Philips AZ1013 User Manual
AZ1008
AZ1008
CD Sound Machine
• Dynamic bass boost
• 19-track programmable
• Repeat one/ all
• CD synchro start recording
Standard product information
Compact disc player
• Top loader
• 19 Track CD programme
• Repeat function
• CD next/previous track search
• CD music search
• CD synchro start recording
Cassette deck
• Single stereo cassette deck
• Normal tape type
• Full auto stop
• Automatic recording level control
Tuner
• Analogue tuning
• Wavebands /17 FM stereo/AM
• Frequency ranges FM 87.5 - 108 Mhz
AM 530 - 1710 kHz
(/17)
• Telescopic aerial for FM reception
• Ferroceptor for AM reception
Display
• 2 digit LCD display
Sound system
• Output power 2 x 1.0 W RMS
Dynamic bass boost
• 2 x 4” Speakers
• Metal speaker grilles
• Front rotary volume control
Power supply
• AC/DC Operation
• Batteries 6 x 1.5V,R14 cells
General
• Dimensions product 400 mm W x 173 mm H
x 240 mm D
• Packaging dimensions 470 mm W x 211 mm H
x 260 mm D
• Weight of product 2.75 kg
• Weight including
packaging 3.5 kg
Power supplies
• /00,/05, /14 230V,50Hz
• /17 120 V,60 Hz
• /01,/11, /16 120/230 V ,50 Hz
Bass reflex speaker system
Acoustic system that enhances the upper bass tones
to provide a warmer,punchier bass sound.
Dynamic bass boost
Enhances bass tone frequencies to give deep,rich
sounds.
19-track programmable
Stores up to 20 of your favourite CD tracks for playing
back in your order of preference.
Repeat one/ all
Repeats the current track,the total CD,or your preselected programme.
CD synchro start recording
Synchronises the start of a recording on audio cassette
with the start of a CD at the touch of a button.
Analogue tuner
Ferroceptor AM antenna
Built-in ferrite bar antenna for excellent AM reception.
Telescopic FM antenna
Extendible FM antenna for excellent FM reception.
Stereo cassette deck
Play back recorded tapes on this full-functional stereo
cassette deck, and record from the built-in CD player
or tuner.
4” Full-range speakers
For excellent sound performance across the entire
audio frequency spectrum.
AC/DC operation
Operates either on batteries or mains supply,using the
detachable AC power cord.
Metal mesh speaker grilles
Perforated,anodized grilles protect the speaker
components.
Two-digit LCD display
Displays CD track numbers and play modes like
Repeat,and CD programme.
Printed in Hong Kong 2000-12-01
Specifications subject to modification
without notice
© 2000 Koninklijke Philips Electronics N.V.
All rights reserved
http://www.philips.com
CD Sound Machine
AZ1008
AZ1008
