Philips BDP3250-05 User Manual

www.philips.com/welcome

BDP3250

EN User manual

COAAV OUTPUT

www.philips.com/welcome

EN User manual

BDP3250

VIDE

Wi-Fi

COAXIAL AV OUTPUT

HDMIVIDEO

( )

1 HDMI

HDMI  VIDEO  COAXIAL  AV OUTPUT

2 VIDEO+AV OUTPUT

HDMI  VIDEO  COAXIAL  AV OUTPUT

OUTP

AV OUTPUT

VIDE

VIDEO

3 COAXIAL

4 AV OUTPUT

HDMI  VIDEO COAXIAL  AV OUTPUT

COAXIAL

HDMI  VIDEO  COAXIAL  AV OUTPUT

AV OUTPUT

SOURCE

BD DVD/VCD/CD DivX Plus HD/MKV MP3 / JPEG

USB

Contents

1 Hookup and play 2-7

2 Use your Blu-ray disc player 10

Basic play control 10 Video, audio and picture options 11 DivX videos 13 Play a musical slideshow 13 BonusView on Blu-ray 14 BD-Live on Blu-ray 14 Set up a network 15 Use Philips EasyLink 16

3 Change settings 17

Picture 17 Sound 18 Network (installation, status...) 18 Preference (languages, parental control...) 18 Advanced options (clear memory...) 19

4 Update software 20

Update software via the Internet 20 Update software via USB 20

5 Speciﬁcations 21

English

6 Troubleshooting 23

7 Safety and important notice 26

9EN

2 Use your Blu-ray disc player

Congratulations on your purchase, and welcome to Philips! To fully beneﬁt from the support that Philips offers (e.g. product software upgrade), register your product at www.philips.com/welcome.

Basic play control

During play, press the following buttons to control.

Button Action

AUDIO Select an audio language or channel. SUBTITLE Select a subtitle language. DISC MENU /

POP-UP MENU TOP MENU Access the main menu of a video disc. Color buttons Select tasks or options for Blu-ray discs.

OK Conﬁrm a selection or entry.

Stop play. Press and hold (more than 4 seconds) to open or close the disc compartment.

Pause play. Press repeatedly to slow forward frame by frame.

Star t or resume play.

Skip to the previous or next track, chapter or ﬁle.

Fast backward or forward. Press repeatedly to change the search speed. Press

once, and then press to slow forward.

Access or exit the disc menu.

Navigate the menus. Press counter-clockwise during slideshow.

Return to a previous display menu.

Access more options during play.

to rotate a picture clockwise or

Video, audio and picture options

More options are available for video or picture play from a disc or USB storage device.

Video options

Access more options during video play.

• [Audio Language]: Select an audio language.

• [Subtitle Language]: Select a subtitle language.

• [Subtitle Shift]: Change the subtitle position on the screen. Press

position.

• [Info]: Display play information.

• [Character Set]: Select a character set that supports the DivX video subtitle (only for DivX

videos).

• [Time Search]: Skip to a speciﬁc time via the numeric buttons on the remote control.

• [2nd Audio Language]: Select the second audio language (only for Blu-ray discs that support

BonusView).

• [2nd Subtitle Language]: Select the second subtitle language (only for Blu-ray discs that support

BonusView).

• [Titles]: Select a title.

• [Chapters]: Select a chapter.

• [Angle List]: Select a camera angle.

• [Menus]: Display a disc menu.

• [PIP Selection] : Display a picture-in-picture window.

• [Zoom] : Zoom into a video picture. Press

• [Repeat] : Repeat a chapter or title.

• [Repeat A-B] : Mark two points within a chapter for repeat play, or turn off repeat mode.

• [Picture Settings] : Select a predeﬁned color setting.

to select a zoom factor.

to change the subtitle

English

Note

Available video options depend on the video source. •

11EN

Picture options

Access more options during slideshow.

• [Rotate +90]: Rotate a picture 90 degrees clockwise.

• [Rotate -90]: Rotate a picture 90 degrees counter-clockwise.

• [Zoom]: Zoom into a picture. Press

• [Info]: Display picture information.

• [Duration per slide]: Set a display interval for a slideshow.

• [Slide Animation]: Select a transition effect for a slideshow.

• [Picture Settings]: Select a predeﬁned color setting.

• [Repeat]: Repeat a selected folder.

Audio options

to select a zoom factor.

Press repeatedly to cycle through the following options.

Repeat the current track.• Repeat all the tracks on the disc or folder.• Play audio tracks in a random loop.• Turn off a repeat mode.•

DivX videos

You can play DivX videos from a disc or a USB storage device.

VOD code for DivX

Before you purchase DivX videos and play them on this player, register this player on www.• divx.com using the DivX VOD code. Display the DivX VOD code: press •

Code].

DivX subtitles

Press • SUBTITLE to select a language. If the subtitle does not appear correctly, change the character set that supports the DivX • subtitle. Select a character set: press

Character set Languages [Standard] English, Albanian, Danish, Dutch, Finnish, French, Gaelic, German, Italian, Kurdish

(Latin), Norwegian, Portuguese, Spanish, Swedish, and Turkish

[Central Europe] Albanian, Croat, Czech, Dutch, English, German, Hungarian, Irish, Polish,

Romanian, Slovak, Slovene, and Sorbian

[Cyrillic] Bulgarian, Belorussian, English, Macedonian, Moldavian, Russian, Serbian, and

Ukrainian

[Greek] Greek

Note

To play DivX DRM protected ﬁles from a USB storage device, connect this player to a TV through HDMI. • To use the subtitles, make sure that the subtitle ﬁle has the same name as the DivX video ﬁle name. For • example, if the DivX video ﬁle is named “movie.avi”, save the subtitle ﬁle as “movie.srt”, or “movie.sub”. This player can play subtitle ﬁles in the following formats: .sr t, .sub, .tx t, .ssa, and .smi.

•

, and select [Setup] > [Advanced] > [DivX® VOD

, and select [Character Set].

English

Play a musical slideshow

Play music and pictures simultaneously to create a musical slideshow.

1 From a disc or connected USB storage device, play a music ﬁle. 2 Press , and go to the picture folder. 3 Select a picture from the same disc or USB, and press OK to star t slideshow. 4 Press to stop slideshow. 5 Press again to stop music play.

13EN

BonusView on Blu-ray

View special content (such as commentaries) in a small screen window. This feature is only applicable to Blu-ray discs compatible with BonusView (also known as picture in picture).

1 During play, press .

The options menu is displayed. »

2 Select [PIP Selection] > [PIP], and press OK.

PIP options [1]/[2] depend on the video contents. » The secondary video window is displayed. »

3 Select [2nd Audio Language] or [2nd Subtitle Language], and press OK.

BD-Live on Blu-ray

Access exclusive online services, such as movie trailers, games, ringtones and other bonus contents. This feature is only applicable to Blu-ray discs that are BD-Live enabled.

1 Prepare the Internet connection and set up a network (see “Set up a network”). 2 Connect a USB storage device to this player.

A USB storage device is used to store the downloaded BD-Live content.• To delete the BD-Live previously downloaded on the USB storage device for memory • release, press

and select [Setup] > [Advanced] > [Clear memory].

3 Play a disc that is BD-Live enabled. 4 On the disc menu, select the BD-Live icon, and press OK.

BD-Live starts to load. The loading time depends on the disc and the Internet connection. »

5 On the BD-Live inter face, select an item to access.

Note

BD- Live services vary from discs and countries. • When you use BD-Live, data on the disc and this player are accessed by the content provider • Use a USB storage device with at least 1GB of free space to store the download. •

Set up a network

Connect this player to a computer network and the Internet to access the services:

• BD-Live: access online bonus features (applicable to Blu-ray discs that are BD-Live enabled)

• Update software: update the software of this player via the Internet.

Note

For wireless connection, you need to use an optional Philips Wi- Fi USB adapter (named WUB1110). • The Wi-Fi USB Adapter (WUB1110) is not included. To purchase this adapter, visit shop.philips.com. If the • Philips online shop is not available in your country, please contact Philips customer service. For contact details, go to w ww.philips.com/support.

1 Connect this player to a computer network and the Internet, through wired (Ethernet) or

wireless connection.

For Wi-Fi, connect a Philips Wi-Fi USB adapter (named WUB1110) to the • Wi-Fi por t on the back of this player.

2 Perform the network installation.

English

1), Press .

2), Select [Setup], and press OK.

3), Select [Network] > [Network Installation], and press OK.

4), Follow the instructions on the TV screen to complete the installation.

Caution

Before you connect to a network, familiarize yourself with the network router, and networking principles. • If necessary, read documentation accompanying network components. Philips is not responsible for lost, damaged or corrupt data.

15EN

Use Philips EasyLink

This player supports Philips EasyLink which uses the HDMI CEC (Consumer Electronics Control) protocol. You can use a single remote control to control EasyLink compliant devices that are connected through HDMI. Philips does not guarantee 100% interoperability with all HDMI CEC devices.

1 Connect the HDMI CEC compliant devices through HDMI, and turn on the HDMI CEC

operations on the TV and other connected devices (see the user manual of the TV or other devices for details).

2 Press . 3 Select [Setup]> [EasyLink]. 4 Select [On] under the options: [EasyLink], [One Touch Play] and [One Touch Standby].

EasyLink function is turned on. »

One Touch Play

When you play a disc on this player, the TV automatically switches to the correct video input source.

One Touch Standby

When a connected device (for example TV) is put to standby with its own remote control, this player is put to standby automatically.

3 Change settings

This section helps you to change the settings of this player.

Note

You cannot change a menu option that is grayed out. • To return to the previous menu, press • . To exit the menu, press .


Press .

1 2 Select [Setup] > [Video] to access the video setup options.

• [TV Display]: Select a picture display format to ﬁt the TV screen.

• [HDMI Video]: Select an HDMI video resolution.

• [HDMI Deep Color]: Display colors with more shades and hues when the video content is

recorded in Deep Color and the TV supports this feature.

• [Picture Settings]: Select a predeﬁned color setting.

English

Note

If you change a setting, make sure that the TV suppor ts the new setting. • For set tings related to HDMI, the TV must be connected through HDMI. • For the composite connection (via the • VIDEO connector), select a video resolution of 480i/576i or 480p/576p under [HDMI Video] to enable video output.

17EN
