Page 1

AP2266

User manual

Page 2

Page 3

10 Notices 21

Electromagnetic elds (EMF) 21 Recycling 22

Contents

1 Important 4

2 Your air purier 7

Product overview 7 Controls overview 8

3 Getting started 9

Installing the lter 9

4 Using the air purier 10

Understanding the air quality

light 10 Turning on and o 10 Changing the fan speed 11 Daylight sensor 12 Night sensing mode 12 Using the lock function 13

5 Cleaning 14

Cleaning the body of the air

purier 14 Cleaning the air quality sensor 14 Cleaning the pre-lter 15

6 Replacing the lter 17

Filter replacement indicator 17 Replacing the lter 17

7 Storage 18

8 Troubleshooting 19

9 Guarantee and service 21

Order parts or accessories 21

3EN

Page 4

service center authorized by Philips, or similarly qualified persons in order to avoid a hazard.

• Do not use the appliance

if the plug, the power cord, or the appliance itself is damaged.

• This appliance can be

used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Child shall not play with the appliance. Cleaning and maintenance shall not be made by children without supervision.

• Do not block the air inlet

and outlet, e.g. by placing items on the air outlet or in front of the air inlet.

• Make sure that foreign

objects do not fall into the appliance through the air outlet.

1 Important

Read this user manual carefully before you use the appliance, and save it for future reference.

Danger

• Do not let water or any

other liquid or flammable detergent enter the appliance to avoid electric shock and/or a fire hazard.

• Do not clean the

appliance with water, any other liquid, or a (flammable) detergent to avoid electric shock and/ or a fire hazard.

• Do not spray any

flammable materials such as insecticides or fragrance around the appliance.

Warning

• Check if the voltage

indicated on the appliance corresponds to the local power voltage before you connect the appliance.

• If the power cord is

damaged, you must have it replaced by Philips, a

4 EN

Page 5

an air conditioner to prevent condensation from dripping onto the appliance.

• Make sure all filters

are properly installed before you switch on the appliance.

• Only use the original

Philips filters specially intended for this appliance. Do not use any other filters.

• Combustion of the filter

may cause inreversible human hazard and/or jeopardize other lives. Do not use the filter as fuel or for similar purpose.

• Avoid knocking against

the appliance (the air inlet and outlet in particular) with hard objects.

• Always lift or move the

appliance by the handle on back side of the appliance.

• Do not insert your fingers

or objects into the air outlet or the air inlet to prevent physical injury or malfunctioning of the appliance.

Caution

• This appliance is not

a substitute for proper ventilation, regular vacuum cleaning, or use of an extractor hood or fan while cooking.

• If the power socket used

to power the appliance has poor connections, the plug of the appliance becomes hot. Make sure that you plug the appliance into a properly connected power socket.

• Always place and use the

appliance on a dry, stable, level, and horizontal surface.

• Leave at least 20cm free

space behind and on both sides of the appliance and leave at least 30cm free space above the appliance.

• Do not place anything on

top of the appliance.

• Do not sit or stand on

the appliance. Sitting or standing on the appliance may lead to potential injuiry.

• Do not place the

appliance directly below

5EN

Page 6

• Do not use the appliance

in wet surroundings or in surroundings with high ambient temperatures, such as the bathroom, toilet, or kitchen.

• The appliance does

not remove carbon monoxide (CO) or radon (Rn). It cannot be used as a safety device in case of accidents with combustion processes and hazardous chemicals.

• If you need to move the

appliance, disconnect the appliance from the power supply first.

• Do not move the

appliance by pulling its power cord.

• Always wash your hands

thoroughly after changing or cleaning a filter.

• Do not use this appliance

when you have used indoor smoke-type insect repellents or in places with oily residues, burning incense, or chemical fumes.

• Do not use the appliance

near gas appliances, heating devices or fireplaces.

• Always unplug the

appliance after use and before cleaning, or carrying out other maintenance or replacing the filters.

• Do not use the appliance

in a room with major temperature changes, as this may cause condensation inside the appliance.

• To prevent interference,

place the appliance at least 2 meters away from electrical appliances that use airborne radio waves such as TVs, radios, and radio-controlled clocks.

• The appliance is only

intended for use under normal operating conditions.

6 EN

Page 7

2 Your air purifier

Congratulations on your purchase, and welcome to Philips!

To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.

Product overview

A Control panel

B Air quality light

C Air outlet

D Air quality sensor

Professional NanoProtect filter series 2000B (AP2026)

F Pre-filter

G Air inlet

H Front panel

7EN

Page 8

Controls overview

I On/Off button

J Healthy sleep mode button

K Display screen

L Fan speed button

M Lock button

I J K L M

8 EN

Page 9

3 Remove the filter.

4 Remove all packaging materials

from the filter.

5 Place the filter (AP2026) into the air

purifier.

3 Getting started

Installing the lter

Note

• Make sure the air purifier is unplugged

from the electrical outlet before installing the filter.

• Make sure the side of the filter with the

tag is pointing towards you.

1 Pull the bottom part of the front

panel to remove it from the air purifier.

2 Press the two clips down (1) and

pull the pre-filter towards you (2).

9EN

Page 10

4 Using the air

purifier

Understanding the air quality light

Air quality light color

Air quality level

Blue

Good

Blue-violet

Fair

Red-purple

Poor

Red

Very poor

The air quality light automatically goes on when the air purifier is switched on, and lights up all colors in sequence. After approximately 30 seconds, the air quality sensors select the color that corresponds to the surrounding air quality of airborne particles.

Turning on and o

Note

• Always place the air purifier on a

stable, horizontal, and level surface with the front of the unit facing away from walls or furniture.

• For optimum purification performance,

close doors and windows.

• Keep curtains away from the air inlet or

air outlet.

1 Put the plug of the air purifier in the

wall outlet.

6 Attach the pre-filter back into the

air purifier.

Note

• Make sure the side with the clip is

pointing towards you, and that all hooks of the pre-filter are properly attached to the purifier.

7 Reattach the front panel by

pressing the top part of the panel onto the top of the air purifier (1). Then, gently push the panel against the body of the air purifier (2).

8 Wash your hands thoroughly after

installing filters.

10 EN

Page 11

Changing the fan speed

There are several fan speeds available. You can choose the auto mode, speed

1, 2, 3 or turbo mode (t).

Auto(A)

• Touch the fan speed button

repeatedly to select the auto mode.

Allergen mode

The specially designed allergen mode can effectively reduce common allergens such as pollen and pet dander.

• Touch the fan speed button to

select the Allergen mode.

» Auto (A) and display on the

screen.

2 Touch to switch on the air purifier.

» The air purifier beeps.

» The air purifier operates under

the auto mode by default.

» After measuring the air

quality for approximately 30 seconds, the air quality sensor automatically selects the appropriate air quality light color.

3 Touch and hold for 3 seconds to

switch off the air purifier.

Note

• If the air purifier stays connected to

the electrical outlet after turning OFF, the air purifier will operate under the previous settings when turned ON again.

• If the air purifier accidentally shuts off

during running, it restarts automatically and operates under previous settings when the power supply is resumed.

11EN

Page 12

Daylight sensor

With the daylight sensor, the air purifier can work according to the ambient light

10 seconds later after the ambient light dimmed, all the lights on the control panel will be go off slowly. During this period, you can touch any of the buttons, all lights will be on again. If you don't perform other operations within 10 seconds, all lights will go off again.

If the ambient light becomes bright and lasts for at least 10 seconds, all light will be on.

Night sensing mode

You can activate the night sensing mode in two ways.

Activating the night sensing mode manually

• Before you go to sleep, touch

manually to activate the night sensing mode.

» If the air quality light is blue,

the air purifier directly goes to the night sensing mode. The air purifier operates quietely and the air quality light will be dimmed.

Manual

• Touch the fan speed button

repeatedly to select the fan speed you need.

Turbo (t)

In turbo mode, the air purifier operates on the highest speed.

• Touch the fan speed button to select the turbo mode (t).

12 EN

Page 13

Using the lock function

1 Touch and hold the lock button

for 3 seconds to activate lock

function.

» The lock icon displays on the

screen.

» When the lock is on, all

the other buttons are not responsive, only icon blinks.

2 Touch and hold the lock button

for 3 seconds again to deactivate lock function.

» The lock icon disapears from

the screen.

Note

• The lock function is automatically

unlocked when the pre-filter cleaning code or the filter replacement code displays on the screen.

» If the air quality light is not blue,

the air purifier operates under turbo mode for a maximum of 10 minutes, the air quality light blinks slow during this time, and then goes to the night sensing mode.

Auto activating the night sensing mode

• If the air purifier operates in auto

mode or allergen mode, when the daylight sensor detects the lights in your room are turned off, the air purifier goes to the night sensing mode automatically.

Note

• The daylight sensor detects the lights

in your room after 11 hours in the night sensing mode.

• If the lights in your room are turned

on, the air purifier will quit the night sensing mode and operate under the previous mode. The air quality light and the display will be on again.

• To exit the night sensing mode

manually, touch or button.

13EN

Page 14

Cleaning the air quality sensor

Clean the air quality sensor every 2 months for optimal functioning of the purifier.

Note

• If the air purifier is used in a dusty

environment, it may need to be cleaned more often.

• If the humidity level in the room is

very high, condensation may develop on the air quality sensor and the air quality light may indicate a more poor air quality even though the air quality is actually good. If this occurs, clean the air quality sensor or use the air purifier on a manual speed setting.

1 Switch off the air purifier and

unplug from the wall outlet.

2 Clean the air quality sensor inlet

and outlet with a soft brush.

5 Cleaning

Note

• Always turn the air purifier off and

unplug the air purifier from the electrical outlet before cleaning.

• Never immerse the air purifier in water

or any other liquid.

• Never use abrasive, aggressive, or

flammable cleaning agents such as bleach or alcohol to clean any part of the air purifier.

• Only the pre-filter is washable. The air

filter is not washable.

• Do not attempt to clean the filters or

air quality sensor with a vacuum.

Cleaning the body of the air purier

Regularly clean the inside and outside of the air purifier to prevent dust from collecting.

1 Use a soft, dry cloth to clean both

the interior and exterior of the air purifier (Especially for the front cover).

2 The air outlet can also be cleaned

with a dry, soft cloth.

3 Detach the front cover from the air

purifier, wash the front cover under running tap water, and then air dry it.

14 EN

Page 15

Cleaning the pre-lter

Clean the pre-filter when F0 is displayed on the screen.

1 Switch off the air purifier and

unplug from the wall outlet.

2 Pull the bottom part of the front

panel to remove it from the air purifier.

3 Press the two clips down (1) and

pull the pre-filter towards you (2).

3 Remove the air quality sensor cover.

4 Clean the air quality sensor, the

dust inlet and the dust outlet with a damp cotton swab.

5 Dry all parts thoroughly with a dry

cotton swab.

6 Reattach the air quality sensor

cover.

15EN

Page 16

Note

• Make sure the side with the two clips

is pointing towards you, and that all hooks of the pre-filter are properly attached to the air purifier.

7 To reattach the front panel, press

the top part of the panel onto the top of the air purifier (1). Then, gently push the panel against the body of the air purifier (2).

8 Put the plug of the air purifier in the

wall outlet.

9 Touch and hold the for 3 seconds

to reset the pre-filter cleaning time.

10 Wash your hands thoroughly after

installing filters.

4 If the pre-filter is very dirty, use a

soft brush to brush away the dust. Then wash the pre-filter under running tap water.

5 Allow the pre-filter to air dry

thoroughly before placing back in the air purifier.

Note

• To optimize the lifetime of the pre-

filter, make sure it dries completely after cleaning.

• Wash your hands after handling the

filter.

6 Put the pre-filter back into the air

purifier.

16 EN

Page 17

2 Take out the used air filter according

to the filter alert light status displayed on the screen. Discard used filter.

Note

• Do not touch the pleated filter surface,

or smell the filter as it has collected pollutants from the air.

3 Remove all packaging material from

the new filter.

4 Place the new filter into the air

purifier.

6 Replacing the

filter

Filter replacement indicator

This air purifier is equipped with a filter replacement indicator to make sure that the air purification filter is in optimal condition when the air purifier is operating. When the filters need to be replaced, the filter code displays on the screen.

If the filters are not replaced in 14 days, the air purifier will stop operating and automatically lock.

Replacing the lter

Note

• The air filter is not washable or

reusable.

• Always turn off the air purifier and

unplug from the electrical outlet before replacing the filter.

• Do not clean the filter with a vacuum.

Replace the filter when A3 is displayed on the screen.

1 Turn off the air purifier and unplug

from the wall outlet.

17EN

Page 18

7 Storage

1 Turn off the air purifier and unplug

from the wall outlet.

2 Clean the air purifier, air quality

sensor and pre-filter (see chapter ‘Cleaning’).

3 Let all parts dry thoroughly before

storing.

4 Wrap the filter and pre-filter

separately in air tight plastic bags.

5 Store the air purifier, the filter and

pre-filter in a cool, dry location.

6 Always thoroughly wash hands

after handling filters.

5 Put the plug of the air purifier in the

wall outlet.

6 Touch and hold the for 3 seconds

to reset the filter lifetime counter.

7 Wash your hands after changing a

filter.

18 EN

Page 19

8 Troubleshooting

This chapter summarizes the most common problems you could encounter with the air purifier. If you are unable to solve the problem with the information below, visit www.philips.com/support or contact the Consumer Care Center in your country.

Problem Possible solution

The air purier cannot be switched on.

• Make sure the front cover is properly attached to the air

purifier.

The air purier does not work even though it is plugged in to the wall outlet and switched on.

• The timer is set to a specific time interval. Reset or turn off

the timer.

• Try a different electrical outlet or check the wall switch.

• The filter alert status is displaying the filter code. Replace

the corresponding filter and reset the filter lifetime counter (see chapter "Replacing the filter").

• If the problem persists, contact the Consumer Care Center

in your country.

The air purier does not work even though it is switched on.

• The filter replacement indicator has been on continuously

but you have not replaced the corresponding filter, and the air purifier is now locked. In this case, replace the filter and reset the filter lifetime counter.

The air purier accidentally powers o.

• The air purifier restarts automatically and goes to the

previous mode when the power resumes.

The airow that comes out of the air outlet is signicantly weaker than before.

• The pre-filter is dirty. Clean the pre-filter (see chapter

"Cleaning").

The air quality does not improve, even though the air purier has been operating for a long time.

• One of the filters has not been placed in the air purifier or

the filter is not placed properly. Make sure that all filters are properly installed in the following order, starting with the innermost filter: 1) Professional NanoProtect filter series 2000B (AP2026); 2) pre-filter.

• The air quality sensor is wet. Make sure that the air quality

sensor is clean and dry (see chapter "Cleaning").

19EN

Page 20

Problem Possible solution

The color of the air quality light always stays the same.

• The air quality sensor is dirty. Clean the air quality sensor

(see chapter "Cleaning").

The air purier produces a unpleasant smell.

• The first few times you use the air purifier, it may produce

a plastic smell. This is normal. The air purifier may also produce an unpleasant smell when the filter is dirty. In this case, clean or replace the appropriate filter.

• If the air purifier produces a burnt odor, switch OFF and

unplug from the electrical outlet. Contact the Consumer Care Center in your country.

The air purier is loud.

• If the air purifier is too loud, change the fan speed to a

lower fan speed level. When using the air purifier in a bedroom at night, choose the night sensing mode or change the fan speed to a lower level.

The air purier still indicates that I need to replace a lter, but I already did.

• Perhaps you did not reset the filter lifetime counter. Plug

in the air purifier, touch to switch on the air purifier, and touch and hold the for 3 seconds.

Error codes "E1", "E2", "E3" or "E4" displays on the screen.

• The air purifier has malfunctions. Contact the Consumer

Care Center in your country.

20 EN

Page 21

21EN

10 Notices

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields.

Compliance with EMF

Koninklijke Philips N.V. manufactures and sells many products targeted at consumers, which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals.

One of Philips' leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable legal requirements and to stay well within the EMF standards applicable at the time of producing the products.

Philips is committed to develop, produce and market products that cause no adverse health effects. Philips confirms that if its products are handled properly for their intended use, they are safe to use according to scientific evidence available today.

Philips plays an active role in the development of international EMF and safety standards, enabling Philips to anticipate further developments in standardization for early integration in its products.

9 Guarantee and

service

If you need information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Consumer Care Center in your country (you find its phone number in the worldwide guarantee leaflet). If there is no Consumer Care Centre in your country, go to your local Philips dealer.

Order parts or accessories

If you have to replace a part or want to purchase an additional part, go to your Philips dealer or visit www.philips.com/ support.

If you have problems obtaining the parts, please contact the Philips Consumer Care Center in your country (you can find its phone number in the worldwide guarantee leaflet).

Page 22

22 EN

Recycling

Do not throw away the product with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment.

Page 23

Page 24
