Short User Manual
BT4080
1 Important
Warning
• Never remove the casing of this speaker.
• Never place this speaker on other electrical equipment.
• Keep this speaker away from direct sunlight, naked ames or heat.
• Make sure that you always have easy access to the power cord, plug, or
adaptor to disconnect the speaker from the power.
• Make sure that there is enough free space around the
speaker for ventilation.
• Only use attachments/accessories specied by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied ser vice personnel. Servicing is
required when the apparatus has been damaged in any way,
such as liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
• Apparatus shall not be exposed to dripping or splashing.
• Do not place any sources of danger on the apparatus (e.g.
liquid lled objects, lighted candles).
• Where the plug of the Direct Plug-in Adapter is used as the
disconnect device, the disconnect device shall remain readily
operable.
Environmental information
All unnecessary packaging has been omitted. We have tried to
make the packaging easy to separate into three materials: cardboard
(box), polystyrene foam (buffer) and polyethylene (bags, protective
foam sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Trademark notice
The Bluetooth word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Gibson
Innovations Limited is under license. Other
trademarks and trade names are those of their respective owners.
The ‘N’ Mark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.
This is CLASS II apparatus with double
insulation, and no protective earth provided.
Specications are subject to change without notice.
2015 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility of Gibson
Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
and are used under license from Koninklijke Philips N.V.
BT4080_98_Short User Manual_V1.0
Note
• The type plate is located on the bottom of the product.
2 Notice
Any changes or modications made to this device that are not
expressly approved by Gibson Innovations may void the user’s
authority to operate the equipment.
Care of the environment
Disposal of your old product
Your product is designed and manufactured with high
quality materials and components, which can be recycled
and reused.
Do not throw away the product with the normal household waste
at the end of its life, but hand it in at an ofcial collection point or
recycling. By doing this, you help to preserve the environment.
Caution
• Removal of the built-in battery invalidates the warranty and may destroy
the product.
Always bring your product to a professional to remove the built-in
battery.
www.philips.com/support.
PDF
To download the full user manual,
visit www.philips.com/support.
Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
User Manual
Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
Short user manual
On Off
DC IN
Note:
• The speaker can be powered by either AC mains or
built-in battery.
• When battery is low or under charging, the LED
indicator ashes red.
• To recharge the built-in battery, connect the speaker
to AC power.
CHARGING
Charge your mobile devices with a USB cable
(not supplied).
BT4080_98_SUM_V1.0 .indd 1 8/6/2015 10:44:32 AM
Page 2
2”
NFC
Philips BT4080
NFC
A
B
Connect
A
B
A Option 1: Connect a device through NFC
1 Press on the speaker.
» The LED indicator ashes blue.
2 On your device, enable NFC feature on your Bluetooth device.
Philips BT4080
3 Touch the NFC tag on the speaker with the NFC area of your Bluetooth
device.
4 Follow the on-screen instructions to complete the pairing and connection.
» After successful pairing and connection, the speaker beeps twice, and
the LED indicator turns solid blue.
B Option 2: Connect a device manually
1 Press on the speaker.
2 On your Bluetooth device, enable Bluetooth and search for Bluetooth devices.
Play
After successful Bluetooth connection,
play audio on the Bluetooth device.
3 Select [Philips BT4080] on your device to start pairing and connection. If
necessary, input default password “0000”.
» After successful pairing and connection, the speaker beeps twice, and
the LED indicator turns solid blue.
• If you fail to nd [Philips BT4080] for pairing, rst press and hold
PAIRING for three seconds to enter pairing mode.
Note:
• Keep away from any other electronic device that may cause interference.
• Before connecting another Bluetooth device, disconnect the current device
rst
After Bluetooth connection, you can control an incoming call with this speaker.
Button Function
Press to answer an incoming call.
Press and hold for 2 seconds to reject an incoming call.
During a call, press to end the current call.
Note: Music play pauses when there is an incoming call.
AUDIO IN
Note: To switch to audio-in mode, make sure that
there is no Bluetooth connection, or music playback
through Bluetooth is paused.
123-456-7890
Enter Bluetooth pairing mode;
Disconnect Bluetooth connection.
Specications
Amplier
Rated Output Power 2 X 10 W RMS
Frequency Response 80 -16000 Hz, ±3 dB
Signal to Noise Ratio >67 dBA
Bluetooth
Bluetooth Version V4.0
Bluetooth Frequency
Brand
Bluetooth Range 10 m (Free space)
Speakers
Speaker Impedance 8 ohm
Sensitivity >84dB/m/W ±3dB/m/W
General information
Power Supply
- AC Power
(Power Adapter)
- Battery (Built-in) 11,1 V, 1500 mAh
2.4 GHz ~ 2.48 GHz
Brand name: PHILIPS;
Model: ASSA32-150240;
Input: 100-240 V~, 50/60 Hz, 1 A;
Output: 15 V 2.4 A;
Operation Power Consumption 12.5 W (with 1A charging loader)
www.philips.com/support.
PDF
Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
User Manual
Eco Standby Power
Consumption
Charging support 5 V, 1 A
Dimensions - Main Unit (W x
H x D)
Weight - Main Unit 1.9 kg
< 0,5 W
300 x 163 x 96 mm
To download the full user manual,
visit www.philips.com/support.
