PowerMOS transistor BUK456-60A/B

GENERAL DESCRIPTION QUICK REFERENCE DATA

N-channel enhancement mode SYMBOL PARAMETER MAX. MAX. UNIT
field-effect power transistor in a
plastic envelope. BUK456 -60A -60B
The device is intended for use in V
Switched Mode Power Supplies I
(SMPS), motor control, welding, P
DC/DC and AC/DC converters, and T
in automotive and general purpose R
switching applications. resistance

DS

D

tot
j

DS(ON)

PINNING - TO220AB PIN CONFIGURATION SYMBOL

Drain-source voltage 60 60 V
Drain current (DC) 52 51 A
Total power dissipation 150 150 W
Junction temperature 175 175 ˚C
Drain-source on-state 0.028 0.03 Ω

PIN DESCRIPTION

tab

d

1 gate
2 drain
3 source

tab drain

123

g

s

LIMITING VALUES

Limiting values in accordance with the Absolute Maximum System (IEC 134)

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

V

DS

V

DGR

±V

GS

Drain-source voltage - - 60 V
Drain-gate voltage RGS = 20 kΩ -60V
Gate-source voltage - - 30 V

-60A -60B

I

D

I

D

I

DM

P

tot

T

stg

T

j

Drain current (DC) Tmb = 25 ˚C - 52 51 A
Drain current (DC) Tmb = 100 ˚C - 36 36 A
Drain current (pulse peak value) Tmb = 25 ˚C - 208 200 A

Total power dissipation Tmb = 25 ˚C - 150 W
Storage temperature - - 55 175 ˚C
Junction Temperature - - 175 ˚C

THERMAL RESISTANCES

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

R
R

th j-mb

th j-a

Thermal resistance junction to - - 1.0 K/W
mounting base
Thermal resistance junction to - 60 - K/W
ambient

April 1993 1 Rev 1.100

Philips Semiconductors Product Specification

PowerMOS transistor BUK456-60A/B

STATIC CHARACTERISTICS

Tmb = 25 ˚C unless otherwise specified

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

V

(BR)DSS

V

GS(TO)

I

DSS

I

DSS

I

GSS

R

DS(ON)

DYNAMIC CHARACTERISTICS

Tmb = 25 ˚C unless otherwise specified

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

g

fs

C

iss

C

oss

C

rss

t

d on

t

r

t

d off

t

f

L

d

L

d

L

s

Drain-source breakdown VGS = 0 V; ID = 0.25 mA 60 - - V
voltage
Gate threshold voltage VDS = VGS; ID = 1 mA 2.1 3.0 4.0 V
Zero gate voltage drain current VDS = 60 V; VGS = 0 V; Tj = 25 ˚C - 1 10 µA
Zero gate voltage drain current VDS = 60 V; VGS = 0 V; Tj =125 ˚C - 0.1 1.0 mA
Gate source leakage current VGS = ±30 V; VDS = 0 V - 10 100 nA
Drain-source on-state VGS = 10 V; BUK456-60A - 0.024 0.028 Ω
resistance ID = 29 A BUK456-60B - 0.027 0.030 Ω

Forward transconductance VDS = 25 V; ID = 29 A 17 22 - S
Input capacitance VGS = 0 V; VDS = 25 V; f = 1 MHz - 1500 2000 pF

Output capacitance - 800 1000 pF
Feedback capacitance - 270 400 pF

Turn-on delay time VDD = 30 V; ID = 3 A; - 20 30 ns
Turn-on rise time VGS = 10 V; - 70 100 ns
Turn-off delay time RGS = 50 Ω; - 170 220 ns
Turn-off fall time R

= 50 Ω - 120 160 ns

gen

Internal drain inductance Measured from contact screw on - 3.5 - nH

tab to centre of die

Internal drain inductance Measured from drain lead 6 mm - 4.5 - nH

from package to centre of die

Internal source inductance Measured from source lead 6 mm - 7.5 - nH

from package to source bond pad

REVERSE DIODE LIMITING VALUES AND CHARACTERISTICS

Tmb = 25 ˚C unless otherwise specified

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

I

DR

I

DRM

V

SD

t

rr

Q

rr

April 1993 2 Rev 1.100

Continuous reverse drain - - - 52 A
current
Pulsed reverse drain current - - - 208 A
Diode forward voltage IF = 52 A ; VGS = 0 V - 1.8 2.5 V

Reverse recovery time IF = 52 A; -dIF/dt = 100 A/µs; - 80 - ns
Reverse recovery charge VGS = 0 V; VR = 30 V - 0.4 - µC

Philips Semiconductors Product Specification

PowerMOS transistor BUK456-60A/B

PD%

120
110
100

90
80
70
60
50
40
30
20
10

0

0 20 40 60 80 100 120 140 160 180

Normalised Power Derating

Tmb / C

Fig.1. Normalised power dissipation.

PD% = 100⋅PD/P

ID%

120
110
100

90
80
70
60
50
40
30
20
10

0

0 20 40 60 80 100 120 140 160 180

Tmb / C

= f(Tmb)

D 25 ˚C

Normalised Current Derating

Fig.2. Normalised continuous drain current.

ID% = 100⋅ID/I

= f(Tmb); conditions: VGS ≥ 10 V

D 25 ˚C

10

1

0.1

0.01

0.001

Zth j-mb / (K/W)

D =

0.5

0.2

0.1

0.05

0.02

0

1E-05 1E-03 1E-01 1E+01

t / s

P

D

BUKx56-lv

p

p

t

t

D =

T

t

T

Fig.4. Transient thermal impedance.

Z

= f(t); parameter D = tp/T

th j-mb

ID / A

100

20
15

80

60

40

20

0

0 2 4 6 8 10

10

VGS / V =

VDS / V

BUK456-50A

8

7

6

5

4

Fig.5. Typical output characteristics, Tj = 25 ˚C

ID = f(VDS); parameter V

GS

.

ID / A

1000

A

100

10

RDS(ON) = VDS/ID

DC

1

1 100

B

10

VDS / V

Fig.3. Safe operating area. Tmb = 25 ˚C

ID & IDM = f(VDS); IDM single pulse; parameter t

tp = 10 us

100 us

1 ms

10 ms
100 ms

BUK456-60

RDS(ON) / Ohm

0.20
4 4.5 5 5.5 6

0.15

0.10

0.05

0.00

0 20 40 60 80 100

6.5

ID / A

Fig.6. Typical on-state resistance, Tj = 25 ˚C

R

p

= f(ID); parameter V

DS(ON)

BUK456-50A

VGS / V =
7

7.5
8

10

.

GS

April 1993 3 Rev 1.100

Philips Semiconductors Product Specification

PowerMOS transistor BUK456-60A/B

ID / A

100

80

60

40

20

0

0 2 4 6 8 10

Tj / C =

VGS / V

BUK456-50A

25

150

Fig.7. Typical transfer characteristics.

ID = f(VGS) ; conditions: VDS = 25 V; parameter T

gfs / S

20

10

BUK456-50A

VGS(TO) / V

4

3

2

1

0

-60 -20 20 60 100 140 180

max.

typ.

min.

Tj / C

Fig.10. Gate threshold voltage.

V

j

= f(Tj); conditions: ID = 1 mA; VDS = V

GS(TO)

1E-01

1E-02

1E-03

1E-04

ID / A

SUB-THRESHOLD CONDUCTION

2 %

typ

GS

98 %

0

0 20 40 60 80 100

Fig.8. Typical transconductance, Tj = 25 ˚C

ID / A

.

gfs = f(ID); conditions: VDS = 25 V

a

2.0

1.5

1.0

0.5

0

-60 -20 20 60 100 140 180

Normalised RDS(ON) = f(Tj)

Tj / C

Fig.9. Normalised drain-source on-state resistance.

a = R

DS(ON)/RDS(ON)25 ˚C

= f(Tj); ID = 29 A; VGS = 10 V

1E-05

1E-06

0 1 2 3 4

VGS / V

Fig.11. Sub-threshold drain current.

ID = f(V

10000

1000

100

10

Fig.12. Typical capacitances, C

C = f(VDS); conditions: VGS = 0 V; f = 1 MHz

; conditions: Tj = 25 ˚C; VDS = V

GS)

C / pF

0 20 40

VDS / V

, C

iss

BUK4y6-50

Ciss
Coss

Crss

, C

oss

GS

rss

.

April 1993 4 Rev 1.100

Philips Semiconductors Product Specification

PowerMOS transistor BUK456-60A/B

VGS / V

12

10

8

6

4

2

0

0 20 40

VDS / V =10

QG / nC

BUK456-50

40

Fig.13. Typical turn-on gate-charge characteristics.

V

= f(QG); conditions: ID = 52 A; parameter V

GS

DS

IF / A

100

50

25 C150 C

0

0 1 2

VSDS / V

Fig.14. Typical reverse diode current.

IF = f(V

); conditions: V

SDS

= 0 V; parameter T

GS

BUK456-50A

j

April 1993 5 Rev 1.100

Philips Semiconductors Product Specification

PowerMOS transistor BUK456-60A/B

MECHANICAL DATA

Dimensions in mm
Net Mass: 2 g

10,3
max

1,3

3,7

4,5
max

3,0 max

not tinned

1,3

max

(2x)

123

2,54 2,54

2,8

3,0

13,5

min

0,9 max (3x)

5,9

min

15,8

max

0,6

2,4

Fig.15. TO220AB; pin 2 connected to mounting base.

Notes

1. Observe the general handling precautions for electrostatic-discharge sensitive devices (ESDs) to prevent
damage to MOS gate oxide.

2. Refer to mounting instructions for TO220 envelopes.

3. Epoxy meets UL94 V0 at 1/8".

April 1993 6 Rev 1.100

Philips Semiconductors Product Specification

PowerMOS transistor BUK456-60A/B

DEFINITIONS

Data sheet status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting values are given in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one
or more of the limiting values may cause permanent damage to the device. These are stress ratings only and
operation of the device at these or at any other conditions above those given in the Characteristics sections of
this specification is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.

 Philips Electronics N.V. 1996

All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the
copyright owner.

The information presented in this document does not form part of any quotation or contract, it is believed to be
accurate and reliable and may be changed without notice. No liability will be accepted by the publisher for any
consequence of its use. Publication thereof does not convey nor imply any license under patent or other
industrial or intellectual property rights.

LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices or systems where malfunction of these
products can be reasonably expected to result in personal injury. Philips customers using or selling these products
for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting
from such improper use or sale.

April 1993 7 Rev 1.100
