Page 1

AZ100_QSG_A5.indd 1 2011/7/28 10:40:57

EN To play with the device, you can

use either alkaline battery (R14) or AC power.

Before connecting AC power,

adjust the voltage selector to correspond to the local power voltage.

www.philips.com/welcome

AZ300

EN User manual

Before using your product, read all accompanying safety information.

FM / MW

Connect power

Listen to FM/MW radio

What’s in the box

Listen to an external audio device

10-

7 V

0 V

RADIO

6 x R14/UM2/C Cell

Safety Sheet

User Manual

Page 2

AZ100_QSG_A5.indd 2 2011/7/28 10:40:59

PROG

- ALBUM +

MODE

EN Need help? Visit www.philips.com/support

AZ300_78_UM_V1.0

+ VOLUME -

www.philips.com/support

Play disk

Adjust volume

Turn the device off

For online help

Warning and maintenance

RADIO

ALBUM

+ / -

For MP3-CDs, select an album.

Skip to the previous/next track or search within play.

Stop play or erase a program.

MODE

Play a track/all tracks/an album repeatedly; play tracks randomly.

PROG

Program tracks.

Pause or start play.

Program tracks

1 In CD mode, press to stop playback. 2 Press PROG to activate programming. 3 For MP3-CDs, press ALBUM +/- to select an album. 4 Press repeatedly to select a track, then press PROG to confirm. 5 Repeat steps 3~4 to program more tracks. 6 Press to play the programmed tracks. 7 To cancel the program, when playback is stopped, press .

Page 3

www.philips.com/welcome

AZ300

Page 4

Congratulations on your purchase and welcome to Philips!

To fully benet from the support that Philips offers, register your product at

www.philips.com/welcome.

1 Important

• Read these instructions.

• Follow all instructions.

• Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the

unit.

• Only use attachments/accessories specied by the manufacturer.

• Unplug this unit during lightning storms or when unused for long periods

of time.

• Refer all servicing to qualied service personnel. Servicing is required when the unit has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the unit has been exposed to rain or moisture, does not operate normally, or has been dropped.

• Battery usage CAUTION – To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit:

• Install all batteries correctly, + and - as marked on the unit.

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Remove batteries when the unit is not used for a long time.

• The unit shall not be exposed to dripping or splashing.

• Do not place any sources of danger on the unit (e.g. liquid lled objects, lighted candles).

Page 5

• Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

Know these safety symbols

This 'bolt of lightning' indicates uninsulated material within your unit may

cause an electrical shock. For the safety of everyone in your household,

please do not remove product covering.

The 'exclamation point' calls attention to features for which you should

read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: To reduce the risk of re or electric shock, this apparatus should not be exposed to rain or moisture and objects lled with liquids, such as vases, should not be placed on this apparatus. CAUTION: To prevent electric shock, match wide blade of plug to wide slot,

fully insert.

Warning

•

Never remove the casing of this apparatus.

• Never lubricate any part of this apparatus.

• Never place this apparatus on other electrical equipment.

• Keep this apparatus away from direct sunlight, naked ames or heat.

• Ensure that you always have easy access to the power cord, plug or adaptor to

disconnect the apparatus from the power.

Page 6

Caution

•

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

2 Notice

Any changes or modications made to this device that are not expressly

approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment.

Disposal of your old product and batteries

Your product is designed and manufactured with high quality materials and

components, which can be recycled and reused.

Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products and batteries. The correct disposal of these products helps prevent potentially negative consequences on the environment and human health.

Your product contains batteries, which cannot be disposed of with normal

household waste. Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health. Please visit www.recycle.philips.com for additional information on a recycling center in your area.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the

packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)

Page 7

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations

regarding the disposal of packaging materials, exhausted batteries and old

equipment.

This apparatus includes this label:

Note

•

The type plate is located on the bottom of the apparatus.

3 Specifications

Amplier

Rated Output Power 2 X 1 W RMS

Frequency Response 80 Hz - 16 kHz, ± 3 dB

Signal to Noise Ratio 50 dB

MP3 Link Input 0.5 V RMS 20 kohm

Discs

Laser Type Semiconductor

Disc Diameter 12cm/8cm

Support Disc CD-DA, CD-R, CD-RW

Page 8

Audio DAC 24Bits / 44.1kHz

Total Harmonic Distortion <1%

Frequency Response 60Hz -16kHz

S/N Ratio 55dBA

Tuner

Tuning Range FM: 87.5 - 108 MHz;

MW: 530 - 1710 kHz;

Total Harmonic Distortion <3%

Signal to Noise Ratio 40 dB

General information

AC power 110–127 V / 220–240 V ~, 50/60

Operation Power Consumption 15 W

Standby Power Consumption 1.5 W

Batteries 9 V, 6 x R14/UM2/C Cell

Dimensions

- Main Unit (W x H x D) 245 x 130 x 212 mm

Weight

- With Packing

- Main Unit

1.8 kg

1.4 kg
