Philips AZ 1060, AZ1061 User Manual

0 (0)

Audio

CD Radio Cassette Recorder

Toll Free Help Line

Ligne d'assistance en service libre Linea de ayuda telefónica sin cargo

800-531-0039

DBB

POWER

TUNER

DYNAMIC BASS BOOST

TAPE

TUNER

DYNAMIC BASS BOOST

TAPE

OFF

RECORD

PLAY

STOP-OPEN

PAUSE

RECORD

PLAY

STOP-OPEN

PAUSE

SHUFFLE

ALL

AZ 1060

CD RADIO CASSETTE RECORDER

PROG.

BAND

PRESET

BATT LOW

MODE

VOLUME

TAPE

TUNER

STOP

PLAY•PAUSE

SEARCH • • •

• • • SEARCH

DIGITAL TUNER

REMOTE CONTROL

PROG.

BAND

PRESET

BATT LOW

MODE

VOLUME

TAPE

TUNER

STOP

PLAY•PAUSE

SEARCH • • •

• • • SEARCH

DIGITAL TUNER

REMOTE CONTROL

AZ 1060

CD RADIO CASSETTE RECORDER

AZ 1060 AZ 1061

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Return your Warranty Registration card today to

ensure you receive all the benefits you’re entitled to.

• Once your Philips purchase is registered, you’re eligible to receive all the privileges of owning a Philips product.

Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your Philips warranty.

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Know these

ssaaffeettyysymbols

• So complete and return the Warranty Registration Card enclosed with your purchase at once. And take advantage of these important benefits.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

For Customer Use

Enter below the Serial No.which is located on the bottom of the set.Retain this information for future reference.

Model No. _______________________

This “bolt of lightning” indicates uninsulated

material within your unit may cause an electrical shock.For the safety of everyone in your household, please do not remove product covering.

The “exclamation point” calls

attention to features for

which you should read the enclosed literature closely to prevent operating and maintenance problems.

Serial No. ________________________

WARNING: TO PREVENT

FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION: To prevent electric

shock,match wide blade of plug to wide slot,and fully insert.

E R

I C

A P

F F

CD RADIO

CASSETTE RECORDER

RADIO

CASSETTE RECORDER

PROG.

ESE

BATT LOW

MODE

TAPE

PLA

•PA U

• • •

• • • SEARCH

!0 &^%@@ $#

2 3 4 65 978

(

)

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure.

ATTENTION

L’utilisation des commandes ou réglages ou le non-respect des procédures ciincluses peuvent se traduire par une exposition dangereuse à l’irradiation.

ATENCIÓN

El uso de mandos o ajustes o la ejecucción de métodos que no sean los aquí descritos puede ocasionar peligro de exposición a radiación.

The set complies with the FCC-Rules, Part 15 and with 21 CFR 1060.10. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

L’appareil répond aux normes FCC, Part 15 et 21 CFR 1060.10. Fonctionnement soumis aux deux conditions suivantes:

1. Cet appareil ne doit pas provoquer d’interférences nuisibles, et

2. Cet appareil doit accepter toute interférence reçue, y compris les interférences susceptibles de provoquer un fonctionement peu satisfaisant.

El aparato cumple las normas FCC, Parte 15 y 21 CFR 1060.10. Funcionamiento dependiente de dos condiciones siguientes:

1. Este aparato no puede provocar interferencia dañina, y

2. Este aparato debe aceptar cualquier interferencia recibida, incluyendo las interferencias que pueden provocar un funcionamiento insuficiente.

INDEX

English

Français

Español

Safety instructions..........2, 4 + 6

Limited warranty.......................7

Controls.....................................8

Power supply.............................9

Basic functions........................10

General information................10

Conseils de sécurité ..4, 18 + 19

Garantie limitée......................20

Commandes.............................21

Alimentation............................22

Fomctions de base..................23

Informations generales...........23

Instrucciones sobre seguridad

....................................4, 31 + 32

Garantie limitada....................33

Controles.................................34

Alimentación...........................35

Funciones básicas...................36

Información general................36

Digital tuner............................11

CD Player ...........................12-14

Cassette recorder....................14

Recording...........................15-16

Maintenance...........................16

Troubleshooting.......................17

Syntoniseur numérique...........24

Lecteur de CD....................25-27

Platine cassette ......................27

Enregistrement...................28-29

Entretien..................................29

Dépannage..............................30

Sintonizador digital.................37

Reproductor de CD.............38-40

Grabadora del casete..............40

Grabación...........................41-42

Mantenimiento........................42

Resolución de problemas........43

English

Français

Español

CANADA

English: This digital apparatus does not exceed the Class B limits for noise emissions from

digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.

Français: Cet appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de Classe B prescrites dans le Régelement sur le Brouillage Radioélectrique édicté par le Ministère des Communications du Canada.

IMPORTANT SAFETY INSTRUCTIONS –

Read before operating equipment

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1. Read these instructions – All the safety and operating instructions should be read before the appliance is operated.

2. Keep these instructions – The safety and operating instructions should be retained for future reference.

3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow all instructions – All operating and use instructions should be followed.

5. Do not use this apparatus near water – for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool, etc.

6. Clean only with a damp cloth. The appliance should be cleaned only as recommended by the manufacturer.

7. Install in accordance with the manufacturers instructions. Do not block any of the ventilation openings. For

example, the appliance should not be situated on a bed, sofa, rug, or similar surface or placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the

polarized or groundingtype plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Polarized Plug

10.Protect the power cord from being walked

on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11.Only use attachments/accessories

specified by the manufacturer.

12. Use only with a cart, stand,

13.Unplug this apparatus during lightning

storms or when unused for long periods of time.

14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15.Battery usage CAUTION. To prevent battery leakage which may result in bodily injury or damage to the unit:

• Install all batteries correctly, + and - as marked on the unit.

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Remove batteries when the unit is not used for a long time.

tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

EL 6475-E001: 00/8

LIMITED WARRANTY

PORTABLE AUDIO

One Y ear Free Exchange

This product must be carried in for an exchange.

WHO IS COVERED?

You must have proof of purchase to exchange the product.A sales receipt or other document showing that you purchased the product is considered proof of purchase. Attach it to this owner’s manual and keep both nearby.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product.For one year thereafter, a defective or inoperative product will be replaced with a new, renewed or comparable product at no charge to you.A replacement product is covered only for the original warranty period.When the warranty on the original product expires,the warranty on the replacement product also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

• labor charges for installation or setup of the product,adjustment of customer controls on the product,and installation or repair of antenna systems outside of the product.

• product repair and/or part replacement because of misuse, accident, unauthorized repair or other cause not within the control of Philips Consumer Electronics Company.

• reception problems caused by signal conditions or cable or antenna systems outside the unit.

• a product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured,approved and/or authorized,or repair of products damaged by these modifications.

• incidental or consequential damages resulting from the product.(Some states do not allow the exclusion of incidental or consequential damages,so the above exclusion may not apply to you. This includes,but is not limited to, prerecorded material, whether copyrighted or not copyrighted.)

• a product used for commercial or institutional purposes.

WHERE IS EXCHANGE AVAILABLE?

You may exchange the product in all countries where the product is officially distributed by Philips Consumer Electronics Company.In countries where Philips Consumer Electronics Company does not distribute the product,the local Philips service organization will attempt to provide a replacement product (although there may be a delay if the appropriate product is not readily available).

BEFORE REQUESTING EXCHANGE...

Please check your owner’s manual before requesting an exchange.Adjustments of the controls discussed there may save you a trip.

EXCHANGING A PRODUCT IN U.S.A., PUERTO RICO OR U.S.VIRGIN ISLANDS...

Contact your dealer to arrange an exchange.Or,ship the product,insured and freight prepaid,and with proof of purchase enclosed,to the address listed below.

(In U.S.A.,Puerto Rico and U.S.Virgin Islands, all implied warranties,including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the duration of this express warranty. But, because some states do not allow limitations on how long an implied warranty may last,this limitation may not apply to you.)

EXCHANGING A PRODUCT IN CANADA...

Please contact Philips at:

(In Canada,this warranty is given in lieu of all other warranties.No other warranties are expressed or implied,including any implied warranties of merchantability or fitness for a particular purpose. Philips is not liable under any circumstances for any direct,indirect, special, incidental or consequential damages,howsoever incurred,even if notified of the possibility of such damages.)

TO GET OUT-OF-WARRANTY EXCHANGE...

In U.S.A.,Puerto Rico or U.S.Virgin Islands, contact Philips Service Company at (800) 531-0039 to obtain the cost of out-of-warranty exchange.Then carefully pack the product and ship it to the Small Product Service Center (address listed above).In Canada, call the phone number listed above under “Exchanging a Product in Canada” to obtain the cost of out-of-warranty exchange.

REMEMBER...

Please record the model and serial numbers found on the product below.Also,please fill out and mail your warranty registration card promptly.It will be easier for us to notify you if necessary.

MODEL # __________________________________

SERIAL # __________________________________

Small Product Service Center

Philips Service Company

907 Snapps Ferry Road,Plant 2, Building 6

Greeneville,TN 37743

1-800-661-6162 (French Speaking) 1-800-363-7278 (English Speaking)

This warranty gives you specific legal rights.You may have other rights which vary from state/province to state/province.

Philips Service Solutions Group, P.O.Box 2976, Longview,Texas 75606, (903) 242-4800

EL6095T002 / MAC5433 / 1-97

CONTROLS

TOP AND FRONT PANELS

1 VOLUME -

English

adjusts the volume level

2 DBB (Dynamic Bass Boost) -

enhances the bass

3 POWER slider -

selects the sound source for CD/ TUNER/ TAPE/

OFF and also switches the set off

4 Function indicators - lights up if the

respective CD, tape or tuner function is in use

5 Display - shows the status of the set 6 p - 3.5 mm stereo headphone jack

Note: Connecting headphones will switch off

the speakers.

7 CASSETTE RECORDER keys:

PAUSE ; - interrupts recording or playback STOP•OPEN 9/

- stops the tape;

- opens the cassette compartment SEARCH 5 / 6 - fast winds/rewinds the

tape

PLAY 1 - starts playback RECORD 0 - starts recording

8 BATT LOW - indicates when battery power

is running low

9 OPEN•CLOSE - opens/ closes the CD door 0 MODE - selects a different play mode for CD

playback e.g. repeats tracks or

SHUFFLE, plays tracks in random order

! Cassette door @ SEARCH ∞ / § -

Radio: - (down/up) tunes to radio stations; CD: - searches back and forward within a

track;

- skips to the beginning of a current track/ previous/ subsequent track

# PLAY•PAUSE 2; -

starts or interrupts CD playback

$ STOP 9 - stops CD playback or erase a

CD program

% PROG -

Radio: programs preset radio stations; CD: programs tracks and reviews the

program

^ PRESET 3 ,4 (up, down) -

selects a tuner preset station

& BAND - selects waveband

BACK PANEL

* Telescopic antenna - improves FM

reception

( AC MAINS - inlet for power cord ) Battery compartment -

for 6 x R-20, UM-1 or D-cells

Environmental information

All unnecessary packaging material has been omitted. We have done our utmost to make the packaging easy to separate into three materials: cardboard (box), expandable polystyrene (buffer), polyethylene (bags, protective foam).

Your set consists of materials which can be recycled if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packing materials, dead batteries and old equipment.

Whenever convenient, use the power supply if you want to

6 x R20 • UM-1 • D-CELLS

conserve battery life. Make sure you remove the plug from the set and wall outlet before inserting batteries.

BATTERIES (NOT INCLUDED)

1. Open the battery compartment and insert six batteries, type

R-20, UM-1 or D-cells, (preferably alkaline) with the correct polarity as indicated by the " compartment.

2. Replace the compartment door, making sure the batteries are firmly and correctly in place. The set is now ready to operate.

– If BATT LOW lights up, battery power is running low.

– The BATT LOW indicator eventually goes out if the

batteries are too weak.

Incorrect use of batteries can cause electrolyte leakage and will corrode the compartment or cause the batteries to burst. Therefore:

• Do not mix battery types: e.g. alkaline with carbon zinc. Only use batteries of the same type for the set.

• When inserting new batteries, do not try to mix old batteries with the new ones.

• Remove the batteries if the set is not to be used for a long time.

Batteries contain chemical substances, so they should be disposed of properly.

+" and "-" symbols inside the

POWER SUPPLY

English

Using AC POWER

1. Check if the power voltage as shown on the type plate on the bottom of the set, corresponds to your local power

supply. If it does not, consult your dealer or service center.

2. If your set is equipped with a voltage selector, adjust the selector so to match with the local power supply.

3. Connect the power cord to the wall outlet and the set is now ready for use.

4. To disconnect the set from the power supply completely, remove the plug from the wall outlet.

BASIC FUNCTIONS GENERAL INFORMATION

Switching on and off

1. Adjust the POWER slider to the desired sound source: CD,

English

TUNER or TAPE/

™ The respective function indicator:

2. To switch off, adjust the POWER slider to TAPE/

OFF.

CD, TUNER or TAPE lights up.

OFF position

with the keys on the tape deck released.

™ The respective function indicator:

CD, TUNER or TAPE goes out.

™ The volume and tuner presets will be retained in the set's

memory.

Adjusting volume and sound

1. Turn VOLUME to the desired level.

2. Adjust the DBB control to select dynamic bass boost on or off.

PHILIPS demo mode

1. Press the CD STOP 9 button for 5 seconds. ™ After about 30 seconds, PH..IL ..IPS scrolls across the display.

2. To return to the current display you can either:

• press any function button on the front panel. This interrupts the demo mode for 30 seconds;

• press the CD STOP 9 button for 5 seconds. PH..IL ..IPS scrolls once before the demo mode is cancelled.

C D

E R

I C

A S

SHUFFLE

• • • S E

•

PAUSE

C D

E R

I C

O S

ALL

• • •

PAUSE

SHUFF

PROG.

GENERAL INFORMATION

General maintenance

• Do not expose the set, batteries, CDs or cassettes to humidity, rain, sand or excessive heat caused by heating equipment or direct sunlight.

• To clean the set, use a soft, slightly dampened chamois leather. Do not use any cleaning agents containing alcohol, ammonia, benzene or abrasives as these may harm the housing.

Safety information

• Place the set on a hard and flat surface so that the system does not tilt. Make sure there is adequate ventilation to prevent the system from overheating.

• The mechanical parts of the set contain self-lubricating bearings and must not be oiled or lubricated.

TUNING TO RADIO STATIONS

SHUFFLE

ALL

PROG.

•

• • •

• • • S E

1. Select RADIO source.

™ The function indication lights up. is displayed briefly

and then the radio station frequency is shown.

2. Press BAND once or more to select your waveband.

3. Press SEARCH ∞ or § and release when the frequency in

the display starts running.

™ The radio automatically tunes to a station of sufficient

reception. Display shows during automatic tuning.

™ If a FM station is received in stereo,

STEREO is shown.

4. Repeat step 3 if necessary until you find the desired station.

• To tune to a weak station, press SEARCH ∞ or § briefly and repeatedly until you have found optimal reception.

To improve radio reception

– For FM, pull out the telescopic antenna. Incline and turn the

antenna. Reduce its length if the signal is too strong (very close to a transmitter).

– For AM, the set is provided with a built-in antenna so the

telescopic antenna is not needed. Direct the antenna by turning the whole set.

5. To switch off, adjust the POWER slider to TAPE/

OFF position

with the keys on the tape deck released.

™ The function indicator goes out.

DIGITAL TUNER

English

Programming radio stations

You can store up to a total of 30 radio stations in the memory.

1. Tune to your desired station (see Tuning to radio stations).

2. Press PROG to activate programming.

– Display:

PROGRAM flashes.

3. Press PRESET 4 or 3 once or more to allocate a number from 1 to 30 to this station.

4. Press PROG again to confirm the setting.

– Display:

PROGRAM disappears, the preset number and the

frequency of the preset station are shown.

5. Repeat the above four steps to store other stations.

– You can erase a preset station by storing another frequency in

its place.

Tuning to preset stations

Press PRESET 4 or 3 until the desired preset station is displayed.

STEREO

SHUFFLE

ALL

• • •

ALL

PROG.

CD PLAYER

PAUSE

T U

E R

I C

P E

A D

S E

C O

ALL

IGITAL

Playing a CD

1. Select CD source.

English

™ is displayed briefly and the function indication lights up.

2. Press OPEN•CLOSE to open the CD door.

™ Display: when you open the CD door.

3. Insert a CD or CD-R(W) with the printed side facing up and close the CD door.

™ Display: flashes as the CD player scans the contents of

a CD. The total number of tracks and playing time are then shown.

4. Press PLAY•PAUSE 2; to start playback.

™ Display: Current track number and elapsed playing time of the

track during CD playback.

5. To interrupt playback press PLAY•PAUSE 2;. Press PLAY•PAUSE 2; again to resume play.

™ The display freezes and the elapsed playing time flashes when

playback is paused.

6. To stop CD playback, press STOP 9

7. To switch off, adjust the POWER slider to TAPE/

with the keys on the tape deck released.

™ The function indicator goes out.

Note: CD play will also stop when:

– the CD door is opened; – the CD has reached the end

(unless you have selected REPEAT or REPEAT ALL);

– you select another source: TAPE / TUNER.

OFF position

SHUFFLE

ALL

•

• • • S

PROG.

• • •

Selecting a different track

• Press SEARCH ∞ or § once or repeatedly until the desired track number appears in the display.

• If you have selected a track number shortly after loading a CD or in the PAUSE position, you will need to press PLAY•PAUSE 2; to start playback.

•

• • • S

DIGITAL

BASS

T L

PROG.

• • •

Finding a passage within a track

SHUFFLE

ALL

1. Press and hold down on SEARCH ∞ or §.

™ The CD is played at high speed and low volume.

2. When you recognize the passage you want, release SEARCH ∞ or §.

– Normal playback continues.

Note:

During a CD program or if SHUFFLE/ REPEAT active, searching is only possible within a track.

•

• • • S

PROG.

• • •

Different play modes: SHUFFLE and REPEAT

SHUFFLE

ALL

•

• • •

• • • S E

GITALT

You can select and change the various play modes before or during playback. The play modes can also be combined with PROGRAM. SHUFFLE - tracks of the entire CD/ program are played in random

order

SHUFFLE and REPEAT ALL - to repeat the entire CD/ program

continuously in random order

REPEAT ALL- to repeat the entire CD/ program continuously REPEAT- repeats the current track continuously

1. To select your play mode, press the MODE button before or during playback until the display shows the desired function.

2. Press PLAY•PAUSE 2; to start playback if in the STOP position.

3. To return to normal playback, press the respective MODE button until the various SHUFFLE/ REPEAT modes are no longer displayed.

– You can also press STOP 9 to cancel your play mode.

Programming track numbers

Program in the STOP position to select and store your CD tracks in the desired sequence. If you like, store any track more than once. Up to 20 tracks can be stored in the memory.

1. Use the SEARCH ∞ or § to select your desired track number.

2. Press PROG.

™ Display: ™ If you attempt to program without first selecting a track

3. Repeat steps 1-2 to select and store all desired tracks.

™ is displayed if you attempt to program more than

4. Press PLAY•PAUSE 2; to start playback of your CD program.

PROGRAM and the selected track number

appears briefly. number, is shown.

20 tracks.

CD PLAYER

English

SHUFFLE

ALL

•

• •

• S E

PROGRAM

T L

PROG.

• • •

Reviewing the program

In the stop position, press and hold down PROG for a while until the display shows all your stored track numbers in sequence.

CD PLAYER CASSETTE RECORDER

PAUSE

I C

T A

S E

Erasing a program

You can erase the program by:

English

– pressing STOP 9 once in the STOP position; – pressing STOP 9 twice during playback; – pressing the CD door open; – switching to another source: TAPE/TUNER.

• The display shows ' ' briefly.

CD player and CD handling

• The lens of the CD player should never be touched!

• If the CD player cannot read CDs correctly, use a commonly available cleaning CD to clean the lens before taking the set to repair. Other cleaning methods may destroy the lens.

• Sudden changes in the surrounding temperature can cause condensation to cloud over on the lens of your CD player. Playing a CD is then not possible. Do not attempt to clean the lens but leave the set in a warm environment until the moisture evaporates.

• Always keep the CD compartment closed to avoid dust on the lens.

• To take a CD out of its box, press the center spindle while lifting the CD. Always pick up the CD by the edge and return the CD to its box after use to avoid scratching and dust.

• To clean the CD, wipe in a straight line from the center towards the edge using a soft, lint-free cloth. Do not use cleaning agents as they may damage the disc.

• Never write on a CD or attach any stickers to it.

CASSETTE PLAYBACK

1. Select TAPE source.

™ The display shows throughout tape operation, and the

function indication lights up.

2. Press STOP•OPEN 9/ to open the cassette door.

3. Insert a recorded cassette and close the cassette door.

4. Press PLAY 1 to start playback.

5. To pause playback, press PAUSE;. To resume, press the key

again.

6. By pressing SEARCH 5 or 6 fast winding of the tape is possible in both directions.

7. To stop the tape, press STOP•OPEN 9/.

– The keys are automatically released at the end of the tape and

the indication and function light go out, except if PAUSE ; has been activated.

+ 30 hidden pages
