Philips BT110 User Manual

Portable speaker

BT110

User manual

Register your product and get support at

www.philips.com/support

Contents

1 Important 2

2 Your portable speaker 2

Introduction 2
What's in the box 2
Overview of the speaker 3

3 Get started 4

Attach the string 4
Charge the built-in battery 4
Turn on/o 4

4 Play from Bluetooth devices 5

Connect a device 5
Disconnect a device 6
Reconnect a device 6
Connect another device 6
Clear Bluetooth pairing information 6

5 Play from external devices 7

6 Product information 7

Audio 7
Speaker 7
Bluetooth 7
General information 8

7 Trouble shooting 8

General 8
About Bluetooth device 9

8 Notice 9

Care of the environment 9
Trademark notice 10

1EN

1 Important

2 Your portable

speaker

Warning

• Never remove the casing of this product.

• Never place this product on other electrical

equipment.

• Keep this product away from direct

sunlight, naked ames or heat.

• Read these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not install near any heat

sources such as radiators, heat
registers, stoves, or other apparatus
(including ampliers) that produce
heat.

• Only use attachments/accessories
specied by the manufacturer.

• The battery shall not be exposed
to excessive heat such as sunshine,
re or the like.

• Do not place any sources of
danger on the product (e.g. lighted
candles).

• The operation temperature of the
product is from -10 °C to 40 °C.

• The product supports USB V2.0 or
V1.1 only.

Congratulations on your purchase,
and welcome to Philips! To fully
benet from the support that Philips
oers, register your product at
www.philips.com/welcome.

Introduction

This speaker has passed splash-proof
test (IPX4) and can be used near water.

With this speaker, you can enjoy audio
from Bluetooth-enabled devices or
other external devices.

What's in the box

Check and identify the contents of your
package:

• Speaker

• USB cable for charging

• String for carrying

• Printed materials

Note

• The type plate is located on the bottom of

the product.

2 EN

Overview of the speaker

d

a

• Enter Bluetooth pairing mode.

• After Bluetooth connection,

respond to a call.

• Clear Bluetooth pairing

information.

b

• Turn the speaker on or o.

c LED indicator

• Indicate battery or Bluetooth

connection status.

d AUDIO IN

• Connect an external audio

device.

e DC IN

• Recharge the built-in battery.

1

2

3

44

5

3EN

3 Get started

Always follow the instructions in this
chapter in sequence.

Attach the string

For easy carrying, attach the supplied
string to this speaker as illustrated.

Connect the speaker to AC power
by using the adaptor (not supplied).

DC IN

The LED indicator indicates the battery
status.

Battery Status LED Indicator

Under
charging

Fully charged/
Not charging

Low battery Flashing red

Red

O (in power-o
mode);
Blue (in Bluetooth
mode)

Charge the built-in battery

The speaker is powered by the built-in
rechargeable battery.

Note

• Before use, fully charge the built-in battery.

• The micro USB socket is for charging only.

• It takes you approximately four hours to

fully charge the battery.

• Rechargeable battery has a limited number

of charge cycles. Battery life and number of
charge cycles vary by use and settings.

4

EN

Turn on/o

Press and hold for three seconds to
turn the speaker on or o.

» When the speaker is turned on,

the LED indicator begins to ash.

» When the speaker is turned o,

the LED indicator lights o.

Note

• The speaker switches to standby mode

automatically when being idle for 15
minutes.

4 Play from

Bluetooth
devices

With this speaker, you can listen to
audio from Bluetooth-enabled devices.

Connect a device

Note

• The speaker can memorize a maximum of

four paired devices. The fth paired device
will replace the rst one.

• Any obstacle between this speaker

and a Bluetooth device can reduce the
operational range.

• Keep away from any other electronic

device that may cause interference.

• The operational range between this

speaker and a Bluetooth device is
approximately 20 meters.

1 Make sure that the speaker is in

Bluetooth pairing mode

• For rst-time use, the

speaker enters pairing mode
automatically.

• If the speaker has been paired

with other device before, press
and hold on the speaker for
two seconds to enter pairing
mode.

» The LED indicator ashes blue

quickly.

2 sec.

2 On your Bluetooth device, enable

Bluetooth and search for Bluetooth
devices that can be paired (refer to
the user manual of the device).

3 Select [Philips BT110] displayed

on your device for pairing and
connection. If necessary, input
“0000” as the pairing password.

Philips BT110

» After successful pairing and

connection, the speaker beeps
twice, and the LED indicator
turns solid blue.

LED Indicator
(blue)

Quick ashing
(2Hz)

Slow ashing
(1Hz)

Solid blue Connected

Bluetooth Connection
Status

Pairing

Connecting

5EN

Play from a Bluetooth-enabled
device

Note

• Music play pauses when there is an

incoming call, and resumes when your
phone call ends.

After successful Bluetooth connection,
play music on the connected Bluetooth
device.

» Music streams from your Bluetooth

device to the speaker.

Tip

• You can use your Bluetooth device to

control play.

Disconnect a device

• Press and hold for two seconds;

• Turn o the speaker;

• Disable Bluetooth on your device;

or

• Move the device beyond the
communication range.

Reconnect a device

• When you turn on the speaker, it

will reconnect the last connected
device automatically;

• If not, select [Philips BT110] on
your Bluetooth menu to start
reconnection.

Control your phone call

After Bluetooth connection, you can
control an incoming call with this
speaker.

Button Function

Press to answer an incoming
call.

Press and hold for two
seconds to reject an incoming
call.

During a call, press to end the
current call.

During a call, press and hold
for two seconds to transfer
the call between your mobile
device and the speaker.

Connect another device

1 Press and hold for two seconds to

disconnect the currently connected
device;

» The speaker enters Bluetooth

pairing mode.

2 Connect another Bluetooth device.

Clear Bluetooth pairing information

Press and hold for 8 seconds to
clear Bluetooth pairing information.

6

EN

5 Play from

6 Product
external
devices

With this speaker, you can also listen
to an external audio device such as an
MP3 player.

Note

• Make sure that music playback through

Bluetooth is stopped.

1 Connect an audio input cable (not

supplied) with a 3.5 mm connector
on both ends to

• the AUDIO IN socket on this
speaker, and

• the headphone socket on the
external device.

2 Play audio on the external device

(refer to its user manual).

» The speaker switches to the

AUDIO IN mode.

Tip

• When you start music streaming from

a connected Bluetooth device, the
speaker switches to the Bluetooth source
automatically.

information

Note

• Product information is subject to change

without prior notice.

Audio

Rated Output
Power

Frequency
Response

Signal to Noise
Ratio

Audio-in Input 600mV RMS

Speaker

Speaker Impedance 4 ohm
Speaker Driver 40mm full range

Sensitivity 80±3dB/m/W

Bluetooth

Bluetooth Version V4.0
Bluetooth Prole A2DP:1.2; HFP: 1.5;

Bluetooth
Frequency Brand

Bluetooth
Distance Range

4W RMS at 1%
THD

80 -16000 Hz

>72 dBA

20kohm

drivers

AVRCP:1.4

2.402GHz ~

2.48GHz ISM Band
20 m

7EN

General information

7 Trouble-

DC Power (Supply
Input)

Built-in Battery 3.7 V, 800 mAh
Dimensions - Main

Unit (W x H x D)
Weight - Main Unit 0.15 kg

5 V, 1 A

98 x 77 x 35
mm

shooting

Warning

• Never remove the casing of this device.

To keep the warranty valid, never try to
repair the system yourself.
If you encounter problems when using
this device, check the following points
before requesting service. If the problem
remains unsolved, go to the Philips Web
page (www.philips.com/support). When
you contact Philips, make sure that the
device is nearby and the model number
and serial number are available.

General

No power

• Recharge your speaker.

No sound

• Adjust volume on the connected

device.

• In AUDIO IN mode, make sure that

music playback through Bluetooth
is stopped.

• Make sure that your Bluetooth

device is within the eective
operational range.

No response from the speaker

• Recharge the speaker.

8

EN

About Bluetooth device

8 Notice

The audio quality is poor after
connection with a Bluetooth-enabled
device.

• The Bluetooth reception is poor.

Move the device closer to this
product or remove any obstacle
between them.

Fail to nd [Philips BT110] on your
device for pairing.

• Press and hold for two seconds

to enter pairing mode, and then try
again.

Cannot connect with the device.

• The Bluetooth function of the

device is not enabled. Refer to the
user manual of the device for how
to enable the function.

• This product is already connected

with another Bluetooth-enabled
device. Disconnect that device and
then try again.

The paired device connects and
disconnects constantly.

• The Bluetooth reception is poor.

Move the device closer to this
product or remove any obstacle
between them.

• For some devices, Bluetooth

connection may be deactivated
automatically as a power-saving
feature. This does not indicate any
malfunction of this product.

Any changes or modications made
to this device that are not expressly
approved by Gibson Innovations may
void the user’s authority to operate the
equipment.

Care of the environment

Disposal of your old product

Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.
Do not throw away the product with
the normal household waste at the
end of its life, but hand it in at an
ocial collection point or recycling. By
doing this, you help to preserve the
environment.

Caution

• Removal of the built-in battery invalidates

the warranty and may destroy the product.

Always bring your product to a
professional to remove the built-in
battery.

9EN

Environmental information

All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials
which can be recycled and reused
if disassembled by a specialized
company. Please observe the local
regulations regarding the disposal
of packaging materials, exhausted
batteries and old equipment.

Trademark notice

The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Gibson Innovations Limited
is under license. Other trademarks
and trade names are those of their
respective owners.

10

EN

2016 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility of WOOX Innovations
(Shanghai) Commercial Company Ltd., and WOOX Innovations (Shanghai) Commercial Company Ltd., is the
warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used
under license.

BT110_93_UM_V1.0
