Philips ADIM ADM0101 User Manual

Philips
Communication,
Security & Imaging

Installation Instructions

Eng

2

IMPORTANT SAFEGUARDS

1. Read Instructions - All safety and operating instructions should be read
before the unit is operated.

2. Retain Instructions - The safety and operating instructions should be
retained for future reference.

3. Heed Warnings - All warnings on the unit and in the operating instructions
should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug the unit from the outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.

7. Water and Moisture - Do not use this unit near water - for example, in a
wet basement, near a swimming pool, in an unprotected outdoor
installation, or any area classified as a wet location.

8. Accessories - Do not place this unit on an unstable stand, tripod, bracket,
or mount. The unit may fall, causing serious injury to a person and
serious damage to the unit. Use only with a stand, tripod, bracket, or
mount recommended by the manufacturer or sold with the product.
Any mounting of the unit should follow the manufacturer’s instructions
and should use a mounting accessory recommended by the
manufacturer.
An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the appliance
and cart combination to overturn.

9. Ventilation - This unit should not be placed in a built-in installation or
rack, unless proper ventilation is provided, or the manufacturer’s
instructions have been adhered to. The equipment must not exceed its
maximum operating temperature requirements.

10. Mechanical Loading - Mounting of the equipment in a rack shall be such that
a hazardous condition is not achieved due to uneven mechanical loading.

11. Power Sources - This unit should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of
power supply you plan to use, consult your dealer or local power company.
For units intended to operate from battery power or other sources, refer to
the operating instructions.

12. Grounding or Polarization - This unit may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
Alternately, this unit may be equipped with a 3-wire grounding-type plug,
a plug having a third (grounding) pin. This plug will only fit into a
grounding-type power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

13. Power Cord Protection - Power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.

14. Power Lines - An outdoor system should not be located in the vicinity of
overhead power lines or other electric light or power circuits or where it
can fall into such power lines or circuits. When installing an outdoor
system, extreme care should be taken to keep from touching such power
lines or circuits, as contact with them might be fatal. U.S.A. models only ­refer to the National Electrical Code Article 820 regarding installation of
CATV systems.

15. Overloading - Do not overload outlets and extension cords, as this can
result in a risk of fire or electric shock.

16. Object and Liquid Entry - Never push objects of any kind into this unit
through openings, as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never spill liquid of any
kind on the unit.

17. Servicing - Do not attempt to service this unit yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.

18. Damage Requiring Service - Unplug the unit from the outlet andrefer
servicing to qualified service personnel under the following conditions:

a. When the power supply cord or plug is damaged.
b. If liquid has been spilled or objects have fallen into the unit.
c. If the unit has been exposed to water and/or inclement weather (rain,

snow, etc.).

d. If the unit does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the
operating instructions, as an improper adjustment of other controls
may result in damage, often requiring extensive work by a qualified

technician, to restore the unit to its normal operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance--this indicates

a need for service.

19. Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer
or having the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.

20. Safety Check - Upon completion of any service or repairs to this unit, ask
the service technician to perform safety checks to determine that the unit is
in proper operating condition.

21. Coax Grounding - If an outside cable system is connected to the unit, be
sure the cable system is grounded. U.S.A. models only--Section 810 of the
National Electrical Code, ANSI/NFPA No. 70-1981, provides information
with respect to proper grounding of the mount and supporting structure,
grounding of the coax to a discharge unit, size of grounding conductors,
location of discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.

22. Lightning - For added protection of this unit during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the cable system. This will prevent
damage to the unit due to lightning and power line surges.

FCC & ICES INFORMATION

(U.S.A. and Canadian Models Only)

WARNING - This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules and
ICES-003 of Industry Canada. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and radiates radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense. Intentional or unintentional changes or modifications not
expressly approved by the party responsible for compliance shall not be made.
Any such changes or modifications could void the user’s authority to operate the
equipment.
If necessary, the user should consult the dealer or an experienced radio/television
technician for corrective action . The user may find the following booklet
prepared by the Federal Communications Commission helpful: “How to
Identify and Resolve Radio-TV Interference Problems.” This booklet is
available from the U.S. Government Printing Office, Washington, DC 20402,
Stock No.004-000-00345-4.

Warning: This is a Class A product. In a domestic
environment, this product may cause radio interference in
which case the user may be required to take adequate measures.

3

SAFETY PRECAUTIONS

The lightning flash with an arrowhead symbol within
an equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is
intended to alert the user to presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

Attention: Installation should be performed by
qualified service personnel only in accordance with the
National Electrical Code or applicable local codes.

Power Disconnect. Units with or without ON-OFF
switches have power supplied to the unit whenever the
power cord is inserted into the power source; however,
the unit is operational only when the ON-OFF switch
is in the ON position. The power cord is the main
power disconnect for all units.

SECURITE

L’éclair fléché dans un triangle équilatéral avertit
l’utilisateur de la présence d’une “tension dangereuse” non
isolée à l’intérieur de l’appareil et d’une valeur suffisante
pour présenter un risque d’électrocution aux personnes.

Le point d’exclamation contenu dans un triangle
équilatéral avertit l’utilisateur de la présence de
consignes d’utilisation et de maintenance importantes
dans la documentation qui accompagne l’appareil.

Attention. L’installation ne doit être effectuée que par
un personnel technique qualifié conformément à la
réglementation du Code Électrique National ou à la
réglementation locale pertinente.

Disjonction de l’alimentation. Les appareils avec ou sans
commutateurs ON-OFF sont alimentés à chaque fois
que le cordon d’alimentation est branché à la source
d’alimentation; toutefois, les appareils disposant de
commutateurs ON-OFF ne fonctionnent que lorsque le
commutateur ON-OFF est dans la position ON. Le
cordon d’alimentation constitue le moyen de disjonction
de l’alimentation principale de tous les appareils.

CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT OPEN
COVERS. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE UNITS NOT SPECIFICALLY
DESIGNED FOR OUTDOOR USE TO RAIN OR
MOISTURE.

DANGER : POUR ÉVITER TOUT RISQUE
D’ÉLECTROCUTION, VEUILLEZ NE PAS
OUVRIR LE BOÎTIER. IL N’Y A PAS DE
PIÈCES REMPLAÇABLES PAR L’UTILISATEUR
À L’INTÉRIEUR DU BOÎTIER. POUR TOUTE
MAINTENANCE, VEUILLEZ VOUS ADRESSER
À UN TECHNICIEN SPÉCIALISÉ.

ATTENTION
POUR ÉVITER TOUT RISQUE
D’ÉLECTROCUTION OU D’INCENDIE,
VEUILLEZ NE PAS EXPOSER À LA PLUIE OU
À L’HUMIDITÉ UN APPAREIL NON CONÇU
POUR UNE UTILISATION EXTÉRIEURE.

WARNING: Electrostatic-

sensitive device. Use proper
CMOS/MOSFET handling
precautions to avoid
electrostatic discharge.

NOTE: Grounded wrist straps
must be worn and proper ESD
safety precautions observed
when handling the electrostatic­sensitive printed circuit boards.

CAUTION: Lithium Battery

Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to
the battery manufacturer’s instructions

A T T E N T I O N

O B S E R V E P R E C A U T I O N S

F O R H A N D L I N G

E L E C T R O S T A T I C

S E N S I T I V E D E V I C E S

4

SICHERHEITSHINWEISE

Das Blitzsymbol im gleichseitigen Dreieck soll den
Benutzer auf nicht isolierte “gefährliche Spannung” im
Produkt hinweisen, die ausreichend stark sein kann,
um die Gefahr von elektrischen Schlägen für
Menschen darzustellen.

Das Ausrufungszeichen im gleichseitigen Dreieck soll
den Benutzer auf wichtige Bedienungs- und
Wartungsanweisungen in der Dokumentation
hinweisen, die dem Gerät beiliegt.

Achtung: Die Installation darf nur von qualifiziertem
Wartungspersonal gemäß dem National Electrical
Code oder den gültigen örtlichen Vorschriften
durchgeführt werden.

Abtrennen der Spannungsversorgung: Die
Spannungsversorgung zu Geräten mit und ohne
Ein/Aus-Schalter ist hergestellt, wenn das Netzkabel an
eine Netzsteckdose angeschlossen ist. Das Gerät ist
jedoch nur betriebsbereit, wenn der Ein/Aus-Schalter
eingeschaltet ist. Bei allen Geräten erfolgt das Abtrennen
der Spannungsversorgung über das Netzkabel.

SEGURIDAD

El símbolo de flecha en forma de rayo situado dentro
de un triángulo equilátero pretende alertar al usuario
de la presencia de “voltaje peligroso” sin aislamiento
dentro de la caja del producto, el cual podría resultar
de una magnitud suficiente como para presentar un
riesgo de descarga eléctrica para las personas.

El punto de exclamación dentro de un triángulo equilátero
pretende alertar al usuario de la existencia de instrucciones
de funcionamiento y mantenimiento (reparación) en la
documentación suministrada con el aparato.

Atención: La instalación debe realizarla personal
cualificado en cumplimiento estricto del código
eléctrico nacional (en el caso de los EE.UU.) o de los
códigos locales aplicables.

Para Desconectar la Alimentación: Unidades no
equipadas con interruptores ON/OFF, son alimentadas
cuando el cable de alimentación es conectado a la
corriente eléctrica. Las unidades equipadas con
interruptores son alimentadas de igual forma, pero
adicionalmente requieren que el interruptor esté
posicionado en ON. El cable de alimentación es el
medio principal de desconexión del equipo.

VORSICHT: DAS GEHÄUSE ZUR
VERMEIDUNG VON ELEKTRISCHEN
SCHLÄGEN NICHT ÖFFNEN. DAS GERÄT
ENTHÄLT KEINE VOM BENUTZER ZU
WARTENDEN TEILE. REPARATUREN NUR
VON FACHPERSONAL AUSFÜHREN LASSEN.

WARNUNG
ZUR VERMEIDUNG VON FEUER UND
ELEKTRISCHEN SCHLÄGEN DAS GERÄT
NICHT REGEN ODER FEUCHTIGKEIT
AUSSETZEN.

PRECAUCIÓN: PARA REDUCIR EL RIESGO
DE DESCARGA ELÉCTRICA, NO ABRA LAS
TAPAS. EN EL INTERIOR NO HAY NINGÚN
COMPONENTE REPARABLE POR EL USUARIO.
LAS REPARACIONES DEBE REALIZARLAS
PERSONAL CUALIFICADO.

AVISO
PARA IMPEDIR EL RIESGO DE INCENDIO O
DESCARGA, NO EXPONGA EL APARATO A
LLUVIA O HUMEDAD

VORSICHT

ELEKTRISCHE SPANNUNG.

NICHT ÖFFNEN!

PRECAUCIÓN

RIESGO DE DESCARGA ELÉCTRICA

¡NO ABRIR!

5

VEILIGHEIDSMAATREGELEN

Het symbool ‘Bliksemflits met pijlkop’ in een
gelijkzijdige driehoek wijst de gebruiker op de
aanwezigheid in de kast van het apparaat van niet­geïsoleerde spanningen die voldoende sterk zijn om
het gevaar van elektrische schokken op te leveren.

Het uitroepteken in een gelijkzijdige driehoek maakt
de gebruiker attent op de aanwezigheid in de bij het
apparaat behorende documentatie van belangrijke
aanwijzingen voor bediening en onderhoud.

Let op: Het apparaat mag uitsluitend door bevoegde
technici geïnstalleerd worden en wel in overeenstemming
met de National Electrical Code of de daarvoor
plaatselijk geldende richtlijnen.

Afsluiten voeding. Apparaten met of zonder
ON-OFF-schakelaar krijgen voeding zodra het
netsnoer in de wandcontactdoos wordt gestoken; het
apparaat is echter alleen operationeel als de ON-OFF­schakelaar op ON staat. Het netsnoer kan bij alle
apparaten worden gebruikt om deze uit te schakelen.

SICUREZZA

Il simbolo triangolare di un fulmine con la punta a
freccia intende mettere in allerta l’utente riguardo alla
presenza di tensioni pericolose non isolate all’interno
del guscio dell’unità, che potrebbero essere di intensità
sufficiente per costituire pericolo di elettrocuzione.

Il punto esclamativo racchiuso in un triangolo equilatero
intende avvisare l’utente in merito alla presenza di
importanti istruzioni operative e di manutenzione nella
documentazione di accompagnamento all’unità.

Precauzione: affidare l’installazione al solo personale
qualificato e nel rispetto del Codice elettrico nazionale
(USA) o dei codici locali pertinenti.

Scollegamento dell’alimentazione. Gli apparecchi con o
senza commutatori ON-OFF ricevono corrente tutte le
volte che il cavo di alimentazione è inserito nella presa
di forza; tuttavia, gli apparecchi muniti di commutatore
ON-OFF funzionano solo se quest’ultimo è in posizione
ON. Il cavo di alimentazione serve a scollegare dalla
corrente tutti gli apparecchi.

VOORZICHTIG: MAAK HET APPARAAT NIET
OPEN OM DE KANS OP ELEKTRISCHE
SCHOKKEN TE VERMIJDEN. BEVAT GEEN
ONDERDELEN DIE DOOR DE GEBRUIKER
MOETEN WORDEN ONDERHOUDEN. LAAT
ONDERHOUD EN REPARATIES UITVOEREN
DOOR BEVOEGDE TECHNICI.

WAARSCHUWING
TER VOORKOMING VAN BRANDGEVAAR
EN ELEKTRISCHE SCHOKKEN MAG DIT
ARMATUUR NIET AAN REGEN EN VOCHT
WORDEN BLOOTGESTELD.

ATTENZIONE: PER RIDURRE IL PERICOLO DI
SCOSSA ELETTRICA, NON APRIRE LE
COPERTURE. L’INTERNO NON CONTIENE
COMPONENTI CHE L’UTENTE PUÒ
RIPARARE PERSONALMENTE. RIVOLGERSI AL
PERSONALE DI ASSISTENZA QUALIFICATO
PER QUALSIASI INTERVENTO DI
RIPARAZIONE.

AVVERTENZA
PER IMPEDIRE INCENDI O SCOSSA
ELETTRICA, NON ESPORRE L’UNITÀ ALLA
PIOGGIA O ALL’UMIDITÀ.

VOORZICHTIG

GEVAAR VOOR ELEKTRISCHE SCHOK.

NIET OPENEN!

AT TE NZIONE

PERICOLO DI SCOSSA ELETTRICA.

NON APRIRE.

6

Błyskawica ze strzałką wewnątrz trójkąta równobocznego
ma za zadanie zwrócić uwagę użytkownika na obecność
nieizolowanego "niebezpiecznego napięcia" wewnątrz
obudowy urządzenia, o wielkości stwarzającej niebez­pieczeństwo porażenia prądem.

Wykrzyknik wewnątrz trójkąta równobocznego ma za
zadanie zwrócić uwagę użytkownika na ważne czynności,
związane z obsługą i konserwacją urządzenia, zamieszc­zone w Instrukcji obsługi.

Uwaga: Instalację urządzenia powinien wykonać tylko
wykwalifikowany personel, zgodnie z przepisami NEC lub
odpowiednimi przepisami miejscowymi.

Odłączanie zasilania. Urządzenia zarówno nie posiada­jące, jak i posiadające wyłączniki ON-OFF znajdują się
pod napięciem, jeżeli tylko przewód zasilający jest
połączony ze źródłem zasilania. Jednakże urządzenie
działa tylko wtedy, gdy wyłącznik znajduje się w położeniu
ON. Przewód zasilający jest głównym odłącznikiem zasila­nia dla wszystkich rodzajów urządzeń.

Wymiana baterii

Stosuj tylko zalecane baterie. Muszą one spełniać wyma­gania najnowszej wersji IEC 65/VDE 0860. Zamienniki
mogą uszkodzić urządzenie lub spowodować pożar czy
porażenie prądem.

UWAGA: ZE WZGLĘDU NA
NIEBEZPIECZEŃSTWO PORAŻENIA PRĄDEM
NIE WOLNO OTWIERAĀ POKRYWY.W
ŚRODKU NIE MA ŻADNYCH ELEMENTÓW,
KTÓRE MOGĄ BYĀ NAPRAWIANE PRZEZ
UŻYTKOWNIKA. NAPRAWĘ NALEŻY
POWIERZYĀ AUTORYZOWANEMU PUNK­TOWI SERWISOWEMU.

OSTRZEŻENIE
ABY UNIKNĄĀ POŻARU LUB PORAŻENIA
PRĄDEM NIE WOLNO WYSTAWIAĀ NA
DZIAŁANIE DESZCZU LUB WILGOCI
URZĄDZEŃ, KTÓRE NIE ZOSTAŁY SPECJALNIE
ZAPROJEKTOWANE DO UŻYWANIA NA
OTWA RTYM POWIETRZU.

ZASADY BESPIECZE ´NSTAWAMEDIDAS DE SEGURANÇA

CUIDADO

RISCO DE CHOQUE ELÉCTRICO.

NÃO ABRIR!

CUIDADO: PARA REDUZIR O RISCO DE
CHOQUE ELÉCTRICO, NÃO ABRA AS TAM­PA S. O INTERIOR NÃO CONTÉM PEÇAS QUE
NECESSITEM DE MANUTENÇÃO.A
MANUTENÇÃO DEVE SER EFECTUADA POR
PESSOAL DE ASSISTÊNCIA TÉCNICA QUALI­FICADO.

O símbolo do raio com a cabeça de uma seta dentro
de um triângulo equilátero serve para alertar o utilizar
para a presença de "corrente eléctrica perigosa" não
isolada no interior da caixa do produto que pode ser
suficiente para dar origem a choques eléctricos.

O ponto de exclamação dentro de um triângulo equilátero
serve para alertar o utilizador para a presença de instruções
de funcionamento e manutenção importantes na docu­mentação fornecida com o aparelho.

AVISO
PARA EVITAR INCÊNDIOS OU CHOQUES
ELÉCTRICOS, NÃO EXPONHA À CHUVA OU
HUMIDADE UNIDADES NÃO ESPECIFICA­MENTE CRIADAS PARA UTILIZAÇÃO NO
EXTERIOR.

UWAGA

NIEBEZPIECZEŃSTWO PORAŻENIA PRĄDEM

ELEKTRYCZNYM. NIE OTWIERAĆ!

Atenção: A instalação deve ser efectuada por pessoal de
assistência técnica qualificado, de acordo com o
National Electrical Code (Normas de Electricidade
Nacionais) ou a legislação local aplicável.

Desconexão da electricidade. Unidades com ou sem
interruptores ON-OFF são activadas sempre que o
cabo eléctrico for ligado a uma fonte de alimentação.
No entanto, a unidade fica operacional apenas quando
o interruptor ON-OFF se encontrar na posição ON.
Para desligar a electricidade em qualquer uma das
unidades deve ser utilizado o cabo eléctrico.

Precauções a ter durante a substituição da bateria

Use apenas fontes de alimentação recomendadas. As
fontes de alimentação devem cumprir os requisitos da
da versão mais recente de IEC 65/VDE 0860.
Qualquer substituição pode causar danos na unidade
ou dar origem a incêndios ou choques eléctricos.

7

TABLE OF CONTENTS

1PRODUCT DESCRIPTION..............................................................................................................................8

1.1 Models ................................................................................................................................................................8

1.2 Features................................................................................................................................................................8

2 UNPACKING......................................................................................................................................................8

2.1 Package Contents ................................................................................................................................................8

3 SYSTEM OVERVIEW ........................................................................................................................................8

4 ADIM CONNECTIONS AND CONFIGURATION........................................................................................10

4.1 DVR Configuration (See DVR manual)............................................................................................................10

4.2 IntuiKey Keyboard and Serial Hub Connections ..............................................................................................10

4.3 ADIM PC is pre-configured as follows ..............................................................................................................10

4.4 Primary DVR Connections................................................................................................................................10

4.5 Backup DVR and Review Monitor Connections (Optional) ............................................................................10

4.6 Network Connections........................................................................................................................................11

4.7 ADIM PC Connections ....................................................................................................................................11

4.8 The PC is pre-configured with the following network parameters ....................................................................11

4.9 Setting up ADIM PC Connections....................................................................................................................11

4.10 Allegiant Connections ......................................................................................................................................11

5 ADIM CONFIGURATION ..............................................................................................................................12

5.1 Logging ON and User Levels ............................................................................................................................12

6OPERATION ....................................................................................................................................................13

6.1 DVR Configuration Page ..................................................................................................................................13

6.2 Other Configuration..........................................................................................................................................14

6.2.1 Allegiant Status Message Monitors..................................................................................................................................14

6.2.2 Auto-Login....................................................................................................................................................................14

6.2.3 Keyboard / Com Port Assignment ..................................................................................................................................14

6.3 Status and Monitoring Page ..............................................................................................................................15

6.4 Allegiant Camera Title Transfer Dialog ..............................................................................................................16

7 ADIM KEYBOARD OPERATION ..................................................................................................................17

7.1 Product Menu....................................................................................................................................................17

7.2 Allegiant Main Menu ........................................................................................................................................17

7.3 ADIM Controls Menu ......................................................................................................................................17

7.4 Joystick Operation ............................................................................................................................................17

7.5 Numeric Keypad Buttons ..................................................................................................................................17

7.6 Softkey Buttons ................................................................................................................................................17

7.7 Keyboard Error Handling ..................................................................................................................................17

7.8 Clearing ADIM Alarms ....................................................................................................................................17

8TROUBLESHOOTING....................................................................................................................................18

APPENDIX A – EVENT LOGS ..........................................................................................................................19

APPENDIX B – TECHNICAL SPECS ................................................................................................................22

APPENDIX C – RECOMMENDED NETWORK SWITCHES ..........................................................................23

APPENDIX D – LIST OF COMPATIBLE DVRS ..............................................................................................23

APPENDIX E – PRIMARY, BACK-UP AND REVIEW DVRS ..........................................................................23

8

1PRODUCT DESCRIPTION

ADIM™is a powerful security and surveillance solution that

combines the power and features of the Philips Allegiant matrix
switcher with the speed and quality of digital video recording.
This tightly integrated solution uses the IntuiKey keyboard to
control all cameras, monitors and digital video recorders. With
the push of a button, the DVR will playback video from the
current camera and display it on the specified CCTV monitor.
The joystick can be used to fast forward, fast reverse and
navigate the menu within the DVR.

1.1 Models

ADM0101 (see package contents below)

1.2 Features

• IntuiKey Keyboard interface for all Camera, Allegiant®and
DVR functions

• One-button transition from Live to recorded video–on the
specified analog monitor

• Synchronization of DVR and Allegiant clocks

• Status monitoring and event logging

• Automatic switchover to backup DVRs

• Monitor review; playback all video that was directed to
specified review monitors

2 UNPACKING

Unpack carefully to prevent damage to the equipment.

2.1 Package Contents

* Revision of this Instruction Manual will increment as changes are

made. Please visit www.Philipscsi.com for the most current version.

3SYSTEM OVERVIEW

ADIM is an integration solution for the IntuiKey Keyboard,
Allegiant Matrix Switcher and selected Philips DVRs.

Components of an ADIM system:

• Allegiant matrix switcher

• Hi-Qs (Revision 1.10 or higher)

• Disk Arrays (optional)

• ADIM PC

• Serial Hub(s)

• Universal IntuiKey Keyboard(s) – (Rev 1.10 or higher)

• Network Switch(es) – (See Appendix C for recommended
network switches.)

NOTE: For your convenience, the Hi-Q Management Utility
and the IntuiKey Keyboard’s Installer program are pre-installed
on the ADIM PC.

Item Qty Part Number

ADIM PC (keyboard, mouse,
monitor, power cord,
Windows NT

®

, ADIM and
system software, rack mounting
hardware)

1 3033743001

Software Key 1 3031874021002

Master Control software 1 30336800100

Serial Hub 1 ACCSH01

Ethernet Cable 2 3032779001

Console Cable, 10-foot 1 LTC 8506/00

Null Modem Cable, 15-foot 1 ACCNM015

Instruction Manual (this manual) 1 393589042712*

Master Control Software for
Windows Manual

1 393589012413
