Philips 60PW9383, 60PW9383/17, 55PW9383/17, 55PW9383 - 2, 60PW9383 - 2 Directions For Use Manual

3135 035 21401

55PW9383
60PW9383

Product Highlights

• High-definition display—1080i/480p

• Philips HD Optics

• Auto IntelliSense

™

Focus

• HD DVI and Component Inputs

• Active Control

™

•Eye Fidelity—selectable progressive or
interlaced scan

•APAC

™

(Automatic Phosphor Aging

Compensation)

Features

• Multipoint digital convergence

•Protective screen filter

• Virtual Dolby

®

Surround—30-watt RMS

• 3-D Y/C comb filter

• Double-window, two-tuner
picture-in-picture

• Slim, upscale styling

• Home-cinema universal remote
with backlighting

Rear-projection

Rear-projection

HDTV Monitor

HDTV Monitor

2

Once your PHILIPS purchase is registered, you’re eligible to receive all the privileges of owning a
PHILIPS product. So complete and return the Warranty Registration Card enclosed with your pur-

chase at once. And take advantage of these important benefits.

Return your Warranty Registration card today to ensure you

receive all the benefits you’re entitled to.

Congratulations

on your

purchase,

and welcome to the

“family!”

Dear PHILIPS product owner:

Thank you for your confidence in PHILIPS. You’ve selected one of the best-built, best-backed prod­ucts available today. And we’ll do everything in our power to keep you happy with your purchase
for many years to come.

As a member of the PHILIPS “family,” you’re entitled to protection by one of the most comprehensive
warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which
you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome–and thanks for investing in a PHILIPS product.

Sincerely,

Lawrence J. Blanford
President and Chief Executive Officer

Know these

safetysymbols

t This “bolt of lightning” indicates uninsulated material within your unit may cause an electri-

cal shock. For the safety of everyone in your household, please do not remove product covering.

s The “exclamation point” calls attention to features for which you should read the enclosed

literature closely to prevent operating and maintenance problems.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT

TO RAIN OR MOISTURE.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert.
ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la

borne correspondante de la prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Warranty

Verification

Registering your product within
10 days confirms your right to
maximum protection under the
terms and conditions of your
PHILIPS warranty.

Owner

Confirmation

Your completed Warranty
Registration Card serves as
verification of ownership in the
event of product theft or loss.

Model

Registration

Returning your Warranty
Registration Card right away guar­antees you’ll receive all the infor­mation and special offers which
you qualify for as the owner of your
model.

P.S. Remember, to get the most from your PHILIPS

product, you must return your
Warranty Registration Card within 10 days. So
please mail it to us right now!

R

E

G

I

S

T

R

A

T

I

O

N

N

E

E

D

E

D

W

I

T

H

I

N

1

0

D

A

Y

S

Hurry!

Visit our World Wide Web Site at http://www.philips.com

3

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in

accordance with the manufacturers instructions.

8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.

9. Do not defeat the safety purpose of the polarized or ground­ing-type plug. Apolarized plug has two blades with one
wider than the other. A grounding type plug has two blades
and third grounding prong. The wide blade or third prong
are provided for your safety. When the provided plug does
not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.

10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11. Only use attachments/accessories specified by the manu­facturer.

12. Use only with a cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the ap-

p- paratus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from
tip-over.

13. Unplug this apparatus during lightning storms or when
unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

15. This product may contain lead and mercury. Disposal of
these materials may be regulated due to environmental con­siderations. For disposal or recycling information, please
contact your local authorities or the Electronic Industries

Alliance: www.eiae.org

16. Damage Requiring Service - The appliance should be
serviced by qualified service personnel when:

A. The power supply cord or the plug has been damaged;

or

B. Objects have fallen, or liquid has been spilled into the

appliance; or

C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or

exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure

damaged.

17. Tilt/Stability - All televisions must comply with recommend­ed international global safety standards for tilt and stability
properties of its cabinet design.

• Do not compromise these design standards by applying
excessive pull force to the front, or top, of the cabinet which
could ultimately overturn the product.

• Also, do not endanger yourself, or children, by placing
electronic equipment/toys on the top of the cabinet. Such
items could unsuspectingly fall from the top of the set and
cause product damage and/or personal injury.

18. Wall or Ceiling Mounting - The appliance should be
mounted to a wall or ceiling only as recommended by the
manufacturer.

19. Power Lines - An outdoor antenna should be located away
from power lines.

20. Outdoor Antenna Grounding - If an outside antenna is
connected to the receiver, be sure the antenna system is
grounded so as to provide some protection against voltage
surges and built up static charges.

Section 810 of the National Electric Code, ANSI/NFPANo.
70-1984, provides information with respect to proper
grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding connectors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for
the grounding electrode. See Figure below.

21. Object and Liquid Entry - Care should be taken so that
objects do not fall and liquids are not spilled into the enclo­sure through openings.

Example of Antenna Grounding
as per NEC - National Electric Code

Note to the CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides

guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close
to the point of cable entry as practical.

Rev. 8/13/01

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMP

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

(NEC SECTION 810-20)

Refer to the simple Quick Use and Setup Guide (supplied with your
TV) for details on the following:

• Basic TV connections

•Television and remote-control operation

• On-screen menu controls

• Installation features.

Selecting the Stereo/Mono Sound Mode . . . . . . . . . . . . . .38

Selecting the SAP (Second Audio Program) Feature . . . . .39

Using the Bass Boost Control . . . . . . . . . . . . . . . . . . . . . .40

FEATURES

The Timer

Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Displaying the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Setting the Timer’s Start Time and Stop Time . . . . . . . . .43

Selecting the Timer’s Channel . . . . . . . . . . . . . . . . . . . . .44

Setting the Timer’s Activate Control . . . . . . . . . . . . . . . .45

AutoLock™

Understanding AutoLock™ . . . . . . . . . . . . . . . . . . . . . . .46

Setting up the AutoLock™ Access Code . . . . . . . . . . . . .47

Using AutoLock™ to Block Channels . . . . . . . . . . . . . . .48

Using AutoLock™ to Block by Movie Rating . . . . . . . . .49

Using AutoLock™ to Block by TV Rating . . . . . . . . . . .50

Turning the AutoLock™ Blocking Control

on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Using AutoLock™ to Block Unrated Broadcasts . . . . . . .52

Using AutoLock™ to Block Broadcasts That

Have No Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Reviewing Your Current AutoLock™ Settings . . . . . . . . .54

Using the Closed Captioning Control . . . . . . . . . . . . . . . . .55

Using the Picture-format Control . . . . . . . . . . . . . . . . .56–57

Using Active Control™ . . . . . . . . . . . . . . . . . . . . . . . . . . .58

APPENDIXES

Appendix A: Compatibility Information

for the TV’s High-definition Inputs . . . . . . . . . .59

Appendix B: Model Specifications . . . . . . . . . . . . . . . . . . .60

Appendix C: Setting Color Space for HD INPUT-AV 4 . . . .61

GENERAL INFORMATION

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63–64

Glossary of Television Terms . . . . . . . . . . . . . . . . . . . . . . .65

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Factory Service Locations . . . . . . . . . . . . . . . . . . . . . .67–68

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

CONTENTS

Items Included with This TV

As you unpack your TV, please note that this Directions for Use manual
contains safety-tip information, the locations of factory-service centers, a
warranty registration card, remote control, and batteries for the remote
control. Please take a few minutes to complete your registration card. The
serial number for the TV is on the rear of the set. Refer to page 62 for
cleaning and care instructions.

INTRODUCTION

Welcome/Registration of Your TV . . . . . . . . . . . . . . . . . . . .2

Safety/Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2–3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

CONNECTING ACCESSORY DEVICES

TO

YOUR TV

Panel Overview: Standard Inputs and Outputs . . . . . . . . . . .6

Panel Overview: High-definition Inputs . . . . . . . . . . . . . . . .7

Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting a VCR and Cable Box . . . . . . . . . . . . . . . . . . . .9

Connecting and Using an Audio Hi-fi System

with Your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Making Optional Surround-sound Connections . . . . . . . . .11

Connecting a Standard DVD Player . . . . . . . . . . . . . . . . . .12

Connecting an S-Video Device . . . . . . . . . . . . . . . . . . . . .13

Connecting a DVD Player with Progressive-scan

Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Connecting an HD Receiver to the

HD INPUT-AV 4 Jacks . . . . . . . . . . . . . . . . . . . . . . . . . .15

Connecting a Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . .16

Connecting and Using Headphones

with Your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

USING THE REMOTE CONTROL

Programming the TV Remote to Work

with Accessory Devices . . . . . . . . . . . . . . . . . . . . .18

Using the Code-entry Method to Program Your

TV Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Using the Search Method to Program Your

TV Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Direct-entry Codes for A/V Accessory Devices . . . . . .21–22

Using the TV Remote with Accessory Devices . . . . . . . . .23

Using the AV and Source Select Buttons . . . . . . . . . . . . . .24

Using AutoSound™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Using AutoPicture™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Using AutoSurf™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Using Program List and Alternate Channel (A/CH) . . . . . .28

Using the Sleep Timer Control . . . . . . . . . . . . . . . . . . . . . .29

USING THE ON-SCREEN SUBMENUS


Adjusting the Picture Controls . . . . . . . . . . . . . . .30

Setting the Eye Fidelity Control . . . . . . . . . . . . . . . . . . . . .31

Setting the Dynamic Contrast Control . . . . . . . . . . . . . . . .32

Adjusting the Manual Converge Controls:

Converge Red/Blue . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Adjusting the Manual Converge Controls:

Multipoint Red/Blue . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

SOUND

Adjusting the Treble, Bass, and

Balance Controls . . . . . . . . . . . . . . . . . . . . . . . .35

Using the AVL (Audio Volume Leveler) Control . . . . . . . .36

Selecting the Surround-sound Modes . . . . . . . . . . . . . . . . .37

QUICK USE AND SETUP GUIDE

4

POWER

ACC

TV

VCR

ACTIVE

FREEZE

SWAP PIP CH

CONTROL

DN

UP


SOUND

MENU/

STATUS/

SELECT

EXIT

ppendixes

BC

A

5

FEATURES

Yo ur new projection television and its packaging contain materials
that can be recycled and reused. Specialized companies can recy­cle your product to increase the amount of reusable materials and
minimize the amounts that need to be properly disposed. The bat­teries used by your product should not be thrown away when
depleted but should be handed in and disposed of as small chemi­cal waste. Please find out about the local regulations concerning
how to dispose of your old television, batteries, and packaging

End-of-life Disposal

Philips HD Optics gives extreme resolution HD with cutting-edge

processing and display technology. Includes a Philips wideband
video amplifier, microphosphor CRTs, hybrid projection lenses,
first-surface mirror, and fine-pitched lenticular screen.

Auto IntelliSense™ Focus automatically adjusts picture conver-

gence at the push of a button. After reviewing a special test pat­tern, optical sensors send position information to the controller,
which then corrects the pictures. Auto IntelliSense™ Focus
responds to the natural and man-made magnetic field conditions
where the TV is located, so you will always enjoy the best possible
picture.

Automatic Phosphor Aging Compensation (APAC) works with

the set’s Automatic Format feature to prevent screen burn left by
nonmoving images. Periodically, APAC automatically shifts your
television picture in very small increments, but in increments large
enough to blur image retention. APAC is like a screen saver for
your TV.

Active Control™ continuously measures and corrects all incoming

signals to provide the best picture settings. This feature provides a
sharp and virtually noise-free picture any time, from any NTSC
source. NTSC is the

National Television Standards Committee for­mat devised in the 1940s for TV broadcast analog video signals
(525 lines: 30 Hz).

Eye Fidelity gives you a choice between two different picture-

scanning techniques—progressive and interlaced. Progressive scan
doubles the number of visible picture lines per field by displaying
all picture frame lines at once, eliminating line flicker. The inter­laced mode provides for a double vertical display (interlaced) of
progressive scan, which reduces annoying motion artifacts. The
Interlaced mode also helps smooth out jagged lines sometimes
seen on curved and angled surfaces.

Protective screen filter helps prevent accidental damage to the

delicate front lenticular screen. This filter has been specifically for­mulated by Philips for HD displays to give the best possible pic­ture and still protect your investment.

HD DVI and Component Inputs—DVI supports High-definition

Copy Protected digital video input for connection to compliant set­top boxes. The HD component connection (Y Pb Pr or RGB +HV0
offers color purity, crisp color detail, and reduced color noise.

3-D Y/C Digital Comb Filter (activated when using the tuner and

composite inputs) processes the video with spatial and temporal
filtering, virtually eliminating cross-color and cross-luminance
interference, improving video resolution. This filter uses extensive
memory to analyze complete video fields, significantly reducing
“dot crawl,” “hanging dots,” and “barber pole artifacts” on the
image.

Double-window, two-tuner Picture-in-Picture (PIP) allows you

to watch two shows, side by side. No VCR is necessary for tuning
PIP pictures. Your set’s two separate tuners let you select two
shows and display both in windows of equal proportion.

Virtual Dolby* Surround (referred to as Dolby Virtual in the
on-screen submenu) uses two speakers to simulate the surround

effect produced by a multichannel system.

Incredible Surround™ enhances stereo programs by making the

sound broader and fuller.

Center channel input, which has standard clip-on style speaker

connectors, simplifies the connection of surround-sound equipment
for optimal home-theater enjoyment. Since it contains the dialog
information, the center channel is vitally important to the overall
performance of any large screen in a home-theater system.

Home-cinema universal remote control operates your TV set and

other devices that work by infrared remote control, such as VCRs,

cable converter boxes, satellite receivers, and others. Note:You may

need to program the remote to work with devices other than the TV.
See pages 18–23.

Hi-fi stereo system, including a built-in audio amplifier and a twin

speaker system with 2-inch tweeters and 5-inch woofers. The sys­tem enables you to hear stereo sound or Second Audio Program
(SAP) bilingual broadcasts when they are available.

Audio/video jacks allow direct connections with VCRs and other

accessories for quality TV picture and sound playback. Component
video input jacks are provided for high-fidelity color and picture
resolution when using digital video source material, such as a DVD.

Audio Volume Leveler (AVL) control keeps the TV’s sound at an

even level. Peaks and valleys that occur during program changes or
commercial breaks are reduced, making for a more consistent, com­fortable sound.

AutoChron™ automatically sets the right time of day and main-

tains it with digital precision through brownouts, power failures,
and even Daylight Savings Time adjustments.

AutoLock™ protects young children from objectionable program-

ming with V-chip technology.

AutoSound™ allows you to select from three factory-set controls

and a personal control that you set according to your own prefer­ences through the on-screen Sound submenu. The three factory-set
controls—Voice, Music, and Theatre—enable you to tailor the TV
sound to enhance the particular programming you are watching.

AutoSurf™ allows you to easily switch among only the channels

that are of interest to you. You can program up to 10 channels into
the TV’s AutoSurf™ memory through the on-screen display.

Channel Edit allows you to add or remove channels from the list of

channels stored in the TV’s memory. Channel Edit makes it easy to
limit or expand the number of channels that are available to you
when you press the CH +/– buttons on your remote control.

Closed Captioning allows you to read TV program dialog or voice

conversations as on-screen text.

Dynamic Contrast helps sharpen the picture quality by making the

contrast between the dark and bright picture areas more noticeable
as the image on screen changes.

As an Energy Star® Partner, Philips Consumer Electronics has
determined this product meets the Energy Star® guidelines for
energy efficiency. Energy Star® is a U.S. registered mark. Using
products with the Energy Star® label can save energy. Saving
energy reduces air pollution and lowers utility bills.

*Manufactured under license from Dolby Laboratories. “Dolby” and the
double-D symbol are trademarks of Dolby Laboratories.

Active Control, APAC, AutoPicture, AutoSound, AutoSurf, Incredible
Surround, and IntelliSense are trademarks of Philips Consumer Electronics.
Copyright 2003 Philips Consumer Electronics. All rights reserved.

6

Connecting Accessory Devices to Your TV

Y

ou can connect a wide range of video and

audio devices to your TV, in various ways.
This page and the next one provide an overview
of signal compatibilities and the types of
devices you can connect to the jacks.
Connection examples follow on subsequent
pages. See pages 1 and 2 of the Quick Use and
Setup Guide that came with your set for exam­ples of basic connections. You may also want to
refer to the user instructions that came with
each particular device for information on con­nections.

What You Can Connect to the

Standard Panel Jacks

1

ANTENNA IN 75Ω jack—use to con-

nect radio-frequency (RF) signals from
VHF/UHF antennas or a cable system.
These are 480i signals.

2

YPbPr (component video input [CVI]
jacks)—compatible with 480i signals

only. Use to connect accessories having
component video outputs, such as DVD
players, laser-disc players, video-game
players, satellite receivers, or other
devices. Use the INPUT-AV 1 L(eft) and
R(ight) AUDIO jacks for sound connec­tions. CVI is not accessible in the PIP
window.

3

S-VIDEO (super video) jacks—com-

patible with 480i signals only. Use to
connect accessories having Super VHS
(S-VHS) outputs, such as VCRs, DVD
players, laser-disc players, video-game
players, satellite receivers, or other
devices.

4

VIDEO (composite) jacks (INPUT-AV

1,
INPUT-AV 2, and TV’s side jack panel
[AV3])—compatible with 480i signals

only. Use to connect accessories having
composite video outputs, such as VCRs,
video-game players, or other devices.

5

AUDIO inputs (INPUT-AV 1,
INPUT-AV 2, and TV’s side jack panel
[AV3])—use to connect from the audio

output jacks on VCRs, DVDs, or other
accessories.

6

OUTPUT (VIDEO/AUDIO)—video is

compatible with 480i signals only. Use to
connect to a VCR to record programs
from the TV. Or use the AUDIO outputs
to connect to an audio hi-fi system.

7

AMP SWITCH, CENTER
CHANNEL AMP INPUT, and
SUBWOOFER Output—use to make

optional surround-sound connections
(see page 11).

8

n Headphone jack—use to connect

headphones for personal listening.

PANEL OVERVIEW

:STANDARD INPUTS AND OUTPUTS

The side jack-panel inputs (recognized by the
TV as AV3) are convenient for connecting a
camcorder. See page 16.

cc

C

HECK IT OUT

Summary of signal compatibilities

TV Input

Compatible output signal

from an external source

or device

ANTENNA IN 75Ω, INPUT AV-1,YPbPr
(component video inputs [CVI]),
INPUT AV-2, and side jack panel (AV3)

480i (480 lines, interlaced)

Signal sources connected to the
HD INPUT-AV 4 or HD INPUT-AV 5 jacks
will provide the best picture (see page 7 for
descriptions of those inputs). Among the
standard (480i-compatible) inputs—
ANTENNA IN 75Ω, INPUT AV-1, CVI
[labeled Y, Pb, Pr], INPUT AV-2, and the
side jack panel [AV3])—the best picture
will come from signal sources connected to
the CVI jacks. S-Video will provide the

HELPFUL HINTS

ANTENNA IN 75Ω

1

4

S-VIDEO

L

3

5

Side Jack Panel

4

G

8

NOTE: The
TV recognizes
the side jack
panel as AV3.

AMP SWITCH

EXT INT

+

CENTER CHANNEL AMP INPUT

6

INPUT-AV 1

VIDEO

AUDIO

Y

Pb

L

Pr

R

7

_

DVI

4

INPUT-AV 2 SUBWOOFEROUTPUT

VIDEO

S-VIDEO

L

L

AUDIO

R

2

3

5

3

5

Rear of TV

HD INPUT-AV 5

HD INPUT-AV 4

G/Y

R/Pr

B/Pb

7

V

L

SYNC

AUDIO

H

R

AUDIO

L

R

7

Connecting Accessory Devices to Your TV

PANEL OVERVIEW

:HIGH-DEFINITION INPUTS

What You Can Connect to the

High-definition Input Jacks

1

HD INPUT-AV 4—use to connect dig-

ital equipment with a 1080i or a 480p
signal output, such as HD receivers
(1080i or 480p) or DVD players with
progressive-scan capability (480p). You
can connect equipment with YPbPr
component video or RGB outputs to
the HD INPUT-AV 4 jacks. H and V
sync connections may or may not be
required for RGB connections. (See
page 59.) Dedicated audio input jacks
are located with the HD INPUT-AV 4
video jacks.

NOTE: The Picture-in-Picture (PIP)

feature is not available for use with AV 4.

2

HD INPUT-AV 5—use to connect digi-

tal equipment with DVI (digital video
interface) 1080i or 480p output. DVI is
a specific digital input allowing encrypt­ed transmission of uncompressed HD
content. DVI includes HDCP (high­bandwidth digital content protection),
which is supported by Hollywood,
satellite providers, and most of the con­sumer electronics industry. DVI is gain­ing momentum and quickly becoming
an industry standard for the consumer to
view high-definition material while keep­ing content protected.

NOTE: The Picture-in-Picture (PIP)

feature is not available for use with AV5.

Summary of signal compatibilities

TV Input

Compatible output signal

from an external source

or device

HD INPUT-AV 4

1080i (1080 lines, interlaced) or
480p (480 lines, progressive scan)

• The TV’s default color-space setting for HD
INPUT-AV 4 is YPbPr. If the picture looks
grossly incorrect, try changing the color-space
setting on either the digital equipment or the
TV. For more information on setting the color
space on the digital equipment, see the equip­ment’s directions-for-use manual. To set the
TV’s color space, see page 61 in this manual.

• This television is designed to be compatible
with high-definition signal standards 1080i
and 480p as specified by the Electronic
Industries Association standard EIA770.3.
Because output standards may vary by manu­facturer, you may encounter some digital
equipment that will not properly display pic-

tures on the TV.

•The PIP (Picture-in-picture) feature

allows you
to tune to a program in the main window and
scan other channels in the PIP window. From a
single antenna or cable input, signals are separat­ed into two signals within the television. The
AV1, AV2, and AV3 inputs are also available as
PIP sources.

HELPFUL HINTS

HD INPUT-AV 5

Digital video interface (DVI) with
1080i (1080 lines, interlaced) or
480p (480 lines, progressive scan)

Because DVI is such new technology, the elec­tronics industry is still working toward a deci­sion on one standard. Philips testing has deter­mined that compatibility issues exist with
respect to a limited number of high-definition
receivers when they are connected to the DVI
input on this television. If you should experi­ence difficulties, please contact our Customer
Care Center at 1-800-531-0039.

HELPFUL HINT

ANTENNA IN 75Ω

VIDEO

S-VIDEO

L

AMP SWITCH

EXT INT

+

CENTER CHANNEL AMP INPUT

INPUT-AV 1

L

AUDIO

R

_

Y

Pb

Pr

Rear of TV

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

SYNC

R/Pr

B/Pb

V

L

AUDIO

H

R

INPUT-AV 2 SUBWOOFEROUTPUT

AUDIO

VIDEO

L

R

S-VIDEO

L

2
1

AUDIO

L

R

8

PIP ON/OFF

213
546
879
0

TV

SWAP PIP CH

DN

UP

ACTIVE

CONTROL

FREEZE

SOUND

MUTE

SURF

A/CH

POWER


STATUS/

EXIT

SURF

SLEEP

REC •

VCR

ACC

MENU/
SELECT

VOL

CH

TV/VCR

FORMAT

SAP

PROG.LISTDOLBY VAV

5

AV1

T

he TV’s audio/video (AV) input jacks provide

for direct picture and sound connections
between the TV and accessory devices such as
VCRs, DVD players, and others that have AV out­put jacks.

This example, which uses the INPUT-AV 1 jacks,
shows you one way to connect a VCR to your TV.

Refer to the directions-for-use manual for your
VCR for further information on connections.

To make the connections shown in this example,
you will need:

• one coaxial cable (75Ω)

• one cable for a video connection (standard

RCA connector)

•two cables for audio connections (standard

RCA connectors) (only one cable is needed for
a nonstereo VCR).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect a cable TV or antenna signal to

the ANT IN jack on the rear of the VCR.

2

Connect from the OUT jack on the rear

of the VCR to the

ANTENNA IN 75Ω

jack on the rear of the TV.

3

Connect the VIDEO OUT jack on the

rear of the VCR to the INPUT AV1
VIDEO jack on the rear of the TV.

4

Connect the audio output R(ight) and
L(eft) jacks on the rear of the VCR to the

INPUT-AV 1 AUDIO jacks on the rear of
the TV.

NOTE: If the VCR is a mono (nonstereo)

unit, connect only the left audio cable,
which usually has a white connector.

5

Press the AV button on the remote con­trol as many times as necessary to select

the AV1 source for the viewing of materi­als from your VCR.

Connecting Accessory Devices to Your TV

CONNECTING A VCR

You can display the AV1, AV2, or AV3 signal
sources in the PIP window. See page 8 of the

Quick Use and Setup Guide for information on

cc

C

HECK IT OUT

• Stereo sound will pass from the ANT
OUT jack on the VCR to the ANTENNA
IN 75Ω jack on the TV only when the
VCR is in TV mode. This is the mode
that allows the TV to use its channel
selector.

•To simplify making connections, audio
and video cables often have color-coded
plugs. The jacks on your TV are likewise
color coded to match the plugs. The cod­ing is as follows:
—Yellow for video (composite)
—Red for the right audio channel
—White for the left audio channel

NOTE: If your VCR is mono (non-

stereo), you will connect only one audio
cable. You must ensure that the TV is set
to MONO for the signal source to which
you’ve connected the VCR (

INPUT-AV

1,
INPUT-AV2, or the side panel inputs
[AV3]). Otherwise, you will receive
sound from only one of the TV’s speakers.
See page 38.

HELPFUL

HINTS

ANTENNA IN 75Ω

2

CENTER CHANNEL AMP INPUT

3

VIDEO

S-VIDEO

L

L

AUDIO

R

Rear of VCR*

* (Example: Philips VCR
model VR674CAT)

AMP SWITCH

EXT INT

+

Y

Pb

Pr

4

Rear of TV

_

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

R/Pr

B/Pb

V

L

L

SYNC

AUDIO

H

R

AUDIO

R

Cable TV Company

or VHF/UHF Antenna

Coaxial Cable

Lead-in from

AUDIO

INPUT-AV 2 SUBWOOFEROUTPUTINPUT-AV 1

VIDEO

S-VIDEO

L

L

R

1

AUDIO

L

ANT

IN

IN

OUT

R

VIDEO

OUT

CH3 CH4

IN

OUT

9

CONNECTING A VCR

AND CABLE BOX

P

resented here is a connection example

involving a VCR and cable box.

Refer to the VCR’s directions-for-use manual
for further information on connections.

To make the connections in this example, you
will need:

• one, two-way signal splitter

•two coaxial cables (75Ω)

• one cable for a video connection (standard
RCA connector)

•two cables for audio connections (standard
RCA connectors) (only one cable is needed
for connection to a nonstereo VCR).

NOTE: The cables are not supplied with your
TV. You should be able to buy them at most
stores that sell electronics. Or you can call
our Customer Care Center at
1-800-531-0039.

1

Connect a cable TV signal to a two-

way signal splitter.

2

Connect one of the two-way signal
splitter outputs to the INPUT on the

cable box.

3

Connect the other two-way signal
splitter output to the ANTENNA IN

75Ω on the rear of the TV.

4

Connect from the cable box OUTPUT
jack to the ANT IN jack on the rear of

the VCR.

5

Connect the VIDEO OUT jack on
the VCR to the INPUT-AV 1 VIDEO

jack on the rear of the TV.

6

Connect the AUDIO OUT R(ight)
and L(eft) jacks on the VCR to

INPUT-AV 1 AUDIO jacks on the rear
of the TV.

NOTE: If the VCR is a nonstereo unit,

connect only the left audio cable,
which usually has a white connector.

7

Press the AV button on the remote
control as many times as necessary

to select the AV1 source for the view­ing of materials from your VCR.

Connecting Accessory Devices to Your TV

• The RF output on a cable box, usually
labeled “OUTPUT,” “OUT,” or “TO TV,”
will not pass a stereo sound signal to the
ANTENNA IN 75Ω jack on the TV. If, how­ever, your cable box has separate
Audio/Video outputs, using A/V cables to
connect to those outputs and to the A/V
inputs on the TV might pass a stereo sound
signal to the TV. Contact your cable TV
company for more information.

•To simplify making connections, the plugs
on audio and video cables are often color
coded. The jacks on your TV are likewise
color coded to match the plugs.
The coding is as follows:
—Yellow for video (composite)
—Red for the right audio channel
—White for the left audio channel

NOTE: If your VCR is mono (nonstereo),

you will connect only one audio cable. You
must ensure that the TV is set to MONO for
the signal source to which you’ve connected
the VCR (INPUT-AV 2, INPUT-AV 1, or the
side panel inputs [AV3]). Otherwise, you will
receive sound from only one of the TV’s
speakers. See page 38.

HELPFUL HINTS

Rear of VCR*

* (Example: Philips
VCR model
VR674CAT)

AV1

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

7

SURF

ITR/ HOME HOME PERSONAL

ANTENNA IN 75Ω

AMP SWITCH

3

EXT INT

+

CENTER CHANNEL AMP INPUT

5

INPUT-AV 1

Y

VIDEO

POWER

ACC

VCR

ACTIVE

CONTROL

DN

REC •

SAP

FREEZE

UP


MENU/
SELECT

MUTE

FORMAT

CH

213
546
879

SURF

0

PIP ON/OFF

SLEEP

PROG.LISTDOLBY VAV

S-VIDEO

L

AUDIO

Pb

L

Pr

R

Rear of TV

_

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

6

AUDIO

INPUT-AV 2 SUBWOOFEROUTPUT

VIDEO

S-VIDEO

L

L

R

R/Pr

B/Pb

V

L

AUDIO

L

AUDIO

R

R

SYNC

H

4

AUDIO

L

ANT

IN

IN

OUT

R

VIDEO

OUT

CH3 CH4

IN

OUT

Rear of Cable Box

Two-way

Signal

Splitter

Coaxial Cable Lead-in from

1

Cable TV Company

or VHF/UHF Antenna

INPUT

OUTPUT

2

10

CONNECTING AND U

SING AN AUDIO HI-FI SYSTEM WITH YOUR TV

Y

ou can use your TV’s AUDIO OUTPUT jacks

to connect to an external audio hi-fi system.

Follow the simple steps below.
To make these connections, you will need two

cables for audio connections (standard RCA).
NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect from the L(eft) and R(ight)
AUDIO OUTPUT jacks on the rear of the

TV to the L(eft) and R(ight) AUX/TV
INPUT jacks on the rear of the hi-fi system.

2

See the section below on using the

AUDIO OUT control.

A

fter connecting the TV’s AUDIO OUTPUT

jacks to the AUDIO INPUT jacks on an
external hi-fi system, set the AUDIO OUT con­trol in the SOUND submenu to either VARI­ABLE or FIXED to determine whether you
adjust the volume at the TV or at the external
hi-fi system. To change the volume at the TV
using the TV’s remote control, you must select
VARIABLE. To adjust the volume at the stereo
using the hi-fi’s controls, you must select
FIXED. You can also use the SPEAKERS
control in the SOUND submenu to turn the
TV’s speakers off.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

once to highlight SOUND.

3

Press the CURSOR RING RIGHT

to enter the SOUND submenu.

4

Press the CURSOR RING DOWN

repeatedly until AUDIO OUT is high­lighted.

5

Press the CURSOR RING LEFT or
RIGHT to set the AUDIO OUT to

either VARIABLE or FIXED.

6

If you want to turn the TV’s internal
speakers off, press the CURSOR
RING DOWN repeatedly until

SPEAKERS is highlighted. Then press
the CURSOR RING LEFT or RIGHT
to turn the speakers off.

7

Press the STATUS/EXIT button to

exit the menu.

Connecting Accessory Devices to Your TV

The sound outputs from the TV to an exter­nal hi-fi system are not affected or tailored
by the TREBLE, BASS, BALANCE, AVL,
INCR. SURROUND, and BASS BOOST
controls in the TV’s SOUND submenu.

HELPFUL HINT

S-VIDEO

L

VIDEO

AUDIO

AMP SWITCH

EXT INT

+

CENTER CHANNEL AMP INPUT

INPUT-AV 1

L

R

Rear of TV

_

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

INPUT-AV 2 SUBWOOFEROUTPUT

Y

VIDEO

S-VIDEO

Pb

Pr

L

L

AUDIO

R

R/Pr

B/Pb

V

L

SYNC

H

L

AUDIO

AUDIO

R

R

ANTENNA IN 75Ω

1

AUX/TV INPUT

L


SOUND

FEATURES
INSTALL

R

PHONO INPUT

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

POWER

Rear

of Hi-fi

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

SOUND

5

7

2,4,

6

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

TV

VCR

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879
0

POSITION

PIP

ACC

SURF

FREEZE


MENU/
SELECT

INCR . SURROUND
HEADPHONE
STEREO
SAP

AUDIO OUT FIXED

3

OR

AUDIO OUT VARIABLE

SOUND

CH

1

HEADPHONE
STEREO
SAP

AUDIO OUT

SPEAKERS OFF

OR

SPEAKERS ON

MAKING OPTIONAL SURROUND-SOUND CONNECTIONS

Connecting Accessory Devices to Your TV

*“Dolby”, “Pro Logic”, and the double-D symbol are
trademarks of Dolby Laboratories.

Y

our TV has extra jacks that allow you to con-

nect to an external audio amplifier system and
a powered subwoofer. This connection option will
provide a surround-sound experience similar to a
movie theater or concert hall.

To make the connections shown in this example,
you will need:

•

two cables for audio connections (standard
RCA connectors)

•four paired wires for speaker connections

• one cable for a subwoofer connection

(standard RCA connectors).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect from the Center Speakers out­put jacks on the amplifier with Dolby Pro

Logic* or Dolby Digital to the correspon­ding CENTER CHANNEL INPUT jacks on
the rear of the TV. Place the TV’s AMP
switch in the EXT (external) position.

2

Connect from the L(eft) and R(ight)
AUDIO OUTPUT jacks on the rear of the

TV to the L(eft) and R(ight) TV IN jacks on
the rear of the Dolby receiver.

3

Connect from the receiver’s front and
surround speaker connectors to the front

and rear surround speakers.

4

Connect from the SUBWOOFER output
jack on the rear of the TV to the L(eft) and

R(ight) Low Level Input jacks on the rear of
the powered subwoofer.

5

Set the TV’s AUDIO OUT control to
FIXED. See page 10.

The diagram below, right shows how to arrange the
speakers and subwoofer for surround sound.

• If you use a single cable to make the connec­tion to the powered subwoofer, you will need
to increase the volume on the back of the
subwoofer to compensate for the absence of
the second cable.

•You must adjust the trim of the powered sub-

woofer at the powered subwoofer. Trim refers

H

ELPFUL HINTS

11

Front Speakers

3

ANTENNA IN 75Ω

2

AMP SWITCH

EXT INT

_

+

CENTER CHANNEL AMP INPUT

Y

VIDEO

S-VIDEO

Pb

L

L

AUDIO

Pr

R

Powered Subwoofer

ANTENNA IN 75Ω

1

Rear of Amplifier with Dolby Pro Logic or Dolby Digital

INPUT-AV 2 SUBWOOFEROUTPUTINPUT-AV 1

VIDEO

S-VIDEO

L

L

AUDIO

R

NOTE: The gray circle indicates the primary viewing area.

Speaker

AMP SWITCH

EXT INT

_

+

CENTER CHANNEL AMP INPUT

Y

VIDEO

S-VIDEO

Pb

L

L

AUDIO

Pr

R

Rear of TV

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

R/Pr

B/Pb

V

L

L

SYNC

AUDIO

AUDIO

H

R

R

Surround-sound Setup

(Center Speakers)

Front

1

Rear of TV

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

INPUT-AV 2 SUBWOOFEROUTPUTINPUT-AV 1

VIDEO

S-VIDEO

L

L

AUDIO

R

R/Pr

B/Pb

V

L

SYNC

AUDIO

H

R

Rear of Powered Subwoofer

90

150 Hz

Crossover
Frequency

TV

L

AUDIO

R

Front

Speaker

Rear Speakers

+-

110

Volume

R

+ R – – L +

-180
Phase
0

L

+

-

o

o

4

Low
Level
Input

High
Level
Input

High
Level
Output

Powered

Subwoofer

Rear

Speaker

Rear

Speaker

12

CONNECTING A STANDARD DVD PLAYER

C

omponent video inputs allow the highest pos-

sible color and picture resolution in the play­back of digital signals, such as those of DVD
players. The color difference signals (Pb, Pr) and
the luminance (Y) signal are connected and
received separately. The result is better color
bandwidth information than is possible with com­posite video (labeled VIDEO on your TV’s jack
panel) or S-Video connections.

To make the connections shown in this example,
you will need:

• three cables for video connections (standard

RCA connectors)

•two cables for audio connections (standard

RCA connectors).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect the YPbPr (component)
VIDEO OUT jacks from the DVD player

to the INPUT-AV 1 YPbPr (component
video) jacks on the rear of the TV.

NOTE:The INPUT-AV 1 YPbPr jacks
will accept 480i (interlaced) output sig­nals only. The connection example on this

page assumes the use of a DVD player
with interlaced output. Some DVD play­ers, however, have YPbPr outputs that can
be switched between interlaced and pro­gressive scan. If you are attempting to use
a DVD player with progressive-scan (480p
output) capability to make the connection
shown in this example, you must be sure
to switch the DVD player to interlaced. If
necessary, refer to the DVD player’s direc­tions-for-use manual for help. If you want
to use the DVD player in progressive-scan
mode, you must use the
HD INPUT-AV 4 jacks (see page 14).

2

Connect the AUDIO OUT L(eft) and
R(ight) jacks from the DVD player to the

INPUT-AV 1 AUDIO jacks on the rear of
the TV.

3

Press the AV button on the remote con­trol as many times as necessary to select

the CVI (component video input) source
on the TV for the viewing of materials
from your DVD player.

Connecting Accessory Devices to Your TV

•To simplify making connections, the con­nectors on audio and video cables are often
color coded. The jacks on your TV are like­wise color coded to match the connectors.

• The names for the component video jacks
may differ depending on the DVD player or
accessory digital source equipment used.
For example, besides YPbPr, you may see
R-Y/B-Y/Y; or CrCbY. Although abbrevia-

tions and terms may vary, the letters B and
R stand for the blue and red color compo­nent signal connectors, respectively, and Y

indicates the luminance signal. If necessary,
refer to the directions-for-use manual for
your DVD or digital accessory for more
information.

•You can also connect a satellite receiver to
the TV in a manner similar to the example
shown on this page. If you connect a satel­lite receiver to the TV, you will need to use
the receiver’s channel-memorization system
to store channels in the receiver’s memory.

• If you experience difficulties receiving
sound with a DVD disc, check the sound
settings through the DVD disc’s menu.

• CVI is not accessible in the PIP window.

See page 8 in the Quick Use and Setup
Guide for more on the PIP feature.

HELPFUL HINTS

To prevent uneven picture-tube aging, do not
leave nonmoving images or picture borders on
the screen for an extended period. See page 62.

WARNING

ANTENNA IN 75Ω

2

S-VIDEO

L

Rear of DVD Player*

PCM-MPEG2-Dolby Digital-DTS

COAXIAL

*(Example: Philips DVD model DVD712)

CVI

POWER

ACC

VCR

ACTIVE

CONTROL

FREEZE

UP


MENU/

SELECT

MUTE

CH

213
546
879

SURF

0

PIP ON/OFF

SLEEP

FORMAT

PROG.LISTDOLBY VAV

HOME

PERSONAL

MOVIES

PIPPOSITION

3

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

ITR/

RECORD

DN

SURF

REC •

SAP

HOME
VIDEO

CENTER CHANNEL AMP INPUT

INPUT-AV 1

VIDEO

L

AUDIO

R

DIGITAL AUDIO OUT

OPT OUT

AMP SWITCH

EXT INT

+

Y

Pb

Pr

SUB WF OUT

_

1

INPUT-AV 2 SUBWOOFEROUTPUT

VIDEO

S-VIDEO

L

L

AUDIO

R

1

2

R

AUDIO OUT

Rear of TV

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

R/Pr

B/Pb

V

SYNC

H

1

2

PR/C

L

VIDEO OUT

R

(CVBS)

VIDEO OUT

AUDIO

L

L

AUDIO

R

R

Y

B/CB

P

(Y/C)

S-VIDEO OUT

PIP ON/OFF

213
546
879
0

TV

SWAP PIP CH

DN

UP

ACTIVE

CONTROL

FREEZE

SOUND

MUTE

SURF

A/CH

POWER


STATUS/

EXIT

SURF

ITR/

RECORD

HOME
VIDEO

HOME

MOVIES

PERSONAL

SLEEP

REC •

VCR

ACC

MENU/

SELECT

VOL

CH

TV/VCR

FORMAT

SAP

PROG.LISTDOLBY VAV

3

AV2

T

he S(uper)-Video connection on the rear (and

side panel) of the TV can give you better pic­ture detail and clarity for the playback of S-VHS
VCR tapes or DVDs than the normal antenna
(RF signal) or Video (composite) picture connec­tions. The example given connects a DVD/VCR
Combi unit to the INPUT-AV 2 jacks on the rear
of the TV.

NOTE: The accessory device must have an
S-VIDEO output jack to make the connection
explained on this page.

To make the connections, you will need:

• one S-Video cable

•two cables for audio connections (standard

RCA connectors).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect the S-VIDEO OUT jack on the

rear of the accessory device with
S-VIDEO output to the INPUT-AV 2
S-VIDEO jack on the rear of the TV.

2

Connect the DVD/VCR AUDIO OUT
jacks on the rear of the accessory device

to the INPUT-AV 2 AUDIO input jacks on
the rear of the TV.

3

Press the AV button on the remote con­trol as many times as necessary to select

the AV2 source on the TV for the viewing
of materials from your S-Video device.

Connecting Accessory Devices to Your TV

CONNECTING AN S-VIDEO DEVICE

•To simplify making connections, audio
cables are often color coded: red for the
right channel, and white for the left chan­nel. The jacks on your TV are likewise
color coded to match the connectors. To
make S-Video connections, you must use
an S-Video cable.

•You can also connect a satellite receiver,
laser-disc player, video-game player, or
other accessory device with S-Video
capability to the TV in a manner similar
to the example shown on this page.

• If you connect a satellite receiver to the
TV, you will need to use the receiver’s
channel-memorization system to store
channels in the receiver’s memory.

HELPFUL HINTS

Video sources that show a constant nonmov­ing pattern on the TV screen can cause pic­ture-tube damage. When you are not using
your video accessory devices, turn them off.
Also, regularly alternate the use of accessory
video sources with normal TV viewing. See
page 62.

WARNING

13

CENTER CHANNEL AMP INPUT

INPUT-AV 1

VIDEO

L

AUDIO

R

AMP SWITCH

EXT INT

+

Y

Pb

Pr

ANTENNA IN 75Ω

S-VIDEO

L

Rear of Device with
S-VIDEO Output*

DVD/VCR

OUT

AUDIO
R

VIDEO

CH3 CH4

IN

L

DVD/VCR

AUDIO OUT

L

R

ANT-IN

ANT-OUT

*(Example: Philips DVD/VCR Combi model DV910VHS)

Rear of TV

_

HD INPUT-AV 5

DVI

HD INPUT-AV 4

G/Y

1

SYNC

R/Pr

B/Pb

V

H

L

AUDIO

R

DIGITAL AUDIO OUT
PCM / BITSTREAM

S-VIDEO

OUT

AUDIO

OPTICAL

L

R

COMPONENT

VIDEO OUT

Y

COAXIAL

Cr

Cb

AUDIO

2

INPUT-AV 2 SUBWOOFEROUTPUT

VIDEO

S-VIDEO

L

L

R

14

T

he following instructions explain how to

connect a DVD player with progressive-scan
capability to the HD INPUT-AV 4 jacks on
your TV.

To make the connections, you will need:

• three cables for video connections (standard

RCA connectors)

•two cables for audio connections (standard

RCA connectors).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect from the YPrPb jacks on

the

rear of the DVD player to the

HD INPUT-

AV 4 G/Y, R/Pr, B/Pb jacks

on the rear of the TV.

2

Connect from the L(eft) and R(ight)
AUDIO OUT jacks on the rear of the

DVD player to the HD INPUT-AV 4
AUDIO L(eft) and R(ight) jacks on the rear
of the TV

.

3

Make sure the DVD player is in pro­gressive-scan mode. You will not get a
viewable picture through the HD
INPUT-AV 4 jacks if the DVD player is
in interlaced mode.

For more information on placing your
DVD player in progressive-scan mode,
see the DVD player’s directions-for-use
manual. Also, see the Helpful Hints to
the right. The way in which progres­sive-scan mode is selected varies among
DVD players.

4

Press the AV button on your TV remote
control as many times as necessary to

select the

AV4 signal source for the view­ing of materials from your progressive­scan DVD player.

If you experience difficulties receiving
sound with a DVD disc, check the sound

HELPFUL HINT

To prevent uneven picture-tube aging, do not
leave nonmoving images or picture borders on
the screen for an extended period. See page 62.

WARNING

CONNECTING A DVD P

LAYER WITH PROGRESSIVE-SCAN CAPABILITY

Connecting Accessory Devices to Your TV

PIP ON/OFF

213
546
879
0

TV

SWAP PIP CH

DN

UP

ACTIVE

CONTROL

FREEZE

SOUND

MUTE

SURF

A/CH

POWER


STATUS/

EXIT

SURF

ITR/

RECORD

HOME
VIDEO

HOME

MOVIES

PERSONAL

SLEEP

REC •

PIPPOSITION

VCR

ACC

MENU/
SELECT

VOL

CH

TV/VCR

FORMAT

SAP

PROG.LISTDOLBY VAV

4

AV4

• If after connecting your DVD player your
display is filled with wavy lines, it may be
that your DVD player is not set to progres­sive-scan mode. Some DVD players have an
I/P (interlaced/progressive scan) switch
located on the back or front of the players for
changing from interlaced to progressive-scan
mode. Other DVD players may allow the
mode to be changed by pressing a button on
the DVD player’s remote control or by using

the DVD player’s on-screen menu. If the

interlaced/progressive-scan selection
option is provided only through the DVD
on-screen menu, you will need to connect
the DVD player to another AV input
source in addition to HD INPUT-AV 4 to
see the DVD menu. Select this additional
AV source on screen to see the DVD menu
and choose progressive-scan mode. You
will then be able to see the DVD picture
through the AV4 source.

• Some DVD players have dedicated progres­sive-scan output jacks that are labeled as
such and require no switching to provide a
picture through the HD INPUT-AV 4 jacks.
See your DVD player’s directions-for-use
manual for information.

• The default color-space setting for the
HD INPUT-AV 4 jacks is YPbPr. RGB is
also an option. If the picture’s color looks
grossly incorrect, try changing either the
DVD player’s or TV’s color-space setting.
See the DVD player’s directions-for-use
manual for information on setting its color
space. Or see page 61 in this manual to set
the TV’s color space.

•The Picture-in-Picture (PIP) feature does
not function with AV4 or AV5.

HELPFUL HINTS

CENTER CHANNEL AMP INPUT

INPUT-AV 1

VIDEO

L

AUDIO

R

AMP SWITCH

EXT INT

+

Pb

Pr

Rear of TV

_

HD INPUT-AV 5

DVI

HD INPUT-AV 4

INPUT-AV 2 SUBWOOFEROUTPUT

Y

VIDEO

S-VIDEO

L

L

AUDIO

R

AUDIO OUT

2CH

BITSTREAM

/PCM

L

R

OPTICAL

COAXIAL

DIGITAL

1

G/Y

R/Pr

AUDIO

2

L

R

AC IN ~

B/Pb

V

L

SYNC

AUDIO

H

R

ANTENNA IN 75Ω

S-VIDEO

L

VIDEO OUT

3

Rear of DVD Player with Progressive-scan Capability

Y

VIDEO

B

P

PR

SELECT

I

S

P

• HD receivers will supply stereo sound to the TV only through the audio
left and right cables, not through the coaxial cable.

• Making a standard connection along with the HD connection as shown
in the example (S-VIDEO) on this page will allow you to see the receiv­er’s on-screen menu and a picture (valid signal) from the receiver should
it be switched to SD mode.

•The HD INPUT-AV 4 jacks are for standard RCA-type phono plugs.
Your HD receiver may use RCA or BNC output jacks. If your HD
receiver comes with BNC jacks, you will need to purchase BNC-to-RCA
adapters to connect the receiver to the TV. You should be able to pur­chase these adapters at most stores that sell electronics. Or you can call
our Customer Care Center at 1-800-531-0039.

•The HD INPUT-AV 4 jacks are compatible with some digital equipment
having RGB outputs with “sync on green” or RGB with “separate H and V
sync.” Output standards for digital equipment, however, may vary by manu­facturer. No industry standards have been established for HD television RGB
signal systems, timing, synchronization, and signal strengths. If the digital
equipment you want to connect to your TV offers both component video and
RGB outputs, component video is the suggested connection to use.

• The default color-space setting for the HD INPUT-AV 4 jacks is YPbPr.
RGB is also an option. If the picture color looks grossly incorrect, try
changing either the receiver’s or TV’s color space. See the receiver’s
directions-for-use manual for information on setting its color space. Or
see page 61 in this manual for setting the TV’s AV4 color space.

•AV4 and AV5 do not function with the PIP feature. They cannot be dis­played in the PIP window, nor can the PIP window be displayed when
those signal sources are being viewed on the main screen.

15

CONNECTING AN HD R

ECEIVER TO THE HD INPUT-AV 4 JACKS

Connecting Accessory Devices to Your TV

BNC-to-

RCA

Adapter

BNC

Connector

Adapter

Fitted to

Connection

OR

RCA

Connector

D

igital equipment with a 1080i or 480p out­put, is compatible with the HD INPUT-AV 4

video jacks.
NOTE: This television is designed to be compati-

ble with high-definition signal standards 1080i
and 480p as specified by the Electronic Industries
Association standard EIA770.3. Because output
standards may vary by manufacturer, you may
encounter some digital equipment that will not
properly display pictures on the TV.

To make the connections shown in this example,
you will need:

• one S-VIDEO cable

• three cables for video connections (standard
RCA connectors)

•four cables for audio connections (standard
RCA connectors)

• one coaxial cable (75Ω).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect S-VIDEO and audio cables.
NOTE: This example uses

INPUT-AV 1. You can use INPUT-AV 2 or
the side input jacks if you want.

• Connect an S-VIDEO cable from the HD
receiver’s S-VIDEO jack to the TV’s
INPUT-AV 1 S-VIDEO jack.

• Connect from the HD receiver’s AUDIO
L(eft) and R(ight) jacks to the TV’s
INPUT-AV 1 L(eft) and R(ight) AUDIO
jacks.

2

Connect component video and audio
cables to the TV’s HD inputs.

• Connect from the YPRPB jacks on
the HD receiver to the TV’s HD
INPUT-AV 4 G/Y, R/Pr, B/Pb jacks.

• Connect from the HD receiver’s AUDIO
L(eft) and R(ight) jacks to the TV’s HD
INPUT-AV 4 L(eft) and R(ight) AUDIO
jacks.

3

Connect coaxial cables.

• Connect the coaxial cable lead-in from
your cable outlet, cable converter box, or
VHF/UHF antenna to the IN FROM
ANT jack on the HD receiver.

• Connect a coaxial cable from the OUT
TO TV jack to the ANTENNA IN 75Ω
jack on the TV.

• Connect the coaxial cable lead-in from a
satellite dish antenna to the SATELLITE
IN jack on the HD receiver.

4

Refer to the directions-for-use manual
that came with the HD receiver for setup
instructions.

HELPFUL H

INTS

ANTENNA IN 75Ω

3

INPUT-AV 2 SUBWOOFEROUTPUT

Y

VIDEO

1

Pb

L

AUDIO

Pr

R

VCR

DIGITAL

AUDIO OUT

Coaxial Cable Lead-in

from Cable Outlet,

Cable Converter Box,

or VHF/UHF Antenna

S-VIDEO

L

1

Rear of HD Receiver
(Example: Philips DSHD800)

INPUT-AV 1

VIDEO

S-VIDEO

L

L

AUDIO

R

AUDIO

AUDIO

Y

PB

RF

PR

REMOTEPHONE JACK

L

L

CONTROL

RR

VIDEOVIDEO

S-VIDEO

Rear of TV

HD INPUT-AV 5

DVI

HD INPUT-AV 4

OUT TO TV

CH 3
CH 4

IN FROM ANT SATELLITE IN

G/Y

R/Pr

B/Pb

V

SYNC

H

3

2

2

L

L

AUDIO

AUDIO

R

R

Coaxial Cable

Lead-in

from

Satellite

Dish Antenna

3

16

CONNECTING A C

AMCORDER

T

he side panel jacks provide a convenient way

for you to connect a camcorder to your TV.
The side panel jacks are recognized by your TV
as AV3.

You can obtain S-VIDEO quality with an S-VHS,
Hi-8, or digital camcorder by connecting to the
S-VIDEO input instead of the VIDEO (composite)
input.

To make the connections shown in this example,
you will need:

• an S-VIDEO cable

•two cables for audio connections (standard

RCA connectors).

NOTE: The cables are not supplied with your TV.
You should be able to buy them at most stores
that sell electronics. Or you can call our
Customer Care Center at 1-800-531-0039.

1

Connect from the S-VIDEO output on

the camcorder to the S-VIDEO input in
the TV’s side panel.

2

Connect from the AUDIO outputs on
the camcorder to the side panel AUDIO

L(eft) and R(ight) inputs.

3

Press the AV button on the remote con­trol as many times as necessary to select
the AV3 source on the TV.

4

Turn the camcorder on, insert a video­tape and press PLAY to view the tape
on the TV.

Connecting Accessory Devices to Your TV

PIP ON/OFF

213
546
879
0

TV

SWAP PIP CH

DN

UP

ACTIVE

CONTROL

FREEZE

SOUND

MUTE

SURF

A/CH

POWER


STATUS/

EXIT

SURF

ITR/

RECORD

HOME
VIDEO

HOME

MOVIES

PERSONAL

SLEEP

REC •

PIPPOSITION

VCR

ACC

MENU/

SELECT

VOL

CH

TV/VCR

FORMAT

SAP

PROG.LISTDOLBY VAV

3

AV3

To simplify making connections, the con­nectors on audio cables are often color
coded: red for the right channel, and white
for the left channel. The jacks on your TV
are likewise color coded to match the con­nectors. To make S-Video connections, you

HELPFUL HINT

Typical

Camcorder

S-VIDEO

DV

1

Side Jack Panel

VIDEO AUDIO

LEFT RIGHT

S-VIDEO

VIDEO

L

AUDIO

R

G

2

17

CONNECTING AND U

SING HEADPHONES WITH YOUR TV

T

he HEADPHONE controls allow you to
adjust the volume and balance of the

sound going to the headphones.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

once to highlight SOUND.

3

Press the CURSOR RING RIGHT

to enter the SOUND submenu.

4

Press the CURSOR RING DOWN

repeatedly until HEADPHONE is
highlighted. Then press the CURSOR
RING RIGHT to enter the
HEADPHONE submenu.

5

Press the CURSOR RING DOWN
or UP to highlight VOLUME or

BALANCE. Then press the CURSOR
RING LEFT or RIGHT to adjust the
control.

6

Press the STATUS/EXIT button to

exit the menu.

T

he TV’s side panel has a headphone jack for

personal listening.

1

Insert the headphone plug into the head­phone jack ; in the TV’s side panel.

2

Turn down the TV’s volume or press
the Mute button

cc

on the remote con-

trol to turn off the TV’s internal speakers.

See the section below for information on
adjusting headphone volume and balance.

NOTE: The headphone impedance must

be between 8 and 4,000 ohms. The head­phone jack is stereo and 3.5 mm in size.

Connecting Accessory Devices to Your TV

The AVL, INCR. SURROUND, and BASS
BOOST controls do not function with the

HELPFUL HINT

Side Jack Panel

G

1


MENU/
SELECT

2

MUTE

CH

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND


SOUND

FEATURES
INSTALL

2

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

STATUS/

EXIT

VOL

SOUND

6

STATUS/

2,4,

5

TV

SWAP PIP CH

SOUND

EXIT

VOL

TV/VCR

A/CH

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/

SELECT

MUTE

213
546
879

SURF

0

POSITION

PIP

CH

3

1

SOUND

TREBLE
BASS
BALANCE
INCR . SURROUND

HEADPHONE

SOUND

HEADPHONE

VOLUME 30

BALANCE

SOUND

HEADPHONE

VOLUME

BALANCE 0

VOLUME
BALANCE

18

PROGRAMMING THE

TV REMOTE TO WORK WITH ACCESSORY DEVICES

Y

our TV remote is capable of working not

only your TV but also other infrared
remote (IR) controlled devices such as VCRs,
cable TV converter boxes, satellite receivers,
DVD players, and laser-disc players.

If you want to use your TV remote to oper­ate a VCR or other accessory device, you
will need to perform this initial check
explained in this section. You may also need
to go to the sections on the “Code-entry
Method” and the “Search Method” in the
pages that follow.

1

Press the VCR or ACC(essory)
mode button on the TV remote for

the desired accessory device category.

NOTE: Pressing the VCR mode button

allows access to product codes for
VCRs. Pressing the ACC(essory) mode
button allows access to the product
codes for cable TV converters, satellite
receivers, DVD players, and laser-disc
players.

2

Point the TV remote toward the
desired accessory device and press
the POWER button.

Does the remote turn the accessory
device on?

If yes, and try other function but-

tons on the TV remote. With a VCR,
for example, try the Play, Stop, and
Rewind buttons, for example. (See
page 23 for information on how the
remote buttons correspond with acces­sory device functions.) If they also
work the accessory device, then the
remote is ready and no further steps
are needed.

If not, do the following:
Look up a four-digit remote code

number on pages 21 or 22 for your

brand of accessory device. Then go
through the simple steps for entering a
four-digit code as explained on
page 19.

Using the Remote Control

If more than one four-digit code number is
listed, you may have to try more than the
first number given to locate your device’s

HELPFUL HINT

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

Satellite Receiver

Cable Converter Box

DVD Player

VCR

1

TV

VCR

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879
0

POWER

ACC

FREEZE


SURF

MENU/

SELECT

2

1

CH

POSITION

PIP

19

USING THE CODE-ENTRY METHOD TO PROGRAM YOUR TV REMOTE

N

ow that you have looked up the four-

digit remote-control Direct-entry Code
for your brand of accessory device, you are
ready to follow the simple steps shown below
to program your TV remote.

Please read through all the steps before
beginning.

1

First, press and hold down the VCR
or ACC (for an accessory device
other than a VCR) mode button on

the TV remote. Then press and hold
down the MENU/SELECT button at
the same time for a brief moment.
Release the buttons. The TV remote
back light will switch on.
NOTE: For correct operation, you
must first press and hold the mode
button and then press and hold the
MENU/SELECT button simultaneously.

2

Within 30 seconds of pressing the
VCR (or ACC) button and
MENU/SELECT button, enter a
four-digit code for the accessory
device (see pages 21 and 22).

If you make a mistake while attempt­ing to enter the four-digit code and
want to start again, press any button
other than one with a number. Then
return to step 1 to begin again.

3

Point the remote at the accessory
device. Then press the POWER button

on the remote to turn the device on.

Using the Remote Control

• If you do not enter a complete code within
30 seconds, you will need to perform step
1 of the Code-entry Method again.

• If you enter more than four digits, the unit
will retain the first four digits entered.

• If the procedure explained above does not

work the first time, repeat the steps using
the same remote code number.

• If after a second try the remote does not

operate your accessory device, and more
code numbers are listed for your brand,
use the next listed code number.

• If after repeated attempts the Entry-code

Method does not allow you to work your
accessory device with your TV remote, try
the Search Method explained on the next
page.

HELPFUL HINTS

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

Satellite Receiver

Cable Converter Box

DVD Player

VCR

1

TV

VCR

SWAP PIP CH

SOUND

STATUS/

EXIT

ACTIVE

CONTROL

DN

UP

POWER

ACC

FREEZE


MENU/
SELECT

3

1

2

VOL

MUTE

213
546
879

TV/VCR

A/CH

0

POSITION

CH

SURF

PIP

20

USING THE S

EARCH METHOD TO PROGRAM YOUR TV REMOTE

Y

our TV remote can be set to work various

accessory devices (VCRs, cable convert­ers, and satellite receivers, for example) by
what is called the Search Method.

NOTE: The Search Method works only with
devices equipped with channel-display indi­cators on the devices themselves or the abili­ty to show channel numbers on the TV
screen. If the Code-entry Method (shown in
the previous section) did not enable your TV
remote to work your accessory device, then
follow the easy steps listed below. Please
read the steps once before performing them.

1

Turn on the desired device. Press
and hold down the VCR or ACC
(for an accessory device other than
a VCR) mode button on the TV

remote. Then press and hold down the
SURF button as you hold down the
desired mode (VCR or ACC) button.

NOTE: For correct operation, you

must press and hold down the desired
mode (VCR or ACC) button first and
then press and hold down the SURF
button second.

While holding down the SURF and
the desired mode (VCR or ACC)
buttons simultaneously, point the
remote toward the accessory device

and continue holding the buttons
down.

2

Watch the Channel Indicator on
your accessory device. Channel num-

bers will scan up when the TV remote
has identified the correct code for
your accessory device. This may take
several minutes.

3

Release the mode (VCR or ACC)
and SURF buttons as soon as chan­nel numbers start to scan up. The

scanning means that your TV remote
has found the code for your accessory
device.

NOTE:

If no channel change happens

after several minutes, repeat steps 1 and

2. Then if a channel change still does not
occur, the remote will not work with the
desired accessory device.

Using the Remote Control

•The remote’s back light will blink
as the remote moves through its
product code list. After the remote
identifies the product code for
your accessory device and you
release the remote buttons, the
back light will blink twice.

•Your TV remote may locate the
accessory device’s code quickly or
within several minutes.

• Don’t let the accessory device
scan up more than five channels
when the correct code is found—
the remote may pass up the right
code and have to repeat the search
cycle.

HELPFUL HINTS

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

Satellite Receiver

Cable Converter Box

06

07

08

1,3

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

06

09

VCR

06

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/
SELECT

MUTE

213
546
879

SURF

0

POSITION

PIP

07

07

CH

08

09

08

09

1,3

1,3

21

DIRECT-ENTRY

CODES FOR A/V ACCESSORY DEVICES

S

EE THE NEXT PAGE FOR MORE CODES.

Using the Remote Control

VCR

CODE NUMBER

DENON . . . . . . . . . . . . . . . .0859

GE . . . . . . . . . . . . . . . . . . .0862

H

ARMAN/KARDON . . . . . . . .0871

H

ITACHI . . . . . . . . . . . . . . . .0870

JVC . . . . . . . . . . . . . . . . . .0868

KENWOOD . . . . . . . . . . . . .0865

MAGNAVOX . . . . . . . . . . . . .0860

MARANTZ . . . . . . . . . . . . . .0866

MITSUBISHI . . . . . . . . . . . . . .0861

ONKYO . . . . . . . . . . . . . . . .0860

O

PTIMUS . . . . . . . . . . . . . . .0869

P

ANASONIC . . . . . . . . . . . . .0859

PHILIPS . . . . . . . . . . . . . . . . .0866, 0860

PIONEER . . . . . . . . . . . . . . .0869, 0863

PROSCAN . . . . . . . . . . . . . . .0862

RCA . . . . . . . . . . . . . . . . . .0862, 0869

SAMSUNG . . . . . . . . . . . . . . .0870

SONY . . . . . . . . . . . . . . . . .0864

T

ECHNICS . . . . . . . . . . . . . .0859

T

HETA DIGITAL . . . . . . . . . . .0869

TOSHIBA . . . . . . . . . . . . . . .0860

YAMAHA . . . . . . . . . . . . . . .0859, 0867

ZENITH . . . . . . . . . . . . . . . .0872, 0860

DVD PLAYER

CODE NUMBER

ADMIRAL . . . . . . . . . . . . . . .0075, 0236

ADVENTURA . . . . . . . . . . . . .0027

AIKO . . . . . . . . . . . . . . . . . .0305

AIWA . . . . . . . . . . . . . . . . .0334, 0495, 0027, 0064

AKAI . . . . . . . . . . . . . . . . . .0133, 0080, 0068, 0076,

. . . . . . . . . . . . . . . . . . . . .0088, 0183, 0269

AMERICA A

CTION . . . . . . . . .0305

A

MERICAN HIGH . . . . . . . . . .0062

ASHA . . . . . . . . . . . . . . . . .0267

AUDIOVOX

. . . . . . . . . . . . . .0064

B

EAUMARK . . . . . . . . . . . . . .0267

BELL & HOWELL . . . . . . . . . .0131

BROKSONIC . . . . . . . . . . . . .0148, 0211, 0029, 0236,

. . . . . . . . . . . . . . . . . . . . .0238, 0322, 0388, 0506

CCE . . . . . . . . . . . . . . . . . .0099, 0305

CALIX . . . . . . . . . . . . . . . . .0064

CANON . . . . . . . . . . . . . . . .0194, 0062, 0129

CAPEHART . . . . . . . . . . . . . .0047

CARVER . . . . . . . . . . . . . . . .0108

CINERAL . . . . . . . . . . . . . . .0305

CITIZEN . . . . . . . . . . . . . . . .0305, 0064

COLT . . . . . . . . . . . . . . . . .0099

CRAIG . . . . . . . . . . . . . . . . .0064, 0099, 0074, 0267,

. . . . . . . . . . . . . . . . . . . . .0298

CURTIS MATHES . . . . . . . . . .0062, 0068, 0087, 0189

CYBERNEX . . . . . . . . . . . . . .0078, 0267

DAEWOO . . . . . . . . . . . . . . .0305, 0588, 0047, 0072

DAYTRON . . . . . . . . . . . . . .0047

DENON . . . . . . . . . . . . . . . .0069

DYNATECH . . . . . . . . . . . . . .0027

ELECTROHOME . . . . . . . . . . .0064

ELECTROPHONIC . . . . . . . . . .0064

EMEREX . . . . . . . . . . . . . . . .0059

EMERSON . . . . . . . . . . . . . . .0211, 0029, 0236, 0305,

. . . . . . . . . . . . . . . . . . . . .0063, 0148, 0238, 0588,

. . . . . . . . . . . . . . . . . . . . .0235, 0321, 0506, 0088,

. . . . . . . . . . . . . . . . . . . . .0115, 0239, 0027, 0064,

. . . . . . . . . . . . . . . . . . . . .0070, 0095, 0322, 0388,

. . . . . . . . . . . . . . . . . . . . .0537

FISHER . . . . . . . . . . . . . . . . .0074, 0131, 0081, 0093

FUJI . . . . . . . . . . . . . . . . . . .0060, 0062

FUNAI . . . . . . . . . . . . . . . . .0027

GE . . . . . . . . . . . . . . . . . . .0062, 0087, 0075, 0092,

. . . . . . . . . . . . . . . . . . . . .0229, 0267

GARRARD . . . . . . . . . . . . . .0027

GO VIDEO . . . . . . . . . . . . . .0306, 0459, 0553, 0259

GOLDSTAR . . . . . . . . . . . . . .0064, 0045, 0065, 0498,

. . . . . . . . . . . . . . . . . . . . .0507

GRADIENTE . . . . . . . . . . . . .0035, 0027, 0435

GRUNDIG . . . . . . . . . . . . . . .0222

HI-Q . . . . . . . . . . . . . . . . .0074

H

ARLEY DAVIDSON . . . . . . . .0027

H

ARMAN/KARDON . . . . . . . .0065, 0102, 0108

H

ARWOOD . . . . . . . . . . . . .0095, 0099

HEADQUARTER . . . . . . . . . . .0073

H

ITACHI . . . . . . . . . . . . . . . .0069, 0193, 0132, 0092,

. . . . . . . . . . . . . . . . . . . . .0027, 0068, 0109

H

UGHES NETWORK SYSTEMS .0069

JVC . . . . . . . . . . . . . . . . . .0094, 0035, 0233, 0234,

. . . . . . . . . . . . . . . . . . . . .0068, 0411

JENSEN . . . . . . . . . . . . . . . . .0068

KEC . . . . . . . . . . . . . . . . . .0064, 0305

KLH . . . . . . . . . . . . . . . . . .0099

KENWOOD . . . . . . . . . . . . .0068, 0094, 0411, 0065

KODAK . . . . . . . . . . . . . . . .0062, 0064

LXI . . . . . . . . . . . . . . . . . . .0064

LLOYD'S . . . . . . . . . . . . . . . .0027, 0235

LOGIK . . . . . . . . . . . . . . . . .0099

MEI . . . . . . . . . . . . . . . . . .0062

MGA . . . . . . . . . . . . . . . . .0070, 0088, 0267

MGN TECHNOLOGY . . . . . . .0267

MTC . . . . . . . . . . . . . . . . .0027, 0267

MAGNASONIC . . . . . . . . . . . .0305

MAGNAVOX

. . . . . . . . . . . . .0062, 0108, 0137, 0130,

. . . . . . . . . . . . . . . . . . . . .0027, 0066, 0176

M

AGNIN . . . . . . . . . . . . . . .0267

MARANTZ . . . . . . . . . . . . . .0108, 0062

MARTA . . . . . . . . . . . . . . . . .0064

MATSUSHITA . . . . . . . . . . . . .0062, 0189, 0481

MEMOREX . . . . . . . . . . . . . .0131, 0074, 0506, 0027,

. . . . . . . . . . . . . . . . . . . . .0064, 0075, 0062, 0073,

. . . . . . . . . . . . . . . . . . . . .0267, 0334, 0066, 0189,

. . . . . . . . . . . . . . . . . . . . .0236, 0481, 0828, 0829

MINOLTA

. . . . . . . . . . . . . . .0132, 0069

M

ITSUBISHI . . . . . . . . . . . . . .0200, 0088, 0102, 0241,

. . . . . . . . . . . . . . . . . . . . .0269, 0070, 0075, 0094,

. . . . . . . . . . . . . . . . . . . . .0470

MOTORO LA . . . . . . . . . . . . .0062, 0075

MULTITECH . . . . . . . . . . . . .0027, 0099

NAD . . . . . . . . . . . . . . . . .0085

NEC . . . . . . . . . . . . . . . . . .0065, 0067, 0068, 0077,

. . . . . . . . . . . . . . . . . . . . .0094, 0109, 0131

NIKKO . . . . . . . . . . . . . . . . .0064

NIKON . . . . . . . . . . . . . . . .0061, 0280

NOBLEX . . . . . . . . . . . . . . .0267

OLYMPUS . . . . . . . . . . . . . . .0062, 0253

OPTIMUS . . . . . . . . . . . . . . .0189, 0481, 0827, 0828,

. . . . . . . . . . . . . . . . . . . . .0075, 0085, 0829, 0064,

. . . . . . . . . . . . . . . . . . . . .0131, 0459

OPTONICA . . . . . . . . . . . . . .0089

ORION . . . . . . . . . . . . . . . .0506, 0029, 0211, 0236,

. . . . . . . . . . . . . . . . . . . . .0322

PANASONIC . . . . . . . . . . . . .0062, 0189, 0828, 0481,

. . . . . . . . . . . . . . . . . . . . .0253, 0104, 0405, 0829,

. . . . . . . . . . . . . . . . . . . . .0129, 0252, 0254, 0273,

. . . . . . . . . . . . . . . . . . . . .0827

PENNEY . . . . . . . . . . . . . . . .0062, 0267, 0064, 0069,

. . . . . . . . . . . . . . . . . . . . .0065, 0067, 0081

PENTAX . . . . . . . . . . . . . . . .0069, 0092, 0132

PHILCO . . . . . . . . . . . . . . . .0062, 0236, 0506

PHILIPS . . . . . . . . . . . . . . . . .0108, 0062, 0089, 0137,

. . . . . . . . . . . . . . . . . . . . .0830, 0831

P

ILOT . . . . . . . . . . . . . . . . .0064

P

IONEER . . . . . . . . . . . . . . .0085, 0195, 0094

P

OLK AUDIO . . . . . . . . . . . .0108

PORTLAND . . . . . . . . . . . . . .0047

P

ROFITRONIC . . . . . . . . . . . .0267

P

ROSCAN . . . . . . . . . . . . . . .0087, 0229

PROTEC . . . . . . . . . . . . . . . .0099

P

ULSAR . . . . . . . . . . . . . . . .0066, 0078

Q

UARTER . . . . . . . . . . . . . . .0073

QUARTZ . . . . . . . . . . . . . . .0073

QUASAR . . . . . . . . . . . . . . .0062, 0189, 0104, 0481,

. . . . . . . . . . . . . . . . . . . . .0828

RCA . . . . . . . . . . . . . . . . . .0087, 0176, 0229, 0069,

. . . . . . . . . . . . . . . . . . . . .0132, 0085, 0062, 0075,

. . . . . . . . . . . . . . . . . . . . .0092, 0104, 0133, 0267,

. . . . . . . . . . . . . . . . . . . . .0304

RADIO SHACK

. . . . . . . . . . .0027

R

ADIX . . . . . . . . . . . . . . . . .0064

RANDEX . . . . . . . . . . . . . . .0064

REALISTIC . . . . . . . . . . . . . . .0027, 0131, 0074, 0075,

. . . . . . . . . . . . . . . . . . . . .0064, 0062, 0089, 0073,

. . . . . . . . . . . . . . . . . . . . .0093

RICOH . . . . . . . . . . . . . . . . .0061, 0280

RUNCO . . . . . . . . . . . . . . . .0066

STS . . . . . . . . . . . . . . . . . .0069

SALORA . . . . . . . . . . . . . . . .0102

SAMSUNG . . . . . . . . . . . . . . .0072, 0078, 0080, 0267

SANKY . . . . . . . . . . . . . . . . .0066, 0075

SANSUI . . . . . . . . . . . . . . . .0068, 0506, 0027, 0094,

. . . . . . . . . . . . . . . . . . . . .0109, 0236, 0298

SANYO . . . . . . . . . . . . . . . . .0074, 0073, 0131, 0267

SCOTT . . . . . . . . . . . . . . . . .0211, 0238, 0148, 0070,

. . . . . . . . . . . . . . . . . . . . .0072, 0237, 0239

SEARS . . . . . . . . . . . . . . . . .0081, 0132, 0064, 0069,

. . . . . . . . . . . . . . . . . . . . .0027, 0062, 0073, 0074,

. . . . . . . . . . . . . . . . . . . . .0093, 0131

SEMP . . . . . . . . . . . . . . . . . .0072

SHARP . . . . . . . . . . . . . . . . .0075, 0089

SHINTOM . . . . . . . . . . . . . . .0099

SHOGUN . . . . . . . . . . . . . . .0078, 0267

SINGER . . . . . . . . . . . . . . . .0099

SONY . . . . . . . . . . . . . . . . .0060, 0061, 0059, 0280,

. . . . . . . . . . . . . . . . . . . . .0027, 0038, 0062

SUNPAK . . . . . . . . . . . . . . . .0280

SYLVANIA . . . . . . . . . . . . . . .0062, 0108, 0027, 0070,

. . . . . . . . . . . . . . . . . . . . .0130, 0137

SYMPHONIC . . . . . . . . . . . . .0027

TMK . . . . . . . . . . . . . . . . .0063, 0235, 0267

TATUNG . . . . . . . . . . . . . . . .0068

TEAC . . . . . . . . . . . . . . . . . .0027, 0068

TECHNICS . . . . . . . . . . . . . .0062, 0189, 0273

TEKNIKA . . . . . . . . . . . . . . .0027, 0062, 0064, 0079

THOMAS . . . . . . . . . . . . . . .0027

TOSHIBA . . . . . . . . . . . . . . .0072, 0237, 0239, 0070,

. . . . . . . . . . . . . . . . . . . . .0093, 0393

TOTEVISION . . . . . . . . . . . . .0064, 0267

UNITECH . . . . . . . . . . . . . . .0267

VECTOR . . . . . . . . . . . . . . . .0072

VECTOR RESEARCH . . . . . . . .0065, 0067

VIDEO CONCEPTS . . . . . . . . .0067, 0072, 0088, 0248

VIDEOSONIC . . . . . . . . . . . . .0267

W

ARDS . . . . . . . . . . . . . . . .0062, 0087, 0089, 0027,

. . . . . . . . . . . . . . . . . . . . .0074, 0239, 0267, 0069,

. . . . . . . . . . . . . . . . . . . . .0075, 0099, 0108, 0176

W

HITE WESTINGHOUSE . . . . .0099, 0305, 0236

XR-1000 . . . . . . . . . . . . . .0099, 0027, 0062

YAMAHA . . . . . . . . . . . . . . .0065

ZENITH . . . . . . . . . . . . . . . .0066, 0027, 0060, 0061,

. . . . . . . . . . . . . . . . . . . . .0236, 0506

TV

VCR

ACTIVE

SWAP PIP CH

CONTROL

DN

UP

SOUND

POWER

ACC

FREEZE


LASER-DISC PLAYER

22

DIRECT-ENTRY

CODES FOR A/V ACCESSORY DEVICES

Using the Remote Control

CABLE CONVERTER BOX

SATELLITE RECEIVER/DIGITAL SATELLITE SYSTEM

CODE NUMBER

ABC . . . . . . . . . . . . . . . . . .0030, 0028, 0034, 0035,

. . . . . . . . . . . . . . . . . . . . .0038, 0040, 0041, 0044,

. . . . . . . . . . . . . . . . . . . . .0060

ALLEGRO . . . . . . . . . . . . . . .0180, 0342

ANTRONIX . . . . . . . . . . . . . .0049, 0234

APACHE . . . . . . . . . . . . . . . .0797

ARCHER . . . . . . . . . . . . . . . .0049, 0066, 0180, 0234,

. . . . . . . . . . . . . . . . . . . . .0824

BBT . . . . . . . . . . . . . . . . . .0294

BELCOR . . . . . . . . . . . . . . . .0083

BELL & HOWELL . . . . . . . . . .0041

CABLE STAR . . . . . . . . . . . . .0083

CABLETENNA . . . . . . . . . . . .0049

CABLEVIEW . . . . . . . . . . . . .0049

CENTURY

. . . . . . . . . . . . . . .0180

C

ITIZEN . . . . . . . . . . . . . . . .0180, 0342

COLOUR VOICE . . . . . . . . . .0052, 0058

COMBAND

. . . . . . . . . . . . . .0259

C

OMTRONICS . . . . . . . . . . . .0067, 0087

CONTEC . . . . . . . . . . . . . . .0046

DIGI

. . . . . . . . . . . . . . . . . .0664

E

ASTERN . . . . . . . . . . . . . . .0029

EMERSON . . . . . . . . . . . . . . .0824

EVERQUEST . . . . . . . . . . . . . .0042, 0067

FOCUS . . . . . . . . . . . . . . . . .0427

GC ELECTRONICS . . . . . . . . .0083, 0234

GE . . . . . . . . . . . . . . . . . . .0259

GARRARD . . . . . . . . . . . . . .0180

GEMINI . . . . . . . . . . . . . . . .0042, 0097, 0269, 0824

GENERAL INSTRUMENT . . . . . .0303, 0038, 0503, 0837

GOLDSTAR . . . . . . . . . . . . . .0067, 0171

GOODMIND . . . . . . . . . . . . .0797, 0824

HAMLIN . . . . . . . . . . . . . . . .0047, 0036, 0286, 0061,

. . . . . . . . . . . . . . . . . . . . .0300

HITACHI

. . . . . . . . . . . . . . . .0038

H

YTEX . . . . . . . . . . . . . . . . .0034

JASCO . . . . . . . . . . . . . . . . .0042, 0180, 0342

JERROLD . . . . . . . . . . . . . . . .0030, 0039, 0303, 0041,

. . . . . . . . . . . . . . . . . . . . .0503, 0038, 0051, 0042,

. . . . . . . . . . . . . . . . . . . . .0837

LINSAY . . . . . . . . . . . . . . . . .0467

MACOM . . . . . . . . . . . . . . . .0060

MAGNAVOX . . . . . . . . . . . . .0054

MEMOREX . . . . . . . . . . . . . .0027

MOVIE TIME . . . . . . . . . . . . .0090, 0183

NSC . . . . . . . . . . . . . . . . . .0183, 0090, 0097

NEXUS . . . . . . . . . . . . . . . .0797

NOVAPLEX

. . . . . . . . . . . . . .0645

O

AK . . . . . . . . . . . . . . . . . .0046, 0034

OPTIMUS . . . . . . . . . . . . . . .0048

PANASONIC

. . . . . . . . . . . . .0048, 0134, 0027

P

ANTHER . . . . . . . . . . . . . . .0664

PARAGON . . . . . . . . . . . . . .0027

PHILIPS

. . . . . . . . . . . . . . . . .0052, 0058, 0269, 0317,

. . . . . . . . . . . . . . . . . . . . .0054, 0180

P

IONEER . . . . . . . . . . . . . . .0171, 0050, 0560

POPULAR MECHANICS . . . . . .0427

PRELUDE . . . . . . . . . . . . . . .0797

PULSAR . . . . . . . . . . . . . . . .0027

QUASAR . . . . . . . . . . . . . . .0027

RCA . . . . . . . . . . . . . . . . . .0048

RADIO SHACK . . . . . . . . . . .0042, 0847, 0342, 0824

REALISTIC . . . . . . . . . . . . . . .0234

RECOTON . . . . . . . . . . . . . .0427

REGAL . . . . . . . . . . . . . . . . .0300, 0047, 0286

REGENCY . . . . . . . . . . . . . . .0029

REMBRANDT . . . . . . . . . . . . .0038, 0097

RUNCO . . . . . . . . . . . . . . . .0027

SL MARX . . . . . . . . . . . . . . .0067

SAMSUNG . . . . . . . . . . . . . . .0067, 0171

SCIENTIFIC ATLANTA

. . . . . . .0035, 0044, 0033, 0504

S

EAM . . . . . . . . . . . . . . . . . .0537

SIGNAL . . . . . . . . . . . . . . . .0042, 0067

SIGNATURE . . . . . . . . . . . . . .0038

SPRUCER . . . . . . . . . . . . . . .0048

STAR SIGHT . . . . . . . . . . . . . .0569, 0449

STARCOM . . . . . . . . . . . . . . .0030, 0042

STARGATE . . . . . . . . . . . . . . .0067, 0042, 0797, 0824

STARQUEST . . . . . . . . . . . . . .0042

SYLVANIA . . . . . . . . . . . . . . .0028

TFC . . . . . . . . . . . . . . . . . .0337

TV86 . . . . . . . . . . . . . . . . .0090

TANDY . . . . . . . . . . . . . . . . .0285

TELE

CAPTION . . . . . . . . . . . .0248

T

ELEVIEW . . . . . . . . . . . . . . .0067

TEXSCAN . . . . . . . . . . . . . . .0028

TIMELESS

. . . . . . . . . . . . . . .0445

T

OCOM . . . . . . . . . . . . . . . .0039, 0040

TOSHIBA . . . . . . . . . . . . . . .0027

TUSA . . . . . . . . . . . . . . . . . .0042

UNIKA . . . . . . . . . . . . . . . . .0180, 0234, 0049

UNITED ARTISTS . . . . . . . . . .0034

UNIVERSAL . . . . . . . . . . . . . .0234, 0049, 0066, 0083,

. . . . . . . . . . . . . . . . . . . . .0180, 0218

VIEWMASTER . . . . . . . . . . . . .0847

VIEWSTAR . . . . . . . . . . . . . .0285, 0054, 0087, 0090

ZENITH . . . . . . . . . . . . . . . .0027, 0552, 0081

ZENTEK . . . . . . . . . . . . . . . .0427

CODE NUMBER

ADS . . . . . . . . . . . . . . . . . .0880

AIWA . . . . . . . . . . . . . . . . .0855

CARVER . . . . . . . . . . . . . . . .0853, 0850, 0858

DENON . . . . . . . . . . . . . . . .0851, 0849, 0875

DISCO VISION . . . . . . . . . . . .0848

FUNAI . . . . . . . . . . . . . . . . .0855

HARMAN/KARDON . . . . . . . .0853

HITACHI . . . . . . . . . . . . . . . .0848

KENWOOD . . . . . . . . . . . . .0877

MAGNAVOX

. . . . . . . . . . . . .0853, 0857, 0875

M

ARANTZ . . . . . . . . . . . . . .0853, 0850

MITSUBISHI . . . . . . . . . . . . . .0849

NAD . . . . . . . . . . . . . . . . .0849

NEC . . . . . . . . . . . . . . . . . .0879

NIKKODO . . . . . . . . . . . . . .0884

OPTIMUS . . . . . . . . . . . . . . .0849

PANASONIC . . . . . . . . . . . . .0856

PHILIPS . . . . . . . . . . . . . . . . .0853, 0850

PIONEER . . . . . . . . . . . . . . .0849, 0848

POLK AUDIO . . . . . . . . . . . .0853

QUASAR . . . . . . . . . . . . . . .0856

RCA . . . . . . . . . . . . . . . . . .0881, 0874

REALISTIC . . . . . . . . . . . . . . .0855

SAMSUNG . . . . . . . . . . . . . . .0858

SEGA . . . . . . . . . . . . . . . . . .0848

SHARP . . . . . . . . . . . . . . . . .0873

SONY . . . . . . . . . . . . . . . . .0854, 0852, 0878

TECHNICS . . . . . . . . . . . . . .0856

THETA DIGITAL

. . . . . . . . . . .0853

V

ICTOR . . . . . . . . . . . . . . . .0876

YAMAHA . . . . . . . . . . . . . . .0857

CODE NUMBER

ALPHASTAR . . . . . . . . . . . . .0799

A

MPLICA . . . . . . . . . . . . . . .0099

A

MWAY . . . . . . . . . . . . . . . .0070, 0102

A

RUNTA . . . . . . . . . . . . . . .0548

ASTRO INDUSTRIES . . . . . . . .0122

BMC . . . . . . . . . . . . . . . . .0114

BSR . . . . . . . . . . . . . . . . . .0122

CABLE INNOVATIONS . . . . . . .0581

C

APETRONIC . . . . . . . . . . . .0122

C

ENTURY . . . . . . . . . . . . . . .0565

CHANNEL MASTER . . . . . . . .0045, 0239

C

HAPARRAL . . . . . . . . . . . . .0080, 0236, 0243

C

ITOH . . . . . . . . . . . . . . . . .0191

CONIFER . . . . . . . . . . . . . . .0031

C

URTIS MATHES . . . . . . . . . .0088, 0099

DX A

NTENNA . . . . . . . . . . .0068

DRAKE . . . . . . . . . . . . . . . .0091, 0272, 0045, 0176

E

CHOSTAR . . . . . . . . . . . . . .0307, 0802, 0175, 0186,

. . . . . . . . . . . . . . . . . . . . .0296

E

XPRESSVU . . . . . . . . . . . . . .0802

GE . . . . . . . . . . . . . . . . . . .0593

G

ENERAL INSTRUMENT . . . . . .0388, 0896, 0574, 0581,

. . . . . . . . . . . . . . . . . . . . .0654

G

OULD . . . . . . . . . . . . . . . .0082

HNS . . . . . . . . . . . . . . . . . .0644

HTS . . . . . . . . . . . . . . . . . .0802

HITACHI . . . . . . . . . . . . . . . .0846

H

OMECABLE . . . . . . . . . . . . .0265

HUGHES NETWORK SYSTEMS .0776
H

YTEK . . . . . . . . . . . . . . . . .0122

IQ . . . . . . . . . . . . . . . . . . .0237

IQ P

RISM . . . . . . . . . . . . . . .0237

I

NTERSAT . . . . . . . . . . . . . . .0070

JVC . . . . . . . . . . . . . . . . . .0802

J

ANEIL . . . . . . . . . . . . . . . . .0179

J

ERROLD . . . . . . . . . . . . . . . .0388, 0654

L

EGEND . . . . . . . . . . . . . . . .0296

MACOM . . . . . . . . . . . . . . . .0088, 0045

M

AGNAVOX . . . . . . . . . . . . .0749, 0751

M

EMOREX . . . . . . . . . . . . . .0296, 0751

NEXT LEVEL . . . . . . . . . . . . .0896

NORSAT . . . . . . . . . . . . . . . .0031

P

ANASONIC . . . . . . . . . . . . .0179, 0728

P

HILIPS . . . . . . . . . . . . . . . . .0227, 0749, 0751

P

ICO . . . . . . . . . . . . . . . . . .0102

P

RIMESTAR . . . . . . . . . . . . . .0654, 0388

RCA . . . . . . . . . . . . . . . . . .0593, 0170, 0882

R

ADIO SHACK . . . . . . . . . . .0581, 0896

R

AMSEY . . . . . . . . . . . . . . . .0102

REALISTIC . . . . . . . . . . . . . . .0079, 0078

STS . . . . . . . . . . . . . . . . . .0237, 0068

SONY . . . . . . . . . . . . . . . . .0666

STAR CHOICE . . . . . . . . . . . .0896

S

TAR TRAK . . . . . . . . . . . . . .0207, 0448, 0574

S

TRONG . . . . . . . . . . . . . . . .0448

TOSHIBA . . . . . . . . . . . . . . .0109, 0776, 0817, 0088

T

OWN & COUNTRY . . . . . . .0574

U

NIDEN . . . . . . . . . . . . . . . .0265, 0079, 0101, 0397,

. . . . . . . . . . . . . . . . . . . . .0581, 0751, 0103, 0323,

. . . . . . . . . . . . . . . . . . . . .0749

ZENITH . . . . . . . . . . . . . . . .0091, 0883, 0088

TELEVISION

CODE NUMBER

MAGNAVOX . . . . . . . . . . . . .0583

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

23

USING THE TV R

EMOTE WITH ACCESSORY DEVICES

Using the Remote Control

T

he Chart below provides you with com-

mon accessory-device functions associat­ed with the buttons on your Philips TV remote
control. (See pages 18–20 for information on
programming your TV remote to operate
accessory devices.)

NOTES:

• Functions can vary according to the manu-

facturer’s specifications for each accessory
device.

•First press the VCR mode button to use the

TV remote to operate a VCR.

•First press the ACC mode button to use the

TV remote to operate a DVD player, laser­disc player, cable converter box, or satellite
receiver/digital satellite system.

*A/CH (Alternate Channel) allows you to switch between the currently viewed channel and the previously viewed channel.
**Press the BACK LIGHT button to light the white buttons on the remote.

TV Remote VCR

and Accessory Mode Buttons

etomeRVTnonottuBnoitcnuFRCVnommoC

reyalPDL/DVDnommoC

noitcnuF

retrevnoCelbaCnommoC

etilletaSroxoB

etilletaSlatigiD/revieceR

noitcnuF)SSD(metsyS

REWOPREWOPREWOPREWOP

ESUAPESUAPESUAP—

DNIWERDNIWERESREVERHCRAES—

POTSPOTSPOTS—

YALPYALPYALP—

DRAWROFTSAFDRAWROFTSAFDRAWROFHCRAES—

PUGNIRROSRUCPUROSRUCPUROSRUCPUROSRUC

NWODGNIRROSRUCNWODROSRUCNWODROSRUCNWODROSRUC

THGIRGNIRROSRUCTHGIRROSRUCTHGIRROSRUCTHGIRROSRUC

TFELGNIRROSRUCTFELROSRUCTFELROSRUCTFELROSRUC

nottuBKOUNEM;MARGORPUNEM

UNEM

)SSD/srevieceretilletasrofEDIUG,osla(

TIXE/SUTATSTIXETIXETIXE

TCELES/UNEMTCELESTCELESTCELES

+HCPULENNAHCTXENPULENNAHC

–HCNWODLENNAHCSUOIVERPNWODLENNAHC

)9–0(snottuBREBMUN)9–0(NOITCELESREBMUN)9–0(NOITCELESREBMUN)9–0(NOITCELESREBMUN

RCV/VTdna*HC/A*HC/A,RCV/VT——

PAS,CER

DROCER

)nottuBYALPhtiwsserP(——

**THGILKCAB**THGILKCAB**THGILKCAB**THGILKCAB

TV

VCR

ACTIVE

SWAP PIP CH

CONTROL

DN

UP

SOUND

POWER

ACC

FREEZE


POWER

PAU SE

REWIND

STOP

CURSOR RING UP

CURSOR RING LEFT

STATUS/EXIT

NUMBER Buttons (0-9)

A/CH & TV/VCR

REC, SAP

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

POWER

ACC

VCR

ACTIVE

CONTROL

MUTE

FREEZE

UP


MENU/
SELECT

CH

DN

213
546
879

SURF

0

PIP ON/OFF

SURF

REC •

SAP

FORMAT

SLEEP

PROG.LISTDOLBY VAV

POWER

FAST FORWARD

PLAY

OK Button

CURSOR RING RIGHT

MENU/SELECT

CURSOR RING DOWN

CH + & CH -

ITR/

HOME

HOME

RECORD

VIDEO

TV

VCR

ACC

MOVIES

PERSONAL

PIPPOSITION

BACK LIGHT

24

USING THE AV

AND SOURCE SELECT BUTTONS

PIP ON/OFF

213
546
879
0

TV

SWAP PIP CH

DN

UP

ACTIVE

CONTROL

FREEZE

SOUND

MUTE

SURF

A/CH

POWER


STATUS/

EXIT

SURF

ITR/

RECORD

HOME
VIDEO

HOME

MOVIES

PERSONAL

SLEEP

REC •

PIPPOSITION

VCR

ACC

MENU/

SELECT

VOL

CH

TV/VCR

FORMAT

SAP

PROG.LISTDOLBY VAV

10

AV1

CVI

AV2

AV3

AV4

AV

Button

AV5

T

he AV button on the remote control and

SOURCE SELECT button on the TV

allow you to access the TV’s signal-source
inputs. With each press of the AV button you
can access a different signal-source input.
The signal-source input jacks are located on
the back and side panels of your TV. (See
pages 6 and 7.)

Using the Remote Control

Selecting a Signal Source

Using the AV Button

on the Remote Control

Press the AV button on the remote control as
many times as necessary to select the signal

source you want to watch.

Selecting a Signal Source

Using the Source Select

Button on the TV

Press the SOURCE SELECT button on the TV
as many times as necessary to select the signal

source you want to watch.

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

25

USING AUTO

SOUND™

Y

ou can use the AutoSound™ options to

automatically tailor the TV’s sound for
the type of program you are watching. The
factory has set the VOICE, MUSIC, and
THEATRE options. The settings for the PER­SONAL option are the ones you select
through the on-screen SOUND submenu. See
descriptions of the options below, right.

1

Press the SOUND button on the

remote control. The current
AutoSound™ setting will appear on

screen. Press the SOUND button

repeatedly to cycle through the four
options: PERSONAL, VOICE,
MUSIC, or THEATRE.

2

When you see the option you want
on the screen, press the
STATUS/EXIT button to exit the

menu. The AutoSound™ option you
selected is then active.

Using the Remote Control

HELPFUL H

INTS

AutoSound™ Options
PERSONAL presents the TV’s sound

according to the TREBLE and BASS set­tings you make within the SOUND sub­menu.

VOICE brings voices to the forefront and

emphasizes them. Moves music to the
background.

MUSIC emphasizes music over voices.
THEATRE provides a balance between

voices and music.

•AutoSound™ works only with the pro­grams coming through the ANTENNA
IN 75Ω jack on the rear of the TV.
AutoSound™ will not control the sound
levels of the other jacks on the rear or
side of the TV.

• If you select an AutoSound™ option
other than PERSONAL, then the TRE­BLE and BASS settings specific to that
option will also be written to the
SOUND submenu items. At that point,
the PERSONAL AutoSound™ option
settings will not be changed. Only when
you go into the

SOUND submenu and

change the TREBLE

and BASS settings
will those settings be reflected in the
PERSONAL AutoSound™ option.

TREBLE 49
BASS 49

1
2

STATUS/

PERSONAL

TV

VCR

SWAP PIP CH

SOUND

EXIT

ACTIVE

CONTROL

DN

UP

POWER

ACC

FREEZE


MENU/

SELECT

VOICE

TREBLE 56
BASS 47

MUSIC

TREBLE 63
BASS 69

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

VOL

MUTE

CH

TREBLE 59
BASS 59

THEATRE

213
546
879

TV/VCR

A/CH

POSITION

SURF

0

PIP

26

USING AUTOPICTURE™

Using the Remote Control

If you select an AutoPicture™ setting
option other than PERSONAL, then the
BRIGHTNESS, COLOR, PICTURE, and
SHARPNESS settings specific to that
option will also be written to the PICTURE
submenu items. At that point, the PERSON­AL AutoPicture™ option settings will not
be changed. Only when you go into the
PICTURE submenu and change the settings
will those settings be reflected in the PER­SONAL AutoPicture™ option.

HELPFUL HINT

Y

ou can use an AutoPicture™ option to

automatically tailor the TV’s picture for
certain types of input signals. The factory
has set the MOVIES, SPORTS, WEAK SIG­NAL, and MULTIMEDIA options. The set­tings for the PERSONAL option are the ones
you select through the on-screen PICTURE
submenu.

1

Press the PICTURE button on the

remote control. The current
AutoPicture™ setting will appear on
screen. Then Press the PICTURE but­ton repeatedly to cycle through the
options: PERSONAL, MOVIES,
SPORTS, WEAK SIGNAL, and
MULTIMEDIA picture settings.

2

When you see the option you want
on screen, press the STATUS/EXIT
button to turn off the on-screen dis-

play. The AutoPicture™ option you
selected is then active.

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

PERSONAL

BRIGHTNESS 48
COLOR 41
PICTURE 81
SHARPNESS 46

POWER

TV

SWAP PIP CH

DN

SOUND

ACC

VCR

ACTIVE

FREEZE

CONTROL

UP

1


2

STATUS/

VOL

EXIT

TV/VCR

A/CH

POSITION

MENU/
SELECT

MUTE

CH

213
546
879

SURF

0

PIP

MOVIES

BRIGHTNESS 50
COLOR 50
PICTURE 50
SHARPNESS 84

SPORTS

BRIGHTNESS 50
COLOR 55
PICTURE 60
SHARPNESS 70

WEAK SIGNAL

BRIGHTNESS 50
COLOR 40
PICTURE 40
SHARPNESS 28

MULTIMEDIA

BRIGHTNESS 50
COLOR 40
PICTURE 40
SHARPNESS 70

27

A

fter you set up a list of your favorite sig-

nal sources in the SURF list, you can
press the SURF button to see the list and
quickly tune to a favorite signal source.
Place up to 10 signal sources in the SURF
LIST.

1

Press the NUMBER buttons,
CH(annel) +/– buttons, or the AV
button to select a signal source to add

to the Surf list.

2

Press the SURF button. The Surf list

box appears. The number of the cur­rent signal source is shown with
ADD? to the right. (If you have not
added any channels to the list, “SURF
LIST EMPTY” appears on screen.)
Press the CURSOR RING RIGHT to
add the signal source to the Surf list.

3

Press the NUMBER buttons,
CH(annel) +/– buttons, or the AV
button to select another signal source

to add to the Surf list. Press the SURF
button and then the CURSOR RING
RIGHT to add the signal source to the
list.

Repeat this step, filling the list with
up to 10 favorite signal sources.

NOTE: If you exceed 10 signal

sources, the first signal source on the
list will be deleted from the list.

4

To tune to a favorite signal source
from the list, press the SURF but­ton. The Surf list box appears. Press

the SURF button or the CURSOR
RING DOWN or UP as many times as
necessary to tune to the signal source.

5

To delete a signal source from the
list, press the SURF button. The

Surf list box appears. Press the SURF
button or the CURSOR RING DOWN
or UP as many times as necessary to
select the signal source to be deleted.
Then press the CURSOR RING
RIGHT to delete the signal source.

Five signal sources can be shown in the Surf
list box at one time. Press the CURSOR
RING UP or DOWN to show any other sig­nal sources that are in the list.

HELPFUL HINT

USING AUTO

SURF™

Using the Remote Control

TV

VCR

ACTIVE

SWAP PIP CH

CONTROL

DN

UP

SOUND

POWER

ACC

FREEZE


1,3

1, 3

12

SURF

12 ADD?

SURF LIST EMPTY

TV

VCR

SWAP PIP CH

DN

UP

SOUND

STATUS/

EXIT

VOL

MUTE

213
546
879

TV/VCR

A/CH

0

SURF

REC •

FORMAT

SAP

ITR/

HOME

RECORD

VIDEO

HOME

MOVIES

ACTIVE

CONTROL

PIP ON/OFF

SLEEP

POWER

ACC

FREEZE


MENU/
SELECT

CH

SURF

PROG.LISTDOLBY VAV

2,4,

PERSONAL

PIPPOSITION

1,3

5

12

SURF

12 DELETE?

24

SURF

12
24 ADD?

24

SURF

12
24 DELETE?

7

SURF

8
11
15
4
7 DELETE?

28

ALTERNATE CHANNEL (A/CH)

You can press the A/CH button on your
remote control to go back and forth between
the current channel and one previously
watched channel.

1

Press the Program List button on
the remote control to display a list of

channel numbers and their names (see
the “Tuner Mode” “Auto Program,”
“Channel Edit,” and “Name” sections

on pages 5 and 7 in the Quick Use
and Setup Guide that came with your

TV for proper setup).

You can also access the Program List
by pressing the button in the center of
the Cursor Ring. Each channel will
appear as a selectable item. The cur­rent channel will be highlighted by
default. Only five channels will be
shown in the list at one time.

2

Press the CURSOR RING UP or
DOWN to go through the list and and

highlight a channel.

3

Press the CURSOR RING RIGHT

to tune to the highlighted channel.
Channels marked “Skipped” in the
“Channel Edit” control will not
appear in the list. Any channel that is
being blocked by AutoLock™ will
appear with a padlock icon to indicate
that the channel is not viewable.

PROGRAM LIST

USING PROGRAM

LIST AND ALTERNATE CHANNEL

Using the Remote Control

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

SWAP PIP CH

2

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

RECORD

TV

VCR

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879
0

PIP ON/OFF

SURF

REC •

SLEEP

FORMAT

SAP

ITR/

PROG.LISTDOLBY VAV

HOME

HOME

VIDEO

MOVIES

PIPPOSITION

POWER

ACC

FREEZE


SURF

PERSONAL

MENU/
SELECT

PROGRAM LIST

71 - - - - ­ 72 - - - - ­ 98 - - - - ­ AV 1 - - - - ­ CVI - - - - -

A padlock image will appear to the
right of a channel or signal source
that is being blocked by AutoLock™.

3

CH

PROGRAM LIST

7 - - - - ­ 8 - - - - ­ 9 - - - - ­ 10 - - - - ­ 11 - - - - -

1

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/
SELECT

MUTE

213
546
879

SURF

0

POSITION

PIP

A/CH

Button

Watch channel

5

Change channel

Watch new channel

10

CH

Press A/CH button
to return to previously
watched channel

29

USING THE S

LEEP TIMER CONTROL

H

ave you ever fallen asleep in front of the

TV? You can program your TV to turn
off while you sleep. The Sleep Timer feature
allows you to set your TV to turn off within a
certain amount of time: 15, 30, 45, 60, 90,
120, 180, or 240 minutes.

Press the SLEEP button on the remote con-

trol. (The SLEEP Timer on-screen display

will appear on screen.) Then within five

seconds, press the SLEEP button again as
many times as necessary to select the

amount of time you want to pass before the
TV will turn itself off.

An on-screen countdown will appear during
the last minute before the TV turns off. Ten
seconds before the Sleep Timer turns the TV
off, the on-screen display will show “Good
Bye.”

Using the Remote Control

•To see how many minutes remain before
the TV shuts itself off, press the
STATUS/EXIT button.

• Changing the channel or volume during
the last minute of a Sleep Timer will
cancel Sleep.

HELPFUL HINTS

SLEEP OFFSLEEP OFF

POWER

TV

SWAP PIP CH

DN

SOUND

ACC

VCR

ACTIVE

CONTROL

FREEZE

UP


SLEEP 15

The Sleep Timer options are 15, 30, 45,
60, 90, 120, 180, or 240 minutes.

TV SWITCHING OFF 59

POWER

ACC

TV

VCR

ACTIVE

SWAP PIP CH

FREEZE

CONTROL

DN

UP


SOUND

STATUS/

EXIT

VOL

MUTE

213
546
879

TV/VCR

A/CH

0

PIP ON/OFF

SURF

REC •

FORMAT

SAP

ITR/

HOME

RECORD

HOME

VIDEO

MOVIES

SLEEP

PROG.LISTDOLBY VAV

PERSONAL

PIPPOSITION

MENU/
SELECT

SURF

CH

SLEEP
Button

During the last minute of a Sleep Timer
setting, an onscreen countdown will be
displayed.

GOOD BYE

TV SWITCHING OFF 9

During the last 10 seconds of a Sleep
Timer setting, "GOOD BYE" will be
displayed on screen.

30

Picture-adjustment Options

Remember, when the bar scale is centered

, the control settings are at nor­mal, mid-range levels. Picture adjustments
are described as follows:

BRIGHTNESS adds or subtracts light from

the darkest part of the picture.

COLOR adds or eliminates color.
PICTURE improves the detail of the lightest

parts of the picture.

SHARPNESS improves the detail in the

picture.

TINT adjusts the picture to obtain natural

skin tones.

COLOR TEMP offers NORMAL, COOL,
or WARM picture preferences.

NORMAL keeps whites, white.
WARM makes whites, reddish.
COOL makes whites, bluish.

T

o adjust your TV picture controls, select a

channel and follow these steps. See descrip-

tions of the picture-adjustment options below.

1

Press the MENU/SELECT button on

the remote control to show the on-screen
menu.

2

Press the CURSOR RING RIGHT.

BRIGHTNESS will be highlighted and an
adjustment bar will be shown to the right.

3

Press the CURSOR RING RIGHT or
LEFT to adjust the BRIGHTNESS level

of the picture. Or press the CURSOR
RING DOWN to select another picture
control to adjust.

4

Press the STATUS/EXIT button to exit

the menu.

Using the On-screen Submenus: Picture

ADJUSTING THE P

ICTURE CONTROLS

4


SOUND
FEATURES
INSTALL

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

BRIGHTNESS
COLOR
SHARPNESS
TINT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP

MUTE

2,3


MENU/
SELECT

CH

1

213
546
879

SURF

0

POSITION

PIP


BRIGHTNESS 30

COLOR
SHARPNESS
TINT


BRIGHTNESS

COLOR 30

SHARPNESS
TINT


BRIGHTNESS
COLOR

PICTURE 30

SHARPNESS
TINT


BRIGHTNESS
COLOR

SHARPNESS 30

TINT


BRIGHTNESS
COLOR
SHARPNESS

TINT 0


COLOR
SHARPNESS
TINT

COLOR TEMP NORMAL

OR

COLOR TEMP WARM

OR

COLOR TEMP COOL

31

SETTING THE E

YE FIDELITY CONTROL

E

ye Fidelity gives you a choice between
two different scanning techniques—pro-

gressive or interlaced.
Progressive scan doubles the number of pic-

ture lines, eliminating line flicker and pro­viding a jitter-free picture.

Interlaced improves the appearance of on­screen motion. It also helps smooth out
jagged lines that are sometimes seen on
curved and angled surfaces in the picture.

1

Press the MENU/SELECT button

on the remote to show the on-screen
menu.

2

Press the CURSOR RING RIGHT

to enter the PICTURE submenu.

3

Press the CURSOR RING DOWN

repeatedly until the EYE FIDELITY
control is highlighted.

4

Press the CURSOR RING RIGHT
or LEFT until you select the option

you want, either PROGRESSIVE or
INTERLACED.

5

Press the STATUS/EXIT button to

turn the menu off.

Using the On-screen Submenus: Picture

• The Eye Fidelity control is not available
for use with AV4 and AV5.

•You may want to use the interlaced
option to enhance programs containing a
lot of motion.

HELPFUL HINT


SOUND
FEATURES
INSTALL

TV

SWAP PIP CH

SOUND

BRIGHTNESS
COLOR
SHARPNESS
TINT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP

2,4


5

STATUS/

EXIT

VOL

3

TV/VCR

MUTE

A/CH

MENU/

SELECT

CH

1

213
546
879

SURF

0


BRIGHTNESS 30

COLOR
SHARPNESS
TINT


SHARPNESS
TINT
COLOR TEMP

PROGRESSIVE

EYE FIDELITY

OR

EYE FIDELITY INTERLACED

POSITION

PIP

32

SETTING THE DYNAMIC CONTRAST CONTROL

T

he Dynamic Contrast control allows you

to sharpen the picture quality by making
dark portions of the picture darker and light
portions of the picture more noticeable.
Normally, you will probably want to select
MED. In certain circumstances, however,
you may prefer MIN or MAX.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING RIGHT
to enter the PICTURE submenu.

3

Press the CURSOR RING DOWN

repeatedly until the DYN. CON­TRAST control is highlighted.

4

Press the CURSOR RING RIGHT
or LEFT until you select the option

you want: MIN, MED, or MAX.

5

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Picture

The Dynamic Contrast control is not avail­able for use with the AV4 and AV 5 signal

HELPFUL HINT

5


SOUND
FEATURES
INSTALL

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

3

TV/VCR

A/CH

BRIGHTNESS
COLOR
SHARPNESS
TINT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/
SELECT

MUTE

213
546
879

SURF

0

POSITION

PIP

2,4

CH

1


BRIGHTNESS 30

COLOR
SHARPNESS
TINT


SHARPNESS
TINT
COLOR TEMP

ON

EYE FIDELITY

DYN. CONTRAST MIN

OR

DYN. CONTRAST MED

OR

DYN. CONTRAST MAX

OR

DYN. CONTRAST OFF

ADJUSTING THE MANUAL CONVERGE CONTROLS:CONVERGE RED/BLUE

Using the On-screen Submenus: Picture

A

s explained in the Quick Use and Setup

Guide, your projection TV has three color
projection tubes: one for red, one for green, and
one for blue. When mixed in proper proportion,
the beams of light coming from the tubes can
produce any color. To create a clear picture,
however, these color beams must be precisely
aligned. This alignment is called conv ergence.
Bumps and vibrations, moving the set, or the
presence of magnetic fields can cause the color
beams to become improperly aligned, or mis­converged, resulting in a fuzzy picture. Using
the Auto IntelliSense™ feature, you can auto­matically adjust convergence in 20 seconds or
less. See page 7 in the Quick Use and Setup
Guide. Also, if you desire, you can use the
MANUAL CONVERGE controls—explained on
this page and the next—to make additional con­vergence adjustments to suit your personal pref­erences or to further fine-tune the picture. See
the chart to the right to determine which
MANUAL CONVERGE controls to use for cur­rent picture conditions.

NOTE: Allow the TV to warm up for 20 minutes
before adjusting convergence.

1

Press the MENU/SELECT button to

show the on-screen menu. Press the
CURSOR RING RIGHT to enter the
PICTURE submenu. Then press the
CURSOR RING DOWN repeatedly until
MANUAL CONVERGE is highlighted.

2

Press the CURSOR RING RIGHT to

enter the MANUAL CONVERGE
submenu. If you want to adjust the Red
Convergence, press the CURSOR RING
RIGHT to enter the adjust mode. To
adjust the Blue Convergence, press the
CURSOR RING DOWN to highlight
CONVERGE BLUE, then press the
CURSOR RING RIGHT to enter adjust
mode.

3

In adjust mode, press the CURSOR
RING RIGHT, LEFT, UP, or DOWN

to adjust the cross hair until the color
outline around it is gone. (The adjust­ment is automatically saved in the TV’s
memory.) To return to the MANUAL
CONVERGE menu, press the
MENU/SELECT button. To exit the on­screen display, press the STATUS/EXIT
button.

Determining Which

Manual Converge

Control to Use

33

MANUAL CONVERGE

CONVERGE RED

CONVERGE BLUE
MULTIPOINT RED
MULTIPOINT BLUE
SAVE MULTIPOINT

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

POSITION

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP

MUTE

213
546
879
0

2,3


MENU/

SELECT

CH

SURF

PIP

1

Converge Red

Converge Red

neercS

ecnaraeppanoitcA

suoiraV

segami

tuohguorht

eritneeht

evaherutcip

.seniltuoder

suoiraV

segami

tuohguorht

eritneeht

evaherutcip

.seniltuoeulb

ehttsujdA

EGREVNOC

.lortnocDER

derynafinehT

,niamerseniltuo

ehttsujda

TNIOPITLUM
.lortnocDER

ehttsujdA

EGREVNOC

.lortnocEULB

eulbynafinehT

,niamerseniltuo

ehttsujda

TNIOPITLUM

.lortnocEULB

ADJUSTING THE MANUAL CONVERGE CONTROLS:MULTIPOINT RED/BLUE

Using the On-screen Submenus: Picture

T

he Multipoint Red/Blue Convergence controls

allow you to adjust picture convergence at

specific points on the TV screen.

1

Press the MENU/SELECT button to

show the on-screen menu. Press the
CURSOR RING RIGHT to enter the
PICTURE menu, then the CURSOR
RING DOWN repeatedly until
MANUAL CONVERGE is highlighted.

2

Press the CURSOR RING RIGHT to

enter the MANUAL CONVERGE sub­menu. Press the CURSOR RING DOWN
repeatedly until MULTIPOINT RED or
MULTIPOINT BLUE is highlighted. Then
press the CURSOR RING LEFT or
RIGHT to enter Navigate mode.

3

Press the CURSOR RING LEFT,
RIGHT, UP, or DOWN to move to a

cross hair that has a color outline. Then
press the STATUS/EXIT button to enter
adjust mode.

4

Press the CURSOR RING LEFT,
RIGHT, UP, or DOWN to adjust the

cross hair until the color outline is
gone.Then press the STATUS/EXIT
button to return to NAVIGATE mode.
Repeat steps 3 and 4 until all misaligned
cross hairs have been adjusted.

5

For your adjustments to be stored in the
TV’s memory, you must activate SAVE
MULTIPOINT.
NOTE: If you are not satisfied with the

adjustments you just made and want to
start over, you can use the UNDO
MULTIPOINT control. This control
allows you to undo the adjustments, but
only if you use it before saving.

To save your multipoint adjustments,
press the MENU/SELECT button to

return to the MANUAL CONVERGE
menu. Press the CURSOR RING DOWN
repeatedly until SAVE MULTIPOINT is
highlighted. Then press the CURSOR
RING LEFT or RIGHT to store your
adjustments in the TV’s memory.

Or, to undo the multipoint adjustments
you just made, highlight UNDO

MULTIPOINT and press the CURSOR
RING LEFT or RIGHT.

Or, to restore the TV’s convergence to
factory settings, highlight RESTORE

FACTORY and press the CURSOR RING
LEFT or RIGHT.

6

Press the STATUS/EXIT button to

exit the menu.

HELPFUL HINTS

•

The on-screen display
will disappear after 20
seconds of inactivity. If
this happens, simply
press the
MENU/SELECT
button to bring the
MANUAL
CONVERGE
submenu back.

• If you should experi­ence a power outage
before saving your
multipoint-convergence
settings, your

settings

will be lost.

34

MANUAL CONVERGE

CONVERGE RED

CONVERGE BLUE
MULTIPOINT RED
MULTIPOINT BLUE
SAVE MULTIPOINT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

UP

MUTE

3,4

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV

DN

6

213
546
879

TV/VCR

A/CH

POSITION

0

SURF

PIP


SELECT

MANUAL CONVERGE

CONVERGE RED
CONVERGE BLUE

MULTIPOINT RED

MULTIPOINT BLUE

▲

▲

SAVE MULTIPOINT

to Navigate Exit to Adjust

É

to Navigate Exit to Adjust

to Adjust Exit to Navigate

2

MENU/

CH

1,5

to Navigate Exit to Adjust

to Adjust Exit to Navigate

MANUAL CONVERGE

CONVERGE RED
CONVERGE BLUE

MULTIPOINT RED

MULTIPOINT BLUE

▲

SAVE MULTIPOINT

MANUAL CONVERGE

CONVERGE BLUE

MULTIPOINT RED

MULTIPOINT BLUE
SAVE MULTIPOINT

▲

UNDO MULTIPOINT

MANUAL CONVERGE

MULTIPOINT RED

MULTIPOINT BLUE
SAVE MULTIPOINT

UNDO MULTIPOINT

▲

RESTORE FACTORY

SAVE MULTIPOINT

OR

UNDO MULTIPOINT

OR

RESTORE FACTORY

to Adjust Exit to Navigate

MANUAL CONVERGE

CONVERGE RED
CONVERGE BLUE

MULTIPOINT RED

MULTIPOINT BLUE

▲

▲

SAVE MULTIPOINT

MANUAL CONVERGE

CONVERGE RED
CONVERGE BLUE

MULTIPOINT RED

MULTIPOINT BLUE

▲

SAVE MULTIPOINT STORED

MANUAL CONVERGE

CONVERGE BLUE

MULTIPOINT RED

MULTIPOINT BLUE
SAVE MULTIPOINT

▲

UNDO MULTIPOINT RESTORED

MANUAL CONVERGE

MULTIPOINT RED

MULTIPOINT BLUE
SAVE MULTIPOINT

UNDO MULTIPOINT

▲

RESTORE FACTORY RESTORED

É

35

ADJUSTING THE T

REBLE,BASS, AND BALANCE CONTROLS

B

esides the normal volume level control,

your TV also has individual sound­adjustment controls. You can use TREBLE
(high frequency), BASS (low frequency), and
Speaker BALANCE to further adjust the
sound playback of TV programs.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

once to highlight SOUND.

3

Press the CURSOR RING RIGHT

to enter the SOUND submenu.

4

To adjust the TREBLE level of the
television’s sound, press the
CURSOR RING RIGHT or LEFT.
T

o adjust another sound control,

press the CURSOR RING DOWN

until the control (BASS or BALANCE)
is highlighted. Then press the
CURSOR RING RIGHT or LEFT to
adjust the selected control.

5

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Sound

When the bar scale is centered, speaker sound
BALANCE is centered between the TV’s left
and right side speakers.

HELPFUL HINT


SOUND

FEATURES
INSTALL

TV

SWAP PIP CH

SOUND

DN

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

VCR

ACTIVE

CONTROL

UP

POWER

ACC

FREEZE


3,4

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

SOUND

TREBLE

BASS 30

BALANCE
AVL
INCR . SURROUND

5

STATUS/

EXIT

VOL

2,4

TV/VCR

A/CH

POSITION

MENU/
SELECT

MUTE

CH

1

213
546
879

SURF

0

PIP

SOUND

TREBLE
BASS

BALANCE 0

AVL
INCR . SURROUND

36

USING THE AVL (AUDIO VOLUME LEVELER) CONTROL

Y

ou may have noticed the peaks and val-

leys of sound that occur between pro­gram changes or at commercial breaks. The
volume levels often vary considerably. By
turning on the AVL (Audio Volume Leveler)
control, you can make your TV produce a
more consistent volume level. Follow these
steps to turn the AVL control on.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

once to highlight SOUND.

3

Press the CURSOR RING RIGHT

to enter the SOUND submenu.

4

Press the CURSOR RING DOWN

repeatedly until AVL is highlighted.
Then press the CURSOR RING
RIGHT or LEFT to turn AVL ON or
OFF.

5

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Sound

The AVL control does not function with the
Dolby* Virtual feature, so the option disap­pears from the SOUND submenu when you

HELPFUL

HINT

*Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.


SOUND

FEATURES
INSTALL

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

5

2,4

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/

SELECT

MUTE

213
546
879

SURF

0

POSITION

PIP

SOUND

TREBLE
BASS
BALANCE

AVL OFF

INCR . SURROUND

3

OR

AVL ON

CH

1

37

SELECTING THE SURROUND-SOUND MODES

B

ased on the signal being received, you can

select various surround-sound modes:
MONO, SPATIAL, STEREO, INCR. SUR­ROUND, or DOLBY* VIRTUAL (Virtual
Dolby Surround). (See descriptions of the
options to the right.)

*Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are
trademarks of Dolby Laboratories.

Using the On-screen Submenus: Sound

The AVL (Audio Volume Leveler) control does
not function with the Dolby Virtual feature, so
the option disappears from the SOUND sub-

H

ELPFUL HINT

Selecting a Surround-sound

Option Using the TV Buttons

Should your remote control become lost or other­wise unavailable for use, follow the steps below to
use the buttons on the front of the TV to access the
on-screen menu and select a surround-sound
mode.

1

Press the Volume + and – buttons
simultaneously. The on-screen menu

appears.

2

Press the Channel Down button to

highlight SOUND. Then press the
Volume + button to enter the SOUND
submenu.

3

Press the Channel Down button

repeatedly until INCR. SURROUND is
highlighted. Then press the Volume + or
– button until you select the surround­sound mode you want.

4

Press the Volume + and – buttons
simultaneously and repeatedly until you

back out of the menu screens.

Selecting a Surround-sound

Option Using the

Remote Control

While watching TV, you can select a surround­sound listening mode immediately by pressing the
DOLBY V button. Each press of the DOLBY V
button selects a different mode based on the TV
signal being received.

Surround-sound Modes

In stereo: select STEREO, INCR.
SURROUND, or DOLBY VIRTUAL.

INCR. (Incredible) SURROUND

enhances stereo programs by making the
sound broader and fuller.

DOLBY VIRTUAL (with Virtual Dolby
Surround signals) creates a virtualized sur-

round-sound experience from two speakers
using Dolby Pro Logic.* It retains all the
original multichannel audio information and
provides the listener with the sensation of
being surrounded by additional speakers.

In mono: select MONO or SPATIAL.
SPATIAL enables you to add a surround

effect to mono programs.

213
546
879

TV/VCR

A/CH

0

SURF

PIP ON/OFF

REC •

FORMAT

SAP

ITR/

HOME
VIDEO


SOUND

FEATURES
INSTALL

HOME

MOVIES

RECORD

SLEEP

SURF

PROG.LISTDOLBY VAV

PERSONAL

PIPPOSITION

Dolby V

Button

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

SOUND

TREBLE
BASS
BALANCE
AVL OFF

INCR . SURROUND STEREO

OR

FORMAT EXPAND 4:3

INCR . SURROUND INCR . SURROUND

Or, when signals are being
broadcast in Virtual Dolby
Surround:

INCR . SURROUND DOLBY VIRTUAL

When signals are being broad­cast in mono (nonstereo):

INCR . SURROUND MONO

OR

INCR . SURROUND SPATIAL

38

SELECTING THE S

TEREO/MONO SOUND MODE

Y

ou can enjoy stereo programs on your

TV. It has both an amplifier and twin
speakers through which stereo sound can be
heard. Follow these steps to select the
STEREO mode.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

once to highlight SOUND.

3

Press the CURSOR RING RIGHT

to enter the SOUND submenu.

4

Press the CURSOR RING DOWN

repeatedly until the STEREO control
is highlighted.

5

Press the CURSOR RING RIGHT
or LEFT to select STEREO or

MONO. When STEREO has been
selected, the television will reproduce
any stereo signal it receives.

6

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Sound

6

2,4


SOUND

FEATURES
INSTALL

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

DN

VCR

ACTIVE

CONTROL

UP

MUTE

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

POWER

ACC

FREEZE

3,5


MENU/
SELECT

CH

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

SOUND

BALANCE
AVL
INCR . SURROUND
HEADPHONE

STEREO MONO

OR

STEREO STEREO

1

213
546
879

TV/VCR

A/CH

SURF

0

POSITION

PIP

39

SELECTING THE SAP (SECOND AUDIO PROGRAM) FEATURE

Using the On-screen Submenus: Sound

S

AP, or Second Audio Program, is an addi-

tional part of the stereo broadcast system.
Sent as a third audio channel, an SAP can be
heard apart from the current TV program sound.
TV stations are free to use SAP for any number
of purposes, such as the broadcast of a second
language or other audio information.

If an SAP signal is not present with a selected
program, the SAP option cannot be selected.

Selecting SAP Using

the TV Buttons

Should your remote control become lost or other­wise unavailable for use, follow the steps below to
use the buttons on the front of the TV to access the
on-screen menu and select SAP.

NOTE: SAP must be broadcast with the program
you are watching for you to be able to select the
feature.

1

Press the Volume + and – buttons
simultaneously. The on-screen menu

appears.

2

Press the Channel Down button to

highlight SOUND. Then press the
Volume + button to enter the SOUND
submenu.

3

Press the Channel Down button

repeatedly until SAP is highlighted.
Then press the Volume + or – button to
turn SAP on or off.

4

Press the Volume + and – buttons
simultaneously and repeatedly until you

back out of the menu screens.

Selecting SAP Using
the Remote Control

Select SAP immediately by pressing the
SAP button on the remote control if the feature is
being made available with the program you are
watching.

STATUS/

EXIT

VOL

MUTE

213
546
879

TV/VCR

A/CH

RECORD

ITR/

Button

0

PIP ON/OFF

SURF

REC •

FORMAT

SAP

HOME

HOME

VIDEO

MOVIES

SAP

SURF

SLEEP

PROG.LISTDOLBY VAV

PERSONAL

PIPPOSITION

MENU/
SELECT

CH


SOUND

FEATURES
INSTALL

SOUND

AVL
INCR . SURROUND
HEADPHONE
STEREO

SAP OFF

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

If a Second Audio Program

is being broadcast:

SAP ON

OR

SAP OFF

If a Second Audio Program

is not being broadcast:

SAP NOT AVAILABLE

OR

SAP OFF

40

USING THE B

ASS BOOST CONTROL

T

he BASS BOOST control allows you to

increase the low-frequency range of the
TV’s sound. This creates a deeper, fuller
sound. Follow these steps to turn BASS
BOOST ON.

1

Press MENU/SELECT button on

the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

once to highlight SOUND.

3

Press the CURSOR RING RIGHT

to enter the SOUND submenu.

4

Press the CURSOR RING DOWN

repeatedly until BASS BOOST is
highlighted.

5

Press the CURSOR RING RIGHT
or LEFT to turn BASS BOOST ON

or OFF.

6

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Sound


SOUND

FEATURES
INSTALL

6

STATUS/

EXIT

VOL

2,4

TREBLE
BASS
BALANCE
AVL
INCR . SURROUND

POWER

TV

SWAP PIP CH

DN

SOUND

ACC

VCR

ACTIVE

FREEZE

CONTROL

UP

MUTE


MENU/

SELECT

CH

3,5

1

SOUND

TREBLE 30

BASS
BALANCE
AVL
INCR . SURROUND

SOUND

STEREO
SAP
AUDIO OUT
SPEAKERS

BASS BOOST ON

OR

BASS BOOST OFF

213
546
879

TV/VCR

A/CH

0

POSITION

PIP

SURF

41

SETTING THE CLOCK

Y

our TV comes with an on-screen clock. You

will need to set the clock before you can use
the Timer feature. During normal operation, the
time appears on the screen when you press the
STATUS/EXIT button. You can show the time on
screen constantly by turning the TIMERDIS­PLAY control on (see page 42).

For instructions on setting the Timer’s START
and STOP times, see page 43. Then go to pages
44 and 45 to learn how to select the Timer’s
channel and activate the Timer.

NOTE:You can access the TIME (clock) feature
directly by pressing the Clock button on the
remote control.

1

Press the MENU/SELECT button on

the remote control to show the on-screen
menu.

2

Press the CURSOR RING DOWN

twice to highlight FEATURES.

3

Press the CURSOR RING RIGHT to

enter the FEATURES submenu.

4

Press the CURSOR RING RIGHT

again to shift the display left and high­light the TIME control.

5

Press the CURSOR RING RIGHT

again to highlight the time indicator area.

6

Press the NUMBER buttons to enter

the correct time. If you make a mistake
entering the time, press the CURSOR
RING LEFT or RIGHT to move among
the input slots to make corrections.

NOTE:You can also press the CURSOR

RING UP or DOWN to cycle through
digits to input the time.

7

Press the CURSOR RING UP or
DOWN to select AM or PM.

8

Press the STATUS/EXIT button to exit

the menu.

Using the On-screen Submenus: Features

•For single-digit entries, be sure to press 0

first and then the hour number.

• If you’d like, set the clock automatically
using the AutoChron™ feature (on page 6

in the Quick Use and Setup Guide).

• Clock settings may be lost when the TV is
unplugged or when AC power to the set is

HELPFUL HINTS


SOUND

FEATURES

INSTALL

SWAP PIP CH

7

SOUND

TV

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

VCR

ACTIVE

CONTROL

DN

FREEZE

UP


8

STATUS/

EXIT

VOL

MUTE

2

213
546
879

TV/VCR

6

A/CH

RECORD

SURF

REC •

SAP

ITR/

HOME
VIDEO

0

FORMAT

HOME

MOVIES

PIP ON/OFF

SLEEP

SURF

Clock

Button

PROG.LISTDOLBY VAV

PERSONAL

PIPPOSITION

3,4,

MENU/

SELECT

CH

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER

TIME _ _:_ _

START TIME
STOP TIME
CHANNEL

ACTIVATE

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

5

FEATURES

TIMER

TIME 8:00 PM

START TIME
STOP TIME

1

Access the TIME (Clock) feature
directly by pressing the Clock
button on the remote control.
After doing so, follow steps 5–8
on this page to set the clock.

CHANNEL

ACTIVATE

42

DISPLAYING THE

TIME

A

fter you have set the TV’s clock, you can

use your TV to keep up with the time on
screen. You can also set the timer to switch
to another channel, and, if you want, turn
the TV off. The Timer’s DISPLAY control
allows you to show the time constantly in the
upper right corner of the screen.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

twice to highlight FEATURES.

3

Press the CURSOR RING RIGHT

to enter the FEATURES submenu.

4

Press the CURSOR RING RIGHT

again. Then press the CURSOR RING
DOWN repeatedly until the DISPLAY
control is highlighted.

5

Press the CURSOR RING RIGHT
or LEFT to turn the TIMER DIS-

PLAY ON or OFF.

6

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Features


SOUND

FEATURES

INSTALL

TV

SWAP PIP CH

SOUND

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


6

STATUS/

EXIT

VOL

MUTE

MENU/

SELECT

CH

2

213
546
879

TV/VCR

A/CH

SURF

0

3,4,

5

1

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER

TIME 8:06 PM

START TIME
STOP TIME
CHANNEL

ACTIVATE

FEATURES

TIMER

START TIME
STOP TIME

CHANNEL

ACTIVATE

DISPLAY ON

DISPLAY OFF

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

OR

POSITION

PIP

43

SETTING THE TIMER’S START TIME AND STOP TIME

Y

ou can set the Timer to switch to a selected

channel at a specific time while you are
watching another channel, or when the TV is in
standby mode. (Standby mode is when the TV is
plugged into the wall outlet but turned off.) If
you want, you can also set the TV to turn off at
some time after the TV switches channels.
Follow the steps below to set the Timer’s
START TIME and STOP TIME.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

twice to highlight FEATURES.

3

Press the CURSOR RING RIGHT to

enter the FEATURES submenu.

4

Press the CURSOR RING RIGHT

again. Then press the CURSOR RING
DOWN once to highlight the START
TIME control.

5

Press the CURSOR RING RIGHT

to highlight the time indicator area.

6

Press the NUMBER buttons to enter

the correct time. If you make a mis­take entering the time, use the CUR­SOR RING LEFT or RIGHT to move
among the time input slots to make
corrections.

NOTE:You can also use the CUR-

SOR RING UP or DOWN to cycle
through digits to input the time.

7

Press the CURSOR RING UP or
DOWN to select AM or PM.

8

Press the CURSOR RING LEFT

repeatedly until START TIME is high­lighted. Then press the CURSOR RING
DOWN to highlight STOP TIME. If you
want the TV to switch off at some time
after the changing of channels, follow
steps 5–7 above to set the STOP TIME.

9

Press the STATUS/EXIT button to exit

the menu.

See pages 44 and 45 for instructions on selecting
the Timer’s channel and activating the timer.

Using the On-screen Submenus: Features


SOUND

FEATURES

INSTALL

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

9

6

8

SWAP PIP CH

7

SOUND

STATUS/

EXIT

VOL

TV/VCR

TV

VCR

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879

A/CH

0

POSITION

PIP

POWER

ACC

FREEZE


2

2

SURF

MENU/

SELECT

CH

3,4,

5

1

FEATURES

TIMER

TIME 8:06 PM

START TIME
STOP TIME
CHANNEL

ACTIVATE

FEATURES

TIMER

TIME

START TIME _ _:_ _

STOP TIME
CHANNEL

ACTIVATE

FEATURES

TIMER

TIME
START TIME 8:00 AM

STOP TIME
CHANNEL

ACTIVATE

FEATURES

TIMER

TIME

START TIME

STOP TIME _ _:_ _

CHANNEL

ACTIVATE

FEATURES

TIMER

TIME
START TIME

STOP TIME 9:30 AM
CHANNEL

ACTIVATE

44

SELECTING THE T

IMER’S CHANNEL

F

ollow these steps to select the channel to
which the Timer will switch the TV.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

twice to highlight FEATURES.

3

Press the CURSOR RING RIGHT to

enter the FEATURES submenu.

4

Press the CURSOR RING RIGHT.

Then press the CURSOR RING
DOWN repeatedly until the CHANNEL
control is highlighted.

5

Press the NUMBER buttons to enter

the desired start-up channel. Or press
the CURSOR RING RIGHT repeatedly
to enter the start-up channel you want.

6

Press the STATUS/EXIT button to

exit the menu.

NOTE: Before the Timer will work, you

must activate it. See page 45.

Using the On-screen Submenus: Features


SOUND

FEATURES

INSTALL

TV

VCR

SWAP PIP CH

DN

UP

SOUND

6

STATUS/

EXIT

VOL

5

MUTE

213
546
879

TV/VCR

A/CH

0

POSITION

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACTIVE

CONTROL

PIP

ACC

FREEZE


MENU/
SELECT

2

2

SURF

3,4

CH

1

FEATURES

FEATURES

TIMER

FEATURES

TIMER

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIME 8:06 PM

START TIME
STOP TIME
CHANNEL

ACTIVATE

TIME
START TIME
STOP TIME

CHANNEL 5

ACTIVATE

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

45

SETTING THE T

IMER’S ACTIVATE CONTROL

A

fter you have set the TIME, START

TIME, STOP TIME, and CHANNEL,
you must activate the Timer for it to operate.
Your options are to set the Timer to work
ONCE or DAILY. Set ACTIVATE to OFF if
you don’t want to use the Timer.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

twice to highlight FEATURES.

3

Press the CURSOR RING RIGHT

to enter the FEATURES submenu.

4

Press the CURSOR RING RIGHT

again. Then press the CURSOR RING
DOWN repeatedly until the ACTI­VATE control is highlighted.

5

Press the CURSOR RING RIGHT

to cycle through the options and make
your selection. The options are
ONCE, DAILY, or OFF.

6

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Features

• Changing the channel or adjusting the
volume during the last minute of a Timer
setting will cancel the shutting off of the
TV.

•Thirty seconds before the set changes to
the channel you set (see page 44), an
announcement appears on screen.

HELPFUL HINT


SOUND

FEATURES

INSTALL

TV

SWAP PIP CH

SOUND

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

VCR

DN

UP

ACTIVE

CONTROL

3,4,

FREEZE


5

FEATURES

FEATURES

TIMER

6

STATUS/

EXIT

VOL

TV/VCR

A/CH

MUTE

POSITION

MENU/

SELECT

CH

2

2

213
546
879

SURF

0

PIP

1

FEATURES

TIMER

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIME 8:06 PM

START TIME
STOP TIME
CHANNEL

ACTIVATE

TIME
START TIME
STOP TIME

CHANNEL

ACTIVATE ONCE

ACTIVATE DAILY

ACTIVATE OFF

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

OR

OR

CHANGING TO
CHANNEL 5
IN 29 SEC

46

UNDERSTANDING A

UTOLOCK™

TV -Y (All Children)—designed to

be appropriate for all children,

especially ones ages 2–6. Programs
rated TV-Y are not expected to frighten
younger children.

TV -Y7 (Directed to Older

Children)—designed for children

ages 7 and older. Programs rated
TV-Y7 may be more appropriate for chil­dren who have acquired the development
skills needed to distinguish between
make-believe and reality. Such programs
may include mild fantasy and comic vio­lence (FV).

TV -G (General A udience)—most

parents will consider programs that

are rated TV-G to be suitable for
children of all ages. Such programs have
little or no violence, no strong language,
and little or no sexual dialogue or sexual
situations.

TV -PG (Parental Guidance
Suggested)—contain material that

parents may find unsuitable for
younger children. This type of program­ming has one or more of the following:
moderate violence (V), some sexual situ­ations (S), infrequent coarse language
(L), or some suggestive dialogue (D).

TV -14 (Parents Strongly

Cautioned—contain material that

many parents will find unsuitable
for children under 14 years of age. Such
programs have one or more of the follow­ing: intense violence (V); intense sexual
situations (S); strong, coarse language
(L); or intensely suggestive dialogue (D).

TV -MA (Mature A udience Only)—

specifically designed to be viewed by

adults and therefore may be unsuit­able for children under 17. Such programs
have one or more of the following: graphic
violence (V); explicit sexual situations (S);
or crude, indecent language (L).

TV PARENTAL GUIDELINES

(TV BROADCASTERS

)

TV

G

TV

PG

TV

Y

TV

Y7

TV

14

TV

MA

G (General Audience)—all ages

admitted. Most parents will find pro­grams that are rated G to be suitable
for children of all ages. Such programs
have little or no violence, no strong
language, and little or no sexual dialog
or sexual situations.

PG (Parental Guidance
Suggested)—

contain material that par­ents may find unsuitable for younger
children. Programs that are rated PG
have one or more of the following: mod­erate violence, some sexual situations,
infrequent coarse language, or some
suggestive dialog.

PG-13 (Parents Strongly
Cautioned)—contain material that par-

ents may find unsuitable for children
under the age of 13. Programs that are
rated PG-13 have one or more of the
following: violence, sexual situations,
coarse language, or suggestive dialog.

R (Restricted)—specifically designed

for adults. Anyone under the age of 17
should view programs that are rated R
only with an accompanying parent or
adult guardian. Such programs have one
or more of the following: intense vio­lence; intense sexual situations; strong,
coarse language; or intensely suggestive
dialogue.

NC-17 (No one under the age of 17
will be admitted)—should be viewed

by adults only. Programs that are rated
NC-17 have graphic violence; explicit
sex; or crude, indecent language.

X (Adults Only)—contain one or more

of the following: very graphic violence,
very graphic and explicit or indecent
sexual acts, or very coarse and intensely
suggestive language.

MOVIE RATINGS

(M

OTION

P

ICTUREASSOCIATION OFAMERICA

)

T

he AutoLock™ feature can help par-

ents control what their children watch
on TV. AutoLock™ does this by using the
content advisories sent by broadcasters
or other program providers. After you
program AutoLock™, it can respond to
the content advisories and block pro­grams that contain content that you may
consider objectionable—offensive lan­guage, violence, or sexual situations. You
can also use AutoLock™ to block chan­nels that you don’t want your children to
watch.

In this section, you’ll learn how to block
channels and programming that is not
rated, is unrated, or has no rating. You
will also find out how to turn these block­ing features on or off. Following on this
page are brief explanations of
AutoLock™ terms and program ratings.

Terms
BLOCKING control—can be thought

of as the “master switch” for
AutoLock™. This control affects the set­tings you have chosen for blocking pro­grams according to movie ratings or TV
ratings, or for blocking programs that
have no rating or are unrated. When the
BLOCKING control is OFF, the blocking
or censoring of programs is disabled.
When the BLOCKING control is ON,
blocking will occur according to the set­tings you have chosen.

BLOCK UNRATED control—if set to

ON, blocks all unrated programs.

Unrated programming consists of the
kind of shows that the MPAA (Motion
Picture Association of America) or the
TV broadcasters have chosen not to rate.

NO RATING control—if set to ON,

blocks all programming with no content
advisory data.

Programming that has No Rating is not
encoded with any rating information
from the MPAA or the Parental
Guidelines. Any programming could fall
into this category.

BLOCK CHANNEL control—enables

you to block individual channels that you
don’t want children to see.

Using the On-screen Submenus: Features

AutoLock

MOVIE RATING

G

PG
PG-13
R
NC-17

ON

AutoLock

TV RATING

TV-Y

TV-Y7
TV-G
TV-PG
TV-14

ON

47

SETTING UP THE AUTOLOCK™ ACCESS CODE

Y

our AutoLock™ access code allows

you to enter the AutoLock™ submenus
to set up or turn off blocking. Your access
code is also the “key” that unlocks pro­grams or channels that are being blocked
by AutoLock™.

1

Press the MENU/SELECT button

on the remote control to show the
on-screen menu.

2

Press the CURSOR RING DOWN

twice to highlight
FEATURES.

3

Press the CURSOR RING
RIGHT. Then press the CURSOR

RING DOWN once to highlight the
AutoLock control.

4

Press the CURSOR RING
RIGHT to highlight ACCESS

CODE.

5

Press 0,7,1,1 on the remote control.

INCORRECT will appear on the
screen.

6

Press 0,7,1,1 on the remote control

again. ENTER NEW CODE will
appear on the screen.

7

Enter a new four-digit code using

the number buttons. CONFIRM
CODE will appear on the screen.

8

Enter your new four-digit code

again. CORRECT will flash on the
screen briefly.

9

Press the STATUS/EXIT button

exit the menu.

Using the On-screen Submenus: Features

• An X appears on screen to confirm the

receipt of each digit by the TV as you
input your AutoLock™ access code.

•Parents, it isn’t possible for your child
to unblock a channel without knowing
your access code or changing it to a
new one. If you discover that your
access code has been changed, you can
assume that blocked channels may
have been viewed.

HELPFUL HINTS

9


SOUND

FEATURES

INSTALL

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/
SELECT

MUTE

2

2

213
546
879

SURF

0

PIP

POSITION

3,4

CH

1

5,6,

7,8

FEATURES

FEATURES

FEATURES

FEATURES

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

FEATURES

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

FEATURES

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

ACCESS CODE

- - - -

ACCESS CODE
X X X X

ACCESS CODE

- - - -

ENTER
NEW CODE

- - - -

CONFIRM
CODE

- - - -

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

ACCESS CODE

- - - -

ACCESS CODE
X X X X
INCORRECT

ACCESS CODE
X X X X

ENTER
NEW CODE
X X X X

You can also set up a new
access code from the main
AutoLock submenu using
the SETUP CODE option.
Simply enter and confirm
the new Code to activate it.

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE

MOVIE RATING
TV RATING
BLOCK OPTIONS

CONFIRM
CODE
X X X X

ENTER
NEW CODE
X X X X

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE

MOVIE RATING
TV RATING
BLOCK OPTIONS

CONFIRM
CODE
X X X X

CORRECT

CONFIRM
CODE
X X X X

CORRECT

USING AUTOLOCK™ TO BLOCK CHANNELS

A

fter you have set up your personal

access code (see page 47), you are
ready to select the channels or program
sources you want to block.

1

Press the MENU/SELECT button

on the remote control to show the
on-screen menu.

2

Press the CURSOR RING DOWN

twice to highlight
FEATURES.

3

Press the CURSOR RING
RIGHT. Then press the CURSOR

RING DOWN once to highlight the
AutoLock control.

4

Press the CURSOR RING
RIGHT again to highlight ACCESS

CODE.

5

Enter your four-digit ACCESS
CODE. CORRECT will flash very

briefly and the submenu will move
to the left with BLOCK CHANNEL
highlighted.

6

Press the CURSOR RING
RIGHT to highlight the TV’s avail-

able channels.

7

Press the CURSOR RING UP or
DOWN to highlight the channel

you want to block.

8

Press the CURSOR RING
RIGHT to block the channel. A

padlock image will appear to the
right of the channel number. If you
decide you don’t want to block the
channel, press the CURSOR RING
RIGHT again to remove the block.
(The padlock image goes away.)

Repeat steps 7 and 8 for any channels you
want to block from viewing.

NOTE:You can highlight the ALL option,

then press the CURSOR RING RIGHT to
block all channels at once. Or press the
CURSOR RING RIGHT to unlock all
channels.

9

Press the STATUS/EXIT button

to exit the menu.

You can use the BLOCK CHANNEL con­trol to prevent the viewing of programs com­ing from a VCR, DVD, or other accessory
device connected to any of the audio/video

HELPFUL HINT

48

9


SOUND

FEATURES

INSTALL

TV

SWAP PIP CH

7

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/
SELECT

MUTE

2

2

213
546
879

SURF

0

PIP

POSITION

3,4,

6,8

CH

1

5

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL

SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

To block all channels at once, highlight ALL in the channel list. Then press
the CURSOR RING RIGHT to block. Remove the blocks the same way.

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

ACCESS CODE

- - - -

1
2
3
4
5

1
2
3
4
5

2
3
4
5
6

ALL
1
2
3
4

FEATURES

FEATURES

FEATURES

AutoLock

FEATURES

AutoLock

FEATURES

AutoLock

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

ACCESS CODE

- - - -

ACCESS CODE
X X X X

1
2
3
4
5

2
3
4
5
6

ALL
1
2
3
4

USING AUTOLOCK™ TO BLOCK BY MOVIE RATING

A

fter you ha ve set your personal access

code (see page 47), you can block
programs by specific movie ratings.

1

Press the MENU/SELECT
button on the remote control to

show the on-screen menu.

2

Press the CURSOR RING DOWN

twice to highlight
FEATURES.

3

Press the CURSOR RING
RIGHT. Then press the CURSOR

RING DOWN once to highlight the
AutoLock control.

4

Press the CURSOR RING
RIGHT again to highlight
ACCESS CODE.

5

Enter your four-digit ACCESS
CODE. CORRECT will flash very

briefly in red and the submenu will
move to the left with BLOCK
CHANNEL highlighted.

6

Press the CURSOR RING DOWN

repeatedly until MOVIE RATING is
highlighted.

7

Press the CURSOR RING
RIGHT and the Rating submenu

will shift to the left with G high­lighted.

8

Press the CURSOR RING UP or
DOWN to highlight each rating you

want. Then press the CURSOR
RING RIGHT to turn the rating ON
or OFF. Turning the rating ON will
block such programs from being
seen.

9

Press the STATUS/EXIT button

to exit the menu.

Using the On-screen Submenus: Features

When a rating is set to be turned on
(blocked), all higher ratings will also be
blocked automatically. For example, if the
R rating is turned on, the NC-17 and X
ratings also will be turned on.

H

ELPFUL HINT

49


SOUND

FEATURES

INSTALL

9

2,6

SWAP PIP CH

8

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

TIMER
AUTOLOCK
PIP
CLOSED CAP
FORMAT

POWER

TV

VCR

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879
0

PIP

POSITION

3,4,

ACC

FREEZE


MENU/
SELECT

CH

SURF

5

7

1

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL

SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

AutoLock

MOVIE RATING

G

PG
PG-13
R
NC-17

FEATURES

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

ACCESS CODE

- - - -

2
3
4
5
6

OFF
AV3
ALL
1
2

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE

MOVIE RATING

TV RATING
BLOCK OPTIONS

AutoLock

MOVIE RATING

G

PG
PG-13
R
NC-17

ACCESS CODE

- - - -

ACCESS CODE
X X X X

G
PG
PG-13
R
NC-17

ON
AV3
ALL
1
2

50

USING AUTO

LOCK™ TO BLOCK BY TV RATING

Y

ou also can block programs by specific
TV ratings. Follow these simple steps.

1

Press the MENU/SELECT
button on the remote control to

show the on-screen menu.

2

Press the CURSOR RING
DOWN twice to highlight

FEATURES.

3

Press the CURSOR RING
RIGHT. Then press the CURSOR

RING DOWN once to highlight
the AutoLock control.

4

Press the CURSOR RING
RIGHT again to highlight

ACCESS CODE.

5

Enter your four-digit ACCESS
CODE.

6

Press the CURSOR RING
DOWN repeatedly until TV

RATING is highlighted.

7

Press the CURSOR RING
RIGHT to enter the TV RATING

submenu.

8

Press the CURSOR RING
DOWN or UP to select a rating.

9

Press the CURSOR RING
RIGHT or LEFT to turn the

block on the rating ON or OFF.

NOTE: More-specific subratings

(for violence, sexual content, dia­logue, or fantasy violence) are
available for TV-Y7, TV-PG, TV­14, and TV-MA.

10

To access these subratings, press
the CURSOR RING RIGHT.

Press the CURSOR RING UP or
DOWN to select the subrating that
you want to block or unblock.
Then press the CURSOR RING
RIGHT or LEFT button to turn the
block on the subrating ON or OFF.

11

Press the STATUS/EXIT button

to exit the menu.

TV-Y (All Children)—designed to be appropriate for all children, especially ones ages 2–6.

Programs rated TV-Y are not expected to frighten younger children.

TV-Y7(Directed to Older Children)—designed for children ages 7 and older. Programs rated

TV-Y7 may be more appropriate for children who have acquired the development skills needed to
distinguish between make-believe and reality. Such programs may include mild fantasy and comic
violence (FV).

TV-G (General A udience)—likely to be considered suitable for children of all ages. Such

programs have little or no violence, no strong language, and little or no sexual dialogue or sexual
situations.

TV-PG(Parental Guidance Suggested)—contain material that parents may find unsuitable for

younger children. This type of programming has one or more of the following: moderate violence
(V), some sexual situations (S), infrequent coarse language (L), or some suggestive dialogue (D).

TV-14(Parents Strongly Cautioned)—contain material that many parents will find unsuitable

for children under 14 years of age. Such programs have one or more of the following: intense vio­lence (V); intense sexual situations (S); strong, coarse language (L); or intensely suggestive
dialogue (D).

TV-MA(Mature A udience Only)—specifically designed to be viewed by adults and therefore

may be unsuitable for children under 17. Such programs have one or more of the following:
graphic violence (V); explicit sexual situations (S); or crude, indecent language (L).

Using the On-screen Submenus: Features


SOUND

FEATURES

INSTALL

TV

SWAP PIP CH

SOUND

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

3,4,

7,9,

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


10

FEATURES

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

ACCESS CODE

- - - -

FEATURES

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

11

STATUS/

EXIT

VOL

2,6,

8

TV/VCR

A/CH

POSITION

MENU/
SELECT

MUTE

CH

1

213
546
879

SURF

0

PIP

5

FEATURES

AutoLock

AutoLock

TV RATING

BLOCK CHANNEL

SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

TV-Y

TV-Y7
TV-G
TV-PG
TV-14

FEATURES

2
3
4
5
6

OFF
AV3
ALL
1
2

AutoLock

AutoLock

TV RATING

BLOCK CHANNEL
SETUP CODE
MOVIE RATING

TV RATING

BLOCK OPTIONS

TV-Y

TV-Y7
TV-G
TV-PG
TV-14

ACCESS CODE

- - - -

ACCESS CODE
X X X X

TV-Y
TV-Y7
TV-G
TV-PG
TV-14

ON
AV3
ALL
1
2

51

TURNING THE A

UTOLOCK™ BLOCKING CONTROL ON OR OFF

T

he BLOCKING control can be thought

of as the “master switch” for
AutoLock™. Use it to turn ON or OFF all
of the settings (based on ratings). This
control does not affect channel blocks (see
page 48).

1

Press the MENU/SELECT button

on the remote control to show the
on-screen menu.

2

Press the CURSOR RING DOWN

twice to highlight
FEATURES.

3

Press the CURSOR RING
RIGHT. Then press the CURSOR

RING DOWN once to highlight the
AutoLock control.

4

Press the CURSOR RING
RIGHT again to highlight ACCESS

CODE.

5

Enter your four-digit ACCESS
CODE.

6

Press the CURSOR RING DOWN

repeatedly until BLOCK OPTIONS
is highlighted.

7

Press the CURSOR RING
RIGHT to enter the BLOCK

OPTIONS submenu. BLOCKING
will be highlighted.

8

Press the CURSOR RING
RIGHT or LEFT to turn

BLOCKING ON or OFF.

9

Press the STATUS/EXIT button

to exit the menu.

Using the On-screen Submenus: Features

9

2,6


SOUND

FEATURES

INSTALL

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

TV

VCR

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879
0

PIP

POSITION

3,4,

ACC

FREEZE

7,8


MENU/

SELECT

CH

SURF

5

1

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL

SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

AutoLock

BLOCK OPTIONS

BLOCKING

BLOCK UNRATED
NO RATING

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

ACCESS CODE

- - - -

2
3
4
5
6

OFF
AV3
ALL
1
2

FEATURES

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING

BLOCK OPTIONS

AutoLock

BLOCK OPTIONS

BLOCKING

BLOCK UNRATED
NO RATING

ACCESS CODE

- - - -

ACCESS CODE
X X X X

BLOCKING
BLOCK UNRATED
NO RATING

ON
AV3
ALL
1
2

52

USING AUTO

LOCK™ TO BLOCK UNRATED BROADCASTS

Using the On-screen Submenus: Features

I

n addition to blocking rated programs or

channels, you may also choose to block
all programming that is unrated. Unrated
programming consists of shows that the
MPAA (Motion Picture Association of
America) or the TV broadcasters have
chosen not to rate.

1

Press the MENU/SELECT but­ton on the remote control to show

the on-screen menu.

2

Press the CURSOR RING
DOWN twice to highlight

FEATURES.

3

Press the CURSOR RING
RIGHT. Then press the

CURSOR RING DOWN once
to highlight the AutoLock control.

4

Press the CURSOR RING
RIGHT again to highlight

ACCESS CODE.

5

Enter your four-digit ACCESS
CODE.

6

Press the CURSOR RING
DOWN repeatedly until BLOCK

OPTIONS is highlighted.

7

Press the CURSOR RING
RIGHT to enter the BLOCK

OPTIONS submenu.

8

Press the CURSOR RING
DOWN once to select BLOCK

UNRATED.

9

Press the CURSOR RING
RIGHT or LEFT to turn

BLOCK UNRATED ON or OFF.

10

Press the STATUS/EXIT button

to exit the menu.

When the BLOCK UNRATED control is
turned ON, attempts to view unrated pro­grams will bring to the screen a message
like the one shown to the right. To watch
the program, enter your access code or go
into the BLOCK OPTIONS submenu and
turn the BLOCK UNRATED control OFF.

HELPFUL HINT

PIP

213
546
879
0

TV

SWAP PIP CH

DN

UP

FREEZE

SOUND

MUTE

SURF

A/CH

POWER


STATUS/

EXIT

POSITION

VCR

ACC

MENU/
SELECT

VOL

CH

TV/VCR

ACTIVE

CONTROL


SOUND

FEATURES

INSTALL

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

FEATURES

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

FEATURES

ACCESS CODE

- - - -

FEATURES

ACCESS CODE

- - - -

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

ACCESS CODE
X X X X

1

2,6,

8

3,4,

7,9

10

5

BLOCK OPTIONS

AutoLock

OFF
OFF

BLOCKING

BLOCK UNRATED

NO RATING

BLOCK OPTIONS

AutoLock

ON
ON

BLOCKING

BLOCK UNRATED

NO RATING

AutoLock

BLOCKING
BLOCK UNRATED
NO RATING

FEATURES

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING

BLOCK OPTIONS

AutoLock

2
3
4
5
6

FEATURES

BLOCK CHANNEL

SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

Channel 12

Blocked by AutoLock

Unrated

Access Code

- - - -

53

USING AUTO

LOCK™ TO BLOCK BROADCASTS THAT HAVE NO RAT I N G

S

ome programs contain no content advi-

sories from the Motion Picture
Association of America or the television
broadcasters (see page 46). To block pro­grams with no rating, follow these steps.

1

Press the MENU/SELECT
button on the remote control to

show the on-screen menu.

2

Press the CURSOR RING
DOWN twice to highlight FEA-

TURES.

3

Press the CURSOR RING
RIGHT. Then press the CUR-

SOR RING DOWN once
to highlight the AutoLock
control.

4

Press the CURSOR RING
RIGHT again to highlight the

ACCESS CODE input area.

5

Enter your four-digit ACCESS
CODE.

6

Press the CURSOR RING
DOWN repeatedly until BLOCK

OPTIONS is highlighted.

7

Press the CURSOR RING
RIGHT to enter the BLOCK

OPTIONS submenu.

8

Press the CURSOR RING
DOWN twice to highlight NO

RATING.

9

Press the CURSOR RING
RIGHT or LEFT to turn NO

RATING ON or OFF.

10

Press the STATUS/EXIT button

to exit the menu.

Using the On-screen Submenus: Features

If the NO RATING control is turned on,
all programs having no content advisory
information will activate a screen like the
one shown to the right. To watch the
channel, enter your access code or turn

HELPFUL HINT

10

2,6,

8


SOUND

FEATURES

INSTALL

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/
SELECT

MUTE

213
546
879

SURF

0

PIP

POSITION

3,4,

7,9

CH

1

5

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL

SETUP CODE
MOVIE RATING
TV RATING
BLOCK OPTIONS

AutoLock

BLOCK OPTIONS

BLOCKING
BLOCK UNRATED

NO RATING

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

ACCESS CODE

- - - -

2
3
4
5
6

OFF
OFF
OFF

FEATURES

TIMER

AutoLock

PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

AutoLock

BLOCK CHANNEL
SETUP CODE
MOVIE RATING
TV RATING

BLOCK OPTIONS

AutoLock

BLOCK OPTIONS

BLOCKING
BLOCK UNRATED

NO RATING

ACCESS CODE

- - - -

ACCESS CODE
X X X X

BLOCKING
BLOCK UNRATED
NO RATING

ON
ON
ON

Channel 12

Blocked by AutoLock

No rating

Access Code

- - - -

54

REVIEWING YOUR

CURRENT AUTOLOCK™ SETTINGS

MOVIERATING—shows all the movie ratings

that you have chosen to block within the MOVIE

RATING control. NOTE: If a lower rating is

blocked, higher ratings will also be blocked auto­matically. For example, if you block R-rated pro­grams, those that are rated X will also be blocked.

TV RATING—shows all the TV ratings that you

have chosen to block within the TV RATING con-

trol. NOTE: If a lower rating is blocked, higher

ratings will also be blocked automatically. For
example, if you block TV-PG-rated programs,
those rated TV-14 and TV-MA will also be
blocked. The TV rating controls also have subrat­ings for Violence (V), Fantasy Violence (FV),
Sexual Situations (S), Coarse Language (L), and
Suggestive Language (D). If you turn off a main
rating but turn on a subrating of that main rating
control, programs having the subrating will be
blocked; however, the main rating will not appear
within the AutoLock review submenu because you
did not turn it ON.

BLOCK UNRATED—shows whether you have

turned this control ON or OFF.

BLOCK NO RATING—shows whether you

have turned this control ON or OFF.

Using the On-screen Submenus: Features

The AutoLock™ review screen will appear
only if you have turned ON the BLOCK­ING control (see page 51).

HELPFUL HINT

A

utoLock™ provides a screen that shows

the settings you have selected. Here’s

how to access the screen.

1

Press the STATUS/EXIT button on

the remote control twice. Your
AutoLock™ settings will appear on
the screen.

NOTE: If you have blocked specific
subratings, such as V for Violence in the

TV-PG category, these blocked subrat­ings will not appear in the review.
Nonetheless, the subratings are still
blocked according to your selections.

2

After a few seconds, the settings will
leave the screen automatically, or
you can press the STATUS/EXIT
button to exit the menu.

MOVIE RATING -

BLOCK UNRATED

NO RATING

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

DN

-

­R
NC17
X

VCR

UP

MUTE

TV RATING -

ON
OFF

POWER

ACC

ACTIVE

FREEZE

CONTROL


SELECT

Y7

­PG
14
MA

MENU/

CH

1, 2

213
546
879

TV/VCR

A/CH

SURF

0

MOVIE RATING -

BLOCK UNRATED

NO RATING

-

­R
NC17
X

TV RATING -

ON
OFF

POSITION

PIP

Y7

­PG
14
MA

55

USING THE CLOSED CAPTIONING CONTROL

C

losed Captioning (CC) allows you to read

the voice content of television programs
on the TV screen. Designed to help the hear­ing impaired, this feature uses on-screen text
boxes to show dialogue and conversations
while the TV program is in progress.

1

Press the MENU/SELECT button

on the remote control to show the on­screen menu.

2

Press the CURSOR RING DOWN

twice to highlight FEATURES.

3

Press the CURSOR RING RIGHT

to enter the FEATURES submenu.

4

Press the CURSOR RING DOWN

repeatedly until the CLOSED CAP
control is highlighted.

5

Press the CURSOR RING RIGHT.

The submenu will shift to the left and
CAPTION MODE will be highlighted.
Then press the CURSOR RING
RIGHT again to highlight the
CAPTION MODEs area.

6

Press the CURSOR RING UP or
DOWN to select a CAPTION MODE.

NOTES:

• CC1 mode is the usual setting. CC2,
CC3, and CC4 may not be supported
by broadcast stations.

• The CC MUTE option turns the
Closed Captioning mode on whenever
the MUTE button on the remote
control is pushed. Select CC MUTE
in the on-screen submenu to turn this
feature on.

7

Press the CURSOR RING LEFT to

return to the CLOSED CAP submenu.
Then press the CURSOR RING
DOWN to highlight CC DISPLAY.

8

Press the CURSOR RING RIGHT

to turn the on-screen display of Closed
Captioning on or off. Closed
Captioning will be shown only if the
TV station broadcasting on the channel
has the feature available.

9

Press the STATUS/EXIT button to

exit the menu.

Using the On-screen Submenus: Features

• Refer to your area’s
TV program listings
for the stations and
times of shows
being broadcast
with Closed
Captioning.

•Broadcasters deter­mine the content of
captions. Any
occurrences of mis­spellings, incorrect
grammar, or strange
characters are not
the result of TV
malfunction.

HELPFUL HINTS


SOUND

FEATURES

INSTALL

SWAP PIP CH

7

SOUND

9

STATUS/

EXIT

VOL

2,4

TV

VCR

6

ACTIVE

CONTROL

DN

UP

MUTE

213
546
879

TV/VCR

A/CH

0

POSITION

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

POWER

ACC

3,5,

FREEZE


MENU/

SELECT

CH

MUTE

Button

SURF

PIP

CAPTION Mode
Example Display

JOHN: Why did they move the
meeting up to this week?
MARSHA: I don't know, but they
are pushing to close the deal.

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER
AutoLock

PIP

CLOSED CAP

FORMAT

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

CAPTION MODE
CC DISPLAY

8

FEATURES

CLOSED CAP

CAPTION MODE
CC DISPLAY

1

Selecting the CC MUTE option
allows you to display Closed
Captioning by pressing the MUTE
button on the remote control.
Note, however, that the program
you are watching must be providing
Closed Captioning. You must also
be sure CC DISPLAY is turned ON.

FEATURES

CLOSED CAP

CAPTION MODE

CC DISPLAY

CC DISPLAY

The TV program is blocked
by the Text screen.

ALL ITEMS ARE EASTERN STANDARD TIME (EST)

6:00 TOP OF THE MORNING
10:00 THE BEST LITTLE CALL-IN SHOW EVER
12:00 NOONDAY NEWS

1:30 AS YOUR LIFE TURNS MY WORLD AROUND

6:00 WORLD NEWS FOR TODAY

9:00 PLAYHOUSE MOVIE OF THE WEEK

CC1
CC2
CC3
CC4
CC MUTE

CC MUTE
TXT1
TXT3
TXT3
TXT4

ON

OR

OFF

TEXT Mode

Example Display

CLOSE CAPTION PROGRAMS ON WXYZ

CHECK LOCAL LISTINGS

FOR TIMES IN YOUR AREA

TONIGHT'S HEADLINES

EVENING WORLD NEWS

TONIGHT'S HEADLINES

EVENING WORLD NEWS

TONIGHT'S HEADLINES

USING THE PICTURE-FORMAT CONTROL

Using the On-screen Submenus: Features

Picture-format Modes

4:3 shows the conventional (4:3 aspect ratio)

picture in its original format. Border bars are
displayed on the sides. (See the warning above.)

EXPAND 4:3 expands, or zooms, the picture

both vertically and horizontally, eliminating or
reducing the size of border bars. Picture infor­mation is lost around the edges.

PANORAMA stretches the outer portions of

the picture horizontally and causes some verti­cal expansion.

WIDE SCREEN expands the picture horizon-

tally. No vertical expansion occurs.

AUTO senses the presence of borders bars and

zooms the picture to reduce or eliminate the
bars. The amount of zoom varies based on the
original picture, but this option can provide
more expansion than EXPAND 4:3.

AUTO works best with video programs that

were originally “letterboxed.” Formatted to pre­serve the original theatrical aspect ratio, these
programs are presented with border bars at top
and bottom.

Selecting a Picture Format

Using the Remote Control

Use your TV’s picture-format modes with video
sources you connect to the ANTENNA, AV1,
CVI, AV2, or AV3 (side panel) inputs on the TV.
While watching a video source—with no on­screen menu or display present—press the
CURSOR RING RIGHT or LEFT as many
times as necessary to select the picture format
you desire. Or press the FORMAT button to
perform the same function.

56

• The term aspect ratio refers to the rela-

tionship between the width and height of
a TV screen. Historically, TV screen
width has been 33 percent greater than its
height, amounting to a 4:3 aspect ratio.
The width of your widescreen TV, how­ever, is nearly 80 percent greater than its
height, which means its aspect ratio is
16:9. This screen corresponds well with
the tendency of the eyes to feel more
comfortable with fields of view and
action planes that are horizontally orient­ed. The wide screen is also proportionally
truer to the formats in which movies are
filmed and presented in theaters.

• Although the term widescreen can have

various meanings, it is most commonly
used to refer to a picture format or screen
that has a greater aspect ratio than the
conventional 4:3.

HELPFUL

HINTS

To prevent uneven
picture-tube aging,
do not leave border
bars or other sta­tionary images on
screen for extended
periods of time. See
page 62.

WARNING

Y

our TV’s wide screen (16:9 aspect ratio)

delivers a home-cinema experience not pos­sible with a conventional (4:3 aspect ratio) set.
High-definition (HD) programs originating in
16:9 format and other widescreen-format video
sources appear more lifelike, dramatic, and the­atrical. Border bars are diminished or eliminat­ed. Most anamorphic-DVD programs will fill
the wide screen without border bars.

Use your HD set-top box or progressive-scan­capable DVD player to control the picture for­mats of video sources connected to the TV’s HD
inputs.

For flexibility with video sources connected to
your TV’s standard inputs—ANTENNA, AV1,
CVI, AV2, or AV3 (side panel)—access your TV’s
picture-format modes. View a video source in
standard (4:3) format or enlarge it to fill the
screen in various ways using EXPAND 4:3,
PANORAMA, WIDE SCREEN, or AUTO.

Pictures appear more lifelike,
dramatic, and theatrical on your
TV's wide screen.

POWER

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

ITR/

RECORD

DN

SURF

REC •

SAP

ACC

VCR

ACTIVE

CONTROL

FREEZE

PIP ON/OFF

SLEEP


SURF

PROG.LISTDOLBY VAV

PERSONAL

PIPPOSITION

CURSOR

MENU/

SELECT

CH

FORMAT

Button

UP

MUTE

213
546
879
0

FORMAT

HOME

HOME

VIDEO

MOVIES

RING

The picture-format modes are available for use only with video
sources connected to the ANTENNA, AV1, CVI, AV2, and AV3
(Side Panel) inputs on the TV. Control the picture formats of
video sources connected to the HD inputs through the set-top
box (for HD programming) or progressive-scan-capable DVD
player (for DVD programs).

Shows the conventional picture

in its original format. Border bars

are displayed on the sides. See the

Warning on this page (below, left).

Stretches the outer parts of the

picture horizontally and causes

some vertical expansion.

4:3

EXPAND 4:3

Zooms the picture

vertically and horizontally.

4:3

EVENING WORLD NEWS

TONIGHT'S HEADLINES

PANORAMA

PANORAMA

EVENING WORLD NEWS

TONIGHT'S HEADLINES

Senses the presence of picture borders and zooms the

picture to reduce or eliminate the borders.

EVENING WORLD NEWS

TONIGHT'S HEADLINES

EVENING WORLD NEWS

AUTO

EXPAND 4:3

EVENING WORLD NEWS

TONIGHT'S HEADLINES

WIDE SCREEN

Expands the picture

horizontally. No vertical

expansion occurs.

WIDE SCREEN

TONIGHT'S HEADLINES

AUTO

EVENING WORLD NEWS

TONIGHT'S HEADLINES

57

USING THE P

ICTURE-FORMAT CONTROL

Using the On-screen Submenus: Features

Selecting a picture Format

Using the TV Buttons

Should your remote control become lost or other­wise unavailable for use, follow the steps below
to use the buttons on the front of the TV to access
the on-screen menu and select a picture-format
control.

1

Press the Volume + and – buttons
simultaneously. The on-screen menu

appears.

2

Press the Channel Down button

repeatedly until FEATURES is high­lighted. Then press the Volume + but­ton to enter the FEATURES submenu.

3

Press the Channel Down button

repeatedly until FORMAT is highlight­ed. Then press the Volume + or – button
until you select the picture format you
want.

4

Press the Volume + and – buttons
simultaneously and repeatedly until

you back out of the menu screens.

To prevent uneven picture-tube aging, do not
leave nonmoving images or black borders on
the screen for an extended period. See page 62.

WARNING

The TV’s Picture-format options are avail­able only with video sources connected to
the ANTENNA, AV1, CVI, AV2, AV3 (side
panel) inputs on the TV. The picture formats
of video sources connected to the HD inputs
are controlled through the HD set-top box
or progressive-scan-capable DVD player
providing the video source.

HELPFUL HINT


SOUND

FEATURES

INSTALL

FEATURES

TIMER
AutoLock

PIP

CLOSED CAP

FORMAT 4:3

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

OR

FORMAT EXPAND 4:3

OR

FORMAT PANORAMA

OR

FORMAT WIDE SCREEN

OR

FORMAT AUTO

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

58

USING ACTIVE CONTROL™

Using the On-screen Submenus: Features

Tu rning Active Control™ on or

off Using the TV Buttons

Should your remote control become lost or oth­erwise unavailable for use, follow the steps
below to use the buttons on the front of the TV
to access the on-screen menu and turn Active
Control™ on or off.

1

Press the Volume + and – buttons
simultaneously. The on-screen menu

appears.

2

Press the Channel Down button
repeatedly until FEATURES is high-

lighted. Then press the Volume + but­ton to enter the FEATURES submenu.

3

Press the Channel Down button

repeatedly until ACTIVE CTRL is
highlighted. Then press the Volume +
or – button to turn Active Control™
on or off.

4

Press the Volume + and – buttons
simultaneously and repeatedly until

you back out of the menu screens.

Tu rning Active Control™ on or

off Using the Remote Control

While watching TV, press the ACTIVE
CONTROL button on the remote control to
turn the feature on or off. When you turn Active
Control™ on, the on-screen display shows the
up-to-the-moment picture Sharpness and Noise
Reduction settings.

A

ctive Control™ Measures and corrects

all incoming signals to provide the best

picture-quality settings.
When you choose to turn Active Control™

on, picture sharpness and noise reduction
are controlled automatically. Active
Control™ adapts picture settings continu­ously and automatically.

NOTE: Active Control™ is not available for
signals connected to HD INPUT-AV 4

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

POWER

ACC

VCR

ACTIVE

FREEZE

CONTROL

DN

UP


MENU/

SELECT

MUTE

213
546
879

SURF

0

POSITION

PIP


SOUND

FEATURES

INSTALL

CONTROL

CH

TIMER
AutoLock
PIP
CLOSED CAP
FORMAT

ACTIVE

Button

ACTIVE CONTROL ON

SHARPNESS 8
NOISE REDUCTION 20

ACTIVE CONTROL OFF

FEATURES

TIMER

AutoLock
PIP
CLOSED CAP
FORMAT

TIME
START TIME
STOP TIME
CHANNEL
ACTIVATE

FEATURES

AutoLock

PIP
CLOSED CAP

FORMAT

ACTIVE CTRL ON

ACTIVE CTRL OFF

OR

59

COMPATIBILITY INFORMATION FOR THE TV’S HIGH-DEFINITION INPUTS

Appendix A

Y

our set’s HD inputs (HD INPUT-AV 4 and

HD INPUT-AV 5) are designed to accept
high-definition signal standards 480p and 1080i
as specified by the Electronic Industries
Association. Output standards may vary by man­ufacturer. Refer to the directions-for-use manual
for the digital equipment before connecting.

NOTE: HD INPUT-AV 5 is for DVI TMDS input
only.

HD INPUT-AV 4

When the Inputs Are Used with Component Video Signals

Y INPUT: 1.0 Vp-p (includes sync), 75 ohms
Pr INPUT: 700m Vp-p, 75 ohms
Pb INPUT: 700m Vp-p, 75 ohms

NOTES:

The Pb INPUT jack can also receive signals from outputs labeled Cb or B-Y.
The Pr INPUT jack can also receive signals from outputs labeled Cr or R-Y.

When the Inputs Are Used with RGB Video Signals

G/Y: 1.0 Vp-p, 75 ohms (compatible with sync on green)
R/Pr: 700 mVp-p, 75 ohms
B/Pb: 700 mVp-p, 75 ohms
H: 3 Vp-p ± 1.0 V, 1 kohm (when using separate H and V sync)
V: 3 Vp-p ± 1.0 V, 1 kohm (when using separate H and V sync).

HD INPUT-AV 5

This input accepts a digital video interface (DVI) connector, which uses digital
data in the format data standard called transition minimized differential signal­ing (TMDS).

• No industry standards have been estab­lished for HD television RGB signal sys­tems, timing, synchronization, and signal
strengths. The HD INPUT-AV 4 RGB
inputs on your Philips TV will not be
compatible with all digital equipment that
offers RGB outputs. If the digital equip­ment you want to connect offers both
component video and RGB, component
video is the suggested type of connection
to use.

•Your TV’s on-screen INSTALL submenu
provides the option of switching the AV4
signal source between YPbPr and RGB
color-space settings. The option is avail­able only when you have selected the
AV4 signal source (using the AV button
on the remote or the Source Select button
on the TV). The default setting for AV4 is
YPbPr. See page 61.

HELPFUL HINTS

Appendix

A

Product Type

Rear-projection HDTV Monitor

Television System

NTSC standard

Channel Coverage

VHF: 2–13
UHF: 14–69
Cable TV: Midband

Superband
Hyperband
Ultraband

Ambient Operating Temperature

+41 to 113ºF (+5 to +45ºC)

Mains Voltage

AC 110 ±10%

Power Consumption

180W (average)

Standby Power

<1 W

Audio

Frequency response: 20Hz–15kHz, +1/–3dB (ampl.)
Stereo output with 2 x 15W RMS
Tw o sets of 2” and 5” speakers.

Speaker Type

51-mm (2 in.) tweeters and 127-mm (5 in.) woofers

Video/Audio Terminals

INPUT-AV 1

VIDEO (composite): 1 Vp-p, 75 ohms
AUDIO: 500 mVrms, 30 kohm

COMPONENT VIDEO INPUTS (YPbPr)

Y INPUT: 1.0Vp-p (includes sync), 75 ohms
Pb INPUT: 700mVp-p, 75 ohms
Pr INPUT: 700mVp-p, 75 ohms
(The Pb INPUT jack can also receive signals from outputs
labeled Cb or B-Y. The Pr INPUT jack can also receive sig­nals from outputs labeled Cr or R-Y.)

S-VIDEO INPUT (INPUT-AV 1, INPUT-AV2, side panel)

Y-INPUT: 1 Vp-p (includes sync), 75 ohms
C-INPUT: 300 mVp-p, 75 ohms

INPUT-AV 2

VIDEO (composite): 1 Vp-p, 75 ohms
AUDIO: 500 mVrms, 30 kohm

HD INPUT-AV 4

Component Video YPrPb/RGB (See page 59.)
AUDIO: 500 mVrms, 30 kohm

HD INPUT-AV 5

Digital video interface (DVI) (See page 59.)
AUDIO: 500 mVrms, 30 kohm

CENTER CHANNEL INPUT

50W maximum power rating

VIDEO/AUDIO OUTPUT

VIDEO: 1 Vpp, 75 ohms
AUDIO: Fixed: 500 mVrms into ˙10 kohm

Variable: 0–2 Vrms into ˙10 kohm

SUBWOOFER OUTPUT

Line-level output

Side Panel (AV3)

VIDEO (composite): 1 Vp-p, 75 ohms
AUDIO: 500 mVrms, 30 kohm
HEADPHONE: 1.5 Vrms, 16 ohm

Picture Visible Area

55PW9383: 55 in.

60PP9383: 60 in.

Dimensions (W” x H” x D”)

55PW9383: 52.6 x 57 x 25.6

60PW9383: 56.7 x 59.4 x 27

Weight (does not include carton)

55PW9383: 190 lb

60PW9383: 210 lb

Supplied Accessories

Remote control with two size “AA” batteries.

Design and specifications are subject to change without notice.

60

MODEL SPECIFICATIONS

Appendix B

ppendix

B

A

C

olor space refers to how colors are

defined and appear on your TV. Your
TV’s default color-space setting for HD
INPUT-AV 4 is YPbPr. RGB is also an
option. If the picture’s color looks grossly
incorrect, try changing the color-space set­ting on either the digital equipment or the
TV. For more information on setting the
color space on the digital equipment, see its
directions-for-use manual. To set the TV’s
color space, follow the steps below.

1

Press the AV button on the remote

control as many times as necessary to
select AV4.

2

Press the MENU/SELECT button.

The on-screen menu appears.

3

Press the CURSOR RING DOWN

until INSTALL is highlighted. Then
press the CURSOR RING LEFT or
RIGHT to enter the INSTALL sub­menu.

4

Press the CURSOR RING DOWN

repeatedly until AV4 is highlighted.
The current color space is shown
(either YPbPr or RGB).

If you want to change the setting, press
the CURSOR RING LEFT or RIGHT.

5

Press the STATUS/EXIT button to

exit the menu.

61

SETTING COLOR SPAC E FOR HD INPUT-AV 4

Appendix C

5

3,4

1

AV4

TV

SWAP PIP CH

SOUND

STATUS/

EXIT

VOL

TV/VCR

A/CH

ITR/

RECORD

POWER

ACC

VCR

ACTIVE

CONTROL

DN

SURF

REC •

SAP

HOME
VIDEO

FREEZE

UP


MENU/

SELECT

MUTE

213
546
879
0

FORMAT

HOME

MOVIES

PIP ON/OFF

SLEEP

CH

SURF

PROG.LISTDOLBY VAV

PERSONAL

PIPPOSITION

2

SOUND

FEATURES

INSTALL

INSTALL

AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME

AV4 YPbPr

OR

AV4 RGB

LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron

ppendix

C

A

62

CARE AND C

LEANING

General Information: Care and Cleaning

WARNING Concerning Stationary Images on
the TV Screen:

Do not leave picture border bars or stationary
images on screen for extended periods of time.
This can cause uneven picture-tube aging.

Normal use of the TV should involve the showing of pictures
that contain constantly moving and changing images that fill the
screen. Be careful not to leave nonmoving images on screen for
extended periods of time, or to display the same images on
screen too frequently, because subtle ghost images can be left
on the picture tubes. Avoid showing pictures with border bars or
the same stationary images more than 15 percent of your total
viewing in any one week. Sources of stationary images may be
broadcast channels, cable channels, satellite channels, digital
television boxes, DVD discs, laser discs, video games, CD-i

discs, videotapes, and others. Here are some examples of sta-

tionary images (this is not an all-inclusive list; you may
encounter others in your viewing):

• Border bars—solid bars shown when viewing a standard

(4:3) picture and some widescreen movies on your
widescreen (16:9) TV

• DVD menus—listings of DVD disc content

• Video-game images and scoreboards

• Television station logos—present a problem if they are bright

and stationary; moving or low-contrast graphics are less like­ly to cause uneven aging of the picture tube

• Stock-market tickers—presented at the bottom of the TV

screen

• Shopping channel logos and pricing displays—bright and

shown constantly or repeatedly in the same location on the
TV screen.

All picture tubes age with use, with their light output diminish­ing over time. But by maintaining normal use—mixing televi­sion picture types—you will create conditions in the tubes age
at an even rate. The result will be a TV picture that is evenly
bright over the entire screen.

PLACEMENT OF THE TV

•To avoid cabinet warping, cabinet color changes, and
increased chance of set failure, do not place the TV where
temperatures can become excessively hot; for example, in
direct sunlight or near a heating appliance.

• Be sure to allow a free flow of air to and from the perforated
back cover of the set.

CLEANING

•To avoid possible shock hazard, be sure the TV is unplugged
from the electrical outlet before cleaning.

•Regularly dust the TV with a dry, nonscratching duster to
keep the TV clean.

• When cleaning the TV, take care not to scratch or damage the
screen surface. Avoid wearing jewelry or using anything abra­sive. Do not use household cleaners. Wipe the front screen
with a clean cloth dampened with water. Use even, easy, ver­tical strokes when cleaning.

Specially designed screen-cleaning kits are also available.
These kits contain anti-static cleaners and cloths designed to
get into the ridges of the TV screen. Purchase the kits at
stores that sell electronics. Or call our Customer Care Center
at 1-800-531-0039.

• Gently wipe the cabinet surfaces with a clean cloth or sponge
dampened in a solution of cool, clear water and a mild soap
or detergent. Use a clean, dry cloth to dry the wiped surfaces.

• Occasionally vacuum the ventilation holes or slots in the back
cover of the set.

•Never use thinners, insecticide sprays, or other chemicals on
or near the cabinet, as they might cause permanent marring of
the cabinet finish.

63

TROUBLESHOOTING

Check This List of Symptoms and Possible Solutions Before Requesting Service

You may be able to solve the problem yourself. Charges for TV installation and adjustment of customer controls are not cov­ered under your warranty.

If you need to call a customer service representative, please know the model number and serial number of your product before you
call. This information is displayed on the back of the product. Also, please take a moment to identify the problem you are having,
and be prepared to explain this to the representative. If you believe the representative will need to help you with operations, please

stay near the product. Our representative will be happy to assist you. To reach our Customer Care Center, call 1-800-531-0039.

General Information:Troubleshooting

Difficulties and Possible Solutions (*Q refers to the Quick Use and Setup Guide that came with your TV.)

The TV remote control does not work

• Check that the batteries are installed correctly. See page Q-2*.

• If the batteries are dead, replace them with two “AA” size heavy duty (zinc chloride) or alkaline batteries. See page *Q-2.

• Be no farther than 30 feet from the TV when using the remote control and point the remote toward the remote-sensor window on
the TV. See page *Q-2 for the location of the remote-sensor window.

• Clean the remote control and the remote-sensor window on the TV. See page *Q-2 for the location of the remote-sensor window.

• Check the TV power cord. Unplug the TV, wait 10 seconds, then reinsert the plug into the outlet and push the remote power or

TV power/standby button again. To locate the TV power/standby button, see page *Q-2.

• If you have your TV plugged into an AC power strip, ensure that the fuse on the power strip is not blown.

• Check to see if the TV is on a wall switch.

The TV has no power

• Check the TV’s power cord. Unplug the TV, wait 10 seconds, then reinsert the plug into the outlet and push the remote-control

power or TV power/standby button again. The location of the TV power/standby button is illustrated on page *Q-2.

• Check that the outlet is not on a wall switch.

• If you are using an AC power strip, be sure the fuse on the power strip is not blown.

You cannot get a picture

• Be sure that you have made signal connections correctly and securely. See pages *Q-1, *Q-2, 6–9, and 12–16.

• Check the Tuner Mode control for the correct tuner setting. See page *Q-5.

•Try running the Auto Program feature. See page *Q-5.

• Ensure that you have selected the correct picture signal source using the AV (remote) or Source Select (TV) buttons. See page 24.

• If you are attempting to view a picture from a progressive-scan-capable DVD player to the HD inputs, ensure that you have
switched the DVD player to progressive-scan mode. See page 14, as well as the DVD player’s directions-for-use manual.

• If you are using an HD receiver, ensure that its output is set correctly (HD or SD) based on the connection to the TV you have
made. See 15. Also, refer to the directions-for-use manual that came with the HD receiver.

Picture is fuzzy or out of focus

Check the set’s convergence and adjust if necessary. See page *Q-7 and pages 33–34.

You cannot see a picture when you play a VCR tape

Press the AV button on the remote control or the Source Select button on the TV until you have selected the source to which you

connected the VCR. See page 24 (AV button) or page *Q-2 (Source Select button).

You cannot tune to a particular channel

• Use the number buttons on the remote instead of the CH +/– buttons. See page *Q-3 (remote-control buttons).

• If necessary, select the Tuner Mode and run Auto Program to store channels to the set’s memory. See page *Q-5.

You see scrolling images

Check to ensure that you have made connections correctly. See pages *Q-1, *Q-2, 6–9 and 12–16.

The list of difficulties and possible solutions continues on the next page.

64

TROUBLESHOOTING

General Information:Troubleshooting

Difficulties and Possible Solutions (*Q refers to the Quick Use and Setup Guide that came with your TV.)

The picture has no color or colors are not correct

• Check to ensure that you have made connections correctly. See pages *Q-1, *Q-2, 6–9, and 12–16.

• If you have connected digital equipment to the HD inputs, check/change the color-space setting on the equipment or TV. See page 61.

• If the picture has red or blue fringes, you may need to adjust the convergence. See page *Q-7 or pages 33–34.

You are not able to get sound

• Check the Volume buttons on the remote control or on the TV. See pages *Q-2 (TV buttons) and *Q-3 (remote-control buttons).

• Check the Mute button on the remote. See page *Q-3 for the location of the Mute button.

• Check the Audio Out and Speaker controls. See page 10.

• If you have connected auxiliary sound equipment, check to ensure that you have made the audio connections correctly. See

pages 6–17. (If you have connected an external audio hi-fi system or amplifier, see pages 10 and 11 to ensure that you have made
the connections and set the AUDIO OUT control correctly.)

TV displays wrong channel or no channels above 13

•Try selecting the channel again.

•Add the desired channel numbers into the TV using the Channel Edit control. See page *Q-5.

• Check to ensure that the Tuner Mode is properly set and run Auto Program. See page *Q-5.

65

GLOSSARY OF

TELEVISION TERMS

General Information: Glossary of Television Terms

Active Control™ • Proactive video-control system for NTSC

(see definition below) sources. Active Control™ continuously
measures and corrects the incoming signals to provide the best
picture possible.

Alternate Channel • The feature that allows you to toggle

between the last two channels viewed by pressing the A/CH button
on the remote control.

Audio/Video Inputs • Jacks (standard RCA), located on the rear of

the TV, used for the input of audio and video signals. These jacks
are designed for use with VCRs (or other accessories) to receive
higher picture resolution and offer sound-connection options.

Auto Program • The feature that, when activated, scans for all

available channels from regular antenna or cable signals and stores
only active broadcast stations in the TV’s memory.

Channel Edit • The feature that allows you to add or delete chan-

nels from the list of channels stored in the TV’s memory. Channel
Edit makes it easy to limit or expand the number of channels that
are available to you when you press the CH +/– buttons on your
remote control.

Closed Captioning • The broadcast standard feature that allows

you to read the voice content of television programs on the TV
screen. Designed to help the hearing impaired, Closed Captioning
uses on-screen text boxes to show dialogue and conversations
while a TV program is in progress.

Coaxial Cable • A single solid wire normally matched with a

metal plug (F-type) end connector that screws (or pushes) directly
onto a 75-ohm input found on the television or VCR.

Comb Filter • TV filter that removes distortion, resulting in a

sharper and purer color display. The comb filter addresses the
annoying cross-color distortion that may occur in TV broadcasts
when, for example, the presenter wears a striped or checked jacket.

Component Video Inputs • Inputs that allow the separate recep-

tion of blue, red, and luminance signals. These inputs provide the
highest possible color and picture resolution in the playback of dig­ital signal-source material, such as the kind available from DVD
players. Component video inputs allow for improved bandwidth
information not possible through composite video or S-Video con­nections.

Composite Video Input • An input in which all the components

required for displaying the on-screen image are combined in one
signal.

Convergence • The technique used in color TV for bringing the

red, green, and blue color beams together so that they hit the same
part of the picture tube screen at the same time. This avoids color
fringes around images in the picture.

High-definition Television (HDTV) • High-resolution digital tele-

vision. HDTV is high-resolution digital television. It has lifelike
pictures, and with it films retain their original width, enhancing the
home theater experience.

Incredible Surround™ • False acoustic management of the audio

signal that produces a dramatic expansion of the wall of sound that
surrounds the listener and heightens overall viewing pleasure.

Interlaced • A picture-scanning technique that improves the

appearance of on-screen motion. It also helps smooth jagged lines
that are sometimes seen on curved and angled surfaces in the pic­ture.

Menu • An on-screen list of feature controls available for the user

to adjust or set.

NTSC • National Television Standards Committee format

devised in the 1940s for TV broadcast analog video signals
(525 lines: 30 Hz).

On-screen Displays (OSD) • The wording or messages generated

by the television (or VCR) to help you with specific feature con­trols (color adjustment or programming, for example).

Picture-in-Picture • The showing of two pictures on the TV screen

at the same time (one main screen picture and one small picture, or
PIP).

Progressive Scan •A picture-scanning technique that doubles the

number of picture lines, eliminating the flicker and providing a
jitter-free picture.

PTV • Projection Television. (Rear- and/or front-projection design

systems are available.)

Remote-control Sensor Window • The window or opening found

on the television control panel through which infrared remote-con­trol command signals are received.

RGB • Red, green, and blue signal. These are the primary colors of

light that are used to produce a picture in television. By mixing
levels or R, G, and B, all colors (chrominance and luminance) are
reproduced.

RF • Radio Frequency or modulated signal design used as the car-

rier for television broadcasts.

Second Audio Program (SAP) •An additional audio channel pro-

vided for in the Multichannel Television Sound (MTS) broadcast
standard. A monaural soundtrack included within the recorded or
video signal (usually containing a second language translation for
the displayed programming).

Status/Exit Button • Remote-control button that, when pressed,

shows the current channel number, name (if set), time (if set),
Sleep Timer setting, and sound setting (stereo, mono, SAP, or
mute). Pressing the button twice shows the current AutoLock™
settings. Pressing the button once when an on-screen display is
showing removes the on-screen display. You can use Status/Exit
rather than having to wait for the displays to “time out,” or auto­matically disappear from the screen.

S-Video Input • Signal input that allows direct connection of high-

resolution video sources, such as a satellite receiver, DVD player, S
(Super)-VHS videocassette recorder, or video games. Provides
improved picture resolution, sharpness, and clarity.

480p • Digital picture format with 704 x 480 pixels, sent at 60

complete frames per second. This is the output format of progres­sive-scan DVD players.

1080i • Digital high-definition picture format with 1920 x 1080

pixels, sent at 60 interlaced frames per second (30 complete frames
per second).

Tint • TV function that allows you to change the general color bal-

ance between cool and warm. Adjust tint according to your person­al preference.

Twin–lead Wire • The more commonly used name for the two-

strand, 300-ohm antenna wire used with many indoor and outdoor
antenna systems. In many cases, this type of antenna wire requires
an additional adapter (or balun) in order to connect to the 75-ohm
input terminals designed into the more recent TVs and VCRs.

66

INDEX

*Q refers to the Quick Use and Setup Guide that came with your TV.

General Information: Index

A

Active Control™, 58, 65
Alternate Channel (A/CH), 28, 65
APAC™, 5
Audio Out Control, 10
Audio/Video Inputs (Definition), 65
AutoChron™ Control, *Q-6
Auto IntelliSense™, *Q-7
AutoLock™ Control

Access code, 47
Blocking channels, 48
Movie ratings, 49
No rating broadcasts, 53
On/off control, 51
Settings review, 54
Setup Code, 47
TV ratings, 50
Understanding AutoLock™, 46

Unrated broadcasts, 52
AutoPicture™, 26
Auto Program, *Q-5, 65
AutoSound™, 25
AutoSurf™, 27
AV Button, 24
AVL Control, 36

B

Balance Control, 35
Bass Boost Control, 40
Bass Control, 35
Brightness Control, 30
Buttons (TV), *Q-2
Buttons (Remote), *Q-3

C

Cables/connectors, *Q-1
Channel Edit Control, *Q-5, 65
Cleaning (TV/Screen), 62
Clock (See Timer Control)
Closed Captioning Control, 55, 65
Coaxial Cable (Definition), 65
Color Control, 30
Color-space Control, 61
Color Temp Control, 30
Component Video Inputs (Definition), 65
Composite Video Input (Definition), 65
Connections

Amplifier, 11

Antenna/cable, *Q-1

Basic, *Q-1, *Q-2

Cable converter box, *Q-2

Camcorder, 16

Compatibility, 6, 7, 59

DVD player, 12, 14

HD receiver, 15

Headphone, 17

Hi-fi system, 10
Satellite receiver (standard), 6, 12, 13
S-Video device, 13
VCR, 8
VCR and cable box, 9

Convergence Controls

Red/blue, 33
Restore factory, 34
Multipoint red/blue, 34
Save multipoint settings, 34
Undo multipoint, 34

D

Digital video interface (DVI), 7, 59
Dolby

**

Virtual Control, 37

Dynamic Contrast Control, 32

E

Eye Fidelity Control, 31

F

Factory Service Locations, 67–68

G

Glossary, 65

H

Headphone Control, 17
High-definition Television (Definition),

65

I

Incredible Surround™ Control, 37, 65
Inputs (See Panel Jacks)

L

Language Control

(See Menu Language Control)

M

Menu, *Q-4, 65
Menu Language Control, *Q-4
Movie Ratings, 46, 49
MPAA, 46, 65
Mute Button, *Q-3, 17, 55

N

Name Control, *Q-7
NTSC, 65

O

On-screen Displays (Definition), 65

P

Panel Jacks (Overviews), 6, 7
Picture Button (See AutoPicture™)
Picture Control, 30
Picture-format Control, 56–57
PIP (Picture-in-Picture)

Definition, 65
Feature description, 5
Remote-control buttons, *Q-3, *Q-8
Tint control, *Q-8
Tuning channels, *Q-5

Program List, *Q-3, 28

R

Registration/Welcome, 2
Remote Control

Battery installation/caution, *Q-2
Button descriptions, *Q-3
Programming, 18–23
Sensor Window, *Q-2, 65

Usage, *Q-2, *Q-3, *Q-4
RF (Definition), 65
RGB Color Space Setting (See Color
Space Control)

S

Safety/Precautions, *Q-2, 2, 3
SAP, 39, 65
Sharpness Control, 30
Sleep Timer Control, 29
Source Select Button, *Q-2, 24
Specifications, 60
Stationary Images/Warning, 62
Status/Exit Button, *Q-3, 65
Stereo/Mono Control, 38
Surf Button (See AutoSurf™)
Surround-sound Modes, 37
S-Video, *Q-1, 6, 13

T

Timer Control,

Activate, 45

Channel, 44

Clock, 41

Start time, 43

Stop time, 43

Time display, 42
Tint Control, 30, 65
Treble Control, 35
Troubleshooting, 63–64
Tuner Mode, *Q-5
Twin-lead Wire (Definition), 65

V

Volume Control, *Q-2, *Q-3

W

Warranty, 72

Y

YPbPr Color Space Setting (See Color
Space Control)

67

FACTORY SERVICE LOCATIONS

Philips Factory Service Locations

3135 015 07541

Rev. FF - 10/1/2002

NOTE: If you reside in one of our Philips Factory Service Branch areas (see directory on back), you can contact the nearest Service Branch to obtain
efficient and expedient repair for your product. If your product is In-Warranty, you should have proof-of-purchase to ensure No Charge Service. For
Out-of-Warranty service, call the location nearest you.

NOTA: Si vous résidez dans une des régions desservies par une succursale de service après vente du fabricant Philips (voir liste ci-dessous), vous
pourrez contacter la branche de service après vente la plus près de chez vous pour obtenir un service après vente rapide et efficace. Si le produit est
sous garantie, il suffira de présenter une preuve d`achat pour bénéficier d'un service sans frais. Pour les produits non couverts par la garantie, con­tactez le centre le plus près de chez vous.

NOTA: Si Ud. reside en una de nuestras zonas para sucursales Philips de servicio al de fábrica (ver directorio más abajo), Ud. puede comunicarse con
la sucursal de servicio más cercana para obtener una reparación oportuna y eficaz de su producto. Si su producto está todavía bajo garantía, Ud.
debe presentar comprobante de compra para no ocasionar ningunos cargos por servicio. Para servicio después del vencimiento de la garantía, llame
al lugar más cercano de los abajo indicados.

In Canada

How you can obtain efficient and expedient carry-in, mail-in, or in-home service for your product
Please contact Philips at 1-800-661-6162 (French speaking)

1-800-531-0039 (English or Spanish speaking)

Au Canada

Comment obtenir le service après-vente pour les produits apportés ou envoyés par la poste à notre centre de service ou le service à domicile
Veuillez contacter philips á: 1-800-661-6162 (Francophone)

1-800-531-0039 (Anglais ou Espagnol)

En el Canadá

Cómo recibir servicio efficiente para su producto, en persona, por correo o a domicillo
Favor de comunicarse con Philips al: 1-800-661-6162 (francófono)

1-800-531-0039 (Inglés o Español))

QUALITY SERVICE IS AS CLOSE AS YOUR TELEPHONE! SIMPLY LOOK OVER THE LIST BELOW FOR THE NUMBER OF A FACTORY SERVICE CENTER

NEAR YOU

. YOUR PRODUCT WILL RECEIVE EFFICIENT AND EXPEDIENT CARRY-IN, MAIL-IN, OR IN-HOME SERVICE, AND YOU WILL RECEIVE PEACE OF MIND,

KNOWING YOUR PRODUCT IS BEING GIVEN THE EXPERT ATTENTION OF PHILIPS’ FACTORY SERVICE.

COMMENT OBTENIR NOTRE SERVICE APRÈS VENTE RAPIDE ET EFFICACE SOIT PAR COURRIER, À DOMICILE, OU EN SE PRÉSENTANT À UN CENTRE DE SERVICE PHILIPS. PLUS DE 600 CENTRES DE
RÉCEPTION DE PRODUITS À RÉPARER À TRAVERS LE PAYS: CONTACTER LE CENTRE DE SERVICE AUX CONSOMMATEURS LE PLUS PROCHE POUR SAVOIR L’EMPLACEMENT DE CES DÉPÔTS DANS
UN RAYON DE 50 À 75 MILES (80 KM À 120 KM) DU CENTRE DE SERVICE LOCAL.

CÓMO OBTENER UN SERVICIO OPORTUNO Y EFICIENTE POR CORREO, EN CASA O EN PERSONA PARA SU PRODUCTO A TRAVÉS DE UN CENTRO PHILIPS DE SERVICIO. MAS DE 600 SITIOS POR
TODO EL PAIS PARA LA RECEPCION DE PRODUCTOS NECESITADOS DE REPARACIONES: COMUNICARSE CON EL CENTRO DE SERVICIO DE FABRICA MAS CERCANO PARA ESTOS LUGARES DENTRO
DE UN RADIO DE 80 A 120 KM (50 A 75 MILLAS) DEL CENTRO DE SERVICIO LOCAL.

ATLANTA

Philips Factory Service
550 Franklin Road., Suite F
Marietta, GA 30067
800-273-1501

TAMPA

Philips Factory Service
1911 US Highway 301 North, Suite 100
Tampa, FL 33619
800-442-2027

SAN FRANCISCO

Philips Factory Service
681 East Brokaw Rd.
San Jose, CA 95112
800-300-9013

HOUSTON

Philips Factory Service
1110 N. Post Oak Rd., Suite 100
Houston, TX 77055
800-952-3254

CLEVELAND

Philips Factory Service
950 Keynote Circle
Brooklyn Heights, OH 44131
800-331-7037

DETROIT

Philips Factory Service
25173 Dequindre
Madison Heights, MI 48071
800-438-1398

DALLAS

Philips Factory Service
415 N. Main Street, #107
Euless, TX 76040
800-952-3254

LOS ANGELES

Philips Factory Service
20930 Bonita, Ste. V
Carson, CA 90746
800-300-9013

CHICAGO

Philips Factory Service
1279 W. Hamilton Pkwy.
Itasca, IL 60143
800-531-2922

KNOXVILLE

Philips Factory Service
One Philips Drive
Knoxville, TN 37914
800-821-1767

PHILADELPHIA

Philips Factory Service
352 Dunks Ferry Rd.
Bensalem, PA 19020
800-847-9320

68

FACTORY

SERVICE LOCATIONS

Philips Factory Service Locations

69

This page is intentionally left blank.

70

This page is intentionally left blank.

71

72

LIMITED WARRANTY

Limited Warranty

PROJECTION TELEVISION

One Year Free Labor

One Year Free Service on Parts

Tw o Years Free Service on Cathode Ray Tube Parts / 30 days Free Service on Projection TV Screen

This product can be repaired in-home.

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

Philips Consumer Electronics, P.O. Box 520890, Miami, FL 33152, [phone]

WHO IS COVERED?

You must have proof of purchase to receive warranty service. A sales
receipt or other document showing that you purchased the product is
considered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product. For one year
thereafter (30 days for the projection TV screen), all parts will be repaired
or replaced, and labor and transportation are free. From one to two years
from the day of purchase, you pay for the replacement or repair of all parts
except the cathode ray tube and for all labor and transportation charges.
After two years from the day of purchase, you pay for the replacement or
repair of all parts and for all labor and transportation charges.

All parts, including repaired and replaced parts, are covered only for
the original warranty period.When the warranty on the product
expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

• labor charges for installation or setup of the product, adjustment of
customer controls on the product, and installation or repair of
antenna systems outside of the product.

•product repair and/or part replacement because of misuse, acci­dent, unauthorized repair or other cause not within the control of
Philips Consumer Electronics Company.

•reception problems caused by signal conditions or cable or antenna
systems outside the unit.

•a product that requires modification or adaptation to enable it to
operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair of
products damaged by these modifications.

• incidental or consequential damages resulting from the product.
(Some states do not allow the exclusion of incidental or consequen­tial damages, so the above exclusion may not apply to you.This
includes, but is not limited to, prerecorded material, whether copy­righted or not copyrighted.)

•a product used for commercial or institutional purposes.

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is offi­cially distributed by Philips Consumer Electronics Company. In coun­tries where Philips Consumer Electronics Company does not distribute
the product, the local Philips service organization will attempt to pro­vide service (although there may be a delay if the appropriate spare
parts and technical manual(s) are not readily available).

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of
purchase. Attach it to this owner’s manual and keep both nearby. Also
keep the original box and packing material in case you need to return
your product.

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service.
Adjustments of the controls discussed there may save you a service
call.

TO GET WARRANTY SERVICE...

Repair must be performed by an authorized service center or a factory
service center. If you do not live near a factory service center, contact your
dealer. If your dealer is an authorized service center, he will arrange
repair. If your dealer is not an authorized service center, he will direct
you to the authorized service center engaged by him to service the
products he sells.

(In U.S.A., Puerto Rico and U.S.Virgin Islands, all implied warranties,
including implied warranties of merchantability and fitness for a particular
purpose, are limited in duration to the duration of this express warranty.
But, because some states do not allow limitations on how long an implied
warranty may last, this limitation may not apply to you.)

(In Canada, this warranty is given in lieu of all other warranties. No
other warranties are expressed or implied, including any implied war­ranties of merchantability or fitness for a particular purpose. Philips is
not liable under any circumstances for any direct, indirect, special, inci­dental or consequential damages, howsoever incurred, even if notified
of the possibility of such damages.)

IF YOU HAVE QUESTIONS...

Please contact Philips at:

1-800-531-0039, if calling from the USA (English or Spanish Speaking)
1-800-661-6162, if calling from Canada (French Speaking)
1-800-531-0039, if calling from Canada (English or Spanish Speaking).

REMEMBER...

Please record below the model and serial numbers found on the prod­uct.Also, please fill out and mail your warranty registration card
promptly. It will be easier for us to notify you if necessary.

MODEL # ________________________________________________

SERIAL # ________________________________________________

EL4945E006 / 2-03
