Philips 65PUT7601/56 user manual
Register your product and get support at
www.philips.com/welcome
7601 series
User Manual
65PUT7601
Contents
1 What's new 4
1.1 All-in-one source menu 4
1.2 Top picks 4
1.3 Media browser 5
2 Setting Up 6
2.1 Read Safety 6
2.2 TV Stand and Wall Mounting 6
2.3 Tips on Placement 6
2.4 Power Cable 6
2.5 Antenna Cable 6
2.6 Satellite Dish 7
3 Remote Control 8
3.1 Key Overview 8
3.2 Pairing the Remote Control 9
3.3 Voice Search 9
3.4 Touch Pad 10
3.5 Keyboard 10
3.6 Remote Control Sensor 11
3.7 Batteries 11
3.8 Cleaning 11
4 Switching On and Off 13
4.1 On or Standby 13
4.2 Keys on TV 13
5 Channels 14
5.1 Antenna/Cable Installation 14
5.2 Channel List Copy 16
5.3 About Channels 16
6 Connect Devices 23
6.1 About Connections 23
6.2 HDMI Ports 23
6.3 Y Pb Pr - Component 24
6.4 Scart 25
6.5 Audio Out - Optical 25
6.6 CAM with Smart Card - CI+ 25
6.7 Receiver - Set-Top Box 26
6.8 Home Theatre System - HTS 26
6.9 Smartphones and Tablets 27
6.10 Blu-ray Disc Player 27
6.11 DVD Player 27
6.12 Bluetooth - Speakers and Gamepads 28
6.13 Headphones 28
6.14 Game Console 29
6.15 Gamepad 29
6.16 USB Hard Drive 29
6.17 USB Keyboard 30
6.18 USB Flash Drive 31
6.19 Photo Camera 31
6.20 Camcorder 31
6.21 Computer 32
7 Connect your Android TV 33
7.1 Network and Internet 33
7.2 Google Account 35
7.3 Philips App Gallery 36
7.4 Android Settings 36
7.5 Home Menu 37
8 Apps 38
8.1 About Apps 38
8.2 Google Play 38
8.3 Start or Stop an App 39
8.4 Lock Apps 39
8.5 Manage Apps 40
8.6 Storage 41
9 Internet 42
9.1 Start Internet 42
9.2 Options on Internet 42
10 TV Menu 43
10.1 About TV Menu 43
10.2 Open TV Menu 43
11 Sources 44
11.1 Switch to a device 44
11.2 Options for a TV Input 44
11.3 Device Name and Type 44
11.4 Computer 44
12 Settings 46
12.1 Frequent Settings 46
12.2 Picture 46
12.3 Sound 51
12.4 Ambilight Settings 53
12.5 Eco Settings 56
12.6 General Settings 56
12.7 Clock, Region and Language 58
12.8 Universal Access 61
12.9 Child Lock 62
13 Videos, Photos and Music 64
13.1 From a USB Connection 64
13.2 From a Computer or NAS 64
13.3 From a Cloud Storage Service 64
13.4 Favourites, Most Popular, Last Played menu
64
13.5 Play your Videos 64
13.6 View your Photos 65
13.7 Play your Music 65
14 TV Guide 67
14.1 What You Need 67
14.2 TV Guide Data 67
14.3 Using the TV Guide 67
15 Recording and Pause TV 69
15.1 Recording 69
15.2 Pause TV 70
16 Smartphones and Tablets 71
16.1 Philips TV Remote App 71
16.2 Google Cast 71
16.3 AirPlay 71
16.4 MHL 71
17 Games 72
17.1 What You Need 72
17.2 Play a Game 72
18 Ambilight 73
18.1 Ambilight Style 73
18.2 Ambilight Off 73
18.3 Ambilight Settings 73
19 Top Picks 75
19.1 About Top Picks 75
19.2 Now on TV 75
19.3 TV on Demand 75
19.4 Video on Demand 75
2
20 Netflix 77
21 Multi View 78
21.1 Text and TV 78
21.2 HDMI and TV 78
21.3 Nettv and TV 78
21.4 Nettv and HDMI 78
22 Software 79
22.1 Update Software 79
22.2 Software Version 79
22.3 Automatic software update 79
22.4 Open Source Software 79
22.5 Open Source License 80
22.6 Announcements 112
23 Specifications 113
23.1 Environmental 113
23.2 Power 113
23.3 Operating System 113
23.4 Reception 113
23.5 Display Type 113
23.6 Display Input Resolution 113
23.7 Dimensions and Weights 114
23.8 Connectivity 114
23.9 Sound 114
23.10 Multimedia 114
24 Help and Support 115
24.1 Register your TV 115
24.2 Using Help 115
24.3 Troubleshooting 115
24.4 Online Help 117
24.5 Support and Repair 117
25 Safety and Care 118
25.1 Safety 118
25.2 Screen Care 119
26 Terms of Use 120
26.1 Terms of Use - TV 120
26.2 Terms of Use - Philips App Gallery 120
27 Copyrights 121
27.1 MHL 121
27.2 Ultra HD 121
27.3 HDMI 121
27.4 Dolby Digital Plus 121
27.5 DTS Premium Sound ™ 121
27.6 Microsoft 121
27.7 Wi-Fi Alliance 121
27.8 Kensington 122
27.9 Other Trademarks 122
28 Disclaimer regarding services and/or
software offered by third parties 123
Index 124
3
1
What's new
1.1
All-in-one source menu
About All-in-one source menu
For the first time you press SOURCES, you can
see instructions how to set your source menu.
The improved source menu contains normal source
menu, easily open TV Guide, and also you can
use (plus key) to set a reminder or schedule a
recording in TV Guide.
An all-in-one Sources menu, a restyled TV guide and
a new easy programme browser.
Your list of favourite channels is now part of
the Sources menu. Same for the channel lists of
both tuners Antenna/Cable and
The new Sources menu will have all connected
devices in the list but also all tuners, so in the
Sources menu the user will find all possible ‘sources’
for TV.
Satellite.
Improved TV guide
A clear and better looking TV guide. Select a
programme and read the programme info or
press to set a reminder or schedule a recording.
Switch from tuner, channel, and TV
guide
Select a tuner source and press to open the list of
channels. Press again to open the TV guide
to see what’s on. Press to return to the list of
channels.
1.2
Top picks
With TOP PICKS your TV recommends current
TV programmes, the latest rental videos and Online
TV services for you to watch.
1 - Press TOP PICKS.
2 - Select one programme and use (plus key) to
schedule a recording, set a reminder or watch the
programme.
3 - Use Arrow / navigation keys to select 3 dots on
the right-top of the screen, then press OK to
open OPTIONS menu.
Select to record, or select to set a reminder
4
Select to mark as favourites
1.3
Media browser
Browse your media as you like it or mark any channel,
song or photo as a favourite easily.
1 - Press (plus key) to mark any video, song or
photo as a favourite.
2 - You can view videos, songs, and photos in grid
view or list view.
3 - Use Arrow / navigation keys to select 3 dots on
the right-top of the screen, then press OK to
open OPTIONS menu.
4 - When playing, there is a secondary control bar on
the bottom of the screen, use the arrows
and OK key to select what you want.
Grid view
List view
5
2
Setting Up
2.1
Read Safety
Read the safety instructions first before you use the
TV.
For more information, in Help, select Keywords and
look up Safety Instructions.
Make sure that the metal screws, to mount the TV to
the VESA-compliant bracket, go about 10mm deep
inside the threaded bushes of the TV.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
2.2
TV Stand and Wall Mounting
TV Stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com.
Use the model number of the TV to look for
the Quick Start Guide to download.
Wall Mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
2.3
Tips on Placement
• Position the TV where light does not shine directly
on the screen.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch TV is 3 times its diagonal
screen size. When seated, your eyes should be level
with the centre of the screen.
15
cm
2.4
Power Cable
• 65PUT7601
VESA MIS-F 400x400, M6
Preparation
First remove the 4 plastic screw caps out of the
threaded bushes on the back of the TV.
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
6
2.5
Antenna Cable
Insert the antenna plug firmly into
the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
2.6
Satellite Dish
Note: Not support for countries in Asia Pacific,
Middle East, and Africa.
Attach the satellite F-type connector to the satellite
connection SAT at the back of the TV.
7
3
Remote Control
3.1
Key Overview
Top
1 - Standby / On
To switch the TV on or back to Standby.
2 - VOICE microphone
3 - LIST
To open or close the channel list.
4 -
To select one of the Ambilight style.
5 - TV GUIDE
To open or close the TV Guide.
6 - SETTINGS
To open the Frequent Settings.
7 - TOP PICKS
To open the menu with recommended programmes,
Video on Demand (Rental Videos) or Online TV
(Catch Up TV).
If available.
8 - VOICE
To start speaking your voice search.
AMBILIGHT
1 - TV Menu
To open the TV Menu with typical TV functions.
2 - SOURCES
To open or close the Sources menu.
3 - INFO
To open or close programme info.
4 - BACK
To switch back to the previous channel you selected.
To return to previous menu.
To go back to the previous App/Internet page.
5 -
Direct selection of options.
6 - EXIT
To switch back to watching TV. To leave an interactive
TV application.
7 - OPTIONS
To open or close the Options menu.
8 - OK key
To confirm a selection or setting.
9 - Arrow / navigation keys
To navigate up, down, left or right.
10 - HOME
To open the Home menu.
Colour keys
Middle
Bottom
8
Pair again
If the pairing with the remote control was lost, you
can pair the TV with the remote control again.
To start pairing...
1 - On the back of the TV, standing in front of the TV
at the right, press the joystick power key in for 3
seconds. A message will show that the TV is ready to
pair.
2 - Press the colour keys (red) and (blue)
simultaneously for 1 second. A message appears
when the pairing is successful.
3.3
1 -
To open the Netflix App directly. With the TV switched
on or from standby.
2 To adjust the volume level.
3 - Number keys
To select a channel directly.
4 - SUBTITLE
To switch subtitles on, off or to show automatically.
5 - Playback and Record
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to go fast forward
• Record , to start recording
6 - Channel
To switch to the next or previous channel in the
channel list. To open the next or previous page in
Text/Teletext. To start the next or previous chapter on
a disc.
7 To mute the sound or to restore it.
8 - TEXT
To open or close Text/Teletext.
3.2
Volume
Mute
Voice Search
You can search for videos, music or anything else on
the Internet by simply using your voice. You can
speak into the microphone on the remote control.
Alternatively, you can use the remote control
keyboard to enter text.
To use Voice…
1 - Press VOICE. The blue light on the remote
control lights up and the search field opens. As long
as the icon is red on screen, the microphone is
active.
2 - Speak out clearly what you are looking for. You
can speak for 10 seconds before the microphone
switches off. It might take some time for the results to
appear.
3 - In the list of search results, you can select the
item you want.
4 - Press BACK to close the search results if
necessary.
To use the remote control keyboard to search…
1 - Press VOICE to open the search field.
2 - Press (right) to highlight the text field.
3 - Turn the remote control keyboard facing upwards
and type what you are looking for.
4 - Press BACK to hide the onscreen keyboard.
5 - In the list of search results, you can select the
item you want.
6 - Press BACK to close the search results if
necessary.
Pairing the Remote Control
For the remote control to communicate with the TV,
both TV and remote control should be paired (linked)
with each other.
Pairing
When you started the initial TV installation, the TV
invited you to press the OK key, and by doing so,
the pairing was done. If the TV does not react on any
remote control key press, pairing was unsuccessful.
See also www.support.google.com/androidtv
Voice Settings
You can set the language you like to use with Voice.
To set the language for Voice Search…
1 - Press , select All Settings and press OK.
2 - Select Android Settings and press OK.
3 - Select Preferences > Speech and
press OK.
9
4 - Select the language you want to use and
press OK.
5 - Press BACK to go back one step or
press EXIT to close the menu.
3.4
Touch Pad
in your remote control, even you reload batteries.
3.5
Keyboard
Overview
The diamond shaped area of the navigation keys on
the remote control - the keys for up, down, left and
right - is also a small touch pad. You can use this
touch pad to swipe through long lists or to go through
a list step by step.
How to use the touch pad…
1 - Open any kind of TV menu with a list, e.g. the
Home menu or Channel list.
2 - Use your thumb to swipe across the touch pad
and towards the direction the list must scroll. Up or
down, or left to right. If you swipe the touch pad, the
highlight will move 1 step. If you swipe and then hold
your thumb on the touch pad (no need to press), the
highlight will scroll through the list until you lift your
thumb from the touch pad.
Take some time to learn this swipe or swipe and hold
gesture. It's really helpful to go through long lists.
Activate/Deactivate touch pad function
To deactivate touch pad on remote control...
1 - Press remote control number keys 8, 6, 8, 7,
and Mute key in sequential order.
Qwerty and Azerty
Overview of a Qwerty/Azerty keyboard.*
1 - Azerty character
Character position if the keyboard layout is set to
Azerty.
2 To type uppercase characters.
3 - Fn key
To type a number or punctuation character.
4 - Spacebar
5 - Navigation and OK
6 - Share this
To share online what you are watching at the
moment.
Shift
2 - The remote control LED indicator lights blue, your
remote control touch pad function is switched off
successfully.
3 - To reactivate touch pad function, you may repeat
the above steps.
Note: The setting (activate/deactivate) will be stored
* Your remote control has a Qwerty / Azerty or a
Qwerty / Cyrillic keyboard, depending on your region.
Qwerty and Cyrillic
Overview of a Qwerty/Cyrillic keyboard.*
1 - Cyrillic characters
Characters available when the keyboard is switched
to Cyrillic.
2 - Cyrillic keyboard switch
To switch the keyboard to the Cyrillic characters or
back to Qwerty.
3 To type uppercase characters.
4 - Fn key
To type a number or punctuation character
5 - Spacebar
6 - Share this
To share online what you are watching at the
moment.
Shift
10
7 - Navigation and OK
* Your remote control has a Qwerty/Azerty or a
Qwerty/Cyrillic keyboard, depending on your region.
Writing Text
Cyrillic keyboard
Depending on your region, the Remote Control
Keyboard can be switched to Cyrillic characters.
The Cyrillic characters are shown at the top right of
the keyboard keys.
To write Cyrillic characters…
With the keyboard on the back of the remote control,
you can write text in any text field on screen.
To write text…
1 - Select a text field if it is not yet selected.
2 - Turn the remote control keyboard facing upwards
to activate the keyboard keys. Hold the remote
control with two hands and type with both thumbs.
3 - To hide the on screen keyboard, press BACK.
Press OK to confirm the text.
On-screen Keyboard
If you use the on-screen keyboard to enter text, you
can configure the keyboard layout to a layout you are
used to.
To open these settings…
Press HOME, select All Settings and press OK.
5 - Select Android Settings and press OK.
6 - Select Preferences > Keyboard and
press OK.
7 - Select Configure > Language and press OK.
You can set your language keyboard layout here.
8 - Press BACK to close the menu to go back
one step.
• Best distance to operate remote control with the TV
is less than 5 m.
• When using remote control keyboard, best to hold
the remote control with the angle less than 50
degree.
• Do not block the IR ray of the remote control.
Qwerty, Azerty and Cyrillic keyboard
The standard layout of the Remote Control Keyboard
is Qwerty.
Azerty keyboard
Depending on your region, the Remote Control
Keyboard can be set to Azerty. The Azerty characters
are shown at the top right of the relevant keys.
To set the keyboard layout to Azerty…
1 - Press , select All Settings and press OK.
2 - Select Region and Language and
press (right) to enter the menu.
3 - Select Remote Control Keyboard and
press OK.
4 - Select AZERTY or QWERTY and press OK.
5 - Press (left) repeatedly if necessary, to close
the menu.
1 - Press on the remote control.
2 - Press again to switch back to Qwerty.
3.6
Remote Control Sensor
The remote control of the TV uses Bluetooth to send
its commands to the TV. With Bluetooth, you do not
need to point the remote control at the TV.
However, the TV can also receive commands from a
remote control that uses IR (infrared) to send
commands. If you use such a remote control, always
make sure you point the remote control at the
infrared sensor on the front of the TV.
3.7
Batteries
The TV will notify you when the battery power of the
remote control is low.
To replace the batteries, open the battery
compartment on the keyboard side of the remote
control.
1 - Use a small coin or other small, blunt object and
press the rectangular shaped release button to open
the battery lid.
2 - Slide the battery in the direction of the metal
spring and pull the opposite end of the battery out.
3 - Replace the old batteries with 2
type AA-LR6-1.5V alkaline batteries. Make sure the
+ and the - ends of the batteries line up correctly.
4 - Reposition the battery door and push it down
until it clicks.
Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.
For more information, in Help, select Keywords and
look up End of use.
11
3.8
Cleaning
Your remote control is treated with a scratch-resistant
coating.
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
household cleaners on the remote control.
12
4
Switching On and
Off
4.1
On or Standby
Make sure the TV is connected to the mains AC
power. Connect the supplied power cord to the AC
in connector at the back of the TV. The indicator light
at the bottom of the TV lights up.
Switch on
Press on the remote control to switch the TV
on. Alternatively, press HOME. You can also
press the small joystick key on the back of the TV to
switch the TV on in case you can't find the remote
control or its batteries are empty.
Switch to standby
movie.
4 - The menu will disappear automatically.
To switch the TV on standby, select and press the
joystick key.
To switch the TV to standby, press on the remote
control. You can also press the small joystick key on
the back of the TV.
In standby mode, the TV is still connected to the
mains power but consumes very little energy.
To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.
4.2
Keys on TV
If you lost the remote control or its batteries are
empty, you can still do some basic TV operations.
To open the basic menu…
1 - With the TV switched on, press the joystick key on
the back of the TV to bring up the basic menu.
2 - Press left or right to
select Volume, Channel or Sources.
Select Demo, to start a demo movie.
3 - Press up or down to adjust the volume or tune to
the next or previous channel. Press up or down to go
through the list of sources, including the tuner
selection. Press the joystick key to start the demo
13
5
Channels
5.1
Antenna/Cable Installation
Update or reinstall
press OK.
8 - Select the type of installation you want, Antenna
(DVB-T) or Cable (DVB-C) and press OK.
9 - Select the type of channels you want, Digital
and Analogue Channels or Only Digital
Channels and press OK.
10 - Press OK to update the digital channels. This
can take a few minutes.
11 - Press BACK to close the menu.
Update digital channels
You can always start an channel update yourself.
To start a channel update manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start.
6 - Select Update digital channels.
7 - Press OK to update the digital channels. This
can take a few minutes.
8 - Press BACK to close the menu.
Quick reinstall
Select Quick reinstall to install all channels again with
default settings.
To start Quick reinstall…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start.
6 - Select Quick reinstall.
7 - Press OK to update the digital channels. This
can take a few minutes.
8 - Press BACK to close the menu.
Advanced reinstall
You can reinstall all channels and leave all other TV
settings untouched.
If a PIN code is set, you will need to enter this code
before you can reinstall channels.
To reinstall channels…
Automatic Channel Update
If you receive digital channels, you can set the TV to
automatically update these channels.
Once a day, at 6 AM, the TV updates the channels
and stores new channels. New channels are stored in
the Channels List and are marked with a .
Channels without a signal are removed. The TV must
be in standby to automatically update channels. You
can switch off Automatic Channel Update.
To switch off the automatic update…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Automatic Channel Update.
5 - Select Off.
6 - Press (left) to go back one step or
press BACK to close the menu.
When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.
To switch off the message…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Channel Update Message.
5 - Select Off.
6 - Press (left) to go back one step or
press BACK to close the menu.
In certain countries, the Automatic channel update is
done while watching TV or on any moment when the
TV is in standby.
DVB-T or DVB-C
Note: Not support DVB-C.
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
3 - Enter your PIN code if necessary.
4 - Select Search for Channels.
5 - Select Start and press OK.
6 - Select Advanced reinstall and press OK.
7 - Select the country where you are now and
DVB-T Reception
During the channel installation, just before you search
for channels, you selected Antenna (DVB-T). Antenna
DVB-T searches for terrestrial analogue channels and
digital DVB-T2 channels.
Channel Number Conflicts
14
In some countries, different TV channels
(broadcasters) might have the same channel number.
While installing, the TV shows the list with channel
number conflicts. You need to select which TV
channel you want to install on a channel number with
multiple TV channels.
Note: Not support DVB-C.
Analogue Channels
If you know your cable operator is not offering
analogue channels, you can skip searching for
analogue channels.
Free / Scrambled
DVB Settings
Network Frequency Mode
If you intend to use the fast Quick Scan method
in Frequency Scan to search for channels,
select Automatic. The TV will use 1 of the predefined
network frequencies (or HC - homing channel) as
used by most cable operator in your country.
If you received a specific network frequency value to
search for channels, select Manual.
Network Frequency
With the Network Frequency Mode set to Manual,
you can enter the network frequency value received
from your cable operator here. To enter the value, use
the number keys.
Frequency Scan
Select the method of searching for channels. You can
select the faster Quick Scan method and use the
predefined settings used by most cable operator in
your country.
If this results in having no channels installed or if
some channels are missing, you can select the
extended Full Scan method. This method will take
more time to search for and install channels.
If you have a subscription and a CAM - Conditional
Access Module for pay TV services, select Free +
Scrambled. If you did not subscribe to pay TV
channels or services, you can select Free
Channels Only .
Reception Quality
You can check the quality and signal strength of a
digital channel. If you have your own antenna, you
can reposition the antenna to try and improve the
reception.
To check the reception quality of a digital channel…
1 - Tune to the channel.
2 - Press , select All Settings and press OK.
3 - Select Channels > Antenna/Cable Installation.
Enter your PIN code if necessary.
4 - Select Digital: Reception Test.
5 - Select Search. The digital frequency is shown
for this channel.
6 - Select Search again and press OK to check the
signal quality of this frequency. The test result is
shown on screen. You can reposition the antenna or
check the connections to possibly improve the
reception.
7 - You can also change the frequency
yourself. Select the frequency number one by one
and use the (up) or (down) keys to change
the value. Select Search and press OK to test the
reception again.
8 - Press (left) repeatedly if necessary, to close
the menu.
Frequency Step Size
The TV searches for channels in steps of 8MHz.
If this results in having no channels installed or if
some channels are missing, you can search in smaller
steps of 1MHz. Using the 1MHz steps will take more
time to search for and install channels.
Digital Channels
If you know your cable operator is not offering digital
channels, you can skip searching for digital channels.
Manual Installation
Analogue TV channels can be manually installed,
channel by channel.
To install analogue channels manually…
1 - Press , select All Settings and press OK.
2 - Select Channels > Antenna/Cable Installation.
Enter your PIN code if necessary.
3 - Select Analogue: Manual Installation.
• System
To set up the TV system, select System.
Select your country or the part of the world where
you are now and press OK.
15
• Search Channel
To find a channel, select Search Channel. You can
enter a frequency yourself to find a channel or let the
TV search for a channel. Press (right) to
select Search to search for a channel
automatically. The found channel is shown on screen
and if the reception is poor, press Search again. If
you want to store the channel, select Done and
press OK.
• Store
You can store the channel on the current channel
number or as a new channel number.
Select Store Current Channel or Store as New
Channel. The new channel number is shown briefly.
You can redo these steps until you have found all
available analogue TV channels.
5.2
Channel List Copy
Upload a Channel List
To not Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To a TV that is not yet installed
1 - Plug in the power plug to start the installation and
select language and country. You can skip the
channel search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, press ,
select All Settings and press OK.
4 - Select Channels > Channel List Copy > Copy
to TV. Enter your PIN code if necessary.
5 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
Copy a Channel List
To copy a channel list…
1 - Switch on the TV. This TV should have channels
installed.
2 - Plug in a USB flash drive.
3 - Press , select All Settings and press OK.
4 - Select Channels > Channel List Copy.
5 - Select Copy to USB. You might be asked to enter
the Child Lock PIN code to copy the channel list.
6 - When copying is done, unplug the USB flash
drive.
7 - Press (left) repeatedly if necessary, to close
the menu.
Now you can upload the copied channel list onto
another Philips TV.
Channel List version
Check the current version of the channel list...
1 - Press , select All Settings and press OK.
2 - Select Channels and press (right) to enter
the menu.
3 - Select Channel List Copy and select Current
Version, then press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
To Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To an already installed TV
1 - Verify the country setting of the TV. (To verify this
setting, see chapter Reinstall All Channels. Start this
procedure until you reach the country setting.
Press BACK to cancel the installation.)
If the country is correct continue with step 2.
If the country is not correct, you need to start a
reinstallation. See chapter Reinstall All Channels and
start the installation. Select the correct country and
skip the channels search. Finish the installation. When
done, continue with step 2.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, press ,
select All Settings and press OK.
4 - Select Channels > Channel List Copy > Copy
to TV. Enter your PIN code if necessary.
5 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
5.3
About Channels
16
Channel Lists
Filter a Channel List
About Channel Lists
After a channel installation, all channels appear on
the channel list. Channels are shown with their name
and logo if this information is available.
There is a channel list with all installed channels. You
can only filter this list to show TV or only Radio
channels.
With a channel list selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using
Channel icons
After an Automatic Channel Update of the channel
list, newly found channels are marked with
a (star).
If you lock a channel, it will be marked with
a (lock).
The 3 most popular channels being watched by
others at this moment are marked with a 1, 2 or 3.
or
keys.
You can filter a list with all channels. You can set the
channel list to show only TV channels or only Radio
stations. For Antenna/Cable channels you can set the
list to show the Free-to-Air or the Scrambled
channels.
To set a filter on a list with all channels…
1 - Press .
2 - Press OK to open the current channel list.
3 - With a channel list open on screen, select the list
name at the top of the channel list and press OK to
open the list menu.
4 - In the list menu, select the list you want to filter.
5 - Press (left) to go back one step or
press to close the menu.
Search for a Channel
You can search for a channel to find it in a long list of
channels.
The TV can search for a channel within one of the 2
main channel lists - the Antenna or Cable channel list.
Radio stations
If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel.
This TV can receive digital television standard DVB .
TV may not work properly with some operators of
digital television , non-compliance with requirements
of the standard in full.
Open a Channel List
Next to the list with all channels, you can select a
filtered list or you can select one of the favourite lists
you created.
To open the current channel list…
1 - Press , to switch to TV.
2 - Press LIST* or OK to open the current
channel list.
3 - Press BACK to close the channel list.
To select one of the channel lists…
To search for a channel…
1 - Press .
2 - Press OK to open the current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Search Channel and press OK to open
a text field.You can use the remote control keyboard
(if available) or the on-screen keyboard to enter text.
5 - Enter a number, a name or part of a name and
select Apply and press OK. The TV will search for
matching channel names in the list you selected.
Search results are listed as a channel list - see the list
name at the top. The search results disappear once
you select another channel list or close the list with
search results.
Watching channels
Tune to a Channel
To start watching TV channels, press . The TV
tunes to the channel you last watched.
1 - With a channel list open on screen.
2 - Select the list name at the top of the channel list
and press OK to open the list menu.
3 - In the list menu, select one of the available
channel lists and press OK.
* If LIST key is available on your remote control
Switch Channels
To switch channels, press or .
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
17
To switch back to the previously tuned channel,
press BACK.
You can also tune to channels from a Channel List.
Lock a Channel
Lock and Unlock a Channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
4 - Back in Parental Rating, select the age.
5 - Press (left) repeatedly if necessary, to close
the menu.
To switch off the parental age rating, select None.
However, in some countries you must set an age
rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Channel Options
To lock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select at the upper right corner and press OK.
4 - Select Lock/UnLock and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Select the channel you want to lock and
press OK. A locked channel is marked with
a (lock).
7 - Press (left) to go back one step or
press BACK to close the menu.
To unlock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select at the upper right corner and press OK.
4 - Select Lock/UnLock and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or
press BACK to close the menu.
If you lock or unlock channels in a channel list, you
only have to enter the PIN code just once until you
close the channel list.
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
or depending on the TV settings you made, some
options are available.
To open the options menu…
1 - While watching a channel,
press OPTIONS >
Preferences.
2 - Press OPTIONS again to close.
Rename Channel
While watching a channel, you can rename channel.
To rename a channel…
1 - While watching a channel, press OPTIONS.
2 - Select
Preferences > Rename Channel.
3 - Use the keyboard on the back of the remote
control to delete the current name and enter a new
name.
Common Interface
Parental Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age
rated. When the age rating of a programme is equal to
or higher than the age you have set as age rating for
your child, the programme will be locked. To watch a
locked programme, you must enter the Parental
Rating code first.
To set an age rating…
1 - Press , select All Settings and press OK.
2 - Select Child Lock > Parental Rating.
3 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set Code in Child Lock. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
If you installed a CAM in one of the Common
Interface slots, you can view the CAM and operator
information or do some CAM related settings.
To view the CAM information…
1 - Press SOURCES.
2 - Select the channel type you are using the CAM
for Watch TV.
3 - Press OPTIONS and
select
Preferences > Common Interface.
4 - Select the appropriate Common Interface slot
and press (right).
5 - Select the TV operator of the CAM and press OK.
The following screens come from the TV operator.
18
Channel Info
Map Channel
You can view the technical characteristics of a
particular channel, like digital or sound type, etc.
To view the technical information on a channel…
1 - Tune to the channel.
2 - Press OPTIONS, select
press OK.
3 - Select Channel Info and press OK.
4 - To close this screen, press OK.
Programme Info
View programme details
To call up the details of the selected programme…
1 - Tune to the channel.
2 - Press OPTIONS, select
press OK.
3 - Select Programme Info and press OK, you can
see progrmme information.
4 - Press BACK to close.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo…
1 - Tune to an analoge channel.
2 - Press OPTIONS, and
select
press (right).
3 - Select Mono or Stereo and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Preferences > Mono/Stereo and
Preferences and
Preferences and
If there is no programme information in the beginning,
you can do map channel to get more programme
information.
1 - Press TV GUIDE, and use navigation keys to
select at the middle and press OK.
2 - Select TV Guide > From the Internet and
press OK.
3 - Select one of channels in TV guide, then
press OK to watch the selected channel.
4 - While watching a channel, press OPTIONS.
5 - Select
6 - Select one item in the list and press OK.
7 - Select Map Channel.
8 - Once completed, you will see the mapped
channel information in the programme.
Change Logo
If there is no programme information in the beginning,
you can get more programme information using
below steps.
1 - Press TV GUIDE, and use navigation keys to
select at the middle and press OK.
2 - Select TV Guide > From the Broadcaster and
press OK.
3 - Select one of channels in TV guide, then
press OK to watch the selected channel.
4 - While watching a channel, press OPTIONS.
5 - Select
6 - Select one item in the list and press OK.
7 - Select Change Logo.
8 - Once completed, you will see the mapped
channel information in the programme.
Preferences > Map Channel.
Preferences > Change Logo.
Video Selection
Digital TV channels can offer multi video signals (multifeed broadcast), different camera viewpoints or
angles of the same event or different programmes on
one TV channel. The TV shows a message if any such
TV channels are available.
Dual I-II
If an audio signal contains two audio languages but
one language or both has no language indication, this
option is available.
Favourite Channels
About Favourite Channels
In a favourite channel list, you can collect the
channels you like.
You can create 8 lists of favourite channels for easy
channel zapping. You can name each Favourites List
individually. Only in a Favourites List you can reorder
channels.
With a Favourites List selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using
19
or
keys.
Create a Favourites List
Add a Range of Channels
To create a favourite channels list from channel list...
1 - Press , to switch to TV.
2 - Press LIST (if available) or OK to open the
current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Create Favourites list and press OK.
5 - In the list at the left, select a channel you want as
a favourite and press OPTIONS. Channels come in
the list at the right in the order you add them. To
undo, select the channel in the list at the left and
press OPTIONS again. You can also select a
range of channels by pressing (down) to select
the last channel of the range you want to add and
then press OK.
6 - To finish adding channels, press BACK.
7 - The TV will ask to rename the Favourites List.
You can use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
If the channel list is long, alternatively, you can select
any channel, then press OPTIONS to open option
menu, then select Create Favourites
list and press OK.
To create a new favourite channels list by copying
existing favourite channel list...
1 - Press , to switch to TV.
2 - Press LIST (if available) or OK to open the
current channel list.
3 - Select at the upper right corner and press OK.
4 - Select Duplicate Favourites list and press OK.
5 - In the list at the left, select a channel you want as
a favourite and press OPTIONS. Channels come in
the list at the right in the order you add them. To
undo, select the channel in the list at the left and
press OPTIONS again. You can also select a
range of channels by pressing (down) to select
the last channel of the range you want to add and
then press OK.
6 - To finish adding channels, press BACK.
7 - The TV will ask to rename the Favourites List.
You can use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
You can add a range of channels in one go or start
a Favourites List by duplicating the channel list with
all channels and removing the channels you do not
want.
To add a consecutive range of channels to
a Favourites List in one go, you can use Select
Range.
To add a range of channels…
1 - Press SOURCE.
2 - Select Favourites.
3 - Open the Favourites List where you want to
add a range of channels.
4 - Select at the upper right corner and press OK.
5 - Select Edit Favourites List and press OK.
6 - In the list at the left select the first channel of the
range you want to add and press OK.
7 - Press (down) to select the last channel of the
range you want to add and then press OK.
8 - Select Add and press OK. The channels are
marked at the left.
Rename a Favourites List
You can only rename a Favourites List.
To rename a Favourites List…
1 - Press SOURCE.
2 - Select Favourites.
3 - Select at the upper right corner and press OK.
4 - Select Rename Favourite List and press OK.
5 - Use the on-screen keyboard
or press BACK to hide the on-screen keyboard,
then use the keyboard on the back of the remote
control (if available) to enter new name.
6 - When done, turn the remote control,
select Close and press OK.
7 - Press BACK to close the channel list.
Remove a Favourites List
You can only remove a Favourites List.
To remove a Favourites List…
1 - Press SOURCE.
2 - Select Favourites.
3 - Select at the upper right corner and press OK.
4 - Select Remove Favourite List and press OK.
Reorder Channels
Only in a Favourites List you can change the
sequence of channels (reorder).
To change the sequence of channels…
1 - Press SOURCES, and select Favourites.
2 - Open the Favourites List you want to reorder.
3 - Select at the upper right corner and press OK.
4 - Select Reorder Channels and press OK.
20
5 - In the Favourites List, select the channel you
want to reorder and press OK. (The channel will be
marked with grey box)
6 - With the (up) or (down) keys move the
channel where you want it.
7 - Press OK to confirm the new location.
8 - You can reorder channels with the same method
until you close the Favourites List with
the BACK key.
Text / Teletext
Text Pages
To open Text/Teletext press TEXT, while you are
watching TV channels.
To close Text, press TEXT again.
Select a Text page
To select a page . . .
1 - Enter the page number with the number keys.
2 - Use the arrow keys to navigate.
3 - Press a colour key to select a colour-coded
subject at the bottom of the screen.
Text sub-pages
A Text page number can hold several subpages. The
subpage numbers are shown on a bar next to the
main page number.
To select a subpage, press or .
T.O.P. Text pages
Some broadcasters offer T.O.P. Text.
To open T.O.P. Text pages within Text,
press OPTIONS and select T.O.P. Overview.
Favourite pages
The TV makes a list of the last 10 Text pages you
opened. You can easily reopen them again in the
Favourite Text pages column.
1 - In Text, select (heart) in the top left corner of
the screen to show the column of favourite pages.
2 - Press (down) or (up) to select a page
number and press OK to open the page.
You can clear the list with the option Clear Favourite
Pages.
Search Text
Text from a connected device
Some devices that receive TV channels can also offer
Text.
To open Text from a connected device . . .
1 - Press SOURCES, select the device and
press OK.
2 - While watching a channel on the device,
press OPTIONS, select Show Device Keys and
select the key and press OK.
3 - Press BACK to hide the device keys.
4 - To close Text, press BACK again.
Digital Text (UK only)
Some digital broadcasters offer dedicated Digital Text
or interactive TV on their digital TV channels. This
includes normal Text using the number, colour and
arrow keys to select and navigate.
To close Digital Text, press BACK.
Text Options
In Text/Teletext, press OPTIONS to select the
following…
• Freeze page
To stop the automatic rotation of subpages.
• Dual screen / Full screen
To show the TV channel and Text alongside each
other.
• T.O.P. overview
To open T.O.P. Text.
• Enlarge
To enlarge the Text page for comfortable reading.
• Reveal
To unhide hidden information on a page.
• Cycle subpages
To cycle subpages when these are available.
• Hide/Show Favourite Pages
To hide or show the list of favourite pages.
• Clear Favourite Pages
To clear the list of favourite pages.
• Language
To switch the group of characters that Text uses to
display correctly.
• Text 2.5
To activate the Text 2.5 for more colours and better
graphics.
You can select a word and scan Text for all
occurences of this word.
1 - Open a Text page and press OK.
2 - Select a word or number with the arrow keys.
3 - Press OK again to jump immediately to the next
occurence of this word or number.
4 - Press OK again to jump to the subsequent
occurence.
5 - To stop searching, press (up) until nothing is
selected.
Text Setup
Text language
Some digital TV broadcasters have several Text
languages available.
To set your primary and secondary Text language . . .
1 - Press , select All Settings and press OK.
2 - Select Region and Language and
21
press (right) to enter the menu.
3 - Select Language > Primary Text or Secondary
Text.
4 - Select your preferred Text languages.
5 - Press (left) repeatedly if necessary, to close
the menu.
Text 2.5
If available, Text 2.5 offers more colours and better
graphics. Text 2.5 is activated as a standard factory
setting.
To switch off Text 2.5…
1 - Press TEXT.
2 - With Text/Teletext open on screen,
press OPTIONS.
3 - Select Text 2.5 > Off and press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
22
6
HDMI Quality
Connect Devices
6.1
About Connections
Connectivity Guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.
When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.
If you need help to connect several devices to the TV,
you can visit the Philips TV connectivity guide. The
guide offers information on how to connect and
which cables to use.
Go to www.connectivityguide.philips.com
Antenna Port
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for TV signal.
For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.
If a device connected with HDMI is not working
correctly, check if a different HDMI Ultra HD setting
can solve this problem. For more information,
in Help, select Keywords and look up HDMI Ultra
HD.
Copy protection
HDMI cables support HDCP 2.2 (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
6.2
HDMI Ports
HDMI ARC
All of the HDMI connections on the TV have HDMI
ARC (Audio Return Channel).
If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to any
of the HDMI connections on this TV. With the HDMI
ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection
combines both signals.
You can use any HDMI connection on this TV to
connect the HTS but ARC is only available for 1
device/connection at a time.
HDMI MHL
With HDMI MHL, you can send what you see on your
Android smartphone or tablet to a TV screen.
The HDMI 4 connection on this TV
incorporates MHL 2.0 (Mobile High-Definition Link).
This wired connection offers great stability and
bandwidth, low latency, no wireless interference and
good quality sound reproduction. On top of that, the
23
MHL connection will charge the battery of your
smartphone or tablet. Although connected, your
mobile device will not be charging when the TV is on
standby.
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink.
Inform yourself about what passive MHL cable is
suited for your mobile device. In particular, with the
HDMI connector for the TV on one side, the type of
connector you need to connect to your smartphone
or tablet.
MHL, Mobile High-Definition Link and the MHL Logo
are trademarks or registered trademarks of the MHL,
LLC.
HDMI CEC - EasyLink
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD)
TV signals. For best signal quality transfer, use a High
speed HDMI cable and do not use an HDMI cable
longer than 5 m.
Example HDMI CEC branding names are property of
their respective owners.
DVI to HDMI
If you still own a device that only has a DVI
connection, you can connect the device to any of
the HDMI connection with a DVI to HDMI adapter.
Use a DVI to HDMI adapter if your device only has a
DVI connection. Use one of the HDMI connections
and add an Audio L/R cable (mini-jack 3.5mm)
to Audio IN for sound, on the back of the TV.
EasyLink HDMI CEC
If your devices are connected with HDMI and have
EasyLink, you can operate them with the TV remote
control. EasyLink HDMI CEC must be switched On on
the TV and the connected device.
With EasyLink you can operate a connected device
with the TV remote control. EasyLink uses HDMI CEC
(Consumer Electronics Control) to communicate with
the connected devices. Devices must support HDMI
CEC and must be connected with an HDMI
connection.
EasyLink setup
The TV comes with EasyLink switched on. Make sure
that all HDMI CEC settings are properly set up on the
connected EasyLink devices. EasyLink might not work
with devices from other brands.
Copy Protection
DVI and HDMI cables support HDCP (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
6.3
Y Pb Pr - Component
Y Pb Pr - Component Video is a high quality
connection.
The YPbPr connection can be used for High Definition
(HD) TV signals. Next to the Y, Pb and Pr signals add
the Audio Left and Right signals for sound.
Match the YPbPr (green, blue, red) connector colours
with the cable plugs when you connect.
Use an Audio L/R cinch cable if your device also has
sound.
HDMI CEC on other brands
The HDMI CEC functionality has different names on
24
6.4
Scart
Note: Not support for countries in Asia Pacific,
Middle East, and Africa.
SCART is a good quality connection.
The SCART connection can be used for CVBS and
RGB video signals but cannot be used for High
Definition (HD) TV signals. The SCART connection
combines video and audio signals. The SCART
connection also supports NTSC playback.
6.6
CAM with Smart Card - CI+
About CI+
Note: Not support for countries in Asia Pacific,
Middle East, and Africa.
CI+
This TV is ready for the CI+ Conditional Access .
With CI+ you can watch premium HD programmes,
like movies and sports, offered by digital TV operators
in your region. These programmes are scrambled by
the TV operator and descrambled with a prepaid CI+
module.
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes. These programmes have
a high level of copy protection.
Contact a digital TV operator for more information on
terms & conditions.
6.5
Audio Out - Optical
Audio Out - Optical is a high quality sound
connection.
This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theatre System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.
Smart Card
Digital TV operators provide a CI+ module
(Conditional Access Module - CAM) and an
accompanying smart card, when you subscribe to
their premium programmes.
Insert the smart card into the CAM module. See the
instruction you received from the operator.
To insert the CAM in the TV…
1 - Look on the CAM for the correct method of
insertion. Incorrect insertion can damage the CAM
and TV.
2 - While looking at the back of the TV, with the front
of the CAM facing towards you, gently insert the CAM
into the slot COMMON INTERFACE.
3 - Push the CAM in as far as it will go. Leave it in the
slot permanently.
25
When you switch on the TV, it may take a few minutes
before the CAM is activated. If a CAM is inserted and
subscription fees are paid (subscription methods can
differ), you can watch the scrambled channels
supported by the CAM smart card.
The CAM and smart card are exclusively for your TV. If
you remove the CAM, you will no longer be able to
watch the scrambled channels supported by the
CAM.
Passwords and PIN codes
Switch Off Timer
Switch off this automatic timer, if you only use the
remote control of the Set-top box. Switch this timer
off to prevent the TV from switching off automatically
after a 4 hour period without a key press on the
remote control of the TV.
Satellite Tuner
Connect the dish antenna cable to the Satellite
receiver.
For some CAMs, you must enter a PIN code to watch
its channels. When you set the PIN code for the CAM,
we recommend you to use the same code you are
using to unlock the TV.
To set the PIN code for the CAM…
1 - Press SOURCES .
2 - Select the channel type you are using the CAM
for Watch TV.
3 - Press OPTIONS and select Common
Interface.
4 - Select the TV operator of the CAM. The following
screens come from the TV operator. Follow the onscreen instruction to look up the PIN code setting.
6.7
Receiver - Set-Top Box
Cable Box
Use 2 antenna cables to connect the antenna to the
Set-top box (a digital receiver) and the TV.
Next to the antenna connection, add an HDMI cable
to connect the device to the TV.
Switch Off Timer
Switch off this automatic timer, if you only use the
remote control of the Set-top box. Switch this timer
off to prevent the TV from switching off automatically
after a 4 hour period without a key press on the
remote control of the TV.
6.8
Home Theatre System - HTS
Next to the antenna connections, add an HDMI cable
to connect the Set-top box to the TV.
Connect with HDMI ARC
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
HDMI ARC
If your Home Theatre System has an HDMI ARC
connection, you can use any HDMI connection on the
TV to connect. With HDMI ARC, you do not need to
connect the extra audio cable. The HDMI ARC
connection combines both signals.
All HDMI connections on the TV can offer the Audio
Return Channel (ARC) signal. But once you have
connected the Home Theatre System, the TV can
only send the ARC signal to this HDMI connection.
26
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Connect with HDMI
If you cannot hear the sound from the TV on your
Home Theatre System, check if you connected the
HDMI cable to an HDMI ARC connection on the
Home Theatre System. All HDMI connections on the
TV are HDMI ARC connections.
6.9
Smartphones and Tablets
To connect a smartphone or tablet to the TV, you can
use a wireless or wired connection.
Wireless
For a wireless connection, on your smartphone or
tablet download the Philips TV Remote App from
your favourite app store.
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
If the Home Theatre System has no HDMI ARC
connection, add an optical audio cable (Toslink) to
send the sound of the TV picture to the Home Theatre
System.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Problems with HTS sound
Wired
For a wired connection, use the HDMI 4 MHL
connection on the back of the TV. For more
information, in Help, select Keywords and
look up HDMI MHL for more information.
6.10
Blu-ray Disc Player
Use a High speed HDMI cable to connect the Bluray Disc player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC,
you can operate the player with the TV remote
control.
Sound with loud noise
If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theatre System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theatre System has no DTS sound processing.
You can fix this by setting the Audio Out Format of
the TV to Stereo (uncompressed).
Press for All
Settings > Sound > Advanced > Audio Out
Format.
No sound
6.11
DVD Player
Use an HDMI cable to connect the DVD player to the
TV.
27
If the DVD player is connected with HDMI and has
EasyLink CEC, you can operate the player with the TV
remote control.
6.12
Bluetooth - Speakers and
Gamepads
What You Need
You can connect a wireless device with Bluetooth® to
this TV – a wireless speaker, a subwoofer, a sound
bar or headphones. You can also connect a wireless
gamepad with Bluetooth LE.
To play the TV sound on a wireless speaker, you must
pair the wireless speaker with the TV. You can pair
some wireless speakers and a maximum of 4
Bluetooth LE (low energy) devices. The TV can only
play the sound on one speaker at a time. If you
connect a subwoofer, the sound is played on the TV
and the subwoofer. If you connect a sound bar the
sound is played on the sound bar only.
Attention - Audio to Video syncronisation
Many Bluetooth speaker systems have a high, so
called, 'latency'. High latency means that the audio
lags behind the video, causing unsynchronised 'lip
sync'. Before you purchase a wireless Bluetooth
speaker system, inform yourself about the newest
models and look for a device with a low latency
rating. Ask your dealer for advice.
Pairing a Device
1 - Switch on the wireless speaker and place it within
range of the TV.
2 - Press , select All Settings and press OK.
3 - Select Wireless and Networks and
press (right) to enter the menu.
4 - Select Bluetooth > Search Bluetooth Device.
5 - Select Start and press OK. Follow the
instuctions on screen. You will pair the device with the
TV and the TV will store the connection. You might
need to unpair a paired device first if the maximum
number of paired devices was reached.
6 - Select the type of device (headphone,
subwoofer, …).
7 - Press (left) repeatedly if necessary, to close
the menu.
Select a Device
Once a wireless Bluetooth speaker is paired, you can
select it to play the TV sound.
To select a speaker to play the TV sound…
1 - Press , select Speakers and press OK.
2 - Select the loudspeaker system you want.
3 - Press (left) repeatedly if necessary, to close
the menu.
Remove a Device
You can connect or disconnect a wireless Bluetooth
device. When a Bluetooth device is connected, you
can use the gamepad or hear the TV sound through
the wireless speaker. You can also remove a wireless
Bluetooth device. If you remove a Bluetooth device,
the device will be unpaired.
To remove or disconnect a wireless device…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks.
3 - Select Bluetooth > Remove Device.
4 - In the list, select the wireless device.
5 - Select Disconnect or Remove.
6 - Select OK.
7 - Press (left) repeatedly if necessary, to close
the menu.
Position the wireless speaker within a distance of 5
meters from the TV. Read the user manual of the
device for specific information on pairing and on
wireless range. Make sure the Bluetooth setting on TV
is switched on.
Once a wireless gamepad is paired, you can use it.
When a wireless speaker is paired, you can select it to
play the TV sound. When a device is paired, you do
not need to pair it again unless you remove the
device.
To pair a wireless speaker with the TV…
6.13
Headphones
You can connect a set of headphones to
the connection on the back of the TV. The
connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
To adjust the volume…
1 - Press , select Headphone Volume.
28
2 - Press the arrows (up) or (down) to adjust
the value.
3 - Press (left) repeatedly if necessary, to close
the menu.
Best Setting
Before you start playing a game from a connected
game console, we advice you to set the TV in the
ideal setting Game.
To set the TV to the ideal setting…
1 - Press , select All Settings and press OK.
2 - Select Picture and press (right) to enter the
menu.
3 - Select Picture Style > Game.
4 - Press (left) repeatedly if necessary, to close
the menu.
6.14
Game Console
HDMI
For best quality, connect the game console with a
High speed HDMI cable to the TV.
Y Pb Pr
Connect the game console with a component video
cable (Y Pb Pr) and an audio L/R cable to the TV.
6.15
Gamepad
Connect a Gamepad
To play games from the Internet on this TV, you can
connect a selected range of wireless Gamepads. You
can use Gamepads with a USB nano receiver or
gamepads with Bluetooth.
To connect a Gamepad with a USB nano receiver…
1 - Plug in the small nano receiver in one of the USB
connections on the side of the TV. The wireless nano
receiver comes with the Gamepad.
2 - If the Gamepad is switched on, you can use the
Gamepad.
You can connect a second Gamepad in the second
USB connection on the side of the TV.
Problems
To solve possible interference with other wireless
devices on TV…
• Use a USB extension cord and move the nano
receiver about 1 meter away from the TV.
• Alternatively, you can use a powered USB hub
connected to the TV and plug in the nano receivers in
the USB hub.
6.16
USB Hard Drive
29
What You Need
Formatting
If you connect a USB Hard Drive, you can pause or
record digital TV broadcasts (DVB broadcasts or
similar).
Minimum Disk Space
• To Pause
To pause a broadcast, you need a USB 2.0
compatible Hard Drive with a minimum of 4GB disk
space.
• To Record
To pause and record a broadcast, you need a
minimum of 250GB disk space.
Installation
Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it
connected permanently.
Before you can pause or record a broadcast, or store
apps, you must connect and format a USB Hard
Drive. Formatting removes all files from the USB Hard
Drive. If you want to record broadcasts with TV Guide
data from the Internet, you must setup the Internet
connection first before you install the USB Hard Drive.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
To format a USB Hard Drive…
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting. Follow the instructions on screen.
4 - The TV will ask if you want to use the USB Hard
Drive to store apps, agree to the question if you do.
5 - When the USB Hard Drive is formatted, leave it
connected permanently.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
6.17
USB Keyboard
Connect
Connect a USB keyboard (USB-HID type) to enter text
on your TV.
Use one of the USB connections to connect.
30
Loading...
