English

Introduction

Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.

Please read this user manual, as it contains information about the features of this shaver as well as some tips to make shaving easier and more enjoyable.

General description (Fig.1)

1 Comb for beard styler attachment 2 Click-on beard styler attachment 3 Click-on trimmer attachment 4 Click-on shaving unit 5 On/off button 6 Socket for small plug 7 Exclamation mark 8 Replacement reminder 9 Battery charge indicator 10 Travel lock symbol 11 Cleaning reminder 12 SmartClean system 13 Cap of SmartClean system 14 On/off button 15 Replacement symbol 16 Cleaning symbol 17 Drying symbol 18 Ready symbol 19 Charge symbol 20 Cleaning cartridge for SmartClean system 21 Supply unit 22 Small plug 23 Retaining ring holder 24 Pouch

English

The accessories supplied may vary for different products. The box shows the accessories that have been supplied with your appliance.

Important safety information

Read this important information carefully before you use the appliance and its accessories and save it for future reference. The accessories supplied may vary for different products.

Danger

- Keep the supply unit dry.

Warning

- To charge the battery, only use the detachable supply unit (type HQ8505) provided with the appliance.

- The supply unit contains a transformer. Do not cut off the supply unit to replace it with another plug, as this causes a hazardous situation.

English

- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

- Always unplug the shaver before you clean it under the tap.

- Always check the appliance before you use it. Do not use the appliance if it is damaged, as this may cause injury. Always replace a damaged part with one of the original type.

Caution

English

- Do not open the appliance to replace the rechargeable battery.

- Never immerse the cleaning system or the charging stand in water and do not rinse it under the tap.

- Never use water hotter than 80°C to rinse the shaver.

- Only use this appliance for its intended purpose as shown in the user manual.

- For hygienic reasons, the appliance should only be used by one person.

- Never use compressed air, scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone to clean the appliance.

English

- If your shaver comes with a cleaning system, always use the original Philips cleaning fluid (cartridge or bottle, depending on the type of cleaning system).

- Always place the cleaning system on a stable, level and horizontal surface to prevent leakage.

- If your cleaning system uses a cleaning cartridge, always make sure the cartridge compartment is closed before you use the cleaning system to clean or charge the shaver.

- When the cleaning system is ready for use, do not move it to prevent leakage of cleaning fluid.

- Water may drip from the socket at the bottom of the shaver when you rinse it. This is normal and not dangerous because all electronics are enclosed in a sealed power unit inside the shaver.

- Do not use the supply unit in or near wall sockets that contain an electric air freshener to prevent irreparable damage to the supply unit.

Electromagnetic fields (EMF)

- This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields.

General

- This shaver is waterproof. It is suitable for use in the bath or shower and for cleaning under the tap. For safety reasons, the shaver can therefore only be used without cord.

- The appliance is suitable for mains voltages ranging from 100 to 240 volts.

- The supply unit transforms 100-240 volts to a safe low voltage of less than 24 volts.

- Максималды шу деңгейі: Lc = 69 дБ(A)

English

The display

Note: Before you use the shaver for the first time, remove the protective foil from the display.

Charging

Quick charge: When you connect the shaver to the wall socket, the lights of the battery charge indicator light up one after another repeatedly. When the shaver contains enough energy for one shave, the bottom light of the battery charge indicator starts to flash slowly.

While the shaver continues to charge, first the bottom light of the battery charge indicator flashes and then lights up continuously. Then the second light flashes and lights up continuously, and so on until the shaver is fully charged (see 'Battery fully charged').

Battery fully charged

When the battery is fully charged, all lights of the battery charge indicator light up white continuously.

Note: This appliance can only be used without cord. When you press the on/off button during or after charging, you hear a sound to indicate that the shaver is still connected to the wall socket.

Note: When the battery is full, the display switches off automatically after 30 minutes.

Battery low

When the battery is almost empty, the bottom light of the battery charge indicator flashes orange and you hear a sound.

Remaining battery charge

The remaining battery charge is shown by the lights of the battery charge indicator that light up continuously.

Cleaning reminder

Clean the shaver after every shave for optimal performance. When you switch off the appliance, the cleaning reminder flashes to remind you to clean the appliance.

Travel lock

You can lock the appliance when you are going to travel. The travel lock prevents the appliance from being switched on by accident.

Activating the travel lock

1 Press the on/off button for 3 seconds to enter

the travel lock mode.

English

While you activate the travel lock, the travel lock symbol lights up white continuously. When the travel lock is activated, the appliance produces a sound and the travel lock symbol flashes.

Deactivating the travel lock

1 Press the on/off button for 3 seconds.

The travel lock symbol flashes and then lights up continuously. The appliance is now ready for use again.

Note: You can also deactivate the travel lock by connecting the appliance to the wall socket.

Replacement reminder

For maximum shaving performance, we advise you to replace the shaving heads every two years.

The appliance is equipped with a replacement reminder which reminds you to replace the shaving heads. The shaving unit symbol lights up white continuously, the arrows flash white and the appliance beeps to indicate that you have to replace the shaving heads.

Note: After replacing the shaving heads, you need to reset the replacement reminder by pressing the on/off button for 7 seconds.

Exclamation mark

Overheating

If the appliance overheats during charging, the exclamation mark flashes orange. When this happens, the shaver switches off automatically. Charging continues once the temperature of the appliance has decreased to the normal level.

Blocked shaving heads

If the shaving heads are blocked, the exclamation mark lights up orange continuously. The replacement reminder and the cleaning reminder flash white alternately and you hear a sound. In this case, the motor cannot run because the shaving heads are soiled or damaged.

If the shaving heads are soiled, you have to clean them. If the shaving heads are damaged, you have to replace them.

Charging

Charge the shaver before you use it for the first time and when the display indicates that the battery is almost empty. The battery charge is indicated by the lights of the battery charge indicator on the display.

When you connect the shaver to the wall socket, you hear a sound.

Charging takes approx. 1 hour. A fully charged shaver has a shaving time of up to 50 minutes.

Note: You cannot use the appliance while it is charging.

Charging with the supply unit

1 Make sure the appliance is switched off. 2 Put the supply unit in the wall socket and put

the small plug in the appliance.

3 After charging, remove the supply unit from the

wall socket and pull the small plug out of the appliance.

English

Charging in the SmartClean system (specific types only)

1 Put the small plug in the back of the

SmartClean system.

2 Put the supply unit in the wall socket. 3 Press the top cap to be able to place the shaver

in the holder ('click').

4 Hold the shaver upside down above the holder.

Make sure the front of the shaver points towards the SmartClean system.

5 Place the shaver in the holder (1), tilt the shaver

backwards (2) and press down the top cap to connect the shaver (‘click’) (3).

Note: The battery symbol starts to flash to indicate that the appliance is charging. When the battery is fully charged, the battery symbol lights up continuously.

Using the appliance

Note: This appliance can only be used without cord.

Switching the appliance on and off

- To switch on the appliance, press the on/off button once.

The display lights up for a few seconds.

- To switch off the appliance, press the on/off button once.

Shaving

English

The display lights up for a few seconds and shows the remaining battery charge.

Skin adaptation period

Your first shaves may not bring you the result you expect and your skin may even become slightly irritated. This is normal. Your skin and beard need time to adapt to any new shaving system. To allow your skin to adapt to this new appliance, we advise you to shave regularly (at least 3 times a week) and exclusively with this appliance for a period of 3 weeks.

Shaving tips

- To ensure the best result, we advise you to pretrim your beard if you have not shaved for 3 days or longer.

- Move the shaving heads over your skin in circular movements.

Dry shaving

1 Switch on the appliance.

The display lights up for a few seconds.

2 Move the shaving heads over your skin in

circular movements to catch all hairs growing in different directions. Exert gentle pressure for a close comfortable shave.

Note: Circular movements provide better shaving results than straight movements.

3 Clean the appliance after use (see 'Cleaning

and maintenance').

Wet shaving

You can also use this appliance on a wet face with shaving foam or shaving gel.

English

To shave with shaving foam or shaving gel, follow the steps below:

1 Apply some water to your skin.

2 Apply shaving foam or shaving gel to your skin.

3 Rinse the shaving unit under the tap to ensure

that the shaving unit glides smoothly over your skin.

4 Switch on the appliance.

5 Move the shaving heads over your skin in

circular movements to catch all hairs growing in different directions. Exert gentle pressure for a close comfortable shave.

Note: Rinse the shaving unit regularly to ensure that it continues to glide smoothly over your skin.

6 Dry your face. 7 Clean the appliance after use (see 'Cleaning

and maintenance'). Note: Make sure you rinse all foam or shaving

gel off the appliance.

Using the click-on attachments

Note: The accessories supplied may vary for different products. The box shows the accessories that have been supplied with your appliance.

Removing or attaching the click-on attachments

1 Make sure the appliance is switched off. 2 Pull the attachment straight off the appliance.

Note: Do not twist the attachment while you pull it off the appliance.

3 Insert the lug of the attachment into the slot in

the top of the appliance. Then press down the attachment to attach it to the appliance (‘click’).

Using the trimmer attachment

You can use the trimmer attachment to groom your sideburns and moustache.

1 Attach the attachment to the appliance (‘click’). 2 Switch on the appliance.

The display lights up for a few seconds.

English

3 Hold the trimmer attachment perpendicular to

the skin and move the appliance downwards while you exert gentle pressure.

4 Clean the attachment after use (see 'Cleaning

and maintenance').

Using the beard styler attachment with comb

You can use the beard styler attachment with the comb attached to style your beard at one fixed

English

setting, but also at different length settings. You can also use it to pre-trim any long hairs before shaving for a more comfortable shave.

The length settings on the beard styler attachment correspond to the remaining hair length after cutting and range from 1 to 5mm.

1 Attach the attachment to the appliance ('click').

2 Slide the comb straight into the guiding grooves

on both sides of the beard styler attachment (‘click’).

3 Press the length selector and then push it to the

left or right to select the desired hair length setting.

4 Switch on the appliance.

5 Move the appliance upwards while you exert

gentle pressure. Make sure the front of the comb is in full contact with the skin.

6 Clean the attachment after use (see 'Cleaning

and maintenance').

Using the beard styler attachment without comb

You can use the beard styler attachment without the comb to contour your beard, moustache, sideburns or neckline to a length of 0.5mm.

English

1 Pull the comb off the beard styler attachment.

Note: Grab the comb in the center to pull it off the beard styler attachment. Do not pull at the sides of the comb.

2 Switch on the appliance.

3 Hold the beard styler attachment perpendicular

to the skin and move the appliance downwards while you exert gentle pressure.

4 Clean the attachment after use (see 'Cleaning

and maintenance').

Cleaning and maintenance

Note: The accessories supplied may vary for different products. The box shows the accessories that have been supplied with your appliance.

Cleaning the shaver in the SmartClean system

The SmartClean system comes in two types. The features available on your SmartClean system differ per type:

- SmartClean system Basic has one phase: the rinsing phase.

- SmartClean system Plus has two phases: the rinsing phase and the drying phase.

English

Preparing the SmartClean system for use

Caution: Do not tilt the SmartClean system to prevent leakage.

Note: Hold the SmartClean system while you prepare it for use.

Note: If you clean the shaver in the SmartClean system once a week, the SmartClean cartridge lasts approximately three months.

1 Put the small plug in the back of the

SmartClean system.

2 Put the supply unit in the wall socket. 3 Press the button on the side of the SmartClean

system (1) and lift the top part of the SmartClean system (2).

4 Pull the seal off the cleaning cartridge.

5 Place the cleaning cartridge in the SmartClean

system.

6 Push the top part of the SmartClean system

back down (‘click’).

English

Using the SmartClean system

Caution: Always shake excess water off the shaver before you place it in the SmartClean system.

1 Press the top cap to be able to place the shaver

in the holder ('click').

2 Hold the shaver upside down above the holder.

Make sure the front of the shaver points towards the SmartClean system.

3 Place the shaver in the holder (1), tilt the shaver

backwards (2) and press down the top cap to connect the shaver ('click') (3).

The battery symbol starts to flash, which indicates that the shaver is charging.

4 Press the on/off button on the SmartClean

system to start the cleaning program. During the rinsing phase, the rinsing symbol

flashes. When the rinsing phase is done (after approx. 10 minutes), the rinsing symbol lights up continuously.

English

SmartClean system Plus only: After the rinsing phase,

the drying phase starts automatically. During this phase, the drying symbol flashes. When the drying phase is done (after approx. 4 hours), the drying symbol lights up continuously.

When the cleaning program is done, the ready symbol lights up continuously.

30 minutes after the cleaning program and charging have been completed, the SmartClean system switches off automatically.

The battery symbol lights up continuously to indicate that the shaver is fully charged. Charging takes approx. 1 hour.

5 SmartClean system Basic only: To let the

shaver dry, you can leave it in the SmartClean system until your next shave. You can also remove the shaver from the SmartClean system, shake off excess water, open the shaving unit and let the shaver air dry.

Note: If you press the on/off button of the SmartClean system during the cleaning program, the program aborts. In this case, the rinsing or drying symbol goes out.

Note: If you remove the supply unit from the wall socket during the cleaning program, the program aborts.

Replacing the cartridge of the SmartClean system

Replace the cleaning cartridge when the replacement symbol flashes orange or when you are no longer satisfied with the cleaning result. If you clean the shaver in the SmartClean system once a week, the SmartClean cartridge lasts approximately three months.

English

1 Press the button on the side of the SmartClean

system (1) and lift the top part of the SmartClean system (2).

2 Remove the cleaning cartridge from the

SmartClean system and pour out any remaining cleaning fluid.

You can simply pour the cleaning fluid down the sink.

3 Throw away the empty cleaning cartridge. 4 Unpack the new cleaning cartridge and pull off

the seal.

5 Place the cleaning cartridge in the SmartClean

system.

6 Push the top part of the SmartClean system

back down (‘click’).

Cleaning the shaver under the tap

Clean the shaver after every shave for optimal performance.

Caution: Be careful with hot water. Always check if the water is not too hot, to prevent burning your hands.

Note: Never dry the shaving unit with a towel or tissue, as this may damage the shaving heads.

English

1 Switch on the appliance. 2 Rinse the shaving unit under a warm tap.

3 Switch off the appliance. Pull the shaving head

holder off the bottom part of the shaving unit.

4 Rinse the hair chamber under the tap.

5 Rinse the shaving head holder under a warm

tap.

6 Carefully shake off excess water and let the

shaving head holder dry.

7 Attach the shaving head holder to the bottom

part of the shaving unit (‘click’).

Cleaning the click-on attachments

Never dry trimmer or beard styler attachments with a towel or tissue, as this may damage the trimming teeth.

English

The accessories supplied may vary for different products. The box shows the accessories that have been supplied with your appliance.

Cleaning the trimmer attachment

Clean the trimmer attachment every time you have used it.

1 Switch on the appliance with the trimmer

attachment attached.

2 Rinse the attachment under a warm tap. 3 After cleaning, switch off the appliance. 4 Carefully shake off excess water and let the

attachment dry.

Tip: For optimal performance, lubricate the teeth of the attachment with a drop of sewing machine oil regularly.

Cleaning the beard styler attachment

Clean the beard styler attachment every time you have used it.

1 Pull the comb off the beard styler attachment.

Note: Grab the comb in the centre to pull it off the beard styler attachment. Do not pull at the sides of the comb.

2 Switch on the appliance.

3 Rinse the beard styler attachment and the

comb separately under a warm tap.

4 After cleaning, switch off the appliance. 5 Carefully shake off excess water and let the

beard styler attachment and comb dry.

6 For optimal performance, lubricate the teeth of

the attachment with a drop of sewing machine oil regularly.

2yrs

English

Storage

1 Store the appliance in the pouch supplied.

Note: Make sure the appliance is dry before you store it in the pouch.

Replacement

Replacing the shaving heads

For maximum shaving performance, we advise you to replace the shaving heads every two years. Replace damaged shaving heads immediately. Always replace the shaving heads with original Philips shaving heads (see 'Ordering accessories').

Replacement reminder

The replacement reminder indicates that the shaving heads need to be replaced.The shaving unit symbol lights up continuously, the arrows flash white and you hear a beep when you switch off the shaver.

1 Switch off the appliance. 2 Pull the shaving head holder off the bottom

part of the shaving unit.

3 Place the retaining ring holder on the retaining

ring (1), turn it anticlockwise (2) and lift it off the shaving head (3).

Remove the retaining ring from the retaining ring holder and repeat this process for the other retaining rings.

English

4 Remove the shaving heads from the shaving

head holder. Throw away the used shaving heads

immediately to avoid mixing them with the new shaving heads.

5 Place the shaving heads in the shaving head

holder. Note: Make sure the notches on both sides of

the shaving heads fit exactly onto the projections in the shaving head holder.

6 Place the retaining ring holder on the retaining

ring (1), place it on the shaving head (2) and turn it clockwise (3) to reattach the retaining ring. Repeat this process for the other retaining rings.

Each retaining ring has two recesses that fit exactly into the projections of the shaving head holder. Turn the ring clockwise until your hear a click to indicate that the ring is fixed.

Note: Hold the shaving head holder in your hand when you reinsert the shaving heads and reattach the retaining rings. Do not place the shaving head holder on a surface when you do this, as this may cause damage.

7 Attach the shaving head holder to the bottom

part of the shaving unit (‘click’).

English

8 To reset the replacement reminder, press and

hold the on/off button for approx. 7 seconds. Wait until you hear two beeps.

Ordering accessories

To buy accessories or spare parts, visit www.shop.philips.com/service or go to your Philips dealer. You can also contact the Philips Consumer Care Centre in your country (see the worldwide guarantee leaflet for contact details).

The following accessories and spare parts are available:

- SH90 Philips shaving heads

- HQ110 Philips shaving head cleaning spray

- RQ111 Philips beard styler attachment

- RQ585 Philips cleansing brush attachment

- RQ560/RQ563 Philips cleansing brush heads

- JC301/JC302/JC303/JC304/JC305 cleaning cartridge

- HQ8505 supply unit

Note: The availability of the accessories may differ by country.

Recycling

- This symbol means that this product shall not be disposed of with normal household waste (2012/19/EU).

+ 386 hidden pages
