Page 1
7110X
7115X
7120X
7125X
Rechargeable Tripleheader
®
Cordless Razor
Page 2
2
ENGLISH 4
ESPAÑOL 22
7110X/7115X/7120X/7125X
Page 3
ENGLISH4 ENGLISH 55
IMPORTANT SAFETY
INSTRUCTIONS
When using an electric razor, basic precautions should always be
followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a corded razor that has fallen into water.
Unplug immediately.
2. Use razor only in dry condition. Do not use a razor while
bathing or in a shower.
3. Do not submerge razor in water.
4. Do not place or store a razor where it can fall or be pulled into
a tub or sink. Do not place or drop a razor into water or other
liquid.
5. Always unplug this razor from the electrical outlet immediately
after use, except when razor is (re)charging.
6. Unplug and remove power supply cord from razor before cleaning.
WARNING
To reduce the risk of burns, fire, electric shock, or injury
to persons:
1. Close supervision is necessary when this razor is used by, on,
or near children or invalids.
2. Use this razor for its intended household use as described in
this manual. Do not use attachments not recommended by
Philips Electronics North America Corporation.
3. Never operate this razor if it has a damaged cord or charging
plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water while plugged in. Return the
4
razor to the Philips Norelco Service Location for
examination and repair.
4. Keep the razor, cord and charging plug away from heated
surfaces.
5. Never drop or insert any object into any opening.
6. Do not charge or plug in razor outdoors or operate where
aerosol (spray) products are being used or where oxygen is
being administered.
7. Do not use this razor with a damaged or broken comb, as facial
injury may occur.
8. Always attach plug to razor first, then to outlet. Be certain that
plug is inserted firmly into razor, up to mark indicated on plug.
To disconnect, turn razor off then remove charging plug from
outlet.
9. Never put the razor in direct sunlight or store in a pouch at a
temperature above 140°F.
10. Razor can be rinsed under running tap water. Do not charge or
operate razor until fully dried.
11.To prevent possible damage to the cord, do not wrap cord
around the razor.
SAVE THESE
INSTRUCTIONS
IMPORTANT: The power plug contains a transformer. Do not
cut off the power plug to replace it with another plug, as this will
cause a hazardous condition.
Page 4
ENGLISH 7ENGLISH6
Table of Contents
Features.........................................................8-9
Indications ......................................................10
Before First Use............................................10
Charging..........................................................11
Put It To The Test & Shaving Tips ..............12
How To Shave With An
Electric Razor................................................13
Trimming.........................................................14
Cleaning....................................................14-18
Storage ............................................................19
Assistance.......................................................19
Accessories....................................................20
Warranty ........................................................21
Spanish ............................................................22
76
60 - DAY MONEY-BACK GUARANTEE
To enjoy the closest and most comfortable shave from your new Philips Norelco
Men’s Razor, the razor should be used exclusiv
ely for 3 weeks. This allows your
hair and skin enough time to adapt to the Philips Norelco Shaving System. If, after
that period of time, you are not fully satisfied with your Philips Norelco Men’s
Razor, send the product back and we’ll refund you the full purchase price.
The razor must be shipped prepaid by insured mail, insurance prepaid,
and have the sales slip, indicating purchase price and the date of
purchase, enclosed. The razor must be postmarked no later than 60 da
ys
after the date of purchase. Philips Norelco reserves the right to verify the
purchase price of the razor and limit refunds not to exceed suggested retail price.
Send dated sales slip, your complete name and address as indicated
below, and the razor, prepaid to:
Philips Domestic Appliances and Personal Care Company
A Division of Philips Electronics North America Corporation
450 North Medinah Rd, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_________________________________________________________
Address________________________________________________________
City___________________________________________________________
State_____Zip__________________________________________________
Daytime Telephone No. (____)______________________________________
E-mail Address__________________________________________________
REASON FOR RETURNING:______________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
Area Code
Page 5
ENGLISH 9ENGLISH88
Spring-Release
Trimmer
Automatic
Worldwide Voltage
100V to 240V AC
Cleaning Brush
Storage/Travel
Pouch (model
7115X, 7125X only)
Rechargeable -
8-hour full charge
for up to 8 days of
cordless shave time
Cordless - To shave
without a cord
Full 2-Year Warranty
60-Day Money-
Back Guarantee
How the Unique Philips Norelco Lift and Cut
®
Shaving System Makes Close Comfortable:
Groove channels beard
closer to cutting system
Lifter raises hair Blade cuts hair which
then drops below skin level
Features
Reflex Action
System
Razor Head Assembly
Protective Razor
Head Cap
Individually
Floating Heads
Razor Head Release
Button
• Hair Chamber
captures
shaven hair
Electronic ON/OFF
Button
LED Charge Indicator
Light
• Indicates razor is
(re) charging
LED Battery Low
Indicator Light
Built-in Charger
Page 6
ENGLISH10 ENGLISH 1110
Indications
C ◗ Low Battery Indicator
If the batteries run low,the red indicator light
will turn on while shaving.After razor has
been switched OFF, the red indicator light will
blink for approximately 4 seconds.
◗ Charging Indicator
When you charge razor, the green LED light
will light up and stay lit to indicate razor is
charging.
Before First Use
◗ Charge the razor before you start using it (see
‘Charging’). Make sure the razor is switched
off before you start charging it.
Important
◗ Only use the power plug provided to charge
the razor.
◗ The charging plug converts 100 – 240V AC to
less than 24V DC.
Charging
◗ Battery performance is best if you recharge
only when the batteries are (almost)
completely empty.
◗ Charging or recharging at temperatures below
40°F and higher than 95°F adversely affects
lifetime of batteries.
◗ Continuously recharging razor will reduce life
of batteries.
◗ Charging and recharging requires a full 8
hours.
◗ If razor has not been used for at least 1
month, razor must be recharged for 8 full
hours.
◗ Do not charge razor in a pouch.
◗ Do not charge/recharge or use razor until
fully dried.
C 1 Connect cord directly to razor. Connect
the charging plug into any 100V to 240V AC
outlet. Use only the charging plug provided.
◗ An adaptor plug may be necessary for charging
plug usage in some foreign countries. Use an
attachment plug adaptor of the proper
configuration for the power outlet.
The charging plug will automatically convert to
work on 100V to 240V AC systems.
2 Charging and recharging requires
8 full hours. A fully charged razor has a
cordless shaving time of up to 8 days.
Page 7
ENGLISH12
How To Shave With An Electric Razor
◗ Use this razor for its intended household use
as described in this manual.
◗ Shaving with a clean,dry face gives the best
results.
C 1 Turn razor ON by pressing the on/off
button once.The green light ring around
the on/off button goes on to indicate the
razor is ON. Shave against the direction of
beard growth using both straight and
circular movements.
2 Stretch your skin with your free hand so
blades can lift and cut whiskers. Gently
press razor to skin so the floating heads can
follow the contours of your face. DO NOT
press too hard.Too much pressure can
pinch the skin into the combs.
3 Turn razor OFF by pressing the on/off
button once.
The green light ring around the on/off button goes
OFF.
C 4 Put the protective razor head cap on the
razor to protect razor heads.
For optimal shaving results, replace Philips
Norelco razor heads (model #HQ8) once a year.
ENGLISH 1312
Put It To The Test & Shaving Tips
◗ 21 Day Trial and Conversion Process.It is a fact
that your skin and beard need time to adjust to
a new shaving system.
◗ Use your new razor exclusively for 3 weeks to
fully enjoy the closeness of a Philips Norelco
shave.
◗ At first you may not get as close a shave as
you expect, or your face may even become
slightly irritated.This is normal since your
beard and skin will need time to adjust. Invest
3 weeks and you’ll soon experience the full
joy of your new razor.
◗ Stick with it! If you alternate shaving methods
during the adjustment period,it may make it
more difficult to adapt to the Philips Norelco
shaving system.
◗ If you are still not convinced after 21 days,
Philips Norelco will refund you the full
purchase price, guaranteed.
Page 8
ENGLISH14 ENGLISH 1514
Trimming
To groom sideburns and moustache:
1 Turn razor ON.
C 2 Push down spring-release trimmer switch.
The trimmer can be activated while the razor is
running.
C 3 Hold trimmer as shown and move in
downward strokes with gentle pressure.
C 4 Close trimmer by pressing trimmer down.
5 Turn razor OFF.
Cleaning
C ◗ The tapsymbol onthe backof the razorindicates
that the razor can be rinsed underrunning tap
water.
◗ Regular cleaning guarantees better shaving
results.
◗ Always switch Razor OFF, unplug and remove
power cord before cleaning.
◗ Never clean, remove or replace head assembly
while motor is on.
◗ Do not apply pressure to combs. Do not touch
razor heads with hard objects as this may dent
or damage precision-made slotted combs.
◗ Do not use razor if combs are damaged or
broken. Facial injury may occur.
Cleaning: Razor Heads
The easiest and most hygienic way to clean the
razor heads is to rinse them after each use or at
least once a week with hot water: Water from
the tap should be on a hot setting, BUT BE
CAREFUL TO TEST WATER FIRST SO AS NOT
TO BURN OR SCALD HANDS.
◗ Regular cleaning guarantees better shaving
results.
◗ Do not immerse razor in water.
C ◗ While rinsing razor heads,water may drip out of
the base of razor.This is a normal occurence.
1 Always turn razor OFF, unplug from outlet
and remove cord from razor before
cleaning.
C 2 Press the Razor Head Release Button, flip
open the Razor Head Assembly.
C 3 Clean inside razor heads and hair chamber
by running under hot water.
C 4 Clean outside of Razor Head Assembly by
running under hot water.
5 Close the Razor Head Assembly and shake
off excess water.
Page 9
ENGLISH16
C 6 Open Razor Head assembly again and
leave open to air dry.
NO
TE:
Do not wipe or dry the shaving heads
with a towel or tissue.This could damage the
shaving heads.
C 7 If the shaving unit becomes detached from
the razor, you can easily reattach it.
8 You may also clean the hair chamber
without water by using the supplied
brush.
Once A Month: Razor Heads
Do not mix up the cutters and combs as the
shaving performance may be adversely affected for
several weeks before optimal shaving performance
is restored.
1 Turn razor OFF, remove the charging plug
from the outlet and cord from the razor.
C 2 Press the razor head release button to
open the razor head assembly.
C 3 Turn the wheel counterclockwise (1) and
remove the retaining frame (2).
ENGLISH 17
C 4 Remove and clean one set of cutters and
combs at a time.
C 5 Separate the cutter from the comb and
rinse clean under hot water.
Do
not clean more than one cutter and comb at a
time, since they are all matching sets.
If you
accidentally interchange the cutters and combs, it
could take several weeks before optimal shaving
performance is restored.
C 6 Replace the set back into the Razor Head
Assembly so that the “wings” on the comb
fit within the brackets located towards the
center of the Assembly.
The set will only fit into the Razor Head Assembly
if the ‘wings’ are between the brackets. Make sure
that the two pointy edges of the head fit exactly
into the recesses.
7 Repeat the process for the other two sets
of cutters and combs.
8 Replace the frame.
C 9 Press down (1) and turn wheel clockwise
(2) until it locks into place.
10 Close the Razor Head Assembly.
16
Page 10
ENGLISH 19
Storage
◗ Be sure razor is turned off. Remove cord from
outlet and razor before storing in a safe, dry
location where it will not be crushed, banged,
or subject to damage.
◗ Do not wrap cord around razor when storing.
◗ Store cord in a safe location where it will not
be cut or damaged.
◗ Do not keep razor permanently plugged into
outlet.
◗ Do not place or store razor where it can fall
or be pulled into a tub or sink, water or other
liquid while plugged in.
C ◗ Put the Protective Razor Head Cap on razor
to protect heads.
Assistance
◗ For assistance, call toll free:
1-800-243-3050 or visit our website:
www.philips.com/norelco
◗ Information is available 24 hours a day, 7 days
a week.
ENGLISH18
Once A Month: Razor Heads
For optimum perf
ormance, razor cutters and
combs should be cleaned in a degreasing liquid
(e.g. Philips Norelco Razor Cleaner, model RC1776,
or rubbing alcohol) and lubricated with Philips
Norelco Razor Lubricant, model AL80, or one drop
of mineral oil (in the center of the head). This
helps prevent wear of the shaving heads.
After Each Use: Trimmer
1 Turn razor OFF.
2 Push down spring-release trimmer switch.
C 3 Clean trimmer with the brush every time
you use it.
C 4 Lubricate the trimmer teeth with Philips
Norelco Razor Lubricant (model AL80) or
with one drop of mineral oil every 6
months.
5 Close trimmer by pressing trimmer down.
This r
azor has no other user-serviceable parts.
Any other service should be performed by the
Philips Norelco Service Location.
Page 11
ENGLISH20 ENGLISH 21
FULL TWO YEAR WARRANTY
Philips Electronics North America Corporation warrants each new Philips Norelco Product, Model 7110X,
7115X, 7120X, 7125X (except cutters and combs) against defects in materials or workmanship for a
period of two years from the date of purchase, and agrees to repair or replace any defective product
without charge.
IMPORTANT: This warranty does not cover damage resulting from accident, misuse or abuse, lack of
reasonable care, the affixing of any attachment not provided with the product or loss of parts or
subjecting the product to any but the specified voltage.* Use of unauthorized replacement parts will void
this warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION WILL NOT PAY FOR
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE AND
WILL NOT REIMBURSE THE CONSUMER FOR DAMAGE RESULTING FROM
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE. NO
RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
In order to obtain warranty service, simply ship the product postage prepaid to the Philips Norelco
Service Location(information available online at www.philips.com/norelco or at 1-800-243-3050). It is
suggested that for your protection you return shipments of product by insured mail, insurance prepaid.
Damage occurring during shipment is not covered by this warranty.
NOTE: No other warranty, written or oral, is authorized by Philips Electronics North America
Corporation.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to
state. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above exclusion and limitations may not apply to you.
* Read enclosed instructions carefully.
Manufactured for:
Philips Domestic Appliances and Personal Care Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd., Stamford, CT 06912-0015
This symbol on the product’s nameplate means it is
listed by Underwriters’ Laboratories, Inc.
Norelco, Reflex Action, Lift and Cut, and are Registered Trademarks of Philips Electronics North
America Corporation.
is a Trademark of Philips Electronics North America Corporation.
PHILIPS is a Registered Trademark of Koninklijke Philips Electronics N.V.
© 2006 Philips Electronics North America Corporation. All Rights Reserved.
Accessories
◗ Replacement Heads
Model HQ8 - For maximum razor
performance, replace your Philips Norelco
razor heads once a year.
◗ Razor Cleaner
RC1776 - Philips Norelco Razor Cleaner.
◗ Razor Lubricant
AL80 - Philips Norelco Razor Lubricant.
◗ Car Cord Adaptor Cable
HQ8010 - Charges razor from a 12V battery
in your car, truck, van, boat or camper.
◗ Philips Norelco Razor Accessories may be
purchased at a store near you,or on our
website www
.philips.com/norelco
TM
Loading...
