Register your product and get support at
AE2330
EN User manual
FR Mode d’emploi
ES Manual del usuario
1
32
a
b
c
f
e
d
+
_
_
+
_
+
+
_
+
_
+
_
English
Register online at www.philips.com/welcome today to
get the very most from your purchase.
*Product Safety Notification *Additional Benefits
By registering your product, you'll receive notification - directly
from the manufacturer.
Registering your product guarantees that you'll receive all of
the privileges to which you’re entitled, including special moneysaving offers.
For Customer Use
Enter below the Serial No. which is located on the rear of the cabinet. Retain this
information for future reference.
Model No.__________________________
Serial No. ________________________
This “bolt of lightning” indicates unin-
sulated material within your unit may
cause an electrical shock. For the safety of
everyone in your household, please do not
remove product covering.
The “exclamation point” calls atten-
tion to features for which you should
read the enclosed literature closely to prevent operating and maintenance problems.
WARNING:To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects
filled with liquids, such as vases, should not
be placed on this apparatus.
CAUTION: To prevent electric shock,
match wide blade of plug to wide slot, fully
insert.
ATTENTION: Pour éviter les choc électriques, introduire la lame la plus large de la
fiche dans la borne correspondante de la
prise et pousser jusqu’au fond.
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your confidence in PHILIPS.You’ve selected one of
the best-built, best-backed products available today.We’ll do everything in our power to keep you happy with your purchase for many
years to come.
As a member of the PHILIPS “family,” you’re entitled to protection
by one of the most comprehensive warranties in the industry.
What’s more, your purchase guarantees you’ll receive all the
information and special offers for which you qualify, plus easy access
to accessories from our convenient home shopping network.
Most importantly, you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome - and thanks for investing
in a PHILIPS product.
P.S. To get the most from your PHILIPS purchase, be
sure to register online at:
www.philips.com/welcome
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below,so don't miss out.
Register online at www.philips.com/welcome to ensure:
PHILIPS LIMITED WARRANTY
ONE (1) YEAR
WARRANTY COVERAGE:
PHILIPS warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
Philips warrants the product to the original purchaser or the person receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
The Philips warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received by Philips
within the Warranty Period. At its option, Philips will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or serviceable used parts and is at least functionally equivalent or most
comparable to the original product in Philips current inventory,
or (3) refund the original purchase price of the product.
Philips warrants replacement products or parts provided under
this warranty against defects in materials and workmanship from
the date of the replacement or repair for ninety (90) days or for
the remaining portion of the
original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes Philips’ property. When a refund
is given, your product becomes Philips’ property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to the new products manufactured by or for Philips that can be identified by the trademark,
trade name, or logo affixed to it. This Limited Warranty does not
apply to any non-Philips hardware product or any software, even
if packaged or sold with the product. Non-Philips manufacturers,
suppliers, or publishers may provide a separate warranty for their
own products packaged with the bundled product.
Philips is not liable for any damage to or loss of any programs,
data, or other information stored on any media contained within
the product, or any non-Philips product or part not covered by
this warranty. Recovery or reinstallation of programs, data or
other information is not covered under this Limited Warranty.
This warranty does not
apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
Philips or Philips Authorized Service Location, (c) to a product or
a part that has been modified without the written permission of
Philips, or (d) if any Philips serial number has been removed or
defaced, or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product to Philips.
• Labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary content for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of Philips.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents
when
returning product to Philips.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., PUERTO
RICO, OR U.S. VIRGIN ISLANDS…
Contact Philips Customer Care Center at:
1-888-PHILIPS (1-888-744-5477)
TO OBTAIN ASSISTANCE IN CANADA…
1-800-661-6162 (French Speaking)
1-888-PHILIPS (1-888-744-5477) - (English or Spanish
Speaking)
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of incidental or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not
apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
3140 035 50201
Philips, P.O. Box 10313 Stamford, CT 06904
Canada
English:
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the Radio Interference
Regulations of the Canadian Department of Communications. This
Class B digital apparatus complies with Canadian ICES-003.
Français:
Cet appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de Classe
B prescrites dans le Règlement sur le Brouillage Radioéle
ctrique
édicté par le Ministère des Communications du Canada. Cet appareil
numérique de la classe B est conforme à la norme NMB-003 du
Canada.
The set complies with the FCC-Rules, Part 15. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
L’appareil est conforme à la réglementation FCC, section 15. Son
utilisation est soumise à deux conditions :
1. L’appareil ne doit pas provoquer d’interférences nuisibles, et
2. L’appareil doit supporter les interférences reçues, y compris les
interférences empêchant son fonctionnement correct.
1 Important
Safety
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Clean only with dry cloth.
f Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
g Only use attachments/accessories specified by the manufacturer.
h Refer all servicing to qualified service personnel. Servicing
is
required when the apparatus has been damaged in any way.
i Battery usage CAUTION – To prevent battery leakage which
may result in bodily injury, property damage, or damage to
the unit:
Install all batteries correctly, + and - as marked on the unit. •
Do not mix batteries (old and new or carbon and alkaline, etc.).•
Remove batteries when the unit is not used for a long time.•
j
Do not place any sources of danger on the apparatus (e.g. liquid
filled objects, lighted candles).
Notice
Any changes or modifications made to this device that are not
expressly approved by Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed of with normal household
waste.
When you see the crossed-out wheel bin symbol with the chemical
symbol ‘Pb’, it means that the batteries comply with the requirement
set by the dir
ective for lead:
Please inform yourself about the local rules on separate collection of
batteries. The correct disposal of batteries helps prevent potentially
negative consequences on the environment and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam
sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Recycling the product
Your product is designed and manufactured with high quality materials
and components, which can be recycled and reused.
Never dispose of your product with other household waste. Please
inform yourself about the local rules on the separate collection of
electrical and electronic products and batteries. The correct disposal of
these products helps prevent potentially negative consequences on the
environment and human health.
Please visit www.recycle.philips.com for additional information on a
recycling center in your area.
2 Your Bathroom Radio
Congratulations on your purchase, and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
Introduction
With this unit, you can:
know the time•
listen to FM/AM radio stations•
What’s in the box
Check and identify the contents of your package:
Main unit•
User manual•
Overview of the main unit
1
a
/VOL
Turn on/off radio.•
Adjust volume. •
Scan and store radio stations automatically. •
Tune to the previous/next radio station. •
Select the previous/next preset radio station. •
Adjust hour/minute digits. •
b TIMER/BAND
Set time. •
Activate or deactivate timer.•
Select FM or AM band. •
c TUNE/PRESET
Tune to a radio station. •
Program preset radio stations. •
d Antenna
Improve radio reception. •
e Display panel
Show the time/radio information.•
f +/-
Select the previous/next preset radio station. •
Adjust hour/minute digits. •
3 Get started
Caution
Use of controls or adjustments or performance of procedures other •
than herein may result in hazardous radiation exposure or other unsafe
operation.
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number
of this apparatus. The model number and serial number are on the
bottom of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Install battery
2
Caution
Risk of explosion! Keep batteries away from heat, sunshine or fire. •
Never discard batteries in fire.
Risk of product damage! When the apparatus is not used for long
•
periods, remove the battery.
Batteries contain chemical substances, so they should be disposed
•
of properly.
Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/
•
hazardouswaste/perchlorate.
1 Open the battery compartment.
2 Insert 3 AA batteries (not supplied) with correct polarity (+/-)
as indicated.
3 Close the battery compartment.
Placement
3
You can place the unit on a flat surface or hang it in your bathroom
through the strap.
Tip
The strap is detachable. •
Set time
1 Press to turn off the radio.
2 Press and hold TIMER/BAND.
The hour digits begin to blink. »
3 Press +/- to set the hour.
4 Press TIMER/BAND to confirm.
The minute digits begin to blink. »
5 Press +/- to set the minute.
6 Press TIMER/BAND to confirm.
Turn on
1 Press to turn on the radio.
4 Listen to radio
Select FM/AM band
1 Press to turn on the radio.
2 Press and hold TIMER/BAND to switch between FM/AM band.
Tune to a radio station
1 Press to turn on the radio.
2 Press TUNE/PRESET to start tuning.
» [FM] or [AM] begins to blink.
3 Rotate clockwise or counter-clockwise to tune to a radio
station.
4 Press TUNE/PRESET again to confirm.
Program radio stations automatically
Note
You can program a maximum of 20 preset FM radio stations and •
20 preset AM radio stations.
1 Press to turn on the radio.
2 Press and hold for 2 seconds.
All available stations are programmed in the order of waveband »
reception strength.
The first programed radio station broadcasts automatically. »
Program radio stations manually
Note
You can program a maximum of 20 preset FM radio stations and 20 AM •
radio stations.
1 Press to turn on the radio.
2 Tune to a radio station.
3 Press and hold TUNE/PRESET.
The number begins to blink. »
4 Rotate clockwise or counter-clockwise to select a preset
number.
5 Press TUNE/PRESET to confirm.
6 Repeat steps 2 - 5 to program more stations.
Tip
To overwrite a programmed station, program another station in its •
place.
Select a preset radio station
1 Press to turn on the radio.
2 Press +/- to select a preset radio station.
Set the sleep timer
You can set the clock radio to turn off automatically after a certain
period of time.
1 Press TIMER/BAND repeatedly to select time (in minutes).
The apparatus turns off automatically after the set period of »
time.
To turn off the sleep timer:
1 Press TIMER/BANDrepeatedly until [OFF] (off) appears or
press
.
»
is displayed when sleep timer is on and disappears when
it is off.
5 Product information
Note
Product information is subject to change without prior notice. •
Tuner
Tuning range FM: 87.5 - 108 MHz
AM: 530 - 1710 kHz
Tuning grid 100 KHz (FM); 10KHz (AM)
Number of presets FM: 20
AM: 20
General
Power supply 3 x AA battery
Maximum power output 300 mW
Operation Power Consumption 100 mW
Dimensions
- Main Unit (H x W x D)
155 x 89 x 62 mm
Weight
- With Packing
- Main Unit
0.38 kg
0.25 kg
6 Troubleshooting
Warning
Never remove the casing of this apparatus. •
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using this apparatus, check the
following points before requesting service. If the problem remains
unsolved, go to the Philips web site (www.philips.com/welcome). When
you contact Philips, ensure that the apparatus is nearby and the model
number and serial number are available.
No power
Ensure that the battery is installed properly. •
Replace the exhausted battery. •
Timer does not work
Set the clock correctly. •
Switch on the timer. •
No sound
Adjust the volume. •
Clock/timer setting erased
Replace the exhausted battery. •
Reset the clock/timer. •
No response from the unit
Take out the batteries and turn on the unit again. •
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
AE2330_37_UM_V2.0
Philips Consumer Lifestyle
A division of Philips Electronics North America
Corporation
P.O. Box 10313
Stamford, CT 06904
Phone: 1-888-PHILIPS (744-5477)
Meet Philips at the Internet
http://www.philips.com/welcome
Loading...
