Philips 75BDL4510D/00 leaflet

Download

Page 1

Philips Signage Solutions D-Line Display

Say more

75"

UHD (3840 x 2160) 500 cd/m²

75BDL4510D

Smart, fast, 24/7 display.

Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb picture quality ensures true colours and intense contrast. You can effortlessly display content from multiple sources on a single screen.

Brilliant picture. Blazing processor speed.

• Place in landscape or portrait orientation

• 4K UHD. Rich, deep images. Stunning contrast

• ADS wide-view panel display

Operational flexibility

• SmartPower for energy saving

Effortless setup. Total control.

• Schedule what you want, when you want with SmartPlayer

• Operate, monitor and maintain with CMND and Control

Cost-effective system solution

• FailOver ensures that content is always playing

• Energy-saving automatic backlight control

Page 2

75BDL4510D/00

D-Line Display

75" UHD (3840 x 2160), 500 cd/m²

Highlights

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

SmartPower

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

CMND and Control

Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

SmartPlayer

Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.

ADS wide-view panel display

Be seen from any angle with ADS wide-view t

echnology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy and superior colour reproduction with 180 degree viewing.

Page 3

75BDL4510D/00

D-Line Display

75" UHD (3840 x 2160), 500 cd/m²

Specifications

Picture/Display

• Diagonal screen size: 74.5 inch / 189.3 cm

• Panel resolution: 3840 x 2160

• Optimum resolution: 3840 x 2160 @ 60 Hz

• Brightness: 500 cd/m²

• Contrast ratio (typical): 1200:1

• Dynamic contrast ratio: 500,000:1

• Aspect ratio: 16:9

• Response time (typical): 8 ms

• Pixel pitch: 0.4296 x 0.429 6 mm

• Display colours: 1.07 G Billion

• Viewing Angle (H / V): 178 / 178 degree

• Picture enhancement: 3/2 - 2/2 motion pull down, mbfi

3D Co MA deinterlacing, Dynamic contrast enhancement, Progressive scan

• Panel technology: ADS

lter, Motion compens. deinterlacing, 3D

Connectivity

• Video input: Display Port1.2 (x 1), DVI-I (x 1),

HDMI 2.0 (x 3), USB 2.0 (x 2)

• Video output: DisplayPort 1.2 (x 1), HDMI 2.0

(x 1)

• Audio input: 3.5 mm jack

• Audio output: 3.5 mm jack

• External control: RJ45, RS232C (in/out) 2.5 mm

k, IR (in/out) 3.5 mm jack

• Other connections: OPS

Supported Display Resolution

• Computer formats

olution Refresh rate

Res 1920 x 1080 60 Hz 1280 x 1024 60 Hz 1024 x 768 60 Hz 1280 x 720 60 Hz 1440 x 900 60 Hz 1600 x 900 60 Hz 1680 x 1050 60 Hz 3840 x 2160 30, 60 Hz 640 x 480 60 Hz 800 x 600 60 Hz

deo formats

• Vi

olution Refresh rate

Res 1080p 50, 60 Hz 1080i 50, 60 Hz 2160p 24, 30, 60 Hz 480i 60 Hz 480p 60 Hz

576i 50 Hz

6p 50 Hz

57 720p 50,60 Hz

Dimensions

•Set dimensions (W x H x D):

1683.5 x 961.7 x 69.5 (@Wall mount)/ (@Handle) mm

91.8

• Set dimensions in inch (W x H x D): 8 x 37.86 x 2.74 inch (wall mount)/

66.2

3.61 (@Handle) inch

•Bezel width: 14.9 mm (Even bezel)

• Product weight (lb): 79.15 lb

• Product weight: 35.9 kg

• VESA Mount: 600(H)x400(V) mm, M8

Convenience

• Placement: Landscape (24/7), Portrait (24/7)

• Keyboard control: Hidden, Lockable

• Signal loop through: IR Loop through, DisplayPort,

HDMI, RS

• Network controllable: RJ45, RS232

• Energy-saving functions: Smart Power

• Screen-saving functions: Pixel Shift, Low Bright

232

Power

• Standby power consumption: <0.5 W

• Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz

• Consumption (Typical): 150 W

• Consumption (Max): 305 W

• Energy Label Class: G

Operating conditions

• Temperature range (operation): 0 ~ 40 °C

• Temperature range (storage): -20 ~ 60 °C

• Altitude: 0 ~ 3000 m

• MTBF: 50,000 hour(s)

• Humidity range (operation)[RH]: 20–80% RH (No

nden

sation)

• Humidity range (storage) [RH]: 5–95% RH (No

sation)

conden

Sound

• Built-in speakers: 2 x 10 W RMS

Accessories

• Included accessories: Quick start guide, RS232

cable, AC Power Cord, IR sensor cable (1.8 M),

mote Control and AAA Batteries

• Included Accessories: RS23 Philips logo (x 1), Screws, USB Cover (x 1), AC

Cover

Switch

2 d

aisy-chain cable,

Multimedia Applications

• USB Playback Audio: AAC, HEAAC, MPEG

• USB Playback Picture: BMP, JPEG, PNG

• USB Playback Video: MPEG, H.263, H.2 VP8

64, H.265,

Miscellaneous

• On-Screen Display Languages: English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish

• Regulatory approvals: CE, RoHS, BSMI, CB, CCC,

, EMF

, EnergyStar 8.0, ETL, FCC, Class A, PSB,

CU VCCI

•Warranty: 3 year warranty

•

Issue date 2021-07-26

Version: 3.0.1

12 NC: 8670 001 68875 EAN: 87 12581 76901 7

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

www.philips.com
