Philips Brilliance
LCD widescreen monitor
61 cm (24") wide
WUXGA
240PW9EB
Professional display with
excellent performance
With high resolution, legible text size, a larger viewing area widest color range up to 102%
for natural and accurate color reproduction. This Philips 240PW9 boots your business
productivity - and is ready for upgrade to Windows Vista.
Outstanding front of screen performance
• Display for Natural, Accurate color reproduction
• SmartImage: Optimized user friendly display experience
• SmartContrast: For incredible rich black details
• DVI-D input and HDCP support
Eco-friendly design
• Green design conserves resources and reduces operating costs
Designed for maximum productivity
• Extra wide view display: 178 degree angle for image accuracy
• 90 degree screen rotation and smart cable management
• 1920 x 1200 resolution: Ideal for two A4 pages side-by-side
Great convenience
• Easy picture format control switching in wide and 4:3 format
• Hassle-free display performance tuning with SmartControl II
• Dual input accepts both analog VGA and digital DVI signals
Page 2
LCD widescreen monitor
61 cm (24") wide WUXGA
Highlights
SmartImage
SmartImage is an exclusive leading edge Philips
technology that analyzes the content displayed
on your screen and gives you optimized display
performance. This user friendly interface
allows you to select various modes like Office,
Image, Entertainment, Economy etc., to fit the
application in use. Based on the selection,
SmartImage dynamically optimizes the
contrast, color saturation and sharpness of
images and videos for ultimate display
performance. The Economy mode option
offers you major power savings. All in real time
with the press of a single button!
WideColor(102%)
WideColor is an LCD monitor that puts
powerful, enhanced wide color gamut cold
cathode florescent lamp back lighting and
superior processing to work to expand the
color range from the 72% of the NTSC color
gamut reproduced by standard LCD panels to
102% or above, dramatically improving color
purity and saturation to display natural, brilliant
color.
SmartContrast
SmartContrast is a Philips technology that
analyzes the contents you are displaying,
automatically adjusting colors and controlling
backlight intensity to dynamically enhance
contrast for the best digital images and videos
or when playing games where dark hues are
displayed. When Economy mode is selected,
contrast is adjusted and backlighting fine-tuned
for just-right display of everyday office
applications and lower power consumption.
SmartControl II
SmartControl II is monitor-based software
with an easy-to-use on-screen graphic
interface that guides you through fine-tuning
resolution, color calibration and other display
settings including brightness, contrast, clock &
phase, position, RGB, white point and - on
models with onboard speakers - volume
adjustments.
Easy picture format control
Philips easy picture format control on OSD is
to switch from the 4:3 aspect ratio to the
widescreen mode and back again to match the
display's aspect ratio with your content for
working with wide documents without
scrolling or viewing widescreen media in the
widescreen mode and distortion-free, native
mode display of 4:3 ratio content.
240PW9EB/00
Eco-friendly design
Eco-friendly design is based on
environmentally conscious engineering of a
display device to minimize power
consumption, reduce packing materials and
eliminate hazardous materials. Being at the
forefront of sustainability and with our
longstanding commitment to reduce the
environmental impact of our products, we
enable consumers to make simple, responsible
choices about the products they buy and the
impact they have before, during and at the end
of their life cycle.
Super Ergo Base
The Super Ergo base is a monitor base that
delivers ergonomic display comfort and
provides intelligent cable management. The
base's people-friendly height, swivel, tilt and
rotation angle adjustments position the
monitor for maximum comfort that can ease
the physical strains of a long workday;
intelligent cable management reduces cable
clutter and keeps the workspace neat and
professional.
Extra wide viewing angle
The widest viewing angle up to 178 degree
provides the clearest display from any angles.
Page 3
LCD widescreen monitor
61 cm (24") wide WUXGA
Specifications
240PW9EB/00
Picture/Display
• Display screen type: LCD-IPS
• Panel Size: 24" / 61.1 cm
• Optimum resolution: 1920 x 1200 @ 60Hz
• Maximum Resolution: 1920 x 1200 @ 60Hz
• Display colors: 16.7 M
• Aspect ratio: 16:10
• Brightness: 400 cd/m²
• Contrast ratio (typical): 1000 : 1
• SmartContrast ratio (dynamic): 3000:1
• Wide Color Gamut display: 102% NTSC Color
Gamut
• Viewing angle: 178º (H) / 178º (V), @ C/R > 10
• White Chromaticity, 6500K: x = 0.313 / y = 0.329
• Response time (typical): 5 ms
• White Chromaticity, 9300K: x = 0.283 / y = 0.297
• Effective viewing area: 518.4 mm x 324 mm
• Horizontal Scanning Frequency: 24 - 94 KHz
• Vertical Scanning Frequency: 48 - 85 Hz
• Pixel pitch: 0.270 x 0.270 mm
•sRGB
Connectivity
• Signal Input: VGA (Analog ), DVI-D
• USB: USB 2.0 x 1
• Sync Input: Composite Sync, Separate Sync, Sync
on Green
Convenience
• User convenience: SmartControl II, SmartManage
enabled, Picture format selection, On-screen
Display
• Monitor Controls: Auto (Back), Brightness (Up),
Input, Input (Down), Menu (OK), Power On/Off,
SmartImage
• OSD Languages: English, French, German, Italian,
Russian, Simplified Chinese, Spanish, Portuguese
• Plug & Play Compatibility: DDC/CI, Mac OS X,
sRGB, Windows 98, Windows 2000, Windows XP,
Windows Vista
• Pivot: 90° (clockwise)
• Regulatory approvals: CE Mark, Energy Star, FCC
Class B, SEMKO, TCO '03, TÜV/GS, TÜV Ergo,
UL/cUL
• Height Adjustment: 130 mm
•Swivel: +/- 45°
• Tilt: -5° to 20°
• Other convenience: Kensington lock compatible
• VESA Mount: 100 x 100 mm
Dimensions
• Set dimensions with stand (W x H x D):
559
x 435 x 220 mm
•Set dimensions with stand in inch (W x H x D):
22
x 17.13 x 8.7 inch
• Relative humidity: 20% - 80%
• MTBF: 50,000 hrs
•Set dimensions (W x H x D): 559 x 381 x 75 mm
• Set dimensions in inch (W x H x D):
22
x 15 x 2.95 inch
• Temperature range (operation): 0°C to 40°C
• Temperature range (storage): -20°C to 60°C
•Box dimensions (W x H x D):
490
x 753 x 277 mm
• Box dimensions in inch (W x H x D):
19.29
x 29.65 x 10.9 inch
• Product weight (+stand): 8.12 kg
• Product weight (+stand) (lb): 17.9 lb
• Weight incl. Packaging: 10 kg
• Weight incl. Packaging (lb): 22
Power
•Consumption (On mode): < 90 W (typical)
• Consumption (economy mode): 45 W
•Consumption (Off Mode): < 1 W
• Complies with: Energy Star
• Power LED indicator: Operation - Blue, Stand by/
sleep -blue(blinking)
• Power supply: Built-in, 100-240VAC, 50/60Hz
•
Issue date 2012-03-07
Version: 4.0.3
12 NC: 8670 000 38781
EAN: 87 12581 41073 5
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
