Philips AJB4500/05 Quick Start Guide

3

Enjoy

Local scan (in the UK):

1 In DAB mode, press SCAN.

The clock radio scans all available local

»

DAB radio stations and broadcasts the
fi rst available station.

Program DAB radio stations

You can program a maximum of 20 preset DAB
radio stations.

1 Tune to a DAB radio station.

2 Press PRESET5∞ to select a preset

number.

3 Press and hold SELECT for two

seconds.

The preset number of the saved station

»

appears.

Listen to a preset DAB radio station

1 Press SOURCE repeatedly to select

[DAB].

2 Press PRESET5∞ to select a preset

number.

© Royal Philips Electronics N.V. 2008

All rights reserved.

Specifi cations are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

Printed in China PDCC-2008

Welcome to Philips!

Register your product and get support at
www.philips.com/welcome

Quick start guide

Connect

1

Setup

2

Enjoy

3

DAB CLOCK RADIO

AJB4500

What’s in the box

AJB4500

Quick Start Guide

Quick Start Guide

User Manual

User Manual

Eng

1

Connect

2

Setup

2

Setup

3

Enjoy

Prepare FM/DAB antenna

A

Connect power

B

Socket

1 Fully extend the antenna and fi x it to the

wall as shown.

1 Connect the power plug to the power

outlet.

Set the clock

A

1 In standby mode, press and hold

SELECT for two seconds.

[SYNC ON] is displayed and [ON]

»

begins to blink.

2 Press PRESET5∞ to select ON or

OFF.

If you select [ON], the Clock Radio

»

reads the DAB/RDS time and sets the
clock automatically.

If you select [OFF], the Clock Radio

»

turns off the time synchronization.

3 Press SELECT to confi rm.

The time format [24H] or [12H]

»

begins to blink.

4 Press PRESET5∞ to select 24H or

12H.

5 Press SELECT to confi rm.

The hour digits are displayed and

»

begin to blink.

6 Press PRESET5∞ to set the hour.

7 Press SELECT to confi rm.

The minute digits are displayed and

»

begin to blink.

8 Press PRESET5∞ to set the minute.

9 Press SELECT to confi rm the clock

setting.

Note

D

The accuracy of the transmitted time depends

•

on the RDS station that transmits the time
signal.

•

If the power supply is disconnected, the set­tings and clock are saved for three minutes.

Set the alarm timer

B

1 Press and hold AL1/AL2 for two

seconds.

The sound source icon, AL1/AL2 icon

»

and the hour digits are displayed and
begin to blink.

2 Press SOURCE repeatedly to select a

sound source: DAB, FM Tuner or Buzzer.

3 Press PRESET5∞ to set the hour.

4 Press AL1/AL2.

The minute digits are displayed and

»

begin to blink.

5 Press PRESET5∞ to set the minute.

6 Press AL1/AL2 to confi rm.

The alarm icon is displayed.

»

The Clock Radio turns on

»

automatically at the set time and
switches to the selected source.

Turn on/off the alarm timer

1 Press AL1/AL2 to turn on or off the

alarm timer.

If the alarm timer is turned on, the

»

alarm icon appears.
If the alarm timer is turned off, the

»

alarm icon disappears.

Repeat alarm

1 When the alarm sounds, press

BRIGHTNESS CONTROL/
REPEAT ALARM.

The source icon and the alarm icon

»

begin to blink.

The alarm stops for nine minutes.

»

Reset alarm

1 When the alarm sounds, press SLEEP/

AL RESET.

The alarm stops but the alarm

»

settings retain for the next day.

Stop alarm sound

1 When the alarm sounds, press AL1/

AL2.

The alarm stops but the alarm

»

settings remain.

Listen to FM radio

A

1 Press SOURCE repeatedly to select

[FM--TUNER].

2 Press TUNING

station.

Program radio stations automatically

You can program a maximum of 20 preset radio
stations.

1 Press and hold SCAN for two seconds.

[FM SCAN] appears.

»

All available stations are programmed

»

in the order of waveband reception
strength.

The fi rst programmed radio station

»

broadcasts automatically.

to tune to a radio

2 3

Listen to a preset radio station

1 Press SOURCE repeatedly to select

[FM--TUNER].

2 Press PRESET5∞ to select a preset

number.

Listen to DAB digital radio

B

1 Press SOURCE repeatedly to select

[DAB].

When you enter the DAB mode for the

»

first time, the Clock Radio automatically
scans DAB radio stations. The Clock Radio
stores all available DAB radio stations and

the fi rst available station broadcasts.
The last selected DAB radio station

»

broadcasts automatically.

Scan DAB radio stations automatically

Full scan (outside the UK):

1

In DAB mode, press and hold SCAN for
more than two seconds.

The clock radio scans all available DAB

»

radio stations and broadcasts the fi rst
available station.
