Philips BT6600 User Manual

BT6600

User manual

Register your product and get support at

www.philips.com/support

Contents

1 Important 1

2 Your Bluetooth speaker 2

Introduction 2
What's in the box 2
Overview of the speaker 3

3 Get started 4

Power supply 4
Turn on/o 5

4 Use Bluetooth devices 6

Connect a device 6
Connect three Bluetooth

devices simultaneously 7
Play from Bluetooth device 7
Control your phone call 7
Clear pairing information 7

5 Other features 8

Listen to an external device 8
Charge your device 8
Adjust volume 8

6 Spec ications 9

7 Tro ubleshooting 10

General 10
About Bluetooth device 10

8 Notice 11

Care of the environment 11
Trademark notice 11

1EN

1 Important

Warning

• Never remove the casing of this speaker.

• Never place this speaker on other electrical

equipment.

• Keep this speaker away from direct

sunlight, naked ames or heat.

• Make sure that you always have easy

access to the power cord, plug, or adaptor
to disconnect the speaker from the power.

• Make sure that there is enough

free space around the speaker for
ventilation.

• After use under humid

circumstance, immediately clean
the product with a soft dry cloth.

• The battery shall not be exposed

to excessive heat such as sunshine,
re or the like.

• The adapter shall not be exposed

to dripping or splashing.

• No objects lled with liquids shall

be placed on the adapter.

• Use only power supplies listed in

the user manual.

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect
device, the disconnect device shall
remain readily operable.

Note

• The type plate is located on the bottom of

the apparatus.

1

EN

2 Your

What's in the box

Bluetooth
speaker

Congratulations on your purchase, and
welcome to Philips! To fully benet from
the support that Philips oers, register
your product at www.philips.com/
welcome.

Introduction

This speaker has passed splash-proof
test (IPX4) and can be used near water.

With this speaker, you can enjoy audio
from Bluetooth-enabled devices or
other external devices.

Check and identify the contents of your
package:

Quick Start Guide

X2

• Speaker

• USB adapter head

• USB cable for charging (X 2)

• Charging base

• Printed materials

2EN

Overview of the speaker

e

e
f

g

a

b

c

d

a /MULTIPAIR

• Enter Bluetooth pairing mode.

• Disconnect Bluetooth

connection.

• Clear Bluetooth pairing

information.

• Answer or reject an incoming

call.

• End the current phone call.

• Transfer the call to your mobile

device.

b NFC

• Connect a NFC compatible

device through Bluetooth.

c LED indicator

• Indicate battery or Bluetooth

connection status.

d Volume knob ( )

• Turn the speaker on or o.

• Adjust volume.

3

EN

e DC IN

• Charge the built-in battery.

f AUDIO IN

• Connect an external audio

device.

g CHARGING (5 V 2.1 A)

• Charge your mobile device.

3 Get started

Always follow the instructions in this
chapter in sequence.

Power supply

Either AC power or battery can be used
as power supply of this product.

Option 1: Battery power

The speaker can operate on the built-in
rechargeable battery.

Note

• Rechargeable battery has a limited number

of charge cycles. Battery life and number of
charge cycles vary by use and settings.

• It takes approximately four hours to fully

charge the battery.

• The LED indicator ashes red when the

battery is low.

To recharge the built-in battery:

• Dock the speaker into the charging

base, then connect the speaker to
AC power by using the supplied
adaptor; or

• Connect the speaker to AC power

by using the supplied adaptor
directly.

Battery status LED indicator

Under charging

Fully charged

Option 2: AC power

Caution

• Risk of product damage! Make sure that the

power voltage corresponds to the voltage
printed on the back or underside of the
speaker.

• Risk of electric shock! When you unplug the

AC adapter, always pull the plug from the
socket. Never pull the cord.

Solid red （in
power-o mode）;
Flashing red for
three seconds,
then turn blue (in
power-on mode)

O （in power-o
mode）

Connect the adapter to:

• the DC IN socket on the speaker or

on the charging base;

• the power outlet.

4EN

Turn on/o

Note

• If the battery is low, the red LED indicator

ashes.

Switch to standby mode

When there is no operation and
audio ouput for 15 minutes, the
speaker switches to standby mode
automatically.

Note

• To wake up the speaker from standby

mode, press or tap the NFC tag on the
top of the speaker with your Bluetooth
device.

ON

OFF

To turn the speaker on or o, rotate the
knob clockwise or anticlockwise until
you hear a click.

» When the speaker is turned on, the

blue LED indicator ashes.

» When the speaker is turned o, the

blue LED indicator lights o.

5

EN

4 Use

Bluetooth
devices

With this speaker, you can listen to
audio from Bluetooth-enabled devices
and control the incoming call through
Bluetooth.

Connect a device

Note

• Make sure that Bluetooth function is

enabled on your device, and your device is
set as visible to all other Bluetooth devices.

• Any obstacle between this speaker

and a Bluetooth device can reduce the
operational range.

• Keep away from any other electronic

device that may cause interference.

• The operational range between this

speaker and a Bluetooth device is
approximately 10 meters (30 feet).

Option 1: Connect a device
through NFC

Near Field Communication (NFC) is a
technology that enables short-range
wireless communication between
various NFC compatible devices, such
as mobile phones and IC tags.
If your Bluetooth device supports NFC,
you can connect it with this speaker
easily.

1 Enable NFC on your Bluetooth

device (refer to its user manual).

2 Turn on the speaker.

» The blue LED indicator ashes.

3 Tap the NFC tag on the top of the

speaker with the NFC area of your
Bluetooth device.

4 Follow the on-screen instructions

to complete the pairing and
connection.

» After successful connection, the

speaker beeps twice, and the
LED indicator turns solid blue.

Option 2: Connect a device
manually

1 On your Bluetooth device, enable

Bluetooth and search for Bluetooth
devices that can be paired (see the
user manual of the device).

2 Turn on the speaker.

» The blue LED indicator ashes.

3 Select [Philips BT6600] displayed

on your device for pairing. If
necessary, input “0000” as the
pairing password.

» After successful connection, the

speaker beeps twice, and the
LED indicator turns solid blue.

Tip

• If the speaker is playing audio from a

connected Bluetooth device, it will not
beep after connected to another device.

6EN

LED indicator Description

Flashing blue
quickly

Flashing blue slowly Connecting

Solid blue Connected

Ready for pairing

Play from Bluetooth device

Note

• If there is an incoming call on the

connected mobile phone, music play
pauses.

Connect three Bluetooth devices simultaneously

The speaker can connect to three
Bluetooth devices at the same time.

2 sec.

• If the speaker is connected to one

device, repeat the above steps to
connect to the second and third
device (see the above section
“Connect a device”).

• If the speaker is connected to three

devices, press and hold for two
seconds.

» The speaker disconnects the

earliest device which is not
playing music, and gets ready to
pair with another device.

• After successful Bluetooth

connection, play audio on the
Bluetooth device.

» Audio streams from your

Bluetooth device to the speaker.

• If more than one device is

connected with the speaker, play
audio from any connected devices,
and the music playback through the
other device is paused.

Control your phone call

After Bluetooth connection, you can
control an incoming call with this
speaker.

Button Function

Press to answer an incoming
call.

Press and hold for two
seconds to reject an
incoming call.

During a call, press to end
the current call.

During a call, press and hold
for two seconds to transfer
the call to your mobile device.

Clear pairing information

Press and hold for 7 seconds to clear
Bluetooth pairing information.

7

EN

5 Other

features

• the AUDIO IN socket on this

speaker, and

• the headphone socket on the

external device.

3 Play audio on the external device

(refer to its user manual).

Listen to an external device

With this speaker, you can also listen
to an external audio device such as an
MP3 player.

Note

• Make sure that music playback through

Bluetooth is stopped.

Tip

• When you start music streaming from

a connected Bluetooth device, the
speaker switches to the Bluetooth source
automatically.

Charge your device

With this speaker, you can charge your
external devices, such as your cell
phone, MP3 player or other mobile
devices.

1 Connect the speaker to your mobile

device with the USB cable.

1 Open the protective cover on the

bottom of the speaker.

2 Connect an audio input cable (not

supplied) with a 3.5 mm connector
on both ends to

2 Turn on the speaker.

» Once the device is recognized,

the charging starts.

Adjust volume

During play, rotate the knob to increase
or decrease volume.

8EN

6 Spec-

ifications

Note

• Product information is subject to change

without prior notice.

Rated output
power
(Amplier)

Acoustic
frequency
response

Speaker driver 2 x 1.75” full range,

Bass
enhancement

Bluetooth
version

Bluetooth
supported
proles

Bluetooth
frequency band
/ Output power

2 x 7.5W RMS
≤1% THD

63-20kHz,+/-3dB

4 Ω

2 x passive radiator

V3.0

HFP V1.6, A2DP V1.2,
AVRCP V1.4

2.402GHz ~

2.480GHz ISM Band
/ ≤ 4dBm (Class 2)

Play time in
battery mode

Charging time 4 hours (with 2A

USB charging 5V 2.1A / Type-A

Power bank
output rating

Dimensions

- Main Unit
(W x H x D) 81 x 214 x 76 mm

Weight

- Main Unit 0.7 kg

Approx. 12 hours

rated power source)

socket

5V / Max. 2.1A

Bluetooth range 10 m (Free space)

AUX input level 650mV RMS

IPX standard 4

Power Supply

- AC Power
(power adapter)

- Built-in
Battery

9

EN

Brand name:
PHILIPS;
Model:GME10D­050200FCu;
Input:100-240V~,
50-60Hz,0.28A;
Output: 5 V 2 A;

Li-ion battery
(3.7 V, 6000 mAh)

7 Tro-

ubleshooting

Warning

• Never remove the casing of this device.

To keep the warranty valid, never try to
repair the system yourself.
If you encounter problems when using
this device, check the following points
before requesting service. If the problem
remains unsolved, go to the Philips Web
page (www.philips.com/support). When
you contact Philips, make sure that the
device is nearby and the model number
and serial number are available.

General

No power

• Make sure that the AC power plug

of the unit is connected properly.

• Make sure that there is power at the

AC outlet.

• Recharge your speaker.

No sound

• Adjust volume on this product.

• Adjust volume on the connected

device.

• Make sure that your Bluetooth

device is within the eective
operational range.

No response from the speaker

• Disconnect and reconnect the

power plug, then turn on the
speaker again.

• Recharge the speaker.

The LED indicator ashes red, and
the speaker has no repsonse when
pressing any key.

• The speaker is in demo mode. Press

and hold for 15 seconds to exit
this mode.

About Bluetooth device

The audio quality is poor after
connection with a Bluetooth-enabled
device.

• The Bluetooth reception is poor.

Move the device closer to this
product or remove any obstacle
between them.

Fail to nd [Philips BT6600] on your
device for pairing.

• Press and hold for two seconds

to enter pairing mode, and then try
again.

Cannot connect with the device.

• The Bluetooth function of the

device is not enabled. Refer to the
user manual of the device for how
to enable the function.

• This product is already connected

with three Bluetooth devices. Press
and hold for two seconds, and
then try again.

The paired device connects and
disconnects constantly.

• The Bluetooth reception is poor.

Move the device closer to this
product or remove any obstacle
between them.

• For some devices, Bluetooth

connection may be deactivated
automatically as a power-saving
feature. This does not indicate any
malfunction of this product.

10EN

8 Notice

Any changes or modications made
to this device that are not expressly
approved by Gibson Innovations may
void the user’s authority to operate the
equipment.

Care of the environment

Disposal of your old product

Environmental information

All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials
which can be recycled and reused
if disassembled by a specialized
company. Please observe the local
regulations regarding the disposal
of packaging materials, exhausted
batteries and old equipment.

Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.
Do not throw away the product with
the normal household waste at the
end of its life, but hand it in at an
ocial collection point or recycling. By
doing this, you help to preserve the
environment.

Caution

• Removal of the built-in battery invalidates

the warranty and may destroy the product.

Always bring your product to a
professional to remove the built-in
battery.

Trademark notice

The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Gibson Innovations Limited
is under license. Other trademarks
and trade names are those of their
respective owners.

The N Mark is a trademark or registered
trademark of NFC Forum, Inc. in the
United States and in other countries.

This is CLASS II apparatus with double
insulation, and no protective earth
provided.

11

EN

12

2016 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility of WOOX Innovations
(Shanghai) Commercial Company Ltd., and WOOX Innovations (Shanghai) Commercial Company Ltd., is the
warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used
under license.

BT6600_93_UM_V1.0
