Philips
Portable CD Player
AX7201
Super sllim and ultra lite
Super-slim and ultra-light, radiating innovation and elegance the AX7201 Portable CD
player is one of the sleekest in the world with 72 hours battery playtime. This player
boasts a high-tech magnesium casing for unsurpassed durability.
Super slim and ultra lite
• Magnesium alloy die-cast technology for ultra light set
Easy to use
• Wearable joystick LCD remote control for total control
Extra long battery playing time
• Continously play CD for 72-hour without change battery
Jogproof
• 45-second ESP™
Rich and clear sound
• Digital Dynamic Bass Boost for optimized bass at any volume
• Digital conversion technoogy ensures crystal clear sound
Portable CD Player
AX7201/13
Specifications
Sound
• D/A converter: 1-bit
• Output Power: 2 x 5mW RMS
• Sound Enhancement: Digital Dynamic Bass Boost
• Signal to noise ratio: > 85dB
• Frequency response: 20 - 20 000 Hz
• Acoustic Feedback
• Volume Control: digital
Audio Playback
• Playback Media: CD, CD-R, CD-RW
• Disc Playback Modes: 30-Track Programmable,
Fast Forward/Backward, Repeat Play, Shuffle Play,
Introscan, Hold, Resume Playback from stop
• Electronic Skip Protection(CD): 45
Convenience
• Indications: ESP, volume, battery status, time, DBB,
Cd functions, track
• Remote control: Wearable LCD remote control
• Display Type: LCD
Power
• Battery type: AA, LR6, UM3
• Battery Playing Time CD: 72h(2xAA+2
recharg.batteries)
• Kind of Battery: Rechargeable
• Rechargeable
Connectivity
• DC in: 4.0 mm, 4.5V, centre +
• Headphone: 3.5 mm
•Line-out: 3,5 mm
Accessories
• AC/DC Adaptor: AY3170(300mA)
• Batteries: 2x AY3364(gum)
• Headphones: SBC HE570/77S
• Included accessories: User Manual
• External Battery Pack: AY3380(AA/LR6/UM3)
Dimensions
• Master carton dimensions: 188 x 166 x 0 mm
• Master carton weight: 2.2 kg
• Packaging type: D-box
• Product dimension (WxDxH) inch:
130x134x14.3mm
• Master carton quantity: 3
• Product weight: 0.122 kg
• Ebox dimensions (W x H x D): 150 x 0 x 0 mm
• Materials: Magnesium alloy(CD door)
• Packaging dimensions (W x H x D):
150
x 56 x 240 mm
•
Highlights
Magnesium alloy die-cast tech
Magnesium alloy die-cast technology for ultra light
set
Wearable LCD remote control
Wearable joystick LCD remote control for total
control
Up to 72-hour playback
Continously play CD for 72-hour without change
battery
45-second ESP™
Electronic Skip Protection is a convenient feature
that ensures skip-free music even when your CD
player is subjected to knocks and jolts while you're
jogging or on the move. Devices with Electronic Skip
Protection have an intelligent electronic buffer that
adjusts both its contents and laser spin speeds
automatically to guarantee uninterrupted music
listening.
Digital Dynamic Bass Boost
Digital Dynamic Bass Boost is an intelligent bass
booster that delivers maximum bass enhancement at
high volumes without sound distortion and at low
volumes without compromising on bottom-end bass
frequencies. Technologically advanced electronics
constantly monitor volume and bass levels, precisely
calibrating both to prevent sound distortion, thus
producing optimized bass. Digital Dynamic Bass
Boost enables the enjoyment of superb bass
performance - regardless of the chosen volume level.
1-Bit D/A converter
Digital conversion technoogy ensures crystal clear
sound
Play CDs, CD-R and CD-RW
Philips is known for making products which are
compatible with many discs available in the market.
This audio system lets you enjoy music from
CD,CD-R and CD-RW. CD-RW (CD-Rewritable
Compatible) means that your audio system can play
both CD-Recordable (CD-R) and CD-Rewritable
(CD-RW) discs. CD-R discs are recordable once and
can be played on any audio CD player while CD-RW
discs can be recorded and rewritten multiple times
and can only be played back on compatible audio CD
players.
Built-in recharge capability
Use built-in circuit to charge rechargable batteirs
ECO-PLUS rechargable batteries
ECO-PLUS Ni-MH rechargabel batteries supplied
Issue date 2014-02-10
Version: 1.0.3
12 NC: 9073 101 00844
EAN: 87 10895 78840 3
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
