Page 1
Philips
LCD monitor
140 cm (55")
multimedia Full HD
BDL5545E
Yay!
with stunning picture clarity in full HD
Deliver your marketing messages in style with this cost-effective 55" LCD display. With a
wide array of features this full HD display is sure to leave your audience spellbound.
Lower total cost of ownership
• SmartPower for energy saving
• Brightness automatically adjusts with ambient conditions
• Advanced anti image sticking function
Operational flexibility
• Open Pluggable Specification Slot
Page 2
LCD monitor
140 cm (55") multimedia Full HD
BDL5545E/01
Specifications
Picture/Display
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 500 cd/m²
• Contrast ratio (typical): 5000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Display colors: 1.07 Billion
• Picture enhancement: 3/2 - 2/2 motion pull down,
mbfilter, Motion compens. deinterlacing,
3D Co
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
• Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
deo formats
• Vi
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x1
• AV input: HDMI x1, Component (BNC) x1, Audio
/R) x2
(L
• AV output: Audio (L/R) x1
• Other connections: OPS, AC-out
Convenience
• Picture in picture:: PBP, PIP, POP
• Signal Loop Through:: RS232, VGA
• Keyboard control:: Hidden, Lockable
• Ease of installation: AC Out, Carrying Handles,
Smart Insert
• Energy saving functions:: Ambient light sensor,
Smart Pow
• Packaging:: Reusable box
• Network controllable: RS232
er
Dimensions
• Bezel thickness: 42.2 mm / 1.6"
•Set dimensions (W x H x D):
99 x 769.8 x 125.4 mm
12
• Set dimensions in inch (W x H x D):
.4 x 30.3 x 5
51
• VESA Mount: 400 x 200 / 400 x 400 mm
inch
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 60,000 hour(s)
Power
• Mains power: 90 - 264 V/AC, 50/60Hz
• Standby power consumption: <0.5W
Sound
• Built-in speakers: 2 x 7W (RMS)
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide
• Optional accessories: Fixed wall mount, Flexible
unt, Ceiling mount
wall mo
Miscellaneous
• Bezel: Metallic Anthracite
• On-Screen Display Languages: En
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
C, RoHS
CC
glish, French,
Packaging dimensions
• EAN: 87 12581 61971 8
• Number of products included: 1
• Packaging type: Carton
•
Highlights
Advanced anti image sticking
Static images left on-screen for extended periods of
time may leave a "ghost image" or image sticking
effect on LCD displays. Although image sticking in
LCD displays is not permanent, you want to prevent
this to happen, especially in locations where content
is shown 24/7.
Automatic brightness control
The adjustment of display settings to correspond
with ambient light without user intervention.
SmartPower
The backlight intensity can be controlled and pre-set
by the system to reduce the power consumption by
up to 50%, which saves substantially on energy costs.
OPS Slot
Developed for the Digital Signage market, the Open
Pluggable Specification (OPS) slot is designed to
make changing or upgrading your media player mere
child’s play. Simply plug your media player in to the
display - and you’re ready. No matter whether you
have an entry level, mid-range or high-end media
player, OPS is fully compatible bringing you a lower
TCO over the longer term.
Issue date 2011-10-18
Version: 1.0.1
12 NC: 8670 000 81655
EAN: 87 12581 61971 8
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
