Philips Brilliance 151AX, 15L5100Q, 15L5100Q99, 15L5200Q, 15L5200Q99 Specifications

15.1" (15.1" VIS) High-Resolution
Active Matrix LCD Monitor with

Technology

• Superior front of screen performance. A bright, high contrast Philips

LCD display shows the image you are looking for in a monitor. The flicker-free screen
allows you to enjoy your monitor longer with little or no eye strain

• Flexible bezel configuration. Easily install a protective cover or touch-

screen in place of the standard
bezel, and you are ready to go in
minutes. No service call, no hassle,
and it’s even spill-proof

• Integrated tilt/swivel.

Adjust the 151AX for the way you
work. Philips new integrated
tilt/swivel design gives the utmost
flexibility on the desk or, using an
arm or wall mounting, anywhere you
need the crisp, clear image Philips
LCD monitors provide

• One-click connectivity.

Implement USBTechnology with one
simple connection into the
USBBay™ slot.

• Long-life backlight. Using

Philips new technology, you’ll now get
two to three times the life out of your
LCD monitor with our 50,000-hour
backlight. That’s almost six years of
unparalleled performance

• Philips technology. Philips continues to

make things better, continuing to provide larger
monitors in a smaller space, reducing harmful
emissions, and lowering power consumption.
As the number two producer of monitors in the world,
Philips strives to enhance your productivity with technology and design

LCD Series Monitor

151AX

®

Optional Protective Cover

LCD PANEL

Screen Size 15.1"/38 cm
Pixel Pitch 0.300 x 0.300mm
Panel Type Active Matrix TFT LCD
Display Format 1024 x 768

RGB Vertical Square

Surface Treatment Non-glare, Hard Coat

25% Haze
Light Transmission 4%
Surface (Pencil) Hardness 3H
Backlight CCFL x 4
Display Area 12.1" x 9.1"/307.2 x 230.4 mm

VIDEO

Video 80MHz
Input Impedance:

- Video 75Ω

- Sync 2kΩ
Input Signal Levels: 0.7Vp-p (S-O-G)

0.286Vp-p (S-O-G)

- Sync Input Signal Separate Sync

Composite Sync

Sync on Green

Sync Polarities Positive and Negative

AUDIO

Input Signal Level 0.4Vp-p
Loud speakers 2 Built-in, Front-firing

1+1 Watt Stereo
Earphone Out 32Ω, 50+50mW
Microphone Internal Electrical Condenser

RESOLUTION AND PRESET MODES

Maximum Resolution 1024 x 768 @ 75Hz
7 User Definable Modes
10 Factory Preset Modes:

Resolution Mode H. Freq.V. Freq. Standard

(kHz) (Hz)

720 x 400 n.i. 31.47 70.09 VGA

®

640 x 480 n.i. 31.47 60.00 VGA

®

640 x 480 n.i. 35.00 66.67 MAC

®

640 x 480 n.i. 37.80 73.00 VESA®/75
800 x 600 n.i. 35.16 56.25 SVGA

®

800 x 600 n.i. 37.88 60.32 VESA®/60
800 x 600 n.i. 48.09 72.19 VESA®/75
800 x 600 n.i. 46.88 75.00 SVGA

®

832 x 624 n.i. 49.72 75.00 MAC

®

1024 x 768 n.i. 48.36 60.00 XGA
1024 x 768 n.i. 60.02 75.03 VESA®/75

PLUG-AND-PLAY COMPATIBILITY

Display Data Channel DDCI/2B (VESA)

LOW-EMISSION CHARACTERISTICS

Complies with MPR-II and TCO 1999
Specifications

OPTICAL CHARACTERISTICS

(at 77°F/25°C)
Contrast Ratio (C/R) 250:1
Brightness 210cd/m2(maximum)

150cd/m2(minimum)

Viewing Angle (C/R>5)

- Horizontal 150° (±75°)

- Vertical 110° (±55°)
Number of Colors 262,144
White Color Temperature and Chromaticity
CIE Coordinates: (measured at ±0°H/±0°V)

at 9300˚K: x = 0.281

y = 0.311

at 6500˚K: x = 0.312

y = 0.338
at 6100˚K: x = 0.320
(as shipped at 100% RGB) y = 0.340

Response time
(0- = 0°, 0/ = 0°) t

rise

= 28mS (typ)

t

fall

= 28mS (typ)

POWER MANAGEMENT

Complies with EPA Energy Star, NUTEK, and
TCO ’99 Specifications

Philips 151AX consumes less than 5 Watts in
Power Off mode

REGULATORY APPROVALS

UL CSA
TUV/GS FCC-B
TCO ’99 CE
TUV/ERGO MPR II Low Emission

CONTROLS AND CONNECTIONS
Front:

- Power

Side:

- Mute Button - Auto Reset Button

- Brightness Button - OSD Button

Rear:

- Power Input Socket A/C & D/C

- 15-Pin D-Sub Input Cable

- 3.5 mm Mini-jack Audio Input Cable

- 3.5 mm Mono Mini-jack Microphone
Input Cable

- Headphone Jack

- Kensington

®

Lock Socket

OSD Controls:

- Brightness - Color Temp.

- Contrast - OSD Time

- Volume - OSD Position

- Exit - Power Saving

- Reset - Rotary Default

- H. Position - Phase Adj.

- V. Position - Clock Adj.

- Language

Cables:

- Detachable Power Cord

- D-Sub Interface Cable

- Stereo Audio Cable

- Microphone Cable

Supported Platforms:

MS-DOS®, Macintosh®, O/S 2®, Windows®,
Windows ’95

®

Includes Windows ’95®Driver Diskette

AVAILABLE ACCESSORIES:

Protective Cover 2G35022Q
USB Wedge 2G350A2H
VESA Mount (not shown) 2G35082Q

PHYSICAL SPECIFICATIONS

Unit Dimensions 15.8"W x 16.5"H x 6.9"D

402 x 418 x 176 mm

(including pedestal)

Unit Weight 11.7 lbs./5.3 kg.

(including stand and adapter)

Carton Dimensions 19.3"W x 20.5"H x 10.3"D/

490 x 520 x 260 mm
Carton Weight 16.5 lbs./7.5 kg.
UPC Code 0 37849 88278 8
Power Supply 85-264 Vac, 50/60Hz
Power Consumption 35 Watts Maximum
Operating Temperature 32°F to 104°F/

0°C to 40°C
Relative Humidity 20% to 80%
Storage Temperature -4°F to 140°F/

-20°C to 60°C

MTBF >50,000 Hours

(excluding LCD)

CCFL Lifetime 50,000 Hours

(brightness ≥50% of original)

USB TECHNOLOGY

For those who need support for USB peripherals,
adding Philips optional USB wedge is a snap. Just click
the USB wedge onto the back of the monitor base, and
let your computer do the rest. Don’t worry about IRQ
settings, hardware interrupts, or jumpers; with USB,
those decisions will be automatically made by your
operating system. The USB wedge is a fully powered
hub supporting five USB devices: four downstream and
one upstream.

Carton contains: 151AX TFT LCD Monitor, power cord, stereo cable,
switchless Mac adapter, users’ manual, and warranty card.
This monitor fulfills all NUTEK requirements regarding power management as
indicated on the TCO 1999 label.
The EPA Energy Star emblem does not represent EPA endorsement of any
product or service. As an Energy Star Partner, Philips has determined that this
product meets the Energy Star guidelines for energy efficiency. Brilliance is a
registered trademark of Philips Electronics N.V. Mac is a registered trademark
of Apple Computer, Inc. VESA is a registered trademark of the Video
Electronics Standards Association. VGA, SVGA, and OS/2 are registered trade­marks of International Business Machines Corp. Windows and Windows ’95
are registered trademarks of Microsoft Corp.

Printed in the U.S.A.
©1998 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
981197, Philips Consumer Electronics Co.

FOR MORE INFORMATION

Internet Address: http://www.philipsmonitors.com
FAX INFORMATION SYSTEM: [phone]

TECHNICAL SUPPORT: toll free [phone] (USA)

toll [phone] (outside USA)

Literature order form: 15L5100QA

Specifications subject to change without notice.

LCD Series Monitor

151AX

PRODUCT NUMBER 15L5100Q
TECHNICAL SPECIFICATIONS:

®
