Philips AZD208/12 leaflet

Page 1

Philips CD Soundmachine

•Dock for iPod

AZD208

Enjoy iPod and CD music anywhere you go

Play music from your iPod and CDs out loud and proud. The cool Philips CD soundmachine boasts a full range speaker system enhanced with powerful Dynamic Bass Boost — perfect for pumping up the volume wherever you go.

Enjoy your music from multiple sources

• MP3 Link for portable music playback

• Play and charge your iPod simultaneously

• Play CD, CD-R and CD-RW

Easy to use

• CD Shuffle/Repeat for personalised music enjoyment

Rich and clear sound

• Dynamic Bass Boost for deep and dramatic sound

Page 2

CD Soundmachine

Dock for iPod

Highlights

AZD208/12

Dynamic Bass Boost

Dynamic Bass Boost maximises your music enjoyment by emphasising the bass content of the music throughout the range of volume settings - from low to high – at the touch of a button! Bottom-end bass frequencies usually get lost when the volume is set at a low level. To counteract this, Dynamic Bass Boost can be switched on to boost bass levels, so you can enjoy consistent sound even when you turn down the volume.

CD Shuffle/Repeat

different and unique music experience every time you hook up to your player.

MP3 Link

The MP3 link connectivity allows direct playback of MP3 content from portable media players. Besides the benefit of enjoying your favourite music in the superior sound quality delivered by the audio system, the MP3 link is also extremely convenient as all you have to do is to plug your portable MP3 player into the audio system.

Play and charge your iPod

and not have to worry about your iPod battery running out. Use the remote control to navigate, select and playback the music stored on your iPod. The Docking entertainment system automatically charges your iPod while it is docked.

Play CD, CD-R and CD-RW

Philips is known for making products which are compatible with many discs available in the market. This audio system lets you enjoy music from CD, CD-R and CD-RW. A single CD can store up to 10 hours of music. CD-RW (CDRewritable Compatible) means that your audio system can play both CD-Recordable (CD-R) and CD-Rewritable (CD-RW) discs. CD-R discs are recordable once and can be played on any audio CD player while CD-RW discs can be recorded and rewritten multiple times and can only be played back on compatible audio CD players.

The "Shuffle/Repeat" function helps you to get rid of the boredom of hearing your music played in the same order all the time. After loading your favourite songs to the player, all you have to do is to select one of the modes "Shuffle" or "Repeat" for your tunes to be played in different modes order. Enjoy the

Enjoy your favourite MP3 music while charging your iPod! The dock lets you connect your iPod directly to the Docking entertainment system so you can listen to your favourite music in superb quality. It also charges your iPod while it plays so you can enjoy your music

Page 3

CD Soundmachine

Dock for iPod

Specifications

AZD208/12

iPod compatibility

• Compatible with: iPod touch, iPod 5th generation, iPod with colour display, iPod mini, iPod nano 1st generation, iPod nano 2nd generation, iPod nano 3rd generation, iPod classic

Audio playback

• Disc playback modes: fast forward/reverse, next/ previous track search, repeat/shuffle/programme

• Playback media: CD, CD-R, CD-RW

• Docking playback modes: fast forward and next and previous track, play and pause

reverse,

Sound

• Sound system: stereo

• Sound enhancement: Dynamic Bass Boost

• Volume control: rotary (analogue)

• Output power: 2 x 1 W RMS

Tuner/Reception/Transmission

• Tuner bands: FM stereo, MW

• Antenna: FM antenna

Loudspeakers

• No. of built-in speakers: 2

Connectivity

• Audio/Video output: Headphone (3.5 mm)

•Aux in

Convenience

• Loader type: top

• Display type: LCD display

• Charging device: iPod

Power

• Battery type: C size (LR14)

• Battery voltage: 1.5 V

• Number of batteries: 6

•Power type: AC Input

Accessories

• Cables/Connection: power cord

• Others: User Manual

• Warranty: Warranty Certificate

Dimensions

• Main unit depth: 228 mm

• Main unit height: 157 mm

• Main unit width: 331 mm

• Packaging width: 400 mm

• Packaging height: 192 mm

• Packaging depth: 260 mm

•

Issue date 2013-05-13

Version: 2.0.8

12 NC: 8670 000 64407 EAN: 87 12581 55131 5

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com
