Page 1
Philips Brilliance
LCD monitor with Ergo
base, USB, Audio
20" (50.8 cm) B-line
WSXGA+
201B2CS
Ergonomic business display
enhances productivity
With features like Ergo base, Stereo Audio, USB port, 0.1watt Soft off mode, SmartImage
and SmartControl, the energy efficient Philips 201B2 Business display enhances your
productivity
Sustainable Eco-friendly solution
• EPEAT Gold ensures lowest impact on environment
• Energy Star for energy efficiency and low power consumption
• SmartPower: Up to 50% power saving
• 0.1 watt Soft-Off mode
Ergonomic design
• 70mm height adjustment for ideal sitting position
• Tilt and swivel adjustment for an ideal viewing angle
Outstanding display performance
• SmartImage: Optimized user friendly display experience
Great convenience
• Modern Touch controls
• Built in stereo audio for multimedia experience
• USB port for convenient peripheral connections
Page 2
LCD monitor with Ergo base, USB, Audio
y
20" (50.8 cm) B-line WSXGA+
Highlights
201B2CS/00
SmartImage
SmartImage is an exclusive leading edge Philips
technology that analyzes the content displayed
on your screen and gives you optimized display
performance. This user friendly interface allows
you to select various modes like Office, Image,
Entertainment, Economy etc., to fit the
application in use. Based on the selection,
SmartImage dynamically optimizes the contrast,
color saturation and sharpness of images and
videos for ultimate display performance. The
Economy mode option offers you major power
savings. All in real time with the press of a single
button!
Screen tilt and swivel
Screen tilt and swivel is a mechanism built into
the
base permits the monitor to swivel and tilt
backward or forward.
70mm height adjustment
The Compact Ergo Base is a 'people friendly'
Phili
ps monitor base that tilts, swivels and is
height adjustable so each user can position the
monitor for maximum viewing comfort and
efficiency
Built-in stereo audio
A pair of high quality stereo speakers built into
a di
splay device. It can be visible front firing, or
invisible down firing, top firing, rear firing, etc
depending on model and design.
Touch controls
Touch controls are intelligent, touch sensitive
i
cons that replace protruding buttons that lets
the user adjust the monitor to their
requirement. Responding to your lightest
touch,Touch control gives the monitor a
modern feel
EPEAT Gold
Philips EPEAT GOLD certified monitors ensure
p
rotection for human health and environment,
and are highly energy efficient ensuring low
emissions of climate changing green house gases.
EPEAT program helps purchasers evaluate,
compare and select Monitors based on 51
environmental criteria supported by US EPA.
GOLD certification ensures that at least 30% of
plastic used is Post Consumer Resin, which
ensures reduction in use of toxic and hazardous
materials. EPEAT Gold is valid only where
Philips registers the product. Please visit
www.epeat.net for registration status in your
country.
Energy Star 5.0
Energy Star is a US EPA sponsored energy
e
fficiency program also adopted by many other
countries. Energy Star certification ensures that
you are buying a product which meets the latest
power efficiency standards which operates with
maximum power efficiency at all operational
levels. New Philips monitors are certified for
Energy Star 5.0 specifications and meet or
exceed the standard. For example, in sleep
mode Energy Star 5.0 requires less than 1watt
power consumption, whereas Philips monitors
consume less than 0.5watts. Further details can
be obtained from www.energystar.gov
SmartPower
SmartPower is an artificial intelligent technology
whic
h dynamically analyzes the content of the
screen image to achieve power saving. The
backlight intensity can be controlled
automatically and pre-set by the system to
reduce the power consumption by up to 50%,
which saves substantially on energy costs
USB 2.0 port
USB port allows user to conveniently connect
their plug and play multimedia devices such as
USB memory devices, camera, portable HDD,
Web camera, PDA, Printer and many other
devices which has USB connection available. The
conveniently located USB 2.0 port on the
monitor allows USB 2.0 signals to pass thru to
the computer. Note that many devices like
cameras and HDD may need to be powered On
independently, as they have higher power
requirements than the monitor USB port can
provide
Built-in Audio
USB
Connectivit
Page 3
LCD monitor with Ergo base, USB, Audio
20" (50.8 cm) B-line WSXGA+
Specifications
201B2CS/00
Picture/Display
• LCD panel type: TFT-LCD
• Panel Size: 20 inch / 50.8 cm
• Aspect ratio: 16:9
• Optimum resolution: 1600 x 900 @ 60Hz
• Response time (typical): 5 ms
• Brightness: 250 cd/m²
• SmartContrast: 500000:1
• Pixel pitch: 0.277 x 0.277 mm
• Viewing angle: 176º (H) / 170º (V), @ C/R > 5
• Picture enhancement: SmartImage
• Display colors: 16.7 M
• Scanning Frequency: 30 - 83 kHz (H) / 56 - 75 Hz (V)
•sRGB
Connectivity
• Signal Input: VGA (Analog ), DVI-D (digital, HDCP)
• USB: USB 2.0 x 1
• Sync Input: Separate Sync,
• Audio In/Out: Stereo Audio, P
out (3.5 mm jack)x 1
Sync on Green
C audio-in, Earphone
Convenience
• Built-in Audio: 1.5 W x 2
• User convenience: SmartImage, Volume, Power On/
f, SmartPower, Menu
Of
• OSD Languages: English, Fre
Italian, Russian, Simplified Chinese, Portuguese
• Other convenience: VESA mount (100x100mm),
sington lock
Ken
• Plug & Play Compatibility: DDC/CI, Windows 7/
ista/XP, Mac OS X, sRGB
V
nch, German, Spanish,
Stand
• Height adjustment: 70 mm
• Swivel: -65/+65 degree
• Tilt: -5/+20 degree
Power
• Smart Power Mode: 11 W(min)
• On mode: 19.62 W (EnergyStar 5.0 test method)
• Standby mode: 0.1 W
• Off mode: 0.1 W
• Power LED indicator: Operation - White, Standby
de- White (blinking)
mo
• Power supply: Built-in, 100-240VAC, 50/60Hz
Dimensions
• Product with stand (mm): 494 x 407 x 220 mm
• Product without stand (mm): 494 x 316 x 49 mm
• Packaging in mm (WxHxD): 564 x 466 x 191 mm
Weight
• Product with stand (kg): 5.06 kg
• Product without stand (kg): 3.69 kg
• Product with packaging (kg): 6.95 kg
Operating conditions
• Temperature range (operation): 0°C to 40°C °C
• Temperature Range (storage): -20°C to 60°C °C
• Relative humidity: 20%-80 %
• MTBF: 50,000 hour(s)
Sustainability
• Environmental and energy: RoHS, EPEAT Gold,
EnergyStar 5.0
• Recyclable packaging material: 100 %
Compliance and standards
• Regulatory Approvals: BSMI, CE Mark, FCC, Class B,
GOST, SEMKO, TCO 5.0, TUV/GS, TUV Ergo, UL/
cUL
Cabinet
• Color: Silver/Black
• Finish: Texture
•
Issue date 2010-10-21
Version: 2.0.2
12 NC: 8670 000 65379
EAN: 87 12581 55322 7
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject t
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
o change without notice.
