Page 1
6856XL
6853XL
Rechargeable T ripleheader
®
Cordless/Cord Razor
Page 2
22
ENGLISH 4
ESPAÑOL 22
6856XL/6853XL
Page 3
5ENGLISH4 ENGLISH
4. Keep the razor and cord away from heated surfaces.
5 Never drop or insert any object into any opening.
6. Do not plug in razor outdoors or operate where aerosol
(spray) products are being used or where oxygen is being
administered.
7. Do not use this razor with a damaged or broken comb,as facial
injury may occur.
8. Always attach plug to razor first,then to outlet. Be certain that
plug is inserted firmly into razor, up to mark indicated on plug.
To disconnect,turn razor off then remove plug from outlet.
9. To prevent possible damage to the cord, do not wrap cord
around the razor.
10. Never put razor in direct sunlight or store in a pouch at a
temperature above 140ºF.
SAVE THESE
INSTRUCTIONS
IMPORTANT
YOUR RAZOR CONTAINS NICKEL-CADMIUM
RECHARGEABLE BATTERIES. See Battery Removal instruction
sheet.
IMPORTANT SAFETY
INSTRUCTIONS
When using an electric razor, basic safety precautions should
always be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a razor that has fallen into water.
Unplug immediately.
2. Do not use razor while bathing or in a shower.
3. Do not place or store razor where it can fall or be pulled into a
tub or sink.Do not place in or drop into water or other liquid.
4. Always unplug this razor from the electrical outlet immediately
after using,except when razor is recharging.
5. Remove power supply cord from razor before cleaning.
6. When discarding razor, unplug razor and remove rechargeable
batteries.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to
persons:
1. Close supervision is necessary when this appliance is used by,
on,or near children or invalids.
2. Use this razor for its intended household use as described in
this manual.Do not use attachments not recommended by
Philips Electronics North America Corporation.
3. Never operate this razor if it has a damaged cord or plug,if it is
not working properly, if it has been dropped or damaged, or
dropped into water. Return the razor to an Authorized Norelco
Service Location for examination and repair.
Page 4
7ENGLISH6 ENGLISHENGLISH6
60 - DAY MONEY-BACK GUARANTEE
To enjoy the closest and most comfortable shave from your new Norelco Men’s
Razor, the razor should be used exclusiv
ely for 3 weeks. This allows your hair
and skin enough time to adapt to the Norelco Shaving System.If, after that
period of time, you are not fully satisfied with your Norelco Men’s Razor, send
the product back and we’ll refund you the full purchase price.
The razor must be shipped prepaid by insured mail, insurance prepaid,
and have the sales slip, indicating purchase price and the date of
purchase, enclosed. The razor must be postmarked no later than 60 da
ys
after the date of purchase. Norelco reserves the right to verify the purchase
price of the razor and limit refunds not to exceed suggested retail price.
Send dated sales slip, your complete name and address as indicated
below,and the razor, prepaid to:
Philips Domestic Appliances and Personal Care Company
A Division of Philips Electronics North America Corporation
450 North Medinah Rd, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_________________________________________________________
Address________________________________________________________
City___________________________________________________________
State_____Zip__________________________________________________
Daytime Telephone No. (____)______________________________________
E-mail Address__________________________________________________
REASON FOR RETURNING:______________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
Area Code
7
Table of Contents
Features.........................................................8-9
Indications......................................................10
Charging...................................................10-11
Quick Charge................................................11
Put It T o The T est & Sha ving Tips ..............12
How to Shave With An
Electric Razor..........................................12-13
Trimming.........................................................13
Cleaning....................................................14-17
Assistance.......................................................18
Accessories....................................................18
Battery Removal...........................................19
Storage............................................................20
War ranty........................................................21
Spanish............................................................22
Page 5
9ENGLISH8 ENGLISH
Full Width Pop-Up
Trimmer
Automatic
W orldwide Voltage
100V to 240V AC
Cleaning Brush
Travel/Storage Pouch
Rechargeable Initial 4-hour full
charge for up to 30
minutes of cordless
shave time
QuickCharge
Cord/ Cordless -
To shave with or
without a cord
Full 2-Year Warranty
60-Day Money-
Back Guarantee
How the Unique Norelco Lift and Cut
®
Shaving System Makes Close Comfortable:
Groove channels beard
closer to cutting system
Lifter raises hair Blade cuts hair which
then drops below skin level
Features
Reflex Plus
Shaving System
Razor Head Assembly
Protective Razor
Head Cap
Individually
Floating Heads
Razor Head Release
Button
• Hair Chamber
captures
shaven hair
Locking ON/OFF
Switch
+ LED Battery Full
Indicator
- LED Battery Low
Indicator
Built-in Charger
Page 6
11ENGLISH10 ENGLISH
◗ Recharge razor only when the red light is ON
and starts blinking.
◗ Do not recharge razor in pouch.
C 1 Connect cord to razor.
Plug into any 120V to 240V AC outlet.Use only
the cord provided.The green LED Light will light
up and stay lit to indicate razor is charging.
◗ An adaptor plug may be necessary for cord
usage in some foreign countries.Use an
attachment plug adaptor of the proper
configuration for power outlet.
Your new razor will automatically convert
internally to work on 100V to 240V AC systems.
2 First time charging and recharging after
non-use for 1 month or more requires a
full 4 hours.
When batteries have been fully charged,the
green LED light will blink.
◗ Recharging (after initial 4 hour charge)
requires approximately 1 hour.
Quick Charge
◗ When batteries are totally depleted,
recharging the razor for approximately 6
minutes gives enough power for a 3 minute
cordless shave.
Indications
C ◗ Low Battery Indicator
If the batteries run low,the red indicator light
will turn on while shaving.After razor has
been switched OFF, the red indicator light will
blink for 4 seconds.
C ◗ Charging Indicator
When you charge razor, the green LED light
will light up and stay lit to indicate razor is
charging.
C ◗ Full Charge Indicator
When the batteries have been fully charged,
the green LED light will blink.
Charging
◗ Battery performance is best if you recharge
only when the batteries are (almost)
completely empty.
◗ Charging or recharging at temperatures
below 40°F and higher than 95°F adversely
affects lifetime of batteries.
◗ Continuously recharging or continuously using
as a corded razor will reduce life of batteries.
◗ You may also shave using the cord provided.
This razor will not recharge while being used
corded.
◗ If razorhas not been used for at least 1 month,
razor must be recharged for a full 4 hours.
Page 7
13ENGLISH12 ENGLISH
2 Stretchyourskinwithyourfree handso
blades can lift andcut whiskers.Gently press
razor to skin,sothe floating heads can
followthe contours of your face.DO NOT
presstoo hard.Too muchpressure can pinch
the skin into the heads.
3 Turn razor to OFF (O) position.
C 4 Put the protective razor head cap on the
razor to protect razor heads.
Replace your Norelco Reflex Plus razor heads
(model # HQ55 PLUS) once a year for optimal
shaving results.
Trimming
To groom sideburns and moustache:
1 Turn razor to ON (1) position.
C 2 Push up trimmer slide switch.
The trimmer can be activated while the razor is
running.
C 3 Hold trimmer as shown and move in
downward strokes with gentle pressure.
4 Close trimmer by sliding trimmer switch
down.
5 Turn razor to OFF (O) position.
Put It T o The Test & Shaving Tips
◗ 21 Day Trial and Conversion Process.It is a
fact that your skin and beard need time to
adjust to any new shaving system.
◗ Use your new razor exclusively for 3 weeks
to fully enjoy the closeness of a Norelco
shave.
◗ At first you may not get as close a shave as
you expect,or your face may even become
slightly irritated.This is normal since your
beard and skin will need time to adjust.Invest
3 weeks and you'll soon experience the full
joy of your new razor.
◗ Stick with it! If you alternate shaving methods
during the adjustment period,it may make it
more difficult to adapt to the Norelco shaving
system.
◗ If you are not convinced after 21 days,
Norelco will refund you the full purchase
price,guaranteed.
How To Shave With An Electric Razor
◗ Use this razor for its intended household use
as described in this manual.
◗ Shaving with a clean,dry face gives the best
results.
C 1 Turn razor to ON (1) position. Shave
against the direction of beard growth using
both straight and circular movements.
Page 8
ENGLISHENGLISH 1514
1 Turn razor to Off (O) position,remove plug
fromoutlet and disconnect cord from razor.
C 2 Press the Razor Head Release Button and
remove Razor Head Assembly from the
razor unit.
C 3 Brush the inside of the razor housing.
4 Turn Razor Head Assembly over so that
underside is exposed.
C 5 Turn wheel of frame counterclockwise.
6 Remove the frame and brush clean.
C 7 Remove and clean one cutter and comb at
a time.
Do not clean more than one cutter and comb at
a time, since they are all matching sets.If you
accidentally interchange the cutters and combs, it
could take several weeks before optimal shaving
performance is restored.
8 Separate the cutter from the comb.
C 9 Only brush the cutter in an upward
motion.Use the short bristled side of the
brush.
3 Replace razor head assembly.Cleaning
Once a week:Razor
◗ Regularcleaningguarantees bettershaving
results.
Always turn razor off,unplug from outlet and
remove cord from razor before cleaning.
C 1 Clean the top of the razor with the
supplied brush.
C 2 Press the Razor Head Release Button and
remove Razor Head Assembly from the
razor unit.
C 3 Brush out hairs from the inside of Razor
Head Assembly and hair chamber.
C 4 Replace theRazorHeadAssemblybackon
razor.
Every Two Months:Razor Head
Do not mix up the cutters and combs asthe
shavingperformancemay be adversely affected
for several weeks before optimal shaving
performance is restored.
Page 9
17ENGLISH16 ENGLISH
After Each Use:Trimmer
1 Turn razor to OFF (O) position.
C 2 Push trimmerslideswitch uptopop up
trimmer.
C 3 Clean trimmer with the brush every time
you use it.
C 4 Lubricate the trimmer teeth with Norelco
Razor Lubricant (model AL80) or with one
drop of mineral oil every 6 months.
5 Close trimmerbysliding trimmerswitch
down.
This razor has no other user-serviceable parts.
Any other service should be performed by an
Authorized Norelco Service Location.
C 10 Brush the slots of the comb.
For optimum performance, razor cutters and
combs should be cleaned in a degreasing liquid
(e.g. Norelco Razor Head Cleaner, model RC1776
or alcohol) and lubricated with Norelco Razor
Lubricant, model AL80,or one drop of mineral oil
(in the center of the head).This helps prevent
wear of the shaving heads.
C 11 Replace the cutter and comb into the
Razor Head Assembly.
12 Repeat the process for the other two sets
of cutters and combs.
13 Replace the frame.
C 14 Turn the wheel clockwise until it locks into
place.
C 15 Replace the Razor Head Assembly back on
razor.
16 Put the protective razor head cap on the
razor to protect heads.
Page 10
Battery Removal
◗ This Norelco Razor contains rechargeable
Nickel-Cadmium batteries,which must be
disposed of properly.
◗ Batteries should only be removed when Razor
is to be discarded.
◗ Refer to Battery Removal instruction sheet
for directions on removing the rechargeable
batteries.
19ENGLISH
Assistance
◗ For assistance or the Authorized Norelco
Service Location nearest you, call toll free:
1-800-243-3050
or visit our website:
www.norelco.com
◗ Authorized Norelco Service Location
information is available 24 hours a day, 7 days a
week.
Accessories
◗ NOTE:Model HQ5 Reflex Action
Replacement Heads DO NOTfit this razor.
◗ Replacement Heads
Model HQ55 PLUS - For maximum razor
performance, replace your Norelco Reflex Plus
razor heads once a year.
◗ Razor Head Cleaner
RC1776 - Norelco Razor Cleaner
◗ Razor Lubricant
AL80 - Norelco Razor Lubricant
◗ Norelco Razor Accessories may be purchased
at a store near you,an Authorized Norelco
Service Location,or on our website
www
.norelco.com
18 ENGLISH
Page 11
21ENGLISH
Storage
◗ Be sure Razor is turned off. Remove cord
from outlet and Razor before storing in a safe,
dry location where it will not be crushed,
banged,or subject to damage.
◗ Do notwrap cordaround Razor when storing.
◗ Store cord in a safe location where it will not
be cut or damaged.
◗ Do not place or store Razor where it can fall
or be pulled into a tub or sink,water or other
liquid while plugged in.
◗ Put the Protective Razor Head Cap on razor
to protect heads.
20 ENGLISH
FULL TWO YEAR W ARRANTY
Philips Electronics North America Corporation warrants each new Norelco Product, Model 6856XL,
6853XL (except cutters and combs) against defects in materials or workmanship for a period of two
years from the date of purchase,and agrees to repair or replace any defective product without charge.
IMPORTANT:This warranty does not cover damage resulting from accident,misuse or abuse, lack of
reasonable care,the affixing of any attachment not provided with the product or loss of parts or
subjecting the product to any but the specified voltage.* Use of unauthorized replacement parts will void
this warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION WILL NOT PAY FOR
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE AND
WILL NOT REIMBURSE THE CONSUMER FOR DAMAGE RESULTING FROM
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE.NO
RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
In order to obtain warranty service, simply take or ship the product postage prepaid to the nearest
Authorized Norelco Service Center Location. It is suggested that for your protection you return
shipments of product by insured mail,insurance prepaid. Damage occurring during shipment is not
covered by this warranty.
NOTE: No other warranty, written or oral, is authorized by Philips Electronics North America
Corporation.
This warranty gives you specific legal rights,and you may also have other rights which vary from state to
state. Some states do not allow the exclusion or limitation of incidental or consequential damages,so the
above exclusion and limitations may not apply to you.
* Read enclosed instructions carefully.
Manufactured for:
Philips Domestic Appliances and Personal Care Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd.,Stamford, CT 06912-0015
This symbol on the product’s nameplate means it is
listed by Underwriters’ Laboratories,Inc.
Norelco,Tripleheader, Lift and Cut, and are Registered Trademarks of Philips Electronics North
America Corporation.
and Reflex Plus are Trademarks of Philips Electronics North America Corporation.
PHILIPS is a Registered Trademark of Koninklijke Philips Electronics N.V.
© 2005 Philips Electronics North America Corporation. All Rights Reser ved.
Rev.3-5/05
®
LISTED
TM
Loading...
