Philips BDP5010, BDP7320-F8, BDP7320-F7 User Manual
Register your product and get support at
Register your product and get support at
www.philips.com/welcome
www.philips.com/welcome
EN User manual
FR Manuel de l’Utilisateur
BDP5010
BDP7320/F7
BDP7320/F8
ES Manual del usuario
EN: For further assistance, call the customer support ser vice in your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact Philips
• To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 504 62 00
FR: Pour obtenir de l’aide supplémentaire, communiquez avec le centre de service à la clientèle de
votre pays.
•
• Pour obtenir l’aide au Mexique, entrez en contact avec le centre de soin de client de Philips à
ES: Para obtener más información, llame al servicio de soporte al cliente de su país.
•
• Solo para Mexico CENTRO DE ATENCIÓN A CLIENTES LADA. 01 800 504 62 00 Solo
Customer Care Center at 1-866-309-0866
Pour obtenir de l’aide aux États-Unis, au Canada, à Puerto Rico ou aux Îles Vierges américaines,
communiquez avec le centre de service à la clientèle Philips au : 1-866-309-0866
01 800 504 62 00
Para obtener asistencia en los Estados Unidos, en Canadá, Puerto Rico o en las Islas Vírgenes de los
Estados Unidos, comuníquese con Centro de atención al cliente de Philips al 1-866-309-0866
Para México.
PRECAUTIONS
Return your Product Registration Card or register online at
www.philips.com/welcome today to get the very most from your purchase.
Registering your model with PHILIPS makes you eligible for all of the valuable benets listed below,
so don't miss out. Complete and return your Product Registration Card at once, or register online at
www.philips.com/welcome to ensure:
*Proof of
Purchase
Returning the enclosed card guarantees that your date of purchase
will be on le, so no additional
paperwork will be required from
you to obtain warranty service.
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your condence in PHILIPS.
You’ve selected one of the best-built, bestbacked products available today. We’ll do
everything in our power to keep you happy
with your purchase for many years to come.
As a member of the PHILIPS “family,”you’re
entitled to protection by one of the most
comprehensive warranties and outstanding
service networks in the industry. What’s more,
your purchase guarantees you’ll receive all the
information and special oers for which you
qualify, plus easy access to accessories from
our convenient home shopping network.
Most importantly, you can count on our
uncompromising commitment to your total
satisfaction.
All of this is our way of saying welcome - and
thanks for investing in a PHILIPS product.
P.S. To get the most from your PHILIPS
purchase, be sure to complete and
return your Product Registration Card
at once, or register online at:
www.philips.com/welcome
*Product Safety
Notication
By registering your product, you'll
receive notication - directly from
the manufacturer - in the rare
case of a product recall or safety
defect.
*Additional
Benets
Registering your product guarantees that you’ll receive all of
the privileges to which you're
entitled, including special moneysaving oers.
Know these
safety
CAUTION:
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
WARNING
shock, this apparatus should not be exposed to rain or
moisture, and objects lled with liquids, such as vases,
should not be placed on this apparatus.
:NOITUAC
lame la plus large de la che dans la borne correspondante de
The symbol for CLASS ll (Double Insulation)
The important note and rating are located on the rear or
bottom of the cabinet.
Enter below the Serial No. which is located on the cabinet.
Retain this information for future reference.
symbols
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TOREDUCE THE RISK OF ELECTRIC
This “bolt of lightning” indicates uninsulated material
within your unit may cause an electrical shock. For
the safety of everyone in your household, please do
not remove product covering.
The “exclamation point” calls attention to features
for which you should read the enclosed literature
closely to prevent operating and maintenance
problems.
To reduce the risk of re or electric
:
To prevent electric shock, match wide blade of
.tresniylluf,tolsediwotgulp
:NOITNETTA Pour éviter les chocs électriques, introduire la
.dnofua’uqsujressuopteesirpal
For Customer Use
Model No. _______________________________________
Serial No. _______________________________________
Visit our World Wide Web Site at http://www.philips.com/welcome
EN2
PRECAUTIONS
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not t into your outlet, consult
an electrician for replacement of the obsolete outlet.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modications to this equipment may
cause harmful interference unless the modications are expressly approved in the manual. The user could lose the
authority to operate this equipment if an unauthorized change or modication is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
This Class B digital apparatus complies with Canadian ICES-003.
Disconnect the mains plug to shut o when nd trouble or not in use. The mains plug shall remain readily operable.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
WARNING:
LASER SAFETY
This apparatus employs a laser. Only a qualied service person should remove the cover or attempt to service this
apparatus, due to possible eye injury.
CAUTION: Use of controls or adjustments or performance of procedures other than those specied herein may
CAUTION: Laser radiation when open. Do not stare into beam.
LOCATION: Inside, near the BD mechanism.
Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine, re, or the like.
result in hazardous radiation exposure.
EN
3
PRECAUTIONS
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates
copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this
copyright protection technology must be authorized by Macrovision, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing
or climbing on it. A falling unit can cause serious injury or even death.
To Avoid the Hazards of Electrical Shock and Fire
•
Do not handle the AC power cord with wet hands.
Do not pull on the AC power cord when disconnecting it from an AC outlet. Grasp it by the plug.
•
Do not put your ngers or objects into the unit.
•
Location and Handling
Do not install the unit in direct sunlight, near strong magnetic elds, or in a place subject to dust or strong vibration.
•
Avoid a place with drastic temperature changes.
•
Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit.
•
Depending on your external devices, noise or disturbance of the picture and/or sound may be generated if the unit is
placed too close to them. In this case, please ensure enough space between the external devices and the unit.
Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.
•
•
Be sure to remove the disc and unplug the AC power cord from the outlet before carrying the unit.
Dew Condensation Warning
Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few
•
hours until its inside gets dry.
- The unit is moved from a cold place to a warm place.
- Under conditions of high humidity.
- After heating a cold room.
Notice for Progressive Scan Output
Consumers should note that not all high denition television sets are fully compatible with this product and may
•
cause artifacts to be displayed in the picture. In case of picture problems with 525(480) progressive scan output,
it is recommended that the user switch the connection to the ‘standard denition’ output. If there are questions
regarding your TV set compatibility with this 525p(480p) BD/DVD player, please contact our customer service center.
4
EN
PRECAUTIONS
Maintenance
Servicing
• Please refer to relevant topics on “TROUBLESHOOTING”
on page 65 before returning the product.
• If you need to call a customer service representative,
please know the model number and serial number of
your product before you call. This information is
displayed on the back of the product. Also, please take a
moment to identify the problem you are having, and be
prepared to explain this to the representative. If you
believe the representative will need to help you with
operations, please stay near the product. Our
representatives will be happy to assist you. For online
reference, please visit our web site at
http://www.philips.com/welcome
Cleaning the Cabinet
• Wipe the front panel and other exterior surfaces of the
unit with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean
the unit. Do not spray insecticide liquid near the unit.
Such chemicals may discolor the surface or damage the
unit.
Cleaning Discs
• When a disc becomes dirty, clean it with a cleaning cloth.
Wipe the disc from the center to out. Do not wipe in a
circular motion.
• Do not use solvents such as benzine, thinner,
commercially available cleaners, detergent, abrasive
cleaning agents or antistatic spray intended for analog
records.
Notice
2010 © Koninklijke Philips Electronics N.V. All rights
reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners. Philips reserves
the right to change products at any time without being
obliged to adjust earlier supplies accordingly.
The material in this manual is believed adequate for the
intended use of the system. If the product, or its individual
modules or procedures, are used for purposes other than
those specified herein, confirmation of their validity and
suitability must be obtained. Philips warrants that the
material itself does not infringe any United States patents.
No further warranty is expressed or implied.
Philips cannot be held responsible neither for any errors in
the content of this document nor for any problems as a
result of the content in this document. Errors reported to
Philips will be adapted and published on the Philips
support website as soon as possible.
Warranty
No components are user serviceable. Do not open or
remove covers to the inside of the product. Repairs may
only be done by Philips Service Centers and official repair
shops. Failure to do so shall void any warranty, stated or
implied.
Any operation expressly prohibited in this manual, any
adjustments, or assembly procedures not recommended
or authorized in this manual shall void the warranty.
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
Cleaning the Disc Lens
• If this unit still does not perform properly although you
refer to the relevant sections and to “TROUBLESHOOTING”
in this user manual, the laser optical pickup unit may be
dirty. Consult your dealer or an Authorized Service Center
for inspection and cleaning of the laser optical pickup
unit.
Disc Handling
• Handle the discs so that fingerprints and dust do not
adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not
used.
• Note that discs with special shapes (heart-shaped discs,
octagonal discs, etc.) cannot be played back on this unit.
Do not attempt to play such discs, as they may damage
the unit.
EN
5
PRECAUTIONS
Important
Registering your model with Philips makes you eligible for
all of the valuable benefits listed below, so don’t miss out.
Complete and return your Product Registration Card at
once, or register online at www.philips.com/welcome to
ensure :
Proof of Purchase
Returning the enclosed card guarantees that your date of
purchase is on file, so no additional paperwork is required
from you to obtain warranty service.
Product Safety Notification
By registering your product you receive notification - directly
from the manufacturer - in the rare case of a product recall or
safety defect.
Additional Benefits of Product Ownership
Registering your product guarantees that you receive all of
the privileges to which you’re entitled, including special
money-saving offers.
For further assistance
For further assistance, call the customer support service in
your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico, or
the U.S. Virgin Islands, contact Philips Customer Care
Center at 1-866-309-0866
Environmental Care
The packaging of this product
is intended to be recycled.
Contact your local authorities
for information about how to
recycle the packaging.
End of life directives
Philips pays a lot of attention
to produce environmentfriendly products in green
focal areas. Your new Blu-ray
Disc Player contains materials
which can be recycled and
reused. At the end of its life,
specialized companies can
dismantle the discarded Bluray Disc Player to concentrate
the reusable materials and to
minimize the amount of
materials to be disposed of.
Please ensure you dispose of
your old Blu-ray Disc Player
according to local regulations.
Supplied Accessories
User Manual
• remote control
• AAA (1.5V) battery × 2
registration card
registration card
USB wireless
LAN adapter
(PH2010A)
User Manual Quick Start
Netflix
Box-insert
Netflix
Box-insert
SD card (2G) x 1
Note
• Wireless LAN Adapter for Philips model: BDP7320/F7
This wireless device can only be used with a limited
number of Philips products. For more details go to:
www.philips.com/welcome and enter your model
number.
• Do not use the supplied USB wireless LAN adapter
with devices other than this unit and a limited
number of Philips products.
• The supplied USB wireless LAN adapter is guaranteed
by manufacturer.
Quick Start Guide
Guide
RCA audio / video cables
Disposal of used batteries
The batteries supplied do not contain the heavy metals
mercury and cadmium. Nevertheless, in many areas
batteries may not be disposed of with your household
waste. Please ensure you dispose of batteries according to
local regulations.
6
EN
PRECAUTIONS
Trademark Information
Manufactured under license
from Dolby Laboratories.
“Dolby” and the double-D
symbol are trademarks of
Dolby Laboratories.
Manufactured under license
under U.S. Patent #'s:
5,451,942; 5,956,674;
5,974,380; 5,978,762;
6,226,616; 6,487,535;
7,392,195; 7,272,567;
7,333,929; 7,212,872 & other
U.S. and worldwide patents
issued & pending. DTS and the
Symbol are registered
trademarks, & DTS-HD, DTSHD Master Audio | Essential
and the DTS logos are
trademarks of DTS, Inc.
Product includes software. ©
DTS, Inc. All Rights Reserved.
HDMI, the HDMI Logo, and
High-Definition Multimedia
Interface are trademarks or
registered trademarks of HDMI
Licensing LLC in the United
States and other countries.
“x.v.Color” and “x.v.Color”
logo are trademarks of Sony
Corporation.
Java and all other Java
trademarks and logos are
trademarks or registered
trademarks of Sun
Microsystems, Inc. in the
United States and/or other
countries.
“BD-LIVE” logo is trademark of
Blu-ray Disc Association.
DLNA®, the DLNA Logo and
DLNA CERTIFIED® are
trademarks, service marks, or
certification marks of the
Digital Living Network
Alliance.
Netflix and the Netflix
logo are trademarks
or registered
trademarks of Netflix,
Inc.
© 2009 Sonic Solutions.
Roxio, CinemaNow, Roxio
CinemaNow and the Roxio
CinemaNow logos are
trademarks or registered
trademarks owned by
Sonic Solutions in the
United States and other
jurisdictions.
BLOCKBUSTER name,
design and related marks
are trademarks of
Blockbuster Inc.
vTuner is a trademark of
Nothing Else Matters
Software, Ltd.
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
Windows Media and the
Windows logo are trademarks
or registered trademarks of
Microsoft Corporation in the
United States and/or other
countries.
DivX®, DivX Certified® and
associated logos are registered
trademarks of DivX, Inc. and
are used under license.
“AVCHD” and the “AVCHD” logo
are trademarks of Panasonic
Corporation and Sony
Corporation.
“BONUSVIEW” is trademark of
Blu-ray Disc Association.
“Blu-ray Disc” and are trademarks.
is a trademark of DVD Format/Logo Licensing
Corporation.
is trademark of Eastman Kodak Company.
EN
7
CONTENTS
Introduction
Precautions ...................................................................2
Maintenance ...............................................................................5
Notice ............................................................................................5
Important .....................................................................................6
Supplied Accessories ...............................................................6
Trademark Information ...........................................................7
Features ........................................................................9
Features ........................................................................................9
Product Info .............................................................................. 10
Symbols Used in this User Manual ...................................10
Functional Overview .................................................. 11
Front Panel ................................................................................ 11
Rear Panel ..................................................................................11
Remote Control ....................................................................... 12
Front Panel Display ................................................................ 14
Guide to On-Screen Display ...............................................15
Connections
Connections ................................................................16
Connection to the TV ............................................................16
Connection to an Audio System ....................................... 19
Connection to the Network ................................................ 21
Basic Setup
Before You Start .........................................................23
Finding the Viewing Channel on Your TV .....................23
Playback
Information on Playback ...........................................24
Information on Playback ......................................................24
Guide to File List .....................................................................26
How to Insert a Disc ............................................................... 26
Basic Playback ............................................................27
Playing Back a BD, DVD or a Disc with AVCHD Files ........ 27
Playing Back an Audio CD or a Disc with DivX® /
MP3 / Windows Media™ Audio / JPEG Files ...............28
Kodak Picture CD .................................................................... 30
Reading the SD Memory Card ...........................................30
Playing Video / Music / Photo Files from DLNA
Certified Home Media Servers ........................................31
About DivX® and DivX® VOD .............................................. 32
Playing Back DivX® with DivX® External Subtitle ........33
Using the Title / Disc Menu .................................................33
Special Playback .........................................................34
Fast Forward / Fast Reverse ................................................34
Slow Forward Playback ........................................................34
Step by Step Playback ..........................................................34
Zoom ...........................................................................................34
Repeat Playback ...................................................................... 35
A-B Repeat ................................................................................35
Slide Show .................................................................................35
PiP (BONUSVIEW) Setting .................................................... 36
Enjoying BD-Live Discs with Internet ..............................36
Title / Chapter Search ...........................................................37
Track Search .............................................................................37
Time Search ..............................................................................37
Switching Subtitles ................................................................38
Switching Audio Soundtrack .............................................38
Switching Camera Angles ...................................................39
Netflix Operations ..................................................... 40
Before Activating the Connection to Netflix .................40
Activating the Connection to Netflix ...............................40
Watching Streaming Movies ...............................................40
CinemaNow / Blockbuster Operations .....................41
Before Activating the Connection to CinemaNow /
Blockbuster ............................................................................41
Activating the Connection to CinemaNow /
Blockbuster ............................................................................41
Guide to CinemaNow / Blockbuster Menu Screen .......... 41
Renting or Purchasing Movies / TV episodes ................42
Searching Movies / TV episodes ........................................42
Watching Rented or Purchased
Movies / TV episodes ..........................................................42
Enjoying Internet Radio with vTuner ...................... 43
Internet Radio Playback ........................................................43
Guide to the Playback Screen .............................................44
Add to Favorite List ................................................................44
Remove from Favorite List ...................................................44
Add Stations on the vTuner Website ...............................44
Reset the Station List .............................................................44
Function Setup
List of Settings ............................................................ 45
Setups ......................................................................... 52
TV Shape .....................................................................................52
HDMI Video Resolution .........................................................52
HDMI Audio ...............................................................................53
Digital Out .................................................................................55
Speaker Setup ..........................................................................56
Ratings Lock ..............................................................................56
Network Connection .............................................................58
EasyLink (HDMI CEC) ..............................................................63
Software Upgrade ...................................................................63
Reset to Factory Default .......................................................64
Others
Troubleshooting ........................................................ 65
Downloading an Electronic Copy .....................................67
Contact Us .................................................................................67
Glossary ......................................................................68
Specifications ............................................................. 70
Network Service Disclaimer ...................................... 71
ONE (1) YEAR LIMITED WARRANTY .......................... 72
EN8
FEATURES
Congratulations on your purchase, and welcome to Philips!
To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.
Features
Blu-ray Disc
You can enjoy Blu-ray Disc which is capable of storing five
times more data than a conventional DVD.
BD-Java
With some BDs which support Java applications, you can
enjoy the interactive functions such as games or interactive
menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before thanks to
video upscaling. Upscaling will increase the resolution of
standard definition DVD to high definition up to 1080p over
an HDMI connection. The picture will be less jagged and more
realistic for a near high definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and SD card
ensures that you can continue to enjoy your current audiovideo collection. Additionally, you can view JPEG digital
pictures or listen to MP3 or Windows Media™ Audio music
files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-life
sound and makes you feel that you are really there.
Intuitive user interface and remote control
The Philips logical user interface allows you to easily navigate
through your content and settings, so you can quickly find
what you are looking for.
Easy and simple connection to your HDTV via HDMI
Connect your BDP7320 to your HDTV with one single HDMI
(High Definition Multimedia Interface) cable. Philips
recommends HDMI1.3 (category 2) cable (also known as High
Speed HDMI cable) for better compatibility. The high definition
video output signal will be transferred to your HDTV without
conversion to analog signals, so you will get excellent picture
and sound quality, completely free from noise.
Thanks to other multiple outputs, you can also easily connect
to your home theater system or amplifier.
About EasyLink (HDMI CEC) (Consumer Electronics
Control)
EasyLink (HDMI CEC) allows you to operate the linked
functions of this player with Philips brand TV with EasyLink
feature.
Philips does not guarantee 100 % interoperability with other
brands of HDMI CEC compliant devices.
PiP (BONUSVIEW)
Some BD-videos have the PiP function which enables you to
display the secondary video in the primary video. You can call
up the secondary video by pressing [BONUSVIEW (PiP)]
whenever the scene contains the secondary video.
BD-Live
BD-Live (BD-ROM version 2 Profile 2.0) that allows interactive
functions to be used when this unit is connected to the
Internet in addition to the BONUSVIEW function. The various
functions differ depending on the disc.
Pop-up menu
Some BD-videos have a pop-up menu which is a navigation
menu that can be called up and be operated on the TV screen
without interrupting playback. You can call up the pop-up
menu by pressing [DISC MENU / POP-UP MENU]. Contents in
the pop-up menu vary depending on the disc.
HDMI Deep Color
Deep Color reduces posterization effect of the playback
image. Refer to “HDMI Deep Color” in the “LIST OF SETTINGS”
on page 46.
HDMI 1080p/24 output (BD only)
This unit is equipped with the feature which can provide smooth
movement during playback of film originated material with the
frame rate of 24 frames per second with progressive. (Available
only when the display device is connected by an HDMI cable.)
Refer to “HDMI 1080p/24” in the
.
page 46
Playing back contents from an SD Memory Card
You can play back
Memory Card. BD-ROM Profile 2.0 (BD-Live) and Profile 1.1 discs
sometimes store picture-in-picture commentary, subtitles or
other extras in the SD Memory Card for use during playback with
the BD-video.
Playing back AVCHD files
This unit supports playback of AVCHD format files (new format
for high definition video camcorders) recorded on disc / SD
card. Your high definition personal archive is playable in HD
quality.
x.v.Color
This unit supports playback of video contents on discs
recorded with “x.v.Color” technology. To watch this video
content with the “x.v.Color” space, a TV or other display
device supporting both video image reproduction using
“x.v.Color” standard and capability of manual switching of its
color space setting is required. Please refer to the owner’s
manual of your display device for further information.
Enjoy contents stored on DLNA certified home media
servers
This unit is a DLNA certified media player that can play video,
music and photo files stored on DLNA certified home media
servers connected to your home network.
Netflix
With this unit, you can enjoy movies and TV episodes
streamed instantly from Netflix via the Internet. In order to use
this feature, you must visit netflix.com/Philips
become a Netflix member.
(This feature is available only in the United States. )
CinemaNow / Blockbuster
With this unit, you can enjoy movies and TV episodes streamed
instantly from CinemaNow / Blockbuster via the Internet.
In order to use this feature, you must visit following website on
your PC and become a CinemaNow / Blockbuster member.
- CinemaNow : www.cinemanow.com/Login
- Blockbuster : www.blockbuster.com/auth/login
vTuner
This unit supports vTuner which is a database service of
Internet radio stations. You can enjoy various kinds of Internet
radio stations with vTuner via the Internet.
AVCHD
“LIST OF SETTINGS” on
/
MP3 / WMA
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
/ JPEGs stored in an SD
on your PC and
9EN
FEATURES
Product Info
“Product Info” screen provides information about this
unit’s hardware and software version.
You can also download the latest firmware from the web
site which is displayed in the “Product Info” screen, and
update the firmware yourself.
To access “Product Info”, select “Product Info” in the home
menu.
Symbols Used in this User Manual
To specify which media type each function is applicable to, we
put the following symbols at the beginning of each item to
operate.
Symbol Description
Description refers to BD-video
Description refers to DVD-video
Description refers to audio CD / DTS-CD
Description refers to DVD-RW/-R and SD card
with AVCHD files
Description refers to BD-RE/-R, DVD-RW/-R
and CD-RW/-R with DivX® files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD card with MP3 files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD card with
Windows Media™ Audio files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD card with JPEG files
Description refers to video files in the DLNA
home server
Description refers to music files in the DLNA
home server
Description refers to photo files in the DLNA
home server
If you do not find any of the symbols listed above under the
function heading, the operation is applicable to all media.
10
EN
FUNCTIONAL OVERVIEW
Front Panel
1
2
4 5 76
1. Q (standby/on) button
• Press to turn on the unit, or to turn the unit into the
standby mode. (To completely turn off the unit, you
must unplug the AC power cord.)
• Press and hold for 10 seconds to shut down the unit.
• This button lights up in red when the unit is in
standby mode and turns off when the power is on.
2. C (stop) button
• Touch to stop playback.
3. F (pause) button
• Touch to pause playback.
4. B (play) button
• Touch to start or resume playback.
5. A (open/close) button
• Touch to open or close the disc tray.
Rear Panel
8
93 10
6. Disc tray
• Place a disc after opening the disc tray.
7. LED light
• Lights up in blue when the power is on and “Ambient
Light Control” is set to “On”. (Refer to page 50.)
8. Display
• Refer to “Front Panel Display” on page 14.
9. Infrared sensor window
• Receive signals from your remote control so that you
can control the unit from a distance.
10.SD card slot
• Insert an SD Memory Card and play back the
contents in it.
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
4
COAXIAL
DIGITAL OUT
PCM/BITSTREAM
76
3
PR/CR
Y
L
PB/CB
R
AUDIO
VIDEO
COMPONENT
VIDEO OUT
OUT
OUT
8
1
LAN
Wireless LAN
2
HDMI OUT
1. LAN terminal
• Use to connect a modem with LAN cable.
2. HDMI OUT jack
• Use to connect to a display with an HDMI compatible
port with an HDMI cable.
3. AUDIO OUT jacks
• Use to connect a TV monitor, an AV receiver /
amplifier or other device with an RCA audio cable.
4. COMPONENT VIDEO OUT jacks
• Use to connect a TV monitor with component video
inputs with an RCA component video cable.
5. AC power cord
• Connect to a standard AC outlet to supply power to
this unit.
• Unplug this cord from the AC outlet to completely
turn off the unit.
6. Wireless LAN terminal
• Use to connect the supplied USB wireless LAN
adapter.
5
SBL
SLCFL
7.1 ch AUDIO OUT
SBR
FR SW SR
9
7. DIGITAL OUT (COAXIAL) jack
• Use to connect an AV receiver / amplifier, Dolby
Digital / DTS decoder or other device with a digital
audio coaxial input jack with a digital audio coaxial
cable.
8. VIDEO OUT jack
• Use to connect a TV monitor, an AV receiver /
amplifier or other device with an RCA video cable.
9. 7.1ch AUDIO OUT jacks
• Use to connect to an AV receiver / amplifier with
7.1ch audio cable.
Note
• Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
• This unit does not have the RF modulator.
• Do not insert a USB flash memory to the Wireless LAN
terminal. This unit is not designed to play back data
in USB flash memory.
11EN
FUNCTIONAL OVERVIEW
Remote Control
1
2
3
4
5
6
7
8
9
10*
11
12
13
14
15*
16
17
18
* The unit can also be turned on by pressing these buttons.
1. Q (standby/on) button
• Press to turn on the unit, or to turn the unit into the
standby mode. (To completely turn off the unit, you
must unplug the AC power cord.)
2. BONUSVIEW (PiP) button
• Press to switch picture in picture feature on/off
(only applicable to BD-video which supports the PiP
(BONUSVIEW) function).
3. ZOOM button
• Press to enlarge the picture on the TV screen.
4. RED / GREEN / BLUE / YELLOW button
• Press to activate short cut keys on some BD-video
function.
• When file list / setup list is shown, press to switch
between pages.
5. (home) button
• Press to display the home menu.
6. DISC MENU / POP-UP MENU button
BD:
• Press to display the pop-up menu.
DVD:
• Press to display the disc menu.
7. K / L / s / B buttons
• Press to select items or settings.
8. OK button
• Press to confirm or select menu items.
9. BACK U button
• Press to return to the previously displayed menu or
screen function.
29
28
27
26
25
24
23
22
21
20
19
10. B (play) button*
• Press to start playback or resume playback.
11. S (previous) button
• During playback, press once to return to the
beginning of the current title, chapter, track or file.
• During playback, press twice to return to the
previous title, chapter, track or file.
• During the JPEG playback, press to return to the
previous file.
12. E (reverse) button
• During playback, press to fast reverse the playback.
13. C (stop) button
• Press to stop playback.
14. ⴐ / ⴑ (volume) button
• Press to adjust the TV volume (only applicable to
the PHILIPS brand TV).
15. A (open/close) button*
• Press to open or close the disc tray.
16. Number buttons
• Press to select a chapter during playback.
• Press to enter values in the input field.
17. SUBTITLE button
• Press to select subtitles on a disc.
18. ANGLE button
• Press to select camera angles on a disc.
• Press to rotate a picture (JPEG).
19. HDMI button
• Press to set the HDMI output mode.
20. AUDIO button
• Press to select the audio channel (such as audio
languages) on a disc.
21. TV CH ⴐ / ⴑ buttons
• Press to change the channel up and down (only
applicable to the PHILIPS brand TV).
22. d (mute) button
• Press to mute the TV volume (only applicable to the
PHILIPS brand TV).
23. D (forward) button
• During playback, press to fast forward the playback.
• When playback is in pause, press to slow forward
the playback.
24. T (next) button
• During playback, press to skip to the next chapter,
track or file.
25. F (pause) button
• Press to pause playback.
• When playback is in pause mode, press repeatedly
to forward the playback step by step.
26. INFO button
• Press to display the information display.
27. TOP MENU button
BD:
• Press to display the top menu.
DVD:
• Press to display the title menu.
28. REPEAT A-B button
• Press to play back a defined section between point
A and B repeatedly.
29. REPEAT button
• Press to toggle between various repeat modes.
12
EN
FUNCTIONAL OVERVIEW
Installing the Batteries in the Remote Control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.
1) Open the cover.
2) Insert batteries.
Make sure to match + and - on the batteries to the
marks indicated in the battery compartment.
3) Close the cover.
Using a Remote Control
Remote Control Usage Guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on the
unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote control for different devices can interfere with
each other. Avoid using remote control for other device
located close to the unit.
• Replace the batteries when you notice a fall off in the
operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
- Line of sight:
approx. 23 feet (7 m)
- Either side of the center:
approx. 16 feet (5 m) within 30°
-Above:
approx. 16 feet (5 m) within 15°
-Below:
approx. 10 feet (3 m) within 30°
30˚ 30˚
16 feet (5 m) 23 feet (7 m)
16 feet (5 m)
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
Note
Incorrect use of batteries can result in hazards such as
leakage and bursting. Please observe the following:
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery
match the indications in the battery compartment.
• Remove batteries from battery compartment that is
not going to be used for a month or more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public instruction’s rules that apply in your country
or area.
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
EN
13
Front Panel Display
1 2 3
FUNCTIONAL OVERVIEW
* Brightness of the display can be adjusted. Refer to “Front Panel Brightness” in “LIST OF SETTINGS” on page 50.
1. Displays repeat icon. (Appears during repeat playback.)
2. Displays USB icon (when the supplied USB wireless LAN adapter is connected).
3. Displays media mode icon (disc mode or SD card mode).
4. Displays playback status icon. Refer to the table below.
5. Displays information such as title number, elapsed playing time, repeat type, menu type, etc.
Playback status icon Mode
4
Playback is in progress
Stop mode
Pause mode
Fast forward mode
Fast reverse mode
Slow forward mode
Loading
5
e.g.)
14
Disc is being played back.
Indicating the current title number and the elapsed time.
Current chapter is in chapter repeat mode during playback of disc.
Loading a disc.
Dolby Digital audio is being played back during playback of disc.
DTS audio is being played back during playback of disc.
Home menu is displayed and the unit is in disc mode.
EN
FUNCTIONAL OVERVIEW
k
BD-Player
Guide to On-Screen Display
Home Menu
When you turn on the unit, home menu will appear
automatically. Otherwise, press [(home)].
Blu-ray Disc Player
“Disc Tray” : To access the track / file list or media
“SD Card” : To access the file list or media filter
“Settings” : To access the settings menus
“Product Info” : To access the product information
“Home Network”:To access the list of DLNA home server
“NETFLIX” : To access the Netflix screen
“CinemaNow” : To access the CinemaNow menu
“BLOCKBUSTER” : To access the Blockbuster menu
“vTuner” : To access the menu screen of vTuner
Disc Tray
SD Card
Settings
Product Info
Home Networ
filter screen
screen
screen
screen
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
Menu Screen
1
23
1. Directory
Displays the current hierarchy.
2. Menus
3. Options
Displays options for the highlighted item on the left
whenever available.
Settings
Quick Setup
Advanced Setup
Factory Default
Player Menu
TV Shape
HDMI Video Resolution
EN
15
Connection to the TV
Choose the appropriate connection, then proceed to the corresponding
1
instruction (A, B or C) on the next page.
CONNECTIONS
Best
No analog audio connection required.
(*1)
1080i : Outputs the video data with frame rate of 30 frames per second.
(*2)
1080p : Outputs the video data with frame rate of 60 frames per second.
No supplied cables are used in this connection:
Please purchase the necessary cables at your local store.
Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection.
High Speed HDMI Cable (also known as HDMI category 2 cable) is recommended for better compatibility.
Better
(Supports up to 1080i
Video
Audio
HDMI cable
(Supports up to 1080i resolution.)
Video
RCA component video cable
(*1)
, 1080p
+
(*2)
, 1080p/24 resolution.)
HDMI IN
COMPONENT
VIDEO IN
Y
PB/CB
PR/CR
L
Your TV
High
Definition
TV
Your TV
High
Definition
TV
Go To
Go To
A
B
Audio
Supplied cables used in this connection are as follows:
• RCA audio cable (L/R) x 1
Please purchase the rest of the necessary cables at your local store.
Basic
Video
+
Audio
• Connect this unit directly to the TV. If the RCA audio / video cables are connected to a VCR, pictures may be distorted
due to the copy right protection system.
Supplied cables used in this connection are as follows:
• RCA audio cable (L/R) x1
• RCA video cable x1
RCA audio cable
(Supports only 480i resolution.)
RCA video cable
RCA audio cable
AUDIO IN
R
VIDEO IN
L
AUDIO IN
R
Your TV
Standard
Definition
TV
Go To
C
EN16
CONNECTIONS
Connect the cables by following the descriptions below.
2
HDMI Video / Audio Connection
PR/CR
Y
A
Wireless LAN
($-)/54
Component Video + Standard Audio Connection
B
LAN
LAN
Wireless LAN
L
HDMI OUT
PB/CB
R
COAXIAL
AUDIO
VIDEO
COMPONENT
DIGITAL OUT
VIDEO OUT
OUT
OUT
PCM/BITSTREAM
FR SW SR
7.1 ch AUDIO OUT
SBL
SLCFL
SBR
HDMI cable
PR/CR
Y
L
HDMI OUT
PB/CB
R
COAXIAL
AUDIO
VIDEO
COMPONENT
DIGITAL OUT
VIDEO OUT
OUT
OUT
PCM/BITSTREAM
FR SW SR
7.1 ch AUDIO OUT
SBL
SLCFL
SBR
RCA component
video cable
Your TV
HDMI IN
COMPONENT
VIDEO IN
Y
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
Your TV
Y
PR/C
R
PB/C
B
COMPONENT
VIDEO OUT
RCA audio cable
AUDIO
OUT
L
R
Standard Video + Standard Audio Connection
C
Wireless LAN
LAN
HDMI OUT
PR/CR
Y
L
PB/CB
R
AUDIO
VIDEO
COMPONENT
COAXIAL
DIGITAL OUT
VIDEO OUT
OUT
OUT
PCM/BITSTREAM
FR SW SR
7.1 ch AUDIO OUT
SBL
SLCFL
SBR
L
RCA video cable
R
AUDIO
VIDEO
OUT
OUT
RCA audio cable
PR/CR
PB/CB
VIDEO IN
L
AUDIO IN
R
Your TV
L
AUDIO IN
R
EN
17
CONNECTIONS
HDMI Mode and Actual Output Signals
Press [HDMI] to change the resolution of the video signal being output from the HDMI OUT jack. The video resolution
changes as follows every time [HDMI] is pressed. Or change the setting in the “HDMI Video Resolution” in the settings
menu.
Font Panel Display HDMI Video Resolution
480 Progressive
Press [HDMI]
720 Progressive
Press [HDMI]
1080 Interlaced
Press [HDMI]
1080 Progressive
Press [HDMI]
Copyright protection system
To play back the digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary that both the
player and the display device (or an AV receiver / amplifier) support a copyright protection system called HDCP (highbandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption
and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of
your display device (or AV receiver / amplifier) for more information.
Note
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• The audio signals from the HDMI jack (including the sampling frequency, the number of channels and bit length)
may be limited by the device that is connected.
• Among the display device(s) that support HDMI, some do not support audio output (for example, projectors). While
connected to a device such as a projector, audio will not be output from the HDMI OUT jack.
• When this unit’s HDMI jack is connected to a DVI-D compatible display device(s) (HDCP compatible) with an HDMI-
DVI converter cable, the signals are output in digital RGB.
•Pressing [HDMI] does not work when HDMI cable is not connected, or when no video signal is being output from
the HDMI OUT jack.
•Pressing [HDMI] does not work during the playback of a BD-video.
• When you make a selection, the TV monitor temporarily goes blank and then comes back again. If it does not, press
[HDMI] repeatedly to change the resolution or press and hold [B (play)] on the front panel for 5 seconds to change
the setting back to its default.
18
EN
CONNECTIONS
Connection to an Audio System
• When you change the connections, all devices should be turned off.
• Refer to the manual accompanying external devices for more information.
2-Channel Analog Audio Connection Digital Audio Connection
EN
stereo system
audio
digital audio coaxial
input jack
analog audio input jacks
AUDIO IN
LR
RCA audio
cable
Wireless LAN
L
P
R
/
C
R
Y
L
P
B
/
C
LAN
HDMI OUT
B
R
AUDIO
VIDEO
COAXIAL
COMPONENT
DIGITAL OUT
VIDEO OUT
PCM/BITSTREAM
OUT
OUT
FR SW SR
7.1 ch AUDIO OUT
SBL
SLCFL
SBR
this unit
Wireless LAN
LAN
HDMI OUT
COAXIAL
DIGITAL OUT
PCM/BITSTREAM
R
AUDI O
OUT
AUDIO OUT
To set up “Digital Out”, refer to page 55.
Audio Output from Analog Out (2ch Jacks)
“Blu-ray Disc Audio” setting A “Primary Audio Only” “Mix Audio Output”
Media
ª
Dolby Digital
Dolby Digital Plus
BD-video
Dolby TrueHD
DTS®
DTS-HD®
LPCM
Dolby Digital DownMix 2ch PCM
DVD-video
DTS® DownMix 2ch PCM
LPCM 2ch PCM
DTS-CD DTS® DownMix 2ch PCM
AVCHD
DivX®
Dolby Digital DownMix 2ch PCM
LPCM DownMix 2ch PCM
Dolby Digital DownMix 2ch PCM
MP3 / MP2 2ch PCM
Audio CD PCM 2ch PCM
MP3 MP3 2ch PCM
Windows Media™ Audio WMA 2ch PCM
Dolby Digital DownMix 2ch PCM
DLNA Video
MP2 2ch PCM
LPCM 2ch PCM
DLNA Music MP3 / WMA / LPCM 2ch PCM
Netflix WMA 2ch PCM
CinemaNow AAC 2ch PCM
Blockbuster AAC 2ch PCM
vTuner MP3 / WMA 2ch PCM
*1)
Full decoded.
*2)
Only the independent substream is decoded.
*3)
Dolby TrueHD stream is decoded.
*4)
Only the Dolby Digital substream is decoded.
*5)
Only the core substream is decoded.
Audio Source
ª
DownMix 2ch PCM DownMix 2ch PCM
DownMix 2ch PCM
DownMix 2ch PCM
DownMix 2ch PCM DownMix 2ch PCM
DownMix 2ch PCM
DownMix 2ch PCM DownMix 2ch PCM
AV receiver / amplifier
DIGITAL AUDIO INPUT
P
R
/
C
R
Y
L
P
B
/
C
B
R
AUDIO
VIDEO
COMPONENT
VIDEO OUT
OUT
OUT
DIGITAL OUT (COAXIAL)
*1
*3
*1
DownMix 2ch PCM
DownMix 2ch PCM
DownMix 2ch PCM
COAXIAL
digital audio
RCA cable
FR SW SR
COAXIAL
DIGITAL OUT
PCM/BITSTREAM
7.1 ch AUDIO OUT
Introduction Connections Basic Setup Playback OthersFunction Setup
SBL
SLCFL
SBR
*2
*4
*5
EN
19
CONNECTIONS
Multi-Channel Analog Audio Connection
AV receiver / amplifier with multi-channel audio input jacks.
audio
7.1ch
audio cable
To set up the speakers, refer to “Analog Audio” on page 48.
Audio Output from Analog Out (7.1ch Jacks)
“Blu-ray Disc Audio” setting A “Primary Audio Only” “Mix Audio Output”
Media
ª
BD-video
DVD-video
DTS-CD DTS® Multi PCM
AVCHD
DivX®
Audio CD PCM 2ch PCM
MP3 MP3 2ch PCM
Windows Media™ Audio WMA 2ch PCM
DLNA Video
DLNA Music MP3 / WMA / LPCM 2ch PCM
Netflix WMA 2ch PCM
CinemaNow AAC 2ch PCM
Blockbuster AAC 2ch PCM
vTuner MP3 / WMA 2ch PCM
*1)
Full decoded.
*2)
Only the independent substream is decoded.
*3)
Dolby TrueHD stream is decoded.
*4)
Only the Dolby Digital substream is decoded.
*5)
Only the core substream is decoded.
Audio Source
ª
Dolby Digital Multi PCM Multi PCM
Dolby Digital Plus Multi PCM
Dolby TrueHD Multi PCM
DTS® Multi PCM Multi PCM
DTS-HD® Multi PCM
LPCM Multi PCM Multi PCM
Dolby Digital Multi PCM
DTS® Multi PCM
LPCM 2ch PCM
Dolby Digital Multi PCM
LPCM Multi PCM
Dolby Digital Multi PCM
MP3 / MP2 2ch PCM
Dolby Digital Multi PCM
MP2 2ch PCM
LPCM 2ch PCM
LAN
Wireless LAN
this unit
SBL
CSL
FL
SBR
SW
SR
PR/CR
Y
L
HDMI OUT
PB/CB
R
AUDIO
VIDEO
COMPONENT
COAXIAL
DIGITAL OUT
VIDEO OUT
PCM/BITSTREAM
OUT
OUT
*1
*3
*1
FR
7.1ch AUDIO OUT
Multi PCM
Multi PCM
Multi PCM
*2
*4
*5
FR SW SR
7.1 ch AUDIO OUT
SBL
SLCFL
SBR
20
EN
CONNECTIONS
HDMI Audio Connection
AV receiver / amplifier with an HDMI input jack
AUDIO
OUT
Y
L
R
VIDEO
OUT
this unit
PR/CR
PB/CB
COMPONENT
VIDEO OUT
audio
HDMI IN
HDMI cable
HDMI OUT
LAN
Wireless LAN
HDMI OUT
COAXIAL
DIGITAL OUT
PCM/BITSTREAM
To set up “HDMI Audio”, refer to page 53.
Supplied cables used in these connections are as follows:
• RCA audio cable (L/R) x 1
Please purchase the rest of the necessary cables at your local store.
Connection to the Network
By connecting this unit to the Internet, you can upgrade the software via the Internet, play contents stored on DLNA
home media servers or access BD-Live, Netflix, CinemaNow, Blockbuster and vTuner services.
- For more information about software upgrade, refer to “Network Upgrade” on page 63.
- For more information about DLNA, refer to “Playing Video / Music / Photo Files from DLNA Certified Home Media
Servers” on page 31.
- For more information about BD-Live, refer to “Enjoying BD-Live Discs with Internet” on page 36.
- For more information about Netflix, refer to “NETFLIX OPERATIONS” on page 40.
- For more information about CinemaNow and Blockbuster, refer to “CINEMANOW / BLOCKBUSTER OPERATIONS” on
page 41.
- For more information about vTuner, refer to “ENJOYING INTERNET RADIO WITH vTuner” on page 43.
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
Note
• Wired connection is recommended when using following features.
(Using following features with wireless connection can be affected by other devices using radio frequencies.)
- Play contents from DLNA certified home media servers
- Video streaming services (Netflix, CinemaNow and Blockbuster)
- Internet radio service (vTuner)
-Network upgrade
Wired Connection
Make the following connection if you are using a wired router.
Hub or wired routerADSL / cable modem
WAN LAN
LAN cable
this unit
SBL
SLCFL
SBR
FR SW SR
7.1 ch AUDIO OUT
Internet
LAN
LAN cable
LAN
HDMI OUT
Wireless LAN
LAN
PR/CR
Y
L
PB/CB
R
AUDIO
VIDEO
COMPONENT
COAXIAL
DIGITAL OUT
VIDEO OUT
OUT
OUT
PCM/BITSTREAM
12345
No supplied cables are used in this connection:
Please purchase the necessary cables at your local store.
EN
21
CONNECTIONS
Note
• After you made a wired connection, set up necessary network settings.
(For the network setting of wired connection, refer to “Enable (Wired)” on page 58.)
• Do not insert any cable other than a LAN cable to the LAN terminal to avoid damaging the unit.
• If your modem does not have router functions, connect a wired router.
• If your modem has router functions but there is no vacant port, use a hub.
• For a wired router, use a router which supports 10BASE-T / 100BASE-TX.
• Do not connect your PC directly to the LAN terminal of this unit.
• Please purchase shielded LAN cables at your local store and use them when you connect to network equipment.
Wireless Connection
Make the following connection if you are using a wireless router.
FR SW SR
7.1 ch AUDIO OUT
this unit
SBL
SLCFL
SBR
ADSL / cable modem
LAN
Wireless LAN
HDMI OUT
COAXIAL
Wireless LAN
PR/CR
Y
L
PB/CB
R
AUDIO
VIDEO
COMPONENT
DIGITAL OUT
VIDEO OUT
PCM/BITSTREAM
OUT
OUT
USB wireless LAN adapter
Internet
LAN WAN
Wireless router
LAN cable
No supplied cables are used in this connection:
Please purchase the necessary cables at your local store.
Note
• After you made the wireless connection, set up necessary network settings.
(For the network setting of wireless connection, refer to “Enable (Wireless)” on page 61.)
• This unit is compatible with the supplied USB wireless LAN Adapter only.
(Commercially available USB wireless adapters are not supported.)
• Do not insert the supplied USB wireless LAN adaptor when the unit is turned on.
Please insert the USB wireless adaptor when the unit is in the standby mode or turned off.
• Do not insert any device other than the supplied USB wireless LAN adapter to the Wireless LAN terminal to avoid
damaging the unit.
• For a wireless router, use a router which supports IEEE 802.11 b/g/n.
(n is recommended for stable operation of the wireless network.)
• Set the wireless router to Infrastructure mode. This unit does not support Ad-hoc mode.
• Other radio devices or obstacles may cause interference to the wireless network connection.
• Do not insert USB flash memory in the Wireless LAN terminal. This unit is not designed to play back data from USB
flash memory.
22
EN
BEFORE YOU START
SD Card
k
After you have completed all the connections, you must find the viewing channel (external input channel) on your TV.
Finding the Viewing Channel on Your TV
1
2
3
After you have made all the necessary
connections, press [Q (standby/on)] to
turn on the unit.
Turn on your TV.
Press the button on the TV’s remote
control that accesses the external input
channel. It may be labeled “SOURCE”,
“AV” or “SELECT” (refer to your TV’s
user manual). Or press “2” on the TV’s
remote control, then press channel
down button repeatedly until you see
the PHILIPS splash screen.
EN
Introduction Connections Basic Setup Playback OthersFunction Setup
This is the correct viewing channel (external
input channel).
• If a certain amount of time has passed since
you turned on the unit, you may see the home
menu instead of the PHILIPS splash screen.
Home menu:
Blu-ray Disc Player
Disc Tray
Settings
Product Info
Home Networ
23EN
Loading...
