Philips AZ7594, AZ7594/17 Specifications

CD portable

AZ7594

Ultra-compact CD player with
45-second ESP and powersave mode

• Electronic skip protection

Automatically stores 45 seconds of music during play to prevent
interruptions caused by vibrations and shocks.

• CD-Rewritable compatible

This ultra-compact CD player is capable of playing both
CD-Writable and CD-Rewritable disks .

• Ultra-compact design

Advanced micro-electronic circuitry for portability and outstanding
performance, with innovative styling in a superb design.

• Powersave mode

Gives you up to 40 hours of playing time with 2 ‘AA’ batteries and
the external battery pac k (supplied).

• Other CD features include:

Large EL-backlit LCD,99-track programming, shuffle, repeat one/all
and introscan functions, and feedback beep to confirm key-push
operation.

CD portable

UPC: 037849879740

Master pack UPC: 137849879747

AZ7594

Printed in Hong Kong 1998-09-25

Specifications subject to modification without notice

© 1998 Koninklijke Philips Electronics N.V.

All Rights Reserved

http://www.philipsmagnavox.com

System

• 3-stage Dynamic bass boost

• Automatic power switch-off

• Rotary volume control

• Built-in battery recharger function for NiCad or NiMH pack

• Acoustic feedback

CD player

• Electronic skip protection (ESP) with 45-second memory

• 99-track programmable, shuffle, repeat 1/all and introscan

• Search forward/backward with sound

• 1-Bit D/A convertor for pure sound reproduction

• S/N ratio (A weighted) : > 95 dB

• Frequency response : 20 Hz - 20 kHz.

• Resume and hold

Display

• 6-digit LCD

• Blue EL-backlit

• Indications for track, time, DBB,CD functions,battery and ESP

Remote control

• 3-key

• Volume control and hold

Connections

• Headphone/CD out : stereo, 3.5 mm

• DC in : 4.0 mm,4.5 V,centre ‘+’

Power supply

• Batteries : 2 x 1.5 V ,type AA/LR6/UM3 cell

• Typical playing time : up to 40 hours with external battery pack

• External supply : 120 V AC to 4.5 V DC

Accessories

• Car acessories

• AC/DC adaptor

• Stereo headphone

• Remote control

• Rechargeable battery pack

• External battery pack

General

• Material : Metal

• Product dimensions : 5.04"W x 1.14"H x 5.37"D

• Product weight : 0.53 lbs (excluding batteries)

• Package dimensions : TBD

• Package weight : TBD

• Master pack dimensions: TBD

• Master pack weight : TBD

• Quantity/mastercarton : 3

Product highlights

• Large EL-backlit LCD

Provides an easy-to-read display even in low light. track, time and other functions
are all visible at the same time and are bigger and brighter.

• 3-Stage Dynamic bass boost

Enhances bass tone frequencies to give three levels of deep,rich sounds.

• Feedback tone

Confirms any key-push with friendly beep.

• Play mode

Let’s you enjoy various track repeat modes (one/all/shuffle) or a combination of
each. Introscan plays 8 seconds of each track automatically.

• Next/previous track search

Two-button control that puts you immediately at the start of the previous track
or next track.

• Search with sound

Produces audible “bits” of sound while you search backwards or forwards within
a CD track.

• Hold

Prevents accidental interruption of play or changing of the setting.

• Resume

Ensures the CD starts precisely from the point it was stopped.

• Automatic power-off

Automatically switches off the CD player at the end of a compact disc.

• 1-Bit D/A conver ter

Advanced digital conversion technology ensures crystal-clear sounds for pure
listening pleasure.

• Adaptive ESP

Automatically stores 45 seconds of music during play to prevent interruptions
caused by vibrations and shocks even during Powersave mode.

• Stereo headphone

Stylish,headphone for exceptionally sound quality.
