Philips BDP2100K/98 User Manual

Download

Page 1

Always there to help you

Question?

Contact

Philips

BDP2100K

User manual 7

Manual pengguna 25

用户手册 43

使用手冊

Page 2

EN Before you connect this Blu-ray disc/ DVD player, read and understand all accompanying

instructions.

MS-MY Sebelum anda menyambungkan cakera Blu-ray/ pemain DVD ini, baca dan fahamkan arahan

yang disertakan.

ZH-CN 开始连接此蓝光光盘

ZH-HK

在您接駁此

Blu-ray disc/ DVD

/DVD

播放机之前，请先阅读并理解所有附带的说明。

播放機之前，請閱讀及明白所有相關指引。

Page 3

HDMI

( )

www.philips.com/welcome

COAXIAL

IAL

Page 4

1 HDMI

2 COAXIAL

HDMI  VIDEO  COAXIAL  AUDIO LINE OUT

HDMI

HDMI  VIDEO COAXIAL  AUDIO LINE OUT

COAXIAL

Page 5

SOURCE

Page 6

BD DVD/VCD/CD DivX Plus HD/MKV MP3 / JPEG

USB

Page 7

English

Contents

1 Hookup and play 2

2 Use your Blu-ray disc/ DVD player 8

Basic play control 8 Video, audio and picture options 9 DivX videos 10 Play a musical slideshow 11 BonusView on Blu-ray 11 BD-Live on Blu-ray 11 Set up a network 11 Smartphone control 12 Browse PC through DLNA 13 Karaoke 13 Use Philips EasyLink 14

3 Change settings 15

Picture 15 Sound 15 Network (installation, status...) 16 Preference (languages, parental

control...) 16

Advanced options (clear memory...) 16

4 Update software 18

Update software via the Internet 18 Update software via USB 18

5 Specications 19

6 Troubleshooting 20

7 Safety and important notice 22

Trademarks 74

Page 8

2 Use your Blu-

ray disc/ DVD player

Congratulations on your purchase, and

welcome to Philips! To fully benet from

the support that Philips offers (e.g. product software upgrade), register your product at www.philips.com/welcome.

Basic play control

During play, press the following buttons to control.

Button Action

Turn on the player, or switch to standby.

Access the home menu.

/ Stop play.

Press and hold (more than 4 seconds) to open or close the disc compartment.

Page 9

English

Pause play. Press repeatedly to slow forward frame by frame.

Start or resume play.

/ Skip to the previous or next

track, chapter or le.

/ Fast backward or forward.

Press repeatedly to change the search speed. Press

once, and then press

to slow forward.

AUDIO Select an audio language or

channel.

SUBTITLE Select a subtitle language. DISC MENU

/ POP-UP MENU

TOP MENU Access the main menu of a

Color buttons

Navigate the menus.

OK Conrm a selection or entry.

Alphanumeric buttons

Access or exit the disc menu.

video disc. Select tasks or options for

Blu-ray discs.

Press

to rotate a picture clockwise or counter-clockwise during slideshow.

Return to a previous display menu.

Access more options during play.

Select an item to play. Enter values. Enter letters via SMS style entry.

Video, audio and picture options

More options are available for video or picture play from a disc or USB storage device.

Video options

Access more options during video play.

• [Audio Language]: Select an audio language.

• [Subtitle Language]: Select a subtitle

language.

• [Subtitle Shift]: Change the subtitle position on the screen. Press change the subtitle position.

• [Info]: Display play information.

• [Character Set]: Select a character set that

supports the DivX video subtitle (only for DivX videos).

• [Time Search]: Skip to a specic time via

the numeric buttons on the remote control.

• [2nd Audio Language]: Select the second audio language (only for Blu-ray discs that support BonusView).

• [2nd Subtitle Language]: Select the second subtitle language (only for Blu-ray discs that support BonusView).

• [Titles]: Select a title.

• [Chapters]: Select a chapter.

• [Karaoke]: Set up Karaoke function.

• [Angle List]: Select a camera angle.

• [Menus]: Display a disc menu.

• [PIP Selection]: Display a picture-in-picture

window (only for Blu-ray discs that support BonusView).

• [Zoom]: Zoom into a video picture. Press

to select a zoom factor.

• [Repeat]: Repeat a chapter or title.

• [Repeat A-B]: Mark two points within a

chapter for repeat play, or turn off repeat mode.

Page 10

• [Picture Settings]: Select a predened

color setting.

Note

• Available video options depend on the video source.

Picture options

Access more options during slideshow.

• [Rotate +90]: Rotate a picture 90 degrees clockwise.

• [Rotate -90]: Rotate a picture 90 degrees counter-clockwise.

• [Zoom]: Zoom into a picture. Press to select a zoom factor.

• [Info]: Display picture information.

• [Duration per slide]: Set a display interval

for a slideshow.

• [Slide Animation]: Select a transition effect for a slideshow.

• [Picture Settings]: Select a predened

color setting.

• [Repeat]: Repeat a selected folder.

Audio options

• Repeat all the tracks on the disc or folder.

• Play audio tracks in a random loop.

• Turn off a repeat mode.

DivX videos

You can play DivX videos from a disc or a USB storage device.

VOD code for DivX

• Before you purchase DivX videos and play them on this player, register this player on www.divx.com using the DivX VOD code.

• Display the DivX VOD code: press , and select [Setup] > [Advanced] > [DivX®

VOD Code].

DivX subtitles

• Press SUBTITLE to select a language.

• If the subtitle is not displayed correctly,

change the character set that supports the DivX subtitle. Select a character set: press

, and select [Character Set].

Character set Languages [Standard] English [Chinese] Simplied Chinese [Chinese-

Traditional] [Korean] Korean

Note

• To play DivX DRM protected les from a USB storage

device, connect this player to a TV through HDMI.

• To use the subtitles, make sure that the subtitle le

has the same name as the DivX video le name. For example, if the DivX video le is named “movie.avi", save the subtitle le as “movie.srt”, or “movie.sub”.

• This player can play subtitle les in the following

formats: .srt, .sub, .txt, .ssa, and .smi.

Traditional Chinese

Press repeatedly to cycle through the following options.

• Repeat the current track.

Page 11

English

Play a musical slideshow

Play music and pictures simultaneously to create a musical slideshow.

1 From a disc or connected USB storage

device, play a music le.

2 Press , and go to the picture folder. 3 Select a picture from the same disc or

USB, and press OK to start slideshow.

4 Press to stop slideshow. 5 Press again to stop music play.

BonusView on Blu-ray

View special content (such as commentaries) in a small screen window. This feature is only applicable to Blu-ray discs compatible with BonusView (also known as picture in picture).

1 During play, press .

» The options menu is displayed.

2 Select [PIP Selection] > [PIP], and press

OK.

» PIP options [1]/[2] depend on the

video contents.

» The secondary video window is

displayed.

3 Select [2nd Audio Language] or [2nd

Subtitle Language], and press OK.

BD-Live on Blu-ray

Access exclusive online services, such as movie trailers, games, ringtones and other bonus contents. This feature is only applicable to Blu-ray discs that are BD-Live enabled.

1 Prepare the Internet connection and set

up a network (see "Set up a network").

2 Connect a USB storage device to this

player.

• A USB storage device is used to store

the downloaded BD-Live content.

• To delete the BD-Live previously

downloaded on the USB storage device for memory release, press and select [Setup] > [Advanced] >

[Clear memory].

3 Play a disc that is BD-Live enabled. 4 On the disc menu, select the BD-Live icon,

and press OK.

» BD-Live starts to load. The loading

time depends on the disc and the Internet connection.

5 On the BD-Live interface, select an item

to access.

Note

• BD-Live ser vices vary from discs and countries.

• When you use BD-Live, data on the disc and this player

are accessed by the content provider

• Use a USB storage device with at least 1GB of free

space to store the download.

Set up a network

Connect this player to the Internet to access the services:

• BD-Live: access online bonus features (applicable to Blu-ray discs that are BDLive enabled)

• Update software: update the software of this player via the Internet.

• Browse PC (DLNA): play photos, music, and video les streamed from your

computer.

Page 12

1 Connect this player to the Internet through

wired (Ethernet) or wireless connection.

• For wired connection, connect a network cable (not supplied) to the LAN port on the back panel of this player.

PC (DLNA)

2 Perform the network installation.

Smartphone control

Use a smartphone to browse, control and play

media les from this player.

What you need

• An iPhone (iOS 3.1.3 and above) or Android based device (Android 2.1 and above)

• On your smar tphone, download Philips MyRemote application

• For iPhone, search for the application

in App Store

• For Android based device, search for

the application in Android Market

Before you start

• Connect this player to a home network (see "Set up a network").

• Connect your smar tphone to the same

home network (see the user manual of the smartphone for details).

• Turn on this player

1) Press .

2) Select [Setup], and press OK.

3) Select [Network] > [Network installation], and press OK.

4) Follow the instructions on the TV screen to

complete the installation. If necessary, use the alphanumeric buttons on the remote control to enter a password.

Caution

• Before you connect to a network, familiarize yourself

with the network router, and networking principles. If necessary, read documentation accompanying network components. Philips is not responsible for lost, damaged or corrupt data.

Control your player

Use a smartphone to browse, control and play

media les from this player.

1 Insert a data disc or USB storage device

into this player.

2 On your smartphone, tap the MyRemote

icon from the home screen.

» The name of this player is displayed on

the smartphone.

3 Select this player from the smartphone

screen.

» The smartphone used as a virtual

remote control is enabled.

4 On the smartphone, tap the Media

(Media) tab, and then select the disc or USB source.

» The folders in the data disc or USB

storage device are displayed.

5 Open a folder, and select a le to play.

• To access the remote control, return

to the previous smartphone screen,

Page 13

English

and then tap the Remote (Remote) tab. Only the relevant control buttons are enabled.

6 Tap the control buttons on the

smartphone to control play.

• To access more control buttons, swipe the screen to the left or right.

• To exit the application, press the home button on the smartphone.

Browse PC through DLNA

Through this player, you can stream and play video, music and photo from a computer on your TV.

Before you start

• On your PC, install a DLNA-compliant media server application (such as Windows Media Player 11 or higher)

• On your PC, enable media sharing and le sharing (see the "Help" document in the

media server application)

1 Connect this player and your PC in the

same home network (see "Set up a network").

• For better video quality, use wired

network connection whenever possible.

2 Press .

» The home menu is displayed on the

TV screen.

3 Select [browse PC], and press OK.

» A content browser is displayed.

4 Select a le, and press OK to play.

• Use the remote control to control play.

Karaoke

1 Connect a microphone (not supplied) to

the MIC connector on this player.

2 Press to display the home menu. 3 Select [Setup] > [Audio] > [Karaoke], and

press OK.

» The Karaoke menu is displayed.

4 Select [Microphone] > [On], and press OK

to turn on the microphone sound output.

5 Play a disc, and then sing through the

microphone.

Set up Karaoke via the Karaoke menu

• [Microphone]: Turn on or off microphone sound output.

• [Microphone volume]: Change the microphone volume.

• [Echo]: Change the echo level.

• [Key]: Change the pitch level that matches

your voice.

Original vocal for Karaoke

Press repeatedly AUDIO on the remote control until the original vocal is turned off. Complete cancelation of the original vocal is disc dependent.

Page 14

Use Philips EasyLink

This player supports Philips EasyLink which uses the HDMI CEC (Consumer Electronics Control) protocol. You can use a single remote control to control EasyLink compliant devices that are connected through HDMI. Philips does not guarantee 100% interoperability with all HDMI CEC devices.

1 Connect the HDMI CEC compliant devices

through HDMI, and turn on the HDMI CEC operations on the TV and other connected devices (see the user manual of the TV or other devices for details).

2 Press . 3 Select [Setup]> [EasyLink]. 4 Select [On] under the options: [EasyLink],

[One Touch Play] and [One Touch Standby].

» EasyLink function is turned on.

One Touch Play

When a video disc is in the disc compartment, press

to wake up the TV from standby, and

then play a disc.

One Touch Standby

When a connected device (for example TV) is put to standby with its own remote control, this player is put to standby automatically.

Page 15

English

3 Change settings

This section helps you to change the settings of this player.

Note

• You cannot change a menu option that is grayed out.

• To return to the previous menu, press . To exit the

menu, press .


1 Press . 2 Select [Setup] > [Video] to access the

video setup options.

• [TV Display]: Select a picture display format to t the TV screen.

• [HDMI Video]: Select an HDMI video

resolution.

• [HDMI Deep Color]: Display colors with more shades and hues when the video content is recorded in Deep Color and the TV supports this feature.

• [Picture Settings]: Select a predened

color setting.

Note

• If you change a setting, make sure that the TV suppor ts

the new setting.

• For settings related to HDMI, the TV must be

connected through HDMI.

• For the composite connection (via the VIDEO

connector), select a video resolution of 480i/576i or 480p/576p under [HDMI Video] to enable video output.

Sound

1 Press . 2 Select [Setup] > [Audio] to access the

audio setup options.

• [Night Mode]: Select quiet or full dynamic sound. Night mode decreases the volume of loud sound and increases the volume of soft sound (such as speech).

• [HDMI Audio]: Set an HDMI audio format when this player is connected through HDMI.

• [Digital Audio]: Select an audio format for the sound output when this player is connected through a digital connector (coaxial).

• [PCM Downsampling]: Set the sampling rate for PCM audio output when this player is connected through a digital connector (coaxial).

• [Karaoke]: Set up Karaoke function (see "Use your Blu-ray disc/ DVD player" > "Karaoke").

Note

• For settings related to HDMI, the TV must be

connected through HDMI.

• Night mode is only available for Dolby encoded DVD

and Blu-ray discs.

Page 16

Network (installation, status...)

1 Press . 2 Select [Setup] > [Network] to access the

network setup options.

• [Network installation]: Start a wired or wireless installation to make the network work.

• [View network settings]: Display the current network status.

• [View wireless settings]: Display the current Wi-Fi status.

• [Name your Product:]: Re-name this player for identication in a home network.

Preference (languages, parental control...)

1 Press . 2 Select [Setup] > [Preference] to access

the preference setup options.

• [Menu language]: Select an onscreen display menu language.

• [Audio]: Select an audio language for video.

• [Subtitle]: Select a subtitle language for

video.

• [Disc Menu]: Select a menu language for a video disc.

• [Parental Control]: Restrict access to discs that are encoded with ratings. Input "0000"

to access the restriction options. To play all discs irrespective of the rating, select level

"8".

• [Screen Saver]: Enable or disable screen

saver mode. If enabled, the screen enters idle mode after 10 minutes of inactivity (for example, in pause or stop mode).

• [Auto Subtitle Shift]: Enable or disable subtitle shift. If enabled, the subtitle position

is changed automatically to t the TV

screen (this feature works with some Philips TVs only).

• [Change Password]: Set or change a password to play a restricted disc. Input

"0000" if you do not have a password or if

you have forgotten your password.

• [Auto Standby]: Enable or disable auto standby. If enabled, the player switches to standby after 30 minutes of inactivity (for example, in pause or stop mode).

• [VCD PBC]: Display or skip the content menu for VCD and SVCD.

Note

• If your preferred language is not available for disc

language, audio or subtitle, you can select [Other] from the menu options and input 4-digit language code which can be found at the back of this user manual.

• If you select a language which is not available on a disc,

this player uses the default language of the disc.

Advanced options (clear memory...)

1 Press . 2 Select [Setup] > [Advanced] to access the

advanced setup options.

• [BD-Live security]: Restrict or allow access to BD-Live (only for non-commercial, usercreated BD-Live discs).

• [Downmix mode]: Control 2-channel stereo audio output.

• [Software update]: Select to update software from a network or from USB storage device.

• [Clear memory]: Delete the previous BD- Live download on the USB storage device.

A "BUDA" folder is automatically created

to store the BD-Live download.

• [DivX® VOD Code]: Display the DivX® registration code or the deregistration code for this player.

• [Version information]: Display the software version of this player.

Page 17

English

• [Restore default settings]: Reset this player to the default settings made at the factory, except for password and parental control level.

Note

• You cannot restrict Internet access on commercial

Blu-ray discs.

• Before you purchase DivX videos and play them on this

player, register this player on www.divx.com with the DivX VOD code.

Page 18

4 Update software

Before you update the software of this player, check the current software version:

• Press , and then select [Setup] > [Advanced] > [Version Info.], and press OK.

Update software via the Internet

3 Connect the USB storage device to the

(USB) connector on this player.

4 Press , and select [Setup]. 5 Select [Advanced] > [Software Update]>

[USB].

» If an upgrade media is detected, you

are prompted to start the update.

6 Follow the instructions on the TV screen

to update the software.

» When the update is complete, this

player automatically turns off and on again.

1 Connect the player to the Internet (see

"Set up a network").

2 Press , and select [Setup]. 3 Select [Advanced] > [Software Update]>

[Network].

» If an upgrade media is detected, you

are prompted to start the update.

4 Follow the instructions on the TV screen

to update the software.

» When the update is complete, this

player automatically turns off and on again.

Update software via USB

1 Check the latest software version on

www.philips.com/support.

• Search for your model and click on

"Software and drivers".

2 Download the software into a USB storage

device.

a Unzip the download, and make sure

that the unzipped folder is named "UPG_ALL".

b Put the "UPG_ALL" folder in the root

directory.

Caution

• Do not turn off the power or remove the USB storage

device when the software update is in progress because you might damage this player.

Page 19

English

5 Specifications

Note

• Specications are subject to change without notice

Region code

This player can play discs with the following region codes.

DVD Blu-ray Countries

Asia Pacic,

Playable media

• BD-Video

• DVD-Video, DVD+R/+RW, DVD-R/-RW,

DVD+R/-R DL (Dual Layer)

• VCD/SVCD

• Audio CD, CD-R/CD-RW, MP3 media, WMA media, JPEG les

• DivX (Ultra)/DivX Plus HD media, MKV

media

• USB storage device

File format

• Video: .avi, .divx, .mp4, .mkv, .wmv,.rmvb, .rm

• Audio: .mp3, .wma, .wav

• Picture: .jpg, .gif, .png

Video

• Signal system: PAL / NTSC

• HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p, 1080p/24Hz

Audio

• Digital output: 0.5 Vp-p (75 ohm)

• Coaxial

• HDMI output

• Sampling frequency:

• MP3: 32 kHz, 44.1 kHz, 48 kHz

• WMA: 44.1 kHz, 48 kHz

• Constant bit rate:

• MP3: 112 kbps - 320 kpbs

• WMA: 48 kpbs - 192 kpbs

Taiwan, Korea

USB

• Compatibility: Hi-Speed USB (2.0)

• Class suppor t: USB Mass Storage Class

• File system: FAT16, FAT32

• USB por t: 5V , 500mA

• Suppor t HDD (a por table hard disc drive):

an external power source may be needed.

Main unit

• Power supply rating: 100-240V~, 50Hz

-60Hz

• Power consumption: 10 W

• Power consumption in standby mode:

< 0.5 W

• Dimensions (w x h x d): 310 x 39.5 x

217.7 (mm)

• Net Weight: 1.12 kg

Accessories supplied

• Remote control and 2 AAA batteries

• AC power cable

• HDMI cable

• User manual

LaserSpecication

• Laser Type (Diode): AlGaInN (BD), AlGaInP (DVD/CD)

• Wave length: 398nm to 413nm (BD),645nm to 664nm (DVD), 770nm to 800nm(CD)

• Output power : 1.7mW (BD),

0.19mW(DVD), 0.25mW (CD)

Page 20

6 Troubleshooting

Note

• For identication and supply ratings, see the type plate

at the back or bottom of the product.

• Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Warning

• Risk of electric shock. Never remove the casing of the

player.

To keep the warranty valid, never try to repair the player yourself. If you have problems using this player, check the following points before you request service. If you still have a problem, register your player and get support at www.philips.com/support. If you contact Philips, you will be asked for the model and serial number of this player. The model number and serial number are on the back of this player. Write the numbers here: Model No. ____________________________ Serial No. _____________________________

Main unit

The buttons on this player do not work.

• Disconnect this player from the power supply for a few minutes, and then reconnect.


No picture.

• Make sure that the TV is switched to the correct source input for this player.

• For the composite connection (via the VIDEO connector) to the TV, on this player select a video resolution of 480i/576i or 480p/576p under [HDMI Video] to enable video output.

No picture on HDMI connection.

• Make sure that the HDMI cable is not faulty. If it is faulty, replace with a new HDMI cable.

• On the remote control, press and then press “731” (numeric buttons) to recover

picture display. Or wait for 10 seconds for auto recovery.

• If this player is connected to an unauthorized display device with an HDMI cable, the audio and video signals may not be output.

Thediscdoesnotplayhigh-denitionvideo.

• Make sure that the disc contains high- denition video.

• Make sure that the TV supports high- denition video.

Sound

No audio output from the TV.

• Make sure that the audio cables are connected to the audio input of the TV.

• Make sure that the TV is switched to the correct source input for this player.

No audio output from the loudspeakers of the external audio device (home theater or

amplier).

• Make sure that the audio cables are connected to the audio input of the audio device.

• Switch the external audio device to the correct audio source input.

No sound on HDMI connection.

• You may not hear any sound from the HDMI output if the connected device is non-HDCP compliant or only DVIcompatible.

No secondary audio output for picture-inpicture feature.

• When [Bitstream] under the [HDMI Audio] or [Digital Audio] menu is selected,

interactive sound like secondary sound for picture-in-picture feature is muted. Deselect [Bitstream].

Page 21

English

Play

Cannot play a disc.

• Clean the disc.

• Make sure that the disc is correctly loaded.

• Make sure that this player supports the disc. See "Specications".

• Make sure that this player supports the

region code of the DVD or BD.

• For DVD±RW or DVD±R, make sure that the disc is nalized.

CannotplayDivXvideoles.

• Make sure that the DivX video le is complete.

• Make sure that the video le name extension is correct.

• To play DivX DRM protected les from a USB storage device, connect this player to a TV through HDMI.

DivX subtitles do not display correctly.

• Make sure that the subtitle le has the same name as the DivX video le.

• Make sure that the subtitle le has an extension name supported by this player (.srt, .sub, .txt, .ssa, or .smi).

Cannot read the contents of a connected USB storage.

• Make sure that the format of the USB storage device is compatible with this player.

• Make sure that the le system on the USB storage device is supported by this player.

• For a USB HDD (a portable hard disc drive), an external power source may be needed.

'No entry' or 'x' sign is displayed on the TV.

• The operation is not possible.

EasyLink feature does not work.

• Make sure that this player is connected to the Philips brand EasyLink TV, and the

EasyLink option is turned on (see "Use your Blu-ray disc/ DVD player" > "Use Philips EasyLink").

Cannot access BD-Live features.

• Make sure that this player is connected to the network (see "Use your Blu-ray disc/ DVD player" > "Set up a network").

• Make sure that the network installation is made (see "Use your Blu-ray disc/ DVD player" > "Set up a network").

• Make sure that the Blu-ray disc supports

BD-Live features.

• Clear memor y storage (see "Change settings" > "Advanced options (BD-Live security, clear memory...)").

Network

Browse PC works slowly.

• Look in your wireless router’s user manual for information on indoor range, transfer rate, and other factors of signal quality.

• You need a high speed Internet connection for your router.

Page 22

7 Safety and

important notice

Read and understand all instructions before you use this Blu-ray disc/ DVD player. If damage is caused by failure to follow the instructions, the warranty does not apply.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories to rain or water. Never place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it from the power outlet immediately. Contact Philips Consumer Care to have the product checked before use.

• Never place the product and accessories near naked ames or other heat sources,

including direct sunlight.

• Never inser t objects into the ventilation

slots or other openings on the product.

• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• Batteries (battery pack or batteries installed) shall not be exposed to excessive

heat such as sunshine, re or the like.

• Disconnect the product from the power

outlet before lightning storms.

• When you disconnect the power cord, always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the power outlet, ensure that the power voltage matches the value printed on the back or bottom of the product. Never

connect the product to the power outlet if the voltage is different.

Riskofinjuryordamagetotheproduct!

• Visible and invisible laser radiation when open. Avoid exposure to beam.

• Do not touch the disc optical lens inside the disc compartment.

• Never place the product or any objects

on power cords or on other electrical equipment.

• If the product is transported in temperatures below 5°C, unpack the product and wait until its temperature matches room temperature before connecting it to the power outlet.

Riskofoverheating!

• Never install this product in a conned

space. Always leave a space of at least four inches around the product for ventilation.

Make sure that curtains or other objects

never cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Remove batteries if they are exhausted or if the remote control is not to be used for a long time.

• Batteries contain chemical substances, they should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may contain a coin type battery, which can be swallowed.

• Keep the batter y out of reach of children at all times!

Class II equipment symbol:

This symbol indicates that this product has a double insulation system.

Page 23

English

CLASS 1

LASER PRODUCT

Care for your product

• Do not inser t any objects other than discs

into the disc compartment.

• Do not inser t warped or cracked discs into the disc compartment.

• Remove discs from the disc compartment if you are not using the product for an extended period of time.

• Only use microber cloth to clean the

product.

Care of the environment

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products and batteries. The correct disposal of these products helps prevent potentially negative consequences on the environment and human health. Your product contains batteries, which cannot be disposed of with normal household waste. Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health. Please visit www.recycle.philips.com for additional information on a recycling center in your area.

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

Open source software

Philips Electronics Singapore Pte Ltd hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source software packages used in this product for which such offer is requested by the respective licenses. This offer is valid up to three years after product purchase to anyone in receipt of this information. To obtain source code, please contact open.source@philips.com. If you prefer not to use email or if you do not receive

conrmation receipt within a week after mailing to this email address, please write to "Open

Source Team, Philips Intellectual Property & Standards, P.O. Box 220, 5600 AE Eindhoven,

The Netherlands." If you do not receive timely conrmation of your letter, please email to the

email address above.

Notes to End User :

By using this product with RealNetworks software and services, the end user agrees to the following terms of REALNETWORKS, INC:

• End User may only use the software for private, non-commercial use in accordance with the terms of RealNetworks EULA.

• End User is not allowed to modify, translate, reverse engineer, decompile, dissemble or use other means to discover the source code or otherwise replicate the functionality of the Real Format Client Code, except to the extent that this restriction is expressly prohibited by applicable law.

Page 24

• RealNetworks Inc. disclaims all warranties and conditions other than those set forth in this Agreement which are in lieu of all other warranties, whether express and implied, including but not limited to any implied warranties or conditions of

merchantability and tness for a particular

purpose; and effectively exclude all liability for indirect, special, incidental and consequential damages, such as but not

limited to lost prots.

This product incorporates proprietar y technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Cinavia notice

This product uses Cinavia technology to limit the use of unauthorized copies of some

commercially-produced lm and videos and

their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA.

Page 25

Trademarks

'Blu-ray Disc ' and 'Blu-ray Disc ' logo are trademarks of Blu-ray Disc Association.

HDMI, and HDMI logo and High-Denition

Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC in the United States and other countries.

ABOUT DIVX VIDEO-ON-DEMAND: This

DivX Certied® device must be registered

in order to play purchased DivX Video-onDemand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

DivX Certied

HD (H.264/MKV) video up to 1080p HD including premium content.

DivX

, DivX Certied®, DivX Plus® HD

and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.

to play DivX® and DivX Plus®

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s: 5,451,942;5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks, & DTS 2.0+ Digital Out and the DTS logos are trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary

of Rovi Corporation. This is an ofcial DivX Certied

divx.com for more information and software

tools to convert your les into DivX videos.

device that plays DivX video. Visit

RealNetworks, Real, the Real logo, RealPlayer, and the RealPlayer logo are trademarks or registered trademarks of RealNetworks, Inc.

BONUSVIEW™

'BD LIVE trademarks of Blu-ray Disc Association.

' and 'BONUSVIEW ' are

'DVD Video' is a trademark of DVD Format/ Logo Licensing Corporation.

Java and all other Java trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and/or other countries.

Page 26

Abkhazian 6566

Language Code

Afar 6565 Afrikaans 6570 Amharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Avestan 6569 Aymara 6589 Azerhaijani 6590 Bahasa Melayu 7783 Bashkir 6665 Belarusian 6669 Bengali 6678 Bihari 6672 Bislama 6673 Bokmål, Norwegian 7866 Bosanski 6683 Brezhoneg 6682 Bulgarian 6671 Burmese 7789 Castellano, Español 6983 Catalán 6765 Chamorro 6772 Chechen 6769 Chewa; Chichewa; Nyanja 7889 9072

Ё᭛

Chuang; Zhuang 9065 Church Slavic; Slavonic 6785 Chuvash 6786 Corsican 6779 Česky 6783 Dansk 6865 Deutsch 6869 Dzongkha 6890 English 6978 Esperanto 6979 Estonian 6984 Euskara 6985

Faroese 7079 Français 7082 Frysk 7089 Fijian 7074 Gaelic; Scottish Gaelic 7168 Gallegan 7176 Georgian 7565 Gikuyu; Kikuyu 7573 Guarani 7178 Gujarati 7185 Hausa 7265 Herero 7290 Hindi 7273 Hiri Motu 7279 Hrwatski 6779 Ido 7379 Interlingua (International)7365 Interlingue 7365 Inuktitut 7385

6976

Inupiaq 7375 Irish 7165

Íslenska 7383 Italiano 7384 Ivrit 7269 Japanese 7465 Javanese 7486 Kalaallisut 7576 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kernewek 7587 Khmer 7577 Kinyarwanda 8287 Kirghiz 7589 Komi 7586 Korean 7579 Kuanyama; Kwanyama 7574 Kurdish 7585 Lao 7679 Latina 7665 Latvian 7686 Letzeburgesch; 7666 Limburgan; Limburger 7673 Lingala 7678 Lithuanian 7684 Luxembourgish; 7666 Macedonian 7775 Malagasy 7771 Magyar 7285 Malayalam 7776 Maltese 7784 Manx 7186 Maori 7773 Marathi 7782 Marshallese 7772 Moldavian 7779 Mongolian 7778 Nauru 7865 Navaho; Navajo 7886 Ndebele, North 7868 Ndebele, South 7882 Ndonga 7871 Nederlands 7876 Nepali 7869 Norsk 7879 Northern Sami 8369 North Ndebele 7868 Norwegian Nynorsk; 7878 Occitan; Provencal 7967 Old Bulgarian; Old Slavonic 6785 Oriya 7982 Oromo 7977 Ossetian; Ossetic 7983 Pali 8073 Panjabi 8065 Persian 7065 Polski 8076 Português 8084

Pushto 8083 Russian 8285 Quechua 8185 Raeto-Romance 8277 Romanian 8279 Rundi 8278 Samoan 8377 Sango 8371 Sanskrit 8365 Sardinian 8367 Serbian 8382 Shona 8378 Shqip 8381 Sindhi 8368 Sinhalese 8373 Slovensky 8373 Slovenian 8376 Somali 8379 Sotho; Southern 8384 South Ndebele 7882 Sundanese 8385 Suomi 7073 Swahili 8387 Swati 8383 Svenska 8386 Tagalog 8476 Tahitian 8489 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 To nga (Tonga Islands) 8479 Tsonga 8483 Tswana 8478 Türkçe 8482 Turkmen 8475 Tw i 8487 Uighur 8571 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapuk 8679 Walloon 8765 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 8973 Yoruba 8979 Zulu 9085

Page 27

BDP2100K_98_UM_V1.0

Philips BDP2100K/98 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
