Philips 64PH9905 User Manual

Instructions for use

Digital Projection Television

64PH9905

ATSC CERTIFIED

DIGITAL TELEVISION

TM

Once your PHILIPS purchase is registered, you’re eligible to receive all the privileges of owning a

PHILIPS product. So complete and return the Warranty Registration Card enclosed with your

purchase at once. And take advantage of these important benefits.

Return your Warranty Registration card today to ensure you receive

all the benefits you’re entitled to.

Congratulations

on your

purchase,

and welcome to the

“family!”

Dear PHILIPS product owner:

Thank you for your confidence in PHILIPS. You’ve selected one of the best-built, best-backed
products available today. And we’ll do everything in our power to keep you happy with your purchase
for many years to come.

As a member of the PHILIPS “family,” you’re entitled to protection by one of the most comprehensive
warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special of fers for which
you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome–and thanks for investing in a PHILIPS product.

Sincerely ,

Robert Minkhorst
President and Chief Executive Officer

Know these

safety

symbols

t This “bolt of lightning” indicates uninsulated material within your unit which may cause an

electrical shock. For the safety of everyone in your household, please do not remove product
covering.

s The “exclamation point” calls attention to features for which you should read the enclosed

literature closely to prevent operating and maintenance problems.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT

TO RAIN OR MOISTURE.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert.
ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la

borne correspondante de la prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Warranty

Verification

Registering your product within
10 days confirms your right to
maximum protection under the
terms and conditions of your
PHILIPS warranty.

Owner

Confirmation

Your completed Warranty
Registration Card serves as
verification of ownership in the
event of product theft or loss.

Model

Registration

Returning your Warranty
Registration Card right away
guarantees you’ll receive all
the information and special
offers which you qualify for as the
owner of your model.

P.S. Remember, to get the most from your PHILIPS

product, you must return your Warranty
Registration Card within 10 days. So please mail it
to us right now!

R

E

G

I

S

T

R

A

T

I

O

N

N

E

E

D

E

D

W

I

T

H

I

N

1

0

D

A

Y

S

Hurry!

2

INTERNET ADDRESS: http://www.philipsusa.com

3

SAFETY INSTRUCTIONS - Read before operating equipment

This product was designed and manufactured to meet strict quality and
safety standards. There are, however, some installation and operation
precautions which you should be particularly aware of.

1. Read Instructions - All the safety and operating instructions should
be read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should
be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating
instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be
followed.

5. Water and Moisture - The appliance should not be used near water

- for example, near a bathtub, washbowl, kitchen sink, laundry tub,
in a wet basement or near a swimming pool, etc.

6. Carts and Stands - The appliance should be used only with a cart or
stand that is recommended by the manufacturer.

6A. An appliance and cart combination should be moved

with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination
to overturn.

6B. Tilt/Stability - All televisions must comply with recommended

international global safety standards for tilt and stability properties
of its cabinet design.

• Do not compromise these design standards by applying exces-

sive pull force to the front, or top, of the cabinet which could
ultimately overturn the product.

• Also, do not endanger yourself, or children, by placing elec-

tronic equipment/toys on the top of the cabinet. Such items
could unsuspectingly fall from the top of the set and cause
product damage and/or personal injury.

7. Wall or Ceiling Mounting - The appliance should be mounted to a
wall or ceiling only as recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or
position does not interfere with its proper ventilation. For example,
the appliance should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings; or, placed in a
built-in installation, such as a bookcase or cabinet that may impede
the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power
supply only of the type described in the operating instructions or as
marked on the appliance.

11. Power-Cord Protection - Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords and
plugs, convenience receptacles, and the point where they exit from
the appliance.

12. Cleaning - The appliance should be cleaned only as recommended
by the manufacturer.

13. Power Lines - An outdoor antenna should be located away from
power lines.

14. Outdoor Antenna Grounding - If an outside antenna is connected to
the receiver, be sure the antenna system is grounded so as to
provide some protection against voltage surges and built up static
charges.

Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper grounding of the mats
and supporting structure grounding of the lead-in wire to an
antenna discharge unit, size of grounding connectors, location of
antenna-discharge unit, connection to grounding electrodes and
requirements for the grounding electrode. See Fig. below.

15. Non-use Periods - The power cord of the appliance should be
unplugged from the outlet when left unused for a long period of
time.

16. Object and Liquid Entry - Care should be taken so that objects do
not fall and liquids are not spilled into the enclosure through
openings.

17. Damage Requiring Service - The appliance should be serviced by
qualified service personnel when:

A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the

appliance; or

C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits

a marked change in performance; or

E. The appliance has been dropped, or the enclosure damaged.

18. Servicing - The user should not attempt to service the appliance

beyond that described in the operating instructions. All other
servicing should be referred to qualified service personnel.

Note to the CATV system installer: This reminder is provided to call the
CATV system installer's attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.

Example of Antenna Grounding
as per NEC - National Electric Code

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE (NEC)

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

(NEC SECTION 810-20)

TABLE OF CONTENTS

Copyright © 1999 Philips Consumer Electronics. All rights reserved.

4

Getting Started

Welcome/Product Registration...................2

Safety/Precautions .....................................................3

Table of Contents.......................................................4

Features, Model and Cabinet Information.................5

12

1

2
3
4

5

6

7

8

9

10

11

NTSC Analog On-Screen Menu Features

FIRST TIME SETUP

✧Automatic Programming of local NTSC

Channels and other Control Features ..............6-7

PICTURE MENU

✧Adjusting Color, Brightness, Sharpness,

Tint, and Picture Controls...................................8

✧Using the Clearview Control...............................8

✧Adjusting the DPTV's Convergence Control......9

FEATURES MENU

✧Setting the Smart Picture Controls ..............10-11

✧Setting the DPTV for Closed Captioning..........12

✧Setting the DPTV for Cable/Antenna Signals...13
✧Adding Channels in Memory (Automatically) .14

✧Adding Channels in Memory (Manually).........15

✧Setting the DPTV Clock....................................16

✧Adjusting the Channel Display Control............17

✧Using the Channel Label Control .....................18

✧Using Parental Control/Content Advisory:

• Code Setup/Blocking Channels...............19-20

• Content Advisory - Movie Ratings .........21-22

• Parental Guidelines.......................................23

• Blocking Options/Review Settings...............24

SOUND MENU

✧Adjusting Bass, Treble, and Balance Sound

Controls.............................................................25

✧Setting the DPTV for Stereo/SAP Programs ...26

✧Using the Volume Display Control...................27

✧Using the Automatic Volume Limiter Control .28

Pronto Remote NTSC Features

✧Analog/NTSC DPTV Features.................29

Audio/Video Connections

✧Auxiliary 1/2/3 Audio/Video Inputs...30-31

✧Audio/Video Outputs........................................31

✧S-Video Input....................................................32

✧DVD (Component Input) Video Connections ..33

✧System Audio Output Connections ..................34

FEATURES

EXIT

MAIN MENU

SOUNDPICTURE

1ST TIME SETUP

ATSC Digital On-Screen Menu Features

DTV SETUP

✧Automatic Programming of Digital Channels

and Tuning Program/Channel Selections..........35

PICTURE MENU

✧Adjusting Color, Brightness, Sharpness,

Tint, and Picture Controls.................................36

✧Adjusting DTV Convergence............................37

SOUND MENU

✧Surround Sound Speaker Connections..............38

✧Selecting the DPTV Surround Mode Control...39
✧Dolby Digital Internal and External Speaker

System Use and Connections ......................39-40

✧Adjusting Bass and Treble Sound Controls......41

✧Using the Auto Volume Control .......................41

SPEAKERS MENU

✧Adjusting Speaker Menu Controls for

Front/Center/Rear multi-speaker arrangements42

✧Using the Test Tone Audio Signal Control.......43

FEATURES MENU

✧Using the DPTV for ATSC Closed Captioning44

✧Adding Channels in Memory (Manually).........45

✧Using Parental Control/Content Advisory:

• Code Setup/Blocking Channels...............46-47

• Content Advisory - Movie Ratings .........48-49

• Parental Guidelines.......................................50

• Blocking Options/Review Settings...............51

Pronto Remote ATSC Features

✧Digital/ATSC DPTV Features ................52

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

MONITOR On-Screen Features

✧Connection of VGA/SVGA/ and High Definition

(HD) Component Video auxiliary equipment ..53

✧Adjusting of DPTV Monitor Display controls

(for VGA/SVGA/EXT HD devices) ................54

General Information

Tips if Something Isn’t Working.............................55

Cleaning and Care....................................................55

Index ........................................................................56

Regulatory Notices ..................................................56

Glossary of DPTV Terms ........................................57

Factory Service Locations..................................58-59

Warranty ..................................................................60

BRIGHTNESS

SHARPNESS
SVM OFF
COLOR
TINT
VOLUME BARON

FEATURES

5

DPTV SET-UP AND QUICK USE GUIDE

Use the Set-Up Guide (supplied with your
DPTV information packet) for details on:

• Antenna Hook-ups

• First Time Use and
Control Descriptions

• Basic DPTV and
Pronto Remote
Operation

• DTV Program Rollout Information

As you unpack your DPTV please note that the
following items have been included with your set:

• Owner's Manual and DPTV Quick Use Guide

- Safety Tip Information

- Factory Service Center Locations

• Warranty Registration Card

• Pronto Remote Control Transmitter

- Product Package contains dedicated Pronto
Owner’s Manual information

• Batteries for Remote Control Use
Please take a few minutes to complete your

registration card. The serial number for the DPTV
is on the back of the product.

Refer to the back of this manual for instructions on
the cleaning and care of the DPTV.

ATSC Certified - for full compliance with analog
NTSC and all 18 digital ATSC formats as specified by
the Federal Communications Commission (FCC).

High Definition Digital - with full 1920 x 1080
interlaced image resolution capability to achieve
superior image performance.

64" Widescreen Display - with a super-large 64"
Widescreen 16:9 display format which provides for a
true home theater or cinematic experience. If a 4:3
aspect ratio picture is the primary source, it will be
expanded to fill the screen.

120-Watt Amplifier - to provide up to 20 watts
amplification for each of the Left/Right front, Center,
Left/Right rear Surround, and Subwoofer channel
speakers.

First Time Set Up - for both NTSC and ATSC
channel programming to automatically preset the
DPTV for available area stations.

Parental Control for “Censoring” - this feature can
block out channels to keep children from watching
undesirable programming. Parental Guideline and
Movie Rating settings can also be used as part of the
new Content Advisory Data system available with TV
programming.

Pronto Remote Control - universal, learn remote
which controls virtually all IR devices, learns new
commands as your system expands, and can be
customized according to your personal preferences.
Featuring a large LCD backlit touchscreen, the Pronto
gives you easy access to all key DPTV features.

Dolby®Digital Sound - for multichannel sound
reproduction at its best. Fully compatible DPTV audio
system will replay a received Dolby Digital 5.1 sound
source through internal system amplification, or
function within a home theater sound system.

Audio/Video Connections - for external sources and
home theater equipment to provide the ultimate in
flexibility. In addition to separate NTSC/ATSC antenna
inputs, connections include inputs formatted for S­Video; composite video; Left/Right audio; six-channel
audio (directly to internal amplifiers); External Center
Channel Audio Amplifier Inputs; VGA; and High
Definition component (Y PB PR) video - such as used
with DVD players..
Output possibilities include Left/Right audio; SPDIF;
rear speaker connections; front speaker connections;
variable and amplified subwoofer speaker connections.

VGA/SVGA - 15-pin D-sub female connection for
impressive multimedia display of computer source
material through the DPTV’s Monitor operation mode.

Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic” and the
double-D symbol are trademarks of Dolby
Laboratories. Confidential Unpublished
Works. ©1992-1997 Dolby Laboratories, Inc.
All rights reserved.

Product End-of-Use disposal

Your new digital projection television and its
packaging contain materials that can be recycled
and reused. Specialized companies can recycle
your product to increase the amount of reusable
materials and minimize the amounts which need
to be properly disposed.

Your product also uses batteries which should not
be thrown away when depleted, but should be
handed in and disposed of as small chemical
waste.

Please find out about the local regulations on how
to dispose of your old products, batteries, and
packaging materials whenever you replace
existing equipment.

NOTE: Not all features (and drawings) discussed in this
owner’s manual will necessarily match those found with your
television set. This is normal and does not require you
contacting your dealer or requesting service.

Because of continuous product improvements, the
information mentioned in the documents accompanying your
product are subject to change without notice.

64PH9905 Digital Projection Television

PRODUCTDESIGN

DPTV/NTSC/MONITOR

T

Projection Television
(DPTV) represents an
advanced first step con­cept in integrated digital
products. Designed for
discrete and cross-over
system functionality the
64PH9905 will support
traditional NTSC
Television standards,
receive all certified FCC
defined ATSC digital
transmission formats,as
well as perform PC

TS1007 Pronto Remote Control

INTEGRATED

he Philips
64PH9905 Digital

DIGITAL PROJECTION TELEVISION

TABLEOF CONTENTS - QUICK USE GUIDE

• For details on product safety,registration,

Getting Started

Warning/Precautions . . . . . . . . . . . . . . . . . .1

DPTV Integrated Product Design and Features
Basic DPTV and Remote Control Description
of Controls and Operations
Digital (ATSC) Menu Control Operations
Analog (NTSC) Menu Control Operations
Monitor Menu Control Operations
Digital TV Rollout - Time/Terms/& Technology

P

Use guide (page 8) for
additional information on:
¥scheduled Digital

. . . . . . . . . . . . . . . . .2-3

digital 1nf0rmation

lease refer to the rear
section of this Quick-

Broadcast program roll­out dates, and what will
be available from the
various netw orks and
program suppliers

. .1

. . . . .4-5

. . . . . .6

. . . . . . . . . . . .7

¥the basics on how HDTV,

Digital, and Analog TV
systems differ and how
they can be received

¥other ATSC (or Advanced

Television System
Committee) news and
details on digital broad
casting product opera­tions and services

.8

warranty,and service refer to the other literature
included with your TV information packet.
Please retain all these materials and keep them
handy for future reference.

NOTE:Not all features (and drawings) discussed in this
owner’s manual will necessarily match those found with
your television set. This is normal and does not require you
contacting your dealer or requesting service.

WARNING:TO PREVENT FIRE OR SHOCK
HAZARD DO NOT EXPOSE THIS UNIT TO

DIGITAL TELEVISION

RAIN OR EXCESSIVE MOISTURE.

TM

ATSC CERTIFIED

NTSC/ANALOG ON-SCREEN MENU FEATURES

FIRST TIME SETUP

6

ok

exit

menu

DTV

Analog

DTV3/3

MAIN MENU

Press the Pronto remote’s
“analog format” (or the
“Source” button on the
DPTV keyboard) to select the
NTSC operating mode.

F

irst Time Setup automatically takes

care of some basic control feature
settings for you. Follow the steps in this
section to quickly add area channel
numbers into the DPTV's scan system
memory, and set the DPTV for your
connected signal (Antenna or Cable.)
You can also set-up your TV Smart
Clock feature for the first time as well.

Press the MENU (or ok) button

on the Pronto remote or DPTV. An
on-screen list of NTSC features
shows on the "MAIN MENU".

Select "1ST TIME SETUP" on

the DPTV's Main Menu. (Selected
MENU item is highlighted in RED.)

Press the remote's Menu
buttons to move UP/DOWN and

from SIDE-TO-SIDE within the list
of on-screen features.

Press CH(annel)▲ ▼ and
VOLume (+) (-)

on the DPTV’s
local keyboard to move UP/DOWN
and from SIDE-TO-SIDE within
the list of on-screen features.

Press MENU (or ok) button on

the remote or DPTV to begin
SETUP.

Follow the instructions shown on
the screen to guide you through the
First Time Setup and use of your
new DPTV.

BEGIN

STOP

1

2

3

Continued on Next Page

SMART HELP

Note: The Smart Clock

option “SET TIME
AUTOMATICALLY” sets the
DPTV’s clock according to TV
station Data Services Information
(where available). With this mode
the clock will automatically reset
itself after power outages and
update itself for Daylight Savings
Time changes. The Smart Clock
feature will also reset itself every
time the TV is turned off.
The “SET TIME MANUALLY”
option allows you to only enter
the current time of day and AM or
PM settings.

See following page for details on “Set Time Manually”

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

ANALOG MAIN MENU

FEATURES

1ST TIME SETUP

SOUNDPICTURE

2

EXIT

UP
CH

+

VOL

M

SOURCE

EXIT

VOL

–

CH
DOWN

3

1

2

The First-Time Setup

provides a simple method

of adjusting the most

important controls for

this television receiver.

Press "M" To Continue

OR

Please check that your

analog TV antenna or cable is

connected to the plug

marked ANT on

the TV rear input panel.

Press STATUS to Quit

Press "M" to Continue

or

The search for active
channels is complete

for the analog TV antenna.

17 channels were found

and saved in memory

Press "M" to Continue

Press "▲ ▼" to select the

time zone that you live in.

Press "M" to Continue

.

ATLANTIC
EASTERN
CENTRAL
MOUNTAIN
PACIFIC
ALASKA

HAWAII

Many of the current TV

control settings will be
modified by continuing

with First-Time Setup.

Press STATUS to Quit

Press "M" to Continue

for the analog TV antenna.

This TV contains a clock

which can automatically

SMART CLOCK feature.

by certain TV stations.

Press "M" to Continue

or

* Please Wait *

System is testing for

correct tuning mode

1

be set through the

The clock will be set

to the time broadcast

Do you observe

Daylight Savings Time?

YES
NO

Press "▲ ▼" to Select

Press "M" to Continue

This TV is equipped with

the Smart Clock feature.

This feature is designed

to operate only on the

analog TV antenna.

Press "M" to Continue

* Please Wait *

System is searching for

all active channels

for the analog TV antenna.

Testing channel 2

in cable mode.

Do you want to set the

clock automatically?

SET TIME AUTOMATICALLY
SET TIME MANUALLY

Press "▲ ▼" to Select

Press "M" to Continue

The time is broadcast by

certain TV stations

We suggest trying PBS first

Enter the channel

X

Press "M" to Continue

7

NTSC/ANALOG ON-SCREEN MENU FEATURES

E

FIRST TIME SETUP

(

CONTINUED)

SMART HELP

P

lease remember, SETUP is a

first-use, one-time operation
and will not have to be repeated
after initial adjustments are made.

Note: Press the “exit” button on
the remote or DPTV to stop the

SETUP operation at any time.

Convergence (or lining

up of red and blue light
paths on the TV screen) has been
preset at the factory for your
convenience and should not need
any further adjustments. However,
Convergence controls are
provided (in both the First Time
Setup and Picture Menu areas) in
case the picture on your DPTV
shows color fringing. Color
fringing is when colors “bleed” or
appear around the edges of on
screen images and objects. If your
DPTV should ever need to be
adjusted for such a condition,
please also refer to the DPTV’s
Picture Menu Convergence
control page section for further
details.

Clock Note: When setting the time
“manually”, you can use the
Pronto remote number buttons
(touchscreen 2/3) to enter the
current time, or use the arrow

▲▼

buttons on the remote to select the
time and the AM/PM settings.

See the “Convergence Control” Smart Help Note given on this page.

OR

System is looking for
time on channel X.

Please wait 45 seconds

Please check TV clock and

adjust if necessary.

The time is currently

set to PM

Please enter current time

Press "M" to Continue

PRESS TO ALIGN RED
PRESS MENU TO RETURN

CONVERGE RED POINTS

DIGIT 2, 4, 6, 8 TO MOVE CURSOR

PRESS MENU NOW TO CONTINUE

12 : 00

or

USE TO ADJUST

MENU TO RETURN

Time was found
on channel X.

The time is 12:00PM.

Press "M" to Continue

CONVERGENCE MENU
ALIGN RED

ALIGN BLUE
CONVERGE MULTI POINT
BACK

PRESS TO ALIGN BLUE

PRESS MENU TO RETURN

S

MART CLOCK NOT

Time was not found

on channel X.

ENTER ANOTHER CHANNEL
SET TIME MANUALLY

Press "▲ ▼" to Select

Press "M" to Continue

This completes the

First-Time Setup.

Press "M" to Exit Setup

CONVERGENCE MULTI POINT
CONVERGE RED POINTS

CONVERGE BLUE POINTS
RESTORE FACTORY SETTINGS
SAVE ADJUSTMENTS
BACK

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSC/ANALOG PICTURE MENU CONTROLS

COLOR, BRIGHTNESS,

SHARPNESS, TINT, PICTURE

8

MAIN MENU

T

o adjust your DPTV color and

picture controls, select a TV
channel and follow the steps shown
below:

Select BRIGHTNESS,

PICTURE, COLOR, TINT, or

SHARPNESS picture control.

With the PICTURE MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU (or ok) button.

Press the § or © arrow

buttons to adjust the selected

control.

Press the “exit” button to clear

the screen.

STOP

1

2

3

CLEARVIEW

C

learview is a sharpness feature

which smoothes out
background snow (or picture noise)
without losing picture image detail
or crispness.

Select CLEARVIEW control.

With the PICTURE MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU (or ok) button.

Press the MENU ▲▼ buttons

to move the RED highlight. Press
the MENU button to select (

U) the

ENHANCED mode.

Press the “exit” button to clear

the screen.

BEGIN

STOP

1

2

3

Remember, control settings are at normal mid-range levels when
the bar scale is centered.

COLOR Press (-) or (+) to add or eliminate color.
BRIGHTNESS Press (-) or (+) until dark parts of the picture

show good detail.

SHARPNESS* Press (-) or (+) to improve detail in the picture.
TINT Press (-) or (+) to obtain natural skin tones.
PICTURE Press (-) or (+) until whitest parts of the picture are

as bright as you prefer.

SMART

HELP

Select the
NEXT control and
then press MENU
(or ok) button on the
remote to view
additional controls
grouped under same
feature heading
(Tint, Brightness,
Picture, etc.).

* Note: An additional Picture Menu “VIDEO

ENHANCEMENT” control (similar in function

and use as the Sharpness control) is also available to
further improve picture intensity and detail,
particularly for the playback of DVD player source
material.

MIN

MAX

VIDEO ENHANCEMENT

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

1

menu

ok

exit

Analog

DTV3/3

3

DTV

1

SOUND

mute

channel

++

volume

++

EXIT

PICTURE MENU

COLOR TINT

BRIGHT

SHARP

EXIT

COLOR

MIN

EXIT

2


CLEARVIEW

MORE...

1 OF 2

MAX

NEXT...

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

ok

exit

Analog

SOUND

EXIT

mute

channel

DTV

++

2

volume

++

DTV4/4

1

PICTURE MENU

COLOR TINT

BRIGHT

SHARP

EXIT

CLEARVIEW

NORMAL

ENHANCED

EXIT


CLEARVIEW

MORE...

1 OF 2

NEXT...

3

NTSC/ANALOG PICTURE MENU CONTROLS

RED/BLUE CONVERGENCE

SMART HELP

9

C

onvergence is the correct

lining up of the red and blue
light paths on the DPTV screen.
NOTE: If no color fringing (see
Smart Help) shows, then no
Convergence adjustments are
necessary.

Select CONVERGENCE

control.

With PICTURE MENU (2 of 2)
on-screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the MENU ▲▼ buttons

to select either the Red or Blue
Convergence control, press the
MENU button to continue.

Press the MENU buttons

to move the selected red (or blue)
convergence cross directly over the
white cross on the DPTV screen.

The red (or blue) cross is properly
adjusted when it is completely
merged with the white cross. (No
color appears around the edge of
the white cross).

Press the “exit” button to clear

the screen when convergence
adjustments are complete.

1

2

3

STOP

4

Remember, Convergence

has been set at the factory for
best viewing, but if one or more of
the (red or blue) colors appear
around the edges of objects (color
fringing) follow the steps given in
this section.

NOTE: Adjustments for “Multi-Point” on­screen color fringing can also be made as part
of the DPTV’s Convergence control system.
Follow the on screen menu directions to
select individual screen areas that can be
readjusted and set for varying red/blue color
fringing conditions. These multi-point
settings can then be “Saved” to memory for
the specific areas of the DPTV screen (or
Factory Settings for convergence can be
recalled and put back into place for use).

CONVERGENCE MULTI POINT
CONVERGE RED POINTS

CONVERGE BLUE POINTS
RESTORE FACTORY SETTINGS
SAVE ADJUSTMENTS
BACK

CONVERGE RED POINTS

USE TO ADJUST

DIGIT 2, 4, 6, 8 TO MOVE CURSOR

MENU TO RETURN

PRESS MENU NOW TO CONTINUE

MULTI-POINT CONVERGENCE CONTROLS

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

ok

exit

Analog

DTV3/3

DTV

2

1

SOUND

EXIT

mute

channel

++

volume

++

2

PICTURE MENU

COLOR TINT

BRIGHT

SHARP

EXIT

PICTURE MENU

CONVERGENCE

VIDEO ENHANCEMENT

EXIT


CLEARVIEW

MORE...

1 OF 2

MORE...

2 OF 2

3

4

CONVERGENCE MENU
ALIGN RED

ALIGN BLUE
CONVERGE MULTI POINT
BACK

PRESS TO ALIGN RED
PRESS MENU TO RETURN

NTSC/ANALOG FEATURE MENU CONTROLS

SMART PICTURE

10

W

ith Smart Picture you can set a

number of video and audio
controls to your own personal
preference. Once the individual
controls have been adjusted to the
levels you desire, use the list of Smart
Picture feature category titles to
quickly reselect these “personalized”
settings contained within the memory
of the DPTV. (See the next page for
more details on the labeling options
and use of Smart Picture.)

Select the SMART PICTURE

control.

With the FEATURES MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the MENU ▲▼ buttons to

highlight the category list for Smart
Picture. Press the MENU button to
select (

U) the desired title.

Press the MENU buttons

to choose any of the individual
controls you wish to adjust for the
Smart Picture selected title. Then
press the Menu (or ok) button to
select the highlighted control.

Press the Menu § or © arrow

(or Menu buttons) to adjust the

selected control as needed.

Press the “exit” button on the

remote to clear the screen after you
have finished with all of your Smart
Picture feature control adjustments.

1

2

STOP

3

4

5

SMART HELP

Note: Select the

“FACTORY SETTINGS”
category to automatically return the
DPTV to the video and audio control
levels preset at the factory prior to
product shipment.

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

SOUND

EXIT

FEATURE MENU

SMART

CABLE
TUNING

BEGIN

CLOSED
CAPTION

EXIT

CHANNEL
MEMORY

MORE...

1 OF 3

3

2

1

menu

ok

exit

Analog

DTV4/4

DTV

mute

channel

++

2

volume

++

1

3

4

SMART PICTURE

LABEL 1
LABEL 2
LABEL 3
LABEL 4
LABEL 5
FACTORY SETTINGS

M to SELECT

EXIT

5

SMART PICTURE MENU

CHANGE LABEL

SHARP

BRIGHT

EXIT

SMART PICTURE MENU

CLEARVIEW

BASS

BALANCE

EXIT

COLOR

TINT


MORE...

1 OF 2

SAP

TREBLE

STEREO

MORE...

2 OF 2

SMART PICTURE

CHANGE LABEL

++

++

mute

volume

channel

ok

exit

menu

DTV

Analog

DTV4/4

3

1

TINT

SMART PICTURE MENU


EXIT

1 OF 2

COLOR

MORE...

BRIGHT

CHANGE LABEL

SHARP

SMART PICTURE LABEL

when FINISHED

to SELECT

M

M Y O W N

to CHANGE

or
or

2

NTSC/ANALOG FEATURE MENU CONTROLS

11

F

ollowing your initial setup

adjustments (see previous page),
just select the desired Smart Picture
category in order to place the DPTV
to the personalized set of audio and
video control settings for that title.

Select the SMART PICTURE

control.

With the FEATURES MENU on­screen, move the RED highlight with
the MENU buttons. Then press

the MENU button.

Press the MENU ▲▼ buttons

with the list of “SMART PICTURE”
categories on the DPTV screen to
highlight the desired category. Then
press the Menu (or ok) button to
select the audio and video control
settings for that particular title.

Press the “exit” button on the

remote to clear the screen.

1

2

STOP

3

T

he "CHANGE LABEL" control

can be used to update the title of
a SMART PICTURE setting into a
name or label that may be easier for
you to remember.

With the "SMART PICTURE

LABEL" control on-screen, press

the MENU ▲▼ buttons to spell out
a new label or title for the selected

SMART PICTURE category title.

Press the MENU § © buttons

to move the red highlight to each

letter space.

Press the “exit” button to clear

the screen when the new label is
finished.

1

2

3

STOP

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

FEATURE MENU

SMART

CLOSED
CAPTION

EXIT

2

1

menu

ok

exit

Analog

CABLE
TUNING

CHANNEL
MEMORY

MORE...

1 OF 3

mute

channel

DTV

++

2

volume

++

DTV4/4

1

SMART PICTURE

LABEL 1
LABEL 2
LABEL 3
LABEL 4
LABEL 5
FACTORY SETTINGS

M to SELECT

EXIT

BEGIN

3

NTSC/ANALOG FEATURE MENU CONTROLS

NOTE: Not all TV programs and product commercials are made for

broadcast with Closed Caption (CC) information included. Neither are all
Closed Caption modes (CAPTION 1-4; or TEXT 1-4) necessarily being used by a
broadcast station during the transmission of a closed caption program. Usually
"CAPTION 1" is the most used mode to view captioned material. Refer to your
area's TV program listings for the stations and times of Closed Caption shows.

CAPTION 1 mode

Example Screen Display

FULL SCREEN TEXT

will block DPTV screen from viewing

Closed Caption information will usually appear
in black and white (although some broadcasters
or networks may occasionally use color to
highlight or draw attention to certain areas.)

CLOSED CAPTION

NOTE: The ON DURING
MUTE ONLY

control can
be used to set the DPTV to
turn the Closed Caption
mode "ON" whenever the
MUTE button on the
remote is pressed.

SMART HELP

12

MAIN MENU

C

losed Captioning (CC) allows

you to read the voice content of
NTSC television programs on the
DPTV screen. Designed to help the
hearing impaired this feature uses
on-screen "text boxes" to show
dialogue and conversations while
the TV program is in progress.

Select CLOSED CAPTIONING

control.

With the FEATURES MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the MENU ▲▼ buttons

to move the RED highlight. Press
the MENU button to select (

U) the
desired Closed Caption mode - For
Example: "ALWAYS ON" and
"CAPTION 1".

CAPTION 1, 2, 3, 4:

dialogue (and descriptions)
for the action on the captioned
TV program shows on-screen.
(See Important Note on this
page.)

TEXT 1, 2, 3, 4:

often used for channel guide,
schedules, or bulletin board
information for CC programs.

After making your Caption mode

selection, press the “exit” button to

clear the screen. The selected
Closed Caption mode will be active.

To cancel, set the Closed Captioned
feature to OFF when finished.

1

2

STOP

3

Remember, broadcast

stations will often use
spelling abbreviations, symbols,
dropouts and other grammatical
shortcuts in order to keep pace
with the on-screen action. These
type factors vary upon the source
of the captioned text material and
do not indicate a need for service
on the part of the DPTV.

CC

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

ok

exit

Analog

DTV3/3

SOUND

EXIT

mute

2

channel

DTV

++

volume

++

FEATURE MENU

SMART

CLOSED
CAPTION

EXIT

CLOSED CAPTION

ALWAYS ON
ALWAYS OFF
ON DURING MUTE ONLY

CAPTION 1
CAPTION 2
CAPTION 3
CAPTION 4

EXIT

CABLE
TUNING

CHANNEL
MEMORY

MORE...

1 OF 3

TEXT 1
TEXT 2
TEXT 3
TEXT 4

1

3

JOHN: Why did they move the
meeting up to this week?
MARSHA: I don't know, but they
are pushing to close the deal.

CLOSE CAPTION PROGRAMS ON WXYZ

ALL ITEMS ARE EASTERN STANDARD TIME (EST)

CHECK LOCAL LISTINGS

FOR TIMES IN YOUR AREA

6:00 TOP OF THE MORNING
10:00 THE BEST LITTLE CALL-IN SHOW EVER
12:00 NOONDAY NEWS

1:30 AS YOUR LIFE TURNS MY WORLD AROUND

6:00 WORLD NEWS FOR TODAY

9:00 PLAYHOUSE MOVIE OF THE WEEK

NTSC/ANALOG FEATURE MENU CONTROLS

CABLE TUNING

13

Y

ou need to make sure the

DPTV is set to pick up either
Cable TV or Antenna signals. In
other words, the DPTV needs to
know if you connected a Cable TV
signal or a normal antenna to its
ANTENNA plug.

NOTE: If you went through First
Time Setup (see page 6), this task
has already been completed for
you.

Select CABLE CHANNEL

TUNING control.

With the FEATURES MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the MENU ▲▼ buttons

to move the RED highlight. Press
the MENU button to select (

U) the
desired mode - For Example:
CABLE.

CABLE- If you DO have

Cable TV connected

to the DPTV.
Channels 1-125
available.

NORMAL- If you have an

Antenna connected

to the DPTV.
Channels 2-69
available.

Press the “exit” button to clear

the screen.

STOP

1

2

3

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

ok

exit

Analog

SOUND

EXIT

mute

channel

DTV

++

2

volume

++

DTV4/4

1

FEATURE MENU

SMART


CLOSED

CAPTIONS

EXIT

CABLE TUNING

CABLE

NORMAL

EXIT

CABLE

TUNING

CHANNEL

MEMORY

MORE...

1 OF 3

3

CHANNEL MEMORY

AUTO-PROGRAMMING

NTSC/ANALOG FEATURE MENU CONTROLS

U Channel Numbers are
Saved in Memory

SMART HELP

14

MAIN MENU

Y

our DPTV can automatically set

itself for local area (or Cable TV)
channels. This makes it easy for you
to select only the TV stations in your
area when the CHANNEL

▲▼

buttons are pressed.
NOTE: If you went through First

Time Setup (see page 6), this task has
already been completed for you.

Select CHANNEL MEMORY

(START AUTO-PROGRAMMING)

control.

With the FEATURES MENU on­screen, move the RED highlight with
the MENU buttons. Then press

the MENU button.

Press the MENU ▲▼ buttons to

select the START AUTO­PROGRAMMING option, then press
the Menu button to begin.

The TV shows which channel
numbers are "SAVED" (

U) as they

are added into memory.
"Auto-programming CHANNEL

MEMORY is finished" shows when
the DPTV is through adding channels.

Press the “exit” (or Menu)

button to clear the screen.

STOP

1

2

3

Try it out. Press the

CHANNEL▲▼ buttons

and see which channels you can
select.

Remember, an Antenna or Cable
signal must first be connected to
your DPTV so that channels can
be saved.

If you want to delete any
unwanted channels from the
DPTV's memory, see
"ADD/DELETE CHANNELS" on
the next page.

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

ok

exit

Analog

3

SOUND

FEATURE MENU

EXIT

mute

channel

DTV

++

2

volume

++

DTV4/4

1

SMART


CLOSED

CAPTIONS

EXIT

CHANNEL MEMORY

ADD/DELETE
CHANNELS

START
AUTO-PROGRAMMING

EXIT

AUTO-PROGRAMMING

CHANNEL MEMORY

1 2 3 4
5 6 7 8
9 1O 11 12

13 14 15 16
17 18 19 20
21 22 23 24

Press "M" to

Stop Auto-Program

CABLE

TUNING

CHANNEL

MEMORY

MORE...

1 OF 3

NTSC/ANALOG FEATURE MENU CONTROLS

ADD/DELETE CHANNELS

15

A

uto-Programming (see

previous page) adds all the
channels it can find (on your
Antenna or Cable TV system) into
the DPTV's memory. Add/Delete
Channels makes it easy for you to
add other channels, or drop
unwanted channels, from the list of
channels in the DPTV's memory.

Select CHANNEL MEMORY

(ADD/DELETE CHANNELS)

control.
With the FEATURES MENU on-

screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the CHANNEL (+)/(-)

(or number buttons on the Pronto’s
2/3 touchscreen display) to select
the channel you want to add or
delete.

Press the MENU © button to

ADD the channel into the DPTV's
memory.

Press the MENU

§ button to

DELETE the channel from
memory.

Repeat steps 2 and 3 for each
channel you wish to add or delete.

Press the “exit” (or Menu)

button to clear the screen when
through.

STOP

1

2

3

4

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

1

menu

ok

exit

Analog

SOUND

FEATURE MENU

EXIT

mute

channel

DTV

++

volume

++

DTV4/4

1

2

3

SMART


CLOSED

CAPTIONS

EXIT

CHANNEL MEMORY

ADD/DELETE
CHANNELS

START
AUTO-PROGRAMMING

EXIT

CABLE

TUNING

CHANNEL

MEMORY

MORE...

1 OF 3

4

ADD/DELETE CHANNEL

Channel 19 Added

SELECT CHANNEL
to DELETE CHANNEL
when FINISHED

M

NTSC/ANALOG FEATURE MENU CONTROLS

DISPLAY FORMAT

16

MAIN MENU

Y

our DPTV is able to deliver

the lifelike, widescreen picture
(or “home cinema” viewing
experience) that is promised with
High Definition TV programming.
The Display Format control can
be used to expand conventional
4:3 aspect ratio (width-to-height)
broadcasts in order to fit your
DPTV’s widescreen 16:9 format;
or to reset the screen to best
match the current programming.

Select DISPLAY FORMAT

control.
With FEATURES MENU (2 of 3)

on-screen, move the RED
highlight with the MENU

buttons. Then press the MENU
button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to

highlight and select (

U) the
desired screen aspect ratio or
screen display control.

Press the “exit” button to clear

the screen.

1

2

3

STOP

Panoramic - Conventional picture
is expanded to fill the full 16:9
aspect ratio screen area. Most of
the non-linear picture expansion is
performed toward the outer edges
so that correct proportions are
retained in the center of the screen.

4:3 (Standard) - Conventional TV
picture format shows on the
screen. Black bar areas show on
the side margins of the screen.

16:9 (Expand) - Full widescreen
mode with linear expansion to
view HDTV program broadcasts.
Used for material originally
produced in 16:9 format.

Theater 1/2 - Expanded zoom
modes with picture images
increased in magnification.
Designed for use with “letterbox”
or cropped movie images such as
found with Cinemascope or
Cinerama type program material.
Note: With the Theater modes
there can be some loss of
information at the edges as the
picture expands to fill the screen.

Panoramic

4:3 (Standard)

16:9 (Expand)

Theater 1 or 2

SMART HELP

Note: In the past the

relationship between a TV
screen’s width to height, or aspect
ratio, has historically been 33%
wider than the picture screen
height (or a 4:3 aspect ratio). The
widescreen format of your DPTV
screen is nearly 80% greater than
its measure height (which
accounts for a 16:9 aspect ratio).
The reason for the 16:9 aspect
ratio screen is that it allows for the
dramatic and lifelike viewing of
original version movies and
cinemas (similar to the type found
in your local theaters). And the
16:9 aspect ratio widescreen is
also a good visual match for how
our eyes work in a horizontally
oriented field of view and action
plane.

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

FEATURE MENU

DTV

CHANNEL
LABELS

PARENTAL
CONTROL

MORE...

2 OF 3

mute

channel

++

2

volume

++

DISPLAY
FORMAT

CHANNEL
DISPLAY

EXIT

2

1

menu

ok

exit

Analog

DTV4/4

1

3

Building Trade News

DISPLAY FORMAT

EXIT

Building Trade News

Building Trade News

PANORAMIC
4 X 3
16 X 9
THEATER 1
THEATER 2

Building Trade News

NTSC/ANALOG FEATURE MENU CONTROLS

SET CLOCK

17

Y

our DPTV comes with an on-

screen clock. During normal
operation the clock appears on the
screen with every channel change
(and when the STATUS button is
pressed).

Select SET CLOCK control.

With FEATURES MENU (3 of 3)
on screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the remote's number

buttons (on the Pronto’s 2/3

touchscreen display) to set the time
clock Note: Be sure to press "0"
first and then the hour number for
single digit hour or minute entries.

Press the “exit” button to set

the clock in operation and clear the
screen.

STOP

1

2

3

CHANNEL DISPLAY

W

ith the Channel Display

control you can change the
size and location of the on-screen
channel and clock information.

Select CHANNEL DISPLAY

control.
With FEATURES MENU (2 of 3)

on-screen, move the RED
highlight with the MENU

buttons. Then press the MENU
button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to

highlight and select (

U) the
LARGE or SMALL display
control.

Press the “exit” button to clear

the screen.

1

2

3

STOP

Channel Display Options

Press the Channel ▲▼ buttons and
you should see the Display Size
you selected.
Note: The SMALL SIZE display
shows only the channel number,
not the time (or clock).

The remote's MENU buttons
can also be used to set the hours,
minutes, and AM/PM portions of
the clock.
DPTV Clock settings may be lost
when the unit is unplugged (or AC
power to the set is interrupted.)

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

FEATURE MENU

DISPLAY
FORMAT

CHANNEL
DISPLAY

EXIT

CHANNEL
LABELS

PARENTAL
CONTROL

MORE...

2 OF 3

CHANNEL DISPLAY

LARGE

SMALL - CHANNEL/LABEL

EXIT

2

PBS

2

1

menu

ok

exit

Analog

DTV4/4

DTV

mute

channel

++

2

volume

++

1

3

2

PBS

10:06

BEGIN

NTSCNTSC

FEATURE MENU

SET
CLOCK

DTV

Analog

MORE...

3 OF 3

mute

channel

++

1

volume

++

DTV

2

A/CH

DTV2/3

EXIT

1

menu

3

ok

exit

Analog

DTV3/3

SET CLOCK

9 : 19 AM

PLEASE ENTER THE

CURRENT HOUR

SET CLOCK

9 : 19 AM

PLEASE USE or

TO SET AM/PM

NTSC/ANALOG FEATURE MENU CONTROLS

CHANNEL LABELS

MANUAL- To create your
own Channel Label:

Press the Channel ▲▼ or
Number buttons to select

desired station.
A red highlight shows the

active letter space for the
channel label.

Press the MENU ▲ ▼

buttons to pick any of the
letters or symbols that are
given for your use.

Press the MENU § ©

buttons to move the red
highlight to the other letter
spaces and repeat.

Press the Exit button to
clear the screen when
finished.

PRESETS -To pick a Label
from the "LABEL" list:

Press the Channel ▲▼ or
Number buttons to select

desired station.

Press the MENU ▲▼

buttons to move up and
down the Channel Label
list.

Just stop on any label you
might want to use.

The selected label
automatically appears with
channel changes and when
the STATUS button is
pressed.

Press the Exit button to
clear the screen when
finished.

18

MAIN MENU

D

o you ever have trouble

remembering on which
channel a particular station or
network is located? The Channel
Labels Control is a quick way to
view and select channels from a
list of Labeled channels.

A Label is a four letter callout you
can set to appear with the on­screen channel number. Example
Label: WXYZ - for a TV station's
call letters.

To create station labels using the
Channel Labels Control:

Select CHANNEL LABELS

control.

With the FEATURE MENU (2 of

3) on-screen, move the RED
highlight using the MENU
buttons. Then press the MENU (or
ok) button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to

highlight and select either:
"MANUAL" to create your own

label for a channel.
"PRESETS" to choose from a list

of prewritten channel labels.
(See instruction details on this

page.)

Press the “exit” button to

clear the screen.

STOP

1

2

3

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

FEATURE MENU

DTV

CHANNEL
LABELS

PARENTAL
CONTROL

MORE...

2 OF 3

mute

channel

++

2

volume

++

1

CHANNEL GUIDE LABEL

C H 1 0 C B S

or
or
when FINISHED

M

MANUAL

PRESETS

EXIT

to SELECT
to CHANGE

DISPLAY
FORMAT

CHANNEL
DISPLAY

EXIT

2

1

menu

ok

exit

Analog

DTV4/4

3

CHANNEL LABELS

Create Your Own

Choose From List

BRV

Channel 1 0

M

CBN
CBS
CNBC
CMT

CHOOSE CHANNEL

to SELECT LABEL
to EXIT

NTSC/ANALOG FEATURE MENU CONTROLS

SMART HELP

19

• Press MENU © to go on and start

to "block" channels.

• Press MENU § to go to "Content

Advisory" (or TV and Movie Ratings
system of channel blocking).

• Press MENU to return to the Parental

Control Menu screen.

• Press STATUS to clear the screen.

PARENTAL CONTROL

SETUP CODE NUMBER

P

arental Control allows parents

to block out, or "censor", any
channels they think children should
not watch. A channel placed under
Parental Control cannot be viewed
until a correct access code is used to
unlock the channel for viewing.

First let's set your Parental Code:

Select the PARENTAL

CONTROL.

With FEATURES MENU (2 of 3)
on screen, move the RED highlight
with the MENU (M) buttons.

Then press the MENU button.
"CHANNEL BLOCKING" and

"SETUP CODE" show on screen.

Press the MENU ▲▼ and

MENU (or ok) buttons

to highlight

and select the SETUP CODE item.

Press 0, 7, 1, 1 on the remote.

"

XXXX" shows on the ACCESS
CODE SETUP screen as you press
the number buttons.

"INCORRECT ACCESS CODE ­TRY AGAIN" will also show on the
screen.

Press 0, 7, 1, 1 on the remote

again.

"Next Enter Your New Access
Code" shows on the screen.

Enter a new four digit number

code using the remote.

"Access Code Changed" shows on

the screen to let you know the new
code has been set.

Continue to the next page to find
out how to "BLOCK" channels from
viewing.

1

2

3

4

5

Parents - it isn't possible

to unlock or defeat your
Censor Code without changing to
a new code number. So if your
Code number changes, and you
didn't change it yourself, then you
will know that someone has
altered the code and the blanked
out channel has been viewed.

NOTE:Your TV left the factory with the Parental Code set to "0000". If you are using your TV and
the Parental Control for the first time, and don't want to SETUP a new Access code number, you can
use the "0000" number to block channels - see next page.
The "0711" Parental Code (shown on this page) is given as a default or way to reset the Code when
the current Access number is not known. Also, once set, the same Access Code Number will apply
for the use and operation of the Parental Control system found in both the NTSC/Analog and the
ATSC/Digital Feature Menu control areas.

BEGIN

FEATURES

1ST TIME SETUP

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

exit

Analog

SOUND

EXIT

mute

channel

2

DTV

++

1

volume

ok

++

DTV3/3

Analog

DTV2/3

5

4

DTV

3

A/CH

FEATURE MENU

SMART


CLOSED

CAPTIONS

EXIT

PARENTAL CONTROL

CONTENT

ADVISORY

SETUP

CODE

EXIT

ACCESS CODE SETUP

X X X X

INCORRECT ACCESS CODE

TRY AGAIN.
See Owner's Manual If
You've Forgotten Your
Access Code.

to EXIT

M

1 OF 3

BLOCK

CHANNELS

CABLE
TUNING

CHANNEL

MEMORY

MORE...

FEATURE MENU

DISPLAY
FORMAT

CHANNEL
DISPLAY

EXIT

ACCESS CODE SETUP

First Enter Your
Current Access Code.

to EXIT

M

ACCESS CODE SETUP

Next Enter Your New
Access Code.

to EXIT

M

X X X X

X X X X

CHANNEL
LABELS

PARENTAL
CONTROL

MORE...

2 OF 3

MAIN MENU

SOUNDPICTURE

EXIT

ACCESS CODE SETUP

X X X X

Access Code Changed.

for CHANNEL BLOCKING
for CONTENT ADVISORY

to EXIT

M

NTSC/ANALOG FEATURE MENU CONTROLS

SMART HELP

BLOCKED CHANNEL SCREEN

MESSAGE
(Appears when an attempt to select a
blocked channel is made and Parental
Control is ON.)

20

PARENTAL CONTROL
CHANNEL BLOCKING

MAIN MENU

A

fter your personal Parental

Code number has been set (see
previous page), you are now ready
to select the channels you want to
block out or censor.

Select the PARENTAL

CONTROL.

With FEATURES MENU (2 of 3)
on screen, move the RED highlight
with the MENU (M) buttons.

Then press the MENU button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to
highlight and select the BLOCK
CHANNELS item.

Enter the correct Parental

Code number.

Press Channel ▲▼ or Channel

Number buttons to select the
channel you want to block.

Press the MENU © button to

"BLOCK VIEWING" on the
selected channel.
Press the MENU

§ button to

"ALLOW VIEWING" on a
blocked channel.

Repeat steps 3 and 4 for any other
channels you wish to block out.

STOP

1

2

3

4

5

Remember, to make

DPTV viewing easier all
channels will be unblocked, once
the correct Parental Code number
has been entered.
When the DPTV is turned OFF
and then back ON again, is when
Parental Control is back in place
for all blocked out channels.

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

exit

Analog

1

SOUND

EXIT

mute

channel

DTV

++

5

volume

ok

++

4

DTV

DTV3/3

3

2

A/CH

Analog

DTV2/3

FEATURE MENU

SMART


CLOSED

CAPTIONS

EXIT

PARENTAL CONTROL

CONTENT

ADVISORY

SETUP

CODE

EXIT

CHANNEL BLOCKING MEMORY

M

CHANNELS

Channel 19 blocked

CHOOSE CHANNEL

to ALLOW VIEWING

to EXIT

BLOCK

CABLE

TUNING

CHANNEL
MEMORY

MORE...

1 OF 3

FEATURE MENU

DISPLAY
FORMAT

CHANNEL
DISPLAY

EXIT

CHANNEL BLOCKING MEMORY

To Block or Un-Block
channels First Enter
your Access Code.

to EXIT

M

CHANNEL 19
CHANNEL BLOCKING ACTIVE

Please enter Access Code

-OR­Select another Channel
for viewing.

X X X X

X X X X

CHANNEL
LABELS

PARENTAL
CONTROL

MORE...

2 OF 3

NTSC/ANALOG FEATURE MENU CONTROLS

PARENTAL CONTROL

CONTENT ADVISORY

21

Note: Please remember that a valid and current Access Code number will be
required in the setup and use of the TV’s “Content Advisory” system. Review the
previous SETUP CODE section on how to obtain a valid Parental Access Code
number before attempting to make adjustments within the Movie Ratings and
Parental Guidelines system.

NOTE: In normal Content Advisory system operation
the TV screen will display a message when
programming is blocked by a Movie Rating, Parental
Guideline, or Blocking Option control feature.
Entering the correct ACCESS CODE number will
unblock all the blocked Content Advisory Rated
channels until the TV is turned Off. The blocked
Advisory Ratings will be back in place when the TV
is turned back On again.

Please enter Access Code

-OR­Select another Channel
for viewing.

CHANNEL 8
BLOCKED BY CONTENT ADVISORY
TV GUIDELINES TV-14 D

X X X X

A

nother new area available to

parents for the censoring of
program material is through the
TV Guidelines and Movie Ratings
system. Program Content Advisory
data will soon be contained within
the broadcast signals of received
TV programs. When setup by the
parent or viewer, the TV can
respond to transmitted advisory
data by blocking out or denying
access to TV shows (based on
whether the program meets or
exceeds the limitations you select
as viewable). The TV program can
then only be viewed by entering the
correct and current Parental Code
Access number.

The Content Advisory system uses
both “Movie Ratings” and a
“Parental Guidelines” form of
censoring. Refer to the following
page sections for explanations on
the different Rating system levels
and their uses.

Select the CONTENT

ADVISORY Menu option

With PARENTAL CONTROL
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

A Parental Guideline/Movie Rating
status screen will appear with a
review of currently BLOCKED
Content Advisory categories.

Press the MENU © button to

select the ENTER ACCESS

CODE Menu item.

Enter the correct Parental

Code number (see note at the top

of this page).
“CONTENT ADVISORY” Menu

screen appears. Parental
Guidelines, Movie Ratings and
other blocking control items are
ready for selection and use.

STOP

BEGIN

1

2

3

to EXIT

X X X X

DISABLED
MOVIE

RATINGS
BLOCKED
PG
PG-13
R
NC-17
X

MOVIE

RATINGS

BLOCKING

OPTIONS

PARENTAL CONTROL

CONTENT

ADVISORY

SETUP

CODE

EXIT

1

menu

ok

exit

Analog

1

CHANNELS

DTV

DTV3/3

BLOCK

2

Analog

mute

channel

volume

++

++

DTV

3

A/CH

DTV2/3

CONTENT ADVISORY
TV PARENTAL

GUIDELINES
BLOCKED
TV-Y
TV-Y7 FV
TV-G
TV-PG DLSV
TV-14 DLSV
TV-MA LSV

to ENTER ACCESS CODE

M

CONTENT ADVISORY ACCESS

To Block or Un-Block
Programs, First Enter
your Access Code.

to EXIT

M

CONTENT ADVISORY

PARENTAL

GUIDELINES

REVIEW

SETTINGS

EXIT

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSC/ANALOG FEATURE MENU CONTROLS

22

CONTENT ADVISORY

MOVIE RATINGS

• G - General Audience: Most parents would find this

program suitable for all ages. This type of programming
contains little or no violence, no strong language, and
little or no sexual dialogue or situations.

• PG - Parental Guidance:

This programming contains
material that parents may find unsuitable for younger
children. It may contain one or more of the following:
Moderate violence, some sexual situations, infrequent
coarse language, or some suggestive dialogue.

• PG-13:

This programming contains material that parents
may find unsuitable for children under the age of 13. It
contains one or more of the following: violence, sexual
situations, coarse language, or suggestive dialogue.

• R - Restricted:

This programming is specifically
designed for adults. Anyone under the age of 17 should
only view this programming with an accompanying parent
or adult guardian. It contains one or more of the following:
intense violence, intense sexual situations, strong coarse
language, or intensely suggestive dialogue.

• NC-17 - No one under 17 admitted:

This type of pro­gramming should be viewed by adults only. It contains
graphic violence, explicit sex, or crude indecent language.

• X - Mature audience only:

This type of programming
contains one or more of the following: very graphic
violence, very graphic and explicit or indecent sexual acts,
very coarse and intensely suggestive language.

SMART HELP

MAIN MENU

Note: When a Movie

Rating is selected (

U) all
higher level ratings are
automatically blocked (although
each individual Movie Rating can
be manually selected and turned
On or Off as desired). Programs
with lower than the selected rating
level are allowed for viewing or
unblocked.

M

ovie Ratings set viewing

access levels for TV
programming according to current
Motion Picture Association of
America (MPAA) ratings. These
ratings are similar to the
categories used with the rated
movies appearing in cinema
theaters and with video rental
material.

Select the MOVIE RATINGS

Menu option.
With CONTENT ADVISORY

Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to

highlight and select (

U) the
desired MOVIE BLOCKING
level.

When in operation a “Blocked ­Movie Rating” TV screen appears
when movies are received which
include the same selected rating as
the Movie Blocking setting(s).
Only the correct Access Code
number, entered by the viewer,
will unblock or allow the viewing
of a block rated program.

STOP

BEGIN

1

2

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

CONTENT ADVISORY

PARENTAL

GUIDELINES

REVIEW

SETTINGS

EXIT

MOVIE

RATINGS

BLOCKING

OPTIONS

2

1

menu

ok

DTV

1

mute

channel

volume

2

++

++

exit

Analog

DTV3/3

MOVIE BLOCKING

G
PG
PG-13
R
NC-17
X

EXIT

NTSC/ANALOG FEATURE MENU CONTROLS

23

CONTENT ADVISORY

PARENTAL GUIDELINES

• TV-Y - Appropriate for all children:

Designed for a
very young audience, including children ages 2-6. This type of
programming is not expected to frighten younger children.

• TV-Y7 -Appropriate for children seven and older:

It
may be more appropriate for children who have acquired the
development skills needed to distinguish between make-believe
and reality. This programming may include mild fantasy and
comic violence (FV).

• TV-G - General Audience:

This type of programming
contains little or no violence, no strong language, and little or
no sexual dialogue or situations.

• TV-PG - Parental Guidance suggested:

This type of
programming contains one or more of the following: Moderate
violence (V), some sexual situations (S), infrequent coarse
language (L), or some suggestive dialogue (D).

• TV-14 - Unsuitable for children under 14:

This type of
programming contains one or more of the following: intense
violence (V), intense sexual situations (S), strong coarse
language (L), or intensely suggestive dialogue (D).

• TV-MA - Mature audience only:

This type of
programming contains one or more of the following: graphic
violence (V), explicit sexual situations (S), or crude indecent
language (L).

• (V) - Violence

• (S) - Sexual situations

• (L) - Language

• (D) - Inappropriate dialogue

• (FV) - Fantasy Violence may frighten children under

seven. Some cartoons may have this rating. Available in
the TV-Y7 category only.

SMART HELP

P

arental Guidelines can be

even more defined and specific
in the degree and extent of
material parents may allow for TV
program viewing. Sub-settings for
Language, Violence, and other
blocking factors can be manually
switched On or Off for use within
the major Parental Guideline
categories (TV-Y7, TV-PG, etc.).

Select the PARENTAL

GUIDELINES Menu option.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

Press the MENU § © to

highlight and select the desired
PARENTAL GUIDELINE rating
level (TV-Y, TV-Y7, etc.).

Press the MENU ▲▼ and

MENU (or ok) buttons

to Block

(

U) the selected Parental
Guideline category (or to set other
individual blocking feature items
available within that Guideline
category (L, V. S, D, etc.) as
desired).

Note: Selecting “ALWAYS
BLOCKED” (or individually
adjusting the L, V, S, D settings)
for any one rating will set all other
higher level ratings to be
automatically blocked as well.

STOP

BEGIN

1

2

3

The TV-Y7; TV-PG;

TV-14; and TV-MA
guidelines also include
customized settings for various
additional items such as V
(violence), S (sexual situations), L
(coarse language), D (suggestive
dialogue), and FV (fantasy
violence). These additional
settings are category specific and
can be individually selected for
use as desired.

CONTENT ADVISORY

PARENTAL

GUIDELINES

REVIEW

SETTINGS

MOVIE

RATINGS

BLOCKING

OPTIONS

PARENTAL GUIDELINES

To Select Rating

TVY7TV GTVPGTV14TV

TV
Y

To Select Blocking

NOT BLOCKED
ALWAYS BLOCKED
(FV) FANTASY VIOLENCE

MA

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

EXIT

3

1

menu

ok

DTV

mute

channel

++

2

volume

++

exit

Analog

1

3

DTV3/3

EXIT

PARENTAL GUIDELINES

To Select Rating

TVY7TV GTVPGTV14TV

TV
Y

To Select Blocking
NOT BLOCKED
ALWAYS BLOCKED
(L) LANGUAGE
(V) VIOLENCE
(S) SEXUAL CONTENT
(D) SUGGESTIVE DIALOG

EXIT

MA

NTSC/ANALOG FEATURE MENU CONTROLS

24

CONTENT ADVISORY

REVIEW SETTINGS

CONTENT ADVISORY

BLOCKING OPTIONS

Note: Remember that Content Advisory data or encoded
information is not available with all received TV
programming (this also includes commercials, and other
program spot announcements). Broadcaster’s can decide
not to encode any kind of content advisory ratings with
their programming, or they can actually choose to encode
programs to be “unrated.”
The TV Blocking Options allow the viewer to block any
program without content advisory data with the use of its
“NO RATING INFORMATION” control. And to block
programs that are encoded as “unrated” with its
“UNRATED PROGRAMMING” control option.

Since the reception of Content Advisory data can take a
few seconds, you may want to use the “CHANNEL
CHANGE” option to be sure no viewing is allowed during
blocked program channel changes. This can eliminate the
display of a few seconds of undesirable video on the TV,
or receiving scenes from a Ratings blocked channel
source.

MAIN MENU

T

he Content Advisory system

also has “Blocking
Option”controls which can be
used to deny viewing access for
channel programs and movies
even when they are “unrated”, or
contain “no rating” information
as broadcasted.

Select the BLOCKING

OPTIONS Menu control.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU
(M) button.

Press the MENU ▲▼ and

MENU (M) buttons

to turn the
Blocking System On (highlight
and select

U ENABLED). Then
use the remote Menu buttons to
select the desired programming
and information blocking options.

Please refer to Note shown with
this page section for details on
“unrated” and “no rating” program
control options.

STOP

BEGIN

1

2

U

se the Review Settings control

to quickly check the status for
Content Advisory system Parental
Guidelines and Movie Rating
“Blocked” program levels.

Select the REVIEW

SETTINGS Menu option.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

The TV screen will display the
current Parental Guideline and
Movie Ratings Blocked program
settings. Content Advisory system
status will also be shown (Enabled

-On, or Disabled - Off).

STOP

BEGIN

1

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

CONTENT ADVISORY

PARENTAL

GUIDELINES

REVIEW

SETTINGS

EXIT

MOVIE

RATINGS

BLOCKING

OPTIONS

2

1

menu

ok

exit

Analog

DTV3/3

DTV

mute

channel

++

1

volume

++

2

BLOCKING OPTIONS

Blocking System:

DISABLED
ENABLED

Set To Block On:

CHANNEL CHANGE
UNRATED PROGRAMMING
NO RATING INFORMATION

EXIT

1

CONTENT ADVISORY

PARENTAL

GUIDELINES

REVIEW

SETTINGS

EXIT

menu

ok

exit

Analog

MOVIE

RATINGS

BLOCKING

OPTIONS

mute

channel

DTV

++

1

volume

++

DTV3/3

CONTENT ADVISORY
TV PARENTAL

GUIDELINES
BLOCKED
TV-Y
TV-Y7 FV
TV-G
TV-PG DLSV
TV-14 DLSV
TV-MA LSV

ENABLED
MOVIE

RATINGS
BLOCKED
PG
PG-13
R
NC-17
X

M

to EXIT

NTSC/ANALOG SOUND MENU CONTROLS

BASS, TREBLE, BALANCE

Select and then press MENU
(or ok) button to view
additional controls grouped
under same feature heading.
For Example: Treble,
Balance, Stereo, etc.

25

Y

our DPTV also has individual

sound adjustment controls. The
BASS (low frequency), TREBLE
(high frequency) , and Speaker
BALANCE may all be used to
adjust the sound playback of NTSC
TV programs.

Select BASS, or TREBLE, or

BALANCE sound control.

With the SOUND MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the MENU § © arrow

buttons to adjust the sound control

to levels you prefer.

Press the “exit” button to clear

the screen.

1

2

3

STOP

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

1

menu

ok

exit

Analog

3

SOUND

SOUND MENU

EXIT

mute

channel

DTV

++

volume

++

DTV3/3

1

2

BASS TREBLE

BALANCE

DISPLAY VOLUME

EXIT

BASS

MIN

EXIT

STEREO

AVL

MORE...

1 OF 2

NEXT...

MAX

SECOND AUDIO PROGRAM

NTSC/ANALOG SOUND MENU CONTROLS

STEREO

NTSCNTSC

t

o

d

a

y

'

s

a

n

d

f

o

r

n

e

w

s

a

n

d

t

o

d

a

y

'

s

a

n

d

f

o

r

n

e

w

s

a

n

d

SECOND AUDIO PROGRAM

EXIT

NORMAL SOUND

SECOND PROGRAM SOUND

SOUND MENU

EXIT

2 OF 2

SECOND AUDIO PROGRAM

MORE...

SECOND PROGRAM SOUND CAN ONLY BE
SELECTED (

U) WHEN SAP INFORMATION

IS PRESENT ON THE CURRENT CHANNEL.

SMART

HELP

26

MAIN MENU

Y

our DPTV is able to receive

broadcast stereo TV programs.
The DPTV is equipped with an
internal amplifier and speaker
system through which the stereo
sound can be heard.

Select STEREO sound control.

With the SOUND MENU on­screen, move the RED highlight
with the MENU buttons. Then

press the MENU button.

Press the MENU ▲▼ and

MENU (M) buttons

to highlight

and turn ON (

U) the STEREO

mode.

Press the “exit” button to clear

the screen.

STOP

1

2

3

Second Audio Program (SAP)

is part of the stereo broadcast
system. Sent as a additional
audio channel SAP can be heard
apart from the current TV
program sound. TV stations are
free to use SAP for any number
of purposes, but many experts
believe it will be used for foreign
language translations of TV
shows (or for weather and news
bulletins.)

NOTE: If a SAP signal is not
present with a selected program,
the SAP option can not be
selected. "This program does not
contain SAP information" will
show on the DPTV screen.

Remember.
If a stereo signal is
not available and
the DPTV is placed
in STEREO, the
sound coming from
the unit will remain
monaural (mono).

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

1

menu

ok

DTV

1

SOUND

EXIT

mute

channel

++

volume

++

SOUND MENU

BASS TREBLE

BALANCE

DISPLAY VOLUME

EXIT

STEREO

STEREO

AVL

MORE...

1 OF 2

MONO AT ALL TIMES

STEREO IF AVAILABLE

exit

Analog

DTV3/3

2

EXIT

NEXT...

3

NTSC/ANALOG SOUND MENU CONTROLS

DISPLAY VOLUME

27

U

se the DISPLAY VOLUME

control to see program
volume level settings on the DPTV
screen. Once set, the Volume
Display will be seen each time the
VOLUME buttons (on the DPTV
local keyboard or Pronto remote)
are pressed.

Select DISPLAY VOLUME

control.
With SOUND MENU on-screen,

move the RED highlight with the
MENU buttons. Then press the

MENU button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to

highlight and turn ON (

U) the

DISPLAY VOLUME control.

Press the “exit” button to clear

the screen.

1

2

3

STOP

BEGIN

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

1

menu

ok

DTV

SOUND

channel

1

volume

EXIT

mute

++

++

SOUND MENU

BASS TREBLE

BALANCE

DISPLAY VOLUME

EXIT

DISPLAY VOLUME

NEVER

DURING ADJUSTMENT

EXIT

STEREO

AVL

MORE...

1 OF 2

NEXT...

exit

Analog

DTV3/3

2

3

AUTOMATIC VOLUME

LIMITER

SMART HELP

NTSC ANALOG SOUND MENU CONTROLS

28

MAIN MENU

A

re you tired of the sound of
commercials following you

into the next room or all through
the house? The Automatic Volume
Limiter (AVL) control allows you
to preset a desired volume level
that the DPTV sound will not go
above. This makes for an even,
more consistent sound by reducing
the “peaks” and “valleys” that can
occur during program changes or
commercial breaks.

Select AVL (Automatic Volume

Limiter) control.
With SOUND MENU on-screen,

move the RED highlight with the
MENU buttons. Then press the

MENU button.

Press the MENU ▲ or ▼ and

then the MENU (or ok) button to
turn the AVL control ON (or OFF).

Press the “exit” button to clear

the screen when completed.

STOP

1

2

3

Remember, AVL works

for sound levels coming
from either the Antenna/Cable
input on the rear of the DPTV (RF
audio) or the Auxiliary (AUX IN)
audio inputs.

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

NTSCNTSC

ANALOG MAIN MENU


FEATURES

1ST TIME SETUP

2

1

menu

ok

exit

Analog

DTV3/3

DTV

2

SOUND

channel

1

volume

SOUND MENU

BASS TREBLE

EXIT

mute

++

++

BALANCE

DISPLAY VOLUME

EXIT

AVL

ON

OFF

EXIT

STEREO

AVL

MORE...

1 OF 2

NEXT...

3

PRONTO REMOTE NTSC/ANALOG FEATURES

PRONTO - ANALOG TV MODE

29

scroll arrows

Press to move to the next (or previous) page of Pronto
controls. The touchscreen will display the current
control screen’s page number, and the total number of
pages available for the selected device (1/3; 2/3; etc.)

SMART HELP

menu buttons

Press the Menu (or ok) button to
show on-screen controls. Press M
▲ or ▼ buttons to move up (or

down), the M

§ or © to move
left (or right) through the list of
controls.

volume buttons

Press to adjust the DPTV sound level up (+) and down (-).

channel scan buttons

Press to scan up (+) or down (-) through any NTSC programmed
channel numbers.

power button

Press to turn the DPTV ON and OFF.

sleep button

Press to set the DPTV to
automatically turn itself OFF.
(15 minutes to 2 hours ahead.)

number buttons

Press the number buttons to select DPTV channels. Press
two number buttons to select single digit “major” channel
numbers. For example: press "0" then "6" for channel 6.

exit button

Press to clear the DPTV screen after control
adjustments. Also press to see the current channel
number on the DPTV screen.

A/CH button

Press Alternate Channel (A/CH) to select previously
viewed channels. Enter the desired two channel numbers
(from the Pronto remote’s number buttons), and then
press A/CH to toggle back and forth between the two
channel selections.

ext input button

Press to quickly select NTSC auxiliary input modes
(AUX1/2/3), as well as cycle through the DPTV’s other
input option modes (Monitor VGA, EXT HD, etc.).

mute button

Press to turn the sound OFF on the DPTV. Press again to return
the sound to its previous level.

status button

Press to see the current channel number on the DPTV screen.
Also press to clear the DPTV screen after control adjustments.

T

he Pronto remote contains

three display screens of
“Analog TV” related controls. Use
the touchscreen controls to access
and adjust NTSC features for Input
selection and Menu feature
adjustments.
Note: For battery installation and
other details on the initial use of
the Pronto remote control also
refer to the 64PH9905 Quick Use
guide included with your DPTV.

Gently tap the Pronto

touchscreen with your finger to

display its control panel for use.
Be sure “DTV” is selected for the

current device tab item category.

Press the “Analog” command
button (on the lower left of
Pronto remote case) to ensure

NTSC mode commands are sent
from the remote.

1

2

STOP

Due to the amount of

optional component and

feature uses available with the

Pronto’s Device Reference and
Learn Code lists, please also refer
to the separate full-use Pronto
Owner’s Manual for complete
details on its function and
operations.

alternate audio

Primarily used for “alt audio” ATSC mode
feature, this button can also be used to
quickly select the NTSC Second Audio

Program (SAP) feature (when available).

analog format button

Press to select one of the TV screen display format modes
(i.e. Panoramic, 4:3, 16:9, etc.).

Analog

Command

Button

BEGIN

mute

channel

power

alt audio

sleep

analog format

Analog

DTV

status

freeze

ext input

DTV1/3

volume

++

++

Analog

DTV

A/CH

DTV2/3

DTV

menu

exit

Analog

ok

DTV3/3

AUDIO/VIDEO NTSC ANALOG CONNECTIONS

ANALOG

TV ANT/CABLE

AUX 1 AUX 2

S-VIDEO

ANALOG

AUDIO OUT

AUDIO INPUT

AUX 1 AUX 2

VIDEO OUT

VIDEO INPUT

L

R

L

R

NTSCNTSC

++

++

mute

volume

channel

ANTENNA

OUT

IN

OUT

IN

AUDIO

R

L

VIDEO

IN

OUT

1

2

AUX 1AUX 1

4

power

DTV

Analog

DTV1/3

sleep

alt audio

status

ext input

freeze

analog format

3

AUX1/2 INPUTS

REAR OF DPTV

VIDEO IN

(YELLOW)

AUDIO IN

(RED/WHITE)

If you have a single (monaural)
Audio Output VCR, "Y" connectors
are available to complete your
connection. Contact your dealer, or
our Parts Information Center (1­800-292-6066) to order any optional
accessories.

VCR

PICTURE AND SOUND FROM

PLAYBACK OF VCR TAPE

SMART HELP

AUDIO/VIDEO

OUTPUT JACKS

ON VCR

30

T

he Analog Audio/Video Input

jacks are for direct NTSC
picture and sound connections
between the DPTV and auxiliary
equipment (VCR, DVD Player,
etc.) that has Audio/Video Output
jacks.
To view the playback of a VCR
tape by using the Analog AUX1
Audio/Video Input jacks:

Connect the VIDEO OUT jack

from the VCR to the AUX 1
VIDEO IN jack on the DPTV.

Connect the AUDIO OUT

jacks R(ight) and L(eft) from the
VCR to the AUX 1 AUDIO IN
jacks on the DPTV.

Press the “ext input” button

on the Pronto (or the Source button
on the DPTV’s local keyboard) to
select the AUX 1 Audio/Video
Inputs on the rear of the DPTV.

Turn the VCR ON and press

PLAY to view the tape playback
on the DPTV.

1

2

3

4

STOP

Remember, connections

and use of the DPTV's
AUX 2 Audio/Video Input jacks
are the same as for the AUX 1
jacks (except "AUX 2" is selected
as the Input Source in step 3).

BEGIN

AUDIO/VIDEO NTSC ANALOG CONNECTIONS

SOURCE

EXIT

UP
CH

CH
DOWN

+
VOL

VOL
–

M

4

NTSCNTSC

++

++

mute

volume

channel

AUX 3AUX 3

AUX3

VIDEO IN

L

AUDIO IN

R

2

1

power

DTV

Analog

DTV1/3

sleep

alt audio

status

ext input

freeze

analog format

3

AUX 3 INPUTS

FRONT AUDIO/VIDEO JACKS

AUX3 Inputs located on right

front side panel of DPTV.

VIDEO IN

(YELLOW)

AUDIO IN

(RED/WHITE)

If you have a single (monaural) Audio Output
Camcorder, "Y" connectors are available to complete
your connection. Contact your dealer, or our Parts
Information Center (1-800-292-6066) to order any
optional accessories.

CAMCORDER

PICTURE AND SOUND FROM PLAYBACK OF

CAMCORDER TAPE

AUDIO/VIDEO

OUTPUT JACKS

ON CAMCORDER

31

F

or more convenient Direct

playback connections use the
DPTV's Front Audio/Video Input
panel (located on the DPTV's right
front side panel). These Inputs
allow for quick and easy access,
particularly for the playback of
Camcorder tape recordings.

Connect the VIDEO OUT jack

from the Camcorder to the AUX3
VIDEO IN jack on the DPTV.

Connect the AUDIO OUT

jacks R(ight) and L(eft) from the
Camcorder to the AUX3 AUDIO
IN jacks on the DPTV.

Press the “ext input” button

on the Pronto (or the Source button
on the DPTV’s local keyboard) to
select the AUX3 Audio/Video
Inputs on the DPTV.

Turn the Camcorder ON and

press PLAY to view the tape on
the DPTV.

1

2

3

4

STOP

AUDIO/VIDEO OUTPUTS

REAR OF DPTV

VIDEO OUT

(YELLOW)

VCR

PICTURE AND SOUND BEING RECORDED ON VCR

AUDIO/VIDEO INPUT

JACKS ON VCR

AUDIO

OUT

(RED/

WHITE)

T

he Audio/Video Output jacks

on the DPTV can be used to
record TV programs on VCRs
which have Audio/Video Input
jacks. To use the Audio/Video
Outputs for program recording:

Connect the VIDEO OUT jack

from the DPTV to the VIDEO IN

jack on the VCR.

Connect the AUDIO OUT

jacks R(ight) and L(eft) from the
DPTV to the AUDIO IN jacks on
the VCR.

Press the “Analog” command

button on the Pronto (or the

Source button on the DPTV’s local
keyboard) to place the DPTV in
the NTSC mode.
Select the channel on the DPTV
that you want to record.

Turn the VCR ON. Put a

cassette tape in the unit and place
the VCR in the RECORD mode.

STOP

1

2

3

4

Remember, if the VCR has an INPUT SELECTOR
switch, place it in the LINE or CAMERA position.
Note: Unattended Timer Recordings with a VCR are
possible, but not recommended with this connection
since the DPTV must be left ON for the VCR to record.

BEGIN

BEGIN

NTSCNTSC

analog format

Analog

status

freeze

ext input

DTV1/3

mute

channel

DTV

++

volume

++

3

power

alt audio

sleep

1

ANALOG

AUDIO INPUT

AUDIO OUT

ANALOG

TV ANT/CABLE

AUX 1 AUX 2

S-VIDEO

L

R

VIDEO OUT

AUX 1 AUX 2

VIDEO INPUT

L

R

OUT

ANTENNA

OUT

VIDEO

IN

IN

4

2

OUT

L

R

AUDIO

IN

AUDIO/VIDEO NTSC ANALOG CONNECTIONS

AUX1 - S-VIDEO INPUTS

S-VHS VCR

AUDIO OUT

(RED/WHITE)

S-VIDEO OUT

REAR OF DPTV

PICTURE AND SOUND FROM PLAYBACK OF S-

VHS VCR TAPE PLAYBACK

S-VIDEO

CABLE

NOTE: A CD-i (Compact Disc Interactive)
player, Video Game, or other S-VIDEO
accessory can be hooked up to the DPTV
using this type of connection. Please be aware
that such video sources, which show a
constant non-moving pattern on the DPTV
screen, can cause picture tube damage. When
not in use turn your video accessories OFF.
Also, regularly alternate the use of video
sources with normal TV program viewing.

32

SMART HELP

T

he S(uper)-Video connections

on the rear of the DPTV offer
improved picture detail and clarity
for the playback of S-VHS VCR
tapes or DVDs over a standard
composite video input connection.

Note: The VCR (or DVD Player)
must have a S-VIDEO OUT(put)
jack in order for you to complete the
connections shown on this page.

Connect the S-VIDEO (S-

VHS) OUT jack from the VCR to

the AUX1 S-VIDEO input plug on
the DPTV.

The S-VIDEO connecting cable
will be supplied with the S-VHS
VCR (or DVD Player).

Connect the AUDIO OUT

jacks R(ight) and L(eft) from the
S-VIDEO VCR to the AUX1
AUDIO input jacks on the DPTV.

Press the “ext input” button

on the Pronto (or the Source button
on the DPTV’s local keyboard) to
select the S VIDEO input on the
DPTV.

Note: The "S VIDEO" picture
source option appears only when a
S-VIDEO cable has been connected
to the DPTV.

Turn the VCR ON and place it

in the S-VIDEO (or S-VHS)
playback mode. Insert S-VHS
cassette tape and playback in a
normal manner.

STOP

1

2

3

4

Remember, connections

and use of the DPTV's S­VIDEO AUX2 Input plug is the
same as for the S-VIDEO AUX1
input (except "S-VIDEO 2" is
selected as the Picture Source in
step 3).

BEGIN

S VIDEOS VIDEO

power

alt audio

sleep

Analog

status

freeze

ext input

analog format

DTV1/3

DTV

mute

channel

volume

NTSCNTSC

++

++

3

ANALOG

AUX 1 AUX 2

4

ANALOG

AUDIO INPUT

AUDIO OUT

1

TV ANT/CABLE

S-VIDEO

OUT

S-VIDEO

ANTENNA

L

R

VIDEO OUT

OUT

IN

AUX 1 AUX 2

VIDEO INPUT

OUT

VIDEO

IN

L

R

OUT

R

AUDIO

IN

2

L

33

AUDIO/VIDEO DVD (COMPONENT INPUT) CONNECTIONS

DVD

VIDEO INPUT

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

R

L

C

RS LS

SW

AUDIO INPUT

FOR DVD,VGA,

OR HD

COMPONENTS

VIDEO S-VIDEO Pb Y Pr

++

++

mute

volume

channel

DVDDVD

1

2

power

DTV

Analog

DTV1/3

sleep

alt audio

status

ext input

freeze

analog format

3

OUT

AUDIO

R

L

S-VIDEO

OUT

VIDEO OUT

Y

P

P

B

R

VIDEO 1

VIDEO 2

OUT

4

COMPONENT VIDEO INPUTS

COMPONENT

VIDEO OUTPUTS

AUDIO OUT (L/R)

(RED/WHITE)

Note: The DPTV is equipped for three
different types of DVD Player Video Input
connections (Component, S-Video, or
Composite Video). Check the manual for
your brand DVD to determine the best
possible video connection for your system.

Optional Video/Audio Cables (with standard
RCA plug connectors) are available to
complete your Component Input Jack
connections. Contact your dealer, or our Parts
Information Center (1-800-851-8885) to order
any optional accessories.

DVD PLAYER

(equipped with Component Color

& Luminance Outputs)

PICTURE AND SOUND FROM PLAYBACK OF

DVD SOURCE MATERIAL

REAR OF DPTV

C

omponent Video Inputs

provide for the highest
possible color and picture
resolution in the playback of
digital signal source material such
as with DVD players. The color
difference signals (PB, PR) and the
luminance (Y) signal are
connected and received separately
which permits for improved color
bandwidth information (not
possible when using composite
video or S-Video connections).

Connect the Component (Y PB

PR) VIDEO OUT jacks from the

DVD player to the (Y PB PR)
VIDEO IN(puts) on the DPTV.

Connect the AUDIO OUT

jacks R(ight) and L(eft) from the
DVD player to the STEREO IN
AUDIO IN jacks on the DPTV.

Select "DVD" as the picture

source mode for the DPTV.
Press the “ext input” button on

the Pronto (or the Source button on
the DPTV’s local keyboard) to
select the DVD input for use on the
DPTV.

Turn the DVD player ON and

press PLAY to view the source
material playback on the DPTV.

1

2

3

4

STOP

SMART HELP

The description for the

component video connectors
may differ depending on the DVD
player or accessory digital source
equipment used (e.g. Y PB PR; R­Y/B-Y/Y; Cr/Cb/Y, etc.).
Although abbreviations and terms
may vary, the letters “B” and “R”
stand for the blue and red color
component signal connectors and
“Y” indicates the luminance
signal. Refer to your DVD or
digital accessory Owner’s Manual
for definitions and connection
details.

DVD MODE - MENU FUNCTIONS

• Note: A variety of Picture,
Sound, and Input adjustment
Menu controls are available for

use within the DVD Input Source
mode. These control feature items
can assist in the setup of optimum
format and viewing levels when
using the DPTV with an external
accessory DVD player.
Just press the Menu (or ok) button
on the Pronto remote when in the
DVD Source mode to display the
list of on screen controls. Then
use the Menu buttons to adjust
the individual controls as desired.

SOUND
FEATURE
EXIT

MAIN MENU

BRIGHTNESS

SHARPNESS
COLOR
TINT
VID ENHANCE
CONVERGENCE
BACK

PICTURE MENU

AUDIO INPUT STEREO BACK
VOLUME BAR ON

BASS
TREBLE
BALANCE
BACK

SOUND MENU

DISPLAY FORMAT 16:9
DVD NPUT Y PB PR
BACK

FEATURE MENU

(OR ADJUST TRIM*)

(OR 6 - CHANNEL*)

BEGIN

SYSTEM AUDIO OUTPUT CONNECTIONS

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

R

L

C

RS LS

SW

AUDIO INPUT

PHONO INPUT

L

R

DTV ANTENNA

DTV DIGITAL

AUDIO OUT

ANALOG

TV ANT/CABLE

AUX 1 AUX 2

S-VIDEO

ANALOG

AUDIO OUT

AUDIO INPUT

AUX 1 AUX 2

VIDEO OUT

VIDEO INPUT

L

R

L

R

IR BLASTER

TV

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL
AUDIO IN

R

L

C

RS LS

SW

VGA IN

75 ohm

HIGH

SYNC

H/H + V

V

R/Pr

G/Y

B/Pb

HD COMPONENT

VIDEO IN

INTERNAL TV SPEAKERS

USED AS CENTER
CHANNEL

CENTER
CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT
SPEAKERS

EXT INT

SUBWOOFER
SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

AUDIO INPUT

FOR DVD,VGA,

OR HD

COMPONENTS

34

SYSTEM AUDIO OUTPUTS

REAR OF DPTV

T

he DPTV's System Audio

Output jacks can be used for
sound playback through an
external audio amplifier or Dolby
Pro Logic receiver.

Connect the R(ight) and L(eft)

SYSTEM AUDIO OUT jacks on

the DPTV to the R and L Audio
Input jacks on your amplifier or
sound system.

Turn DPTV ON and place the

external amplifier system to the
AUX INPUT mode (if applicable).

Note: Dependent upon the audio
information received the DPTV
outputs a straight two channel
Left/Right stereo audio signal for
output.

STOP

1

2

AUDIO SYSTEM (or Dolby Pro Logic Receiver )

SPEAKERS USED FOR PLAYBACK SOUND

AUDIO INPUT JACKS

SMART HELP

Note: To eliminate

sound playback through the
DPTV cabinet speakers when using
an external amplifier audio
connection you can either:

-Press the MUTE button on the

Pronto remote to eliminate sound
through the DPTV speakers

OR

-Place the FRONT SPEAKERS

switch on the rear of the DPTV
to the EXT(ernal) position,
which will also eliminate the
use of the Front External
Speaker Out connection
terminals on the DPTV.
Note: Using the Front Speakers
switch alone does not shut off all
the DPTV speakers, when they
are used as a Center Channel or
Surround sound playback source.
In such cases, you may also need
to reset additional speaker
switches on the rear of the DPTV
to completely shut the sound off
from the DPTV cabinet speakers.
See the “Internal TV Speakers
Used as Center Channel” and
“Center Channel Input Switch”
section on page 40 for details.

The System Audio Out(put) jacks send the DPTV’s current audio
(ATSC, NTSC, or Monitor) to an external amplifier for output. The
advantage of such an additional System Audio Out connection (as
shown in this diagram) is that it could continue to route the supplied
audio signals from the DPTV to an external amplifier or Pro Logic
Receiver (even when the selected program source switches between a
digital ATSC program, NTSC, or Monitor supplied source). In the case
of digital multichannel audio the DPTV downmixes the audio output to a
straight 2-channel stereo signal.

Note: For best audio reproduction and playback of Dolby Digital
surround sound through a Pro Logic Receiver (when using the
System Audio Out jacks):

• place the REAR SPEAKER DELAY control (located in the DPTV’s

ATSC Speakers Menu) to the maximum “15 feet or more” setting

• place the Center Channel Delay control (located in the DPTV’s

ATSC Speakers Menu) to the “Back 2 feet” position

BEGIN

ATSC/DIGITAL ON-SCREEN MENU FEATURES

DTV Setup Complete

Auto Program

Autoprogramming in progress.
This may take several minutes.

Cancel

Installing

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

++

++

mute

volume

channel

ok

exit

menu

DTV

Analog

DTV4/4

1

2

3

Would you like to program DTV channels?

This process may take several minutes.

Yes, full installation

No

Yes, add new channels

DTV Setup

1

2

DTV SETUP (AUTOPROGRAM)

SMART HELP

35

Press the Pronto remote’s “DTV” Command mode
button (or the “Source” button on the DPTV’s local
keyboard) to select the ATSC operating mode.

• Note: Standards were devised as part of the ATSC

system to allow TV stations to transmit Program

Service Information Protocol (or PSIP) for DTV
channels. This information system enables
stations to broadcast various electronic on-screen
program guides (in order to inform digital TV
viewers of station channel locations and availability
of programs); as well as allowing for the reception of
signal coding necessary for digital audio processing
and Parental Content Advisory system for movies
and TV programming .

Program and System Information (PSIP)

O

nce connected to receive

digital ATSC broadcast
signals, available area channels
can be added into the DPTV’s
channel scan memory by the use of
the DTV Setup Menu.

Note: Refer to the 64PH9905
Quick Use guide for additional
information on digital channel
programming and direct ATSC
channel selections or access.

Select DTV Setup control.

With the DTV Main Menu on­screen, move the highlight with the
MENU ▲▼ buttons. Then press

the MENU (or ok) button.

Press the MENU ▲▼ buttons

to select the Full Installation
option, then press the Menu button.

The DPTV shows an Installing
indicator bar on screen as the
digital channels are added into
scan memory.

"DTV Setup Complete" shows
when the DPTV is through adding
digital channels into memory.

Press the “exit” (or Menu)

button to clear the screen.

1

2

3

Note: With the “full

installation” Auto Program
option the DPTV rewrites its entire
digital channel scan “map”
currently held in memory.
The “add new channels” Auto
Program option allows you to retain
the current DPTV channel scan
memory map, and include only the
new digital channel stations as they
become available for selection.

STOP

DTV

Command

Button

TUNING PROGRAM/CHANNEL MENU

• The DPTV’s “Tuning - Program
or Channel” Menu control allows

you to switch between either tuning
to a specific physical channel (direct
tune); or using the DTV Setup list of
programmed channels (or the
“installed” channel map) without
the loss of previously stored
PSIP channel encoded information
(see explanation given above).
If, for instance, a new program is
located during the use of the direct
access “Tuning - Channel” search
mode of operation, the viewer could
easily add the new channel number
into the memory code list of the
DPTV by the use of the “Add/Delete
Channels” control found under the
FEATURES MENU option.

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

Channel

OR

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

BEGIN

ATSC/DIGITAL PICTURE MENU CONTROLS

COLOR, BRIGHTNESS,

SHARPNESS, TINT, PICTURE

SMART HELP

36

Control settings are at normal mid-range levels when
the bar scale is centered.

DTV Main Menu

T

o adjust your ATSC color and

picture controls, select a digital
channel and follow the steps shown
below:

Select the ATSC Picture

Menu.

With the DTV Main Menu on­screen, move the highlight with
the MENU ▲▼ buttons. Then

press the MENU (or ok) button.

Press the Menu § or © arrow

buttons

to adjust the selected

picture or color control.
Press the Menu ▲▼ buttons to

move up and down the list of on­screen Picture controls.

Press the “exit” button to clear

the screen.

STOP

1

2

3

Color Press Menu §

or © to add or eliminate

color.

Brightness Press Menu § or ©

until dark parts of the picture show
good detail.

Sharpness Press Menu § or © to
improve detail in the picture.

Picture Press Menu § or © until
whitest parts of the picture are as
bright as you prefer.

Tint Press Menu § or © to obtain
natural skin tones.

Sound
Speakers

Features

DTV Setup

Exit

BEGIN

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

DTV

mute

channel

++

volume

++

1

2

1

menu

ok

exit

Analog

DTV3/3

Picture Menu

Color

Brightness
Sharpness
Tint
Convergence

Back

3

ATSC/DIGITAL PICTURE MENU CONTROLS

RED/BLUE CONVERGENCE

SMART HELP

37

C

onvergence is the correct

lining up of the red and blue
light paths on the DPTV screen.
NOTE: If no color fringing (see
Smart Help) shows, then no
Convergence adjustments are
necessary.

Select the ATSC Convergence

control.

With Picture Menu on-screen,
move the highlight with the
MENU ▲▼ buttons. Then press

the MENU (or ok) button.

Press the MENU ▲▼ buttons

to select either the Align Red or
Align Blue Convergence control,
press the MENU button to
continue.

Press the MENU buttons

to move the selected red (or blue)
convergence cross directly over the
white cross on the DPTV screen.

The red (or blue) cross is properly
adjusted when it is completely
merged with the white cross. (No
color appears around the edge of
the white cross).

Press the “exit” button to clear

the screen when convergence
adjustments are complete.

1

2

3

STOP

4

Remember, Convergence

has been set at the factory for
best viewing, but if one or more of
the (red or blue) colors appear
around the edges of objects (color
fringing) follow the steps given in
this section.

NOTE: Adjustments for “Multi-Point” on­screen color fringing can also be made as part
of the DPTV’s Convergence control system.
Follow the on screen menu directions to
select individual screen areas that can be
readjusted and set for varying red/blue color
fringing conditions. These multi-point
settings can then be “Saved” to memory for
the specific areas of the DPTV screen (or
Factory Settings for convergence can be
recalled and put back into place for use).

CONVERGENCE MULTI POINT
CONVERGE RED POINTS

CONVERGE BLUE POINTS
RESTORE FACTORY SETTINGS
SAVE ADJUSTMENTS
BACK

CONVERGE RED POINTS

USE TO ADJUST

DIGIT 2, 4, 6, 8 TO MOVE CURSOR

MENU TO RETURN

PRESS MENU NOW TO CONTINUE

MULTI-POINT CONVERGENCE CONTROLS

BEGIN

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

2

1

menu

ok

exit

Analog

DTV3/3

4

DTV

mute

channel

++

volume

++

1

2

3

Picture Menu

Color

Brightness
Sharpness
Tint
Convergence

Back

CONVERGENCE MENU
ALIGN RED

ALIGN BLUE
CONVERGE MULTI POINT
BACK

PRESS to ALIGN RED

Press MENU to Return

ATSC/DIGITAL SOUND MENU CONTROLS

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers

25W, 8 ohms Min.

R

L

DTV ANTENNA

DTV DIGITAL

AUDIO OUT

ANALOG

TV ANT/CABLE

AUX 1 AUX 2

S-VIDEO

ANALOG

AUDIO OUT

AUDIO INPUT

AUX 1 AUX 2

VIDEO OUT

VIDEO INPUT

L

R

L

R

IR BLASTER

TV

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL
AUDIO IN

R

L

C

RS LS

SW

VGA IN

75 ohm
HIGH

SYNC

H/H + V

V

R/Pr

G/Y

B/Pb

HD COMPONENT

VIDEO IN

INTERNAL TV SPEAKERS

USED AS CENTER
CHANNEL

CENTER
CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT
SPEAKERS

EXT INT

SUBWOOFER
SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

+

-

+-

1

38

SURROUND SOUND

REAR OF DPTV

REAR SURROUND SOUND SPEAKERS

• Note: Surround Sound will not work with only
one speaker connected; or with monaural audio
playback source

PRIMARY VIEWING AREA

DPTV

REAR SPEAKER

REAR SPEAKER

REAR SURROUND SOUND

SPEAKER TERMINALS

(Operational only in ATSC or

Monitor Display modes)

B

y adding optional external

speakers to the DPTV's sound
system, you can create the feeling
of reflected sound that surrounds
you at a movie theater or concert
hall.

Connect both external

speakers to the speaker wire

terminals on the DPTV.
Recommended speakers: 25W, 8

ohm minimum. Be sure the (+) and
(-) speaker wires are connected to
the correct R(ight) and L(eft)
speaker terminals on the DPTV.

Place the speakers so the

viewing area is between the DPTV
and the rear surround speakers.
(See overhead view drawing on
this page.)

Turn DPTV ON. After setup

whenever a stereo signal is
received the audio will be heard in
Surround Sound.

STOP

1

2

3

SMART HELP

Note: The rear Surround

Sound speakers will not be
heard at the same volume level as
the front DPTV speakers. It is
intended for the rear speakers to
give a background noise effect
which requires a lower volume
level than the DPTV's front
speakers.

BEGIN

2

ATSC/DIGITAL SOUND MENU CONTROLS

ATSCATSC

++

++

mute

volume

channel

ok

exit

menu

DTV

Analog

DTV3/3

1

4

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

2

3

1

2

Sound Menu

Surround Mode
Treble
Bass

Auto Volume

Back

Surround

Day time linstening

Stereo

DOLBY DIGITAL SURROUND

39

SURROUND SOUND

Surround Mode -

• Dolby Digital 5.1 sound is processed normally

directing discrete channel audio sound to 6 speakers
(DPTV Front Right/Center/Left speakers; two rear
Surround speakers; and one Subwoofer low
frequency speaker.)

• For any two channel plain stereo audio (arriving

within the ATSC Dolby Digital carrier signal) the
DPTV processes the audio to play standard stereo in
the Left/Right Front DPTV speakers only.

Stereo Mode -

• Left/Right audio input signals are directed to the

DPTV’s two front L/R speakers.

• ATSC Dolby Digital multichannel sound signals are

downmixed to two channels and sent to the Front
Left/Right DPTV speakers.

TV

INTERNAL TV SPEAKERS

USED AS CENTER

CHANNEL

CENTER

CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT

SPEAKERS

EXT INT

SUBWOOFER
SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

SOURCE

EXIT

UP

CH

CH

DOWN

+

VOL

VOL

–

M

Sound Menu

Surround Mode
Treble
Bass

Auto Volume

Back

Surround

Day time listening

• Left/Right Front External speakers can be used in substitution

for the DPTV internal cabinet speakers if desired. (See the “Front
Speakers Switch” note in the section to the left for an explanation.)

• Subwoofer speaker connections are available on the rear of the

DPTV for either powered, or non-powered, types of optional
Subwoofer speakers. Contact your Philips dealer for further details
on Dolby Digital Surround Sound system speakers and their use.

REAR OF DPTV

Subwoofer

Speaker

-

(nonpowered) -

25W, 8Ω Min.

•Ask your dealer
about subwoofer
and surround
sound speakers
suggested for use
with your DPTV.

Rear Surround

Speaker

Rear Surround

Speaker

T

he Surround Sound control

option allows you to select the
type of sound mode sent to the
DPTV’s speaker system.

Select the ATSC Sound Menu.

With DTV Main Menu on-screen,
move the highlight with the MENU
▲▼ buttons. Then press the

MENU (or ok) button.

Press the MENU ▲▼ buttons

to select the Surround Mode
control.

Press the Menu § or ©

buttons to select the Surround (or

Stereo) mode for DPTV sound
playback.
(See the Surround Sound
information box to the right for
further details on the feature and its
use.)

Press the “exit” button to clear

the screen.

STOP

1

2

3

4

I

n order to receive the full

reproduction capability of true
Dolby Digital Surround Sound
you require the proper use and
arrangement of a Subwoofer and
surround speakers. The DPTV’s

extra speaker connections make it
possible to create a multichannel
soundfield effect previously
available only within a movie
theater or concert hall. With the
new 5.1 discrete digital channel
surround sound system the listener
can now attain a true soundstage
realism for audio signal
separation, imaging, and pinpoint
sound placement.

Note: If the Front External
Speaker Out terminals are used for

Left/Right audio channel playback
of Dolby Digital material, the
FRONT SPEAKER slide switch on
the rear of the DPTV must also be
placed to the EXT(ernal) position
in order for the connection and
signal routing to operate properly.

Front External

Speaker

(25W, 8Ω Min.)

Front External

Speaker

(25W, 8Ω Min.)

Subwoofer

Speaker

-

(powered) -

Suggested or
equivalent
optional
subwoofer
speakers for
use:

•Velodyne ­VAIC120
(12”, 120W)

•Infinity ­INI BU120
(12”, 120W)

•JBL ­PSWD110
(10”, 100W)

BEGIN

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

R

L

C

RS LS

SW

AUDIO INPUT

PHONO INPUT

L

R

DTV ANTENNA

DTV DIGITAL

AUDIO OUT

ANALOG

TV ANT/CABLE

AUX 1 AUX 2

S-VIDEO

ANALOG

AUDIO OUT

AUDIO INPUT

AUX 1AUX 2

VIDEO OUT

VIDEO INPUT

L

R

L

R

IR BLASTER

TV

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

R

L

C

RS LS

SW

VGA IN

75 ohm

HIGH

SYNC

H/H + V

V

R/Pr

G/Y

B/Pb

HD COMPONENT

VIDEO IN

INTERNAL TV SPEAKERS

USED AS CENTER
CHANNEL

CENTER
CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT
SPEAKERS

EXT INT

SUBWOOFER
SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

DTV DIGITAL

AUDIO OUT

SPDIF INPUT

DIGITAL AUDIO

AUDIO INPUT
FOR DVD,VGA,

OR HD

COMPONENTS

ATSC/DIGITAL SOUND MENU CONTROLS

INTERNAL TV SPEAKERS

USED AS CENTER

CHANNEL

CENTER

CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT

SPEAKERS

EXT INT

SUBWOOFER
SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

+

-

+-

+ R -

- L +

SURROUND

SPEAKERS

_

+

_

CENTR CH

OUT

DTV ANTENNA

DTV DIGITAL

AUDIO OUT

ANALOG

TV ANT/CABLE

AUX 1 AUX 2

S-VIDEO

ANALOG

AUDIO OUT

AUDIO INPUT

AUX 1AUX 2

VIDEO OUT

VIDEO INPUT

L

R

L

R

IR BLASTER

TV

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

R

L

C

RS LS

SW

VGA IN

75 ohm
HIGH

SYNC

H/H + V

V

R/Pr

G/Y

B/Pb

HD COMPONENT

VIDEO IN

INTERNAL TV SPEAKERS
USED AS CENTER

CHANNEL

CENTER

CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT
SPEAKERS

EXT INT

SUBWOOFER
SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

40

DOLBY DIGITAL SURROUND

ADDITIONAL CONNECTIONS

DTV Main Menu

REAR OF DPTV

Rear Surround

Speakers

Right Front

External

Speaker

Left Front

External

Speaker

A

Center Channel Input terminal

is also located on the rear of
the DPTV for additional Dolby
Digital Surround sound connection
options. This input can be used to
connect an external Dolby Digital,
or Home Theater Surround Sound,
capable Amplifier (with Center
Channel output) in order to play
Center Channel sound through the
DPTV’s internal cabinet speakers.

For example: With the use of an
external Amplifier capable of
Dolby Digital 5.1 (or Home
Theater Surround Sound) the Front
(Left/Right), Center, and Rear
(Left/Right) Surround system
speakers have their signals
supplied by the connections located
on the rear of the Amplifier.

Note: When an external
Amplifier is used as the audio

playback source for the DPTV’s
Center Channel Input terminals:

• Place the DPTV’s “INTERNAL

TV SPEAKERS USED AS
CENTER CHANNEL” switch
and the “CENTER CHANNEL
INPUT” switch to the YES
position in order for the
connection and Center Channel
speaker playback to function
properly.
These two slide switches are
used in tandem and should both
be kept in either the YES
position (when the DPTV is used
for Center Channel Input
playback), or the NO position
(when the DPTV uses its own
internal speaker system for
Surround sound purposes).

External Amplifier

(capable of Dolby Digital

5.1 or Home Theater
Surround Sound

Reproduction)

SONY-PHILIPS DIGITAL INTERFACE FORMAT

SPDIF is the term used for ATSC
module digital audio that can be
routed to an auxiliary amplifier that
accepts such an input signal. The
DTV Digital Audio Out(put) jack
on the rear of the DPTV is for the
connection of SPDIF audio
compatible external amplifiers or
home theater equipment.

SYSTEM AUDIO OUTPUT JACKS

Note:

The Left/Right Audio Out jacks
send the current available system audio
(whether NTSC, ATSC, or Monitor) for
output to an external amplifier. In the
case of digital multichannel audio the
DPTV downmixes the audio output to a
straight 2-channel stereo signal.

REAR OF DPTV

AMPLIFIER/RECEIVER

(SPDIF INPUT CAPABLE)

DTV DIGITAL

AUDIO OUTPUT (SPDIF)

RCA PHONO PLUG CONNECTOR

(SPDIF is active only when the DPTV is

in the ATSC mode)

(50W Max. Input)

Sound
Speakers

Features

DTV Setup

Exit

ATSC/DIGITAL SOUND MENU CONTROLS

BASS, TREBLE

41

T

he DPTV also has individual

sound adjustment controls for
the ATSC system audio. The BASS
(low frequency) and TREBLE
(high frequency) controls may be
used to adjust the sound of ATSC
TV programs, or other external
playback source material.

Select Bass or Treble sound

control.
With the Sound Menu on-screen,

move the highlight with the
MENU ▲▼ buttons. Then press

the MENU (or ok) button.

Press the MENU § © arrow

buttons to adjust the sound control

to levels you prefer.

Press the “exit” button to clear

the screen.

1

2

3

STOP

Treble and Bass are set to factory midpoint or default
levels when the barscale adjustments are placed to the
center detent position.

AUTO VOLUME

P

erforming a function similar to

the AVL sound control (in the
NTSC operating mode) the Auto
Volume control applies certain
value levels to variables within the
Dolby sound standard in order to
achieve dynamic audio range
compression. This single value
setting by the Auto Volume control
allows for a more consistent, even
sound reproduction in the
playback of ATSC audio.

Select Auto Volume sound

control.
With the Sound Menu on-screen,

move the highlight with the
MENU ▲▼ buttons. Then press

the MENU (or ok) button.

Press the MENU § © arrow

buttons

to set the Auto Volume
control to Day Time Listening (for
non-compressed full range audio
signals); or Night Time Listening
to receive a compressed ATSC
audio signal.

Press the “exit” button to clear

the screen.

1

2

3

STOP

BEGIN

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

DTV

mute

channel

++

2

volume

++

1

1

menu

ok

exit

Analog

DTV3/3

Surround Mode
Treble
Bass

Auto Volume

Back

Sound Menu

Surround

Day time listening

BEGIN

3

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

DTV

channel

volume

mute

++

2

++

1

menu

ok

Sound Menu

Surround Mode
Treble
Bass

Auto Volume

Back

Surround

Day time listening

exit

Analog

DTV3/3

1

3

ATSC/DIGITAL SPEAKERS MENU CONTROLS

SPEAKERS

42

DTV Main Menu

T

he Speakers Menu involves

various setup and function
aspects of multichannel speaker
configurations possible within
Dolby Digital Surround Sound
system playback. Basically, the
Speakers Menu controls deal with
distinct “one-time” settings for
such items as speaker volume
levels and sound delay (as related
to speaker distance and listening
room size dimensions).

Select the ATSC Speakers

Menu.

With the DTV Main Menu on­screen, move the highlight with the
MENU

▲▼ buttons. Then press

the MENU (or ok) button.

Press the Menu § or © arrow

buttons to adjust the selected

Speaker adjustment control.
Press the Menu ▲▼ buttons to

move up and down the list of
individual Speaker Menu controls.
(See the Speaker Menu
information box to the right for
detailed descriptions on the select
controls.)

Press the “exit” button to clear

the screen.

1

2

3

STOP

SMART HELP

Note: Other speaker

configuration slide switch
controls are also located on the
rear of the DPTV. The FRONT
SPEAKERS and CENTER
CHANNEL INPUT switches
direct the use and audio signal
routing for the DPTV’s internal
cabinet speakers and external
output speaker terminals. (See
pages 39 and 40 for further details
on the location and use of these
additional audio speaker controls.)

Center

• Delay - control allows the user to adjust center

channel speaker sound for situations where external
Left/Right speakers are in use and their relative
distance/position from the DPTV’s internal cabinet
speakers may vary. (See pages 39 and 40 for further
details on front external speakers, amplifier surround
systems, and the use of the DPTV as a source for
center channel speaker sound.)

- Front in Line - is for the speaker arrangement

where the center, left, and right speakers are
evenly lined up and roughly equidistant from the
user.

- Forward 1 foot (2 feet/ 3 feet) - settings

compensate for a center speaker being placed a
few feet

in front of the external left and right

speakers.

- Back 1 foot (2 feet) - settings compensate for a
center speaker being placed a few feet behind the
position of the external left and right speakers.

Front

• Left - control adjusts the volume level of the DPTV’s

left front internal cabinet speaker (or the Left Front
External Speakers Output terminal source on the rear
of the DPTV).

• Right - control adjusts the volume level of the

DPTV’s right front internal cabinet speaker (or the
Right Front External Speakers Output terminal
source on the rear of the DPTV).

Rear

• On/Off - control allows the user to turn the rear

surround sound signals On or Off to the Surround
External Speaker Output terminals on the rear of the
DPTV.

• Left - control adjusts the volume level of the DPTV’s

left rear surround sound speaker (as connected
through the Left Surround External Speaker Output
terminal on the rear of the DPTV).

• Right - control adjusts the volume level of the

DPTV’s right rear surround sound speaker
(as connected through the Right Surround External
Speaker Output terminal on the rear of the DPTV).

• Delay - control adjusts rear surround sound to

compensate for room size and how far the rear
surround speakers are located behind the system user
(Less than 3 feet; 3-5 feet; 5-8 feet; 8-12 feet; 12-15
feet; 15 feet or more).

Test Tone

• On/Off - allows the use of a test tone signal in order

to help set the volume levels for the individual
channel DPTV audio system speakers. (See the
following page for details on the use of the test tone
speaker adjustment process.)

Subwoofer Level

• Adjusts the volume level of a subwoofer speaker (as
connected through the Subwoofer Speaker Output
terminal on the rear of the DPTV).
Note: The DPTV’s additional Subwoofer Preamp
Output plug provides a variable line level signal
intended for an external “powered” subwoofer
capable of its own volume level adjustments.

Sound
Speakers

Features

DTV Setup

Exit

BEGIN

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

DTV

mute

channel

++

2

volume

++

1

2

1

menu

ok

exit

Analog

DTV3/3

3

Speaker Menu

Center Delay
Front Left

Right

Rear On/Off

Left
Right

Delay
Test Tone
Subwoofer Level

Back

Front in Line

On

15 feet or more
Off

ATSC/DIGITAL SPEAKERS MENU CONTROLS

TEST TONE

43

T

he Test Tone Speaker Menu

control generates a sound test
signal that can be used to adjust
individual DPTV speakers to
desired volume levels. The Test
Tone signal will be directed to each
audio speaker channel separately
(both internal DPTV cabinet
speakers and external Speaker
Output terminal connections) when
the control is turned On.

Select Test Tone sound control.

With the Speakers Menu on-screen,
move the highlight with the MENU
▲▼ buttons.

Press the MENU § © arrow

buttons to turn the Test Tone

control ON.

With the Test Tone speaker

signal active, press the
MENU▲▼ arrow buttons to

select the desired DPTV system
speaker for individual volume level
adjustment (for example:
Front/Left, Rear/Right, etc.).

Press the MENU § © arrow

buttons on the Pronto remote, or
the Volume (+, -) buttons on the
DPTV’s local keyboard, to adjust
the selected speaker volume levels.

Continue and select the other
DPTV system speakers for
adjustment as desired.

Press the MENU▲▼ arrow

buttons

to return to the Test Tone
Menu control when speaker
adjustments are complete and turn
the control Off.

1

2

3

STOP

4

5

Test Tone signal circulates through the speaker system
in a clockwise direction, and is meant to be used with the
adjustable Speaker Menu “barscale” controls (such as
Front Speaker Left/Right and Rear Speaker Left/Right).
Once turned On, the Test Tone will continue to circulate
through the Front and Rear speakers (even when other
sound controls are selected, such as Subwoofer, which
are not adjustable within the Test Tone mode.)

BEGIN

Speaker Menu

Center Delay
Front Left

Right

Rear On/Off

Left
Right

Delay
Test Tone
Subwoofer Level

Back

2

menu

ok

exit

Analog

DTV3/3

Front in Line

On

15 feet or more
On

mute

channel

DTV

++

volume

++

1

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

Speaker Menu

Right
Left

Right
Delay

Center Delay
Front Left

Rear On/Off

Test Tone
Subwoofer Level

Back

Front in Line

On

15 feet or more
On

Speaker Menu

Front in Line

Right

On

Left
Right

15 feet or more

Delay

On

UP

CH

+
VOL

M

SOURCE EXIT

VOL
–

CH

DOWN

TV

Center Delay
Front Left

Rear On/Off

Test Tone
Subwoofer Level

Back

4

3

5

ATSC/DIGITAL FEATURES MENU CONTROLS

CAPTIONS FORMAT

44

DTV Main Menu

T

he Captions Format control is

used to set the DPTV to receive
the ATSC mode Closed Caption
(CC) feature. ATSC Closed
Caption presents the viewer with
program dialogue and
conversations as written on-screen
“text box” windows.

Select the ATSC Features

Menu.

With the DTV Main Menu on­screen, move the highlight with the
MENU ▲▼ buttons. Then press

the MENU (or ok) button.

Press the Menu ▲▼ arrow

buttons

to select the Captions

Format control.

Press the Menu § © arrow

buttons buttons to select the

desired Closed Caption format
mode. (Captions 1,2,3,4 and Text
1,2,3,4 modes are available for
selection.)
Note: As in the NTSC system not
all CC modes will currently be
active or available for all program
selections. Check your local
listings for CC program details.

Press the “exit” button to clear

the screen. The selected Closed
Caption mode will be active (with
the Captions On/Off control also
set to the “Always On” position.

To cancel, set the Captions On/Off
control to “Always Off.”

1

2

3

STOP

SMART HELP

Due to the increased data

capacity within the DTV
broadcast system (10 times the
capacity of the analog NTSC
system) the ATSC version of
Closed Caption will allow for
simultaneous transmission of
multiple languages and offer
various reading level options for
the captioned material (when
available).

Note: The added resolution of active scan lines for
DTV (720p or 1080i) broadcasts, as opposed to analog
NTSC TV (525), can also provide for more defined
Closed Caption system character fonts and objects.
The ATSC display window for CC may be more on
the level of a computer with text windows containing a
variety of colors, size, and other object attributes.

4

Note: The “On during Mute” setting under the
Captions On/Off control can be used to set the DPTV
to turn the current selected Closed Caption mode
(example: Caption 1) "ON" whenever the MUTE
button on the remote is pressed.

Sound
Speakers

Features

DTV Setup

Exit

BEGIN

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

DTV

mute

channel

++

3

volume

++

1

2

1

menu

ok

exit

Analog

DTV3/3

4

Features Menu

Captions Format
Captions On/Off

Add/Delete Channel

Parental Control
Back

Features Menu

Captions Format
Captions On/Off

Add/Delete Channel

Parental Control
Back

Caption 1

Always On

Caption 1

On during Mute

ATSC/DIGITAL FEATURES MENU CONTROLS

ADD/DELETE CHANNEL

45

T

he DTV Setup Menu control

(see page 35) autoprograms all
available signal ATSC digital
channels into the DPTV’s scan
memory. Use the Add/Delete
Channel control to eliminate or
add to the specific list of “major”
channels contained within the
DPTV’s scan memory.

Note: Refer to page 5 in the
64PH9905 Quick Use guide for
additional information on “major
and sub-channel” digital channel
selections and how they are used
within the ATSC broadcast system.

Select the ATSC Features

Menu.

With the DTV Main Menu on­screen, move the highlight with the
MENU ▲▼ buttons. Then press

the MENU (or ok) button.

Press the Menu ▲▼ buttons to

select the Add/Delete Channel
control. Then press the MENU
button.

Press the CHANNEL (+)/(-)

(or number buttons on the Pronto’s
2/3 touchscreen display ) to select
the channel you want to add or
delete.

Press the MENU ▲▼ buttons

to select “Add this Major Channel”
control option, and then press the
Menu button to add the specific
digital channel into the DPTV's
scan memory.

OR

Press the MENU ▲▼ buttons to
select “Delete this Major Channel”

and press the Menu button to drop
the digital channel from the
DPTV’s scan memory.

Repeat steps 2, 3 and 4 for each
channel you wish to add or delete.

Press the “exit” button to clear

the screen when complete.

1

2

3

STOP

4

5

BEGIN

DTV Main Menu

Sound
Speakers

Features

DTV Setup

Exit

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

Features Menu

Captions Format
Captions On/Off

Add/Delete Channel

Parental Control
Back

Caption 1

Always On

4

2

1

menu

ok

exit

Analog

DTV3/3

DTV

mute

channel

++

volume

++

1

3

Add/Delete Channel

Add This Major Channel

Delete This Major Channel
Back

2

4

5

ATSC/DIGITAL FEATURES MENU CONTROLS

SMART HELP

NOTE:Your TV left the factory with the Parental Code set to "0000". If you are using your TV and
the Parental Control for the first time, and don't want to SETUP a new Access code number, you can
use the "0000" number to block channels - see next page.
The "0711" Parental Code (shown on this page) is given as a default or way to reset the Code when
the current Access number is not known. Also, once set, the same Access Code Number will apply
for the use and operation of the Parental Control system found in both the NTSC/Analog and the
ATSC/Digital Feature Menu control areas.

46

• Press MENU © to go on and start

to "block" channels.

• Press MENU § to go to "Content

Advisory" (or TV and Movie Ratings
system of channel blocking).

• Press MENU to return to the Parental

Control Menu screen.

• Press STATUS to clear the screen.

PARENTAL CONTROL

SETUP CODE NUMBER

MAIN MENU

P

arental Control allows parents

to block out, or "censor", any
channels they think children should
not watch. A channel placed under
Parental Control cannot be viewed
until a correct access code is used to
unlock the channel for viewing.

First let's set your Parental Code:

Select the PARENTAL

CONTROL.

With FEATURES MENU on screen,
move the RED highlight with the
MENU buttons. Then press the

MENU (or ok) button.
"CHANNEL BLOCKING" and

"SETUP CODE" show on screen.

Press the MENU ▲▼ and

MENU (or ok) buttons

to highlight

and select the SETUP CODE item.

Press 0, 7, 1, 1 on the remote.

"XXXX" shows on the ACCESS

CODE SETUP screen as you press
the number buttons.

"INCORRECT ACCESS CODE ­TRY AGAIN" will also show on the
screen.

Press 0, 7, 1, 1 on the remote

again.

"Next Enter Your New Access
Code" shows on the screen.

Enter a new four digit number

code using the remote.

"Access Code Changed" shows on

the screen to let you know the new
code has been set.

Continue to the next page to find
out how to "BLOCK" channels from
viewing.

1

2

3

4

5

Parents - it isn't possible

to unlock or defeat your
Censor Code without changing to
a new code number. So if your
Code number changes, and you
didn't change it yourself, then you
will know that someone has
altered the code and the blanked
out channel has been viewed.

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

BEGIN

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

Features Menu

Captions Format
Captions On/Off

Add/Delete Channel

Parental Control
Back

Caption 1

Always On

Parental Control

Content Advisory
Channel Blocking

Setup Code

Back

ACCESS CODE SETUP

X X X X

2

1

menu

ok

exit

Analog

mute

channel

2

DTV

++

1

volume

++

5

4

DTV

DTV3/3

Analog

3

A/CH

DTV2/3

First Enter Your
Current Access Code.

M

to EXIT

ACCESS CODE SETUP

X X X X

Next Enter Your New
Access Code.

M

to EXIT

ACCESS CODE SETUP

X X X X

INCORRECT ACCESS CODE

TRY AGAIN. If you've
Forgotten Your Access
Code, go to Setup Code
and see Owner's Manual.

to EXIT

M

ACCESS CODE SETUP

X X X X

Access Code Changed.

for Channel Blocking
for Content Advisory

to EXIT

M

ATSC/DIGITAL FEATURES MENU CONTROLS

SMART HELP

BLOCKED CHANNEL SCREEN

MESSAGE
(Appears when an attempt to select a
blocked channel is made and Parental
Control is ON.)

47

PARENTAL CONTROL

CHANNEL BLOCKING

A

fter your personal Parental

Code number has been set (see
previous page), you are now ready
to select the channels you want to
block out or censor.

Select the PARENTAL

CONTROL.

With FEATURES MENU on
screen, move the RED highlight
with the MENU buttons. Then

press the MENU (or ok) button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to
highlight and select the BLOCK
CHANNELS item.

Enter the correct Parental

Code number.

Press Channel ▲▼ or Channel

Number buttons to select the
channel you want to block.

Press the MENU © button to

"BLOCK VIEWING" on the
selected channel.
Press the MENU

§ button to

"ALLOW VIEWING" on a
blocked channel.

Repeat steps 3 and 4 for any other
channels you wish to block out.

STOP

1

2

3

4

5

Remember, to make

DPTV viewing easier all
channels will be unblocked, once
the correct Parental Code number
has been entered.
When the DPTV is turned OFF
and then back ON again, is when
Parental Control is back in place
for all blocked out channels.

BEGIN

ATSCATSC

DTV Main Menu

Sound
Speakers

Features

Tuning Program
DTV Setup

Exit

Features Menu

Captions Format
Captions On/Off

Add/Delete Channel

Parental Control
Back

Caption 1

Always On

Parental Control

Content Advisory
Channel Blocking

Setup Code

Back

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

CHANNEL BLOCKING MEMORY

X X X X

2

1

menu

ok

exit

Analog

1

mute

channel

DTV

++

5

volume

++

4

DTV

DTV3/3

3

2

A/CH

Analog

DTV2/3

To Block or Un-Block
Channels, First Enter
your Access Code

to EXIT

M

CHANNEL 19
CHANNEL BLOCKING ACTIVE

X X X X

Please enter Access Code

-OR­Select another Channel
for viewing.

CHANNEL BLOCKING MEMORY

Channel 19 Blocked
SELECT CHANNEL

to ALLOW Viewing

to EXIT

M

ATSC/DIGITAL FEATURES MENU CONTROLS

PARENTAL CONTROL

CONTENT ADVISORY

48

Note: Please remember that a valid and current Access Code number will be
required in the setup and use of the TV’s “Content Advisory” system. Review the
previous SETUP CODE section on how to obtain a valid Parental Access Code
number before attempting to make adjustments within the Movie Ratings and
Parental Guidelines system.

NOTE: In normal Content Advisory system operation
the TV screen will display a message when
programming is blocked by a Movie Rating, Parental
Guideline, or Blocking Option control feature.
Entering the correct ACCESS CODE number will
unblock all the blocked Content Advisory Rated
channels until the TV is turned Off. The blocked
Advisory Ratings will be back in place when the TV
is turned back On again.

Please enter Access Code

-OR­Select another Channel
for viewing.

CHANNEL 8
BLOCKED BY CONTENT ADVISORY
TV GUIDELINES TV-14 D

X X X X

MAIN MENU

A

nother new area available to

parents for the censoring of
program material is through the
TV Guidelines and Movie Ratings
system. Program Content Advisory
data will soon be contained within
the broadcast signals of received
TV programs. When setup by the
parent or viewer, the TV can
respond to transmitted advisory
data by blocking out or denying
access to TV shows (based on
whether the program meets or
exceeds the limitations you select
as viewable). The TV program can
then only be viewed by entering the
correct and current Parental Code
Access number.

The Content Advisory system uses
both “Movie Ratings” and a
“Parental Guidelines” form of
censoring. Refer to the following
page sections for explanations on
the different Rating system levels
and their uses.

Select the CONTENT

ADVISORY Menu option

With PARENTAL CONTROL
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

A Parental Guideline/Movie Rating
status screen will appear with a
review of currently BLOCKED
Content Advisory categories.

Press the MENU © button to

select the ENTER ACCESS

CODE Menu item.

Enter the correct Parental

Code number (see note at the top

of this page).
“CONTENT ADVISORY” Menu

screen appears. Parental
Guidelines, Movie Ratings and
other blocking control items are
ready for selection and use.

STOP

BEGIN

1

2

3

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

CONTENT ADVISORY STATUS

CONTENT ADVISORY

Parental Control

Content Advisory
Channel Blocking

Setup Code

Back

DTV

Analog

mute

channel

++

2

volume

++

DTV

3

A/CH

DTV2/3

1

menu

ok

exit

Analog

1

DTV3/3

TV RATINGS BLOCKED
TV-Y
TV-Y7 FV
TV-G
TV-PG DLSV
TV-14 DLSV
TV-MA LSV

Enter Access Code

CONTENT ADVISORY ACCESS

To Block or Un-Block
Programs, First Enter
your Access Code

to EXIT

M

Content Advisory Setup

Parental Guidelines
Movie Ratings

Review Settings
Blocking Options

Back

M

X X X X

DISABLED

MOVIE RATINGS BLOCKED
PG
PG-13
R
NC-17
X

to EXIT

ATSC/DIGITAL FEATURES MENU CONTROLS

49

CONTENT ADVISORY

MOVIE RATINGS

• G - General Audience: Most parents would find this

program suitable for all ages. This type of programming
contains little or no violence, no strong language, and
little or no sexual dialogue or situations.

• PG - Parental Guidance:

This programming contains
material that parents may find unsuitable for younger
children. It may contain one or more of the following:
Moderate violence, some sexual situations, infrequent
coarse language, or some suggestive dialogue.

• PG-13:

This programming contains material that parents
may find unsuitable for children under the age of 13. It
contains one or more of the following: violence, sexual
situations, coarse language, or suggestive dialogue.

• R - Restricted:

This programming is specifically
designed for adults. Anyone under the age of 17 should
only view this programming with an accompanying parent
or adult guardian. It contains one or more of the following:
intense violence, intense sexual situations, strong coarse
language, or intensely suggestive dialogue.

• NC-17 - No one under 17 admitted:

This type of pro­gramming should be viewed by adults only. It contains
graphic violence, explicit sex, or crude indecent language.

• X - Mature audience only:

This type of programming
contains one or more of the following: very graphic
violence, very graphic and explicit or indecent sexual acts,
very coarse and intensely suggestive language.

SMART HELP

M

ovie Ratings set viewing

access levels for TV
programming according to current
Motion Picture Association of
America (MPAA) ratings. These
ratings are similar to the
categories used with the rated
movies appearing in cinema
theaters and with video rental
material.

Select the MOVIE RATINGS

Menu option.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to

highlight and select (

U) the
desired MOVIE BLOCKING
level.

When in operation a “Blocked ­Movie Rating” TV screen appears
when movies are received which
include the same selected rating as
the Movie Blocking setting(s).
Only the correct Access Code
number, entered by the viewer,
will unblock or allow the viewing
of a block rated program.

STOP

BEGIN

1

2

Note: When a Movie

Rating is selected (

U) all
higher level ratings are
automatically blocked (although
each individual Movie Rating can
be manually selected and turned
On or Off as desired). Programs
with lower than the selected rating
level are allowed for viewing or
unblocked.

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

MOTION PICTURE BLOCKING

Content Advisory Setup

Parental Guidelines
Movie Ratings

Review Settings
Blocking Options

Back

G
PG
PG-13
R
NC-17
X
BACK

2

1

menu

ok

exit

Analog

DTV3/3

DTV

1

mute

channel

volume

++

++

2

ATSC/DIGITAL FEATURES MENU CONTROLS

50

CONTENT ADVISORY

PARENTAL GUIDELINES

• TV-Y - Appropriate for all children:

Designed for a
very young audience, including children ages 2-6. This type of
programming is not expected to frighten younger children.

• TV-Y7 -Appropriate for children seven and older:

It
may be more appropriate for children who have acquired the
development skills needed to distinguish between make-believe
and reality. This programming may include mild fantasy and
comic violence (FV).

• TV-G - General Audience:

This type of programming
contains little or no violence, no strong language, and little or
no sexual dialogue or situations.

• TV-PG - Parental Guidance suggested:

This type of
programming contains one or more of the following: Moderate
violence (V), some sexual situations (S), infrequent coarse
language (L), or some suggestive dialogue (D).

• TV-14 - Unsuitable for children under 14:

This type of
programming contains one or more of the following: intense
violence (V), intense sexual situations (S), strong coarse
language (L), or intensely suggestive dialogue (D).

• TV-MA - Mature audience only:

This type of
programming contains one or more of the following: graphic
violence (V), explicit sexual situations (S), or crude indecent
language (L).

• (V) - Violence

• (S) - Sexual situations

• (L) - Language

• (D) - Inappropriate dialogue

• (FV) - Fantasy Violence may frighten children under

seven. Some cartoons may have this rating. Available in
the TV-Y7 category only.

SMART HELP

MAIN MENU

P

arental Guidelines can be

even more defined and specific
in the degree and extent of
material parents may allow for TV
program viewing. Sub-settings for
Language, Violence, and other
blocking factors can be manually
switched On or Off for use within
the major Parental Guideline
categories (TV-Y7, TV-PG, etc.).

Select the PARENTAL

GUIDELINES Menu option.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

Press the MENU § © to

highlight and select the desired
PARENTAL GUIDELINE rating
level (TV-Y, TV-Y7, etc.).

Press the MENU ▲▼ and

MENU (or ok) buttons

to Block

(

U) the selected Parental
Guideline category (or to set other
individual blocking feature items
available within that Guideline
category (L, V. S, D, etc.) as
desired).

Note: Selecting “ALWAYS
BLOCKED” (or individually
adjusting the L, V, S, D settings)
for any one rating will set all other
higher level ratings to be
automatically blocked as well.

STOP

BEGIN

1

2

3

The TV-Y7; TV-PG;

TV-14; and TV-MA
guidelines also include
customized settings for various
additional items such as V
(violence), S (sexual situations), L
(coarse language), D (suggestive
dialogue), and FV (fantasy
violence). These additional
settings are category specific and
can be individually selected for
use as desired.

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

TV PARENTAL GUIDELINES

to select rating

to select blocking

TVY7TV GTVPGTV14TV

TV
Y

Not Blocked
Always Blocked
(FV) Fantasy Violence

Back

Content Advisory Setup

Parental Guidelines
Movie Ratings

Review Settings
Blocking Options

Back

3

1

menu

ok

exit

Analog

1

3

DTV3/3

DTV

mute

channel

++

2

volume

++

MA

TV PARENTAL GUIDELINES

to select rating
to select blocking

TVY7TV GTVPGTV14TV

TV
Y

Not Blocked
Always Blocked
Language (L)
Violence (V)
Sexual Content (S)
Suggestive Dialog (D)

Back

MA

ATSC/DIGITAL FEATURES MENU CONTROLS

51

CONTENT ADVISORY

REVIEW SETTINGS

CONTENT ADVISORY

BLOCKING OPTIONS

Note: Remember that Content Advisory data or encoded
information is not available with all received TV
programming (this also includes commercials, and other
program spot announcements). Broadcaster’s can decide
not to encode any kind of content advisory ratings with
their programming, or they can actually choose to encode
programs to be “unrated.”
The TV Blocking Options allow the viewer to block any
program without content advisory data with the use of its
“NO RATING INFORMATION” control. And to block
programs that are encoded as “unrated” with its
“UNRATED PROGRAMMING” control option.

Since the reception of Content Advisory data can take a
few seconds, you may want to use the “CHANNEL
CHANGE” option to be sure no viewing is allowed during
blocked program channel changes. This can eliminate the
display of a few seconds of undesirable video on the TV,
or receiving scenes from a Ratings blocked channel
source.

T

he Content Advisory system

also has “Blocking
Option”controls which can be
used to deny viewing access for
channel programs and movies
even when they are “unrated”, or
contain “no rating” information
as broadcasted.

Select the BLOCKING

OPTIONS Menu control.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

Press the MENU ▲▼ and

MENU (or ok) buttons

to turn the
Blocking System On (highlight
and select

U ENABLED). Then
use the remote Menu buttons to
select the desired programming
and information blocking options.

Please refer to Note shown with
this page section for details on
“unrated” and “no rating” program
control options.

STOP

BEGIN

1

2

U

se the Review Settings control

to quickly check the status for
Content Advisory system Parental
Guidelines and Movie Rating
“Blocked” program levels.

Select the REVIEW

SETTINGS Menu option.

With CONTENT ADVISORY
Menu on screen, move the RED
highlight with the MENU

buttons. Then press the MENU (or
ok) button.

The TV screen will display the
current Parental Guideline and
Movie Ratings Blocked program
settings. Content Advisory system
status will also be shown (Enabled

-On, or Disabled - Off).

STOP

BEGIN

1

MAIN MENU

SOUNDPICTURE

FEATURES

1ST TIME SETUP

EXIT

Content Advisory Setup

Parental Guidelines
Movie Ratings

Review Settings
Blocking Options

Back

CONTENT ADVISORY OPTIONS

Disable Blocking System
Enable Blocking System

SET TO BLOCK ON:

Channel Change
Unrated Programming
No Rating Information

Back

2

1

menu

ok

exit

Analog

DTV3/3

DTV

mute

channel

++

1

volume

++

2

CONTENT ADVISORY STATUS

CONTENT ADVISORY

Content Advisory Setup

Parental Guidelines
Movie Ratings

Review Settings
Blocking Options

Back

1

menu

ok

exit

Analog

DTV3/3

DTV

mute

channel

++

1

volume

++

TV RATINGS BLOCKED
TV-Y
TV-Y7 FV
TV-G
TV-PG DLSV
TV-14 DLSV
TV-MA LSV

ENABLED

MOVIE RATINGS BLOCKED
PG
PG-13
R
NC-17
X

to Continue

M

PRONTO REMOTE ATSC DIGITAL FEATURES

PRONTO - DIGITAL TV MODE

52

scroll arrows

Press to move to the next (or previous) page of Pronto
controls. The touchscreen will display the current
control screen’s page number, and the total number of
pages available for the selected device (1/3; 2/3; etc.)

SMART HELP

menu buttons

Press the Menu (or ok) button to
show on-screen controls. Press M
▲ or ▼ buttons to move up (or
down) the list of DTV controls.
Press the (M)

§ or © buttons to
make adjustments to the selected
controls.

volume buttons

Press to adjust the DPTV sound level up (+) and down (-).

channel scan buttons

Press to scan up (+) or down (-) through any ATSC programmed
channel numbers.

power button

Press to turn the DPTV ON and OFF.

sleep button

Press to set the DPTV to
automatically turn itself OFF.
(15 minutes to 2 hours ahead.)

number buttons

Press two number buttons to select single digit “major”
DTV channels. Use a four-digit channel entry to select
ATSC system “sub-channel” programs, for example: press
“0, 6, 0, 1” for sub-channel 6.01. (See page 5 in the
64PH9905 Quick Use guide for details on the use and
selection of sub-channels.)

exit button

Press to clear the DPTV screen after control
adjustments. Also press to see the current channel
number on the DPTV screen.

A/CH button

Press Alternate Channel (A/CH) to select previously
viewed channels. Enter the desired two channel numbers
(from the Pronto remote’s number buttons), and then
press A/CH to toggle back and forth between the two
channel selections.

mute button

Press to turn the sound OFF on the DPTV. Press again to return
the sound to its previous level.

dtv freeze

Press to freeze or stop the current picture on the DPTV screen.
Program sound will continue to play. Repress the freeze button, or
wait for a 60-second time out, to return to live program action.

T

he Pronto remote contains

touchscreen displays for
“DTV” related controls. Use the
Pronto’s touchscreen buttons to
access and adjust the DPTV for
dedicated ATSC mode features, as
well as perform on-screen Menu
adjustments and select other
program functions.
Note: For battery installation and
other details on the initial use of
the Pronto remote control also
refer to the 64PH9905 Quick Use
guide included with your DPTV.

Gently tap the Pronto

touchscreen with your finger to

display its control panel for use.
Be sure “TV” is selected for the

current device tab item category.

Press the “DTV” button on

the Pronto to ensure ATSC mode

commands are sent from the
remote.

1

2

STOP

Due to the amount of

optional component and
feature uses available with the
Pronto’s Device Reference and
Learn Code lists, please also refer
to the separate full-use Pronto
Owner’s Manual for complete
details on its function and
operations.

alternate audio*

Press to cycle through the available audio
language tracks for the current DTV program.
(See the additional alternate audio section

information shown below.)

status button

Press to see the current channel number on the DPTV screen.
Also press to clear the DPTV screen after control adjustments.

* The “alt(ernate) audio” button on the Pronto

remote allows the user to select a language
preference for multilingual or alternate language
audio track programs that may be received for DTV
viewing. (English is the default language setting.)

When digital broadcast material is received which
contains multiple language soundtracks the DPTV
will identify, find, and then select the preferred
alternate audio language for sound playback. If the
selected language preference is not available within
the received program material, the default audio
language is then selected.

ext input button

Press to select the auxiliary input connections available on
the rear of the DPTV (analog NTSC - AUX1/2/3; Monitor

-VGA; External High Definition - EXT HD, etc.).

BEGIN

mute

channel

power

alt audio

sleep

analog format

Analog

DTV

status

freeze

ext input

DTV1/3

++

volume

++

Analog

DTV

A/CH

DTV2/3

menu

ok

exit

Analog

DTV3/3

DTV

Alternate Audio preference: English

MONITOR FEATURES MENU CONTROLS

VGA/SVGA/HDCOMPONENT

53

A

nother function of the DPTV is

for the connection and use of
Personal Computers (PCs), and
other High Definition (HD) digital
source equipment, through the
DPTV’s Monitor inputs and
display mode. Dedicated Audio
Input jacks (located on the rear of
the DPTV) are also paired to the
external source Monitor Video
Inputs (VGA and HD Component
Video In) for audio playback
connections as well.

For example: To connect a Philips
DVX8000 Multimedia Home
Theater (MMHT) for monitor
mode display use on the DPTV:

Connect a 15 pin VGA signal

cable (optional) from the VGA

(or SVGA) jack on the select
auxiliary equipment (example:
DVX8000 MMHT) to the VGA
Input jack on the DPTV.

Connect the Left/Right

STEREO IN jacks on the DPTV

to the (L/R) Audio Output jacks
(labeled Front) on the DVX8000
MMHT.

Press the “ext input” button

on the Pronto remote (or the

Source button on the DPTV’s local
keyboard) to select the required
Monitor mode. (VGA, SVGA, and
EXT HD Monitor modes are
available for selection with the
“ext input” or Source buttons.)

Use the DVX8000 MMHT as

the video (and/or audio) playback
source for material to be displayed
on the DPTV.

1

2

3

STOP

4

REAR OF DPTV

REAR OF DVX8000 MMHT

15 PIN VGA

Connection Cable

Left/Right

Audio IN

HD COMPONENT VIDEO IN

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

R

L

C

RS LS

SW

VGA IN

75 ohm

HIGH

SYNC

H/H + V

V

R/Pr

G/Y

B/Pb

HD COMPONENT

VIDEO IN

INTERNAL TV SPEAKERS

USED AS CENTER

CHANNEL

CENTER

CHANNEL INPUT

50 W MAX IN

– +

NO YES

SUBWOOFER
PREAMP OUT

FRONT

SPEAKERS

EXT INT

SUBWOOFER

SPEAKER OUT

– +

FRONT EXTERNAL SPEAKERS OUT

– +

– +

SURROUND EXTERNAL SPEAKERS OUT

– +

– +

All External Speakers 8 ohms Min.

R

L

R

L

AUDIO INPUT

FOR DVD,VGA,

OR HD

COMPONENTS

• BNC (Bayonet Connectors) are available to

attach a computer to the DPTV for use as a
monitor display. The optional BNC cables
twist and secure to the individual
Red/Green/Blue and Horizontal/Vertical
Sync(hronization) component Video Inputs
on the rear of the DPTV. This type
connection ensures optimum video and color
reproduction performance from a computer,
or other external High Definition playback
source.

• SYNC(hronization) slide switch used to set

the DPTV for digital HD Component signal
input source impedance (low-75 ohm or High).

• 6 CHANNEL AUDIO IN(put) jacks paired to

HD Component Monitor Video Inputs (shown
below). For use with external accessory
equipment capable of Dolby Digital 5.1 level
audio output playback connections.

• Separate Red/Green/Blue (Luminance-Y and

Color Difference-Pr/Pb) Component Video
Inputs provided for improved color bandwidth

information and highest possible picture
resolution for digital source connections. (See
BNC Connector information below.)

• H/H + V (for combined Horizontal/Vertical

sync signals) or V(ertical) sync inputs control
the display of a RBG sourced picture in the left­to-right dimension and from top-to-bottom.

SMART HELP

Note: The DPTV’s video

display may temporarily appear
misconverged during the initialization
of certain VGA input connected PC
programs (i.e., DOS). Once the PC
program has completed its “bootup”
phase, normal signal level processing
will reoccur and the DPTV display will
return to normal.

Note: The DPTV will
display any Television
compatible VGA or
SVGA (60Hz only)
signal input.

BEGIN

VGAVGA

SVGASVGA

EXT HDEXT HD

power

alt audio

sleep

Analog

analog format

UP
CH

VOL

M

SOURCE EXIT

–

CH
DOWN

status

freeze

ext input

DTV1/3

BRIGHTNESS

SHARPNESS
SVM OFF
COLOR
TINT
VOLUME BARON

C

SW

2

SYSTEM AUDIO OUT

STEREO IN

6 CHANNEL

AUDIO IN

1

AUDIO INPUT

FOR DVD,VGA,

OR HD

COMPONENTS

R

RS LS

L

AUDIO OUTPUT

SUB

L

WOOFER
CENTER

R

CENTERSURROUNDFRONT

TV

PHONE

TV/CABLE

ANT

RGB

SVGA

LINE

R DATA

(RGB)

MIC

IR

LINE IN

VGA IN

75 ohm

SYNC

HIGH

H/H + V

V

GND

ANTENNA

HD COMPONENT

AM

ON

OFF

R/Pr

G/Y

B/Pb

VIDEO IN

LD VCR 2 IN-VCR-OUT

DSS

IN-VCR-OUT

USB

VIDEO

MULTI

+
VOL

DTV

channel

volume

mute

++

++

FM

L

R

IN-TAPE-OUT DSSLDVCR 2

CD

3

FRONT

SPEAKERS

EXT INT

SUBWOOFER
PREAMP OUT

SUBWOOFER

SPEAKER OUT

FRONT EXTERNAL SPEAKERS OUT

SURROUND EXTERNAL SPEAKERS OUT

All External Speakers 8 ohms Min.

MULTI REMOTE

TV

MONT

AC-3 RF

AC-3/

PCM

COAX

IN

2

1

R

R

AC-3/PCM

INTERNAL TV SPEAKERS

– +

– +

– +

IN

OUT

OPT

IN

USED AS CENTER

CHANNEL

NO YES

CENTER

CHANNEL INPUT

– +

50 W MAX IN

– +

L

– +

L

MONITOR FEATURES MENU CONTROLS

MONITOR MENU CONTROLS

54

BRIGHTNESS

T

he Monitor Menu feature
controls are to aid you in

setting up the DPTV for the best in
display image quality. Generally,
the Monitor feature controls cover
the basics in color and video
image screen adjustments. A
variety of Monitor Audio Input
controls are also available for
various speaker trim adjustments
(dependent upon whether the
externally supplied Monitor input
source is capable of 2-channel
stereo or 6-channel digital sound
replay).

Press the “ext input” button

on the Pronto’s TV touchscreen, or
SOURCE on the local keyboard, to
place the DPTV in the desired
monitor display mode (VGA,
SVGA, EXTHD).

Press the MENU button to

display the Monitor Feature
Control Menu.

Press the (M) Up/Down ▲▼

Arrows on the Pronto’s

touchscreen display to highlight
items within the Monitor control
screen list.

Press the Left/Right § ©

Arrows on the Pronto to adjust the

selected on-screen feature control.

Press the “exit” button to clear

the screen when complete.

1

2

3

STOP

4

• Use the Brightness and other

Monitor picture features (such as
Picture, Sharpness, etc.) to adjust
overall DPTV screen intensity for
optimum light/dark screen areas
and shading details.

• Turn the Volume Bar Sound

Menu control ON to display the
volume level settings for external
audio sourced material on the
DPTV screen.

• Select the Bass/Treble/Balance

Sound Menu controls to adjust
low/high frequency sound and
speaker balance for external input
audio source material played
through the DPTV’s audio system.

• Use the Adjust Trim (Left,
Right, Center, Subwoofer,
Surround Left, Surround Right)

Sound Menu controls when
adjusting sound for a 6-channel
audio input received externally for
playback through the DPTV’s
Monitor display operating mode.

• Use the Display Mode, Format,
and Input Feature Menu controls

to set the DPTV for the type of
external monitor display mode
source (VGA, AUTO, SVGA,
EXT HD); the DPTV’s display
screen format used (PC,
NORMAL); and input type signal
received (RGB; Y P

B PR; RGB-

Direct).

• Additional Sync Type,
Horizontal Phase, Back Porch
Width Feature Menu controls can

be used to adjust for color shifts,
black level, and various other
display screen imagery.

• Note: The list of Monitor Menu features (and

their individual control settings) will change
or readjust according to the capabilities of
the selected Display Mode (VGA, SVGA, etc.) .

SMART HELP

Certain barscale Monitor

Feature Menu adjustments
(such as Brightness, Picture, etc.)
will display separate control panel
screens for individual settings.
Repress the Menu button (on the
Pronto remote or local keyboard)
to return the DPTV to the Monitor
Menu when control adjustments
are complete.

5

SHARPNESS
SVM OFF
COLOR
TINT
VOLUME BARON

BEGIN

VGAVGA

SVGASVGA

EXT HDEXT HD

SOUND
FEATURE
EXIT

power

alt audio

sleep

analog format

Analog

MAIN MENU

ext input

2

DTV1/3

5

status

freeze

DTV

menu

exit

Analog

channel

volume

mute

++

1

++

DTV

4

ok

DTV3/3

3

BRIGHTNESS

SHARPNESS
COLOR
TINT
BACK

AUDIO INPUT STEREO BACK
VOLUME BAR ON
INTERNAL AMP ON

BASS
TREBLE
BALANCE
BACK

DISPLAY MODE VGA
DISPLAY FORMAT NORMAL
INPUT TYPE RGB
SYNC TYPE AUTO

HOR PHASE

BP WIDTH
BACK

(OR 6 - CHANNEL*)
(OR OFF)
(OR OFF)

(OR ADJUST TRIM*)

(OR SVGA/AUTO/HD)
(OR PC)
(OR Y PB PR/RGB DIRECT)
(OR MODE 1-5)

TIPS IF SOMETHING ISN'T WORKING

• Check the DPTV power cord. Unplug the DPTV, wait 1 minute for the unit to reset,
then reinsert plug into outlet and push POWER button again.

• Check to be sure power outlet is not on a wall switch.

• Check for proper ATSC or NTSC antenna connections on the rear of the DPTV. Are
they properly secured to the appropriate antenna plug on the DPTV?

• For ATSC Autoprogram check DTV Setup for proper Full Installation option. Use
“Without Program and System Info” selection for initial digital station programming.

• Check the SOURCE, or “ext input” control on the remote, for the correct operating
mode for the DPTV (ATSC, NTSC, Auxiliary Inputs, Monitor, etc.).

• Check the CLOSED CAPTIONS control. Some TEXT modes could block the screen.

• Check for correct battery placement and position in Pronto remote battery compartment.
Replace with AA Heavy Duty (Zinc Chloride) or Alkaline batteries if necessary.

• Check the Device Tab button on the Pronto remote for correct selected device (“TV” to
operate the DPTV). Refer to the separate Pronto Remote Owner’s Manual for complete
details on its operation and use.

• Press the Pronto’s “analog TV” or “DTV” touchscreen button to properly select and
send remote commands to the desired NTSC or ATSC DPTV mode of operation.

• Check the VOLUME and MUTE buttons on the DPTV and Pronto remote.

• Check the INTERNAL SPEAKERS CENTER CHANNEL INPUT switches (on rear of
DPTV) for proper position. Use the “NO” switch position for internal DPTV cabinet
speaker routing; and “YES” position when the DPTV speakers are intended as Center
Channel speakers within an external amplifier supplied Surround Sound system.

• If attempting auxiliary equipment hook-ups, check audio jack connections and ensure
auxiliary equipment is on and in the proper operating modes.

• Check FRONT SPEAKERS switch (on rear of DPTV). Place in INT(ernal) position for
sound playback through the DPTV’s internal speaker system. EXT(ernal) for optional
external speaker playback connections using the Front and Surround Speakers Out(put)
terminals on the DPTV.

• Check and be sure DPTV is in the proper operating mode (ATSC, NTSC, or Monitor).

• Repeat channel selection. In ATSC mode allow time for DTV channel acquisition and
display process to take place. For ATSC sub-channel selections be sure to enter the
desired four-digit channel number using the Pronto remote.

P

lease make these simple

checks before calling for
service. These tips can save you
time and money since charges for
DPTV installation and
adjustment of customer controls
are not covered under your
warranty.

Note: The DPTV is equipped with protective circuitry that shuts the unit off in case of moderate power surges. Should this occur turn the DPTV
back on by pressing the POWER button once or twice, or unplug and then replug the power cord at the AC outlet. This feature is NOT designed to
prevent damage due to high power surges such as those caused by lightning, which is not covered by your warranty.

Cleaning and Care

• To avoid possible shock hazard be sure the DPTV is unplugged
from the electrical outlet before cleaning.

• When cleaning the DPTV screen take care not to scratch or
damage the screen surface (avoid wearing jewelry or using
anything abrasive, do not use household cleaners). Wipe the front
screen with a clean cloth dampened with water. Use even, easy,
vertical strokes when cleaning.

• Specially designed screen cleaning kits are also available which
contain anti-static cleaners and cloths designed for use with the
DPTV screen. If interested, ask your dealer or call our toll-free
Accessory Parts ordering number 1-800-851-8885.

• Gently wipe the cabinet surfaces with a clean cloth or sponge
dampened in a solution of cool clear water and a mild soap or
detergent. Use a clean dry cloth to dry the wiped surfaces.

• Occasionally vacuum the ventilation holes or slots in the cabinet
back.

• Never use thinners, insecticide sprays, or other chemicals on or near
the cabinet, as they might cause permanent marring of the cabinet
finish.

CAUTION: A video source (such as a video game, Compact Disc Interactive - CDI, or
TV information channel) which shows a constant non-moving pattern on the DPTV
screen, can cause picture tube damage. When your DPTV is continuously used with
such a source the pattern of the non-moving portion of the game (CDI, etc.) could leave
an image permanently on the picture tube. When not in use, turn the video source OFF.
Regularly alternate the use of such video sources with normal DPTV viewing.

55

No Power

No Picture or

Autoprogrammin

g Difficulties

No Sound

Remote Does

Not Work

DPTV Displays

Wrong Channel or

incorrect program

INDEX

Add/Delete Channels ..................6, 14-15, 35, 45, *Q/U-2, 5, 6

Audio Controls.........................25-28, 38-41, *Q/U-2, 4, 5, 6, 7

Audio/Video Inputs.........................30-34, 38-40, 53 *Q/U-2, 7

Automatic Programming..................................6, 35, *Q/U-5, 6

Auxiliary Inputs..............................30-33, 38-40, 53 *Q/U-2, 7

AVL (Automatic Volume Limiter).........................................28

Balance .......................................................................25, 41, 54

Bass.............................................................................25, 41, 54

Battery Installation .........................................................*Q/U-3

Cable TV Connections/Settings ...........................13, *Q/U-5, 6

Channel/Time Display..............................................17, *Q/U-6

Channel Memory.....................................14-15, 35, 45, *Q/U-2

Channel Label.........................................................................18

Cleaning and Care ....................................................55, *Q/U-3

Clearview..................................................................................8

Clock Setting ......................................................................6, 16

Closed Captioning..........................................12, 44, *Q/U-5, 6

Color Controls..............................................8, 36, *Q/U-5, 6, 7

Convergence.........................................................9, 37, *Q/U-5

Content Advisory...................................................19-24, 46-51

Controls DPTV.......................................................*Q/U-2, 4, 6

Controls Remote.....................................29, 52, *Q/U-3, 4, 6, 7

Dolby Digital.....................................5, 39-40, 42, *Q/U-1, 2, 8

DVD Connections...................................................................33

Exit .........................................................................*Q/U-2, 4, 6

Features.......................................................................5, *Q/U-1

First Time Set Up..........................................6-7, 35, *Q/U-5, 6

Glossary DPTV Terms ...........................................................57

High Definition Component Inputs.................53-54, *Q/U-2, 7

Inputs (Audio and Video) ................................30-34, 39-40, 53

Menu...................................................................*Q/U-2, 4, 6, 7

Menu Arrow Buttons.............................................*Q/U-4, 6, 7

Monitor Controls..................................................54, *Q/U-2, 7

Parental Control .....................................................19-24, 46-51

Programming Channels........................................6, 35, *Q/U-2

Pronto Remote Control...........................29, 52, *Q/U-3, 4, 6, 7

Requesting Service............................................... 55, 58-59, 60

Safety/Precautions............................................2, 3, 55, *Q/U-1

Second Audio Program (SAP)................................................26

Sensor Remote................................................................*Q/U-2

Sleep Timer.......................................................................29, 52

Smart Picture.....................................................................10-11

SPDIF.......................................................................40, *Q/U-2

Speaker Switches ..........................................39-40, 42, *Q/U-2

Status Button.....................................................................29, 52

Surround Sound................................................38, 39-40, 42-43

SVGA..............................................................53-54, *Q/U-2, 7

System Audio Out ..............................................34, 40, *Q/U-2

Time/Channel Display..............................................17, *Q/U-2

VCR/DPTV Connections..................................................30-32

Tips for Service...........................................................55, 58-59

Treble..........................................................................25, 41, 54

VGA....................................................................53-54, *Q/U-7

Volume Display......................................................................27

Volume Limiter ................................................................28, 41

Warranty.................................................................................60

* Information contained in DPTV Quick-Use (Q/U) Guide - page listed

56

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. this
equipment generates, uses, and can radiate radio frequency energy
and , if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio or television technician
for help.

Modifications ­The FCC requires the user to be notified that nay changes or
modifications made to this device that are not expressly approved
by Philips Consumer Electronics may void the user’s authority to
operate the equipment.

Cables ­Connections to this device must be made with shielded cables with
metallic RFI/EMI connector hoods to maintain compliance with
FCC Rules and Regulations.

Canadian Notice ­This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.

Avis Canadien ­Cet appareil numérique de la classe B respecte toutes les exigences
du Règlement sur le matériel brouilleur du Canada.

Regulatory Notices - Federal Communications Commission Notice

GLOSSARY TO TELEVISION TERMS

57

Audio/Video Inputs * Located on the rear of the DPTV these

connectors (RCA phono type plug) are used for the input of audio and
video signals. Designed for use with VCRs (or other accessories) in
order to receive higher picture resolution and offer sound connection
options.

Aspect Ratio * The proportions of a rectangular display screen. NTSC

television has a 4:3 ratio; HDTV is 16:9.

ATSC * Advanced Television Systems Committee established by the

Federal Communications Commission to set standards for digital
television.

Coaxial Cable * A single solid antenna wire normally matched with a

metal plug (F-type) end connector that screws (or pushes) directly onto a
75 Ohm input found on the Television or VCR.

Display * An on screen message or graphics that help the user operate

and adjust DPTV feature controls. See On Screen Displays (OSD).

Dolby Digital * A digital 6-channel compression and surround sound

audio standard developed by Dolby Labs Inc. (also known as 5.1.)

DPTV * Digital Projection Television comprised of ATSC, NTSC, and

Monitor modules.

DTV * The broadly defined term used to describe the new digital

television system adopted by the Federal Communications Commission
(FCC) in December 1996.

HDTV * High Definition Television which offers approximately twice

the vertical/horizontal resolution of NTSC video, and sound quality
approaching that of compact disc. (Usually taken to mean a picture of
1920 x 1080 pixels in a 16:9 aspect ratio.)

LED * Light Emitting Diode or indicator.
Major Channel * The RF transmitted channel on which an ATSC

digital station is broadcast. (Also referred to as virtual channel.)

Menu * An on-screen listing of feature controls shown on the DPTV

screen that are made available for user adjustments.

MPEG * Motion Picture Experts Group and the video compression

formats devised for transmission of digital broadcasts.

Multichannel Television Sound (MTS) * The broadcast standard

that allows for stereo sound to be transmitted with the TV picture.

NTSC * National Television Standards Committee format devised for

TV broadcasting signals in the 1940s (525 lines; 30Hz.)

On Screen Displays (OSD) * Refers to the wording or messages

generated by the DPTV to help the user with specific feature controls
(color adjustment, programming, etc.).

Pre-Amplifier * The control center of a hi-fi system. Not only

amplifies source inputs, but also allows for source selection, volume,
tone, balance and all other controls that affect the sound.

Programming * The procedure of adding or deleting channel

numbers into the DPTV’s memory circuits. In this way the DPTV
“remembers’’ only the locally available or desired channel numbers and
skips over any unwanted channel numbers.

PSIP * Program and System Information Protocol.
PTV * Projection Television (Rear and/or Front projection design

systems are available.)

Remote Sensor Window * A window or opening found on the

DPTV control panel through which infrared remote control command
signals are received.

RF * Radio Frequency or modulated signal design used as the carrier

for television broadcasts.

RGB * Red, Green, Blue color component inputs used for connection

purposes with personal computers (PCs) and other high definition video
devices.

Second Audio Program (SAP) * Another or additional audio

channel provided for in the Multichannel Television Sound (MTS)
broadcast standard. A monaural soundtrack included within the
recorded or video signal (usually containing a second language
translation for the displayed programming.)

SDTV * Standard Definition Television is a digital television

transmission, but with approximately the picture quality and aspect ratio
equivalent to NTSC video.

Status * Allows the user to quickly confirm what channel number is

currently being viewed. Status can also be used to clear the DPTV of on­screen displays or information (rather than waiting for the displays to
“time out” or automatically disappear from the screen).

Subchannel * A complete digital channel number is composed of both

a major and minor (sub-) channel number. Located within the “major”
channel’s transmitted signal the “minor” channel can be used and
selected for additional programming.

Subwoofer * A speaker designed for audio playback of only the

lowest-frequency notes (under 100 Hz.)

SVGA * Super Video Graphics Array
S-Video Input * Allows direct connection of high-resolution video

sources, such as a Super VHS videocassette recorder, Laser Disc player,
etc. Provides improved picture resolution, sharpness, and clarity.

Twin Lead Wire * The more commonly used name for the two strand

300 Ohm antenna wire used with many indoor and outdoor antenna
systems. In many cases this type of antenna wire requires an additional
adapter (or balun) in order to connect to the 75 Ohm Input terminals
designed into the more recent Televisions and VCRs.

Variable Audio Output * An adjustable audio output which allows

for volume variations at the source.

VGA * Video Graphics Array
YUV * Component video signals consisting of Y luminance and

normalized color differences U and V.

•

•

★ Miami/SE Florida

•

Chicago

Cleveland/

N Ohio

•

•

Tampa/W Florida

★ Ft. Myers/SW Florida

•

•

San Francisco/Metro Area

•

Detroit/Toledo

★ Pittsburgh/WV Area

•

•

•

Philadelphia/S New Jersey

•

See Reverse Side for More Details.

Atlanta/N Georgia

Houston/Galveston

Beaumont/Austin

San Antonio

Knoxville/E Tennessee

•

Charlotte

Los Angeles★

• Dallas

★ Columbus

★ Wash/Balt

★ Orlando

★ Indicates In-Home Service Only

1-800-242-9225

• Indicates In-Home/Carry-In Service

NOTE: If you reside in one of our Philips Factory Service Branch areas (see directory on back), you can contact the nearest Service Branch to
obtain efficient and expedient repair for your product. If your product is In-Warranty, you should have proof-of-purchase to ensure No Charge
Service. For Out-of-Warranty service, call the location nearest you.

NOTA: Si vous résidez dans une des régions desservies par une succursale de service après vente du fabricant Philips (voir liste ci-dessous), vous
pourrez contacter la branche de service après vente la plus près de chez vous pour obtenir un service après vente rapide et efficace. Si le produit
est sous garantie, il suffira de présenter une preuve d`achat pour bénéficier d'un service sans frais. Pour les produits non couverts par la garantie,
contactez le centre le plus près de chez vous.

NOTA: Si Ud. reside en una de nuestras zonas para sucursales Philips de servicio al de fábrica (ver directorio más abajo), Ud. puede comunicarse
con la sucursal de servicio más cercana para obtener una reparación oportuna y eficaz de su producto. Si su producto está todavía bajo garantía,
Ud. debe presentar comprobante de compra para no ocasionar ningunos cargos por servicio. Para servicio después del vencimiento de la
garantía, llame al lugar más cercano de los abajo indicados.

Philips Consumer Electronics Company

Factory Service Center Locations

In Canada

How you can obtain efficient and expedient carry-in, mail-in, or in-home service for your product
Please contact Philips at 1-800-661-6162 (French speaking)

1-800-363-7278 (English speaking)

Au Canada

Comment obtenir le service après-vente pour les produits apportés ou envoyés par la poste à notre centre de service ou le service à domicile
Veuillez contacter philips á: 1-800-661-6162 (Francophone)

1-800-363-7278

En el Canadá

Cómo recibir servicio efficiente para su producto, en persona, por correo o a domicillo
Favor de comunicarse con Philips al: 1-800-661-6162 (francófono)

1-800-363-7278 (anglófono)

58

EL4482-3 Rev. AA

3135 015 07541

MAC2929 12/98

QUALITY SERVICE IS AS CLOSE AS YOUR TELEPHONE! SIMPLY LOOK OVER THE LIST BELOW FOR THE NUMBER OF A FACTORY SERVICE CENTER

NEAR YOU

. YOUR PRODUCT WILL RECEIVE EFFICIENT AND EXPEDIENT CARRY-IN, MAIL-IN, OR IN-HOME SERVICE, AND YOU WILL RECEIVE PEACE OF MIND,

KNOWING YOUR PRODUCT IS BEING GIVEN THE EXPERT ATTENTION OF PHILIPS’ FACTORY SERVICE. AND, IF THE PHONE NUMBER LISTED FOR YOUR AREA

IS LONG DISTANCE

, CALL 1-800-242-9225 FOR FACTORY SERVICE.

COMMENT OBTENIR NOTRE SERVICE APRÈS VENTE RAPIDE ET EFFICACE SOIT PAR COURRIER, À DOMICILE, OU EN SE PRÉSENTANT À UN CENTRE DE SERVICE PHILIPS. PLUS DE 600 CENTRES DE

RÉCEPTION DE PRODUITS À RÉPARER À TRAVERS LE PAYS: CONTACTER LE CENTRE DE SERVICE AUX CONSOMMATEURS LE PLUS PROCHE POUR SAVOIR L’EMPLACEMENT DE CES DÉPOTS DANS

UN RAYON DE 50 À 75 MILES (80 KM À 120 KM) DU CENTRE DE SERVICE LOCAL.

CÓMO OBTENER UN SERVICIO OPORTUNO Y EFICIENTE POR CORREO, EN CASA O EN PERSONA PARA SU PRODUCTO A TRAVÉS DE UN CENTRO PHILIPS DE SERVICIO. MAS DE 600 SITIOS POR

TODO EL PAIS PARA LA RECEPCION DE PRODUCTOS NECESITADOS DE REPARACIONES: COMUNICARSE CON EL CENTRO DE SERVICIO DE FABRICA MAS CERCANO PARA ESTOS LUGARES DENTRO

DE UN RADIO DE 80 A 120 KM (50 A 75 MILLAS) DEL CENTRO DE SERVICIO LOCAL.

GEORGIA

Philips Factory Service of Georgia
200 N. Cobb Pkwy., Suite 120
Marietta, GA 30062
[phone]

FLORIDA

Philips Factory Service of Florida
1911 US Highway 301 North
Tampa, FL 33619
[phone]

WESTERN U.S.A.

Philips Factory Service Western Region
681 East Brokaw Rd.
San Jose, CA 95112
[phone]

TEXAS

Philips Factory Service of Texas
1110 N. Post Oak Rd., Suite 100
Houston, TX 77055
[phone]

CENTRAL U.S.A.

Philips Factory Service Central US
950 Keynote Circle
Brooklyn Heights, OH 44131
[phone]

MICHIGAN

Philips Factory Service of Michigan
25173 Dequindre
Madison Heights, MI 48071
[phone]

DALLAS AREA

Philips Factory Service of Dallas
415 N. Main Street, #107
Euless, TX 76040
[phone]

ILLINOIS

Philips Factory Service of Illinois
1279 W. Hamilton Pkwy.
Itasca, IL 60143
[phone]

TENNESSEE

Philips Factory Service of East Tennessee
6700 D Papermill Rd.
Knoxville, TN 37919
[phone]

MID-ATLANTIC

Philips Factory Service Mid-Atlantic
352 Dunks Ferry Rd.
Bensalem, PA 19020
[phone]

59

MAC2929 1/99

DIGITAL PROJECTION TELEVISION

One Year Free Labor

One Year Free Service on Parts

Two Years Free Service on Cathode Ray Tube Parts / 30 days Free Service on Projection TV Screen

This product can be repaired in-home.

LIMITED WARRANTY

WHO IS COVERED?

You must have proof of purchase to receive warranty service. A sales
receipt or other document showing that you purchased the product is
considered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product. for one year
thereafter (30 days for the digital projection TV screen), all parts will be
repaired or replaced, and labor and transportation are free. From one to
two years from the day of purchase, you pay for the replacement or
repair of all parts except the cathode ray tube and the “Clear-Vu” lens,
and for all labor and transportation charges. After two years from the day
of purchase, you pay for the replacement or repair of all parts except the
“Clear-Vu” lens (which is guaranteed against manufacturer’s defects for
the life of the product), and for all labor and transportation charges.

All parts, including repaired and replaced parts, are covered only for
the original warranty period. When the warranty on the product
expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

• labor charges for installation or setup of the product, adjustment of
customer controls on the product, and installation or repair of
antenna systems outside of the product.

• product repair and/or part replacement because of misuse,
accident, unauthorized repair or other cause not within the control
of Philips Consumer Electronics Company.

• reception problems caused by signal conditions or cable or antenna
systems outside the unit.

• a product that requires modification or adaptation to enable it to
operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair of
products damaged by these modifications.

• incidental or consequential damages resulting from the product.
(Some states do not allow the exclusion of incidental or
consequential damages, so the above exclusion may not apply to
you. This includes, but is not limited to, prerecorded material,
whether copyrighted or not copyrighted.)

• a product used for commercial or institutional purposes.

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is
officially distributed by Philips Consumer Electronics Company. In
countries where Philips Consumer Electronics Company does not
distribute the product, the local Philips service organization will attempt
to provide service (although there may be a delay if the appropriate
spare parts and technical manual(s) are not readily available).

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of
purchase. Attach it to this owner’s manual and keep both nearby. Also
keep the original box and packing material in case you need to return
your product.

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service.
Adjustments of the controls discussed there may save you a service
call.

TO GET WARRANTY SERVICE...

Repair must be performed by an authorized service center or a factory
service center. If you do not live near a factory service center, contact your
dealer. If your dealer is an authorized service center, he will arrange
repair. If your dealer is not an authorized service center, he will direct
you to the authorized service center engaged by him to service the
products he sells.

(In U.S.A., Puerto Rico and U.S. Virgin Islands, all implied warranties,
including implied warranties of merchantability and fitness for a
particular purpose, are limited in duration to the duration of this
express warranty. But, because some states do not allow limitations on
how long an implied warranty may last, this limitation may not apply to
you.)

(In Canada, this warranty is given in lieu of all other warranties. No
other warranties are expressed or implied, including any implied
warranties of merchantability or fitness for a particular purpose. Philips
is not liable under any circumstances for any direct, indirect, special,
incidental or consequential damages, howsoever incurred, even if
notified of the possibility of such damages.)

IF YOU HAVE QUESTIONS...

Please contact Philips at:

1-800-661-6162 (French Speaking)
1-800-363-7278 (English Speaking)

REMEMBER...

Please record the model and serial numbers found on the product
below. Also, please fill out and mail your warranty registration card
promptly. It will be easier for us to notify you if necessary.

MODEL # ________________________________________________
SERIAL # ________________________________________________

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

Philips Service Company, P.O. Box 2976, Longview, Texas 75606, [phone]

60

3135 015 16091
