Philips BT6700 User Manual

BT6700

Register your product and get support at

www.philips.com/support

User manual

1EN

Contents

1 Important 1

Safety 1
Notice 1

2 Your Bluetooth speaker 2

Introduction 2
What's in the box 3
Overview of the speaker 3

3 Get started 4

Charge the built-in battery 4
Turn on/o 4

4 Use Bluetooth devices 5

Connect a Bluetooth device 5
Connect two Bluetooth devices

simultaneously 5
Play from Bluetooth device 6
Disconnect a device 6
Reconnect a device 6
Clear pairing information 6
Control your phone call 6

5 Other features 7

Listen to an external device 7
Adjust volume 7

6 Speci cations 8

7 Trouble shooting 8

General 8
About Bluetooth device 9

1

EN

1 Important

Safety

Warning

•

Never remove the casing of this speaker.

• Never place this speaker on other electrical

equipment.

• Keep this speaker away from direct

sunlight, naked ames or heat.

• Only use attachments or
accessories specied by the
manufacturer.

• After use under humid
circumstance, immediately clean
the product with a soft dry cloth.

• The battery shall not be exposed
to excessive heat such as sunshine,
re or the like.

• Do not place any sources of
danger on the speaker (e.g. lighted
candles).

Note

• The type plate is located on the bottom

of the speaker.

Notice

Any changes or modications made
to this device that are not expressly
approved by Gibson Innovations may
void the user’s authority to operate the
equipment.

Compliance

Hereby, Gibson Innovations declares that
this product is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC. You
can nd the Declaration of Conformity on
www.philips.com/support.

Care of the environment

Disposal of your old product and
battery

Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.

This symbol on a product means that the
product is covered by European Directive
2012/19/EU.

This symbol means that the product
contains a built-in rechargeable
battery covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste. We
strongly advise you to take your product
to an ocial collection point or a Philips
service centre to have a professional
remove the rechargeable battery.

2EN

Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and
never dispose of the product and
rechargeable batteries with normal
household waste. Correct disposal of
old products and rechargeable batteries
helps prevent negative consequences
for the environment and human health.

Caution

•

Removal of the built-in battery invalidates
the warranty and may destroy the product.

Always bring your product to a
professional to remove the built-in
battery.

Environmental information

All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials
which can be recycled and reused if
disassembled by a specialized company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.

Trademark notice

The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Gibson Innovations Limited
is under license. Other trademarks
and trade names are those of their
respective owners.

2 Your

Bluetooth
speaker

Congratulations on your purchase, and
welcome to Philips! To fully benet from
the support that Philips oers, register
your product at www.philips.com/
welcome.

Introduction

This speaker has passed splash-proof
test (IPX4) and can be used near water.

With this speaker, you can enjoy audio
from Bluetooth-enabled devices or
other external devices.

3 EN

What's in the box

Check and identify the contents of your
package:

• Speaker

• USB cable for charging

• Printed materials

Quick Start Guide

Overview of the speaker

1 2

3

4

a

• Charge the built-in battery.

b AUDIO IN

• Connect an external audio
device.

c Volume knob (

)

• Turn the speaker on or o.

• Adjust volume.

d

• Enter Bluetooth pairing mode.

• After Bluetooth connection,

respond to an incoming call.

• Clear Bluetooth pairing
information.

4EN

3 Get started

Always follow the instructions in this
chapter in sequence.

Charge the built-in
battery

The speaker is powered by the built-in
rechargeable battery.

Note

•

It takes you approximately four hours to
fully charge the battery.

• Rechargeable battery has a limited number

of charge cycles. Battery life and number of
charge cycles vary by use and settings.

• When the battery is low, the LED indicator

ashes red for ten minutes, and then turns
o.

To recharge the built-in battery:

• Connect the speaker to AC power
by using the adaptor (not supplied).

System
status

Battery status LED status

On Low power Flashing

red for 10
minutes, then
turn o

On Under

charging

Solid red for 5
seconds, then
turn o

O Under

charging

Solid red

O Fully charged Turn o

Turn on/o

To turn the speaker on or o, rotate the
knob clockwise or anticlockwise until
you hear a click.

» When the speaker is turned on, the

blue LED indicator ashes.

» When the speaker is turned o, the

blue LED indicator lights o.

Note

•

The speaker turns o automatically when
being idle for 15 minutes.

OFF

ON

5 EN

4 Use

Bluetooth
devices

With this speaker, you can listen to
audio from Bluetooth-enabled devices
and control the incoming call through
Bluetooth.

Connect a Bluetooth
device

Note

•

Make sure that Bluetooth function is
enabled on your device, and your device is
set as visible to all other Bluetooth devices.

• Any obstacle between this speaker

and a Bluetooth device can reduce the
operational range.

• Keep away from any other electronic

device that may cause interference.

• The operational range between this

speaker and a Bluetooth device is
approximately 10 meters.

1 Turn on the speaker.

» The blue LED indicator ashes.

2 On your Bluetooth device, enable

Bluetooth and search for Bluetooth
devices that can be paired (see the
user manual of the device).

3 Select [Philips BT6700] displayed

on your device for pairing. If
necessary, input “0000” as the
pairing password.

» After successful connection, the

speaker beeps twice, and the
Bluetooth indicator turns solid
blue.

Connect two Bluetooth
devices simultaneously

You can pair and connect a maximum
of two Bluetooth-enabled devices to
the speaker at the same time.

• If the speaker is already connected
to one device, press and hold

for

two seconds to enter pairing mode.

» The Bluetooth indicator ashes

blue quickly.

» The speaker is ready to pair with

a new Bluetooth device.

» The previous device is

disconnected with the speaker.
You need select [Philips
BT6700] for reconnection.

• If the speaker is connected to two
devices at the same time, press
and hold

for two seconds to enter

pairing mode.

» The two Bluetooth devices are

disconnected, and the speaker is
ready for pairing.

Bluetooth indicator Description

Flashing blue
quickly

Ready for pairing

Flashing blue
slowly

Connecting
the previously
connected device

Solid blue Connected

6EN

Play from Bluetooth
device

Note

•

Music play pauses when there is an
incoming call, and resumes when your
phone call ends.

After successful Bluetooth connection,
play audio on any connected device.

» Audio streams from your Bluetooth

device to the speaker.

Disconnect a device

• Press and hold for two seconds;

• Turn o the speaker;

• Disable Bluetooth on your device;

or

• Move the device beyond the
communication range.

Reconnect a device

• When you turn on the speaker,

it tries to reconnect the last
connected device automatically;

• If not successful, select [Philips
BT6700] on your Bluetooth menu

to start reconnection.

Clear pairing information

Press and hold for 10 seconds.

Control your phone call

After Bluetooth connection, you can
control an incoming call with this
speaker.

Button Function

Press to answer an
incoming call.

Press and hold for two
seconds to reject an
incoming call.

During a call, press to end
the current call.

During a call, press and
hold for two seconds to
transfer the call to your
mobile device.

7 EN

5 Other

features

Listen to an external
device

With this speaker, you can also listen
to an external audio device such as an
MP3 player.

Note

•

Make sure that music playback through
Bluetooth is stopped.

1 Open the protective cover on the

left of the speaker.

2 Connect an audio input cable (not

supplied) with a 3.5 mm connector
on both ends to

• the AUDIO IN socket on this

speaker, and

• the headphone socket on the

external device.

3 Play audio on the external device

(refer to its user manual).

Tip

•

When you start music streaming from
a connected Bluetooth device, the
speaker switches to the Bluetooth source
automatically.

Adjust volume

During music playback, rotate the knob
to increase or decrease volume.

8EN

6 Specif ications

Note

•

Product information is subject to change
without prior notice.

Rated output
power
(Amplier)

12W RMS

Acoustic
frequency
response

100-20000 Hz

Speaker driver 2 x 1.5” full range, 8 Ω

Bass
enhancement

2 x passive radiator

Bluetooth
version

V4.0

Bluetooth
supported
proles

HFP V1.5, A2DP V1.2,
AVRCP V1.4

Bluetooth
frequency band
/ Output power

2.400GHz ~

2.483GHz ISM Band
/ ≤ 4dBm (Class 2)

AUX input level 650mV RMS

Water
resistance

IPX4

Built-in battery Li-ion battery

(3.7 V, 4400 mAh)

Play time in
battery mode

Approx. 8 hours

Dimensions

- Main unit

(W x H x D) 188 x 71 x 70 mm

Weight ­Main unit

0.5 kg

7 Trouble-

shooting

Warning

•

Never remove the casing of this device.

To keep the warranty valid, never try to
repair the system yourself.
If you encounter problems when using
this device, check the following points
before requesting service. If the problem
remains unsolved, go to the Philips Web
page (www.philips.com/support). When
you contact Philips, make sure that the
device is nearby and the model number
and serial number are available.

General

No power

• Recharge the speaker.

No sound

• Adjust volume on this product.

• Adjust volume on the connected

device.

• In AUDIO IN mode, make sure that

music playback through Bluetooth
is stopped.

• Make sure that your Bluetooth

device is within the eective
operational range.

The LED indicator is solid red, and
the speaker has no repsonse when
pressing any key.

• The speaker is in demo mode. To

exit this mode: after connecting to
AC power, press and hold

, turn on

the speaker, then release the

key

after 20 seconds.

9 EN

About Bluetooth device

The audio quality is poor after
connection with a Bluetooth-enabled
device.

• The Bluetooth reception is poor.

Move the device closer to this
product or remove any obstacle
between them.

Fail to nd [Philips BT6700] on your
device for pairing.

• Press and hold

for two seconds
to enter pairing mode, and then try
again.

Cannot connect with the device.

• The Bluetooth function of the

device is not enabled. Refer to the
user manual of the device for how
to enable the function.

• This product is already connected

with two Bluetooth devices. Press
and hold

for two seconds, and

then try again.

The paired device connects and
disconnects constantly.

• The Bluetooth reception is poor.

Move the device closer to this
product or remove any obstacle
between them.

• For some devices, Bluetooth

connection may be deactivated
automatically as a power-saving
feature. This does not indicate any
malfunction of this product.

2016 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility of Gibson
Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
and are used under license.

BT6700_00 _UM_V1.0
