Page 1
Philips
LED Display
119 cm (47")
multimedia Full HD
BDL4785SL
Superb image quality. Super slim bezel.
Still big on performance
Deliver your marketing messages in style with this super-slim 46" full HD Display. Ideal
for locations where space is of the essence, but without compromise in performance or
picture quality.
Lower total cost of ownership
• SmartPower for energy saving
• Brightness automatically adjusts with ambient conditions
• Advanced anti image sticking function
Operational flexibility
• Edge LED Backlight
• Network Controllability: RJ45
•Many Functions. One Wire
• Display Port for faster graphics support
• 120 Hz Panel
•DVI Out
Optimized for public viewing
• Full HD LCD display, 1920x1080p
Page 2
LED Display
119 cm (47") multimedia Full HD
BDL4785SL/01
Specifications
Picture/Display
• Diagonal screen size: 47 inch / 119.3 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60Hz
• Brightness: 450 cd/m²
• Contrast ratio (typical): 1600:1
• Response time (typical): 5 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.54 x 0.54 mm
• Display colors: 1.07 billion colors
• Picture enhancement: 3/2 - 2/2 motion pull down,
tion compens. deinterlacing, Progressive scan,
Mo
Dynamic contrast enhancement
Packaging dimensions
• EAN: 87 12581 61957 2
• Number of products included: 1
• Packaging type: Carton
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
RJ45, RS232 D-Sub9, RS232 D-sub9 output
• AV input: HDMI x1, DVI-D x1, Component (BNC)
x1
• Audio output: Audio L/R x1
• Other connections: AC-out, Display Port, USB
Convenience
• Tiled Matrix: Up to 5 x 5
• Picture in picture:: PBP, PIP, POP
• Signal Loop Through:: RS232, VGA
• Keyboard control:: Hidden, Lockable
• Remote control signal:: Lockable
• Energy saving functions:: Smart Power
• Packaging:: Reusable box
• Network controllable: RS232, RJ45
Dimensions
• Bezel thickness: 19mm
• Set dimensions (W x H x D): 1058 x 659 x 38 mm
• VESA Mount: 400 x 200 mm
Miscellaneous
• Bezel: Metallic Anthracite
• On-Screen Display Languages: En
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
C, RoHS
CC
glish, French,
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 60,000 hour(s)
Power
• Mains power: 90 - 264 V/AC, 50/60Hz
• Standby power consumption: <1W
Sound
• Built-in speakers: 2 x 10W (RMS)
Supported Display Resolution
• Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
deo formats
• Vi
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
•
Highlights
Edge LED Backlight
Experience an even dispersion of light with cutting
edge LED technology. White LED's (light emitting
diodes) are positioned around the rim of the panel
to give a more even spread of light. This results in
even lower power consumption, less heat to
dissipate, and a true, uniform color range.
Issue date 2011-12-13
Version: 3.0.2
12 NC: 8670 000 81582
EAN: 87 12581 61957 2
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
