Page 1
Philips
wireless speaker dock
for Android
Bluetooth
AS860
Stream your music and charge
your Android phone
Dock to charge your Android phone and enjoy the sensational sound quality of the
AS860 docking speaker. For added convenience, One-Touch with NFC-enabled
smartphones for Bluetooth pairing and easy music streaming.
Crystal clear sound
• Wireless music streaming via Bluetooth
• High fidelity wireless Bluetooth®-aptX® music streaming
• Digital Sound Processing for lifelike sound without distortion
• Bass Reflex Speaker System delivers a powerful, deeper bass
• Audio-in for easy portable music playback
Easy to use
• Smartly designed FlexiDock to fit any Android phone
• Charge second mobile device via USB port
Advanced versatility
• One-Touch with NFC-enabled smartphones for Bluetooth pairing
• Easy Bluetooth pairing Widget for Android phones
• Built-in rechargeable battery for even better portability
Page 2
Wireless speaker dock
for Android Bluetooth
Highlights
AS860/10
NFC technology
Pair Bluetooth devices easily with one-touch
NFC (Near Field Communications)
technology. Just tap the NFC-enabled
smartphone or tablet on the NFC area of a
speaker to turn the speaker on, start
Bluetooth pairing and begin streaming music.
FlexiDock
The improved version of Philips FlexiDock
features a micro
any Android phone. The docking mechanism is
a great fit for any Android phone, thanks to the
smooth and rounded edge design of the
connector. It offers maximum adjustability.
Simply slide the connector left or right, or
rotate it to fit any location or orientation of
the Micro USB port on your phone. This
extreme flexibility is the first of its kind,
catering to Android phones that are made by
different manufacturers with no standardised
position and orientation for the micro USB
connector.
Wireless music streaming
USB connector, perfect for
smartphones, tablets or even laptops. So you
can enjoy your favourite music and sound from
videos or games wirelessly.
Bluetooth®-aptX® streaming
With advanced technology, sound streamed
via Blue
tooth® is brought to the next level.
Standard Bluetooth® audio uses an SBC codec
that is built for basic audio transmission,
leaving listeners sometimes disappointed and
dissatisfied. The Philips speaker, however, is
armed with high fidelity Bluetooth®-aptX®
wireless technology — giving you rich,
powerful and crystal clear sound. Compatible
with the latest Android™ smartphones, tablets
and other devices, Philips now delivers the
audio quality you have come to expect.
Wireless music never sounded this good.
Easy Bluetooth pairing Widget
Available for download from Google Play, the
Phili
ps Bluetooth Audio Connect widget allows
you to connect and pair your mobile device to
any Philips Bluetooth audio device easily. Tap
the widget to automatically add, pair and
connect to any Philips Bluetooth audio device.
Once paired, you can also rename and change
the icons. This widget allows you to have
several Philips audio devices, making it easy for
you to switch between different Bluetooth
devices easily. Simply tap to select your desired
Philips audio device and start streaming.
Digital Sound Processing
Processing technology optimises the
performance of compact speaker boxes,
delivering sound that is clear, detailed and
powerful without any distortion.
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep
b
ass experience from a compact loudspeaker
box system. It differs from a conventional
loudspeaker box system in the addition of a
bass pipe that is acoustically aligned to the
woofer to optimise the low frequency roll-off
of the system. The result is deeper controlled
bass and lower distortion. The system works
by causing the air mass in the bass pipe to
vibrate like a conventional woofer. Combined
with the response of the woofer, the system
extends the overall low frequency sounds to
create a completely new dimension of deep
bass.
AUDIO-IN (3.5 mm)
Make one easy connection and enjoy all your
music from portable devices and computers.
Simply plug your device into the AUDIO-IN
(3.5 mm) port on your Philips set. With
computers,
from the headset output. Once linked, you can
enjoy your entire music collection directly, on
a set of superior speakers. Philips simply
delivers better sound.
the connection is typically made
Bluetooth is a short range wireless
communication technology that is both robust
and energy-efficient. The technology allows
easy wireless connection to iPod/iPhone/iPad
or other Bluetooth devices, such as
Advanced sound processing technology
enhances the reproduction of your music so
that each note resonates with crystal-clear
accuracy, and each pause is sealed with pristine
silence. Philips' proprietary Digital Sound
Page 3
Wireless speaker dock
for Android Bluetooth
Specifications
AS860/10
Compatibility
• micro USB connector: for charging all Android
phones
• music streaming via Bluetooth: iPad 1, iPad 2, new
Pad mini, iPad with Retina display, iPhone 3,
iPad, i
iPhone 3GS, iPhone 4, iPhone 4S, iPhone 5, iPod
touch 3rd gen. or later, Android phones and
tablets, other Bluetooth-enabled device
• work with: Bluetooth 4.0 or below
Sound
• Output power (RMS): 20 W
• Sound System: Stereo
• Volume Control: Volume Control up/down
Loudspeakers
• Speaker drivers: 2 x 3" full range woofers
Connectivity
• Bluetooth version: 2.1
• Bluetooth profiles: A2DP, AVRCP, SPP
• Bluetooth range: line of sight, 10 m or 30 ft
• NFC: for Bluetooth pairing
• Support Bluetooth aptX: streaming
• Audio in (3.5 mm)
Dimensions
• Product dimensions (WxDxH): 325 x 115 x
117 mm
• Weight incl. Packaging: 2.5 kg
•Product weight: 2 kg
• Packaging dimensions (WxDxH): 358 x 166 x 196
mm
Power
• Power supply: 100-240 VAC, 50/60 Hz, Battery
• Battery type: Li-ion (built-in)
• Operating time on battery: 8 hr
•
Issue date 2013-10-23
Version: 2.0.5
12 NC: 8670 001 03621
EAN: 08 71258 16904 96
© 2013 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
