Philips AZ1116, AZ1117, AZ1118 User Manual

CD Radio Cassette Recorder
DYNAMIC
•CD
•RADIO
•TAPE
POWER OFF
•CD
•RADIO
•TAPE
POWER OFF
DBB
BOOST
SHUFFLE
SEARCH
MODE
STOP
SEARCH
MODE
STOP
PAUSE
SEARCH
PLAY
RECORD
STOP • OPEN
PAUSE
SEARCH
PLAY
RECORD
STOP • OPEN
PLAY•PAUSE
FM
FM -
MW -
FM -
MW -
88
92
96
100
104
108
MHz
FM
88
92
96
100
104
108
MHz
MW
530
650
830
1000
1200
1600
KHz
MW
530
650
830
1000
1200
1600
KHz
OPEN
OPEN
AZ 1110
DYNAMIC
•CD
•RADIO
•TAPE
POWER OFF
DBB
BOOST
POWER ON
SHUFFLE
SEARCH
MODE
STOP
PLAY•PAUSE
FM
FM -
AM -
88
92
96
100
104
108
MHz
AM
530
650
830
1000
1200
1600
KHz
OPEN
PAUSE
SEARCH
PLAY
RECORD
STOP • OPEN
PAUSE
SEARCH
PLAY
RECORD
STOP • OPEN
@
4
3
2
1
!
0
7
9
5
6
8
^#%
$
3
CONTROLS
English
TOP and FRONT PANEL
1 DBB (Dynamic Bass Boost) – to increase the bass level 2 VOLUME – to adjust the volume level 3 Cassette keys
PAUSE ; – to interrupt playback
STOPOPEN 9/– to stop playback and open the cassette compartment SEARCH 5 – to fast forward the tape SEARCH 6 – to fast rewind the tape PLAY 1 – to start playback RECORD 0 – to start recording
4 CD buttons
PLAYPAUSE 2; – to start or interrupt CD playback STOP 9 – to stop playback SEARCH ∞§– to skip or search a passage or a track MODE – to select a different playback mode e.g. to SHUFFLE or REPEAT and to program track
numbers
5 CD display – to indicate CD functions 6 Cassette compartment 7 TUNING – to tune to radio stations 8 Tuning dial pointer 9 Band selector – to select the wave band (FM-MW) 0 OPEN – to open the CD door ! Source selector – POWER ON/OFF switch and to select the sound source: CD - RADIO - TAPE @ p – 3.5 mm headphone socket
Note:
Connecting headphones will automatically disconnect the speakers
BACK PANEL
# Telescopic aerial – To improve FM reception $ MAINS – for mains lead % Battery door – to open the battery compartment ^ Voltage selector – (inside battery compartment)
Both the model and production numbers can be found on the bottom of the set.
4
BATTERIES
6 x D-cells - R20
POWER SUPPLY
Whenever convenient, use the mains supply if you want to conserve battery life. Make sure you remove the mains plug from the set and wall socket before inserting batteries.
Batteries (optional)
1.
Open the battery compartment and insert as shown six batteries, type R20, or D-cells.
2.
Replace the compartment door, making sure the batteries are firmly and correctly in place.
3.
Remove the batteries if exhausted or if they will not be used again for a long period.
– The incorrect use of batteries can cause electrolyte leakage and will
corrode the compartment or cause the batteries to burst. Therefore:
– Do not mix battery types, e.g. alkaline with zinc carbonate. – When insertingnew batteries,replace allbatteries at the same time.
Batteries contain chemical substances, so they should be disposed of properly
The battery supply is switched off when the set is connected to
Note:
the mains.
MAINS
1.
Check if the mains voltage as shown on the type plate (on the bottom of the set) corresponds to your local mains voltage. If it does not, con­sult your dealer or service organisation.
2.
If your set is equipped with a voltage selector, set it to the local mains voltage.
3.
Connect the mains lead to the MAINS socket and the wall socket. – The set is now ready to use.
4.
To switch off the mains supply completely, pull the mains plug out of the wall socket.
– Disconnect the mains lead when you change over to battery supply, or
to protect the set during heavy thunderstorms.
English
MAINS
Environmental information
All redundant packaging material has been omitted. We have done our utmost to make the packaging easily separable into three mono materials: cardboard (box), expandable polystyrene (buffer) and polyethylene (bags, protective foam sheet).
Your set consists of materials which can be recycled if dissassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.
5
