Philips BDL8470QU/00 Datasheet

Philips Signage Solutions

U-Line Display

84"

Edge LED Backlight Ultra HD

BDL8470QU

Captivate your audience

With an ultra-large screen experience

Experience your content like never before thanks to four times the resolution of a conventional display. This ultra-large 84" display offers 3840 x 2160 pixels so refined, so lifelike, it's a window to a new world

Optimised for public viewing

• 4K Ultra HD: resolution like you've never seen before

Innovative solutions for any signage application

•Optional OPS Insert to create an all-in-one solution

•Play content from 4 separate inputs with QuadViewer

•Connect and control your content via the cloud with HTML5

•Free and easy-to-use content management with SmartCMS

•Schedule what you want, when you want with SmartPlayer

Care about you, your business and your audience

•Keep your content up and running with FailOver

•SmartPower for energy saving

Maximising the impact of your message

• Manage and control your network remotely via SmartControl

U-Line Display	BDL8470QU/00
84" Edge LED Backlight, Ultra HD

Highlights

4K Ultra-HD Resolution

See your Signage Solutions like never before thanks to four times the resolution of a conventional Full HD display. 3840 x 2160 pixels provide and image so refined, so lifelike, it's a window to a new world.

QuadViewer

Be more flexible with your screen real estate. With the ability to play content from up to four separate inputs, all on one screen, QuadViewer is ideal for control rooms, corporate environments and meeting rooms.

OPS Insert

Turn your display into an all-in-one digital signage solution and create a display network that is connected, intelligent and secure. Open Pluggable Specification (OPS) is an industrystandard slot into which you can add an OPSstandardised media player. This cable-free solution gives you the ability to install, use or maintain your hardware whenever you need to.

Integrated HTML5 browser

Connect and control your content via the cloud with the integrated HTML5 browser. Design your signage content online and connect it with a display or with your entire network. Simply plug in a RJ45 Internet cable for network connection and connect the

display with the dedicated URL address, and you are ready to play your cloud-based content.

SmartCMS

Free and easy-to-use content management system that works exclusively with Philips Signage Solutions displays to manage your digital signage content. With SmartCMS you can create and schedule your own content over 24 hours every day. Simply create your network, design your content and schedule your playlist, and you are ready to play!

FailOver

Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides 24/7 protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and you're ready for instant protection.

SmartPower

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

SmartPlayer

Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.

SmartControl

SmartControl lets you remotely control and manage your network of displays via RJ45 and RS232C. Easily fine-tune all display settings including resolution, brightness, contrast and cloning of your settings over your complete network.

SmartCollection

SmartCollection offers you customisable solutions to meet your specific requirements.

Both integrators and solution providers are offered the latest innovations, while the audience can enjoy impactful solutions. When developing smart innovations we focus on Caring, Innovative and Impactful solutions.

OPSInsert
