Philips 55PUS8809 User Manual

www.philips.com/welcome

55PUS8809 55PUS8809

User Manual

1 TV Tour 4

1.1 Android TV 4

1.2 Ultra HD TV 4

1.3 Apps 4

1.4 Movies and Missed Shows 4

1.5 Social Networks 4

1.6 Pause TV and Recordings 4

1.7 Gaming 4

1.8 Skype 5

1.9 3D 5

1.10 Smartphones and Tablets 5

2 Setting Up 6

2.1 Read Safety 6

2.2 TV Stand and Wall Mounting 6

2.3 Tips on Placement 6

2.4 Power Cable 6

2.5 Antenna Cable 6

2.6 Satellite Dish 7

3 Network 8

3.1 Connect to Network 8

3.2 Network Settings 9

3.3 Network Devices 10

3.4 File Sharing 10

4 Connections 11

4.1 Tips on Connections 11

4.2 EasyLink HDMI CEC 12

4.3 CI+ CAM with Smart Card 13

4.4 Set-Top Box - STB 14

4.5 Satellite Receiver 14

4.6 Home Theatre System - HTS 15

4.7 Blu-ray Disc Player 16

4.8 DVD Player 16

4.9 Game Console 17

4.10 Gamepad 17

4.11 USB Hard Drive 18

4.12 USB Keyboard or Mouse 18

4.13 USB Flash Drive 19

4.14 Photo Camera 19

4.15 Camcorder 20

4.16 Computer 20

4.17 Headphones 21

5 Switching On and Off 22

5.1 On, Standby or Off 22

5.2 Philips Logo Brightness 22

5.3 Keys on TV 22

5.4 Sleep Timer 22

5.5 Switch Off Timer 22

6 Remote Control 24

6.1 Key overview 24

6.2 Pointer 25

6.3 Voice 26

6.4 Keyboard 26

6.5 Link up with the TV 27

6.6 IR Sensor 28

6.7 Batteries 28

6.8 Cleaning 28

7 Gesture Control 29

7.1 About Gesture Control 29

7.2 Camera 29

7.3 Hand Gestures 29

7.4 Gesture Overview 29

7.5 Tips 29

8 Home Menu 31

8.1 Open the Home Menu 31

8.2 Overview 31

8.3 Notifications 31

8.4 Search 31

9 Now on TV 32

9.1 About Now on TV 32

9.2 What You Need 32

9.3 Using Now on TV 32

10 Apps 33

10.1 About Apps 33

10.2 Install an App 33

10.3 Start an App 33

10.4 Chrome™ 33

10.5 App Lock 33

10.6 Widgets 34

10.7 Remove Apps and Widgets 34

10.8 Clear Internet Memory 34

10.9 Android Settings 34

10.10 Terms of Use - Apps 35

11 Video on Demand 36

11.1 About Video on Demand 36

11.2 Rent a Movie 36

11.3 Streaming 36

12 TV on Demand 37

12.1 About TV on Demand 37

12.2 Request a Programme 37

13 Channels 38

13.1 Watching Channels 38

13.2 TV Guide 44

14 Sources 46

14.1 Switch to a device 46

14.2 Device Detection 46

14.3 One Touch Play 46

15 3D 47

15.1 What You Need 47

15.2 The 3D Glasses 47

15.3 Watch 3D 49

15.4 Optimal 3D Viewing 49

15.5 Care of the 3D Glasses 49

15.6 Health Warning 49

16 Multi View 51

16.1 Open Multi View 51

16.2 Swap Screens 51

16.3 Open Recent 51

17 Games 52

17.1 What You Need 52

17.2 Game Settings 52

17.3 Play a Game 52

17.4 Gamepads 52

17.5 Split Screen Gaming 52

18 Videos, Photos and Music 54

18.1 From a USB Connection 54

18.2 From a Computer or NAS 54

18.3 From a Mobile Device 54

18.4 Videos 55

18.5 Photos 55

18.6 Music 56

19 Pause TV 57

19.1 What You Need 57

19.2 Pause a Programme 57

20 Recording 58

20.1 What You Need 58

20.2 Record a Programme 58

20.3 Watch a Recording 59

27 Specifications 107

27.1 Environmental 107

27.2 Power 107

27.3 Operating System 107

27.4 Reception 107

27.5 Display 107

27.6 Dimensions and Weights 108

27.7 Connectivity 108

27.8 Sound 108

27.9 Multimedia 109

28 Support 110

28.1 Register 110

28.2 Troubleshooting 110

28.3 Help 111

28.4 Online Help 111

28.5 Repair 111

29 Safety and Care 113

29.1 Safety 113

29.2 Screen Care 114

30 Terms of Use, Copyrights and Licenses 115

30.1 Terms of Use - TV 115

30.2 Copyrights and Licences 115

21 Skype 60

21.1 About Skype 60

21.2 What you need 60

21.3 Start with Skype 60

21.4 Skype Menu 60

21.5 People 61

21.6 Calling on Skype 62

21.7 Skype Credit 63

21.8 Skype settings 63

21.9 Back to TV 64

21.10 Sign out 64

22 Multi Room 65

22.1 About Multi Room 65

22.2 What You Need 65

22.3 Using Multi Room 65

23 Share This… 66 24 Philips TV Remote App 67 25 Setup 68

25.1 Quick Settings 68

25.2 Picture 68

25.3 Sound 71

25.4 Ambilight 73

25.5 General Settings 76

25.6 Eco Settings 76

25.7 Accessibility 77

25.8 Network 78

25.9 Installation Antenna/Cable 78

25.10 Installation Satellite 81

Index 117

26 Software 85

26.1 Update Software 85

26.2 Software Version 85

26.3 Open Source Software 85

26.4 Open Source License 85

26.5 Announcements 106

1.4

TV Tour

1.1

Android TV

This Philips TV is powered by As on your smartphone or tablet, your new TV has the most

practical Apps for every bit of TV entertainement you can think of. Watch TV channels, play online games, call a friend on Skype or simply speak and ask the TV to find your favourite song on the Internet.

With the you have your TV channels at your fingertips. Send a photo to the large TV screen or follow your favourite cooking show on your tablet in the kitchen. From now on your TV is part of your mobile household.

Connect the TV to your home network and the Internet. Android, Google Play and other marks are trademarks of

Google Inc. The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License.

http://creativecommons.org/licenses/by/3.0/legalcode

Philips TV Remote App

Android™

on your smartphone or tablet,

Movies and Missed Shows

To get a Open

your TV directly. Open the video store App, create your personal account, select the movie and press play. No fuss with downloading*.

Video on Demand is available in selected countries. For more information, press

on Demand

* Depending on the video streaming service of the selected video store.

1.5

rental video

Video on Demand

, you don't need to leave the house.

and get that latest movie streamed to



Keywords

and look up

Video

Social Networks

No need to get up to check your friend's messages on your computer.

On this TV you get the messages from your your TV screen. You can send a return message from your couch. You can find the Facebook and Twitter Apps on the Home menu tab

For more information, press



Apps



Keywords

social network

and look up

Apps

1.2

Ultra HD TV

This TV has an much as normal HD displays. Ultra HD means 8 million pixels for the most refined and lifelike picture on TV.

On top, the new any incoming TV signal into Ultra HD resolution. So you can enjoy this stunning picture quality the moment you switch on the TV. Or you can watch native Ultra HD videos through an HDMI connection. Ultra HD offers TV viewing that is crisp and sharp even on a big screen.

1.3

Ultra HD

Ultra Pixel HD Engine

display. Its resolution is four times as

continuously converts

Apps

To get you started, some practical your TV.

The Apps pages show the collection of Apps (Applications) on your TV. Like Apps on your smartphone or tablet, the Apps on your TV offer specific functions for an enriched TV experience. Apps like Facebook, YouTube, Twitter, TV games or weather forecasts (a.o.). Or start an Internet Browser App, like Google Chrome, to surf the Internet.

For more information, press



Keywords

are pre-installed on

Apps

and look up

Apps

1.6

Pause TV and Recordings

If you connect a broadcast from a digital TV channel.

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can watch it again later. With a USB Hard Drive connected, you can also record digital broadcasts. You can record while you are watching a programme or schedule a recording of an upcoming programme.

For more information, press

Recording

1.7

USB Hard Drive

, you can pause and record a



Keywords

and look up

Pause

Gaming

This TV is your big screen for You can play a game from a connected Game Console, a game

from an installed App or simply an online game on a website. You can set the TV to the ideal settings for gaming, to allow quick and responsive action. If you play a multi-player game with split screens, you can set the TV to show each screen as a full screen simultaneously. Each player can focus on his own

. Big enough for two.

gaming

game to play. For more information, press



Keywords

and look up

Gaming

Download the Philips TV Remote App from your favourite app

store today. It's free.

1.8

Skype

With

Skype™

right from your living room, even when you’re apart. So there’s no more huddling ‘round the computer or missing an out-ofshot moment.

You can make free Skype-to-Skype voice and video calling to other Skype-enabled devices.

To make a video call, you need a camera with a built-in microphone and a good connection to the Internet. Some Philips TVs have a camera and microphone built in.

For more information, press

on your TV, you can create and share memories



Keywords

and look up

Skype

The Philips TV Remote App is available for iOS and Android.

1.9

Your new TV is a Enjoy the immersive experience of watching a movie in 3D. Play

a movie in 3D on your Blu-ray Player or rent a 3D movie from a Video Store from the Home menu, Video on Demand.

The TV uses the Active 3D technology to watch 3D in its full resolution.

For more information, press

1.10

3D TV



Keywords

and look up 3D.

Smartphones and Tablets

The new With the TV Remote App on your smartphone or tablet, you

master your media around you. Send photos, music or videos to your big TV screen or watch any of your TV channels live on your tablet or phone. Open the TV Guide and schedule a recording for tomorrow. Your TV at home will do the job. Switch on Ambilight+hue and set the coziest colour effects in your living room. With the TV Remote App you are in control. You might consider to simply lower the TV volume.

Philips TV Remote App

is your new TV buddy.

Setting Up

TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

2.1

Read Safety

Read the safety instructions first before you use the TV. To read the instructions, press the colour key

look up

2.2

Safety instructions



Keywords

and

TV Stand and Wall Mounting

TV Stand

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com.

Use the product type number of the TV to look for the

Start Guide

to download.

Quick

2.3

Tips on Placement

• Position the TV where light does not shine directly on the screen.

• Dim lighting conditions in the room for best Ambilight effect.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

2.4

Power Cable

Wall Mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

• 55PUS8809

VESA MIS-F 400x400, M8

Preparation

First remove the 4 plastic screw caps out of the threaded bushes on the back of the TV. Make sure that the metal screws, to mount the TV to the VESAcompliant bracket, go about 10mm deep inside the threaded bushes.

• Insert the power cable into the back of the TV.

• Make sure the power cable is securely inserted in the connector.

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

Press the colour key  for more information on switching the TV on or off.

Keywords

POWER

and look up

connector on the

Switching On

Caution

Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV.

2.5

Antenna Cable

Insert the antenna plug firmly into the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

Antenna

socket at the

Two Tuners

To watch a satellite channel and to record another channel at the same time, you must connect 2 identical cables from your satellite dish to the TV.

Connect the first cable from the satellite dish directly to the

connection and connect the second cable to

coaxial cable fit for connecting a satellite antenna dish. Make sure your satellite dish is perfectly aligned before you start the installation.

During the satellite installation, select

Two Tuners

SAT 2

SAT

. Use a

2.6

Satellite Dish

One Tuner

To watch a satellite channel and to record another channel at the same time, you must connect 2 identical cables from your satellite dish to the TV. If you only have 1 cable available, the channel you are recording is the only channel you can watch.

Connect the cable from the satellite dish directly to the connection. Use a coaxial cable fit for connecting a satellite antenna dish. Make sure your satellite dish is perfectly aligned before you start the installation.

During the satellite installation, select

One Tuner

SAT 1

Unicable or MDU

If you use a Unicable system, connect the cable to the

connection. Use a coaxial cable fit for connecting a satellite

antenna dish. Make sure your satellite dish is perfectly aligned before you start the installation.

During the satellite installation, select later

Unicable

Two Tuners

SAT

and

Network

3.1

5 - Go to the router, press the WPS button and return to the TV within 2 minutes.

6 - Click 7 - A message will be shown when the connection is successful.

Connect

to make the connection.

Connect to Network

Wireless Connection

What You Need

To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

Make the Connection

Wireless

To make a wireless connection…

1 - Press  and press  (left) 2 - Click 3 - Click 4 - In the list of found networks, click on your wireless network.

If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select 5 - Depending on the type of router, enter your encryption key

- WEP, WPA or WPA2. If you entered the encryption key for this network before, you can click OK to make the connection immediately. 6 - A message will be shown when the connection is successful.

Network Wireless

Enter Name

and click

to enter the network name yourself.

Connect to Network

Setup

WPS with PIN Code

If your router has WPS with a PIN code, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Press HOME to open the Home menu. 2 - In the menu bar, click 3 - Go to 4 - Click 5 - Write down the 8-digit PIN code shown on screen and

enter it in the router software on your PC. Consult the router manual on where to enter the PIN code in the router software.

6 - Click 7 - A message will be shown when the connection is successful.

Problems

Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi 802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

DHCP

• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.

Network

WPS with PIN code

Connect



and click

to make the connection.

and click

Apps

Connect to Network



Setup

WPS

If your router has WPS, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Press HOME to open the Home menu. 2 - In the menu bar, click 3 - Click 4 - Click

Network WPS

and click



and click

Apps

Connect to Network



Setup

Wired Connection

What You Need

To connect the TV to the Internet, you need a network router with a connection to the Internet. Use a high-speed (broadband) connection to the Internet.

Switch On with Wi-Fi (WoWLAN)

You can switch this TV on from your smartphone or tablet if the TV is in Standby. The setting

(WoWLAN)

To switch on WoWLAN…

must be switched on.

Switch On with Wi-Fi

Make the Connection

To make a wired connection… 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is switched on. 3 - Press  and press  (left) 4 - Click 5 - Click

connection. 6 - A message will be shown when the connection is successful.

If the connection fails, you can check the DHCP setting of the router. DHCP should be switched on.

**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.

3.2

Network Wired

and click

. The TV constantly searches for the network

Connect to Network

Setup

1 - Press  and press  (left) 2 - Click 3 - Click On. 4 - Press

Network



and click

repeatedly if necessary, to close the menu.

BACK

Switch on with Wi-Fi (WoWLAN)

Setup

Digital Media Renderer - DMR

If your media files do not play on your TV, make sure that the Digitial Media Renderer is switched on. As a factory setting, DMR is switched on.

To switch on DMR…

1 - Press  and press  (left) 2 - Click 3 - Click On. 4 - Press

Network



and click

repeatedly if necessary, to close the menu.

BACK

Digital Media Renderer

Setup

Wi-Fi Miracast

Switch on Wi-Fi Miracast to share the screen of your smartphone, tablet or computer on the TV.

Network Settings

View Network Settings

You can view all current network settings here. The IP and MAC address, signal strength, speed, encryption method, etc.

To view the current network settings…

1 - Press  and press  (left) 2 - Click 3 - Press

Network



and click

repeatedly if necessary, to close the menu.

BACK

View Network Settings

Network Configuration

If you are an advanced user and want to install your network with Static IP addressing, set the TV to

To set the TV to Static IP…

1 - Press  and press  (left) 2 - Click 3 - Click 4 - Click 5 - Press

Network Static IP Static IP Configuration



and click

and return to

repeatedly if necessary, to close the menu.

BACK

Network Configuration

Setup

Static IP

Setup

Network

and configure the connection.

For more information, press up

Miracast™, switch on



Keywords

and look

Wi-Fi Smart Screen

To watch digital TV channels on your smartphone or tablet with the Philips TV Remote App, you must switch on Wi-Fi Smart Screen. Some scrambled channels might not be available on your mobile device.

To switch on Wi-Fi Smart Screen…

1 - Press  and press  (left) 2 - Click 3 - Click On. 4 - Press

Network



and click

repeatedly if necessary, to close the menu.

BACK

Wi-Fi Smart Screen

Setup

TV Network Name

If you have more than one TV in your home network, you can give the TV a unique name.

To change the TV name…

1 - Press  and press  (left) 2 - Click

Network

and click

TV Network Name

Setup

3 - Enter the name with the Remote Control Keyboard. 4 - Click 5 - Press

Done



BACK

repeatedly if necessary, to close the menu.

Clear Internet Memory

With Clear Internet Memory you clear all Internet files stored on your TV. You clear your Philips Smart TV registration and parental rating settings, your video store app logins, all Smart TV app favourites, Internet bookmarks and history. Interactive MHEG applications can also save so-called 'cookies', on your TV. These files will also be cleared.

To clear the Internet memory…

1 - Press  and press  (left) 2 - Click 3 - Click 4 - Press

3.3

Network Yes



and click

to confirm.

repeatedly if necessary, to close the menu.

BACK

Clear Internet Memory

Setup

Network Devices

The TV can connect to other devices in your wireless network, like your computer or smartphone. You can use a computer with Microsoft Windows or Apple OS X.

3.4

File Sharing

On this TV, you can open photos, music and videos stored on your computer. Use a recent version of media server software like Philips MediaManager*, Windows Media Player 11, Twonky™ or similar.

Install the media server software on your computer and set it up to share your media files with the TV. Read the manual of the media server software for more information. This software must be running on your computer to view or play your files on TV.

* You can download the Philips MediaManager software from the Philips support site www.philips.com/support

For an overview of supported media server software, press



supported

Keywords

and look up

Media server software,

Connections

4.1

Tips on Connections

Connectivity Guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to

www.connectivityguide.philips.com

Antenna

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

and look up

EasyLink CEC

HDMI ARC

EasyLink HDMI CEC

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device. For more information on using EasyLink, press the colour key



Keywords

DVI to HDMI

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.

Copy protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

All of the HDMI connections on the TV have (Audio Return Channel).

HDMI

HDMI CEC

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) or Ultra HD (UHD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

If the device, typically a Home Theatre Sysytem (HTS), also has the HDMI ARC connection, connect it to any of the HDMI connections on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

You can use any HDMI connection on this TV to connect the HTS but ARC is only available for 1 device/connection at a time.

HDMI Ultra HD

You can watch videos filmed or made in 'native' Ultra HD resolution - 3840x2160 pixels - on this TV.

Connect a Blu-ray Disc player, game console or computer that plays Ultra HD videos to the speed HDMI cable to connect. The HDMI UHD connections have ARC (Audio Return Channel).

Only the

HDMI 1

connection has HDCP 2.2 .

HDMI 1

connection. Use a High

DVI to HDMI

If you still own a device that only has a DVI connection, you can connect the device to any of the to HDMI adapter.

connection with a DVI

HDMI

Connect the audio L/R cable to the jack 3.5mm).

AUDIO IN

connector (mini-

Y Pb Pr

Y Pb Pr - Component Video is a high quality connection. The YPbPr connection can be used for High Definition (HD) TV

signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.

Audio Out - Optical

Audio Out - Optical is a high quality sound connection. This optical connection can carry 5.1 audio channels. If your

device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In

- Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.

Match the YPbPr (green, blue, red) connector colours with the cable plugs when you connect. Use an Audio L/R cinch cable if your device also has sound.

Scart

SCART is a good quality connection. The SCART connection can be used for CVBS and RGB video

signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals. The SCART connection also supports NTSC playback.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System. For more information, press

Out Settings

If the sound does not match the video on screen, you can adjust the audio to video synchronisation. For more information, press

to Video Sync

4.2



Keywords



Keywords

and look up

Audio

EasyLink HDMI CEC

EasyLink

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

4 - Press

EasyLink Remote Control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink remote control separately. In the EasyLink settings menu, select and select



Off

repeatedly if necessary, to close the menu.

BACK

EasyLink Remote Control

EasyLink setup

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

Example HDMI CEC branding names are property of their respective owners.

Operate Devices

To operate a device connected to HDMI and set up with EasyLink, select the device - or its activity - in the list of TV connections. Press an HDMI connection and press OK.

Once the device is selected, the TV remote control can control the device. However the keys and  other TV keys, like device.



SOURCES



Ambilight

, select a device connected to

OPTIONS

, are not forwarded to the

and some

4.3

CI+ CAM with Smart Card

CI+

This TV is ready for the CI+ Conditional Access. With CI+ you can watch premium HD programmes, like movies

and sports, offered by digital TV operators in your region. These programmes are scrambled by the TV operator and descrambled with a prepaid CI+ module. Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes. These programmes have a high level of copy protection.

Contact a digital TV operator for more information on terms & conditions.

If the key you need is not on the TV remote control, you can select the key in the Options menu. Press  the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.

Only devices that support will respond to the TV remote control.

OPTIONS

and select

Controls

EssyLink Remote Control

in the menu bar. On

function

EasyLink Settings

The TV comes with the EasyLink settings switched on.

EasyLink

To switch off EasyLink completely…

1 - Press  and press  (left) for 2 - Click

step further. 3 - Click

General Settings

Off

EasyLink

Setup

and click

EasyLink

one

One Smart Card

Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes.

Insert the smart card into the CAM module. See the instruction you received from the operator.

To insert the CAM in the TV… 1 - Look on the CAM for the correct method of insertion.

Incorrect insertion can damage the CAM and TV. 2 - While looking at the back of the TV, with the front of the CAM facing towards you, gently insert the CAM into the slot

COMMON INTERFACE 1

3 - Push the CAM in as far as it will go. Leave it in the slot permanently.

When you switch on the TV, it may take a few minutes before the CAM is activated. If a CAM is inserted and subscription fees are paid (subscription methods can differ), you can watch the

scrambled channels supported by the CAM smart card. The CAM and smart card are exclusively for your TV. If you

remove the CAM, you will no longer be able to watch the scrambled channels supported by the CAM.

Two Smart Cards

Some Digital TV operators can provide a second CI+ module (CAM) and smart card. A second CAM and smart card is needed when you want to watch one channel while recording another channel from the same TV operator.

If you can watch the same amount of channels with each card, both cards have identical viewing rights. If you can watch less channels with one of the cards, the cards have non-identical viewing rights.

If your smart cards have identical viewing rights, it does not matter which card you put in which slot. If one of the cards has more viewing rights than the other one, insert the card with the most viewing rights in the slot the card with less rights in

COMMON INTERFACE 2

COMMON INTERFACE 1

. Insert

1 - Press 2 - Click on the channel type you are using the CAM

for.

3 - Press 4 - Click on the TV operator of the CAM. The following screens

come from the TV operator. Look up the PIN code setting.

4.4



SOURCES

Antenna TV, Cable TV



OPTIONS

Satellite TV

and click

Common Interface

Set-Top Box - STB

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV. Alternatively, you can use a SCART cable if the Set-top box has no HDMI connection.

Insert the smart cards into the CAM modules. See the instruction you received from the operator.

To insert the CAM in the TV… 1 - Look on the CAM for the correct method of insertion.

Incorrect insertion can damage the CAM and TV. 2 - While looking at the back of the TV, with the front of the CAM facing towards you, gently insert the CAM into the slot. 3 - Push the CAM in as far as it will go. Leave it in the slot permanently.

When you switch on the TV, it may take a few minutes before the CAM is activated. If a CAM is inserted and subscription fees are paid (subscription methods can differ), you can watch the scrambled channels supported by the CAM smart card.

The CAM and smart card are exclusively for your TV. If you remove the CAM, you will no longer be able to watch the scrambled channels supported by the CAM.

Passwords or PIN codes

For some CAMs, you must enter a PIN code to watch its channels. When you set the PIN code for the CAM, we recommend you to use the same code you are using to unlock the TV.

To set the PIN code for the CAM…

Switch Off Timer

Switch off this automatic timer, if you only use the remote control of the Set-top box. Switch this timer off to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

, press the colour key 

Help

Off Timer

4.5

for more information.

Keywords

and look up

Switch

Satellite Receiver

Connect the dish antenna cable to the Satellite receiver. Next to the antenna connection, add an HDMI cable to connect

the device to the TV. Alternatively, you can use a SCART cable if the device has no HDMI connection.

Connect with HDMI

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to send the sound of the TV picture to the Home Theatre System.

Switch Off Timer

, press the colour key 

Help

Off Timer

4.6

for more information.

Keywords

and look up

Switch

Home Theatre System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

For more information, press the colour key look up

Audio to Video Sync



Keywords

and

Audio Out Settings

Audio Out Delay

With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.

Automatic audio to video sync

With recent Philips Home Theatre Systems, the audio to video sync is done automatically and always correct.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

For more information, press the colour key look up

Audio to Video Sync



Keywords

and

Audio sync delay

For some Home Theatre Systems you might need to adjust the audio sync delay to synchronise the audio to the video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio Out Delay on the TV.

To switch off the Audio Out Delay…

1 - Press  and press  (left) for 2 - Click 3 - Click 4 - Press

Sound Off



Setup

Advanced

repeatedly if necessary, to close the menu.

BACK

and click

Audio Out Delay

Audio Out Offset

If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates for the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms.

The Audio Out Delay setting should be switched on. To synchronise the sound on the TV…

1 - Press  and press  (left) for 2 - Click 3 - Use the slider bar to set the sound offset and press OK. 4 - Press

Audio Out Format

If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio Out Format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.

Sound



BACK

Advanced

repeatedly if necessary, to close the menu.

and click

Setup

Audio Out Offset

Problems with HTS sound

Sound

Stereo

Advanced

Audio

Audio Out Format

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the

Out Format

Press  for

No sound

If you cannot hear the sound from the TV on your Home Theatre System, check if you connected the HDMI cable to an

HDMI ARC

HDMI connections on the TV are HDMI ARC connections.

4.7

of the TV to

Setup

connection on the Home Theatre System. All

Blu-ray Disc Player

Use a

High speed HDMI

player to the TV.

cable to connect the Blu-ray Disc

To set the Audio Out Format…

1 - Press  and press  (left) for 2 - Click 3 - Click 4 - Press

Audio Out Levelling

Use the Audio Out Levelling setting to level the volume (loudness) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume…

1 - Press  and press  (left) for 2 - Click 3 - If the volume difference is large, select

difference is small, select 4 - Press

Audio Out Levelling affects both the Audio Out - Optical and HDMI ARC sound signals.

Sound Multichannel



Sound



Advanced

repeatedly if necessary, to close the menu.

BACK

Advanced

repeatedly if necessary, to close the menu.

BACK

and click

Stereo

and click

Less

Setup

Audio Out Format

Setup

Audio Out Levelling

. If the volume

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.

In Help, press the colour key

EasyLink HDMI CEC

4.8

for more information.



Keywords

and look up

DVD Player

Use an HDMI cable to connect the DVD player to the TV. Alternatively, you can use a SCART cable, if the device has no HDMI connection.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

For more information on EasyLink, press the colour key

4.9



Keywords

and look up

EasyLink HDMI CEC

Game Console

HDMI

For best quality, connect the game console with a High speed HDMI cable to the TV.

YPbPr

Connect the game console with a component video cable (Y Pb Pr) and an audio L/R cable to the TV.

4.10

Gamepad

Connect a Gamepad

To play games from the Internet on this TV, you can connect a selected range of wireless Gamepads. When you connect the Gamepad, you can use it immediately.

To connect a Gamepad… 1 - Plug in the small nano receiver in one of the USB

connections on the side of the TV. The wireless nano receiver comes with the Gamepad. 2 - If the Gamepad is switched on, you can use the Gamepad.

You can connect a second Gamepad in the second USB connection on the side of the TV.

You can also use the Gamepad to control the Pointer.

Video-Audio LR / Scart

Connect the game console to the TV with a composite cable (CVBS) and an audio L/R cable to the TV.

If your game console only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.

Suitable Gamepads

A selected range of wireless Gamepads are suited and tested for use on this TV. Other Gamepads might not be fully compatible.

The suited Gamepads are…

• Logitech F710

• Logitech F510

• Xbox 360 Wireless Controller for Windows

• Speedlink Strike FX Wireless Gamepad

Trouble with Interference

To solve possible interference with other wireless devices on TV…

• Use a USB extension cord and move the nano receiver about 1 meter away from the TV.

• Alternatively, you can use a powered USB hub connected to the TV and plug in the nano receivers in the USB hub.

4.11

USB Hard Drive

What You Need

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

To Pause

To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 32GB disk space.

To Record

To pause and record a broadcast, you need a minimum of 250GB disk space. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive.

For more information on how to install a USB Hard Drive, press the colour key

installation

and look up

USB Hard Drive,



Keywords

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

For more information, press the colour key look up

4.12

Pause TV

Recording



Keywords

and

USB Keyboard or Mouse

USB Keyboard

Install the Keyboard

Connect a USB keyboard (USB-HID type) to enter text on your TV.

You can connect a keyboard and a mouse to the TV. Use one of the

connections to connect.

USB

Installation

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel, press

(Pause). Trying to pause will start the formatting. Follow the instructions on screen. When the USB Hard Drive is formatted, leave it connected

permanently.

USB



Install the keyboard

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.

To change the keyboard layout setting when a layout was selected…

1 - Press  and press  (left) for 2 - Click

start the keyboard setup.

General Settings

connections on the TV. When

USB

and click

Setup

USB Keyboard Settings

Keys

Keys for entering text

• Enter key = OK

• Backspace = delete character before cursor

• Arrow keys = navigate within a text field

• To switch between keyboard layouts, if a secondary layout is set, press the

Keys for Smart TV Apps and Internet pages

• Tab and Shift + Tab = Next and Previous

• Home = scroll to the top of the page

• End = scroll to the bottom of the page

• Page Up = jump one page up

• Page Down = jump one page down

• + = zoom in one step

• - = zoom out one step

• * = fit the web page to the screen width

Ctrl + Spacebar

keys simultaneously.

press OK. 3 - Press the arrows  (up) or  (down) to increase or lower the speed. 4 - Press the arrow  (right) move the mouse around to test the speed you set. 5 - Press the arrow  (left) to return to the slider bar. You can adjust the setting again. 6 - With the slider bar selected, press  (left) to store and close this setting. 7 - Press

4.13



repeatedly if necessary, to close the menu.

BACK

USB Flash Drive

You can view photos or play your music and videos from a connected USB flash drive.

USB Mouse

Connect USB Mouse

You can connect a USB mouse (USB-HID type) to navigate on TV.

Back



Connect the mouse

Switch the TV on and connect the USB mouse to one of the

connections on the TV. You can also connect the USB

USB

mouse to a connected USB keyboard.

Mouse clicks

• Left click =

• Right click = You can use the scroll wheel to scroll pages up and down.

Insert a USB flash drive in one of the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press

SOURCES

To stop watching the USB flash drive content, press select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

Ultra HD on USB

You can view photos in Ultra HD resolution from a connected USB device or flash drive. The TV will downscale the resolution to Ultra HD if the resolution of the photo is higher. You cannot play a native Ultra HD video on any of the USB connections.

For more information on watching or playing content from a USB flash drive, press the colour key

Photos, Videos and Music

and click

USB

connections on the

USB



Keywords





and look up

For more information on how to connect a keyboard, press the colour key

Mouse Speed

You can adjust the speed of the mouse, the mouse moving on screen.

To adjust the speed…

1 - Press  and press  (left) 2 - Select



Keywords

General Settings

and look up

Pointer/Mouse Speed

Setup

USB Keyboard

and

4.14

Photo Camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the on the camera after you made the connection.

connections on the TV to connect. Switch

USB

Video-Audio LR / Scart

You can use an HDMI, YPbPr or SCART connection to connect your camcorder. If your camcorder only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.

If the contents list does not appear automatically, press



Keywords

, and click

and look up

SOURCES

Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

Ultra HD on USB

For more information on viewing photos, press the colour key

Ultra HD on USB

4.15

USB

Photos, Videos and Music



4.16

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

Camcorder

HDMI

For best quality, use an HDMI cable to connect the camcorder to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

Settings

If your computer is added as a Computer type of device in the Source menu (the list of connections), the TV is set to the ideal Computer setting automatically.

If you use your computer to watch movies or use it to play games, you might want to set the TV back to the ideal TV watching or gaming setting.

To set the TV to the ideal setting manually…

1 - Press  and press  (left) for 2 - Click 3 - Click

movie). 4 - Press

Remember to set the Game or computer setting back to

Computer

4.17

Picture Game



Advanced

(for gaming) or click

repeatedly if necessary, to close the menu.

BACK

when you stop playing the game.

and click

Setup

Game or Computer

Computer

(for watching a

Headphones

You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

To adjust the volume…

1 - Press  and press  (left) 2 - Click

slider bar to adjust the value. 3 - Press

Sound



BACK

Headphones Volume

repeatedly if necessary, to close the menu.

Setup

and click inside the

5.3

Switching On and Off

5.1

On, Standby or Off

Before you switch on the TV, make sure you plugged in the mains power in the

To put the TV in Standby when the indicator light is off, press the small joystick key on the back of the TV. The indicator will light up.

With the TV in Standby, press  on the remote control to switch the TV on. Alternatively, press

Switch back to Standby

To switch the TV to Standby, press  on the remote control.

POWER

connector on the back of the TV.

HOME

Keys on TV

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu… 1 - With the TV switched on, press the joystick key on the back

of the TV to bring up the basic menu. 2 - Press left or right to select the TV is in Shop location, you can also select 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. Press the joystick key to slide out the camera. 4 - The menu will disappear automatically.

To switch the TV off, select

Volume, Channel

and press the joystick key.

TV Off

Sources

Camera

. If

Switch Off

To switch the TV Off, press the joystick key. The indicator light goes off. The TV is still connected to the mains power but consumes very little energy.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

5.2

Philips Logo Brightness

You can switch off or adjust the brightness of the Philips logo on the front of the TV.

To adjust or switch off…

1 - Press  and press  (left) 2 - Click 3 - Click

the lighting of the logo. 4 - Press

General Settings Maximum, Medium, Minimum



BACK

and click

repeatedly if necessary, to close the menu.

Setup

Philips Logo Brightness

or click

Off

to switch off

5.4

Sleep Timer

With the automatically after a preset time.

To set the Sleep Timer…

1 - Press  and press  (Left) 2 - Click

you can set the time to up to 180 minutes in increments of 5 minutes. If set to 0 minutes, the Sleep Timer is switched off. You can always switch off your TV earlier or reset the time during the countdown. 3 - Press

5.5

Sleep Timer

General Settings



BACK

, you can set the TV to switch to Standby

Setup

Sleep Timer

repeatedly if necessary, to close the menu.

. With the slider bar

Switch Off Timer

If the TV receives a TV signal but you don't press a key on the remote control during a 4 hour period, the TV switches of automatically to save energy. Also, if the TV does not receive a TV signal nor a remote control command for 10 minutes, the TV switches off automatically.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.

To deactivate the Switch Off Timer

…

1 - Press  and click 2 - Click

Switch Off Timer

Eco Settings

. Click inside the slider bar to adjust

the value. The value 0 (Off) deactivates the automatic switch off.

The icon  is shown in front of Switch Off Timer when it is active.

For more information on environmentally friendly TV settings, press the colour key



Keywords

and look up

Eco Settings

Remote Control

6.1

Key overview

Top

HOME

To open the Home menu.

- 

SOURCES

To open the Sources menu.

- 

Standby

To switch the TV on or back to Standby.

Playback and Record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Fast forward , to go fast forward

• Record , to start recording



To switch Ambilight on or off and to switch Ambilight on in Standby.



To open or close the TV Guide.

VOICE microphone

6 - 

Settings

To open the Settings menu.

Ambilight

TV GUIDE

   

Direct selection of options. Blue key , opens 4 -



INFO

To open or close programme info.



BACK

To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous App/Internet page.

6 -  - EXIT

To switch back to watching TV. To leave an interactive TV application.



OPTIONS

To open or close the Options menu.

- OK key

To confirm a selection or setting. To activate Pointer and click.

Arrow / navigation

To navigate up, down, left or right.



To open an extra small screen.

MULTIVIEW

Colour keys

keys

Help



Picture Format

To open or close the Picture Format menu.



To open or close the 3D menu or switch to 3D immediately.



VOICE

To start a search request with voice input.

Middle

Bottom



Volume

To adjust the volume level.

Number keys

To select a channel directly.

SUBTITLE

To switch Subtitles on, off or on during mute.



LIST

To open or close the Channel List.



Channel

To switch to the next or previous channel in the channel list. To open the next or previous page in Text/Teletext. To start the next or previous chapter on a disc.



Mute

To mute the sound or to restore it.

TEXT

To open or close Text/Teletext.

6.2

Pointer

About Pointer

Instead of navigating the screen with the arrow keys, you can use the

Pointer

briefly jiggle the remote control.

Clicking

To select what you need, hover over the item with the Pointer and press – click – the OK key. As you do with a computer mouse. For the still need to press the keys on the remote control.

To press a key while using the Pointer… 1 - Place the Pointer on top of the item on screen – a channel in

the Channel List for example.

2 - Lift your thumb to leave the Pointer on that position. 3 - Press the colour key you need. 4 - Put your thumb back on the OK key to go on using the

Pointer.

Arrow Navigation

If you press an arrow key (left, right, up or down) to navigate, the Pointer disappears. The TV switches to arrow key navigation. To wake up the Pointer, put your thumb on the OK key and briefly jiggle the remote control.

Colour Keys



INFO

and



OPTIONS

you

The Pointer works like a computer mouse. You move the Pointer  — a blue arrow — by slightly moving the remote control. As for a computer mouse, you can adjust the speed of the Pointer.

Next to the Pointer, you can always use the arrow keys to make a selection, the Pointer will temporarily disappear. Some applications — like Text/Teletext — or some Internet pages, do not support the Pointer. The TV will automatically switch back to the arrow keys for navigation.

If you do not wish to use the Pointer, you can switch it off. If you connect a Gamepad, you can also use the Gamepad to

control the Pointer.

Using the Pointer

Activate

When you open a screen or application that supports Pointer control, an inactive Pointer will appear. A greyish  (arrow tip) somewhere in the middle of the screen.

Put your thumb on the OK key – do not press it – to activate the Pointer. Now move the remote control from the wrist, no need to move your arm. You can let go of the OK key and leave the Pointer where it is. The Pointer will disappear after 5 seconds. You can move the remote control and call up the Pointer when you put your thumb back on the OK key.

Reposition

The Pointer might get disoriented after a while. To reposition the Pointer, lift your thumb, point the remote control at the blue arrow on screen and put your thumb back on the OK key.

Pointer Speed

You can adjust the speed of the Pointer, the speed at which the Pointer moves on screen.

To adjust the speed…

1 - Press  and press  (left) 2 - Select

press OK. 3 - Press the arrows  (up) or  (down) to increase or lower the speed. 4 - Press the arrow  (right) to test the speed you set. Put your thumb on the OK key to test the speed of the Pointer. 5 - Press the arrow  (left) to return to the slider bar. You can adjust the setting again. 6 - With the slider bar selected, press  (left) to store and close this setting. 7 - Press

General Settings



BACK

repeatedly if necessary, to close the menu.

Setup

Pointer/Mouse Speed

and

To wake up the Pointer, put your thumb on the OK key and

Switch Off Pointer

To switch off the Pointer…

what you are looking for. Channels must be installed and media must be set to share. Connected devices must be switched on. The TV must have a connection to the Internet.

1 - Press  and press  (left) 2 - Select

select

Off

3 - Press

6.3

General Settings



BACK

repeatedly if necessary, to close the menu.

Setup

Remote Control Pointer

and

Voice

Using Voice

With Voice, you can control the TV by simply talking to the remote control. The TV must be connected to the Internet.

You can tell the TV to tune to a specific channel or to start watching an ongoing programme from the TV Guide. You can use Voice anytime to search for whatever you are looking for on the Internet. Alternatively, you can say the name of an App to start it on TV.

To control the TV with Voice…

1 - Press 2 - First say the command followed by what you want. You can

speak for 10 seconds before the microphone switches off. You can always press

The TV will try to execute your command.



VOICE



VOICE

to repeat your command.

6.4

Keyboard

Overview

Qwerty and Azerty

Overview of a Qwerty/Azerty keyboard.*

Azerty character

Character position if the keyboard layout is set to Azerty.



Shift

To type uppercase characters.

Ω Special characters

To open the onscreen keyboard to select accented characters or symbols.

Voice is not available during a Skype call.

Voice Commands

To help Voice to better understand what you want, you can use these commands.

WATCH

look for this TV programme and will try to switch to the correct channel.

CHANNEL

channel and will try to tune to it.

PLAY

in you collection of music and will try to play it.

your media and show the search results.

GOOGLE

the Internet and show the google search results.

GO TO

the Philips website.

, [e.g. say 'watch The Muppets Show'] - The TV will

, [e.g. say 'channel BBC1'] - The TV will look for this

, [e.g. say 'play Jingle Bells'] - The TV will look for this song

, [e.g. say 'search The Hobbit'] - The TV will search

, [e.g. say 'google stock market'] - The TV will search

, [e.g. say 'go to Philips.com'] - The TV will try to open

- Fn key

To type a number or punctuation character.



Spacebar

Navigation

- 

To share online what you are watching at the moment. * Your remote control has a Qwerty / Azerty or a Qwerty /

Cyrillic keyboard, depending on your region.

Qwerty and Cyrillic

Overview of a Qwerty/Cyrillic keyboard.*

and

Philips 55PUS8809 User Manual

Contents
