Register your product and get support at
AJH510
User manual
Contents
1 Important 2
Safety 2
2 Notice 4
Compliance 4
Care of the environment 4
Copyright 5
3 Your Alarm Clock 6
Introduction 6
What's in the box 6
Overview of the main unit 6
4 Get started 8
Connect power 8
Plug and set 8
Select time zone 8
Set clock 9
5 Main features 10
Set alarm timer 10
Listen to relaxing music 10
Enjoy mood light 11
Adjust volume 11
6 Other features 12
Set sleep timer 12
Charge your devices 12
Select daylight saving time (DST) mode 12
Adjust display brightness 13
7 Product information 14
Specications 14
8 Troubleshooting 15
1EN
1 Important
Safety
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
j Only use attachments/accessories
specied by the manufacturer.
k Use only with the cart, stand, tripod,
bracket, or table specied by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to
the unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
o The batteries (battery pack or batteries
installed) shall not be exposed to
excessive heat such as sunshine, re or
the like.
p CAUTION: Danger of explosion if
battery is incorrectly replaced. Replace
only with the same or equivalent type.
q Apparatus shall not be exposed to
dripping or splashing.
r Do not place any sources of danger on
the apparatus (e.g. liquid lled objects,
lighted candles).
s This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
t Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
2 EN
the disconnect device shall remain readily
operable.
Risk of swallowing batteries
• The product or remote control may
contain a button cell battery, which is
possible to be swallowed. Keep the battery
out of reach of children at all times! If
swallowed, the battery can cause serious
injury or death. Severe internal burns can
occur within two hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.
• If the battery compar tment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
3EN
2 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Compliance
Notice for Canada
This Class B digital apparatus complies with
Canadian ICES-003.
This device complies with Industry Canada
licence-exempt RSS standard(s): Operation
is subject to the following Two conditions:(1)
this device may not cause interference, and
(2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
Notice for the USA
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
The set complies with the FCC-Rules, Part-
15. Operation is subject to the following two
conditions:
• This device may not cause harmful
interference, and
• This device must accept any interference
received, including interference that may
cause undesired operation.
Care of the environment
Disposal of your old product and batteries
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Please visit www.recycle.philips.com for
additional information on a recycling center in
your area.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by a
4 EN
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, and old equipment.
Note
• The type plate is located on the bottom of the product.
Copyright
2013 © Koninklijke Philips Electronics N.V.
Specicationsaresubjecttochangewithout
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
5EN
3 Your Alarm
Clock
Introduction
With this alarm clock, you can:
• know the time;
• set one alarm;
• set time zone and daylight saving time;
• wake up to buzzer or music stored in the
alarm clock; and
• enjoy mood light and music.
What's in the box
Check and identify the contents of your
package:
• Main unit (with battery)
• Short user manual
Overview of the main unit
m
• Adjust display brightness.
b ALARM
• Turn alarm on/off.
• Set the alarm clock.
c LIGHT
• Turn the mood light on/off.
• Dim the brightness of the mood light.
d VOL
• Adjust music volume.
• Adjust settings.
e Power cord
f LIGHT•COLOR
• Select a color of the mood light.
g TIME ZONE •SET TIME
• Select time zone.
• Set time.
h BATTERY
• Replace battery.
i 12/24H·DST
• Select 12/24 hour format.
• Activate or deactivate daylight saving
time (DST) function.
a
b
l
k
a SNOOZE/BRIGHTNESS
• Snooze alarm.
6 EN
ji hgf
c
d
e
j MUSIC•TUNES
• Select music tracks.
k USB Charging socket
• Charge an external device through
USB cable.
l MUSIC
• Activate or deactivate music.
m SLEEP
• Turn the sleep timer on/off.
• Set sleep timer.
7EN
4 Get started
Always follow the instructions in this chapter in
sequence.
Connect power
Caution
• Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the alarm clock.
• Risk of electric shock! When you unplug the AC
adapter, always pull the plug from the socket. Never
pull the cord.
Note
• The type plate is located on the bottom of the alarm
clock.
Connect the AC adapter to the wall outlet.
Replace battery
Note
• You can only use AC power as power supply. The pre-
installed lithium CR2032 battery can only back up clock
and alarm settings.
• When power is disconnected, the display backlight is off.
Tip
• Remove the battery if the alarm clock will not be in use
for a long period of time.
Plug and set
Time has been preset at the factory. When
power is connected, the set time is displayed
automatically.
The built-in lithium battery can maintain clock
setting despite power interruption.
Select time zone
If the hour digits of the preset time do not
match your local time, you need adjust the time
zone settings.
1 In standby mode, press TIME ZONE.
» The current time zone number blinks
on the display panel.
2 Rotate VOLUME +/- to select time zone
(-10 to -4 adjustable).
3 Press TIME ZONEtoconrmthesetting.
When the low battery indicator is displayed,
replace the battery as illustrated.
8 EN
For USA and Canada:
Atlantic Standard Time -4
Eastern Standard Time -5 (De-
fault)
Central Standard Time -6
Mountain Standard Time -7
PacicStandardTime -8
Yukon Standard Time -9
Hawaiian Standard Time -10
Set clock
In standby mode, you can set the clock manually.
1 Press and hold SET TIME for 2 seconds..
» The hour digits blink.
2 Rotate VOLUME +/- to set the hour.
3 Press SET TIMEtoconrm.
» The minute digits blink.
4 Rotate VOLUME +/- to set the minute.
5 Press SET TIMEtoconrm.
» The [12H] or [24H] begins to blink.
6 Rotate VOLUME +/- to select [12H] or
[24H] for 12 or 24 hour format.
7 Press SET TIMEtoconrm.
» The set time is displayed.
Tip
• You can also press 12/24H·DST repeatedly to select
12/24 hour format.
9EN
5 Main features
Set alarm timer
Activate/deactivate the alarm timer
Press ALARM repeatedly.
» The alarm icon appears if the alarm
timer is on and disappears if it is off.
Note
• Make sure that you have set the clock correctly.
1 In standby mode, press and hold ALARM
for 2 seconds to activate alarm setting.
» The hour digits blink.
2 Rotate VOLUME +/- to adjust hour.
3 Press ALARMtoconrm.
» The minute digits blink.
4 Repeat steps 2-3 to set the minute.
5 Repeat steps 2-3 to select an alarm source.
• BUZ and
alarm sound.
icon: select buzzer as
• Nx (1-5) and icon: select one from
theveprestoredsoundsasalarm
sound.
6 Repeat steps 2-3 to set the alarm volume.
» The alarm time and icon are displayed.
Theveprestoredsoundsarelistedbelow:
n1 Bell
n2 Jungle
n3 Bird
n4 Wake music 1
n5 Wake music 2
Snooze alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing nine
minutes later.
Listen to relaxing music
With this alarm clock, you can get relaxed by
listening to realistic nature sounds and soft
music.
1 In standby mode, press MUSIC to activate
sounds stored in the alarm clock.
• To stop playing the music, press
MUSIC again.
2 Press MUSIC•TUNES repeatedly to select
a sound.
10 EN
The 15 sounds are listed as follows:
Sound
sequence
1 Rain
2 Thunderstorm
3 Stream
4 Ocean
5 Night forest
6
7 Wind
8 Wind chime
9 Train
10 Space
11 Heartbeat
12 White noise
13 Sleep music 1
14 Sleep music 2
15 Sleep music 3
Sound name
Wildre
2 Press LIGHT repeatedly to set the
brightness of the mood light: hi, low or off.
To select a color of the mood light:
Press LIGHT•COLOR repeatedly to select a
color.
Adjust volume
Enjoy mood light
This alarm clock provides you with changeable
mood light. You can adjust the color of the light
to match your mood.
To turn the mood light on or off:
1 In standby mode, press LIGHT to turn the
mood light on.
Rotate VOLUME +/- to adjust volume.
11EN
6 Other features
Set sleep timer
This alarm clock can switch to standby mode
automatically after a preset period.
Press SLEEP repeatedly to select the sleep
timer period (in minutes).
» When the sleep timer is activated,
appears.
To deactivate the sleep timer, press SLEEP
repeatedly until [OFF] (off) appears.
15 30 60 90 120
Charge your devices
With this alarm clock, you can charge your
external devices, such as your cell phone, MP3
player or other mobile devices.
1 Use a USB cable to connect the USB
OFF
charging socket of the alarm clock with the
USB socket of your devices.
2 Connect the alarm clock to power.
» Once the device is recognized, the
charging starts.
Note
• Philips does not guarantee the compatibility of this
product with all devices.
• The USB charging port is for charging only.
Select daylight saving time
(DST) mode
For countries with daylight saving time (DST),
the alarm clock offers you DST option to adjust
summer time.
In standby mode, press and hold 12/24H·DST
for two seconds.
» DST appears on the display panel.
» The clock advances by one hour.
Note
• To exit DST mode, repeat the above operation.
12 EN
Adjust display brightness
Press BRIGHTNESS repeatedly to select
different brightness levels: high, mid, and low.
13EN
7 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Speaker
Speaker Impedance 8 ohm
Speaker Driver 1.5''
General information
AC Power Model: AS060-050-
EA120
Input: 100-240 V~,
50/60 Hz; 0.15A
Operation Power
Consumption
Standby Power
Consumption
Dimensions
- Main Unit (W x H
x D)
Weight
- With Packing
- Main Unit
Output: 5.0 V
1.2 A
5 W
<1 W
144 x 144 x 65 mm
0.73 kg
0.45 kg
14 EN
8 Troubleshooting
Warning
• Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support). When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
No power
• Ensure that the power plug is connected
properly.
• Ensure that there is power at the AC
Mains.
• Ensure that the batteries are inserted
correctly.
No response from the alarm clock
• Disconnect and reconnect the AC power
plug.
Alarm does not work
• Set the clock/alarm correctly.
Clock/alarm setting erased
• Power has been interrupted or the power
plug has been disconnected.
• Reset the clock/alarm.
15EN
Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved. AJH510_37_UM_V1.0
Loading...
