Philips 55PUT6002S User Manual

EN 1

Contents

1 Caution 2

2 Important 3

3 TV Overview 5

Control Panel 5
Remote Control 6
Remote Control Usage 7

4 Use Your TV 7

Switch on/off the TV or switch it to
standby 7
Watch content on connected devices 8
Switch channels 8
Adjust TV volume 9

5 Use More Functions 9

Access to the TV menu 9
Change Language 10
Change picture settings 10
Change sound settings 11
EPG Usage 11
Recording Menu 12
Use Philips EasyLink 12
Use EDID 12
Use Timer 12
Software Update 13

6 Media Center 14

Play media files from USB device
connected to TV 14
Remove USB Storage Device 15

7 Set Channels 15

Automatic Channel Searching 15
Manual Channel Setting 15
Search Digital Channels 16

8 Network Setup 16

Switch on/off Smart TV 16
Network Type 17
Cable Installation 17
Wireless Network Installation 17
Screen Sharing 17

9 Product information 18

Display resolutions 18
Multimedia 18
Sound power 18
Inherent resolution 18
Tuner / Reception / Transmission 19
Remote Control 19
Power Supply 19
Supported TV mounts 19

10 Troubleshooting 19

General issues 19
Channel issues 19
Picture issues 20
Sound issues 20
HDMI connection issues 20
Computer connection issues 20
Network Connection Issues 21
Contact us 21

11 Open Source 21

Open source software 21
Open source license statement 21

EN 2

1 Caution

2017©TP Vision Europe B.V. All rights reserved.
Specification is subjected to change without
notice. Trademarks are the property of
Koninklijke Philips N.V or their respective
owners. TP Vision Europe B.V. reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
The material in this manual is believed adequate
for the intended use of the system. If the
product, or its individual modules or procedures,
are used for purposes other than those specified
here in,confirmation of their validity and
suitability must be obtained. TP Vision Europe
B.V. warrants that the material itself does not
infringe any United States patents. No further
warranty is expressed or implied.
TP Vision Europe B.V. cannot be held
responsible neither for any errors in the content
of this document nor for any problems as a
result of the content in this document. Errors
reported to Philips will be adapted and
published on the Philips suppor t website as
soon as possible.

Terms of warranty

 Risk of injury, damage to TV or void of

warranty! Do not attempt to repair the TV
your self.

 Use the TV and accessories only as intended

by the manufacturer.

 The caution sign printed on the back of the

TV indicates risk of electric shock.Never
remove the TV cover. Always contact Philips
Customer Support for service or repairs.

Any operation expressly prohibited in this
manual, or any adjustments and assembly
procedures not recommended or authorized
in this manual shall void the warranty.

Pixel characteristics

This LCD/LED product has a high number of
color pixels. Although it has effective pixels of

99.999% or more, black dots or bright points of
light (red, green or blue) may appear constantly
on the screen. This is a structural property of
the TV (within common industry standards) and
is not a malfunction.

Main fuse(/56)

This TV is fitted with an approved moulded plug.
Should it become necessary to replace the main
fuse, this must be replaced with a fuse of the
same value as indicated on the plug (example
10A).

1. Remove fuse cover and fuse.

2. The replacement fuse must comply with

BS 1363 and have the ASTA approval mark.
If the fuse is lost, contact your dealer in
order to verify the correct type.

3. Refit the fuse cover

EN 3

2 Important

Read and understand all instructions before you
use your TV. If damage is caused by failure to
follow instructions, the warranty does not apply..

Safety

Risk of electric shock or fire!

 Never expose the TV to rain or water.

Never place liquid containers, such as vases,
near the TV. If liquid is spilt on or into the TV,
disconnect the TV from the power outlet
immediately. Contact Philips Consumer
Care to have the TV checked before use.

 Never place the TV, remote control or

batteries near naked flame or other heat
sources, including direct sunlight.
To prevent the spread of fire, keep candles
or other flames away from the TV, remote
control and batteries at all times.

 Never inser t objects into the ventilation

slots or other openings on the TV.

 When the TV is swivelled ensure that no

strain is exerted on the power cord. Strain
on the power cord can loosen connections
and cause arcing.

 To disconnect the TV from the mains power,

the power plug of the TV must be
disconnected. When disconnecting the
power, always pull the power plug, never the
cord. Ensure that you have full access to the
power plug, power cord and outlet socket at
all times.

Risk of short circuit or fire!

 Never expose the remote control or

batteries to rain, water or excessive heat.

 Avoid force coming onto power plugs.

Loose power plugs can cause arcing or fire.

Risk of injury or damage to the TV !

 Two people are required to lift and carry a

TV that weighs more than 25 kg or 55 lbs.

 When stand mounting the TV, use only the

supplied stand. Secure the stand to the TV
tightly. Place the TV on a flat, level surface
that can support the combined weight of
the TV and the stand.

 When wall mounting the TV, use only a wall

mount that can support the weight of the
TV. Secure the wall mount to a wall that can
support the combined weight of th e TV and
wall mount TP Vision Europe B.V. bears no
responsibility for improper wall mounting
that results in accident, injury or damage.

 If you need to store the TV, disassemble the

stand from the TV. Never lay the TV on its
back with the stand installed.

 Before you connect the TV to the power

outlet, ensure that the power voltage
matches the value printed on the back of
the TV. Never connect the TV to the power
outlet if the voltage is different.

 Par ts of this product may be made of glass.

Handle with care to avoid injury and
damage.

Risk of injury to children!

Follow these precautions to prevent the TV
from toppling over and causing injury to
children:

 Never place the TV on a surface covered by

a cloth or other material 1: that can be
pulled away.

 Ensure that no par t of the TV hangs over

the edge of the surface.

 Never place the TV on tall furniture (such as

a bookcase) without anchoring both the
furniture and TV to the wall or a suitable
support.

 Educate children about the dangers of

climbing on furniture to reach the TV.

Risk of swallowing batteries!

 The product/remote control may contain a

coin-type battery, which can be swallowed.
Keep the battery out of reach of children at
all times!

Risk of overheating!

 Never install the TV in a confined space.

Always leave a space of at least 4 inches or

EN 4

10 cm around the TV for ventilation. Ensure
curtains or other objects never cover the
ventilation slots on the TV.

Risk of injury, fire or power cord damage!

 Never place the TV or any objects on the

power cord.

 Disconnect the TV from the power outlet

and antenna before lightning storms.
During lightning storms, never touch any
part of the TV, power cord or antenna cable.

Risk of hearing damage!

 Avoid using earphones or headphones at

high volumes or for prolonged periods of
time.

Low temperatures

 If the TV is transported in temperatures

below 5°C or 41°F, unpack the TV and wait
until the TV temperature matches room
temperature before connecting the TV to
the power outlet.

Screen care

 Avoid stationary images as much as possible.

Stationary images are images that remain
on-screen for extended periods of time.
Example: on-screen menu, black bar and
time display. If you must use stationary
images, reduce screen contrast and
brightness to avoid screen damage.

 Unplug the TV before cleaning.
 Clean the TV and frame with a soft, damp

cloth. Never use substances such as alcohol,
chemicals or household cleaners on the TV.

 Risk of damage to the TV screen! Never

touch, push, rub or strike the screen with
any object.

 To avoid deformations and color fading,

wipe off water drops as soon as possible.

Recycling

Your product is designed and manufactured with
high quality materials and components, which
can be recycled and reused.

When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.

Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.

Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative
consequences for the environment and human
health.

Environmental Protection Use Period

This logo labelled on the product itself indicates
that the Environmental Protection Use Period
thereof is 10 years.
The Environmental Protection Use Period of
electrical information products refers to the
time period during which the toxic and

EN 5

hazardous substances or elements contained
within the product will not leak or suddenly
spoil, and users of such products will not cause
any serious environmental pollution or serious
damage to human and property.
During the Environmental Protection Use
Period, please use this product according to the
instructions given in this user manual.
The Environmental Protection Use Period does
not cover consumable parts: the battery.

Suggestive description of the
Recycling Administrative Regulations
for Waste Electrical and Electronics
Products

In order to care and protect the Earth in a
better way, please adhere to the national and
applicable laws in relation to the recycling
management of waste electrical and electronics
products when the user no longer needs to use
this product, or when it has reached the end of
its product life

3 TV Overview

Congratulations on your purchase and use of
Philips product! In order to fully enjoy the
support provided by Philips, please register your
TV at the following website:
www.philips.com/welcome.
(The following machine pictures are used for
reference only. Please refer to the actual
product.)

Control Panel

1. Indicator/remote signal receiving window

2. SOURCE: press it to display the list of

various sources.

3. CH+/CH-: switch to the previous or next

channel.

4. VOL+/VOL-: increase or decrease volume.

5. MEMU: open or close menu.

: Turn on or off the product. Be sure to

6.
unplug the power plug to completely turn
off the product.

EN 6

Remote Control

To p

1.

2.

3.

4. ●

Middle

Standby-Power on

 Switch the TV to standby if it is on.
 Power on the TV if it is in standby

state.

, , , , , ,

buttons

Control multimedia playback: “Previous”,
“Play”, “Next”, “REW”, “Pause”, “FF”, and
“Stop”.

REC LIST

View the list of recordings.

PVR recording function key.

Multimedia play

6.

7. ▲/▼//

8.

9.

10.

11.

12.

13.

Bottom

SOURCE

Select the input source of

Navigation key: you can select the items in
the setting function list.

INFO

View program information and return to
the previous channel or exit the current
menu.

Back

Return to the previous channel or exit the
current menu.

SMART TV

Enter the main interface of smart TV.

SETUP

Open or close the setup menu.

OK

TV.

 Confirm an operation.
 In TV mode, press this key show

channel list

OPTION

 Show menu functions.
 Access to the options related to the

current activities or selection.

5.

TOOL

Shortcut tool use to set the relevant items
of the machine

14.

CH+/CH-

Switch to the previous or next channel.

15.

+/-

Increase or decrease volume.

EN 7

16.

AUDIO

Nicam function

17.

SUBTITLE

Display subtitle message when the current
channel has subtitle option.

18.

0~9 numeric keys

Select a channel or input channel number.

19.

TV GUIDE

Program guide

20.

Mute

Mute or unmute the sound.

21.

AD

Turn on/off AD volume.

22.

FAV

Display the favorite list.

23.

TV

Switch to the TV function.

Remote Control Usage

When you use the remote control, hold it close
to the TV and point it at the remote control
sen s o r. Make sure that the line-of-sight between
the remote control and TV is not blocked by
furniture, walls or other objects.

4 Use Your TV

Switch on/off the TV or switch it to standby

Switch on the TV

 If the indicator is off, plug the TV power

cable into the power socket. Press the
on-off key of the TV to the ON state as
shown in the figure.

 If the indicator is turned on, please press

EN 8

(Standby-On) on the remote control or

 Though the TV consumes very little

extended period of time.

 Switch on the device before selecting it as

an external source.

key on the TV.

Switch the TV to standby if it is on.

 Press (Standby-On) on the remote

control. The “Standby” indicator is turned
on.

Switch off the TV.

 Press the on-off key on the back of the TV

to the OFF state shown in the figure. The
“standby” indicator is turned off.

Switch channels

Tip

power when in standby mode, energy
continues to be consumed. Disconnect
the TV power cable from the power
outlet when the TV is not used for an

Watch content on connected devices

Note

Use the Source button

1. Press

2. Press ▲/▼ key to select a device.

3. Press

SOURCE

OK

selected device.

key. The source list appears.

key. The TV switches to the

Switch channels without Using Channel list:

 Press CH+/CH- key on the TV or the

remote control.

 Enter a channel number using the numeric

buttons on the remote control.

 Press the (Back) key on the remote

control to return to the previous channel.

Switch channels Using Channel list:

You can use the channel list to watch all available
channels.

1. Press OK key. The channel list appears.

2. Press ▲/▼ key to select a channel.

3. Press
channel.

4. Press the
previously watched channel.

key to watch the selected

OK

(Back) key to switch to the

EN 9

Adjust TV volume

 The settings vary with input sources.

Increase or decrease volume

 Press the VOL+/VOL- key on the TV or the

+/- key on the remote control.

Mute or unmute the sound.

 Press key to mute.
 Press key again to restore the sound.

5 Use More Functions

Access to the TV menu

The function list helps to set channels, change
pictures, and set audio and other functions.

1. Press

2. Press ▲/▼ key to select one of the
following options; then press OK.












ke y. Open the Setting menu

apply the predefined picture

Pi c t u re :

setting option.

apply the predefined sound setting

Sound:

option.

ECO Setting:

items
TV Setting:
Language:

keyboard and input method.

Connection:

connection and wireless network

connection.

Channels:
Parental control:

parents to set channels available for

children of different age groups.

set screen backlight display

.

set TV function items.

set the menu language,

set wired network

set channel searching.

this function helps

Note

EN 10

Change Language

 Some picture settings may not be

available for certain sources.

Subtitle zoom:

4:3:

Movie Expand 16:9:

from 4:3 to 16:9.

You can change the menu language.

1. Press
language; then press  key.

2. Select your needed language and then press

OK

key to select language>menu

key.

Change picture settings

You can change picture settings to your
preferred settings by applying predefined
settings or manually modifying settings.

Quick picture setting

You can set up picture quickly using this
function.

1. Press key to select picture; and then
press

2. Select your preferred settings according to
the instructions on the screen.

Picture style

Apply the predefined picture style setting.

1. Press key to select picture mode.

2. Select one of the following settings and then
press OK key.







Manually adjust picture settings

1. Press key to select picture; and then
press

2. Select one of the following settings and then
press OK key.






key.

OK

Vivid: apply the color dynamic setting

suitable for watching during daytime.

Standard: adjust the picture setting to suit

most video environments and types.
Natural: s et natural mode.
Personal: use the self-defined picture

setting.

key.

OK

Contrast: adjust contrast and increase the

light intensity difference between the

bright part and the dark par t.
Brightness: adjust the light intensity and

fineness of the darker area.
Saturation: adjust color saturation.

Sharpness: adjust image definition.



Color temperature: adjust the overall



image color temperature.

Advanced settings:



● Noise reduction; filter and reduce

the noisy points in the image.

● Auto adjustment: automatically

adjust the PC display picture.

● Picture shift : set your PC display

picture, e.g. horizontal position,
vertical position, clock and phase.

Change picture format

Press key to select Picture>Picture format;
then press  key.

Picture format

You can choose from the following picture
formats.

Note

(This format is not
applicable to HD
mode and PC mode.)
Display subtitles
completely when the
video source with
subtitles is played, but
part of the image on
the top will be
cropped.

Display the picture in
the traditional 4:3
picture format.

(This format cannot
be applied to PC
mode.) The picture
format is adjusted

EN 11

Wide screen:

The picture format is

Auto:

ratio.

 EPG cannot be turned on directly in

non-digital TV mode.

adjusted from 4:3 to
16:9.

Automatically adjust
the picture to an
appropriate aspect

Change sound settings

You can change sound settings to your preferred
settings by applying predefined settings or
manually modifying settings.

Quick sound setting

You can set up sound quickly by applying
predefined sound settings in Sound Style.

1. Press key to select Sound; and then
press

2. Select one of the following settings and then
press OK key.








Manually adjust sound settings

1. Press key to select sound; and then
press OK key.

2. Select one of the following settings and then
press






key.

OK

Sound mode:
Standard: it can be applied to most

situations and sound sources.

News: it can be applied to speech (e.g.

news).

Cinema: The sound setting for movies can

be applied.

Personal setting: use self-defined sound

settings.

key.

OK

120Hz, 500Hz, 1.5KHz, 5KHz, 10KHz:

adjust according to the sound
frequency range of file or source.

Balance: adjust the balance of left and

right loudspeakers.

Surround: turn on or off the surround

sound function.

Advanced setting: select PCM/RAW



mode of SPDIF.

● Hearing impaired: turn on or off the

hearing impaired function.

● AD switching: turn on or off AD

switch.

EPG Usage

EPG is the electronic program guide provided
on digital channels. With EPG, you can

 View the list of the currently broadcast

digital programs.

 Watch the current transmitted program.
 Set up program reminder.

Turn on EPG (Program Guide)

Press the TV GUIDE key on the remote control
to display the program list.

Note

 Press the green key in the program

guide to remind or cancel the program to
be played within one week.

 Press the red key to turn on the

scheduled recording function: Automatic
or manual is available. According to your
preference, you can manually set recording
time and mode.

 Press the yellow key to display the

program information on different dates.

 Press the blue key to display the help

instructions.

EN 12

Recording Menu

 Make sure that the USB storage device has

function properly.

 The EasyLink compatible device must be

devices.

 Do not enable Philips EasyLink if you

don’t intend to use it.

 EDID version is valid only under HDMI

source.

 You can switch off the TV or reset the

zero.

Note

been well connected.

 When parental control is activated,

schedule recording may not be able to

Program recording

In digital TV mode, press ● key to display the
recorder menu on the screen and start program
recording. Press the / key to select the
operation menu and press OK key to confirm.

During recording, you can press keys such as 、

、■ to carry out shortcut operation.

Use Philips EasyLink

With Philips EasyLink you can operate a
connected device with the TV remote control.
EasyLink uses HDMI CEC (Consumer
Electronics Control) to communicate with the
connected devices. Devices must support

HDMI CEC and must be connected with an
HDMI connection.
To enable Philips EasyLink, you need to:

 Compatible device can work normally.
 Switch to EasyLink.

3. Select OFF or ON and then press

OK

key.

Set HDMI-Audio Output

1. Press ke y.

2. Select TV Settings > EasyLink > HDMI –
Audio Output.

3. Select OFF or ON and then press OK key.

Use EDID

1. Press key.

2. Select TV Settings > EDID Version and

then press OK key to enter.

3. Select your needed version and then press

key to confirm.

OK

Tip

Use Timer

You can use Timer so as to switch the TV to
standby after the specified time.

Use Sleep Timer

Set the time when the TV is switched to
st a n dby.

Note

turned on and selected as a source.

 Philips doesn’t ensure 100%

interoperability with all HDMI-CEC

Turn on or off EasyLink

Note

1. Press

2. Select TV Settings > EasyLink > EasyLink.

ke y.

Tip

Sleep Timer before the timer reaches

1. Press
Sleep Timer. The Sleep Timer is shown on
the screen.

2. Set the timer to a value between 0 to 240
minutes . The increment of the Sleep Timer is
10 minutes. If the Sleep Timer is set to 0, it
will be turned off.

3. Press OK key to turn on the Timer. The TV
is switched to standby when reaching the
preset time.

key and then select TV Settings >

EN 13

Software Update

 Unplug the USB device after software is

insufficient power supply.

Philips keeps improving our products. We
suggest that you update TV software when a
new version is launched.

Check the current software version

Press key to select TV Settings > About the
TV > Current Software Info and then press OK
key. The current software version information
will show.

Software Update

You can update the software using the following
methods:

 Connect to network for automatic update.

Press
TV > Auto Software Update and then press
OK key. Update the software according to
the instructions on the screen.

 Update the software using an USB storage

device.

1. Press key to select TV Settings > About
TV > Manual Software Update and then
press OK key. Update the software
according to the instructions on the screen.

2. Press
TV > Local Update and then press OK key.
Update the software according to the
instructions on the screen.

key to select TV Settings > About

key to select TV Settings > About

EasyLink: set up EasyLink functions.



About the TV: show the TV related



information.

Key Beep: turn on the key tone of the



remote control. When you press a
button on the remote control, the TV
will make a sound.

Sleep Timer : switch the TV to sleep mode



after the preset time.

Reinstall TV: restore your TV to default



settings.

Shop Mode: choose to turn on or off



Shop Mode.

Time Zone: set the time zone of TV.



PVR File System:



● Select disk: Select the folder where

you want to save the recording file.

● Format start: format the external

USB device.

● Speed check: test the

reading/writing speed of the USB
device.

Software update (OAD): turn on/off



software update (OAD).

Note

well updated.

 For software update, please use a USB

device. The use of a hard disk may result
in update failure and restarting due to

Change the preferred TV settings

1. Press key to select TV Settings.

2. Select one of the following and then press

key.

OK

Picture and Sound Reset: restore all TV



picture and sound settings to the preset
values.

EN 14

6 Media Center

 Supported storage device: make sure that

USB has been connected.

You can play pictures, videos, music and other
multimedia files in USB devices.

Play media files from USB device connected to TV

Note

1. Switch on the TV.

2. Connect a USB storage device to the USB

port on the side of the TV.

3. Press

4. Select the USB disk and then press OK k e y.

5. If there are multiple USB storage devices,

select the desired USB storage device and
then press OK k ey. T he browser opens.

View pictures

1. Select a folder or a picture in the browse

page and then press OK key.

2. Select a picture and then press OK k e y.

Zoom in this picture to full screen.

key to display the source menu.

Change slide play settings

Please press key when playing slides. Display
the list of slide play options and browse pictures
according to the instructions on the screen.

Listen to music

Select a folder or music in the browser page and
then press
play settings according to the instructions on the
screen.

key to play. Change the music

OK

/: Play/Pause music.
 /: Fast Forward/Fast Backward

I / I: Play the previous/next music.

: Return to the browser page.

: Set the music play mode.

Play music while watching slides

You can play background music while watching
slides.

1. Select a music album.

2. Press OK ke y.

3. Press
of browser page.

4. Select a picture.

5. Press OK key to play slides.

key to return to the main screen

/: Play/Pause lantern slide.
I / I: View the previous/next picture.

: Return to the browser page.

EN 15

Wat ch Videos

 Please remove a USB storage device

prevent damage.

 This function can be used only in TV

mode.

 Frequency fine-tuning can be performed

only when the source is ATV.

1. Select a folder or a video in the browser

page.

2. Press OK key to play a video. Change the

video play settings according to the
instructions on the screen.

/: Play/Pause video.
 /: Fast Forward/Fast Backward

I / I: Play the previous/next video.

: Return to the browser page.

: Set the video play options.

7 Set Channels

For the initial setup, the system will remind you
to select network connection or TV channel
installation. The Section provides the instructions
on how to reinstall and fine-tune channels.

Automatic Channel Searching

1. Press ke y.

2. Select Channel > Channel Settings and then

press OK ke y.

3. Press OK key to begin automatic channel

searching.

Note

Remove USB Storage Device

Note

according to the following steps to

1. Press key to return to or quit the main
screen of browser page.

2. Wait for about 5 seconds and then remove

the USB storage device.

Manual Channel Setting

Step 1 Select System

1. Press ke y.

2. Select Channel > Analog channel manual

installation.

3. Choose to begin scanning and fine-tuning.

Note

Step 2 Search and Store New Channels

1. Press ke y.

2. Select Channel > Analog channel manual

installation > Begin Scanning.

You can directly input the channel



frequency.

Choose to Scan and then press



to begin scanning.

3. Upon searching completion, select Save to

quit the current interface.

Save the searched channels.



OK

key

EN 16

Step 3 ATV Fine Tuning

1. Press ke y.

2. Select Channel > Analog channel manual

installation > Fine-tuning.

3. Select Decrease or Increase to adjust the

frequency.

Search Digital Channels

1. Press ke y.

2. Select Channel > Digital channel manual

installation and then press OK ke y.

3. Directly input the channel frequency

4. Choose Scan and then press OK key to

begin scanning.

8 Network Setup

Switch on/off Smart TV

You can set the network so as to access to
different networks.

1. Connect the TV to Internet. If there is no
network connection, certain functions of the
smart TV cannot work.

2. Press SM A RT TV button on the remote
control. The picture automatically skips to
Smar t TV.

(The picture and the applications in it are for
reference only!)

Applications

You can obtain apps from App store or manage
installed apps, and quickly switch between hot
apps and My Apps.

EN 17

Note

 Some apps support only mouse operation.

not within the warranty scope.

 The multi-screen interaction function may

devices.

 The memory space is not equal to

available space.

 Philips reserves the right to add or delete

some apps.

 Do not change the ROM of TV at random.

Otherwise, any faults caused thereof are

Wired Network Setting - Automatic Input

1. Press key and then select Connection >
Wired or Wi-Fi > Connect Network >
Wired Network.

2. Select static IP, press  key, and place the
cursor in the input box.

3. Use the remote control to input IP address,
subnet mask, gateway, DNS1 and DNS2.

4. Upon input completion, select OK and then
press OK ke y.

Network Type

You can select network setting type.

 Press key and then select Connection >

Wired or Wi-Fi. To view MAC address, press

key and then select Connection > Wired

or Wi-Fi > View Network Settings.

Cable Installation

To needing to connect the TV to PC network or
Internet, you need to install a route in the PC
network. Use a network cable (Ethernet cable)
to connect the route to the TV.
Connect the route to the network interface at
the bottom of
turn on the route before network installation.

Wired Network Connection and
Automatic Searching

1. Press key and then select Connection >
Wired or Wi-Fi > Connect Network >
Wired Network.

2. Select DHCP and then Connect and press
OK key. The network protocol will be set
automatically.

TV using a network cable, and

Wireless Network Installation

1. Press key and then select Connection >
Wired or Wi-Fi > Connect Network >
Wireless Network.

2. Select ON. The screen will show the current
set network parameters and available
wireless network.

3. Select Connect WPS, turn on the WPS
function of the router, and press OK key to
connect WPS network.

Screen Sharing

Multi-screen Interaction shows the contents on
the mobile device screen on the TV screen and
plays the sound on the mobile device in the TV
speakers synchronously. Use the volume button
on the remote control to control volume.

Note

not be compatible with some mobile

Create Connection

1. Press key and then select Connection >
Wired or Wi-Fi > Screen Sharing.

2. Select ON or OFF and then press OK key
to confirm.

3. Use the WLAN/wireless display function on
the mobile device to send a connection
request. When it is connected successfully,

EN 18

the picture on the mobile device will be

 The multi-screen interaction function can

and mobile device is turned on.

transmitted to the TV screen.

Disconnection Mode

1. You can disconnect the mobile device
during transmission.

2. Press
disconnect during transmission.

button on the remote control to

Note

be used only when the Wi-Fi of the TV

9 Product information

Product information is subject to change
without notice. For detailed product information,
please visit www.philips.com/support.

Display resolutions

Computer Formats

 Resolution - refresh rate:

640 x 480 60Hz



800 x 600 60Hz



1024 x 768 60Hz



1360 x 768 60Hz



1920 x 1080 60Hz



HDMI Video Formats

 Resolution - refresh rate:

480i - 60Hz



480p - 60Hz



576i - 50Hz



576p - 50Hz



720p - 50Hz,60Hz



1080i - 50Hz,60Hz



1080p - 50Hz, 60Hz.



2160p - 50Hz, 60Hz.



Multimedia

Supported storage device: USB ( NTFS, FAT or
FAT 32 USB storage devices are suppor ted.)
Compatible multimedia file formats:

 Image : JPEG
 Audio: M P3
 Video: MPEG 2/MPEG 4, H.264(FHD) ,

H.265

Sound power

 50" : 8W x 2
 55" : 8W x 2

Inherent resolution

 50" : 3840 x 2160
 55" : 3840 x 2160

EN 19

Tuner / Reception /

 Please follow all instructions provided

damage.

Transmission

 Aerial input: 75ohm coaxial (IEC75)
 Suppor ted Systems:

ATV : PA L , S E CAM , I , D /K , B/G, L
DTV: DVB-T/T2.

Remote Control

 Batteries: 2 x AAA

Power Supply

 Main Power Supply:

100-240V ~, 50/60Hz

 Standby Energy Consumption:

≤0.5W

 Environment Temper ature: 5 - 40°C
 Power consumption:

50": 110W



55": 155W



Supported TV mounts

To mount the TV, please purchase a Philips TV
mount or any TV mount compliant with the
VESA standard. To prevent damage to cables
and connectors, be sure to leave a clearance gap
of at least 2.2 inches or 5.5cm between the back
of the TV to the wall.

Warning

10 Troubleshooting

This section covers common problems and their
accompanying solutions.

General issues

The TV cannot be switched on:

 Disconnect the power cable from the

power outlet. Wait for one minute before
reconnecting it.

 Check that the power cable is securely

connected.

The remote control is not working properly:

 Check that the remote control batteries are

correctly inserted according to the +/­orientation.

 Replace the remote control batteries if they

are flat or weak.

 Clean the remote control and TV sensor

lens.

The TV menu is in the wrong language.

 Change the TV menu to your preferred

language.

When turning the TV On/Off or to Standby,
you hear a creaking sound from the TV chassis

 No action is required. The creaking sound

comes from the normal expansion and
contraction of the TV as it cools down and
warms up. This does not impact its
performance.

with the TV mount. TP Vision Europe B.V.
bears no responsibility for improper TV
mounting that results in accident, injur y or

Model No.

50" 200 x 200 4 x M6

55" 200 x 200 4 x M6

Required Pixel
Pitch (mm)

Required
Mounting Screws

Channel issues

Previously installed channels do not appear in
the channel list:

 Check that the correct channel list is

selected.

EN 20

Picture issues

Sound issues

The TV is on, but there is no picture:

 Check that the antenna is properly

connected to the TV.

 Check that the correct device is selected as

the TV source.

There is sound but no picture:

 Check that the picture settings are correctly

set.

Poor TV reception from the antenna
connection:

 Check that the antenna is properly

connected to the TV.

 Loudspeakers, unearthed audio devices ,

neon lights, high buildings and other large
objects can influence reception quality. if
possible, try to improve the reception
quality by changing the antenna direction or
moving devices away from the TV.

 If the reception on one particular channel is

poor, please fine tune this channel.

There is poor picture quality from connected
devices:

 Check that the devices are connected

properly.

 Check that the picture settings are correctly

set.

The picture does not fit the screen; it is too big
or too small:

 Try using a different picture format.

The picture position is incorrect:

 Picture signals from some devices may not

fit the screen correctly. Please check the
signal output of the device.

The pictures are showing but sound quality is
poor:

 Check that all cables are properly

connected.

 Check that the volume is not set to 0.
 Check that the sound is not muted.
 Check that the sound settings are correctly

set.

The pictures are showing but sound comes
from one speaker only:

 Verify that sound balance is set to the

centre.

HDMI connection issues

There are problems with HDMI devices:

 Please note that HDCP (High-bandwidth

Digital Content Protection) suppor t can
delay the time taken for a TV to TV content
from a HDMI device.

 If the TV does not recognize the HDMI

device and no picture is displayed, please try
switching the signal source to another
device before switching it back again.

 If there are intermittent sound disruptions,

please check that output settings from the
HDMI device are correct.

Computer connection issues

The computer display on the TV is not stable:

 Check that your PC uses the supported

resolution and refresh rate.

 Set the TV picture format to unscaled.

EN 21

Network Connection Issues

 Do not attempt to repair the TV yo u rs e l f .

warranty.

 Please make a note of your TV model and

of the TV and on the packaging.

Failure to connect to the Internet:

 If the TV is correctly connected to the

router, please check the connection
between the router and the Internet.

Network speed is slow:

 Please refer to the instruction manual of

your router to learn about the factors that
may affect transfer rate and signal quality.

 Yo u m a y need to upgrade your broadband

speed.

Contact us

If you cannot resolve your problem, please refer
to the FAQs for this model at
www.philips.com/support.
If the problem remains unresolved, please
contact your local Philips Customer Service
Centre.

Warning

This may cause severe injury, irreparable
damage to your TV or void your

Note

serial number before you contact Philips
Customer Service Centre. These
numbers are printed on the back/bottom

11 Open Source

Open source software

This television contains open source software.
TP Vision Europe B.V. hereby offers to deliver,
upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by the
respective license.

This offer is valid up to three years after product
purchase to anyone in receipt of this
information.
To obtain the source code, please write in
English to .
. .
[e-mail]

Open source license statement

Acknowledgments and License Texts for any
open source software used in this Philips TV.

This is a document describing the distribution of
the source code used on the Philips TV, which
fall either under the GNU General Public
License (the GPL), or the GNU Lesser General
Public License (the LGPL), or any other open
source license. Instructions to obtain source
code for this software can be found in the user
manual.

PHILIPS MAKES NO WARRANTIES
WHATSOEVER,EITHER EXPRESS OR
IMPLIED, INCLUDING ANY WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, REGARDING THIS
SOFTWARE. Philips offers no support for this
software. The preceding does not affect your
warranties and statutory rights regarding any
Philips product(s) you purchased. It only applies
to this source code made available to you.

U-Boot - Universal Bootloader (2010 06)
U-Boot, a boot loader for Embedded boards
based on PowerPC, ARM, MIPS and several

EN 22

other processors, which can be installed in a
boot ROM and used to initialize and test the
hardware or to download and run application
code.

http://www.denx.de/wiki/U-Boot/

Source:

udev – Userspace Device Management
Daemon (164.0) This program creates the files
for devices on a Linux system for easier
management. udev is a program which
dynamically creates and removes device nodes
from /dev/. It responds to /sbin/hotplug device
events and requires a 2.6 kernel.
Source: https://launchpad.net/udev

Util-Linux (2.22-rc2)
Source:

https://www.kernel.org/pub/linux/utils/util-linux/

Linux Kernel (3.10)
Real-Time Operating System
Source: http://www.kernel.org/

BusyBox (1.16.1)
BusyBox combines tiny versions of many
common UNIX utilities into a single small
executable. It provides replacements for most of
the utilities you usually find in GNU fileutils,
shellutils, etc. The utilities in BusyBox generally
have fewer options than their full-featured GNU
cousins; however, the options that are included
provide the expected functionality and behave
very much like their GNU counterparts .
BusyBox provides a fairly complete environment
for any small or embedded system.

http://busybox.net/

Source:

Ext2 Filesystems Utilities (1.41.11)
The Ext2 Filesystem Utilities (e2fsprogs) contain
all of the standard utilities for creating,
fixing,configuring, and debugging ext2
filesystems.
Source:

http://e2fsprogs.sourceforge.net/e2fsprogs-relea
se.html#1.41.12

GDB - The GNU Project Debugger (6.8)
GDB allows you to see what is going on "inside"
another program while it executes - or what
another program was doing at the moment it
crashed. GDB can do four main kinds of things

(plus other things in support of these) to help
you catch bugs in the act:
* Start your program, specifying anything that
might affect its behavior. Make your program
stop on specified conditions. * Examine what
has happened, when your program has stopped.
* Change things in your program, so you can
experiment with correcting the effects of one
bug and go on to learn about another. The
program being deb

https://www.gnu.org/software/gdb/

Source:

genext2fs (1.4.1)
it generates an ext2 filesystem as a normal (i.e.
non-root) user. It doesn't require you to mount
the image file to copy files on it. It doesn't even
require you to be the superuser to make device
nodes or set group/user ids.

http://genext2fs.sourceforge.net/

Source:

Iperf (2.0.5iPerf3 is a tool for active
measurements of the maximum achievable
bandwidth on IP networks. It supports tuning of
various parameters related to timing, buffers and
protocols (TCP, UDP, SCTP with IPv4 and IPv6).
For each test it repor ts the bandwidth, loss, and
other parameters. This is a new implementation
that shares no code with the original iPerf and
also is not backwards compatible.

http://iperf.fr/

Source:

libnl - Netlink Librar y (2.0)
The libnl suite is a collection of libraries
providing APIs to netlink protocol based Linux
kernel interfaces.
Netlink is a IPC mechanism primarly between
the kernel and user space processes. It was
designed to be a more flexible successor to ioctl
to provide mainly networking
related kernel configuration and monitoring
interfaces.
Source: http://www.infradead.org/~tgr/libnl/

Mem Tester (4.3.0)
A userspace utility for testing the memory
subsystem for faults.
Source: http://pyropus.ca/software/memtester/

mtd-utils (1.5.0)
We're working on a generic Linux subsystem
for memory devices, especially Flash devices.The

EN 23

aim of the system is to make it simple to provide
a driver for new hardware, by providing a
generic interface between the hardware drivers
and the upper layers of the system.

http://git.infradead.org/mtd-utils.git

Source:

squashfs - a compressed fs for Linux
(squashfs4.2) Squashfs is a highly compressed
read-only filesystem for Linux. Squashfs
compresses both files, inodes and directories,
and supports block sizes up to 1Mbytes for
greater compression. It is implemented as a
kernel module under VFS.
Source: http://sourceforge.net/projects/squashfs/

Alsa Libraries (1.0.21)
linux standard audio application libraries
Source:

http://www.alsa-project.org

Alsa Utils (1.0.21)
linux standard audio tool library
Source: http://www.alsa-project.org

Helix Realplay (1.0.5)
The Helix Player is an open source media player
for Linux, Solaris, and Symbian based on the
Helix DNA Client media engine. More
operating system versions are currently in
development.
Source: https://helixcommunity.org/

libjpeg (6b)

1.HIGO dependent (jpeg decoder )

2.DirectFb dependent (jpeg decoding)

http://ijg.org/

Source:

libpng (1.4.0)

1.DirectFb dependent (PNG decoder )

2.HiGO dependent (PNG decoding)

Source: http://github.com/jongwook/libpng/

zlib (1.2.5)
A data compression algorithm , the compiler
toolset mtd time required to use the zlib library

http://www.zlib.net/

Source:

rp-pppoe (3.11)
Internet Dependence
Source:

https://www.roaringpenguin.com/products/pppoe/

ISC DHCP (4.1.1-P1)
Internet Dependence
Source:

https://www.isc.org/downloads/dhcp/

Ffmpeg (0.1)
Development of media properties , the player
must assembly

http://ffmpeg.org/

Source:

Android - kernel - common (3.4)
Common Android Kernel Tr ee
Source:

https://android.googlesource.com/kernel/common/

Android (5.1.1_r1)
Android Operating System
Source:

https://developer.android.com/index.html

mali-400-kernel-drivers (master-20121127)
mali-400 kernel drivers for external compilation
for use with linux-sunxi kernel.
Source:

https://github.com/linux-sunxi/mali-400-kernel-d
rivers

NFS- nfs-utils (1.1.2)
File system dependency

http://sourceforge.net/projects/nfs/

Source:

coreutils (8.5)
The GNU Core Utilities are the basic file, shell
and text manipulation utilities of the GNU
operating system. These are the core utilities
which are expected to exist on every operating
system.

Source: http://www.gnu.org/software/coreutils/

dosfstools (3.0.25)
Source:

http://daniel-baumann.ch/software/dosfstools/

Samba (3.5.11)
Internet Dependence
Source:

https://www.samba.org/samba/

Arp Scan (1.8.4)
Internet Dependence
Source:

http://www.nta-monitor.com/tool-sresources/
security-tools/arp-scan
