Philips A2.310/25 User Manual

4399 294 60201

soundcard.

music and brings games and web-sites to life! Ideal with a stereo

CD/MP3 players, game consoles and even TV's it adds realism to your

across the whole frequency range. Connected to PC's,

frequencies. The system is optimized to produce superb sound quality

subwoofer with bass reflex system, to add unbelievable depth to low

Deep Bass, crisp highs and great looks!

The Rhythmic Wave 310 includes a powerful, down-firing wooden

2.310 / MMS213

EL 4562-E004: 99/3

Polarized Plug

not expose this appliance to rain or moisture.

15.Warning! To reduce the risk of fire or electric shock, do

not operate normally, or has been dropped. the apparatus has been exposed to rain or moisture, does

has been spilled or objects have fallen into the apparatus, way, such as power-supply cord or plug is damaged, liquid is required when the apparatus has been damaged in any

14. Refer all servicing to qualified service personnel. Servicing

unused for long periods of time.

13.Unplug this apparatus during lightning stor ms or when

apparatus combination to avoid injury from tip-over. When a cart is used, use caution when moving the cart/ specified by the manufacturer, or sold with the apparatus.

12. Use only with a cart, stand, tripod, bracket, or table

by the manufacturer.

11. Only use attachments/accessories specified

and the point where they exit from the apparatus.

pinched particulary at plugs, convenience receptacles,

10.Protect the power cord from being walked on or

of the obsolete outlet. not fit into your outlet, consult an electrician for replacement are provided for your safety. When the provided plug does a third grounding prong. The wide blade or the third prong slot, fully insert. A grounding type plug has two blades and one wider than the other. Match wide blade of Plug to wide grounding-type plug. A polarized plug has two blades with

9. Do not defeat the safety purpose of the polarized or

heat. (including amplifiers) that produce registers, stoves, or other apparatus

sources such as radiators, heat

8. Do not Install near any heat

http://www.pcsound.philips.com http://www.pcstuff.philips.com

air through the ventilation openings. bookcase or cabinet that may impede the flow of or placed in a built-in installation, such as a be situated on a bed, sofa, rug, or similar surface

openings. For example, the appliance should not Instructions. Do not block any of the ventilation

7. Install in accordance with the manufacturers

manufacturer. should be cleaned only as recommended by the

6. Clean only with a damp cloth. The appliance

in a wet basement or near a swimming pool, etc. near a bathtub, washbowl, kitchen sink, laundry tub,

5. Do not use this apparatus near water - for example,

instructions should be followed.

4. Follow all instructions - All operating and use

to. and in the operating instructions should be adhered

3. Heed all warnings - All warnings on the appliance

instructions should be retained for future reference.

2. Keep these instructions - The safety and operating

appliance is operated. operating instructions should be read before the

1. Read these instructions - All the safety and

should be particularly aware of. some installation and operation precautions which you strict quality and safety standards. There are, however, This product was designed and manufactured to meet

IMPORTANT SAFETY INSTRUCTIONS - Read before operating equipment

For US/Canada only

Multimedia Speaker System

Â Ã Ä Å Æ

~ EXPLANATION ~

➀ Rotary Volume Control

To adjust the volume higher or lower

➁ Power On/Off

To switch on or off power (Green LED indicates that the power is On)

➂ Bass Control

To adjust bass level to desired volume

➃ Control In

Plug in the mini DIN connector

➄ Line In

To connect the Line In cable from the sound card/sound source.

➅ Power In

To connect the adapter

Æ Satellite Out

To connect the satellite speakers

Installation

Italiano:

1. Collegare laltoparlante satellite.

2. Collegare alla scheda audio/sorgente audio.

3. Collegare la spina mini DIN allingresso control.

4. Collegare lalimentatore.

5. Accendere il sistema utilizzando il pulsante di accensione posto sul pannello satellite.

6. Sintonizzare il sistema utilizzando la scheda audio/ sorgente audio e i comandi posti sul pannello satellite.

Nota: Non inserire la spina di alimentazione nella presa di

corrente fino a che i collegamenti non sono stati tutti ultimati!

ÁÃÂ

Nederlands:

1. Sluit de satellietluidspreker aan.

2. Sluit aan op geluidskaart/geluidsbron.

3. Sluit de kleine DIN-stekker aan op control in.

4. Sluit het netsnoer aan.

5. Zet het systeem aan met de aan-uitknop op het satellietpaneel.

6 Stem het systeem af met de geluidskaart/geluidsbron

en de toetsen op het satellietpaneel

Opmerking: Steek de netsteker pas in het stopcontact

als alle aansluitingen gedaan zijn!

English:

1. Connect the satellite speaker.

2. Connect to sound card/sound source.

3. Connect the mini DIN plug into the control in.

4. Connect the power supply.

5. Switch On/Off the system using the power button on the satellite panel.

6. Tune the system using sound card/sound source and the controls on the satellite speaker.

Note: Do not insert the power plug into the AC outlet

until all connections are made!

Español:

1. Conecte el altavoz satélite.

2. Realice la conexión a la tarjeta o fuente de sonido.

3. Inserte el miniconector DIN en el terminal de entrada

de control.

4. Conecte el cable de alimentación.

5. Active el sistema con el botón de encendido situado

en el panel del satélite.

6. Afine el sistema utilizando la tarjeta o fuente de

sonido y los controles del panel del satélite.

Observación: No inserte el conector de

alimentación en la toma de corriente mientras no haya completado todas las conexiones

Svenska:

1. Anslut satellithögtalaren.

2. Anslut till ljudkort/ljudkälla.

3. Anslut mini-DIN-kontakten till Control In

(regleringsingången).

4. Anslut strömförsörjningen.

5. Sätt på systemet med på-knappen på satellitpanelen.

6. Ställ in systemet via ljudkort/ljudkälla och knapparna

på satellitpanelen

Obs: Anslut inte nätkontakten till nätuttaget förrän alla

anslutningar har gjorts!

Français:

1. Branchez lenceinte satellite.

2. Connectez la carte son/source sonore.

3. Branchez la mini fiche DIN sur lentrée Control.

4. Branchez lalimentation.

5. Mettez le système sous tension à laide de la touche dalimentation située sur lenceinte satellite.

6. Accordez le système au moyen de la carte son/ source sonore et des commandes sur lenceinte satellite

Remarque: Nintroduisez pas la iche dans la prise CA

tant que tous les branchements ne sont pas effectués !

Deutsch:

1. Den Satellitenlautsprecher anschließen.

2. An die Soundkarte/Signalquelle anschließen.

3. Den Mini-DIN-Stecker an die Buchse Control in anschließen.

4. Das Netzteil anschließen.

5. Das System mit Hilfe der Taste Power auf dem Bedienfeld des Satellitenlautsprechers einschalten.

6. Das System mit Hilfe der Soundkarte/Signalquelle und den Bedienelementenauf dem Bedienfeld des Satellitenlautsprechers einstellen.

Hinweis: Den Netzstecker nicht an eine Steckdose

anschließen, bevor alle Verbindungen hergestellt worden sind.

Suomi:

1. Liitä satelliittikaiutin.

2. Liitä äänikorttiin/äänilähteeseen.

3. Liitä minidin-pistoke Control In -sisääntuloon.

4. Liitä virtalähde.

5. Kytke järjestelmä päälle satelliittikaiuttimen virtakytkimestä.

6. Viritä järjestelmä äänikortin/äänilähteen ja satelliittikaiuttimen säädinten avulla.

Huom: Älä yhdistä pistotulppaa pistorasiaan,ennen kuin

kaikki kytkennät ovat valmiit!

Polski:

1. Podùàcz gùoúnik satelitarny.

2. Podùàcz go ze êródùem dêwiæku/kartà dêwiækowà

3. Wùóê wtyk mini DIN do wejúcia sterujàcego.

4. Podùàcz przewód zasilajàcy do êródùa zasilania.

5. Wùàcz system, uêywajàc przycisku zasilania na panelu gùoúnika satelitarnego.

6. Dostrój system, uêywajàc êródùa dêwiæku/karty dêwiækowej oraz kontrolek na panelu gùoúnika satelitarnego.

Uwaga: Nie wkùadaj przewodu zasilajàcego do

gniazda sieciowego dopóki nie wykonasz wszystkich (innych)

Norsk: Dansk:

1. Kople til satellitthøyttaleren.

2. Kople til lydkortet/lydkilden.

3. Kople mini DIN-pluggen til kontrollinngangen.

4. Kople til strømtilførselen.

5. Slå på systemet med strømknappen på satellittpanelet.

6. Still inn systemet ved hjelp av lydkortet/lydkilden og kontrollene på satellittpanelet.

Merk: Ikke sett støpselet i en stikkontakt før alle

tilkoplingene er gjort!

poùàczeñ!

Dansk:

1. Tilslut satellithøjttaleren.

2. Tilslut til lydkortet/lydkilden.

3. Tilslut mini-DIN-stikket til bøsningen Control In.

4. Tilslut strømforsyningen.

5. Tænd systemet ved hjælp af tænd-/slukknappen på

5. Tænd systemet ved hjælp af tænd-/slukknappen på satellitpanelet.

satellitpanelet.

6. Afstem systemet ved hjælp af lydkortet / lydkilden og

6. Afstem systemet ved hjælp af lydkortet / lydkilden og betjeningselementerne på satellitpanelet.

betjeningselementerne på satellitpanelet.

Bemærk: Sæt netstikket ikke til i vekselstrømsudgangen,

før alle tilslutninger er i orden!

Türkçe:

1. Uydu hoparlörünü baðlayýnýz.

2. Ses kartýný/ses kaynaðýný baðlayýnýz.

3. Mini DIN fiþi kontrol giriþine baðlayýnýz.

4. Güç kaynaðýný baðlayýnýz.

5. Uydu paneli üzerindeki güç düðmesini kullanarak sistemi çalýþtýrýnýz.

6. Ses kartý/ses kaynaðýný ve uydu paneli üzerindeki kumandalarý kullanarak sistemi ayarlayýnýz.

Açýklama: Güç kablosunu, tüm baðlantýlar

yapýlmadan AC çýkýþýna sokmayýnýz!

Portuguese:

1 Ligue as colunas satélite. 2 Ligue a placa de som / fonte sonora. 3 Ligue a tomada DIN mini em Control In. 4 Ligue a energia eléctrica. 5 Ligue/desligue a aparelhagem utilizando o botão

respectivo na coluna satélite.

6 Ajuste a aparelhagem utilizando a placa de som/fonte de

som e os controlos na coluna satélite.

Nota: Não introduza a ficha eléctrica na tomada antes de

fazer todas as ligações!

Important notes for users in the U.K.

Mains plug

This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this type of plug proceed as follows:

1 Remove fuse cover and fuse. 2 Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type. 3 Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place. If the mains plug contains a fuse, this should have a value of 5 Amp. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5 Amp.

Note: The severed plug must be disposed of to avoid a possible shock hazard should it be inserted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code: blue = neutral (N), brown = live (L). As these colours may not correspond with the colour markings identifying the terminals in your plug, proceed as follows:

 Connect the blue wire to the terminal marked N or coloured black.  Connect the brown wire to the terminal marked L or coloured red.  Do not connect either wire to the earth terminal in the plug, marked E (or ) or coloured green (or green and yellow).

Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead - not simply over the two wires.

Recording and playback of material may require consent. See Copyright Act 1956 and The Performer's Protection Acts 1958 to 1972.

Русский:

1. Подсоедините сателлитную колонку.

2. Подсоедините звуковую плату или другой источник звукового сигнала.

3. Вставьте миниатюрный штекер типа DIN в гнездо для управляющего входного сигнала.

4. Подсоедините источник питания.

5. Включите систему с помощью кнопки питания на панели сателлита.

6. Настройте систему с помощью звуковой платы и регуляторов, расположенных на панели сателлита.

Примечание: Не подсоединяйте вилку

сетевого шнура крозетке сетипеременного тока, покане будут выполнены все необходимые соединения!

Norge

Typeskilt finnes på apparatens underside.

Observer: Nettbryteren er sekundert innkoplet. Den innebygde netdelen er derfor ikke frakoplet nettet så lenge apparatet er tilsluttet nettkontakten.

For å redusere faren for brann eller elektrisk støt, skal apparatet ikke utsettes for regn eller fuktighet.

Deutschland

Hiermit wird bescheinigt, daß dieses Gerät in Übereinstimmung mit

den Bestimmungen der Amtsblattverfügung 1046/1984 funkentstört ist.

Der Deutschen Bundespost wurde das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur Überprüfung der Serie auf Einhaltung der Bestimmungen eingeräumt.
