
• Select [Deactivation], then press [OK]
to conrm.
Enter or edit the code, then press [OK] to
4
conrm.
» The setting is saved.
Call return
You can check the most recent unanswered call.
Call the return service centre
Select [Menu] >
return] > [Call], then press [OK] to conrm.
» Your call is made to the service center.
Edit the call return service centre number
Select [Menu] > > [Call Services] >
1
[Call return] > [Settings], then press [OK]
to conrm.
Enter or edit the number, then press [OK]
2
to conrm.
» The setting is saved.
> [Call Services] > [Call
Call back service
The call back service noties you when a party
you have tried to call becomes available. You can
cancel this service from the menu after you have
activated it from the service provider.
Cancel the call back service
Select [Menu] >
call bk] > [Call], then press [OK] to conrm.
» A call is made to the service centre to
cancel the call back option.
> [Call Services] > [Cancel
Edit the cancel call back service number
Select [Menu] > > [Call Services] >
1
[Cancel call bk] > [Settings], then press
[OK] to conrm.
Enter or edit the number, then press [OK]
2
to conrm.
» The setting is saved.
Hide your identity
You can hide your identity from the caller.
Activate ID withheld
Select [Menu] >
my ID] > [Activate], then press [OK] to
conrm.
» When you make a call to your contact,
your ID is withheld.
Edit the ID withheld code
Select [Menu] > > [Call Services] >
1
[Hide my ID] > [Settings], then press [OK]
to conrm.
Enter or edit the number, then press [OK]
2
to conrm.
» The setting is saved.
> [Call Services] > [Hide
Restore default settings
You can reset your phone settings to the original
factory settings.
Select [Menu] > > [Reset], then press
1
[OK] to conrm.
» The handset displays a conrmation
request.
Press [OK] to conrm.
2
» All settings are reset.
English
EN 33
1.5m
15 Baby monitor
Send an alert
Your phone supports the baby monitor function
which sends an alert if the sound level exceeds
the set limit.
Caution
Make sure that you do not leave the handset that has
•
the active monitor in the baby room.
• Make sure the baby unit and the cord are always out of
reach of the baby.
• Place the baby unit at least 1 meter/3 feet but not
more than 2 meters/6 feet away from the baby.
1-2m
Activate/Deactivate the baby monitor
Select [Menu] > > [Activate], then press
[OK] to conrm.
» The baby monitor mode is activated.
You can send an alert to other handsets within
the home or an external line. External line can
be a cell phone or another xed line outside the
house.
Note
Make sure that any prex digits and/or country code
•
are included when you send an alert.
Send to other handsets
Select [Menu] > > [Send alert to] >
1
[Connected line], then press [OK] to
conrm.
Select the handset number, then press
2
[OK] to conrm.
Note
Make sure that the distance between the baby unit and
•
the parent unit is at least 1.5 meter away from each
other to prevent the howling effect.
Tip
If you have not set the parent unit, a notication
•
message appears. Then you are asked to select to
where you send the alert: external lines or other
handset number. For information, see the next section.
• To exit from the baby monitor menu, press [Off].
Note
When the baby monitor mode is activated, the baby
•
handset does not ring on incoming calls.
34 EN
Send to an external line
Select [Menu] > > [Send alert to] >
1
[External line], then press [OK] to conrm.
Enter a telephone number, then press
2
[Save] to conrm.
Note
You can still send an alert to the external line even
•
though it is in the barred list (see 'Add new number to
the barred list' on page 29).
Send to a contact from the phonebook
Select [Menu] > > [Send alert to]
1
> [Select number], then press [OK] to
conrm.
Select a contact from the phonebook, then
2
press [Save] to conrm.
Set the baby cry level
Select [Menu] > > [Baby cry level], then
1
press [OK] to conrm.
Select a new setting, then press [OK] to
2
conrm.
» The setting is saved.
English
EN 35
16 Telephone
answering
machine
Note
Available only for CD695.
•
Your phone includes a telephone answering
machine that records unanswered calls when it
is on. By default, the answering machine is set to
the [Answer & rec.] mode. You can also access
the answering machine remotely and change the
settings through the answering machine menu
on the handset.
The LED indicator on the base station lights up
when the answer machine is on.
Turn the answering machine on or off
You can turn the answering machine on or off
through the base station or the handset.
Through the handset
Select [Menu] > > [Answer mode],
1
then press [OK] to conrm.
Select [Answer only]/[Answer &
2
rec.]/[Off], then press [OK] to conrm.
» The setting is saved.
Set the answering machine language
Note
This feature only applies to models with multiple-
•
language support.
The answering machine language is the language
for the announcements.
Select [Menu] > > [Voice language],
1
then press [OK] to conrm.
Select a language, then press [OK] to
2
conrm.
» The setting is saved.
Set the answer mode
You can set the answering machine and select if
the callers can leave messages. Select [Answer &
rec.] if you allow the callers to leave messages.
Select [Answer only] if you forbid the callers to
leave messages.
Select [Menu] > > [Answer mode],
1
then press [OK] to conrm.
Select an answer mode, then press [OK]
2
to conrm.
» The setting is saved.
Note
If the memory is full, the answering machine switches to
•
[Answer only] mode automatically.
Through the base
Press to turn the answering machine on or
off in standby mode.
Note
When the answering machine is switched on, it answers
•
incoming calls after a certain number of rings based on
the ring delay setting.
36 EN
Announcements
The announcement is the message your caller
hears when the answering machine picks up
the call. The answering machine has 2 default
announcements: the [Answer & rec.] mode and
[Answer only] mode.
Record an announcement
The maximum length of the announcement you
can record is 3 minutes. The newly recorded
announcement automatically replaces the old
one.
Select [Menu] > > [Announcement],
1
then press [OK] to conrm.
Select [Answer & rec.] or [Answer only],
2
then press [OK] to conrm.
Select [Record new], then press [OK] to
3
conrm.
Recording starts after the beep.
4
Press [OK] to stop recording or the
5
recording stops after 3 minutes.
» You can listen to the newly recorded
announcement on the handset.
Note
Make sure that you speak close to the microphone
•
when you record an announcement.
Listen to the announcement
Select [Menu] > > [Announcement],
1
then press [OK] to conrm.
Select [Answer & rec.] or [Answer only],
2
then press [OK] to conrm.
Select [Play], then press [OK] to conrm.
3
» You can listen to the current
announcement.
Restore the default announcement
Select [Menu] > > [Announcement],
1
then press [OK] to conrm.
Select [Answer & rec.] or [Answer only],
2
then press [OK] to conrm.
Select [Use default], then press [OK] to
3
conrm.
» The handset displays a conrmation
request.
Press [OK] to conrm.
4
» The default announcement is restored.
Incoming messages (ICM)
Each message can be up to 3 minutes long.
When you receive new messages, the new
message indicator ashes on the answering
machine and the handset displays a notication
message.
Note
If you pick up the phone when the caller leaves a
•
message, the recording stops and you can talk to the
caller directly.
Note
If the memory is full, the answering machine switches
•
to [Answer only] automatically. Delete old messages to
receive new ones.
English
Note
You can no longer listen to the announcement when
•
you pick up an incoming call.
EN 37
Listen to the incoming messages
You can listen to the incoming messages in the
sequence they are recorded.
From the base
• To start/Stop listening, press
• To adjust the volume, press
• To play the previous message/replay the
current message, press
• To play the next message, press
• To delete the current message, press
Note
No deleted messages can be recovered.
•
.
/ .
.
.
.
Delete all old incoming messages
From the base
Press and hold
» All old messages are permanently
From the handset
Select [Menu] > > [Delete all], then
1
press [OK] to conrm.
» The handset displays a conrmation
Press [OK] to conrm.
2
» All old messages are permanently
in standby mode.
deleted.
request.
deleted.
From the handset
Select [Menu] >
conrm.
» New messages start playing. Old
messages start playing if there is no
new message.
• Press [Back] to stop listening.
• Press [Option] to enter the options menu.
• Press
volume.
> [Play], then press [OK] to
/ to increase/decrease the
Delete an incoming message
From the base
Press
when you listen to the message.
» The current message is deleted.
From the handset
When you listen to the message, press
1
[Option] to enter the options menu.
Select [Delete], then press [OK] to
2
conrm.
» The current message is deleted.
Note
You can only delete the read messages. No deleted
•
messages can be recovered.
Call screening
You can hear the caller while he is leaving a
message. Press
From the base
Press / to adjust the speaker volume
during call screening.
Note
If you turn the speaker to the lowest volume level, the
•
call screening function is off.
to answer the call.
38 EN
Set the sound quality of the message
You can adjust the sound quality of the
messages received from the answering machine.
Select [Menu] > > [Msg quality], then
1
press [OK] to conrm.
Select the new setting, then press [OK] to
2
conrm.
» The setting is saved.
Note
The sound quality can only be adjusted before
•
recording starts.
Set the ring delay
You can set the number of times the phone
rings before the call goes to the answering
machine..
Select [Menu] > > [Ring delay], then
1
press [OK] to conrm.
Select a new setting, then press [OK] to
2
conrm.
» The setting is saved.
Note
Make sure that the answering machine is switched on
•
before this feature can be applied.
Remote access
You can operate your answering machine when
you are away from home. Simply make a call to
your phone with a touch tone phone and enter
your 4-digit PIN code.
Note
The remote access PIN code is the same as your
•
system PIN. The preset PIN is 0000.
Change the PIN code
Select [Menu] > > [Remote access] >
1
[Change PIN], then press [OK] to conrm.
Enter the old PIN, then press [OK] to
2
conrm.
Enter the new PIN code, then press [OK]
3
to conrm.
Enter the new PIN code again, then press
4
[Save] to conrm.
» The setting is saved.
Activate/deactivate the remote access
You can allow or block remote access to the
answering machine.
Select [Menu] > > [Remote access],
1
then press [OK] to conrm.
Select [Activate] / [Deactivate], then press
2
[OK] to conrm.
» The setting is saved.
English
Tip
When you access the answering machine remotely,
•
you are recommended to set the ring delay to[Toll
saver] mode. This is a cost effective way to manage
your messages. When there are new messages, the
answering machine picks up the call after 3 rings; When
there is no messages, it picks up the call after 5 rings.
EN 39
Access the answering machine remotely
Make a call to your home number with a
1
touch tone phone.
Enter # when you hear the announcement.
2
Enter your PIN code.
3
» You now have access to your answering
machine, and you can listen to the new
messages.
Note
You have 2 chances to enter the correct PIN code
•
before your phone hangs up.
Press a key to carry out a function. See the
4
Remote access commands table below for
a list of available functions.
Note
When there is no message, the phone hangs up
•
automatically if no key is pressed for 8 seconds.
Remote access commands
Key Function
1 Repeat the current or listen to the
previous message.
2 Listen to messages.
3 Skip to the next message.
6 Delete the current message.
7 Switch the answering machine on.
(not available when you listen to the
messages).
8 Stop listening to the message.
9 Switch the answering machine off.
(not available when you listen to the
messages).
Behavior of the LED display on the base station
The table below shows you the current status
with different LED display behavior on the base
station.
LED
display
No
display
Answering
machine
status
Off --
On No message
On It is steady on when
On It ashes when the
On It keeps scrolling when
On
On It ashes when you
Message status
there are 3 new
messages.
memory is full.
the answering machine
is recording the
incoming message or
announcement.
Press
/ to display
the volume level.
access the answering
machine menu from
the handset, the
answering machine
remotely, or listen to
messages from the
handset.
40 EN
17 Technical data
Display
• 24 color TFT display
General telephone features
• Dual mode caller name & number
identication
• Conference call and voicemails
• Intercom
• Maximum talk time: 22 hours
Phonebook list, Redial list and Call log
• Phonebook list with 200 entries
• Redial list with 20 entries
• Call log with 50 entries
Battery
• CORUN: 2 x AAA Ni-MH 1.2V 600mAh
rechargeable batteries
• BYD: 2 x AAA Ni-MH 1.2V 600mAh
rechargeable batteries
• GPI: 2 x AAA Ni-MH 1.2V 600mAh
rechargeable batteries
Power adapter
Base and charger
• Philips, SSW-2095UK-1, input: 100-240Vac,
50-60Hz 0.2A, output: 5V 600mA
• Philips, S003PB0500060, input: 100-240Vac,
50-60Hz 0.2A, output 5V 600mA
Power consumption
• Power consumption at standby mode:
around 0.5 W (CD690); 0.55 W (CD695)
Weight and dimensions (CD695)
• Handset: 145 grams
• 167.4 x 49.24 x 27.08 mm (H x W x D)
• Base: 171.4 grams
• 138.13 x 101.72 x 55.87 mm (H x W x D)
• Charger: 56.8 grams
• 94.47 x 82.03 x 53.04 mm (H x W x D)
English
Note
It only applies when the screen saver is turned off (see
•
'Display settings' on page 26).
Weight and dimensions (CD690)
• Handset: 145 grams
• 167.4 x 49.24 x 27.08 mm (H x W x D)
• Base: 130.8 grams
• 138.13 x 101.72 x 55.87 mm (H x W x D)
• Charger: 56.8 grams
• 94.47 x 82.03 x 53.04 mm (H x W x D)
EN 41
18 Notice
Declaration of conformity
Hereby Philips Consumer Lifestyle, Accessories,
declares that the CD690/695 is in compliance
with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
You can nd the Declaration of Conformity on
www.p4c.philips.com.
This product has been designed, tested and
manufactured according the European R&TTE
directive 1999/5/EC.
Use GAP standard compliance
The GAP standard guarantees that all DECT™
GAP handsets and base stations comply with
a minimum operating standard irrespective of
their make. The handset and base station are
GAP compliant, which means they guarantee
the minimum functions: register a handset,
take the line, make a call and receive a call. The
advanced features may not be available if you
use them with other makes. To register and use
this handset with a GAP compliant base station
of different make, rst follow the procedure
described in the manufacturer's instructions,
then follow the procedure described in this
manual for registering a handset. To register a
handset from different make to the base station,
put the base station in registration mode, then
follow the procedure described in the handset
manufacturer's instructions.
Compliance with EMF
Koninklijke Philips Electronics N.V. manufactures
and sells many products targeted at consumers,
which, like any electronic apparatus, in
general have the ability to emit and receive
electromagnetic signals.
One of Philips’ leading Business Principles is to
take all necessary health and safety measures for
our products, to comply with all applicable legal
requirements and to stay well within the EMF
standards applicable at the time of producing
the products.
Philips is committed to develop, produce and
market products that cause no adverse health
effects. Philips conrms that if its products are
handled properly for their intended use, they
are safe to use according to scientic evidence
available today.
Philips plays an active role in the development of
international EMF and safety standards, enabling
Philips to anticipate further developments
in standardization for early integration in its
products.
Disposal of your old product and batteries
Your product is designed and manufactured with
high quality materials and components, which
can be recycled and reused.
42 EN
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.
When this logo is attached to a product, it
means a nancial contribution has been paid to
the associated national recovery and recycling
system.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
English
EN 43
19 Frequently asked
questions
No signal bar is displayed on the screen.
• The handset is out of range. Move it closer
to the base station.
• If the handset displays [Unregister], put
the handset on the base until the signal bar
appears..
Tip
For further information, see 'Register the handsets' on
•
the Services section.
If I fail to register the additional handsets to
the base station, what do I do?
Your base memory is full. Unregister the unused
handsets and try again.
No dialing tone
• Check your phone connections.
• The handset is out of range. Move it closer
to the base station.
No docking tone
• The handset is not placed properly on the
base station/charger.
• The charging contacts are dirty. Disconnect
the power supply rst and clean the
contacts with a damp cloth.
I cannot change the settings of my voice mail,
what do I do?
The voice mail service is managed by your
service provider but not the phone itself.
Contact your service provider to change the
settings.
The handset on the charger does not charge.
• Make sure the batteries are inser ted
correctly.
• Make sure the handset is placed properly
on the charger. The battery icon animates
when charging.
• Make sure the docking tone setting is
turned on. When the handset is placed
correctly on the charger, you can hear a
docking tone.
• The charging contacts are dirty. Disconnect
the power supply rst and clean the
contacts with a damp cloth.
• Batteries are defective. Purchase new ones
from your dealer.
No display
• Make sure the batteries are charged.
• Make sure there is power and the phone is
connected.
Bad audio (crackles, echo, etc.)
• The handset is nearly out of range. Move it
closer to the base station.
• The phone receives interference from the
nearby electrical appliances. Move the base
station away from them.
• The phone is at a location with thick walls.
Move the base away from them.
The handset does not ring.
Make sure the handset ringtone is turned on.
The caller ID does not display.
• The ser vice is not activated. Check with
your service provider.
• The caller's information is withheld or
unavailable.
Note
If the above solutions do not help, disconnect the
•
power supply from both the handset and base station.
Try again after 1 minute.
44 EN
20 Appendix
Text and number input tables
Key Upper case characters (for English/
French/ German/ Italian/Turkish/
Portuguese/Spanish/Dutch/Danish/
Finnish/Norwegian/Swedish)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \^ ~|
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ § ...
2 A B C 2 À Â Æ Á Ã Ä Å Ç
3 D E F 3 È É Ê Ë Δ Φ
4 G H I 4 Ğ Í Ï İ Γ
5 J K L 5 Λ
6 M N O 6 Ñ Ó Ô Õ Ö
7 P Q R S 7 Ş Π Θ Σ
8 T U V 8 Ù Ú Ü
9 W X Y Z 9 Ø Ω Ξ Ψ
Key Lower case characters (for English/
French/ German/ Italian/Turkish/
Portuguese/Spanish/Dutch/Danish/
Finnish/Norwegian/Swedish)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \ ^ ~ |
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ §
…
2 a b c 2 à â æ á ã ä å ç
3 d e f 3 è é ê ë Δ Φ
4 g h i 4 ğ í ì ï ı Γ
5 j k l 5 Λ
6 m n o 6 ñ ó ô õ ö ò
7 p q r s 7 β ş Π Θ Σ
8 t u v 8 ù ú ü μ
9 w x y z 9 ø Ω Ξ Ψ
Key Upper case characters (for Greek)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \^ ~|
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ § ...
2 A B Г 2 A B C Æ Ä Å Ç
3 Δ Ε Ζ 3 D E F É
4 Η Θ Ι 4 G H I
5 Κ Λ Μ 5 J K L
6 Ν Ξ Ο 6 M N O Ñ Ö
7 Π Ρ Σ 7 P Q R S
8 Τ Υ Φ 8 T U V Ü
9 Χ Ψ Ω 9 W X Y Z Ø
Key Lower case characters (for Greek)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \ ^ ~ |
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ §
…
2 α β γ 2 a b c à æ ä å
3 δ ε ζ 3 d e f è é
4 η θ ι 4 g h i ì
5 κ λ μ 5 j k l Λ
6 ν ξ ο 6 m n o ñ ö ò
7 π ρ σ ς 7 p q r s ß
8 τ υ φ 8 t u v ù ü
9 χ ψ ω 9 w x y z ø
Key Upper case characters (for Romanian/
Polish/Czech/Hungarian/Slovakian/
Slovenian/Croatian)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \^ ~|
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ § ...
2 A B C 2 Â Æ Á Ă Ä Å Ą Ç Ć Č
3 D E F 3 Ď Đ Ė Ě É Ę Δ Φ
4 G H I 4 Í Î Γ
5 J K L 5 Λ Ł Ĺ Ľ
6 M N O 6 Ñ Ň Ń Ó Ö Ő
7 P Q R S 7 Ř Ş Š Ś Π Θ Σ
8 T U V 8 Ţ Ť Ú Û Ü Ů Ű
9 W X Y Z 9 Ý Ž Ź Ż ſ Ø Ω Ξ Ψ
English
EN 45
Key Lower case characters (for Romanian/
Polish/Czech/Hungarian/Slovakian/
Slovenian/Croatian)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \ ^ ~ |
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ §
…
2 a b c 2 à â æ á ă ä å ą ć č
3 d e f 3 ď đ ė ě è é ę Δ Φ
4 g h i 4 í ì Γ
5 j k l 5 Λ
6 m n o 6 ñ ň ó ö ő ò
7 p q r s 7 ř š ś Π Θ Σ ß
8 t u v 8 ţ ť ù ú û ü ů ű
9 w x y z 9 ý ž ƒ ø Ω Ξ Ψ
Key Upper case characters (for Serbian/
Bulgarian )
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \^ ~|
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ § ...
2 А Б В Г Ђ Ć Č 2 A B CÆ Ä Å Ç
3 Д Е Ж З Ј Đ 3 D E F É Δ Φ
4 И Й К Л Љ 4 G H I Γ
5 М Н О П Њ 5 J K L Λ
6 Р С Т У Ћ 6 M N O Ñ Ö
7 Ф Х Ц Ч
7 P Q R S Π Θ Σ
8 Ш Щ Ъ Ы 8 T U V Ü
9 Ь Э Ю Я Ž 9 W X Y Z Ø Ω Ξ Ψ
Key Lower case characters (for Serbian/
Bulgarian)
0 Space . 0 , / : ; " ' ! ¡ ? ¿ * + - % \ ^ ~ |
1 1 @ _ # = < > ( ) & € £ $ ¥ [ ] { } ¤ §
…
2 a b c 2 à æ ä å
3 d e f 3 è é Δ Φ
4 g h i 4 ì Γ
5 j k l 5 Λ
6 m n o 6 ñ ö ò
7 p q r s 7 Π Θ Σ ß
8 t u v 8 ù ü
9 x y z 9 ø Ω Ξ Ψ
46 EN
21 Index
A
additional handsets 31
alarm 25
announcements 36
answer a call 13
answering machine 36
answering machine language 36
auto clock 31
auto conference 29
auto prex 30
B
baby monitor 34
base station
installation 8
overview 6
battery 9, 11, 41
E
ECO mode 24
exception list, silent mode 20
F
nd handsets/paging 6
rst ring 31
G
GAP 42
H
hide own call 33
I
incoming message 37
intercom 15
internal call 15
English
C
call back service 33
call barring 29
call forward service 32
call log 21
call return 33
call screening 38
caller ID 13, 21, 31
calling 12
charging 10
conference call 14, 16, 29
contacts 18
D
date setting 10, 31
default settings 33
delete messages 38
dial mode 30
display icons 7
display settings 26
disposal 42
L
language setting
answering machine 36
handset 9, 24
LED behavior 40
listen to messages 38
M
main menu icons 7
missed calls 21
mute 13
N
name the handset 24
network type 30
O
on or off 36
EN 47
P
phone settings 24
phonebook 21, 23
PIN
answering machine 10, 39
calling barring 29
registration 32
R
recall time 30
redial 23
register/unregister 31, 32
remote access to the answering machine 39
ring delay 39
ringtone 27
ringtone customization 20
S
safety 3
save a number 21
signal strength 11
silent mode 20, 27
sounds
docking 28
keytone 28
sound prole 28
speaker phone 13
standby mode 11
T
text entry 17, 45
time setting 10, 31
transfer call 15
troubleshooting/FAQ 44
two calls/call on hold 14
V
volume adjustment 13
48 EN
Specifications are subject to change without notice
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
UM_CD690-695_05_EN_V1.2
WK12185
0168
Loading...
