AJT600/37
User manual
Contents
1 Important safety instruction 3
2 Your Bluetooth Speaker 4
What's in the box 4
Overview of the main unit 5
3 Get started 6
Connect power 6
Set time 7
Turn on 7
4 Play from Bluetooth device 7
Bluetooth reset 7
5 Play audio from an external device 8
6 Other features 8
Set alarm timer 8
Set sleep timer 9
Adjust display brightness 9
7 Product information 10
Specications 10
8 Troubleshooting 10
9 Notice 11
Disposal of your old product 11
2EN
1 Important safety
instruction
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
j Only use attachments/accessories
specied by the manufacturer.
k Use only with the cart, stand, tripod,
bracket, or table specied by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
m Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to
the unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
• The battery (batter y or batteries
installed) shall not be exposed to
excessiveheatsuchassunshine,reor
the like.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid lled objects,
lighted candles).
q This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
r Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
3 EN
Warning
• Never remove the casing of this Bluetooth speaker.
• Never place this Bluetooth speaker on other electrical
equipment.
• Keep this Bluetooth speaker away from direct sunlight,
nakedamesorheat.
• Toreducetheriskofreorelectricshock,donot
expose this apparatus to rain or moisture.
• Ensure that you always have easy access to the power
cord, plug or adapter to disconnect this Bluetooth
speaker from the power.
2 Your Bluetooth
Speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
What's in the box
Always there to help you
Register your product and get support at
www.philips.com/welcome
Question?
Contact
Philips
AJW600
Short User Manual
4EN
Overview of the main unit
e
a
b
c
d
j
a SOURCE
• Select a source.(Bluetooth/AUDIO IN)
• Press repeatedly to switch to standby mode.
b SLEEP
• Set sleep timer.
c SNOOZE/BRIGHTNESS
• Snooze alarm.
• Adjust display brightness.
d Display panel
• Show current information.
e AL1/AL2
• Activate or deactivate alarm timer.
f VOLUME +/-
• Adjust volume.
f
g
h
i
k
NI OIDUA
l
g First Knob (HOUR)
• Adjust hour.
h Second Knob (MINUTE)
• Adjust minute.
i Third Knob (CLOCK/SET TIME/SET AL1/
SET AL2)
• Set clock.
• Set alarm.
j BUZZ/SOUND 1/SOUND 2
• Select an alarm source for Alarm 1 and
Alarm 2.
k
• Charge your devices through USB
cable (not included).
l AUDIO IN
• Connect an external audio device.
5 EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Option 2: Battery power
Caution
• Batteries contain chemical substances, so they should
be disposed of properly.
Connect power
The unit can only be powered by supplied AC
power. Batteries are only used for time and
alarm backup if not connected with AC power.
Option 1: AC power
Warning
• Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back or the underside of the unit.
• Risk of electric shock! When you disconnect the AC
power, always pull the plug from the socket. Never pull
the cord.
Connect the AC power cord to the wall socket.
Tip
• To save energy, turn the unit off after use.
Note
• Batteries are not supplied with the accessories.
• bAt shows on the display when the battery level is low.
1 Open the battery compartment.
2 Insert 2 batteries (type: 1.5V LR6/AA) with
correct polarity (+/-) as indicated.
3 Close the battery compartment.
6EN
Set time
4 Play from
1 Rotate the Third Knob to "SET TIME" to
activate clock setting mode.
» Hour and minute digits blinks.
2 Rotate the First Knob to adjust the hour.
3 Rotate the Second Knob to adjust the
minute.
4 Press OK on the First Knobtoconrm.
» The setting time is displayed.
5 Rotate the Third Knob to CLOCK after
setting.
» The hour and minute digits stops
blinking.
Turn on
The clock radio turns on automatically once
your plugged in.
Bluetooth
device
Note
• The effective operation range between the Bluetooth
speaker and the paired device is approximately 10
meters (30 feet).
• Keep this Bluetooth speaker away from other electronic
devices that may cause interference.
• Make sure that the Third Knob switches to CLOCK
before setting.
1 Press SOURCE repeatedly to select
Bluetooth source.
» onthedisplaypanelashes.
2 Activate the Bluetooth function in your
Bluetooth device (see the device user
manual).
3 Select “AJT600” displayed on your device
for pairing.
» If connection is successful, the
Bluetooth speaker beeps twice and
steadily on.
4 Start music play on your Bluetooth device.
» If Bluetooth disconnected, the music
will pause. Press on the Bluetooth
device to start play again.
7 EN
Bluetooth reset
In Bluetooth mode, press OK ontherst
knob for over 5 seconds to erase all pairing
informations.
» "BT RESET" displayes on the panel.
• The Bluetooth speaker enters
Bluetooth mode automatically after
erase completed.
5 Play audio from
an external
device
6 Other features
Set alarm timer
Note
• Make sure that the Third Knob switched to CLOCK
before setting.
• The speaker can not pair with other Bluetooth devices
in AUDIO IN mode.
You can listen to audio from an external device
through this Bluetooth speaker.
1 Connect an audio cable to:
• the AUDIO IN socket on the
Bluetooth speaker.
• the headphone socket on an external
device.
2 Press SOURCE repeatedly to select the
Audio-in source.
» The on the display panel lights up.
3 Play audio on the external device (refer to
its user manual).
You can set two alarms to ring at different time.
Note
• Make sure that you have set the clock correctly.
1 Rotate the Third Knob to SET AL1 or SET
AL2 to activate alarm setting mode.
» The / and time digits blink.
2 Rotate the First Knob to adjust the hour.
3 Rotate the Second Knob to adjust the
minute.
4 Press OK on First Knobtoconrm.
5 Rotate the Third Knob to CLOCK after
setting.
Select alarm source
You can select buzzer, sound 1,or sound 2 as
your alarm sound.
ALARM
BUZZ
2
1
8EN
Activate/deactivate alarm timer
Note
• Make sure that the Third Knob switched to CLOCK
before setting.
Press AL1/AL2 to activate or deactivate the
alarm timer.
» The / appears if alarm timer is on and
disappears if it is off.
To stop the ringing alarm, press the
corresponding AL1/AL2.
» The alarm repeats ringing for the next day.
Snooze the alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing nine
minutes later.
Set sleep timer
Note
• Make sure that the Third Knob switched to CLOCK
before setting.
Adjust display brightness
This Bluetooth speaker can switch to standby
mode automatically after a preset period.
• Press SLEEP repeatedly to select the sleep
timer period (in minutes).
» When the sleep timer is activated,
appears.
To deactivate the sleep timer:
• Press SLEEP repeatedly until [OFF] (off)
appears.
15 30 60 90 120
9 EN
OFF
7 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 5W RMS
Bluetooth
Bluetooth
specication
Supportedproles HFP v1.5, AD2P v1.2,
Range 10 m (Free space)
General information
Power supply
-AC Power
-Battery
Operation Power
Consumption
Standby Power
Consumption
Dimensions - Main
Unit (W x H x D)
Weight - Main Unit 0.70 kg
V3.0+EDR
HSP v1.2
Model:
ASSA36A-090160;
Input: 100-240 V ~,
50/60Hz, 0.6A;
Output: 9.0V 1600
mA
2 x AA batteries
<15 W
<1 W
195 x 99 x 98 mm
8 Troubleshooting
Warning
• Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support). When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
No power
• Ensure that the power cord is connected
securely.
• Ensure that there is power at the power
supply socket.
• Ensure that the batteries are installed
correctly.
No response from the Bluetooth speaker
• Disconnect and reconnect the AC power
plug, then turn on the Bluetooth speaker
again.
• Check if you have selected the correct
audio source.
• Make sure that your Bluetooth device is
within the effective operation range.
Alarm does not work
• Set the clock/alarm correctly.
Clock/alarm setting erased
• Power has been interrupted or the power
plug has been disconnected.
• Reset the clock/alarm.
10EN
9 Notice
Disposal of your old product
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authority to operate the equipment.
Notice of compliance
The device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
a This device may not cause harmful
interference, and
b This device must accept any interference
received, including interference that may
cause undesired operation.
Notice for the USA
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot be
disposed of with normal household waste. Please
inform yourself about the local rules on separate
collection of batteries. The correct disposal of batteries
helps prevent potentially negative consequences on
the environment and human health.
Please visit www.recycle.philips.com for additional
information on a recycling center in your area.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old equipment.
The making of unauthorized copies of copyprotected material, including computer programs,
les,broadcastsandsoundrecordings,maybe
an infringement of copyrights and constitute a
criminal offence. This equipment should not be
used for such purposes.
Note
• The type plate is located on the bottom of the
apparatus.
11 EN
Specifications are subject to change without notice
2014 © WOOX Innovations Limited.
All rights reserved.
This product was brought to the market by WOOX Innovations Limited or one of its affiliates,
further referred to in this document as WOOX Innovations, and is the manufacturer of the
product. P&F is the warrantor in relation to the product with which this booklet was packaged.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
AJT600D_37_UM_V2.0
Loading...
