DISCRETE SEMICONDUCTORS

DATA SH EET

BGD602

CATV amplifier module

Product specification
File under Discrete Semiconductors, SC16

Philips Semiconductors

February 1994

Philips Semiconductors Product specification

CATV amplifier module BGD602

FEATURES

• Excellent linearity

• Extremely low noise

• Silicon nitride passivation

• Rugged construction

• Gold metallization ensures

excellent reliability.

DESCRIPTION

PINNING - SOT115J

PIN DESCRIPTION

1 input
2 common
3 common
5+V

B

7 common
8 common
9 output

page

2

351

Side view

Fig.1 Simplified outline.

Hybrid high dynamic range amplifier
module designed for applications in
CATV systems with a bandwidth of
40 to 600 MHz operating with a
voltage supply of 24 V (DC).

QUICK REFERENCE DATA

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

G

p

power gain f = 50 MHz 18 19 dB

f = 600 MHz 19 − dB

I

tot

total current consumption (DC) VB = 24 V − 435 mA

789

MSA319

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

SYMBOL PARAMETER MIN. MAX. UNIT

V

i

T

stg

T

mb

RF input voltage − 65 dBmV
storage temperature −40 +100 °C
operating mounting base temperature −20 +100 °C

February 1994 2

Philips Semiconductors Product specification

CATV amplifier module BGD602

CHARACTERISTICS

Bandwidth 40 to 600 MHz; V

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

G

p

power gain f = 50 MHz 18 19 dB

SL slope cable equivalent f = 40 to 600 MHz 0.2 2.2 dB
FL flatness of frequency response f = 40 to 600 MHz −±0.3 dB
S

11

S

22

S

21

input return losses f = 40 to 80 MHz 20 − dB

output return losses f = 40 to 80 MHz 20 − dB

phase response f = 50 MHz −45 +45 deg

CTB composite triple beat 85 channels flat;

X

mod

cross modulation 85 channels flat;

CSO composite second order distortion 85 channels flat;

d

2

V

o

second order distortion note 1 −−70 dB

output voltage dim = −60 dB; note 2 63 − dBmV
F noise figure f = 600 MHz − 8dB
I

tot

total current consumption (DC) note 3 − 435 mA

= 24 V; Tmb = 35 °C; ZS = ZL = 75 Ω.

B

f = 600 MHz 19 − dB

f = 80 to 160 MHz 19 − dB
f = 160 to 600 MHz 18 − dB

f = 80 to 160 MHz 19 − dB
f = 160 to 600 MHz 18 − dB

V
measured at 595.25 MHz

Vo = 44 dBmV;
measured at 55.25 MHz

V
measured at 596.5 MHz

= 44 dBmV;

o

= 44 dBmV;

o

−−62 dB

−−66 dB

−−60 dB

Notes

1. f

= 55.25 MHz; Vp = 44 dBmV;

p

fq = 541.25 MHz; Vq = 44 dBmV;
measured at fp + fq = 596.5 MHz.

2. Measured according to DIN45004B:
fp = 590.25 MHz; Vp = Vo;
fq = 597.25 MHz; Vq = Vo−6 dB;
fr = 599.25 MHz; Vr = Vo−6 dB;
measured at fp + fq− fr= 588.25 MHz.

3. The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.

February 1994 3

Philips Semiconductors Product specification

CATV amplifier module BGD602

CHARACTERISTICS

Bandwidth 40 to 550 MHz; V

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

G

p

power gain f = 50 MHz 18 19 dB

SL slope cable equivalent f = 40 to 550 MHz 0.2 2.2 dB
FL flatness of frequency response f = 40 to 550 MHz −±0.3 dB
S

11

S

22

S

21

input return losses f = 40 to 80 MHz 20 − dB

output return losses f = 40 to 80 MHz 20 − dB

phase response f = 50 MHz −45 +45 deg

CTB composite triple beat 77 channels flat;

X

mod

cross modulation 77 channels flat;

CSO composite second order distortion 77 channels flat;

d

2

V

o

second order distortion note 1 −−72 dB

output voltage dim = −60 dB; note 2 64 − dBmV
F noise figure f = 550 MHz − 7.5 dB
I

tot

total current consumption (DC) note 3 − 435 mA

= 24 V; Tmb = 35 °C; ZS = ZL = 75 Ω.

B

f = 550 MHz 18.8 − dB

f = 80 to 160 MHz 19 − dB
f = 160 to 550 MHz 18 − dB

f = 80 to 160 MHz 19 − dB
f = 160 to 550 MHz 18 − dB

V
measured at 547.25 MHz

Vo = 44 dBmV;
measured at 55.25 MHz

V
measured at 548.5 MHz

= 44 dBmV;

o

= 44 dBmV;

o

−−66 dB

−−68 dB

−−62 dB

Notes

1. f

= 55.25 MHz; Vp = 44 dBmV;

p

fq = 493.25 MHz; Vq = 44 dBmV;
measured at fp + fq = 548.5 MHz.

2. Measured according to DIN45004B:
fp = 540.25 MHz; Vp = Vo;
fq = 547.25 MHz; Vq = Vo−6 dB;
fr = 549.25 MHz; Vr = Vo−6 dB;
measured at fp + fq− fr= 538.25 MHz.

3. The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.

February 1994 4

Philips Semiconductors Product specification

CATV amplifier module BGD602

CHARACTERISTICS

Bandwidth 40 to 450 MHz; V

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

G

p

power gain f = 50 MHz 18 19 dB

SL slope cable equivalent f = 40 to 450 MHz 0.2 1.8 dB
FL flatness of frequency response f = 40 to 450 MHz −±0.3 dB
S

11

S

22

S

21

input return losses f = 40 to 80 MHz 20 − dB

output return losses f = 40 to 80 MHz 20 − dB

phase response f = 50 MHz −45 +45 deg

CTB composite triple beat 60 channels flat;

X

mod

cross modulation 60 channels flat;

CSO composite second order distortion 60 channels flat;

d

2

V

o

second order distortion note 1 −−75 dB

output voltage dim = −60 dB; note 2 67 − dBmV
F noise figure f = 450 MHz − 7dB
I

tot

total current consumption (DC) note 3 − 435 mA

= 24 V; Tmb = 35 °C; ZS = ZL = 75 Ω.

B

f = 450 MHz 18.6 − dB

f = 80 to 160 MHz 19 − dB
f = 160 to 450 MHz 18 − dB

f = 80 to 160 MHz 19 − dB
f = 160 to 450 MHz 18 − dB

V
measured at 445.25 MHz

Vo = 46 dBmV;
measured at 55.25 MHz

V
measured at 446.5 MHz

= 46 dBmV;

o

= 46 dBmV

o

−−67 dB

−−66 dB

−−60 dB

Notes

1. f

= 55.25 MHz; Vp = 46 dBmV;

p

fq = 391.25 MHz; Vq = 46 dBmV;
measured at fp + fq = 446.5 MHz.

2. Measured according to DIN45004B:
fp = 440.25 MHz; Vp = Vo;
fq = 447.25 MHz; Vq = Vo−6 dB;
fr = 449.25 MHz; Vr = Vo−6 dB;
measured at fp + fq− fr= 438.25 MHz.

3. The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.

February 1994 5

Philips Semiconductors Product specification

CATV amplifier module BGD602

DEFINITIONS

Data sheet status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.

LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.
