Lumea
BRI958, BRI957,
BRI955
1
2a736
4
14
15
16
BRI955 (2a, 2b, 2e)
BRI957, BRI958 (2a, 2b, 2c, 2d)
2d
3
4
2e
3
4
1
8
12
11
9
10
17
18
2c
3
4
2b
3
4
5
5
5
5
5
13
Suitable skin tones / Teintes de peau adaptées /
Suitable skin tones Suitable body hair colors
適合的皮膚色調 / /
ﺔﺒﺳﺎﻨﻤﻟا ةﺮﺸﺒﻟا ناﻮﻟأ
ﺐﺳﺎﻨﻣ ﺖﺳﻮﭘ یﺎﻫ ﮓﻧر
Suitable body hair colors / Couleurs de poils du
corps adaptées / 適合的體毛顏色 /
ﺔﺒﺳﺎﻨﻤﻟا ﻢﺴﺠﻟا ﺮﻌﺷ ناﻮﻟأ
/ نﺪﺑ ﺐﺳﺎﻨﻣ یﺎﻫﻮﻣ ﮓﻧر
English 6
Français 32
繁體中文
ﺔﻴﺑﺮﻌﻟﺍ
ﯽﺳرﺎﻓ
61
84
108
6
English
Contents
Welcome_______________________________________________________________________________________________ 6
Device overview________________________________________________________________________________________ 7
Contraindications _____________________________________________________________________________________ 7
Important safety instructions__________________________________________________________________________ 9
How IPL works_________________________________________________________________________________________ 12
Recommended treatment schedule__________________________________________________________________ 12
What to expect_________________________________________________________________________________________ 13
How to use your Lumea Series 9000_________________________________________________________________ 14
Learning more about your Lumea Series 9000_______________________________________________________ 19
Charging________________________________________________________________________________________________ 19
Attachments___________________________________________________________________________________________ 19
SmartSkin sensor______________________________________________________________________________________ 21
Selecting the light intensity____________________________________________________________________________ 22
Two treatment modes: Stamp & Flash and Slide & Flash_____________________________________________ 23
Treatment time per area_______________________________________________________________________________ 24
Using your Lumea Series 9000 before and after tanning____________________________________________ 25
Traveling with the device______________________________________________________________________________ 25
After use________________________________________________________________________________________________ 25
Troubleshooting_______________________________________________________________________________________ 27
Warranty and support_________________________________________________________________________________ 29
Recycling_______________________________________________________________________________________________ 29
Technical specifications_______________________________________________________________________________ 30
Electromagnetic compatibility - Compliance information____________________________________________ 30
Explanation of symbols________________________________________________________________________________ 30
Welcome
Welcome to the beauty world of Lumea Series 9000! You are only a few
weeks away from silky-smooth skin.
Philips Lumea Series 9000 uses Intense Pulsed Light (IPL) technology,
known as one of the most effective methods to continuously prevent hair
regrowth. In close collaboration with skin experts we adapted this lightbased technology, originally used in professional beauty salons, for easy
and effective use in the comfort of your home. Philips Lumea Series 9000 is
gentle and offers convenient and effective treatment at a light intensity that
you find comfortable. Unwanted hairs are finally a thing of the past. Enjoy
the feeling of being hair-free and look and feel amazing every day.
Philips Lumea Series 9000 has been designed and developed for women,
but may be suitable for use by men.
To fully benefit from the support that Philips offers, register your product
and find further information about your product at
www.philips.com/support to find our experts' advice, tutorial videos and
FAQs and make the most of your Lumea Series 9000.
Note: Keep these instructions with your product at all times.
Device overview
1 Light exit window with integrated UV filter
2 Attachments
a Body attachment
b Facial attachment
c Bikini attachment (BRI957, BRI958)
d Underarm attachment
e Precision attachment
3 SmartSkin sensor
4 Integrated safety system
5 Reflector inside the attachment
6 Electronic contacts
7 Opening for electronic contacts
8 Flash button
9 On/off button
10 Confirmation button
11 Toggle buttons
12 Intensity lights
13 Setting advice button
14 'READY to flash' light
15 Air vents
16 Device socket
17 Adapter
18 Small plug
19 Luxurious pouch (not shown)
20 Cleaning cloth (not shown)
(BRI957, BRI958)
(BRI955 )
English
7
Contraindications
Conditions
Never use the device:
-
If you have skin type VI (you rarely to never sunburn, very dark tanning). In
this case you run a high risk of developing skin reactions, such as
hyperpigmentation and hypopigmentation, strong redness or burns.
-
If you are pregnant or breastfeeding as the device was not tested on
pregnant or breastfeeding women.
-
If you have any active implants such as a pacemaker, neurostimulator,
insulin pump etc.
Medications/History
Never use the device if you take any of the medications listed below:
-
If your skin is currently being treated with or has recently been treated in
the past week with Alpha-Hydroxy Acids (AHAs), Beta-Hydroxy Acids
(BHAs), topical isotretinoin and azelaic acid.
8
English
-
If you have taken any form of isotretinoin Accutane or Roaccutane in the
last six months. This treatment can make skin more susceptible to tears,
wounds and irritations.
-
If you are taking photosensitizing agents or medications, check the
package insert of your medicine and never use the device if it is stated
that it can cause photo-allergic reactions, photo-toxic reactions or if you
have to avoid sun when taking this medicine.
-
If you take anticoagulation medications, including heavy use of aspirin, in
a manner which does not allow for a minimum 1-week washout period
prior to each treatment.
Never use the device:
-
If you have received radiation therapy or chemotherapy within the past 3
months.
-
If you are on painkillers which reduce the skin's sensitivity to heat.
-
If you take immunosuppressive medications.
Pathologies/Disorders
Never use the device:
-
If you have diabetes or other systemic or metabolic diseases.
-
If you have congestive heart disease.
-
If you have a disease related to photosensitivity, such as polymorphic
light eruption (PMLE), solar urticaria, porphyria etc.
-
If you have a history of collagen disorder, including a history of keloid
scar formation or a history of poor wound healing.
-
If you have epilepsy with flashlight sensitivity.
-
If your skin is sensitive to light and easily develops a rash or an allergic
reaction.
-
If you have a skin disease such as active skin cancer, you have a history
of skin cancer or any other localized cancer in the areas to be treated.
-
If you have a history of vascular disorder, such as the presence of
varicose veins or vascular ectasia in the areas to be treated.
-
If you have any bleeding disorder.
-
If you have a history of immunosuppressive disease (including HIV
infection or AIDS).
Skin conditions
Never use the device:
-
If you have infections, eczema, burns, inflammation of hair follicles, open
lacerations, abrasions, herpes simplex (cold sores), wounds or lesions
and haematomas (bruises) in the areas to be treated.
-
On irritated (red or cut), sunburned, recently tanned or fake‑tanned skin.
-
On the following areas: On moles, freckles, large veins, darker pigmented
areas, scars, skin anomalies without consulting your doctor. This can
result in a burn and a change in skin color, which makes it potentially
harder to identify skin-related diseases.
-
On the following areas: warts, tattoos or permanent make‑up.
Location/areas
Never use the device on the following areas:
-
Around the eyes and near the eyebrows.
-
On the lips, nipples, areolas, labia minora, vagina, anus and the inside of
the nostrils and ears.
-
If you have had surgery in the areas to be treated in the last three weeks.
-
Men must not use the device on the face and neck including all beardgrowing areas, nor on the whole genital area.
-
On areas where you use long-lasting deodorants. This can result in skin
reactions.
-
Over or near anything artificial like silicone implants, subcutaneous
injection ports (insulin dispenser) or piercings.
Note: This list is not exhaustive. If you are not sure whether you can use the
device, we advise you to consult your doctor.
Important safety instructions
Warnings
-
Please read and follow these instructions to optimize the use of the
device and prevent/ minimize the risk of injury, skin reactions and side
effects.
-
Before you use Lumea Series 9000, you should clean your skin and make
sure it is hair‑free, entirely dry and free from any lotion or gel.
-
Keep the device and the adapter dry.
-
This device is not washable. Never immerse the device in water and do
not rinse it under the tap.
-
Water and electricity are a dangerous combination. Do not use this
appliance in wet surroundings (e.g. near a filled bath, a running shower or
a filled swimming pool). Moisture can damage the device and lead to a
potential safety hazard.
-
Always check the device before you use it. Do not use the device or
adapter if it is damaged. Always replace a damaged part with one of the
original type.
-
If the device or adapter is broken or damaged, do not touch any inner
part to avoid electric shock.
-
Do not use the device if the UV filter of the light exit window and/or
attachment is broken, as safe operation cannot be guaranteed under
these circumstances.
-
Do not attempt to open or repair your device or change the nonreplaceable batteries. Opening Philips Lumea Series 9000 may expose
you to dangerous electrical components and to pulsed light energy,
either of which may cause bodily and/or eye injury.
English
9
10
English
-
Always return the device to a service center authorized by Philips for
examination or repair. Repair by unqualified people could cause an
extremelyhazardous situation for the user.
-
No modification of this equipment is allowed. Do not modify, override or
cut off any part of the device (e.g. battery, adapter or the cord), as this
causes a hazardous situation.
-
Do not look at the flash while using the device. Use the device in a well-lit
room so that the light is less glaring to your eyes. While not necessary for
safety, you may wear sunglasses or goggles for your convenience if you
find the light uncomfortable or too bright.
-
Do not treat the same skin area more than once during a session. This
may increase the risk of skin reactions.
-
For hygienic reasons, the device should only be used by one person.
-
Do not use hair removal creams in the area (to be) treated with the
device, as chemicals may cause skin reactions.
-
Do not use any pencil or pen to mark the areas to be treated. This may
cause burns on your skin.
-
The device can be stored at a temperature between -25°C and 70°C.
Charge and use the device at a temperature between 5°C and 35°C. The
device will not work properly outside of this temperature range. This may
cause burns on your skin.
-
Only use thisproduct for its intended purpose and follow the general
and battery safety instructions as described in this user manual. Any
misuse can cause electric shock, burns, fire and other hazards or injuries.
-
Hair removal by intense pulsed light sources can cause increased hair
growth in some individuals. Based upon currently available data, the
highest risk groups for this response are females of Mediterranean,
Middle Eastern and South Asian heritage treated on the face and neck.
-
If you experience skin irritation or skin redness after treatment, wait until
it disappears before applying any product to your skin. If you experience
skin irritation after applying a product to your skin, wash it off with water.
If you still get skin reactions, stop using the device and consult your
doctor.
-
If shaving, epilating or waxing causes skin irritation, we advise you not to
use the device until skin irritation has disappeared.
-
This device is not intended for use by persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of
the device by a person responsible for their safety.
-
Children should be supervised to ensure that they do not play with the
device. Supervision is required to avoid potential risks such as exposure
to the light output, electrocution, strangulation from the cables or
choking on the attachments.
-
Tanning with natural or artificial sunlight might influence the sensitivity
and color of your skin. Perform a skin test to determine the appropriate
light intensity setting.
-
After each treatment, wait at least 48 hours before tanning to ensure any
skin reaction has been resolved.
-
If you notice a skin tone change since the last treatment, we advise you
to perform a skin test and to wait 24 hours before your next treatment.
English
-
Always check the device before you use it. Make sure that the SmartSkin
sensor window is clean when using the device, to avoid improper
operation (see 'D Clean & store after treatment').
-
The adapter, light exit window and the filter of the attachments can
become very hot ( >210°C/>410°F ) during usage. Always let the adapter,
the light exit window as well as the filter and inner parts of the
attachments cool down before you touch them.
-
This device has a detachable power supply unit that is IEC 60601-1 and
IEC 60950-1 class II compliant. Only use the adapter provided with this
device. Do not use an extension cord. The reference number
(AD2069x20020HF) can be found on your device. The 'x' in this number
refers to the plug type for your country.
-
Never leave the product unattended when it is plugged in.
-
Always unplug the product when it is fully charged.
-
Do not expose the device to direct sunlight or to high temperatures (near
hot stoves, in microwave ovens or on induction cookers). Batteries may
explode if overheated.
-
If the battery is damaged or leaking, avoid contact with skin or eyes. If this
occurs, immediately rinse well with water and seek medical attention.
-
If the device behaves in a different way during your normal routine (e.g.
abnormal smell or vibrations, longer charging time) stop using and
charging your device and contact customer support for help.
-
Follow the recommended treatment schedule. Increasing the frequency,
especially in the initial phase, can increase the risk of skin reactions.
11
12
1
2
3
English
How IPL works
With Intense Pulsed Light technology, gentle pulses of light are applied to
the skin and absorbed by the hair root. The lighter the skin and the darker
the hair, the better the pulses of light are absorbed.
The pulses of light stimulate the hair follicle to go into a resting phase. As a
consequence, the hair sheds naturally and hair regrowth is prevented.
The cycle of hair growth consists of different phases. IPL technology is only
effective when the hair is in its growing phase. Not all hairs are in the
growing phase at the same time. This is why we recommend you to follow
the initial treatment phase (4 treatments, every treatment 2 weeks apart)
and then the follow‑up treatment phase (touch‑ups every 4 weeks) to make
sure all hairs are effectively treated in the growing phase.
Tip: To assure long lasting hair removal, touch-ups every 4 weeks are
recommended.
Suitable body hair colors
Treatment with Lumea Series 9000 is not effective if you have light blond,
grey, red or white hairs as hairs with these colors do not absorb enough
light.
Note: To check if your body hair color allows usage of the device, consult the
hair color table on the foldout page.
Recommended treatment schedule
Initial phase
To achieve effective hair reduction, follow the initial treatment schedule.
Touch-up phase
English
13
Initial treatment schedule
For the first 4 treatments, use Lumea Series 9000 once every two weeks to
ensure that all hairs are treated.
-
Treat yourself within 3 days before or after the planned treatment date.
-
If you have not treated yourself within 3 days before or after the planned
treatment date, restart the initial phase. Plan in 4 treatments, one
treatment every two weeks.
Note: If you do not restart the initial phase, you may not see effective hair
reduction.
Note: Replacing one of the IPL treatments with another hair removal
method (waxing, epilating, etc.) will not help to reach the desired hair
reduction.
If you want to remove hairs in between the Lumea Series 9000 treatments,
you can use your normal hair removal method (excluding hair removal
creams).
After the initial phase (4 treatments), we recommend touch-ups every 4
weeks.
Touch-up treatment schedule
Treat yourself every 4 weeks. Repeat this 8 times to achieve effective hair
reduction. This is to maintain results and enjoy smooth skin for months.
-
We advise you to treat yourself within 4 days before or after the planned
treatment date.
-
The results may vary based on your individual hair regrowth and also
across different body areas.
-
If you have completed the touch-up phase and you see the need to
continue treatment (hair starts coming back), we advise you to restart the
initial phase.
Tip: Mark the treatment schedule on your calendar to remind yourself of the
planned treatments.
Note: Using the device more often does not enhance the effectiveness.
What to expect
After initial phase
-
-
-
Afterthe first treatment, it can take 1 to 2 weeks for the hairs to fall out. In
the first weeks following the initial treatments, you still see some hairs
growing.These are likely to be hairs that were not in their growing phase
during the first treatments.
After 2-3 treatments, you should see a noticeable reduction in hair
growth. However, to effectively treat all hairs, it is important to keep on
treating according to the recommended treatment schedule.
After 4 treatments, you should see a significant reduction of hair growth
in the areas that you treated with Lumea Series 9000. A reduction of hair
density should be visible as well.
14
English
During touch-up phase
-
Keep on treating with frequent touch-ups (every 4 weeks) to maintain the
result.
How to use your Lumea Series 9000
A Remove hair & clean your skin
1 Remove hair before every treatment as long as hair is still visible. You can
either shave, epilate or wax. Make sure you start to treat before new hair
is visible on your skin. If you choose to wax, wait 24 hours before you use
Lumea Series 9000.
2 Clean and dry your skin. Make sure that it is free from any lotion or gel.
B Test skin 24 hrs before treatment
1 Test your skin to find the correct light setting:
-
For every new body area.
-
After recent tanning.
2 Select the correct attachment to test your skin (see 'Attachments').
English
3 Press the on/off button to turn on the device.
4 Choose an area for your skin test.
5 Press the device firmly onto your skin and hold it in place.
The integrated safety system prevents unintentional flashingwithout full
skin contact.
6 Confirm that the 'READY to flash' light lights up white to ensure that there
is full contact with your skin.
15
-
If the 'READY to flash' light is orange, your skin is too dark to treat. Try
Lumea Series 9000 on a lighter body area.
7 Try each setting on your skin if comfortable:
-
When the 'READY to flash' light is white, press the flash button on the
handle once, to treat one spot with setting ➀
The device makes a soft popping sound. The flash gives you a warm
sensation.
16
1
2
3
4
5
24 hrs
English
• You will see a flash of light •
Note: You can toggle through the light intensity settings by pressing the
toggle button.
-
Move to next area. Treat one spot with setting ➁
-
Move to next area. Treat one spot with setting ➂
-
Move to next area. Treat one spot with setting ➃
-
Move to next area. Treat one spot with setting ➄
8 Wait 24 hours.
9 Check your skin. The highest setting that...
-
still felt comfortable and
-
did not show a skin reaction (e.g. redness, irritation, rash)
... is the setting to start the treatment with.
C Treatment
English
IMPORTANT: First finish section A (Remove hair & clean your skin) and B
skin 24 hrs before treatment).
(Test
1 Connect the power adapter to the device and plug into a power outlet or
charge
the device and use cordless.
2 Press the on/off button to turn on the device.
3 Choose the setting you selected after the skin test (section B, step 9).
17
4 Press the device firmly onto your skin and hold it in place. The 'READY to
flash' light should light
5 Press the flash button to release a flash on your skin. The flash treats the
skin
in that spot.
The device
sensation.
After
flash again.
up white.
makes a soft popping sound. The flash gives you a warm
each flash, it takes up to 3.5 seconds until the device is ready to
You can release a flash when the 'READY to flash' light lights
up white.
18
A
English
6 Move the device to the next spot, close to, but not overlapping the
previous spot. Make sure that you flash the same area only once.
7 Continue until you have treated the full area. There are two treatment
modes (see 'Two treatment modes: Stamp & Flash and Slide & Flash').
8 Turn off the device when you finished the treatment.
9 Remove hair before every next treatment, as long as hair is still visible.
Note: Do not try the device on difficult or sensitive areas (ankle and bony
area).
D Clean & store after treatment
1 Unplug the device from the power outlet if you have used it with the
power adapter.
2 Let the device cool down.
3 Moisten the soft cloth supplied with a few drops of water.
4 Take the attachment off the device.
5 Clean the light exit window of the device (A).
English
D
E
CB
6 Clean all surfaces of the attachment, including the metal reflector and
window of the attachment (parts B, C, D, E).
7 Let all parts dry thoroughly.
8 Store in a dust-free place at room temperature.
Learning more about your Lumea Series 9000
Charging
Fully charge the batteries before you use the device for the first time and
when they are empty. Charging the batteries takes up to 1 hour and 40
minutes. Charge the device when the charging light lights up orange during
use to indicate that the battery is low and will run out soon.
Fully charged batteries provide at least 130 flashes at light intensity 5.
Charging the device
1 Turn off the device.
2 Insert the small plug into the device and the adapter in to the power
outlet.
-
During charging, the charging light flashes white.
-
When the batteries are fully charged, the charging light lights up white
continuously.
-
Never cover the adapter and device during charging.
Note: The adapter and device can feel warm during charging. This is
normal.
Note: This device is equipped with battery-overheat protection and does
not charge if the room temperature exceeds 40°C.
3 After charging, remove the adapter from the power outlet and pull the
small plug out of the device.
Tip: Charge the device after each use to save battery life.
19
Attachments
For optimal results, it is important to use the correct attachment intended
for the specific body area you want to treat. Lumea Series 9000 offers
full‑body treatment with several attachments designed for use on specific
body areas. SenseIQ technology adapts the treatment program when a
different attachment is connected.
Note: The device may not work anymore and show an error when there is
dirt on the attachment connector. Clean the contact leads when this occurs.
20
English
Body attachment
To place the attachment, simply snap it onto the light exit window.
To remove the attachment, pull it off the light exit window.
The body attachment has the largest treatment window and a curved-in
design to effectively cover and treat areas below the neckline, especially
large areas such as legs, arms and stomach.
Facial attachment
The facial attachment has a precise flat design with extra integrated filter for
safe and precise treatment on the sensitive skin above the upper lip, chin
and sideburns. The device is only intended for removing unwanted body
hair from areas below the cheekbones. When you use the device on areas
with sharp contours like the jawline and chin, it may be difficult to establish
full skin contact and release a flash.
Tip: Place your tongue between your upper lip and your teeth or puff out
your cheeks to make the treatment easier.
Underarm attachment (BRI957, BRI958)
The underarm attachment has a specifically curved-out design to treat
underarm hairs that might be hard to reach.
Bikini attachment (BRI957, BRI958)
The bikini attachment has a specialized design for effective treatment of the
bikini area. It has a curved-out design and has a higher light intensity
compared to body attachment. Hair in this area tends to be thicker and
stronger than leg hair.
Precision attachment (BRI955)
The precision attachment has a curved-out design for use on bikini and
underarm areas. It has a medium sized window with a transparent filter. It is
designed for precise and effective coverage of bikini and underarm areas.
SmartSkin sensor
Lumea Series 9000 offers SenseIQ technology for a personalized hair
removal treatment. The integrated SmartSkin sensor measures the skin tone
at the start of each session and during the session. This provides two
features:
1 The SmartSkin sensor prevents you to treat areas of your skin that are
too dark: if it detects a skin tone that is too dark for treatment with
Lumea Series 9000, the 'READY to flash' light starts blinking orange. It
does not flash when you press the flash button. The device automatically
disables. This prevents you from developing skin reactions.
2 The SmartSkin sensor will help you to select the light intensity setting
that is comfortable for your skin. For this you can use the SmartSkin
button.
English
21
22
English
Selecting the light intensity
Lumea Series 9000 provides 5 different light intensities, you will always be
able to change to a light intensity setting you find comfortable.
1 Press the on/off button to turn on the device. The device starts to
operate at light intensity setting 1.
Note: To adjust the light intensity setting manually without using the
SmartSkin button, use the toggle button until you have reached the
required setting. The corresponding intensity light level lights up white.
2 Press the SmartSkin button
3 After the device has scanned your skin, the light intensity indicators will
blink white to indicate which intensities are most comfortable based on
your skin tone.
4 Press the confirmation button
indicated setting.
Lumea Series 9000 automatically uses the highest indicated intensity,
which is shown by a blinking intensity indicator. Lumea Series 9000 gives
you the freedom to select the light intensity that you find most
comfortable. Skin sensitivity can differ per person. Therefore, the skin test
is the most important guide for selecting your light intensity setting (see
'B Test skin 24 hrs before treatment').
5 Using Lumea Series 9000 should never be uncomfortably painful. If you
experience discomfort, reduce the light intensity setting. You can do this
by using the toggle buttons.
Note: The device is automatically disabled when your skin tone is too
dark (brownish black or darker), to prevent you from developing skin
reactions. The ‘READY to flash’ light will blink orange to indicate if the skin
tone is too dark.
6 After moving to another body area or after recent tanning (see 'Using
your Lumea Series 9000 before and after tanning'), perform a skin test to
determine a comfortable light intensity setting. To re-activate the setting
indication feature, press the SmartSkin button
Note: Perform a skin test before you start to treat another body area or
after a skin tone change. Determine the light intensity setting for each
body area separately.
and put the device to your skin.
to confirm that you want to use the
.
English
Two treatment modes: Stamp & Flash and Slide & Flash
YourPhilips Lumea Series 9000 has two treatment modes for more
convenient use on different body areas:
-
The Stamp & Flash mode is ideal to treat small orcurvy areas like knees
and underarms. Simply press and releasethe flash button to release a
single flash.
-
The Slide & Flash mode offers convenient use on larger areas like legs.
Keep the flash button pressed while you slide the device over your
skinto release several flashes in a row.
23
24
2
1
41
1
1 3 5
2 min.
3 min.
1.5 min.
2.5 min.
1.5 min.
2 min.
5
6.5 min.4.2 min.
1
2
3 4 5
BRI955
( , , )
BRI957, BRI958
( , , , )
1 52
1 32 4
English
Treatment time per area
This symbol means: Using the device corded
This symbol means: Using the device cordless
English
Note: The battery capacity is not enough for a full body treatment. We
recommend you to use the device corded while treating large body areas
such as legs.
Using your Lumea Series 9000 before and after tanning
Tanning with natural or artificial sunlight
Intentionally exposing your skin to natural or artificial sunlight with the aim
of developing a tan influences the sensitivity and color of your skin.
Therefore the following is important:
-
After each treatment, wait at least 48 hours before tanning. Even after 48
hours, make sure that the treated skin does not show any redness from
the treatment anymore.
-
If you expose your skin to the sun (without tanning intentionally) in the 48
hours after treatment, use a sunblock SPF 50+ on the treated areas. After
this period, you can use a sunblock SPF 30+ for two weeks.
-
After tanning, wait at least 2 weeks before you use Lumea Series 9000
and perform a skin test. This is to determine the appropriate light
intensity setting (see 'B Test skin 24 hrs before treatment').
-
Do not use Lumea Series 9000 on sunburned body areas.
Note: Occasional and indirect sun exposure does not qualify as tanning.
25
Tanning with creams
If you have used an artificial tanning lotion, wait until the artificial tan is
completely gone before you use the device.
Traveling with the device
When you travel with the device, check with the airplane carrier to confirm
that the device can be carried and/or used on the airplane.
After use
Aftercare
After use, you can apply lotions, creams, deodorant, moisturizer or
cosmetics to the treated areas.
Warning: If you experience skin irritation or skin redness after
treatment, wait until it disappears before you apply any product
to your skin. If you experience skin irritation after applying a
product to your skin, wash it off with water. If you still get skin
reactions, stop using the device and consult your doctor.
26
English
Common skin reactions
Your skin may show slight redness and/or may prickle, tingle or feel warm.
This reaction disappears quickly.
Dry skin and itching may occur due to shaving or a combination of shaving
and light treatment. You can cool the area with an ice pack or a wet face
cloth. If dryness persists, you can apply a non-scented moisturizer on the
treated area.
Rare side effects
-
Burns, excessive redness (e.g. around hair follicles) and swelling: these
reactions occur rarely. They are the result of using a light intensity that is
too high for your skin tone. If these reactions do not disappear within 3
days, we advise you to consult a doctor. Wait with the next treatment
until the skin has healed completely and make sure you use a lower light
intensity.
-
Skin discoloration: this occurs very rarely. Skin discoloration manifests
itself as either a darker patch (hyperpigmentation) or a lighter patch
(hypopigmentation) than the surrounding area. This is the result of using
a light intensity that is too high for your skin tone. If the discoloration
does not disappear within 2 weeks, we advise you to consult a doctor. Do
not treat discolored areas until the discoloration has disappeared and
your skin has regained its normal skin tone.
-
Skin infection is very rare but is a possible risk following a (micro)wound,
a skin burn, skin irritation etc.
-
Epidermal heating (a sharply defined brownish area which often occurs
with darker skin tones and is not accompanied with skin dryness): This
reaction occurs very rarely. In case this reaction does not disappear
within 1 week, we advise you to consult a doctor. Wait with the next
treatment until the skin has healed completely and make sure you use a
lower light intensity.
-
Blistering (looks like small bubbles on the surface of the skin): this occurs
very rarely. In case this reaction does not disappear within 1 month or
when the skin gets infected, we advise you to consult a doctor. Wait with
the next treatment until the skin has healed completely and make sure
you use a lower light intensity.
-
Scarring: often the secondary effect of a burn, which can take longer than
a month to heal.
-
Folliculitis (swelling around hair follicles combined with pustule
formation): this reaction occurs very rarely and is the result of bacteria
penetrating the damaged skin. In case this reaction occurs, we advise you
to consult a doctor as folliculitis may need antibiotic ointment.
-
Pain: this can occur during or after treatment if you use the device on skin
that is not hair-free, if you use the device at a light intensity that is too
high for your skin tone, if you flash the same area more than once and if
you use the device on open wounds, inflammations, infections, tattoos,
burns, etc.
Troubleshooting
Problem
Possible cause Solution
English
27
The device/adapter
becomes warm during
use.
When I place the device
on the skin, it does not
release a flash. The
'ready to flash' light
blinks orange.
The 'ready to flash' light
blinks orange and all 5
intensity lights blink as
well.
The 'ready to flash' light
does not light up white.
It is normal for the device
and adapter to become
warm (but not too hot to
touch) during use.
The fan is not working. Check if the attachment is well connected.
The cooling airflow of the
fan is blocked by hands or
a towel.
Your skin tone in the area
to be treated is too dark.
The device needs to be
reset.
The device is not
completely in contact with
your skin.
Use the device in a slightly cooler environment
and/ or let it cool down before continuing use.
Clean the connectors on the attachment if
needed. In case the attachment is well
connected and it is possible to produce flashes
with the device, contact the Consumer Care
Center in your country, your Philips dealer or a
Philips service center.
Make sure the cooling airflow of the fan is
unblocked.
Treat other body areas with lighter skin tones
with Lumea.
To reset the device, take the plug out of the
socket, wait for 30 minutes to let the device
cool down. The device should function
normally again. In case it does not work again,
contact the Consumer Care Center in your
country.
Place the device at a 90 degree angle on the
skin so that the integrated safety system in in
contact with your skin.
The device produces a
strange smell.
The device does not
flash, the fan is not
switched on and all 5
intensity lights blink.
The light exit window or
the SmartSkin sensor is
dirty.
You have not removed the
hairs on the area to be
treated properly. These
hairs may get burned and
can cause the smell.
The attachment is not
attached properly.
Clean thelight exit window and the SmartSkin
sensorcarefully.
Pretreat your skin before you use Lumea.
Make sure you attach the attachment
completely. If necessary, clean the electronic
contacts on the attachment.
28
English
Problem
The skin feels more
sensitive than usual
during treatment. I
experience discomfort
when I use the device.
Possible cause Solution
The light intensity setting
you use is too high.
You did not remove the
hairs on the areas to be
treated.
The UV filter of the light
exit window is broken.
You treated an area for
which the device is not
intended.
Check if you have selected a comfortable light
intensity setting. If necessary, select a lower
setting.
Pretreat your skin before you use Lumea.
If the UV filter is broken, do not use the device
anymore. Contact the Consumer Care Center in
your country, your Philips dealer or a Philips
service center.
Never use the device on the following areas: on
moles, freckles, large veins, darker pigmented
areas, scars, skin anomalies, warts, tattoos or
permanent make-up, around the eyes and on
or near the eyebrows, on the lips, nipples,
areolas, labia minora, vagina, anus and the
inside of the nostrils and ears. Men must not
use the device on the face and neck including
all beard-growing areas, nor on the whole
genital area.
Never use the device on moles, freckles, large
veins, darker pigmented areas, scars, skin
anomalies without consulting your doctor.
Never use the device on warts, tattoos,
permanent make-up.
Never use the device irritated (red or cut),
sunburned, recently tanned or fake-tanned
skin.
Never use the device if you have infections,
eczema, burns, inflammation of hair follicles,
open lacerations, abrasions, herpes simplex
(cold sores), wounds or lesions and
haematomas (bruises) in the areas to be
treated.
There is no glass filter in
my attachment.
The skin reaction after
treatment lasts longer
than usual.
The flash is very bright
to my eyes. Do I need to
wear goggles?
This is normal. No action required: there is no filter in the body
You have used a light
intensity setting which is
too high for you.
No, Philips Lumea does
not hurt your eyes.
and underarm attachment. Only the facial,
precision and bikini attachment have a
specialized filter.
Select a lower intensity next time.
The scattered light produced by the device is
harmless to your eyes. Do not look at the flash
while using the device. It is not necessary to
wear goggles during use. Use the device in a
well-lit room so that the light is less glaring to
your eyes. Be sure to make good skin contact
to avoid scattered light.
English
29
Problem
The results of the
treatment are not
satisfactory.
Possible cause Solution
You have used a light
intensity setting which is
too low for you.
You did not flash an area
adjacent to an area you
treated before.
The device is not effective
on your body hair color.
You do not use the device
as often as recommended.
You respond more slowly
to IPL treatment.
Warranty and support
If you need information or support, please visit www.philips.com/support or
read the international warranty leaflet.
Recycling
-
Do not throw away the product with the normal household waste at the
end of its life, but hand it in at an official collection point for recycling. By
doing this, you help to preserve the environment.
-
This product contains a built-in rechargeable battery which shall not be
disposed of with normal household waste. Please take your product to
an official collection point or a Philips service center to have a
professional remove the rechargeable battery.
-
Follow your country’s rules for the separate collection of electrical and
electronic products and rechargeable batteries. Correct disposal helps
prevent negative consequences for the environment and human health.
Please take your product to an official collection point or a Philips service
center to have a professional remove the rechargeable battery. Philips
Lumea products contain recyclable materials and should not be put into the
municipal waste stream. Refer to the Philips Lumea support website for
recycling options. Do not dispose of in fire.
Select a higher setting next time.
You have to release the flashes close to, but
not overlapping, the previous spot.
If you have light blond, grey, red or white hair,
the treatment is not effective.
To remove all hairs successfully, we advise you
to follow the recommended treatment
schedule. You can reduce the time between
treatments, but do not treat more often than
once every two weeks.
Continue using the device for at least 6
months, as hair regrowth can still decrease
over the course of this period.
30
English
Technical specifications
Transport and storage
conditions
Lumea Series 9000 remains operational in NORMAL USE within its
specification after transport or storage in the following environmental
range:
-25°C to +70°C up to 90% RH, non‑condensing, 700hPa to 1060hPa
Operating temperature
conditions
Emitted wavelengths 565 to 1400 nm
Pulse duration 1 - 2.5ms, for all settings
Flash interval Between 1 - 3.5 s depending on battery/mains connected use
Optical exposure Body attachment: 2.5 – 5.6J/cm2
Adapter input 100 - 240 V 50/60 Hz 1.5 A
Adapter output 19.5V 3.33 A 65.0 W
Average active efficiency ≥88.0%
Efficiency at low load
(10%)
No-load power
consumption
Lumea Series 9000 complies with its specifications when operated in
NORMAL USE under the following environmental operating conditions:
+5°C to +35°C up to 90%RH, non-condensing, 700hPa to 1060hPa
Underarm attachment: 2.5 – 6.5 J/cm2
Precision/Bikini attachment: 2.5 – 6.5J/cm2
Facial attachment: 2.4 – 5.9J/cm2
≥79.0%
<0,21W
Electromagnetic compatibility - Compliance information
This device complies with all applicable standards and regulations regarding
exposure to electromagnetic fields.
Explanation of symbols
The warning signs and symbols are essential to ensure that you use this
product safely and correctly and to protect you and others from injury.
Below you find the meaning of the warning signs and symbols on the label
and in the user manual.
This symbol identifies the manufacturer of the product: Philips Consumer Lifestyle B.V.
Tussendiepen 4, 9206 AD Drachten. The Netherlands
This symbol means that you have to read the user manual carefully before you use the
device. Save the user manual for future reference.
English
This symbol means that the user should consult the instructions for use for important
safety information such as cautions that cannot, for a variety of reasons, be presented
on the device itself.
This symbol means that the user should consult the instructions for use for important
safety information such as contraindications and warnings that cannot, for a variety of
reasons, be presented on the device itself.
To identify the manufacturer's serial number.
To identify the manufacturer's catalog number.
Symbol to identify equipment meeting the safety requirements specified for Class II
equipment.
This symbol indicates that the equipment is suitable for direct current only.
Symbol indicates that the device should not be used around the eyes and near the
eyebrows.
This symbol means: 'Do not use this device in a bathtub, shower or water-filled reservoir.
This symbol means that the transformer is designed to be short-circuit proof.
31
This symbol means that the transformer is considered a Switch Mode Power Supply
(SMPS) unit.
This symbol means that the device is designed for indoor use.
This symbol indicates the maximum temperature at which the transformer may be
operated continuously under normal conditions of use
A recycling symbol to identify the material of which an item is made, to facilitate
recycling or other reprocessing. The symbol may include a number and/or abbreviation.
This symbol indicates that a specific separate supply unit is required for connecting
electrical equipment to the supply mains.
This symbol indicates that RoHS substances above the maximum concentration limit are
used in this product.
Loading...
