Blu-ray disc / DVD player

BDP3290B

User manual

www.philips.com/support

Safety and important notice

Read and understand all instructions before you use this Blu-ray disc/ DVD player. If damage is caused by failure to follow the instructions, the warranty does not apply.

Safety

Risk of electric shock or re!

• Before you make or change any connections, make sure that all devices are disconnected from the power outlet.

• Never expose the product and accessories to rain or water. Never place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it from the power outlet immediately. Contact Philips Consumer Care to have the product checked before use.

• Never place the product and accessories near naked ames or other heat sources, including direct sunlight.

• Never insert objects into the ventilation slots or other openings on the product.

• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, re or the like.

• Disconnect the product from the power outlet before lightning storms.

• When you disconnect the power cord, always pull the plug, never the cable.

Risk of short circuit or re!

• For identication and supply ratings, see the type plate at the back or bottom of the product.

• Before you connect the product to the power outlet, ensure that the power voltage matches the value printed on the back or bottom of the product. Never connect the product to the power outlet if the voltage is dierent.

Risk of injury or damage to the product!

• For wall mounting, this product must be securely attached to the wall in accordance with the installation instructions. Use only the supplied wall mount bracket (if available). Improper wall mounting may result in accident, injury or damage. If you have any query, contact Consumer Care in your country.

• Visible and invisible laser radiation when open. Avoid exposure to beam.

• Do not touch the disc optical lens inside the disc compartment.

• Never place the product or any objects on power cords or on other electrical equipment.

• If the product is transported in temperatures below 5°C, unpack the product and wait until its temperature matches room temperature before connecting it to the power outlet.

Risk of overheating!

• Never install this product in a conned space. Always leave a space of at least four inches around the product for ventilation. Make sure that curtains or other objects never cover the ventilation slots on the product.

Risk of contamination!

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Danger of explosion if batteries are incorrectly replaced. Replace only with the same or equivalent type.

• Remove batteries if they are exhausted or if the remote control is not to be used for a long time.

• Batteries contain chemical substances, they should be disposed of properly.

Risk of swallowing batteries!

• The product/remote control may contain a coin/button type battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion.

• If you suspect that a battery has been swallowed or placed inside any part of the body, seek immediate medical attention.

• When you change the batteries, always keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery.

• If the battery compartment cannot be completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer.

This is CLASS II apparatus with double insulation, and no protective earth provided.

Use only the power supplies listed in the user manual.

CLASS 1

LASER PRODUCT

3D health warning

• If you or your family has a history of

epilepsy or photosensitive seizures, consult a medical professional before exposing yourself to ashing light sources, rapid image sequences or 3D viewing.

• To avoid discomfort such as dizziness, headache or disorientation, we recommend not watching 3D for extended periods of time. If you experience any discomfort, stop watching 3D and do not immediately engage in any potentially hazardous activity (for example driving a car) until your symptoms have disappeared. If symptoms persist, do not resume watching 3D without consulting a medical professional rst.

• Parents should monitor their children during 3D viewing and ensure they do not experience any discomfort as mentioned above. Watching 3D is not recommended for children under 6 years of age as their visual system is not fully developed yet.

Care for your product

• Do not insert any objects other than

discs into the disc compartment.

• Do not insert warped or cracked discs into the disc compartment.

• Remove discs from the disc compartment if you are not using the product for an extended period of time.

• Only use microber cloth to clean the product.

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

This symbol on a product means that the product is covered by European Directive 2012/19/EU.

This symbol means that the product contains batteries covered by European Directive 2013/56/EU which cannot be disposed of with normal household waste. Inform yourself about the local separate collection system for electrical and electronic products and batteries. Follow local rules and never dispose of the product and batteries with normal household waste. Correct disposal

of old products and batteries helps prevent negative consequences for the environment and human health.

Removing the disposable batteries

To remove the disposable batteries, see battery installation section.

Compliance

This product complies with the radio interference requirements of the European Community.

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2013 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Cinavia notice

This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced lm and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA.

Open source software

Philips Electronics Hong Kong hereby oers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source software packages used in this product for which such delivery is requested by the respective licenses. This oer is valid up to three years after product purchase to anyone in receipt of this information. To obtain source code, please send your request in English with product type to open.source@philips.com. If you prefer not to use email or if you do not receive conrmation receipt within 2 weeks after mailing to this email address, please write in English to “Open Source Team, Philips Intellectual Property & Standards, P.O. Box 220, 5600 AE Eindhoven, The Netherlands”. If you do not receive timely conrmation of your letter, please email to the email address above. The texts of the licenses

and acknowledgements for open source software used in this product are included in the printed user manual.

BDP32

0 B

HDMI OUT

Blu-ray disc /

Проигрыватель

DVD player Blu-ray/DVD

BDP3290B BDP3290B

Зарегистрируйте свое устройство и получите поддержку на

www.philips.com/support

x 2

Руководство пользователя

Посібник користувача

Қолданушының нұсқасы

SOURCE

USB

BD BD 3D DVD/VCD/CD

DivX Plus HD/MK MP3 / JPEG

31 mm

4~4.5 mm

8-9 mm

>25 mm

3.5-4 mm

Contents

1 Use your Blu-ray disc/ DVD

player 2

Basic play control 2 “Smile” light indication 3 Video, audio and picture options 3 DivX videos 4 Play a musical slideshow 5 Auto play 5 BonusView on Blu-ray 6 BD-Live on Blu-ray 6 Play a Blu-ray 3D video 6 Set up a network 7 Use Philips EasyLink 7

2 Change settings 8

Picture 8 Sound 8 Network (installation, status...) 8 Preference (languages, parental

control...) 9

Advanced options (clear memory...) 9

3 Update software 10

Update software via USB 10

4 Optional placement 11

Vertical placement 11 Wall mount 11

5 Product specications 12

6 Trouble shooting 15

1EN

1 Use your Blu-

ray disc/ DVD player

Congratulations on your purchase, and welcome to Philips! To fully benet from the support that Philips oers (e.g. product software upgrade), register your product at www.philips.com/welcome.

Basic play control

2 EN

During play, press the following buttons to control.

Button Action

Turn on the player, or switch to standby.

Access the home menu.

Button Action

DISC MENU Access or exit the disc

menu or Pop-up menu.

TOP MENU Access the main menu

of a video disc.

Navigate the menus.

Press to rotate a picture clockwise or counter-clockwise during slideshow.

OK Conrm a selection or

entry. Return to a previous

display menu. Access more options

during play.

Color buttons Select tasks or options

for Blu-ray discs. Eject a disc from the

disc compartment. Start or resume play. Pause play.

Press repeatedly to slow forward frame by frame.

Stop play.

/ Skip to the previous or

next track, chapter or le.

/ Fast backward or

forward. Press repeatedly to change the search speed. Press once, and then press to slow forward.

AUDIO Select an audio

language or channel.

SUBTITLE Select a subtitle

language.

Alphanumeric buttons

Select an item to play. Enter values. Enter letters via SMS style entry.

“Smile” light indication

This product is designed with an animated light strip to form an expression of this product’s current status.

• Light o: standby.

• Light on: power on and ready.

• Light dim: playback in progress.

• 2 lights ashing: Error or unable to

read disc.

• Other light animation: Like starting up, loading disc, pause, stop, skip to next/previous, forward/backward play, and ejecting disc.

Video, audio and picture options

More options are available for video or picture play from a disc or USB storage device.

Video options

Access more options during video play.

• [Audio language]: Select an audio language.

• [Subtitle language]: Select a subtitle language.

• [Subtitle shift]: Change the subtitle position on the screen. Press to change the subtitle position.

• [Info]: Display play information.

3EN

• [Character set]: Select a character set that supports the DivX video subtitle (only for DivX videos).

• [Time search]: Skip to a specic time via the numeric buttons on the remote control.

• [2nd audio language]: Select the second audio language (only for Blu-ray discs that support BonusView).

• [2nd subtitle language]: Select the second subtitle language (only for Blu-ray discs that support BonusView).

• [Titles]: Select a title.

• [Chapters]: Select a chapter.

• [Angle list]: Select a camera angle.

• [Menus]: Display a disc menu.

• [PIP selection]: Display a picture-

in-picture window (only for Blu-ray discs that support BonusView).

• [Zoom]: Zoom into a video picture. Press to select a zoom factor.

• [Repeat]: Repeat a chapter or title.

• [Repeat A-B]: Mark two points

within a chapter for repeat play, or turn o repeat mode.

• [Picture settings]: Select a predened color setting.

Note

• Available video options depend on the

video source.

Access more options during slideshow.

• [Rotate +90]: Rotate a picture 90 degrees clockwise.

• [Rotate -90]: Rotate a picture 90 degrees counter-clockwise.

• [Zoom]: Zoom into a picture. Press to select a zoom factor.

• [Info]: Display picture information.

• [Duration per slide]: Set a display

interval for a slideshow.

• [Slide animation]: Select a transition eect for a slideshow.

• [Picture settings]: Select a predened color setting.

• [Repeat]: Repeat a selected folder.

Audio options

Press repeatedly to cycle through the following options.

• Repeat the current track.

• Repeat all the tracks on the disc or

folder.

• Play audio tracks in a random loop.

• Turn o a repeat mode.

Picture options

4 EN

DivX videos

You can play DivX videos from a disc or a USB storage device.

VOD code for DivX

• Before you purchase DivX videos and play them on this player, register this player on www.divx.com using the DivX VOD code.

• Display the DivX VOD code: press , and select [Setup] > [Advanced] >

[DivX® VOD Code].

DivX subtitles

• Press SUBTITLE to select a language.

• If the subtitle is not displayed correctly, change the character set that supports the DivX subtitle. Select a character set: press , and select [Character set].

Character set

[Standard] English, Albanian,

[Central Europe]

[Cyrillic] Bulgarian, Belorussian,

[Greek] Greek [Baltic] Estonian, Latvian and

[Chinese] Simplied Chinese [Chinese-

Traditional] [Korean] English and Korean

Languages

Danish, Dutch, Finnish, French, Gaelic, German, Italian, Kurdish (Latin), Norwegian, Portuguese, Spanish, Swedish, and Turkish

Albanian, Croat, Czech, Dutch, English, German, Hungarian, Irish, Polish, Romanian, Slovak, Slovene, and Serbian

English, Macedonian, Moldavian, Russian, Serbian, and Ukrainian

Lithuanian

Traditional Chinese

Note

• To use the subtitles, make sure that the

subtitle le has the same name as the DivX video le name. For example, if the DivX video le is named “movie.avi", save the subtitle le as “movie.srt”, or “movie.sub”.

• This player can play subtitle les in the

following formats: .srt, .sub, .txt, .ssa, and .smi.

Play a musical slideshow

Play music and pictures simultaneously to create a musical slideshow.

1 From a disc or connected USB

storage device, play a music le.

2 Press , and go to the picture

folder.

3 Select a picture from the same

disc or USB, and press OK to start slideshow.

4 Press to stop slideshow. 5 Press again to stop music play.

Auto play

This player can automatically play a disc or a video le.

Auto play disc

When this player is switched on, the disc automatically plays.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Preference] > [Auto play

disc]> [On].

• The feature is turned on.

• To turn o the feature,

select [O]. The disc will not automatically play.

5EN

Auto play video sequentially

If two or more video les are available in the same folder from a USB storage device, the next video le automatically plays after the end of a video.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Preference] > [Auto play

after video]> [On].

• The feature is turned on.

• To turn o the feature, select

[O]. The next video le will not automatically play after the end of a video in the same folder.

BonusView on Blu-ray

View special content (such as commentaries) in a small screen window. This feature is only applicable to Blu-ray discs compatible with BonusView (also known as picture in picture).

1 During play, press .

» The options menu is displayed.

2 Select [PIP selection] > [PIP], and

press OK.

» PIP options [1]/[2] depend on

the video contents.

» The secondary video window is

displayed.

3 Select [2nd audio language] or [2nd

subtitle language], and press OK.

This feature is only applicable to Blu-ray discs that are BD-Live enabled.

1 Prepare the Internet connection

and set up a network (see "Set up a network").

2 Connect a USB storage device to

the (USB) connector on this player.

• A USB storage device is used to store the downloaded BD-Live content.

• To delete the BD-Live previously downloaded on the USB storage device for memory release, press and select [Setup] >

[Advanced] > [Clear memory].

3 Play a disc that is BD-Live enabled. 4 On the disc menu, select the BD-

Live icon, and press OK.

» BD-Live starts to load. The

loading time depends on the disc and the Internet connection.

5 On the BD-Live interface, select an

item to access.

Note

• BD-Live services vary from discs and

countries.

• When you use BD-Live, data on the disc

and this player are accessed by the content provider

• Use a USB storage device with at least 1GB

of free space to store the download.

Play a Blu-ray 3D video

BD-Live on Blu-ray

Access exclusive online services, such as movie trailers, games, ringtones and other bonus contents.

6 EN

What you need

• A 3D compliant TV

• This player is connected to the TV

through HDMI

• 3D glasses compatible with the TV

• 3D Blu-ray disc

1 Make sure that 3D output is turned

on: press , and select [Setup] > [Video] >[Watch 3D video] > [Auto].

2 Play a Blu-ray 3D video. 3 Put on the 3D glasses for 3D eects.

• To turn o 3D output, press , and select [Setup] > [Video] >

[Watch 3D video] > [O].

Caution

• Before you connect to a network,

familiarize yourself with the network router and networking principles. If necessary, read documentation accompanying network components. Philips is not responsible for lost, damaged, or corrupt data.

Set up a network

Connect this player to the Internet to access the following service:

• BD-Live: access online bonus features (applicable to Blu-ray discs that are BD-Live enabled).

1 Connect this player to the

Internet through wired (Ethernet) connection.

• Connect a network cable (not

supplied) to the LAN port on the back panel of this player.

2 Perform the network installation.

1) Press .

2) Select [Setup], and press OK.

3) Select [Network] > [Network installation], and press OK.

4) Follow the instructions on the TV

screen to complete the installation.

Use Philips EasyLink

This player supports Philips EasyLink which uses the HDMI CEC (Consumer Electronics Control) protocol. You can use a single remote control to control EasyLink compliant devices that are connected through HDMI. Philips does not guarantee 100% interoperability with all HDMI CEC devices.

1 Connect the HDMI CEC compliant

devices through HDMI, and turn on the HDMI CEC operations on the TV and other connected devices (see the user manual of the TV or other devices for details).

2 Press . 3 Select [Setup]> [EasyLink]. 4 Select [On] under the options:

[EasyLink], [One Touch Play] and [One Touch Standby].

» EasyLink function is turned on.

One Touch Play

When a video disc is in the disc compartment, press to wake up the TV from standby, and then play a disc.

One Touch Standby

When a connected device (for example TV) is put to standby with its own remote control, this player is put to standby automatically.

7EN

2 Change

settings

This section helps you change the settings of this player.

• [Watch 3D video]: Set to 3D or 2D output when playing a Blu-ray 3D disc. The player must be connected to a 3D TV through HDMI.

Note

• If you change a setting, make sure that the

TV supports the new setting.

2 3

TV display

HDMI video

Picture settings

Watch 3D video

16:9 Widescreen

Note

• You cannot change a menu option that is

grayed out.

• To return to the previous menu, press .

To exit the menu, press .


1 Press . 2 Select [Setup] > [Video] to access

the video setup options.

• [TV display]: Select a picture display format to t the TV screen.

• [HDMI video]: Select an HDMI video resolution.

• [HDMI Deep Color]: Display colors with more shades and hues when the video content is recorded in Deep Color and the TV supports this feature.

• [Picture settings]: Select a predened color setting.

Sound

1 Press . 2 Select [Setup] > [Audio] to access

the audio setup options.

• [Night mode]: Select quiet or full dynamic sound. Night mode decreases the volume of loud sound and increases the volume of soft sound (such as speech).

• [HDMI audio]: Set an HDMI audio format when this player is connected through HDMI.

Note

• Night mode is only available for Dolby

TrueHD / Dolby® Digital Plus encoded DVD and Blu-ray discs.

Network (installation, status...)

1 Press . 2 Select [Setup] > [Network] to access

the network setup options.

• [Network installation]: Start a wired installation to make the network work.

• [View network settings]: Display the current network status.

8 EN

Preference (languages, parental control...)

1 Press . 2 Select [Setup] > [Preference]

to access the preference setup options.

• [Menu language]: Select an onscreen display menu language.

• [Audio]: Select an audio language for video.

• [Subtitle]: Select a subtitle language for video.

• [Disc menu]: Select a menu language for a video disc.

• [Parental control]: Restrict access to discs that are encoded with ratings. Input "0000" to access the restriction options. To play all discs irrespective of the rating, select level "8".

• [Screen saver]: Enable or disable screen saver mode. If enabled, the screen enters idle mode after 10 minutes of inactivity (for example, in pause or stop mode).

• [Auto subtitle shift]: Enable or disable subtitle shift. If enabled, the subtitle position is changed automatically to t the TV screen (this feature works with some Philips TVs only).

• [Change password]: Set or change a password to play a restricted disc. Input "0000" if you do not have a password or if you have forgotten your password.

• [Auto standby]: Enable or disable auto standby. If enabled, the player switches to standby after 18 minutes of inactivity (for example, in pause or stop mode).

• [Fast wake up]: Enable or disable the player to wake up faster from standby. If fast wakeup is turned

o, less power is consumed during standby.

• [VCD PBC]: Display or skip the content menu for VCD and SVCD.

• [Auto play disc]: Enable or disable the automatic disc playback after power on.

• [Auto play after video]: Enable or disable sequential playback of videos from USB.

Note

• If your preferred language is not available

for disc language, audio or subtitle, you can select [Other] from the menu options and input 4-digit language code which can be found at the back of this user manual.

• If you select a language which is not

available on a disc, this player uses the default language of the disc.

Advanced options (clear memory...)

1 Press . 2 Select [Setup] > [Advanced] to

access the advanced setup options.

• [BD-Live security]: Restrict or allow access to BD-Live (only for noncommercial, user-created BD-Live discs).

• [Downmix mode]: Control 2-channel stereo audio output.

• [Software update]: Update software through a USB storage device.

• [Clear memory]: Delete the previous BD-Live download on the USB storage device. A "BUDA" folder is automatically created to store the BD-Live download.

• [DivX® VOD Code]: Display the DivX® registration code or the deregistration code for this player.

9EN

• [Version information]: Display the software version of this player.

• [Restore default settings]: Reset this player to the default settings made at the factory, except for password and parental control level.

Note

• You cannot restrict Internet access on

commercial Blu-ray discs.

• Before you purchase DivX videos and play

them on this player, register this player on www.divx.com with the DivX VOD code.

3 Update

software

Before you update the software of this player, check the current software version:

• Press , and then select [Setup] > [Advanced] > [Version information], and press OK.

Update software via USB

1 Check the latest software version on

www.philips.com/support.

• Search for your model and click

on "Software and drivers".

2 Download the software into a USB

storage device.

a Unzip the download, and make

sure that the unzipped folder is named "UPG".

b Put the "UPG" folder in the root

directory.

10 EN

3 Connect the USB storage device

to the (USB) connector on this player.

4 Press , and select [Setup]. 5 Select [Advanced] > [Software

update]> [USB].

» If an upgrade media is detected,

you are prompted to start the update.

6 Follow the instructions on the TV

screen to update the software.

» When the update is complete,

this player automatically turns o and on again.

Caution

• Do not turn o the power or remove the

USB storage device when the software update is in progress because you might damage this player.

4 Optional

placement

The design of this product allows you to place this product in the following ways:

• Horizontal placement on the tabletop.

• Vertical placement on the tabletop.

• Wall mount

You may simply place this product horizontally on the tabletop.

Vertical placement

You may place this product vertically on the tabletop. See the section of the quick start guide in this user manual for placement illustration.

1) Assemble the supplied brackets.

2) Fix the assembled bracket to this

product.

Wall mount

Note

• Before wall mounting, make sure the wall

can support the weight of this product.

• For wall mounting, this product must be

securely attached to the wall in accordance with the installation instructions. Improper wall mounting may result in accident, injury or damage. If you have any query, contact Consumer Care in your country.

You may mount this product on the wall. See the section of the quick start guide in this user manual for placement illustration.

1) Fix the supplied bracket to this

prodcut.

11EN

2) Drill two holes on the wall, then secure the dowels and screws in the holes.

3) Hang this product on the wall.

5 Product

specifications

Note

• Specications and design are subject to

change without notice.

Region code

This player can play discs with the following region codes.

DVD Blu-ray Countries

Russia, India

Media formats

• BD-Video, BD 3D

• DVD-Video, DVD+R/+RW,

DVD-R/-RW, DVD+R/-R DL (Dual Layer)

• VCD/SVCD

• Audio CD, CD-R/CD-RW,

MP3 media, WMA media, JPEG les

• DivX (Ultra)/DivX Plus HD media, MKV media

• USB storage device

File formats

• Audio:

• .aac, .mka, .mp3, .wma, .wav,

.m4a, .ac, .ogg

• Video:

• .avi, .divx, .mp4, .m4v, .ts, .mov,

.mkv, .m2ts, .mpg, .mpeg, .3gp

• Picture: .jpg, .jpeg, .gif, .png

12 EN

Audio formats

This product supports the following audio les.

Extension

.mp3 MP3 MP3 Up to

.wma ASF WMA Up to

.aac AAC AAC, HE-

.wav WAV PCM 27.648 Mbps .m4a MKV AAC 192 kbps

.mka MKA PCM 27.648 Mbps AC-3 640kbps DTS core 1.54 Mbps MPEG 912 kbps MP3 Up to

WMA Up to

AAC, HE-

.ac FLAC FLAC Up to 24 bit

.ogg OGG Vorbis Variable

MP3 Upto

Container

Audio codec

Bit rate

320 kbps

192 kbps Up to

AAC

192 kbps

ALAC Up to 192kHz

sampling rate

320 kbps

192 kbps Up to

AAC

192 kbps

per sample

bit rate, maximum block size 4096

FLAC Up to 192kHz

sampling rate

OGGPCM No limitation

320 kbps

Video formats

If you have a high denition TV, this product allows you to play your video les with:

• Resolution: 1920 x 1080 pixels at

• Frame rate: 6 ~ 30 frames per

second.

.avi les in AVI container (or .ts les in TS container)

Audio codec Video codec Bit rate

PCM, AC-3, DTS core, MP3, WMA, DD+

MPEG 1,

MPEG 4 SP

H.264/

WMV9 45 Mbps

.divx les in AVI container

Audio codec

PCM, AC-3, DTS core, MP3, WMA, DD+

.mp4 or .m4v les in MP4 container

Audio codec Video codec Bit rate

AC-3, MPEG, MP3, AAC, HE-AAC, DD+

DivX 3.11, DivX 4.x,

10 Mbps

max DivX 5.x, DivX 6.x

40 Mbps MPEG 2

38.4 Mbps

/ ASP

25 Mbps AVC up to HiP@5.1

Video codec Bit rate

DivX 3.11, DivX 4.x,

10 Mbps

max DivX 5.x, DivX 6.x

MPEG 1,

40 Mbps MPEG 2

MPEG

38.4 Mbps

4 ASP H.264/

25 Mbps AVC up to HiP@5.1

13EN

.mov les in MOV container

Audio codec Video codec Bit rate

AC-3, MPEG, MP3, AAC, HE-AAC

.mkv les in MKV container

Audio codec Video codec Bit rate

PCM, AC-3, DTS core, MPEG, MP3, WMA, AAC, HEAAC, DD+, FLAC

.m2ts les in MKV container

Audio codec Video codec Bit rate

PCM, AC-3, DTS core, MPEG, MP3, WMA, AAC, HEAAC, DD+

MPEG 1, MPEG 2

MPEG 4 ASP

H.264/ AVC up to HiP@5.1

DivX Plus HD30 Mbps

MPEG 1, MPEG 2

MPEG 4 ASP

H.264/ AVC up to HiP@5.1

WMV9 45 Mbps

MPEG 1, MPEG 2

MPEG 4 ASP

H.264/ AVC up to HiP@5.1

40 Mbps

38.4 Mbps

25 Mbps

40 Mbps

38.4 Mbps

25 Mbps

40 Mbps

38.4 Mbps

25 Mbps

Audio codec Video codec Bit rate

WMV9 45 Mbps

.mpg and .mpeg les in PS container

Audio codec Video codec Bit rate

PCM, DTS core, MPEG, MP3

.3gp les in 3GP container

Audio codec Video codec Bit rate

AAC, HEAAC

H.264/

MPEG 1, MPEG 2

MPEG 4 ASP

AVC up to HiP@5.1

40 Mbps

38.4 Mbps

25 Mbps

max

Video

• Signal system: PAL / NTSC

• HDMI output: 480i/576i,

480p/576p, 720p, 1080i, 1080p, 1080p/24Hz

Audio

• HDMI output

• Sampling frequency:

• MP3: 32 kHz, 44.1 kHz, 48 kHz

• WMA: 44.1 kHz, 48 kHz

• Constant bit rate:

• MP3: 112 kbps - 320 kpbs

• WMA: 48 kpbs - 192 kpbs

USB

• Compatibility: Hi-Speed USB (2.0)

• Class support: USB Mass Storage

Class

• File system: FAT16, FAT32

• USB port: 5V , 500mA

• Support HDD (a portable hard disc

drive): an external power source may be needed.

Main unit

• Power supply:

• Model (Philips branded AC power adapter): NU010A120080

• Input: 100-240 V~, 50/60 Hz

0.2 A

• Output: 12 V , 0.8 A

• Power consumption in standby

mode: < 0.5 W

• Dimensions (w x h x d): 210 x 52.5 x 210 (mm)

• Net Weight: 0.75 kg

Operating Temperature & Humidity

• 0°C to 45°C, 5% to 90% Humidity for all climates.

Storage Temperature & Humidity

• -40 °C to 70 °C, 5% to 95%

Accessories

• Remote control and batteries

• User manual

• 2 brackets and 2 screws

• AC power adapter

Laser

• Laser Type (Diode): AlGaInN (BD),

AlGaInP (DVD/CD)

• Wave length: 398nm to 413nm (BD), 645nm to 664nm (DVD), 770nm to 800nm(CD)

• Output power: 1.7mW (BD),

0.19mW(DVD), 0.25mW (CD)

Standby information

• When the product remains inactive

for 18 minutes, it automatically switches to standby or networked standby.

• The power consumption in standby or networked standby is less than

0. 5 W.

6 Trouble-

shooting

Warning

• Risk of electric shock. Never remove the

casing of the player.

To keep the warranty valid, never try to repair the player yourself. If you have problems using this player, check the following points before you request service. If you still have a problem, register your player and get support at www.philips.com/support. If you contact Philips, you will be asked for the model and serial number of this player. The model number and serial number are on the back of this player. Write the numbers here: Model No. _______________________ Serial No. ________________________

Main unit

The buttons on this player do not work.

• Disconnect this player from the power supply for a few minutes, and then reconnect.


No picture.

• Make sure that the TV is switched to the correct source input for this player.

No picture on HDMI connection.

• Make sure that the HDMI cable is not faulty. If it is faulty, replace with a new HDMI cable.

• On the remote control, press and then press “731” (numeric buttons) to recover picture display. Or wait for 10 seconds for auto recovery.

• If this player is connected to an unauthorized display device with an HDMI cable, the audio and video signals may not be output.

The disc does not play high-denition video.

• Make sure that the disc contains high-denition video.

• Make sure that the TV supports high-denition video.

Sound

No sound on HDMI connection.

• You may not hear any sound from the HDMI output if the connected device is non-HDCP compliant or only DVI-compatible.

No secondary audio output for Picturein-Picture feature.

• When [Bitstream] under the [HDMI audio] menu is selected, interactive

sound like secondary sound for Picture-in-Picture feature is muted. De-select [Bitstream].

Play

Cannot play a disc.

• Clean the disc.

• Make sure that the disc is correctly

loaded.

• Make sure that this player supports the disc. See "Specications".

• Make sure that this player supports the region code of the DVD or BD.

• For DVD±RW or DVD±R, make sure that the disc is nalized.

Cannot play DivX video les.

• Make sure that the DivX video le is

complete.

• Make sure that the video le name

extension is correct.

DivX subtitles do not display correctly.

• Make sure that the subtitle le has

the same name as the DivX video le.

• Make sure that the subtitle le has

an extension name supported by this player (.srt, .sub, .txt, .ssa, or .smi).

Cannot read the contents of a connected USB storage.

• Make sure that the format of the

USB storage device is compatible with this player.

• Make sure that the le system on

the USB storage device is supported by this player.

• For a USB HDD (a portable hard

disc drive), an external power source may be needed.

'No entry' or 'x' sign is displayed on the TV.

• The operation is not possible.

EasyLink feature does not work.

• Make sure that this player is connected to the Philips brand EasyLink TV, and the EasyLink option is turned on (see "Use your Blu-ray disc/ DVD player" > "Use Philips EasyLink").

Cannot access BD-Live features.

• Make sure that this player is connected to the network (see "Use your Blu-ray disc/ DVD player" > "Set up a network").

• Make sure that the network installation is made (see "Use your Blu-ray disc/ DVD player" > "Set up a network").

• Make sure that the Blu-ray disc supports BD-Live features.

• Clear memory storage (see "Change settings" > "Advanced options (BDLive security, clear memory...)").

Network

Network is not found or distorted.

• Make sure that the network is correctly connected (see "Use your Blu-ray disc/ DVD player" > "Set up a network").

• Make sure that the network installation is made (see "Use your Blu-ray disc/ DVD player" > "Set up a network").

• Check the router connection (refer to the user manual for the router).

Internet speed is slow.

• You need a high speed Internet connection for your router.

3D videos

Cannot see 3D eects

• Make sure that 3D output is turned on(see "Use your Blu-ray disc/ DVD player" > "Play a Blu-ray 3D video").

• Make sure that the disc title being played is Blu-ray 3D compliant.

• Make sure that the TV is 3D and HDMI compliant, and the TV is set to 3D mode (refer to the TV's user manual).

• Make sure that the 3D glasses are activated (refer to the TV’s user manual).

"Blu-ray 3D " and "Blu-ray 3D " logo are trademarks of Blu-ray Disc Association.

HDMI, and HDMI logo and HighDenition Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC in the United States and other countries.

Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

This DivX Certied device has passed rigorous testing to ensure it plays DivX video. To Play purchased DivX movies, rst register your device at vod.divx.com.

Find your registration code in the DivX VOD section of your device setup menu. DivX Certied to play DivX and DivX Plus HD (H.264/MKV) video up to 1080p HD, including premium content. DivX , DivX Certied , DivX Plus HD and associated logos are trademarks of

DivX, LLC and are used under license.

For DTS patents,see http://patents. dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS

BONUSVIEW™

'BD LIVE ' and 'BONUSVIEW ' are trademarks of Blu-ray Disc Association.

'DVD Video' is a trademark of DVD Format/Logo Licensing Corporation.

Oracle and Java are registered trademarks of Oracle and/or its aliates. Other names may be trademarks of their respective owners.

Abkhazian 6566

Language Code

Afar 6565 Afrikaans 6570 Amharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Avestan 6569 Aymara 6589 Azerhaijani 6590 Bahasa Melayu 7783 Bashkir 6665 Belarusian 6669 Bengali 6678 Bihari 6672 Bislama 6673 Bokmål, Norwegian 7866 Bosanski 6683 Brezhoneg 6682 Bulgarian 6671 Burmese 7789 Castellano, Español 6983 Catalán 6765 Chamorro 6772 Chechen 6769

Chewa; Chichewa; Nyanja

9072 Chuang; Zhuang 9065 Church Slavic; Slavonic 6785 Chuvash 6786 Corsican 6779 Česky 6783 Dansk 6865 Deutsch 6869 Dzongkha 6890 English 6978 Esperanto 6979 Estonian 6984 Euskara 6985

Faroese 7079 Français 7082 Frysk 7089 Fijian 7074 Gaelic; Scottish Gaelic 7168 Gallegan 7176 Georgian 7565 Gikuyu; Kikuyu 7573 Guarani 7178 Gujarati 7185 Hausa 7265 Herero 7290 Hindi 7273 Hiri Motu 7279 Hrwatski 6779 Ido 7379 Interlingua (International)7365 Interlingue 7365 Inuktitut 7385

7889

6976

Inupiaq 7375

Irish 7165 Íslenska 7383 Italiano 7384 Ivrit 7269 Japanese 7465 Javanese 7486 Kalaallisut 7576 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kernewek 7587 Khmer 7577 Kinyarwanda 8287 Kirghiz 7589 Komi 7586 Korean 7579 Kuanyama; Kwanyama 7574 Kurdish 7585 Lao 7679 Latina 7665 Latvian 7686 Letzeburgesch; 7666 Limburgan; Limburger 7673 Lingala 7678 Lithuanian 7684 Luxembourgish; 7666 Macedonian 7775 Malagasy 7771 Magyar 7285 Malayalam 7776 Maltese 7784 Manx 7186 Maori 7773 Marathi 7782 Marshallese 7772 Moldavian 7779 Mongolian 7778 Nauru 7865 Navaho; Navajo 7886 Ndebele, North 7868 Ndebele, South 7882 Ndonga 7871 Nederlands 7876 Nepali 7869 Norsk 7879 Northern Sami 8369 North Ndebele 7868 Norwegian Nynorsk; 7878 Occitan; Provencal 7967 Old Bulgarian; Old Slavonic 6785 Oriya 7982 Oromo 7977 Ossetian; Ossetic 7983 Pali 8073 Panjabi 8065 Persian 7065 Polski 8076 Português 8084

Pushto 8083 Russian 8285 Quechua 8185 Raeto-Romance 8277 Romanian 8279 Rundi 8278 Samoan 8377 Sango 8371 Sanskrit 8365 Sardinian 8367 Serbian 8382 Shona 8378 Shqip 8381 Sindhi 8368 Sinhalese 8373 Slovensky 8373 Slovenian 8376 Somali 8379 Sotho; Southern 8384 South Ndebele 7882 Sundanese 8385 Suomi 7073 Swahili 8387 Swati 8383 Svenska 8386 Tagalog 8476 Tahitian 8489 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 To nga (Tonga Islands) 8479 Tsonga 8483 Tswana 8478 Türkçe 8482 Turkmen 8475 Tw i Uighur 8571 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapuk 8679 Walloon 8765 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 8973 Yoruba 8979 Zulu 9085

8487

BDP3290B_51_UM_V1.0

Philips BDP3290B/51 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Basic play control

“Smile” light indication

Video, audio and picture options

DivX videos

Play a musical slideshow

Auto play

BonusView on Blu-ray

Play a Blu-ray 3D video

BD-Live on Blu-ray

Set up a network

Use Philips EasyLink


Sound

Network (installation, status...)

Preference (languages, parental control...)

Advanced options (clear memory...)

Update software via USB

Vertical placement

Wall mount
