Philips 7P6031C User Manual

PROJECTION TELEVISION

A L

PHILIPS

/ /

[]

/

-^7

MAGNAVOX

IMPORTANT!

Return Your Warranty Registration Card

Within 10 Days. See Why Inside.

1 - IB7893 E001

Return your Warranty Registration card today to ensure you receive

all the benefits you’re entitled to.

Once your PHILIPS MAGNAVOXpurchase is registered, you’re eligible to receive all the privileges of

owning a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card

enclosed with your purchase at once. And take advantage of these important benefits.

, Warranty_;

Verification

Registering your product within

10 days confirms your right to max
imum protection under the
terms and conditions of your

PHILIPS MAGNAVOX warranty.

Congratulations on your purchase,

and welcome to the “family!”

Dear PHILIPS MAGNAVOX product owner:

Thank you for your confidence in PHILIPS MAGNAVOX. You’ve selected one of the best-built, best-

backed products
available today. And we’ll do everything in our power to keep you happy with your purchase for many
years to come.

As a member of the PHILIPS MAGNAVOX “family,” you’re entitled to protection by one of the most

comprehensive warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive ail the information and special offers for which

you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction.

All of this is our way of saying welcome-and thanks for investing in a PHILIPS MAGNAVOX product.

Sincerely,

.Owner I

Confirmation

Your completed Warranty
Registration Card serves as

verification of ownership in the

event of product theft or loss

PHILIPS

.M.odeli
Registration

Returning your Warranty

Registration Card right away guar
antees you'll receive all the infor
mation and special offeis which
you qualify for as the owner of your
model.

MAGNAVOX

Robert Minkhorst

President and Chief Executive Officer

Know these

S&ÎGty symbols

CAUTION

RISK OF ELECTRIC SHOCK

A

CAUTION: TO REDUCE THE RISK OF EUCTRIC SHOCK. DO NOT

REMOVE COVER (OR SACK). NO USER4CRVKEASLE PARTS

INSOE. REFER SERVICNO TO OUAUREO SERVICE PERSONNEL

OO NOT OPEN

PHILIPS E!HB Visit our World Wide Web Site at http://www.philipsmagnavox.com

A

P.S. Remember, to get the most from your PHILIPS

MAGNAVOX product, you must return your
Warranty Registration Card within 10 days. So
please mail it to us right now!

A This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical

shock. For the safety of everyone in your household, please do not remove product covering.
.iA The “exclamation point' calls attention to features for which you should read the enclosed lit

erature closely to prevent operating and maintenance problems.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT

TO RAIN OR MOISTURE.
CAUTION; To prevent electric shock, match wide blade of plug to wide slot, and fully insert.
ATTENTION; Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la

borne correspondante de la prise et pousser jusqu’au fond.

2 - IB7893 E001

SAFETY INSTRUCTIONS - Read before operating equipment

This product was designed and manufactured to meet strict quality and
safety standards. There are, however, some installation and operation
precautions which you should be particularly aware of.

1. Read Instructions - All the safety and operating instructions should

be read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should

be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating

instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be

followed.

5. Water and Moisture - The appliance should not be used near water

- for example, near a bathtub, washbowl, kitchen sink, laundry tub,
in a wet basement or near a swimming pool, etc.

Carts and Stands - The appliance should be used only with a cart or

6.

stand that is recommended by the manufacturer.

6A.

Wall or Ceiling Mounting - The appliance should be mounted to a

7.
wall or ceiling only as recommended by the manufacturer.

Ventilation - The appliance should be situated so that its location or

8.

position does not interfere with its proper ventilation. For exampie,

the appliance should not be situated on a bed, sofa, rug, or similar

surface that may block the ventilation openings; or, placed in a
built-in instailation, such as a bookcase or cabinet that may impede

the flow of air through the ventilation openings.

An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination
to overturn.

Heat - The appiiance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.

Power Sources - The appliance shouid be connected to a power

10.

supply only of the type described in the operating instructions or as

marked on the appliance.

Power-Cord Protection - Power supply cords should be routed so

11.

that they are not likely to be walked on or pinched by items placed

upon or against them, paying particular attention to cords and
plugs, convenience receptacles, and the point where they exit from

the appliance.

12. Cleaning - The appliance should be cleaned only as recommended

by the manufacturer.

13. Power Lines - An outdoor antenna should be located away from

power lines.

14. Outdoor Antenna Grounding - If an outside antenna is connected to

the receiver, be sure the antenna system is grounded so as to pro
vide some protection against voltage surges and built up static
charges.

Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper grounding of the mats
and supporting structure grounding of the lead-in wire to an anten
na discharge unit, size of grounding connectors, location of anten
na-discharge unit, connection to grounding electrodes and require

ments for the grounding electrode. See Fig. below.

15. Non-use Periods - The power cord of the appliance should be

unplugged from the outlet when left unused for a long period of

time.

16. Object and Liquid Entry - Care should be taken so that objects do

not fall and liquids are not spilled into the enclosure through open
ings.

17. Damage Requiring Service - The appliance should be serviced by

qualified service personnel when;

A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the appli

ance; or

C. The appliance has been exposed to rain; or

D. The appliance does not appear to operate normally or exhibits

a marked change in performance; or

E. The appiiance has been dropped, or the enclosure damaged.

18. Servicing - The user should not attempt to service the appliance

beyond that described in the operating instructions. All other servic
ing should be referred to qualified service personnel.

Note to the CATV system installer: This reminder is provided to cail the

CATV system installer's attention to Article 820-40 of the NEC that pro
vides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building,
as close to the point of cable entry as practical.

3 - IB7893 E001

Table of Contents

Gettin2 Started

Welcome/Product Registration

Safety/Precautions.....................................................3

Table of Contents

Features and Model Information...............................5

□ On-Screen Features

PICTURE MENU

•❖ ^Adjusting Color, Brightness, Sharpness,
Tint, and Picture Controls

•❖ ^Using the Clearview Control................:..........7

“❖ ■ Adjusting the TV's Convergence Control.,...8

•❖ ■ Using the Flesh Correction Control

FEATURES MENU--------------------------:

•❖ ■ Selecting a Picture Source/RF Switcher
❖ ■ Setting the TV for Closed Captioning

•❖ ■ Setting the TV for Cable or Antenna Signals.... 12

•❖ ^Adding Channels in Memory (Automatically) .13

•❖ Adding Channels in Memory (Manually)

•❖ •Setting the TV Clock....................................15

•❖ Tum-On Timer

•❖ Using the Sleep Timer Control

•❖ Using the Time/Channel Reminder Control

•❖ ^Using the Parental Control

•❖ ■ Adjusting the Channel Display Control

•❖ ■ Using the Language Control

......................................................

---------------------------------

...................................

.............

..................................16

..................

.............

----

......................

.....................

.....................

.....

.........

.......

18-19

.....

2
4

6

9

10
11

14

16

...

17
20

20

Remote Control Operation

Using the Smart Picture Control.................28

B

Using the Smart Sound Control
Using the Smart Surf Control and the Surf button...29
Setting the Remote to Work VCRs
Setting the Remote to Work

Cable TV Converters
Setting the Remote to Work VCRs or Cable

Converters - "Search Method"
Using the Remote's VCR buttons

Picture-In-Picture (PIP)

How to Use PIP (Connections)...........................36-37

How to Use PIP with the TV Remote
Selecting the Picture Source for PIP
Adjusting Picture-in-Picture Color and Tint
More PIP Connections (Cable Converter)

General Information

Tips if Something Isn’t Working
TV Help Menu

Glossary of TV Terms..............................................44

Index.........................................................................45

Factory Service Locations

Warranty...................................................................48

..........................................

.........................................................

...............................

....................

.................................

............................

......................

........................

............

...............

.............................

..................................

28

30-31
32-33

34

35

38
39

40

41

42

43

46-47

SOUND MENU

•❖ ■ Adjusting Bass, Treble, and Balance Sound

Controls............................................................21

•❖ ■ Setting the Bass Boost Control.................21

•❖ Setting the TV for Stereo and SAP Programs ..22

•❖ ■ Using the Sound Image Control

•❖ Using the Volume Display Control

•❖ Using the TV Speaker On/Off Control with
the Audio Output jacks

❖ Surround Sound Speaker Connections and

Variable Audio Output Control

❖ Using the TV's Audio/Video Input and

Output Jacks ...............................................26-27

-----------------------------------

...............

...............

....................................

.......................

23

23
24

25

Set-up and Quick Use Guide

Use the simple Set-Up Guide (supplied with
your TV information packet) for details on;

• Antenna Hook-ups

• First Time Set-Up
(Automatic Settings)

--

.-s=;sg«a

te

s

• Basic TV and Remote
Control Operation

• On-Screen Menu Use

Copyright © 1996 Philips Consumer Electronics Company. All rights reserved.

4 -187893 E001

Picture Menu Controls (continued)

CLEARVIEW

learview is a sharpness feature
which smoothes out back

C

ground snow (or picture noise)
without losing picture image detail
or crispness.

<J> Select CLEARVIEW control.

o

With the PICTURE MENU on
screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

Press the MENU

<l>

to move the RED highlight. Press
the MENU button to select (t^) the
ENHANCED mode.

Press the STATUS button to

clear the screen.

AT

buttons

— PICTURE MENU ■

|№ |»frj

iSitI

— CLEAR^

jj_J NORf

I ENHAtlEDM

_______

H EXIT 1

1 »

¡TitpT"

7 - IB7893 E001

□

COLOR, BRIGHTNESS,

SHARPNESS, TINT, PICTURE

adjust your TV color and

picture controls, select a TV
channel and follow the steps shown
below:

Select BRIGHTNESS, PIC

<X>

TURE, COLOR, TINT, or

SHARPNESS picture control.
With the PICTURE MENU on

screen, move the RED highlight

with the MENU tbuttons. Then
press the MENU (M) button.

Press the (+) or (-) buttons to

adjust the selected control.

Press the STATUS button to

clear the screen.

___

Picture Menu Control Adjustments

-lOTLO^-

rgn

■ i:

IVIL.I<4W

I TINT 1

IcLEARVIEwi

— 1^2-—^

S.MART Help

Remember. When the bar

S scale is centered, control set
tings are at normal mid-range lev
els.

BRIGHTNESS Press {-) or (+) until
dark parts of the picture show good
detail.

PICTURE Press (-) or (+) until

whitest parts of the picture are as

bright as you prefer.

COLOR Press {-) or (+) to add or
eliminate color.

TINT Press {-) or (+) to obtain natu
ral skin tones. (Also see Flesh
Correction on page 9 for more infor
mation).

SHARPNESS Press {-) or (+) to
improve detail in the picture.

Press MENU (M)
to select RED hi
lighted feature.

Select and then press
MENU (M) button to
view an explanation of
the selected feature.

HOW TO SELECT FEATURES

(WITH BUTTONS ON THE REMOTE)

i

(aII ^

^l/lf —f r\

jT\ ) -mNW

Press MENU (M)
A T to move Up

and'Down within
the Menu.

Select and then press MENU
(M) button to view additional
controls grouped under same
feature heading. For
Example: Tint, Brightness,
Picture, etc.

Press MENU (M)-^^

to move from Sidc-to-

Side within the Menu.

6 • IB7893 E001

Picture Menu Controls (continued)

CLEARVIEW

learview is a sharpness feature
which smoothes out back

C

ground snow (or picture noise)
without losing picture image detail
or crispness.

<J> Select CLEARVIEW control.

o

With the PICTURE MENU on
screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

Press the MENU

<l>

AT

to move the RED highlight. Press
the MENU button to select (t^) the
ENHANCED mode.

Press the STATUS button to

clear the screen.

buttons

— PICTURE MENU ■

|№ |»frj

iSitI

— C LEAR ^

jj_J NORf

I EN HAtlEDM

____________________

H EXIT 1

1 »

¡TitpT"

7 - IB7893 E001

□

RED/BLUE CONVERGENCE

onvergence is the correct lin
ing up of the red and blue

C

light paths on the TV screen.
NOTE: If no color fringing (see
Smart Help) shows, then no

Convergence adjustments are nec
essary for your TV.

(BEOINJ

<i> Select CONVERGENCE con

trol.
With PICTURE MENU (2 of 2) on

screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

<l> If there is RED or BLUE color

fringing on the White cross, press
the MENU button to continue.

■ w ■

Picture Menu Controls (continued)

Press the MENU buttons

<i>

to move the red or blue cross
directly over the white cross on the
TV screen.

The red or blue cross is properly

adjusted when it is completely
merged with the white cross. (No
color appears around the edge of

the white cross).

Press the STATUS button to
clear the screen when convergence
adjustments are complete.

Smart Help

Remember. Convergence

* has been set at the factory for
best viewing, but if one or more of
the (red or blue) colors appear
around the edges of objects (color
fringing) follow the steps given in
this section.

I

Use keys to merge the

reO fringe into the WHITE

cross. Press "M* *' to Continue.

8 - IB7093 EOOl

Picture Menu Controls (continued)

FLESH CORRECTION

T Tse the Flesh Correction con-

\J trol to keep skin tone hues (or

facial tint) from varying from TV

channel to TV channel.

<i> Select FLESH CORREC

TION control.
With PICTURE MENU (2 of 2) on

screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

Press the MENU AT buttons

<l>

to move the RED highlight. Press
the MENU button to turn (»^) the
FLESH CORRECTION control
ON.

Press the STATUS button to

clear the screen.

* PICTURE MENU '

I COLOR I

iBRIGtnJ

EXIT i

■ PICTURE MENU •

IjpproLO^

TONVE^N^

I

j^^^TORRECTIOJ^;

/ • • I • \ * \ ' ' \ '

o

ITINTJ

I picture'|[

9 • IB7893 E001

Feature Menu Controls (continued)

CLOSED CAPTION

o

'losed Captioning (CC) allows
you to read the voice content of

C

television programs on the TV
screen. Designed to help the hearing
impaired this feature uses on-screen

"text boxes" to show dialogue and

conversations while the TV program

is in progress.

CBEGINJ

Select CLOSED CAPTION

<i>

ING control.
With the FEATURES MENU on

screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

<|> Press the MENU

AT

buttons

to move the RED highlight. Press
the MENU button to select (t^) the
desired Closed Caption mode - For
Example: "ALWAYS ON" and

"CAPTION 1".
CAPTION 1, 2, 3, 4:

dialogue (and descriptions)

for the action on the captioned

TV program shows on-screen.

(See Important Note on this

page.)

TEXT 1,2, 3,4:

often used for channel guide,

schedules, or bulletin board

information for CC programs.

NOTE: Not all TV programs and product commercials are made for broadcast

with Closed Caption (CC) information included. Neither are all Closed Caption

modes (CAPTION 1-4; or TEXT 1-4) necessarily being used by a broadcast station

during the transmission of a closed caption program. Usually "CAPTION 1" is the
most used mode to view captioned material. Refer to your area's TV program list
ings for the stations and times of Closed Caption shows.

ALWAYS ON
ALWAYS OFF
ON DURING MUTC ONLY

NOTE: The ON DURING
MUTE ONLY control can
be used to set the TV to
turn the Closed Caption
mode "ON” whenever the
MUTE button on the
remote is pressed.

After making your Caption mode
selection, press the STATUS button
to clear the TV screen. The selected
Closed Caption mode will be active.

To cancel, set the Closed Captioned
feature to OFF when finished view
ing.

Smart Help

Remember. Broadcast

stations will often use
spelling abbreviations, symbols,
dropouts and other grammatical
shortcuts in order to keep pace
with the on-screen action. These
type factors vary upon the source
of the captioned text material and
do not indicate a need for service
on the part of the TV.

Closed Caption information will usually appear
in black and white (although some broadcasters
or networks may occasionally use color to high**^
light or draw attention to certain areas.)

This symbol will appear on channels that con­status display is shown.

T-1 - IB7893 E001

CAPTION 1 mode

Example Screen Display

CLOSE CAPriON PROCHAMS ON WXY2

ALL ITEMS ARE EASTERN STANDARO TIME |EST)

CHECK LOCAL LISTINGS

FOR TIMES IN VOUR AREA

FULL SCREEN TEXT

will block TV screen from viewing

—

12:00

Feature Menu Controls (continued)

CLOSED CAPTION

o

'losed Captioning (CC) allows
you to read the voice content of

C

television programs on the TV
screen. Designed to help the hearing
impaired this feature uses on-screen

"text boxes" to show dialogue and

conversations while the TV program

is in progress.

CBEGINJ

Select CLOSED CAPTION

<i>

ING control.
With the FEATURES MENU on

screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

<|> Press the MENU

AT

buttons

to move the RED highlight. Press
the MENU button to select (t^) the
desired Closed Caption mode - For
Example: "ALWAYS ON" and

"CAPTION 1".
CAPTION 1, 2, 3, 4:

dialogue (and descriptions)

for the action on the captioned

TV program shows on-screen.

(See Important Note on this

page.)

TEXT 1,2, 3,4:

often used for channel guide,

schedules, or bulletin board

information for CC programs.

NOTE: Not all TV programs and product commercials are made for broadcast

with Closed Caption (CC) information included. Neither are all Closed Caption

modes (CAPTION 1-4; or TEXT 1-4) necessarily being used by a broadcast station

during the transmission of a closed caption program. Usually "CAPTION 1" is the
most used mode to view captioned material. Refer to your area's TV program list
ings for the stations and times of Closed Caption shows.

ALWAYS ON
ALWAYS OFF
ON DURING MUTC ONLY

NOTE: The ON DURING
MUTE ONLY control can
be used to set the TV to
turn the Closed Caption
mode "ON” whenever the
MUTE button on the
remote is pressed.

After making your Caption mode
selection, press the STATUS button
to clear the TV screen. The selected
Closed Caption mode will be active.

To cancel, set the Closed Captioned
feature to OFF when finished view
ing.

Smart Help

Remember. Broadcast

stations will often use
spelling abbreviations, symbols,
dropouts and other grammatical
shortcuts in order to keep pace
with the on-screen action. These
type factors vary upon the source
of the captioned text material and
do not indicate a need for service
on the part of the TV.

Closed Caption information will usually appear
in black and white (although some broadcasters
or networks may occasionally use color to high**^
light or draw attention to certain areas.)

This symbol will appear on channels that con­status display is shown.

T-1 - IB7893 E001

CAPTION 1 mode

Example Screen Display

CLOSE CAPriON PROCHAMS ON WXY2

ALL ITEMS ARE EASTERN STANDARO TIME |EST)

CHECK LOCAL LISTINGS

FOR TIMES IN VOUR AREA

FULL SCREEN TEXT

will block TV screen from viewing

—

12:00

□ I

CABLE TUNINt

A TOTE: If you went through

1 y First Time Setup (in your

Quick Use Guide), this task has
already been completed for you.

You need to make sure the TV is
set to pick up either Cable TV or
Antenna signals. In other words,

the TV needs to know if you con
nected a Cable TV signal or a nor

mal antenna to its ANTENNA plug.

<1> Select CABLE CHANNEL

TUNING control.

With the FEATURES MENU on

screen, move the highlight
with the MENU t.buttons.

Then press the MENU (M) button.

Feature Menu Controls (continued)

<|> Press the MENU

to move the RED highlight. Press
the MENU button to select (t^) the

desired mode - For Example;
CABLE.

CABLE- K you DO have

NORMAL- If you have an

Press the STATUS button to

<s>

clear the screen.

AT

buttons

Cable TV connected
to the TV. Channels

1- 125 are available.

Antenna connected
to the TV. Channels
2- 69 are available.

12 - IB7893 E001

Feature Menu Controls (continued)

CHANNEL MEMORY

AUTO-PROGRAM.MING

A TOTE: If you went through First

1

V

Time Setup (in your Quick Use
Guide), this task has already been
completed for you.

Your TV can automatically set itself

for local area (or Cable TV) chan

nels. This makes it easy for you to
select only the TV stations in your

area when the CHANNEL A Y but
tons are pressed.

CBEGINJ

<1> Select CHANNEL MEMORY

(START AUTO-PROGRAM

MING) control.
With the FEATURES MENU on

screen, mov^the RED highlight with
the MENU <•! buttons. Then press

the MENU (M) button.

o

Press the MENU button to turn

AUTO-PROGRAMMING ON.
The TV shows which channel num

bers are "SAVED" (t>) as they are
added into memory.

"Auto-programming CHANNEL
MEMORY is finished" shows when
the TV is through adding channels.

<|> Press the STATUS or Menu (M)

button to clear the screen.

Smart Help

Try it out. Press the

_ CHANNELAT buttons and

see which channels you can select.

Remember. An Antenna or Cable TV

signal must first be connected to your

TV so that channels can be saved.

If you want to delete any unwanted

channels from the TV's memory, see

"ADD/DELETE CHANNELS" on

page 14.

Channel Numbers are

Saved in Memory

AUTCM>flOGRAMMING

CHANNEL MEMORY

1 2^

6v^ 8v^
10 11 12
14 15 16

13
17 1B 19 20
21 22

23

Press "M" to

4v^

24

13-1B7893 E001

□

ADD/DELETK CHANNELS

uto-Programming (see page 13)
adds all the channels it can find
(on your Antenna or Cable TV sys

A

tem) into the TV's memory.

Add/Delete Channels makes it easy

for you to add other channels, or

drop unwanted channels, from the

list of channels in the TV's memory.

Select CHANNEL MEMORY
(ADD/DELETE CHANNELS)
control.

With the FEATURES MENU on
screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

Feature Menu Controls (continued)

<l> Press the CHANNEL

number buttons to select the chan
nel you want to add or delete.

Press the MENU ► button to
ADD the channel into the TV's
memory.

Press the MENU button to
DELETE the channel from memory.

Repeat steps 2 and 3 for each chan
nel you wish to add or delete.

Press the STATUS or MENU

<$>

button to clear the screen.

Smart Help

Remember. You can also

* add the VCR/AUX mode

just like a channel. Then by

pressing the CHANNEL
buttons the VCR/AUX mode can

quickly be selected to use the
Input jacks on the rear of the TV
(see page 26).

Note; "VCR/AUX" mode is
located between the lowest and
highest channel numbers within
the ADD/DELETE CHANNEL
control screen.

AT

or

* *

AT

(33

Cm)

SELECT CHANNEL

to DELETE CHANNa

when RNISHED

14 - IB7893 E001

Feature Menu Controls (continued)

\U'

SET CLOCK

A TOTE: If you went through

1

V

First Time Setup (in your
Quick Use Guide), this task has
already been completed for you.

Your TV comes with an on-screen
clock. During normal operation the
clock appears on the screen with
every channel change (and when
the STATUS button is pressed).

<j> Select SET CLOCK control.

With FEATURES MENU (2 of 3)
on screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

Press the remote's number

<l>

buttons to set the time clock.

Press the STATUS button to

set the clock in operation and clear

the screen.

I

Smart Hf.lp

Remember, be sure to

¡press "0" first and then the
hour number for single digit
entries.

The remote's MENU buttons

can also be used to set the hours,
minutes and AM/PM portions of
the clock.

TV Clock settings may be lost
when the TV is unplugged (or AC
power to the set is interrupted.)

You can also set the TV Clock

automatically if you follow the First

Time Set-up procedure for the

Smart Clock feature.

15-IB7893E001

□ I

SET ON TIMER

Tust like an alarm clock you can
U set the TV to turn itself on at the
same time everyday.

rr^tTTT»

<|> Select SET ON TIMER con

trol.
With FEATURES MENU (2 of 3)

on screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

Feature Menu Controls (continued)

<|> Press the MENU

AT

and

MENU (M) buttons to highlight

and select "ON" (t^.

<|> Press the MENU

AT

and

then the MENU (M) buttons to
select "SET ON TIME".

Press the remote's number
buttons to set the "TURN ON"
time for the TV. (Press MENU

T

for AM or PM.)

Press the STATUS button to

set thè "ON TIME" and clear the
screen.

SLEEP TIMER

TTave you ever fallen asleep in

JLJ. front of the TV only to have it

wake you up at two in the morning
with a test pattern screeching in
your ears? Well, your TV can save
you all that trouble by automatical

ly turning itself off.

( BEGIN)

<î> Select SLEEP TIMER control.

With FEATURES MENU (2 of 3)

on screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

Press the MENU ^buttons
to pick the amount of time (15 min
utes to 2 hours ahead) before the
TV will turn itself off.

<|> Press the STATUS or MENU

(M) button to clear the screen after
you have set the time for the TV to
turn off. jmtk.

A

- 8CT ON TlMei——————
Ml

F

OFf

I

IsCTONTiMe |-

ÎHI .

Remember,
to see how many
minutes are left
before the TV shuts
itself off, reselect
the SLEEP TIMER
control screen.

To stop a SLEEP
TIMER setting,

reset the timer back
to OFF. (Turning
the TV off and on,
or pressing a button
during the last
minute of a timer
setting, will also
cancel a setting.)

A few seconds
before the TV is to
shut off a message

will come on the
screen telling you

GOODNIGHT.

16 - IB7893 E001

Feature Menu Controls (continued)

HALF HOUR RFMINDER

ith the Half Hour Reminder
control the TV automatically

W

shows you the current time and

channel every thirty minutes.

rmnni

<i> Select HALF HOUR

REMINDER control.

With FEATURES MENU (2 of 3)

on screen, move the RED high
light with the MENU buttons.

Then press the MENU (M) button.

<|> Press the MENU AT and

MENU (M) buttons to highlight
and select (i^) the EVERY HALF
HOUR item.

Press the STATUS button to

clear the screen.

! □

S.MART Help

Remember, the Time and

_ Channel Reminders will
show on the hour and the half­hour for several seconds.

17 - IB7893 E001

□ I

PARENTAL CONTROL

arental Control allows parents
to block out, or "censor", any

P

channels they think children should
not watch. A channel placed under
Parental Control cannot be viewed
until a correct access code is used to
unlock the channel for viewing.

First let's set your Parental Code:

<1> Select the PARENTAL CON

TROL.
With FEATURES MENU (3 of 3)

on screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

"BLOCK CHANNELS" and
"SETUP CODE" show on screen.

Feature Menu Controls (continued)

NOTE:Your TV left the factory with the Parental Code set to "0000". If you are using
your TV and the Parental Control for the first time, and don't want to SETUP a new
Access code number, you can use the "0000" number to block channels - see next page.
The "0711" Parental Code (shown on this page) is given as a default or way to reset the
Code when the current Access number is not known.

<l>

Press the MENU

MENU (M) buttons to highlight
and select the SETUP CODE item.

Press 0,7,1,1 on the remote.

"XXXX" shows on the ACCESS
CODE SETUP screen as you press
the number buttons.

"INCORRECT ACCESS CODE ­TRY AGAIN" will also show on the

screen.

Press 0,7,1,1 on the remote

again.

"Next Enter Your New Access

Code" shows on the screen.

Enter a new four digit number

code using the remote.

"Access Code Changed" shows on
the screen to let you know the new
code has been set.

Continue to the next page to find
out how to "block" channels from
viewing.

Smart Help

AT

and

• Press MENU ► to go on and start
to “block" channels

• Press MENU to return to the
Parental Control Menu screen.

• Press STATUS to clear the screen.

Parents - it isn't possible

to unlock or defeat your
Censor Code without changing to
a new code number. So if your
Code number changes, and you
didn't change it yourself, then you

will know that someone has
altered the code and the blanked
out channel has been viewed.

18 - 1B7893 E001

Feature Menu Controls (continued)

PARENTAL CONTROL

fter your personal Parental
Code number has been set (see

A

previous page), you are now ready
to select the channels you want to
block out or censor.

<1> Select the BLOCK CHAN

NELS control.

With FEATURES MENU (3 of 3)

on screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

<|> Press the MENU AT and

MENU (M) buttons to highlight
and select the BLOCK CHAN
NELS item.

Enter the correct Parental

I Code number.

o

Number buttons to select the chan-

nel you want to block.

Press the MENU ► button to
"BLOCK VIEWING" on the
selected channel.

Press the MENU button to
"ALLOW VIEWING" on a
blocked channel.

Repeat steps 3 and 4 for any other
channels you wish to block out.

Smart Help

Remember, to make TV

g viewing easier all channels
(and AudioA^ideo Input jacks)
will be unblocked, once the cor

rect Parental Code number has

been entered.
When the TV is turned OFF and
then back ON again. Parental
Control is back in place for all
channels.

twrtwtt Ml snwl

|j!ilU

Please enter Access Code

•OB'

Select snocher Chenoel

for viewing.

BLOCKED CHANNEL SCREEN MESSAGE
(Appears when an attempt to select a blocked
channel is made and Parental Control is ON.)

Note: You can also block out the
use of the Audio/Video Input jacks
on the TV. This stops the viewing
of VCR programs which can be
shown through the A/V IN jacks.
Just select VCR/AUX 1 (located
between the lowest and highest
channel numbers) on the Channel
Blocking screen, and select
"blocked".

19 - IB7893 E001

□

Feature Menu Controls (continued)

CHANNEL DISPLAY

ith the Channel Display con

W

trol you can change the size
and location of the on screen
channel and clock information.

<X >

Select CHANNEL DISPLAY

control.
With FEATURES MENU (2 of 3)

on screen, move the RTO high
light with the MENU tbuttons.
Then press the MENU (M) button.

<l>

Press the MENU

MENU (M) buttons to highlight
and select (»>') the LARGE or
SMALL display control.

Press the STATUS button to

clear the screen.

AT

and

- MATURE M0>IU «

i EWT j

171 iu«g I

□ SMALL • Charmai A«tM<

rsn

UlHMi

Try it out. g
Press the CHAN
NEL

AT

buttons

and you should see

the Display Size you

selected.
Remember. The

SMALL SIZE dis
play shows only the
channel number, not
the time (or clock).

CHANNEL DISPLAY OPTIONS

LANGUAGE

A Jote: If you went through First

1V Time Setup, This task has

already been completed for you.
For our Spanish and French

speaking TV owners an on-screen
LANGUAGE option is present.

With the LANGUAGE control you
can set the TV's on-screen fea
tures to be shown in either

English, Spanish or French.

IBEOINJ

Select the LANGUAGE DIS

<i>

PLAY control.
With FEATURES MENU (3 of 3)

on screen, move the RED high
light with the MENU buttons.
Then press the MENU (M) button.

<|> Press the MENU

MENU (M) buttons to highlight
and select {y*) English, Spanish
(ESPAÑOL), or French (FRAN
ÇAIS) on the display control.

Text for the on-screen Menu will
change to the selected language.

AT

and

DSIQI

Remember, g
the Language con
trol only makes the
TV’s on-screen
(MENU) items
appear in English,
Spanish, or French
text. It does not
change the other on
screen text features

such as Closed
Captioned (CC) TV
shows.

Press the STATUS button to

<I>

clear the screen.

LANGUAGE DISPLAY OPTIONS

20 - IB7893 E001

Sound Menu Control Adjustments

BASS, TREBLE, BALANCE

"X/bur TV also has individual

JL sound adjustment controls. The

BASS (low frequency), TREBLE

(high frequency), and Speaker
BALANCE may all be used to
adjust the sound playback of TV

programs.

CPESiri)

<i> Select BASS, or TREBLE, or

BALANCE sound control.
With the SOUND MENU on the

screen, move the RED highlight
with the MENU <buttons. Then

press the MENU (M) button.

<l> Press the (+) or (-) buttons to

adjust the sound control to levels

you prefer.

o

Press the STATUS button to

clear the screen.

1-^

BASS BOOST

'/ic BASS BOOST control
increases the low frequency

T

audio range of the TV. This creates
a deeper, fuller playback sound
which can be heard through the

TV's speakers.

(BEGIN)

<sp* Select BASS BOOST sound

control.

With the SOUND MENU on the
screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

<l>

Press the MENU

AT

and

MENU (M) buttons to highlight

and turn ON (»^) the BASS

BOOST control.

— MAIN MENU
JPICTUR^ -¡SOUND

I FEATURES

In HELP]

EXIT I

Select and then press MENU
(M) button to view additional
controls grouped under same
feature heading. For
Example: Treble. Balance,
Bass Boost, Stereo, etc.

— SOUND MENU

isASsI tTHEBlip

1 BALANCE J

»STtREoj

;iBASSBOOST|-.

1 • 1 • 1 1 • 1 ■ »

¡SOUND IMAGE 1

ifMore^

_ 1 0F3—•

Press the STATUS button to

clear the screen.

21 - IB7893 E001

□

STEREO

bur TV is able to receive

broadcast stereo TV programs.

y

The TV is equipped with an ampli

fier and twin speaker system

through which the stereo sound
can be heard.

A RED stereo light (on the front of
the TV) will come on when a
stereo broadcast is received.

Select STEREO sound control.

Sound Menu Control (continued)

MAIN MENU

I PICTURE I

y i=EATUREsl

Remember, g
If a stereo signal is

not available and
the TV is placed in
the STEREO mode,
sound coming from
the TV will remain
monaural (mono).

■ SOUND MENU

iBtósl

I BASS BOOSTi

With the SOUND MENU on the

screen, move the RED highlight
with the MENU buttons. Then
press the MENU (M) button.

Press the MENU

<S>

AT

MENU (M) buttons to highlight
and turn ON (»^) the STEREO
mode.

Press the STATUS button to

clear the screen.

SECOND AUDIO PROGRAM

Second Audio Program (SAP) is
part of the stereo broadcast sys
tem. Sent as a third audio chan
nel SAP can be heard apart from
the current TV program sound.
TV stations are free to use SAP

for any number of purposes, but

many experts believe it will be
used for foreign language transla
tions of TV shows (or for weath
er and news bulletins.)

and

DISPLAY VOLUME I

I SECOND AUDIO PROGRAM I*

ii BOT I

f » 1 « \

EXIT I

MONO AT ALL TIMES

v'l I STEREO IF AVAILABLE I

SECOND PROGRAM SOUND CAN
ONLY BE SELECTED WHEN
SAP INFORMATION IS PRESENT

, ON CURRENT CHANNEL.

¡_MOn£,.

• aoF3-

NOTE: If a SAP signal is not pre

sent with a selected program, the

SAP option can not be selected.

"This program does not contain

SAP information" will show on

the TV screen.

D NORMAL SOUND

El I SECOND PROGRAM SOUNol

A

c »

22 - IB7893 E001

Sound Menu Controls (continued)

SOUND IMAGE

'/ie Sound Image control can be

used to add greater depth and

J

dimension to both monaural

(MONO) and STEREO TV sound.

<j> Select SOUND IMAGE con

trol.
With the SOUND MENU on the

screen, move the RED highlight
with the MENU buttons. Then

press the MENU (M) button.

<|> Press the MENU

MENU (M) buttons to highlight
and select (y) the desired SOUND
IMAGE mode.

For Example: "MAXIMUM"

spreads the Sound Image effect as
wide as possible.

Press the STATUS button to

clear the screen.

AT

and

— 90UN0MENU

BaALANcel

1 EXITj

MINMUM

ImaximumI

NOEXPANSDN

¿«tI |heu8 I next,,,.I

boost!

’i SOUND IMAGE N-

1 Of 3 —

#

-------------------

! □

Remember, ^
with the Sound
Image control
turned ON even
monaural (mono)
audio source materi
al can be heard
through rear
Surround Sound

speaker connections
(see page 25).

Note: The monaural

version of Surround
Sound may be loud
er at the rear set of
speakers than what
is normally heard
with true stereo sig
nal Surround
Sound, but this is
normal.

DISPLAY VOLUME

T

Jse the DISPLAY VOLUME

\_y control to see the TV's volume

level settings on the TV screen.

Once set the Volume Display will
be seen each time the VOLUME
buttons (on the TV or remote) are

<1> Select DISPLAY VOLUME

control.

With SOUND MENU (2 of 3) on

screen, move the RED highlight

with the MENU buttons. Then

yr

press the MENU (M) button.

Press the MENU

<l>

AT

and

MENU (M) buttons to highlight

and turn ON y) the DISPLAY

VOLUME control.

Press the STATUS button to

clear the screen.

lil

..........

...

I^BAUN^

IjsTS^
jBErli

' yEAKEreg

lOtSPLAYVOLUMEl-

Vtrn ".r>l.rr

^BASSBOOSrl

¡SOUND IMAKI

Smart

HF.LP ; •

Remember, g
"DURING
ADJUSTMENT"
means the volume
level will be on
screen whenever the
Volume buttons are
pressed.

23 - IB7893 E001

□

TV SPEAKERS

buld you like to hear TV pro
grams through your audio hi-

W

fi system? The TV's Variable Audio
Output jacks and TV Speaker
On/Off control work together to
offer you this TV sound option.

Connect the R(ight) and L(eft)

VARIABLE AUDIO OUT jacks
on the TV to the R and L Audio
Input jacks on your amplifier or
sound system.

Set the audio system’s volume to
normal listening level.

<|> Turn the TV and audio system

ON. You can now adjust the sound
level coming from the audio sys
tem with the Volume

on the TV or remote.

(.peeiH)

AT

Sound Menu Controls (continued)

BACK OF TV

;j|Tv№ EAKgSj^

VARIABLE

AUDIO

OUTPUTJACKS

buttons

To hear the TV sound from only
the audio system speakers, select
TV SPEAKERS control.

With SOUND MENU (2 of 3) on

screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

<|> Press the MENU

MENU (M) buttons to highlight
and turn OFF (»^) the TV SPEAK
ERS control.

You should now only hear TV

sound coming from the audio sys
tem speakers.

Press the STATUS button to

clear the screen.

Remember, the audio sys-

§tem may have to be in
AUX(iliary) mode to play sound
from the TV (Outputs).

Note: When the TV SPEAKER
control is set to "NORMAL" (for
TV speaker operation) make sure
the VARIABLE AUDIO OUTPUT
control (see next page) is also set
to "STEREO" in order for the TV's
AUDIO OUTPUT jacks to work
properly.

AT

Smart Help

and

k

24 - IB7893 E001

Sound Menu Controls (continued)

SURROUND SOUND

T^y adding optional external

IJ speakers to the TV's sound sys

tem, you can create the feeling of
reflected sound that surrounds you
at a movie theater or concert hall.

Connect both external speak
ers to the speaker wire terminals
on the TV.

Recommended speakers: 8ohm, 15
watt minimum. Be sure the (+) and
(-) speaker wires are connected to
the correct R(ight) and L(eft)
speaker terminals on the TV.

Place the speakers so the view
ing area is between the .TV and the­rear surround speakers. (See over
head view drawing.)

REAR SURROUND SOUND

SPEAKER TERMINALS

___________8____1____

VCAIAUX IN I

V106O At mm 1

0©©l

VIOCO VAR AUDIO OUT 1

niiT 8URAUOIOOUT

®®®l

1 1

-----------------a--------

BACK OF TV

LJ

o

Smart

Help

Remember, _
Surround Sound
will not work with
only one speaker
connected; or with
monaural audio
material (unless the
Sound Image con
trol is turned ON ­see page 23.)

Turn TV ON and place the

STEREO control to the "STEREO

IF AVAILABLE" (i>) position.

After setup whenever a stereo sig
nal is received the audio will be
heard in Surround Sound.

VARIABLE AUDIO OUTPUT

the TV's Variable Audio Output
jacks can also be used for

7

Surround Sound. Once they are
connected an external hi-fi system
its speakers can be used for the

playback of Surround Sound.

(begin)

Connect the R(ight) and L(eft)

<i>,

VARIABLE AUDIO OUT jacks
on the TV to the R and L Audio
Input jacks on your amplifier or
sound system.

REAR SURROUND SOUND SPEAKERS

Note: The rear Surround Sound speakers will not
be heard at the same volume level as the front TV
speakers. It is intended for the rear speakers to give
a background noise effect which requires a lower
volume level than the TV’s front speaken.

REAR SPEAKER

PRIMARY VIEWING AREA

REAR SPEAKER

VARIABLE AUDIO

OUTPUT JACKS

Turn TV ON and place the

VARIABLE AUDIO OUTPUT on
screen control to the SURROUND
(te') position. (Select the Main Menu
Sound option, screen 3 of 3).

AUDIO SYSTEM SPEAKERS USED AS REAR

SURROUND SOUND SPEAKERS

25 - IB7893 E001

□ :

VCR7AUX INPUTS

'^he TV's Audio/Video Input
jacks are for direct picture and

J

sound connections between the TV

and a VCR (or Video Disc Player,

etc.) that has AudioA'ideo Output

jacks.

To view the playback of a VCR
tape by using the AudioA'ideo
Input jacks on the TV:

Cbegin)

Connect the VIDEO OUT jack

from the VCR to the VCR/AUX

VIDEO IN jack on the TV.

<|> Connect the AUDIO OUT

jacks R(ight) and L(eft) from the

VCR to the VCR/AUX AUDIO IN

jacks on the TV.

Using the AudioA^ideo Input Jacks

PICTURE AND SOUND FROM PLAY

BACK OF VCR TAPE

Select the "VCR/AUX" PIC

<s>

TURE SOURCE SELECT con

trol on the TV.
With the FEATURES MENU on

screen, move the ^D highlight
with the MENU tbuttons.

Then press the MENU (M) button.

Press the MENU

<$>

AT

and

MENU (M) buttons to highlight
and select (i^') the VCR/AUX
mode.

<|> Turn the VCR ON and press

PLAY to view the tape on the TV.

Smart Hfxp

Remember, an easy way

I

to select VCR/AUX mode is
to press the VCR button on the
front of the TV. (Channels 3 and 4
can also be selected in this way.)

Or if you have added VCR/AUX
to the TV's channel memory (see
page 14), just press the CHAN
NEL

AT

buttons to select the

VCR/AUX mode.

If you have a single (monaural) Audio Output
VCR, ”Y" connectors are available to complete
your connection. Contact your dealer, or our
Piuts Information Center (1-800-292-6066) to
order any optional accessories.

26 -107893 E001

Using the AudioA^ideo Input Jacks

AUDIOA^IDEO OUTPUTS

o

'he Audio/Video Output jacks
on the TV can be used to

J

record TV programs on VCRs

which have Audio/Video Input

Jacks.

To record TV programs by using
the Audio/Video jacks on the TV:

<i> Connect the VIDEO OUT jack

from the TV to the VIDEO IN Jack
on the VCR.

<|> Connect the AUDIO OUT

jacks R(ight) and L(eft) from the
TV to the AUDIO IN jacks on the

VCR.

<i> Select the "ANTENNA" PIC

TURE SOURCE control on the
TV.

With the FEATURES MENU on

screen, move the RED highlight
with the MENU buttons.

Then press the MENU (M) button.

PICTURE AND SOUND BEING

RECORDED ON VCR.

AUDIO

OUT

(RED/

WHITE)

Select the channel on the TV that
you want to record.

Turn the VCR ON. Put a cas

sette tape in the unit and place the

VCR in the RECORD mode.

S.MART Help

Remember, if the VCR

§has an INPUT SELECTOR
switch, place it in the LINE or
CAMERA position.

Unattended Timer Recordings
with a VCR are possible, but not
recommended with this connec
tion since the TV must be left ON

for the VCR to record.

27 - IB7893 E(XI1

SMART PICTURE

J^egardless of what type ofpro-

J\gram your watching, your TV

has automatic video control settings
matched for your current program
source or content. The Smart Picture

feature quickly resets your TV's video

controls for a number of different
types of programs and viewing condi
tions you may have in your home.

Press the Smart button on the

<£>

remote.

I

Press the Menu (M) button to

<l>

select the Smart Picture feature (high

lighted in red).

<l>

<$>

Press the Menu (M) A or T but

tons to choose any of the preset view
ing categories (Example: Cartoons,
Movies, etc.). Then press the Menu
(M) button to select the highlighted
control.

Press STATUS button on the

remote control to clear the screen.

Remote Control Operation

o©o

©

«1H qt M w B

*■ " 0 0 t

Remember, _
with the Smart
Picture “ CUSTOM”
mode selected you
can set a number of

video controls to

your own preference.

Use the remote’s
SMART button to
reselect these person
ally adjusted Custom
settings contained
within the Smart
Picture feature.

The video control
settings for the

Smart Picture cate

gories (except CUS
TOM) are memo
rized into the TV at

the factory and can

only be reset by

field and service

technicians.

SMART SOUND

re you tired of the sound of
commercials following you
throughout the house? Smart Sound

A

allows you to preset a desired vol
ume level that the TV sound will not
go above. This makes for an even,
more consistent sound by reducing

the “peaks" and “valleys" that can

occur during commercials.

n^iTTTi

Press the Smart button on the

I remote.

With the SMART Menu on

screen, move the RED highlight
with the Menu tbuttons. Then
press the MENU (M) button to
select the highlighted Smart Sound
control.

Press the Menu A or T and

then the Menu (M) button to turn
the Smart Sound control ON (or
OFF.)

Press the STATUS button to

clear the screen when completed.

KfZJ "f

■ A.!''

...V -I SOUND l-^

-----

Milt\N

Remember,
Smart Sound works

for sound levels
coming from either
the Antenna/Cable
input on the rear of
the TV (RF audio);
or the Auxiliary
(VCR/AUX IN)
audio inputs.
When using a Cable
Converter Box with
the Smart Sound
Control ON, the
TV’s volume level
may take up to ten
seconds to gradually
increase to normal

listening levels

(when the TV’s first

turned on). This is

considered NOR

MAL with various

Cable Converter

Box use.

28 - IB7893 E001

2-Ch,vnm;l Si ui/S.\iaut Suuk

"list" or series of previously
viewed channels can be selected

A

with the SURF button on your remote
control. With this feature you can
easily switch between different TV

programs that currently interest you.

The Smart Surf control allows you to
set up to 10 channels in its quick
viewing "list”.

Press the Smart button on the

remote.

With the SMART Menu on

<l>

screen, move the RED highlight with
the Menu (M) buttons. Press the

MENU button to select the highlight

ed Smart Surf control.

Press the Menu ▲ or T, then the

Menu (M) button to select either
Smart Surf or 2-Channel Surf. (See
explanation of Surf options with the

illustration on this page.)

Remote Control Operation

To Use 2-Channel
Surf:

With the 2-Channel
Surf control ON,
select the two desired
channels for viewing
with the number but
tons on the remote
control.

Press the SURF but

ton on the remote to
"toggle" between the
two selected channels.

2 CHANNEL SURF- Current and
one previous channel in the ring.

SMART SURF - Current and up to
nine additional channels available in
the ring. Note: The Channel Surf
ring can be used with fewer than ten
channels. In this way, the number of
Surf channels can match or fit your
present viewing interests.

Press STATUS button on the

<l>

remote control to clear the screen.

How To U.SK SiMAUT SUKF

r

With the Smart Surf control

<i>

ON (see above), select a desired
channel for viewing. You can use
the number buttons on the remote (or
the Channel AT buttons).

<|> Press the SURF button on the

remote. (Some channel numbers
may already appear within the Surf
channel list.)

Press the Menu button to "ADD"

the selected channel to the Surf list.
Select the next desired channel and

repeat steps 2 and 3. Continue until

all desired channels are on the Surf
list.

Note: To Delete a channel from
the Surf list just press the SURF
button to select die desired chan
nel. Then press the Menu button

and the channel will be immedi
ately dropped from the on screen
Surf list.

<|> Press the SURF button on the

remote to quickly review current

action on channels contained within
the Surf list.

29 - IB7893 E001

bur remote control is set to

work your TV and many

y

infrared remote (IR) control

VCRs. However, an easy one
time step may be necessary
before the remote will work your

VCR.

Try this initial check to see if
going on to the following section

is necessary.

rr^rTTTI

Press the VCR System but

ton on the remote.

Point remote toward VCR

<l>

and press the POWER button.

Does the remote turn the VCR

<l>

ON?
IF YES, ® and try the other
VCR buttons on the remote. If
they also work the VCR, then
the remote is ready and no fur
ther steps are needed.
If NO, continue...

Setting the Remote to Work VCRs

<3> First look up a TWO-DIGIT

remote code number for your
brand VCR before going through
the simple ”1,2,3" steps (on the
following page).

continue to next page

Smart Help

Remember, if more than

one number is listed, you
may have to try more than the first
two-digit code given in order to
locate your VCR's remote code.

VCR

BRAND
Akai

................

Capehart ....

Conoid

............

Curtis Mathes
Daewoo

Emerson .... ... .20, 31, 34, 40

Fisher

Goldstar

Go Video ....

Hitachi
JVC
Magnavox ...

Matsushita ...

Mitsubishi ...

Multitech ....

NEC

..........

.............

..........

............

.................

...............

REMOTE VCR REMOTE

CODE NO. BRAND CODE NO.

............

.........................

.........................

.........................

.........................

...................

.........................

...................45, 46 Sharp

.

.............14, 47, 48 Sony

...................

...................01, 02 Toshiba..................

.16, 17,38, 39,50 Video Concepts .. ...................29

...................

.........................21

24, 25, 36

..................

33
13
42

33 Samsung................

06, 07 Sanyo

23 Sears ..................... ...................08

03,51
00, 05 Teknika

27, 28

Panasonic
Philips

Philips Video CD
RCA

Sansui ...................

Shintom.................

Zenith

.............

...................

.................

...................

.....................

.....................

.................

...................

04,32,42,43,44

....01,02,52

............

..................

............

..................

...................13

............

...................35

... .09,10,41

...................26

............

...................15

00, 05

37

22, 30

49

11,12

18,19

30 - IB7893 E001

'K Tow that you have looked up

1

V

the two-digit Remote Code

Number for your brand of VCR

(on previous page), you are
ready to follow the four simple
steps below.

Please read through steps 1-4
before beginning.

Press and release the REC

I (RECORD) button.

Within thirty seconds after
releasing the REC button, press
and release the VCR System
button.

Within thirty seconds after
releasing the VCR System but
ton, ENTER THE TWO
DIGIT CODE NUMBER for

the desired VCR. The remote is
now ready to send commands to
the VCR.

<Ci^ Point the remote at the VCR.

Press the POWER button on the
remote to turn the VCR ON.

S.MART Help

Try it out. The Channel

and VCR buttons on the
remote should now operate the
VCR.

Remember, if this doesn’t work
the first time, repeat steps using
the same remote code number.

If after a second try the remote
does not operate your VCR, and
there are more code numbers list
ed for your brand VCR, use the
next listed code number.

If after repeated attempts the code
number method does not work
your VCR, try the "VCR
SEARCH" method on page 34.

31 - IB7893 E001

Setting the Remote to Work Cable TV Converters

'our remote control is set to

work your TV and many

y

infrared remote (IR) control
Cable Converters. However, an
easy one-time step may be neces

sary before the remote will work
your Converter.

Try this initial check to see if
going on to the following section
is necessary.

n^^TTTI

Press the CBL System button

I on the remote.

Point remote toward Cable
Converter and press the POWER
button.

<s>

<i> First look up a TWO-DIGIT

Does the remote turn the

Converter ON?

IF YES, ® and try the CH
and CH number buttons on the

remote. If they also work the
Converter then the remote is
ready and no further steps are

needed.
If NO, continue...

remote code number for your
brand Converter before going
through the simple "1,2,3" steps
(on the following page).

continue to next page

Smart Help

Remember, if more than

g one number is listed, you

may have to try more than the first
two-digit code given in order to
locate your Converter's remote
code.

A T

CONVERTER REMOTE

BRAND CODE NO.
Archer

..................................

Diamond

Drake....................................37

Gemini
Hamlin

Hitachi..................................25

Jerrold .00,01,02,03,04,05,46,55
Macom

Magnavox.............................17, 31

NSC......................................49

Oak.............................06,27,39

Panasonic
Philips
Pioneer
Regency

..............................

.................................

..................................

............................

........................

..............

19,20,21,24,26

............................

................................

28
23

45

14, 15

29, 38

18, 35

09, 32

10, 11

CONVERTER REMOTE

BRAND CODE NO.

Rembrant

Salora....................................52

Scientific Atlanta .. .08, 22, 47

Sheritech ..............................34

Starcom ................................30

Sylvania

Texscan ................................48

Tocom
Toshiba
Uniden Satellite
Unika
United Satellite
Universal
Video Tech
Video Way

Zenith.........................07, 41, 42

..............................

................................

.........................

................................

....................................

.............................

...........................

...........................

12,13, 53

....................

....................

33

16
43

44
50
54
36
40

51

32 - IB7893 E001

A Tow that you have looked up

1

V

the two-digit Remote Code

Number for your brand of Cable

Converter (on previous page),
you are ready to follow the four
simple steps below.

Please read through steps 1-4

before beginning.

( BEGIN j

Press and release the REC

j (RECORD) button.

Within thirty seconds after
releasing the REC button, press
and release the CBL System

button.

Within thirty seconds after

releasing the CBL System but
ton, ENTER THE TWO
DIGIT CODE NUMBER for
the desired Converter. The
remote is now ready to send
commands to the Converter.

Cable Converter

№ №

S' M ® iV

Pi

va

r*USH

1 SURF)

PI

CH

o

Point the remote at the
Converter. Press the POWER
button on the remote to turn the
Converter ON.

Smart Hfxp

Try it out. The Channel

land POWER buttons on the
remote should now operate the
Converter.

Remember, if this doesn’t work
the first time, repeat steps using
the same remote code number.

If after a second try the remote
does not operate your Converter,

and there are more code numbers
listed for your brand Converter,
use the next listed code number.

If after repeated attempts the code
number method does not work
your Converter, try the "CON
VERTER SEARCH" method on
page 34.

33 - IB7893 E001

Setting Your Remote To Work VCRs, Converters - Search

bur TV remote can be set to

work your VCR or Cable

y

Converter by what is called the

SEARCH method.

If the "REMOTE CODE" number
method shown in the previous sec
tion did not set your remote to
work your VCR or Converter, then

follow the easy steps listed below.

Please read through steps 1-4
before beginning.

Press the POWER button on

<S>

the VCR or Converter to turn the
unit ON.

Stand at least six feet away
from the front of the VCR or •
Converter.
Point the remote toward the unit.
HOLD DOWN the SURF and
the desired System (V CR or
CBL-Converter) buttons at the
same time. KEEP HOLDING
BUTTONS DOWN.

CABLE CONVERTER

Watch the Channel Indicator
on the unit.
Channel Numbers will SCAN UP
when the unit has been identified.

This may take up to two minutes.

Release the SURF and System
(VCR or CBL) buttons as soon
as channel numbers start to scan
up. The code has been identified
and the remote is ready to operate
with the VCR or Converter.

Smart Help

Remember, a minute or

two can seem very long, but
the code should be located within
two minutes.

Don't let the VCR scan up more
than five channels. If you do the
remote may pass up the right code

and another two minute search

cycle will have to be repeated.

If no channel change happens
within two minutes, repeat steps

1-4. Should a channel change still
not occur, the remote will not
work with the desired unit.

la

Iq

imc/oiift K» a amr n nmT>

PIP

P\

[qI

34 - IB7893 E001

hen using the TV remote
with a VCR, first make cer

W

tain it is set to control your VCR
(by the REMOTE CODE or
SEARCH method - see earlier
section).

Press the VCR System but-

I ton on the remote.

<l> Point the top of the remote

toward the front of the VCR
(remote sensor window) when
pressing buttons.

Using the Remote's VCR Buttons

Play Button

Press to playback a tape. Hold down
after pressing the RECORD button to
start a recording.

Stop Button

Press to stop the tape.

Record Button

Hold the RECORD button down, and
then press the PLAY button to begin
a VCR recording.

Rewind Button

Press to rewind tapes. For some
VCRs you may need to press STOP
button first then REWIND. In play

back mode, hold button down to view
picture moving rapidly in reverse.

Pause Button

Press to temporarily stop the tape dur
ing a playback or recording. Press
again to release Pause.

TV-VCR Button

Press to the VCR position ("VCR"
indicator on the VCR will light) to

view the playback of a tape. Press
again to place in the TV position
("VCR" indicator on the VCR will go

OFF) to view one program while

recording another program.
When used with the TV the TVA'CR
button works as a source button. Each
press cycles the TV between chan
nels 3 and 4; or the VCR/AUX Input
mode. It is a quick one-button way to
select these channels and modes
(without directly entering the TV's
Menu system.)

Fast Forward Button

Press to rapidly advance the tape. For

some VCRs you may need to press
STOP first then FF. In Playback
mode hold button down to view the
picture moving rapidly in the forward
direction.

Channel Scan Buttons

Press to scan up or down through
VCR channel numbers.

Number Buttons

Press buttons for direct VCR channel

selections.

VCR System Button

Press to send remote commands to
the VCR.

Power Button

Press to turn the VCR ON and OFF.

Smart Help

Remember, the VCR but-

S tons on the remote will not

operate your VCR if those fea
tures are not already found on
your VCR remote control.

Note: All VCR functions (particu
larly Search, Rewind, Fast
Forward, etc.) will operate the
same as with the original VCR
remote control provided with the
VCR.

35 - IB7893 E001

□ I

icture in Picture (PIP) is the
showing of two pictures on the

P

TV screen at the same time. (One

main screen picture and one small

inset picture - or PIP).

Note: The PIP picture must be
supplied by a VCR (or other

accessory equipped with a VIDEO
OUTPUT jack). If you already
went through FIRST TIME SETUP
(in the Quick-Use Guide), then the

connections for PIP have been
completed.

To see how channels selected on a
VCR can be shown as PIP:

How TO Use the Picture-In-Picture (PIP) Feature

C BEGIN]

<t>

Connect the VIDEO OUT
jack on the VCR to the
VCR/AUX VIDEO IN jack (yel
low) on the TV.

Also connect the AUDIO OUT (R

and L) jacks from the VCR to the

VCR/AUX AUDIO IN jacks (red

and white) on the TV.
Also be sure the normal antenna

connection between the VCR and
TV are in place.

<l> Move to the next page after

the VCR to TV PIP connections
are completed.

S.MART HfXP

For other possible PIP

connections see page 41 for
the "More PIP Connections" sec
tion.

If you have a single (monaural)
Audio Output VCR, "Y" connec
tors are available to complete your
connection. Contact your dealer,
or our Parts Information Center
(1-800-292-6066), for details.

OUTDOOR UHFA'HF

ANTENNA

VCR

36 - IB7893 E001

A Tow that you have completed

1

V

the required connections on

the previous page you are ready to

follow the simple steps shown

below.

<i> Turn the VCR and TV ON.

Place the VCR in the TV mode -

Use the TVA^CR button on
the VCR (or on the TV remote
if it has been set to work with
your VCR - see page 30.)

Place the TV's PIP SOURCE

SELECT control to "VCR/AUX"-

With FEATURES MENU (3
of 3) on screen, move the RED

highlight with the MENU (M)

tbuttons. Then press the
MENU button.

Press the MENU AT and
MENU (M) buttons to

highlight and select the
"VCR/AUX" (»^) item.

VCR IN “TV MODE"

(VCR Indicator Light will go out)

VCR - FOR PIP CHANNEL

• PIP SOURCE SELECT

ANTENNA

✓

IVCR/AUXI

PIP INPUT CONTROL SET TO "VCR/AUX"

TV - FOR MAIN SCREEN CHANNEL

<$>

Select the channel on the VCR

to view in the PIP window.
Select the channel on the TV to

view on the main screen.

<§> Press the PIP ON/OFF button

on the remote.

The PIP window should show in

one of the comers of the TV
screen.

Smart Help

Remember, if you see the

same picture on the main
screen and in the PIP window, you
need to be sure the TV's PIP
Picture Source control (page 39) is
set to "VCR/AUX".

No sound will be heard with the
PIP picture. See page 38 on how
to "SWAP" the PIP picture with
the main screen picture so that
sound can be heard.

Also see the following page on
how to operate other PIP features

with the remote controls

TV

SELECTED

CHANNEL

IUT» ^2i!!!^

ieri

o

Q

Be sure to point the remote at the
front of the VCR when pressing
VCR function buttons.

37 - IB7893 E001

Qi

using the PIP buttons on the

remote the PIP picture can be
moved and swapped with the main
screen. The main screen picture
can also be frozen in the PIP win
dow.

Press the PIP ON/OFF button

<i>

to show the PIP picture.

PIP appears in a comer of TV
screen. Press PIP ON/OFF again to
remove PIP from the main screen.

<i> Press the PIP POSITION but

ton to move the PIP picture (from
comer-to-comer on the TV
screen.)

This feature allows you to move
PIP and avoid blocking off any
main screen action.

Using PIP with the Remote Control

Remember, g
if the TV is show
ing a "VCR/AUX"
supplied picture on

the main screen
(when the TV and
VCR are turned
OFF), a blank
screen will appear
when the TV is
turned back ON
again.

If this happens, just
press the CH(annel)

A

or T buttons to

select a TV station
for normal viewing.

With PIP on the TV screen,

press the SWAP button to swap

the main screen picture with the
PIP picture. See "Smart Help"
note on this page.

Press FREEZE to hold the cur
rent MAIN screen picture in the
PIP window (Main picture is still
active).

If PIP is currently OFF, the PIP

window will automatically appear.

Press FRZ repeatedly to update

the frozen PIP with current pic
tures from the Main screen.

You cannot reposition a frozen
PIP picture.

Press the PIP ON/OFF button to
drop the frozen PIP picture from
the screen.

Press the PIP SIZE button to

change the size of the PIP window

shown on the TV screen.
Press the PIP SIZE button again to

see and compare the large and
small size PIP windows.

You cannot change the size of a

frozen PIP picture.

38 - IB7893 E001

Selecting the Picture Source for PIP

I'll* SOURCE

^he picture for the PIP window
can come through either the

T

ANT/CABLE or VCR/AUX Inputs
(on the rear of the TV). PIP Picture
Source simply tells the TV which
one of these sources it is to show in

the PIP window.

<|> Select PIP SOURCE control.

With FEATURES MENU (3 of 3)
on screen, move the RED highlight
with the MENU tbuttons. Then

press the MENU (M) button.

<|> Press the MENU AT and

MENU (M) buttons to highlight

and select either the ANTENNA or
VCR/AUX (J>) item.

VCR/AUX- for a picture signal

coming from the
VCR/AUX IN
Audio/Video jacks
on the TV.

ANTENNA- for a picture signal

coming from the
ANT/CABLE Input
on the TV.

o

Press the STATUS button to

clear the screen.

Smart Help

Remember. The PIP

g screen will be blank unless a
signal is connected to the selected
source (either ANT/CABLE or
VCR/AUX Inputs) on the rear of
the TV.

ANTENNA

IVCB/AUXI

0

39 - IB7893 E001

EHI

PIP COLOR/PIP TINT

'T'he Picture-In-Picture (PIP)

JL Color and Tint controls are

used to make fine tune adjustments

to the color settings for PIP (when
it is shown on the TV screen).

<S> Select PIP COLOR (or PIP

TINT) control.

Adjusting Picture-In-Picture Color and Tint

With PICTURE MENU (2 of 2) on
screen, move the highlight
with the MENU Ibuttons. Then

press the MENU (M) button.

<s>

Press the MENU AT buttons

to move the RED highlight. Press
the MENU button to turn the PIP
COLOR or TINT control ON.

The PIP automatically comes on to

show the PIP window on the TV
screen.

Press the (+) and (-) buttons to

adjust the PIP for Color (or Tint)
levels you prefer.

Press the STATUS button to

clear the screen.

o

S.MART Help

Remember. Although

S there are separate COLOR
and TINT controls for PIP, the
adjustment levels for these con
trols depend on the TV's main pic
ture. For example: If the main
screen is showing a black and

white picture, PIP would also be
in black and white (even though
its source is in color).

[[soundJ

ISATugiy

T?-,P)Cppp^MENU —

I EXIT I fHELpi

40 - IB7893 E001

□ I

IP hookup with Cable

Converter Box and VCR.

rT^?TT7>

First use an optional signal

<x>

splitter and connect the original
cable TV signal to both the
CABLE IN on the Cable Converter
and the ANTENNA plug on the
rear of the TV.

Connect the CABLE OUT on

<s>

the Converter to the ANT. IN on

the VCR.

[> Connect the VIDEO OUT

jack on the VCR to the VIDEO

IN jack on the TV.
Also connect the AUDIO OUT (R

and L) jacks from the VCR to the
AUDIO IN jacks on the TV.

More PIP Connections

Contact the Parts

Inforaiation Center

I 800 292-6066

to order any optional

accessories

CABLE TV CONVERTER

41 - IB7893 E001

Tips If Something Isn't Working

lease make these simple
checks before calling for ser

P

vice. These tips can save you
time and money since charges for
TV installation and adjustment of
customer controls are not cov
ered uruier your warranty.

No Power

No Picture

No Sound

CAUTION: A video source (such as a video game, Compact Disc Interactive - CDI, or
TV information channel) which shows a constant non-moving pattern on the TV screen,
can cause picture tube damage. When your TV is continuously used with such a source
the pattern of the non-moving portion of the game (CDI, etc.) could leave an image per
manently on the picture tube. When not in use, turn the video source OFF. Regularly
alternate the use of such video sources with normal TV viewing.

Check the TV power cord. Unplug the TV, wait 1 minute, then reinsert plug into outlet
and push POWER button again.
Check to be sure outlet is not on a wall switch.

Check antenna connections on the rear of the TV. Are they properly secured to the
antenna plug on the TV?
Check the CABLE TUNING control for correct position.
Check PICTURE SOURCE control for correct position "VCR/AUX" position without a

signal source will result in a blank screen.
Check the VOLUME buttons.

Check the MUTE button on the remote control..
Check the TV SPEAKER ON/OFF control for the correct position.
If attempting auxiliary equipment hook-ups, check audio jack connections and that the
auxiliary equipment is on and in the proper operating modes.

Check TV-VCR-CBL “System” buttons on the remote. Press the remote’s IV System

Remote Does Not

Work

TV Displays Wrong

Channel or No

Channels Above 13

Cleaning and Care

• To avoid possible shock hazard be sure the TV is unplugged from the electrical outlet before cleaning.

• When cleaning the TV screen take care not to scratch or damage the screen surface (avoid wearing jewelry or using
anything abrasive- do not use household cleaners). Wipe the front screen with a clean cloth dampened with water. Use
even, easy, vertical strokes when cleaning.

• Specially designed screen cleaning kits are also available which contain anti-static cleaners and cloths designed to get
into the ridges of the TV screen. If interested, ask your dealer about the MAG4600 Projection TV Screen Cleaning Kit or
call our toll-free Accessory Parts ordering number 1-800-292-6066.

• Gently wipe the cabinet surfaces with a clean cloth or sponge dampened in a solution of cool clear water and a mild soap
or detergent. Use a clean dry cloth to dry the wiped surfaces.

• Occasionally vacuum the ventilation holes or slots in the cabinet back.

• Never use thinners, insecticide sprays, or other chemicals on or near the cabinet, as they might cause permanent marring
of the cabinet finish.

button to send commands to the TV; VCR System to sent to VCR; etc.
Check batteries. Replace with AA Heavy Duty (Zinc Chloride) or Alkaline batteries
if necessary.
Clean the remote and the remote sensor window on the TV.

Repeat channel selection.
Add desired channel numbers (ADD/DELETE CHANNELS control) into TV memory.
Check CABLE TUNING control for correct position.

This TV is equipped with protective circuitry that shuts the TV off in case of moderate
power surges. Should this occur turn the TV back on by pressing the POWER button
once or twice, or unplug and then replug the power cord at the AC outlet.
This feature is NOT designed to prevent damage due to high power surges such as those
caused by lightning, which is not covered by your warranty.

42 - IB7093 E001

^he on screen HELP menu
offers both Operating Tips and

T

a list of Glossary definitions for
different features on your TV.
These items are given to provide

you with more information and

details on a select group of feature
operations.

frnTTTTi

Select "HELP" on the TV's

<i>

Main Menu.
Press the remote's Menu <

buttons to move UP/DOWN and
from SIDE-TO-SIDE within the
list of on-screen features.

Press MENU (M) to select the
highlighted "HELP" item.

<|> Press the MENU AT and

then the MENU (M) buttons to

select either the OPERATING

TIPS or GLOSSARY item.

TV Help Menu

-----

MAIN MBIU •

jP|CTUn|J

I FEATUreS 1^

fow/offBfotBswtf Mnigni

P1P<

■ OPERATING TIPS <

USING OPERATING TIPS

• Use the and ▼ keys on
your remote to scroll
through the different

help items.

• Use the ”M’ key on
your remote will go back
to the help menu.

jl yg K at B IV B

MODE

FOLLOW THE ON SCREEN DIREC
TIONS TO VIEW OPERATING TIPS

43 - IB7893 E001

Glossary to Television Terms

Coaxial Cable ♦ A single solid antenna wire normally matched
with a metal plug (F-type) end connector that screws (or pushes)
directly onto a 75 Ohm input found on the Television or VCR.

Display * An on screen message or graphics that help the user
operate and adjust his Television feature controls. See On
Screen Displays (OSD).

Direct AudioA^ideo Inputs * Located on the rear of the TV

these connectors (RCA phono type plug) are used for the input
of audio and video signals. Designed for use with VCRs (or
other accessories) in order to receive higher picture resolution
and offer sound connection options.

Identify* Method by which a remote control searches and finds
an operating code for another product (such as a VCR or Cable
Converter). Once the code has been "identified" then the TV
remote can operate and send commands to the other product.

Multichannel Television Sound (MTS) * The broadcast stan
dard that allows for stereo sound to be transmitted with the TV
picture.

Menu * An on-screen listing of feature controls shown on the

Television screen that are made available for user adjustments.

On Screen Displays (OSD) * Refers to the wording or mes
sages generated by the television (or VCR) to help the user with
specific feature controls (color adjustment, programming, etc.).

Picture -In-Picture (PIP) * Term used when two pictures are
shown on the TV screen at the same time. The smaller PIP
picture is supplied by a VCR (or other tuner/video playback
source). The PIP picture can also be moved and swapped with
the TV’s main screen picture.

Programming * The procedure of adding or deleting channel
numbers into the Television’s memory circuits. In this way
the Television “remembers’ ’ only the locally available or
desired channel numbers and skips over any unwanted chan

nel numbers.
Remote Sensor Window * A window or opening found on

the Television control panel through which infrared remote
control command signals are received.

Second Audio Program (SAP) * Another or additional audio
channel provided for in the Multichannel Television Sound
(MTS) broadcast standard. The most frequently proposed use
for SAP is the simultaneous bilingual broadcast of TV pro
gram material.

Status * Allows the user to quickly confirm what channel

number is currently being viewed. Status can also be used to

clear the Television of on screen displays or information

(rather than waiting for the displays to “time out’’ or automati

cally disappear from the screen).

Twin Lead Wire * The more commonly used name for the
two strand 300 Ohm antenna wire used with many indoor and
outdoor antenna systems. In many cases this type of antenna
wire requires an additional adapter (or balun) in order to con
nect to the 75 Ohm Input terminals designed into the more
recent Televisions and VCRs.

44 - IB7893 E001

Index

Accessories/Optional

Adapter Connector...............................................36,41, *Q/U-1

Add/Delete Channels
Advance Buttons

Audio Controls...................................................................21-27

AudioA^ideo Input

Automatic Programming..........................................................13, *Q/U-2

Battery Installation..........................................................*Q/U-3

Cable TV Connections/Settings
Channel/Time Display
Channel Memory

Channel/Time Reminder

Clock Setting...........................................................................15

Clock Timer........................................................................... 16

Closed Captioning...................................................................11

Color Controls

Convergence............................................................................. 8

ControlsAV
Controls/Remote

Exit..................................................................................*QAJ-4

Features
First Time Set Up

GlossaryTTV Terms................................................................44

Help Menu................................................................................43, *Q/U-2,4

Inputs/Audio and Video...............................................

Language Control.....................................................................20, *QAJ-2

Menu............................................................................*QAJ-2,4

Minus(-)/Plus (+) Buttons............................................*Q/U-3,4

Parental Control.................................................................18-19

Picture-In-Picture (PIP).....................................................36-41

.............................................................

.....................................................................................

..................

..........................................................

..........................................................

........................................

.......................,..........

................................................

.........................................................

.............................................................

....................................

...........................................................

24,25,26-27, 36,41, *QAJ-1

26, 36,41, *Q/U-2

................

12, 36, 41, *QAJ-1,2

14, 17,20, *Q/U-3

13-14, *Q/U-2

28-35, 38, "‘Q/U-2, 3,4

13-14, *QAJ-2

*Q/U-2,4

17

6,*QAJ-4

*Q/U-2, 3,4

*QAJ-2

26, 36, 41

Power Light Indicator
Precautions/Safety
Programming Channels
Remote Control
Remote with VCRs

Requesting Service........................................................42, 43, 48

RF Coaxial Cable..................................................36,41, *Q/U-1

RF Switcher..............................................................................10

Reminder/Time and Channel
Safety/Precautions

Second Audio Program (SAP).................................................22

Sensor Remote.................................................................*QAJ-3

Sleep Timer..............................................................................16

Smart Button.......................................................................28-29

Smart Picture............................................................................28

Smart Sound.............................................................................28

Smart Surf
Sound Image

Surf Button...............................................................................29

Status Button.................................................................*Q/U-3,4

5

Stereo Light Indicator...............................................................22, *QAJ-3

Surround Sound
Speaker Terminals
Time/Channel Display

Timer (Turn On).......................................................................16

VCR Button.........................................................................26, 35

VCR/TV Connections

Tips for Service..............................................................42, 46-48

TV Speaker Control

Warranty...................................................................................48

.......................................................

........................................

.............................................

.......................................

.................................................

...................................................

..............................................

................................................................................

............................................................................

.......................................................................

...................................................................

....................................

...............................

.................................................................

2, 3, 42, 48, *QAJ-1

28-35, 38, *Q/U-2, 3, 4

2, 3,42, *QAJ-1

14,17,20, *QAJ-3

26-27, 36,41, *Q/U-1

*QAJ-3

13, *QAJ-2

30-31, 34, 35

17

29
23

25
25

24

* Information contained in Quick-Use (Q/U) Guide - page listed

45 - 1B7893 E001

Philips Consumer Electronics Company

Factory Service Center Locations

NOTE; If you reside in one of our Philips Factory Service Branch areas (see directory on back), you can contact the nearest Service Branch to

obtain efficient and expedient repair for your product. If your product is In-Warranty, you should have proof-of-purchase to ensure No Charge
Service. For Out-of-Warranty service, call the location nearest you.

NOTA; Si vous résidez dans une des régions desservies par une succursale de service après vente du fabricant Philips (voir liste ci-dessous), vous

pourrez contacter la branche de service après vente la plus près de chez vous pour obtenir un service après vente rapide et efficace. Si le produit
est sous garantie, il suffira de présenter une preuve d'achat pour bénéficier d'un service sans frais. Pour les produits non couverts par la garantie,
contactez le centre le plus près de chez vous.

NOTA; Si Ud. reside en una de nuestras zonas para sucursales Philips de servicio al de fábrica (ver directorio más abajo), Ud. puede comunicarse

con la sucursal de servicio más cercana para obtener una reparación oportuna y eficaz de su producto. Si su producto está todavía bajo garantía,

Ud. debe presentar comprobante de compra para no ocasionar ningunos cargos por servicio. Para servicio después del vencimiento de la garan

tía, llame al lugar más cercano de los abajo indicados.

In Canada

How you can obtain efficient and expedient carry-in, mail-in, or in-home service for your product
Please contact Philips at 1-800-661-6162 (French speaking)

1-800-363-7278 (English speaking)

Au Canada

Comment obtenir le service après-vente pour les produits apportés ou envoyés par la poste à notre centre de service ou le service à domicile
Veuillez contacter philips á: 1-800-661-6162 (Francophone)

1-800-363-7278

En el Canadá

Cómo recibir servicio efficiente para su producto, en persona, por correo o a domicilio

Favor de comunicarse con Philips al; 1 -800-661-6162 (francófono)

1-800-363-7278 (anglòfono)

46 - IB7893 E001

Quality service is as close as your telephone! Simply look over the list below for the number of a Factory S ervice Center

NEAR YOU. Your product will receive efficient and expedient carry-in, mail-in, or in-home service, and you will receive peace of mind,

KNOWING YOUR PRODUCT IS BEING GIVEN THE EXPERT ATTENTION OF PHILIPS’ FACTORY SERVICE. AnD, IF THE PHONE HUMBER LISTED FOR YOUR AREA

IS LONG DISTANCE, еда 1-800-242-9225 FOR Factory Service.

COMMENT OBTENIR NOTRE SERVICE APRÈS VENTE RAPIDE ET EFFICACE SOIT PAR COURRIER, A DOMICIU, OU EN SE PRÉSENTANT A UN CENTRE DE SERVICE PHILIPS. PLUS DE SOO CENTRES DE

RÉCEPTION DE PRODUITS A RÉPARER A TRAVERS LE PAYS; CONTACTER LE CENTRE DE SERVICE AUX CONSOMMATEURS LE PLUS PROCHE POUR SAVOIR L'EMPLACEMENT DE CES DÉPÔTS DANS

CÓMO OBTENER UN SERVICIO OPORTUNO Y EFICIENTE POR CORREO, EN CASA O EN PERSONA PARA SU PRODUCTO A TRAVÉS DE UN CENTRO PHILIPS DE SERVICIO. MAS DE 600 SITIOS POR

TODO EL PAIS PARA LA RECEPCION DE PRODUCTOS NECESITADOS DE REPARACIONES; COMUNICARSE CON EL CENTRO DE SERVICIO DE FABRICA MAS CERCANO PARA ESTOS LUGARES DENTRO

UN RAYON DE 50 A 75 MILES (SO KM A120 KM) DU CENTRE DE SERVICE LOCAL.

DE UN RADIO DE 80 A120 KM (50 A 75 MILLAS) DEL CENTRO DE SERVICIO LOCAL.

Atlanta-Athens-Macon-Chattanooga,
TN-North Georgia Area

200 North Cobb Parkway

Building 100, Suite 120
Marietta, GA 30062
[phone]

Charlotte-Winston Salem­Greensboro

520-G Clanton Road
Charlotte, NC 28217

[phone]

Chicago-Gary Area

1360 W. Hamilton Parkway
Itasca, IL 60143
[phone]

Cleveland-Akron-Youngstown Area

24090 Detroit Road

Westlake. OH 44145

[phone]

Columbus-Dayton-Cincinnati Area

6333 Busch Blvd.
Columbus, Ohio 43229
[phone]

Dallas-Ft. Worth Area

13375 Stemmons Freeway,
Suite 200
Dallas, Texas 75234
[phone]

Detroit/Toledo Area

25173 Dequindre
Madison Heights, Ml 48071
[phone]

Knoxville-Greeneville­Tri Cities-East Tennessee Area

6700 D. Papermill Road
Papermill Plaza
Knoxville, TN 37919
[phone]

Ft. Myers-Naples-

Southwest Florida Area

11601 Cleveland Ave., Suite 15
Ft. Myers, FL 33907
[phone]

Houston-Gaiveston-Beaumont-Austin­San Antonio Area

1110 North Post Oak Road
Suite 100
Houston, TX 77055
[phone]

Miami-Southeast Florida Area

2099 W. Atlantic Blvd.
Pompano Beach, FL 33069
[phone]

New York Metro Area

116 Charlotte Avenue
Hicksville, NY 11801
[phone] Nassau County

Orlando->lacksonville-North
Florida-Southeast Georgia Area

2452 Sand Lake Road
Orlando, FL 32809
[phone]

Philadelphia/S. New Jersey Area

352 Dunks Ferry Road
Bensalem, PA 19020
[phone]

Pittsburgh, PA-Steubenviile, OH­Wheeiing/Morgantown, WV Area

2891 Banksville Road
Pittsburgh, PA 15216
[phone]

San Francisco-Oakland-San Jose Area

3370 Montgomery Drive
Santa Clara, CA 95054
[phone]

Seattle-Tacoma/Olympia Area

1055 Andover Park East
Tukwila,WA98188
[phone]

Tampa-St.Petershurg-Sarasota Area

Center Point Business Park, Building B-1,
Suite 100

1911 U.S. Hwy.301 North

Tampa, FL 33619

[phone]

47 - IB7893 E001

LIMITED WARRANTY

PROJECTION TELEVISION

One Year Free Labor

One Year Free Service on Parts

Two Years Free Service on Cathode Ray Tube Parts / 30 days Free Service on Projection TV Screen

This product can be repaired in-home.

WHO IS COVERED?

You must have proof of purchase to receive warranty service. A sales
receipt or other document showing that you purchased the product is
considered proof of purchase.

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of
purchase. Attach it to this owner’s manual and keep both nearby. Also
keep the original box and packing material in case you need to return
your product

WHAT IS COVERED?

Warranty coverage begins the day you buy your product for one year
thereafter (30 days for the projection TV screen), all parts will be repaired

or replaced, and labor and transportation are free. From one to two years

from the day of purchase, you pay for the replacement or repair of all

parts except the cathode ray tube and the “Clear-Vu” lens, and for all

labor and transportation charges. After two years from the day of pur

chase, you pay for the replacement or repair of all parts except the

“Clear-Vu" lens (which is guaranteed against manufacturer’s defects for
the life of the product), and for all labor and transportation charges.

All parts, including repaired and replaced parts, are covered only for
the original warranty period. When the warranty on the product
expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover

• labor charges for installation or setup of the product, adjustment of
customer controls on the product, and installation or repair of

antenna systems outside of the product.

• product repair and/or part replacement because of misuse, acci
dent, unauthorized repair or other cause not within the control of
Philips Consumer Electronics Company.

* reception problems caused by signal conditions or cable or antenna

systems outside the unit.

• a product that requires modification or adaptation to enable it to
operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair of
products damaged by these modifications.

* incidental or consequential damages resulting from the product.

(Some states do not allow the exclusion of incidental or consequen
tial damages, so the above exclusion may not apply to you. This
includes, but is not limited to, prerecorded material, whether copy
righted or not copyrighted.)

* a product used for commercial or institutional purposes.

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is offi
cially distributed by Philips Consumer Electronics Company. In coun
tries where Philips Consumer Electronics Company does not distribute
the product the local Philips service organization will attempt to pro
vide service (although there may be a delay if the appropriate spare
parts and technical manual(s) are not readily available).

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service.
Adjustments of the controls discussed there may save you a service
cali.

TO GET WARRANTY SERVICE...

Repair must be performed by an authorized service center or a factory

service center. If you do not live near a factory service center, contact your

dealer. If your dealer is an authorized service center, he will arrange
repair. If your dealer is not an authorized service center, he will direct

you to the authorized service center engaged by him to service the

products he sells.
(In U.SA, Puerto Rico and U.S. Virgin Islands, all implied warranties,

including implied warranties of merchantability and fitness for a particu
lar purpose, are limited in duration to the duration of this express war

ranty. But, because some states do not allow limitations on how long

an implied warranty may last, this limitation may not apply to you.)

(In Canada, this warranty is given in lieu of all other warranties. No
other warranties are expressed or implied, including any implied war
ranties of merchantability or fitness for a particular purpose. Philips is
not liable under any circumstances for any direct, indirect, special, inci
dental or consequential damages, howsoever incurred, even if notified
of the possibility of such damages.)

IF YOU HAVE QUESTIONS...

Please contact Philips ac

REMEMBER...

Please record the model and serial numbers found on the product
below. Also, please fill out and mail your warranty registration card
promptly. It will be easier for us to notify you if necessary.

MODEL# ________________________________________________
SERIAL# ________________________________________________

I -800-661-6162 (French Speaking)

1-800-363-7278 (English Speaking)

tostatelpmvi

Philips Service Company, P.O.Box 555, Jefferson City, Tennessee 37760, [phone]

48 - IB7893 E001
