Philips 55PUH6101, 49PUH6101, 43PUH6101 User Manual

0 (0)

www.philips.com/welcome

6101 series

User Manual

43PUH6101 49PUH6101 55PUH6101

1 TV tour 4

1.1 Smart TV 4

1.2 App gallery 4

1.3 Rental videos 4

1.4 Ultra HD TV 4

1.5 Pause TV and recordings 4

1.6 Smartphones and tablets 4

2 Setting up 6

2.1 Read safety 6

2.2 TV stand and wall mounting 6

2.3 Tips on placement 6

2.4 Power cable 6

2.5 Antenna cable 6

3 Network 8

3.1 Network and Internet 8

4 Connect devices 12

4.1 About connections 12

4.2 CAM with smart card - CI+ 15

4.3 Receiver - Set-Top Box 16

4.4 Home Theatre System - HTS 17

4.5 Smartphones and tablets 18

4.6 Blu-ray disc player 18

4.7 DVD player 19

4.8 Headphones 19

4.9 Game console 19

4.10 USB hard drive 20

4.11 USB keyboard 21

4.12 USB mouse 21

4.13 USB flash drive 22

4.14 Photo camera 22

4.15 Camcorder 22

4.16 Computer 22

5 Switching On and Off 24

5.1 On or standby 24

5.2 Keys on TV 24

5.3 Sleep timer 24

5.4 Switch off timer 24

6 Remote control 25

6.1 Key overview 25

6.2 IR sensor 26

6.3 Batteries 26

6.4 Cleaning 26

7 Channels 27

7.1 Install Channels 27

7.2 Switch channels 27

7.3 Channel lists 27

7.4 Watching channels 28

7.5 Text / Teletext 30

7.6 Interactive TV 31

8 TV Guide 33

8.1 What you need 33

8.2 TV guide data 33

8.3 Using the TV guide 33

9 Recording and Pause TV 35

9.1 Recording 35

9.2 Pause TV 36

10 Home menu 37

10.1 About the Home menu 37

10.2 Open the Home menu 37

11 Utilities 38 12 Netflix 39 13 Sources 40

13.1 Switch to a device 40

13.2 Options for a TV Input 40

13.3 Scan connections 40

13.4 Game or computer 40

14 Internet 41

14.1 Start Internet 41

15 Videos, photos and music 42

15.1 From a USB connection 42

15.2 From a computer 42

15.3 Menu bar and sorting 42

15.4 Play your videos 42

15.5 View your photos 42

15.6 Play your music 43

16 Smartphones and tablets 44

16.1 Philips TV Remote App 44

16.2 Miracast 44

16.3 MHL 45

16.4 Smart TV 45

17 Multi room 49

17.1 About Multi room 49

17.2 What you need 49

17.3 Using Multi room 49

18 Settings 51

18.1 Quick settings 51

18.2 Picture 51

18.3 Sound 55

18.4 Eco settings 57

18.5 General settings 58

18.6 Clock and language 60

18.7 Universal access 63

19 Networks 65 20 Channel installation 66

20.1 Antenna/cable installation 66

20.2 Channel list copy 68

21 Software 70

21.1 Update software 70

21.2 Software version 70

21.3 Local updates 70

21.4 Look for OAD updates 70

21.5 Open source software 71

21.6 Open source license 71

22 Specifications 82

22.1 Environmental 82

22.2 Power 82

22.3 Reception 83

22.4 Display type 83

22.5 Display input resolution 83

22.6 Dimensions and Weights 83

22.7 Connectivity 83

22.8 Sound 83

22.9 Multimedia 83

23 Help and support 85

23.1 Register your TV 85

23.2 Using help 85

23.3 Troubleshooting 85

23.4 Online help 87

23.5 Consumer care / Repair 87

24 Safety and care 88

24.1 Safety 88

24.2 Screen care 89

25 Terms of use 90 26 Copyrights 91

26.1 MHL 91

26.2 Ultra HD 91

26.3 HDMI 91

26.4 Dolby Digital Plus 91

26.5 DTS 2.0 + Digital Out ™ 91

26.6 DTVi 91

26.7 Java 91

26.8 Microsoft 91

26.9 Wi-Fi Alliance 92

26.10 Kensington 92

26.11 MHEG software 92

26.12 Other trademarks 92

Index 93

TV tour

movie immediately*. In Help, press  Keywords and look up Rental

videos for more information.

1.1

Smart TV

Connect this Philips Smart LED TV to the Internet and discover a new world of television. You can make a wired connection to your router or you can link up wirelessly with Wi-Fi.

With the TV connected to your home network, a smartphone can show a photo on TV, you can play videos stored on your computer or control the TV with your tablet.

With your TV connected to the Internet, you can watch a rental video from an online video store, read the online TV guide or record your favourite TV show on a USB Hard Drive.

The Smart TV Apps add to the fun with all sorts of entertainment and convenient services.

In Help, press  Keywords and look up Smart TV for more information.

* Depending on the video streaming service of the selected video store.

1.4

Ultra HD TV

This TV has an Ultra HD display. Its resolution is four times as much as normal HD displays. Ultra HD means 8 million pixels for the most refined and lifelike picture on TV.

On top, the new Ultra Pixel HD Engine continuously converts any incoming TV signal into Ultra HD resolution. So you can enjoy this stunning picture quality the moment you switch on the TV. Or you can watch native Ultra HD videos through an HDMI connection. Ultra HD offers TV viewing that is crisp and sharp even on a big screen.

1.2

App gallery

Open the App gallery in Smart TV to browse the Apps, the collection of tailored websites for TV.

Find the App for YouTube videos, a national newspaper, an online photo album, Twitter, etc.

There are Apps to rent a video from an online video store and Apps for watching programmes you missed.

If the App gallery does not hold what you are looking for, try the World Wide Web and surf the Internet on TV.

In Help, press  Keywords and look up App gallery for more information.

1.3

Rental videos

To watch a rental video, you don't need to leave your home. Simply rent the latest movie from your regional online video store.

Start Smart TV and add the video store App to the Smart TV start page.

Open the video store App, create your personal account, select the movie and press play. No fuss with downloading, you can watch the

1.5

Pause TV and recordings

If you connect a USB Hard Drive, you can pause and record a broadcast from a digital TV channel.

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can watch it again later. With a USB Hard Drive connected, you can also record digital broadcasts. You can record while you are watching a programme or schedule a recording of an upcoming programme.

For more information, in Help, press the colour key  Keywords and look up Pause TV or Recording.

1.6

Smartphones and tablets

The new Philips TV Remote App is your new TV buddy.

With the TV Remote App on your smartphone or tablet, you master your media around you. Send photos, music or videos to your big TV screen or

watch any of your TV channels live on your tablet or phone. Open the TV Guide and schedule a recording for tomorrow. Your TV at home will do the job. With the TV Remote App you are in control. You might consider to simply lower the TV volume.

Download the Philips TV Remote App from your favourite app store today.

It's free. The Philips TV Remote App is available for iOS and

Android.

Setting up

2.1

Read safety

Read the safety instructions first before you use the TV.

should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

2.3

To read the instructions, in Help, press the colour key  Keywords and look up Safety instructions.

2.2

TV stand and wall mounting

TV stand

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com.

Use the product type number of the TV to look for the Quick Start Guide to download.

Wall mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

Tips on placement

• Position the TV where light does not shine directly on the screen.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

2.4

Power cable

• Insert the power cable into the POWER connector on the back of the TV.

• Make sure the power cable is securely inserted in the connector.

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

• 43PUx6101

VESA MIS-F 200x200, M6

• 49PUx6101

VESA MIS-F 400x200, M6

• 55PUx6101

VESA MIS-F 400x200, M6 Preparation

First remove the 4 plastic screw caps out of the threaded bushes on the back of the TV. Make sure that the metal screws, to mount the TV to the VESA-compliant bracket, go about 10mm deep inside the threaded bushes of the TV.

Caution

Wall mounting the TV requires special skills and

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

For more information, in Help, press the colour key  Keywords and look up Switching on for more information.

2.5

Antenna cable

Insert the antenna plug firmly into the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

Network

3.1

Network and Internet

select Done to make the connection immediately. If your router supports WPS or WPS PIN, you select WPS, WPS PIN or Standard. Select your choice and press OK. 7 - A message will be shown when the connection is successful.

Home network

To enjoy the full capabilities of your Philips TV, your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed Internet connection. You can connect your TV wirelessly or wired to your network router.

Connect to network

Wireless connection

What you need

To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

WPS

If your router has WPS, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Press , select Network and press  (right) to enter the menu.

2 - Select Connect to network and press OK. 3 - Select WPS then press OK. 4 - Go to the router, press the WPS button and return

to the TV within 2 minutes.

5 - Select Connect to make the connection. 6 - A message will be shown when the connection is

successful.

WPS with PIN code

If your router has WPS with a PIN code, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

Make the connection

Wireless

To make a wireless connection… 1 - Make sure that the router of your wireless network

is switched on. 2 - Press , select Network and press  (right) to enter the menu.

3 - Select Connect to network and press OK. 4 - Select Wireless and press OK. 5 - In the list of found networks, select on your

wireless network. If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select Manual entry to enter the network name yourself. 6 - Depending on the type of router, enter your encryption key - WEP, WPA or WPA2. If you entered the encryption key for this network before, you can

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Connect to network and press OK. 3 - Select WPS with PIN code and press OK. 4 - Write down the 8-digit PIN code shown on

screen and enter it in the router software on your PC. Consult the router manual on where to enter the PIN code in the router software.

5 - Select Connect to make the connection. 6 - A message will be shown when the connection is

successful.

Problems Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

DHCP

• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.

Wired connection

What you need

To connect the TV to the Internet, you need a network router with a connection to the Internet.

Use a high-speed (broadband) connection to the Internet.

Network settings

View network settings

You can view all current network settings here. The IP and MAC address, signal strength, speed, encryption method, etc.

To view the current network settings…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select View network settings and press OK. 3 - Press  (left) repeatedly if necessary, to close

the menu.

Network configuration

If you are an advanced user and want to install your network with Static IP addressing, set the TV to Static IP.

To set the TV to Static IP…

Make the connection

To make a wired connection… 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is switched on. 3 - Press , select Network and press  (right) to

enter the menu.

4 - Select Connect to network and press OK. 5 - Select Wired and press OK. The TV constantly

searches for the network connection. 6 - A message will be shown when the connection is successful.

If the connection fails, you can check the DHCP setting of the router. DHCP should be switched on.

**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Network configuration and press OK. 3 - Select Static IP and press OK to enable Static

IP configuration.

4 - Select Static IP configuration and configure the connection.

5 - You can set the number for IP address, Netmask, Gateway, DNS 1, or DNS 2.

6 - Press  (left) repeatedly if necessary, to close the menu.

Switch On with Wi-Fi (WoWLAN)

You can switch this TV on from your smartphone or tablet if the TV is in Standby. The setting Switch On with Wi-Fi (WoWLAN) must be switched on.

To switch on WoWLAN…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Switch on with Wi-Fi (WoWLAN) and press OK.

3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Digital Media Renderer - DMR

If your media files do not play on your TV, make sure that the Digitial Media Renderer is switched on. As a factory setting, DMR is switched on.

To switch on DMR…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Digital Media Renderer - DMR and press OK.

3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Switch on Wi-Fi connection

You can switch on or off Wi-Fi connection on your TV.

To switch on Wi-Fi…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Wi-Fi On/Off and press OK. 3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Switch on Wi-Fi Miracast

Switch on Wi-Fi Miracast to share the screen of your smartphone, tablet or computer on the TV.

To switch on Miracast…

device. To switch on Wi-Fi Smart Screen…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Wi-Fi smart screen and press OK. 3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

TV network name

If you have more than one TV in your home network, you can give the TV a unique name.

To change the TV name…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select TV network name and press OK. 3 - Enter the name with the on-screen keyboard. 4 - Select Done to confirm the change. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Netflix settings

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Wi-Fi Miracast and press OK. 3 - Select On and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu. For more information, in Help, press the colour

key  Keywords and look up Miracast™, switch

on.

Reset Wi-Fi Miracast connections

Clear the list of connected and blocked devices that are used with Miracast.

To clear Miracast connections…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Reset Wi-Fi Miracast connections and press OK.

3 - Select Clear all and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

With Netflix settings, you can view ESN number or deactive Netflix device.

To enter Netflix settings… 1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Netflix settings and press OK. 3 - Press  (left) repeatedly if necessary, to close

the menu.

Clear Internet memory

With Clear Internet Memory, you can clear all Internet files and logins stored on your TV, such as passwords, cookies, and history.

To clear the Internet memory…

1 - Press , select Network and press  (right) to

enter the menu.

2 - Select Clear Internet memory and press OK. 3 - Select OK to confirm. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Wi-Fi smart screen

To watch digital TV channels on your smartphone or tablet with the Philips TV Remote App, you must switch on Wi-Fi Smart Screen. Some scrambled channels might not be available on your mobile

File sharing

The TV can connect to other devices in your wireless network, like your computer or smartphone. You can use a computer with Microsoft Windows or Apple OS X.

On this TV, you can open photos, music and videos stored on your computer.

Connect devices

4.1

About connections

Connectivity guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to www.connectivityguide.philips.com

Antenna port

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

Copy protection

HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

Only HDMI 1 on the TV have HDMI ARC (Audio Return Channel).

If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to HDMI 1 connection on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

HDMI MHL

With HDMI MHL, you can send what you see on your Android smartphone or tablet to a TV screen.

The HDMI 4 connection on this TV incorporates MHL 2.0 (Mobile High-Definition Link).

HDMI ports

HDMI quality

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for TV signal.

For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

This wired connection offers great stability and bandwidth, low latency, no wireless interference and good quality sound reproduction. On top of that, the MHL connection will charge the battery of your smartphone or tablet. Although connected, your mobile device will not be charging when the TV is on standby.

Inform yourself about what passive MHL cable is suited for your mobile device. In particular, with the HDMI connector for the TV on one side, the type of connector you need to connect to your smartphone or tablet.

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

HDMI Ultra HD

This TV can display Ultra HD signals. Some devices connected with HDMI - do not recognise a TV with Ultra HD and might not work correctly or show distorted picture or sound. To avoid the malfunctioning of such a device, you can set the signal quality to a level the device can handle. If the device is not using Ultra HD signals, you can switch off Ultra HD for this HDMI connection.

that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

The setting UHD 4:4:4/4:2:2 allows UHD YCbCr 4:4:4 / 4:2:2 signals. The setting UHD 4:2:0 allows UHD YCbCr 4:2:0 signals.

To set the signal quality… 1 - Press , select General settings and

press  (right) to enter the menu. 2 - Select HDMI Ultra HD > HDMI 3 & 4 and press OK.

3 - Select UHD 4:4:4/4:2:2, UHD 4:2:0 or UHD Off and press OK.

4 - Press  (left) repeatedly if necessary, to close the menu.

HDMI CEC - EasyLink

EasyLink

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

Example HDMI CEC branding names are property of their respective owners.

Operate devices

To operate a device connected to HDMI and set up with EasyLink, select the device or its activity in the list of TV connections. Press  SOURCES , select a device connected to an HDMI connection and press OK.

Once the device is selected, the TV remote control can control the device. However the keys  Home and  OPTIONS and some other TV keys, are not forwarded to the device.

If the key you need is not on the TV remote control, you can select the key in the Options menu. Press  OPTIONS and select Controls in the menu bar. On the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.

Only devices that support EasyLink Remote Control function will respond to the TV remote control.

EasyLink HDMI CEC

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device.

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

EasyLink setup

The TV comes with EasyLink switched on. Make sure

EasyLink On or Off

You can switch EasyLink on or off. The TV comes with the EasyLink settings switched on.

To switch off EasyLink completely…

1 - Press , select General settings and

press  (right) to enter the menu.

2 - Select EasyLink, press  (right) and select EasyLink one step further.

3 - Select Off. 4 - Press  (left) repeatedly if necessary, to close

the menu.

EasyLink remote control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink Remote Control separately.

To switch EasyLink Remote Control on or off…

1 - Press , select General settings and

press  (right) to enter the menu.

2 - Select EasyLink > EasyLink Remote Control and press OK.

3 - Select On or Off and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Copy protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

Pixel Plus Link

Some devices, a DVD or Blu-ray Disc player, might have their own picture quality processing. To avoid bad picture quality caused by interference with the TV processing, the picture processing of these devices should be disabled. The TV comes with Pixel Plus Link switched on and disables the picture quality processing of recent Philips devices connected to the TV.

To switch Pixel Plus Link on or off… 1 - Press , select General settings and

press  (right) to enter the menu. 2 - Select EasyLink > Pixel Plus Link and press OK.

3 - Select On or Off and press OK. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Auto switch off devices

You can set the TV to switch off the connecting HDMICEC compliant devices if they are not the active source. The TV switches the connected device to standby after 10 minutes of inactivity.

DVI to HDMI

If you still own a device that only has a DVI connection, you can connect the device to any of the HDMI connection with a DVI to HDMI adapter.

Y Pb Pr - Component

Y Pb Pr - Component Video is a high quality connection.

The YPbPr connection can be used for High Definition (HD) TV signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.

Match the YPbPr (green, blue, red) connector colours with the cable plugs when you connect. Use an Audio L/R cinch cable if your device also has sound.

CVBS - Audio L R

CVBS - Composite Video is a high quality connection. Next to the CVBS signal adds the Audio Left and Right signals for sound.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.

Audio Out - Optical

Audio Out - Optical is a high quality sound connection.

This optical connection can carry 5.1 audio channels. If your device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In - Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System. For more information, in Help, press the colour key  Keywords and look up Audio out settings.

If the sound does not match the video on screen, you can adjust the audio to video synchronisation. For more information, in Help, press the colour key  Keywords and look up Audio to video sync.

Scart

SCART is a good quality connection. The SCART connection can be used for CVBS and

RGB video signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals. The SCART connection also supports NTSC playback.

4.2

CAM with smart card - CI+

CI+

This TV is ready for the CI+ Conditional Access. With CI+ you can watch premium HD programmes,

like movies and sports, offered by digital TV operators in your region. These programmes are scrambled by the TV operator and descrambled with a prepaid CI+ module. Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes. These programmes have a high level of copy protection.

Contact a digital TV operator for more information on terms & conditions.

Smart card

Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes.

Insert the smart card into the CAM module. See the instruction you received from the operator.

To insert the CAM in the TV… 1 - Look on the CAM for the correct method of

insertion. Incorrect insertion can damage the CAM and TV. 2 - While looking at the back of the TV, with the front of the CAM facing towards you, gently insert the CAM into the slot COMMON INTERFACE. 3 - Push the CAM in as far as it will go. Leave it in the slot permanently.

When you switch on the TV, it may take a few minutes before the CAM is activated. If a CAM is inserted and subscription fees are paid (subscription methods can differ), you can watch the scrambled channels supported by the CAM smart card.

4.3

Receiver - Set-Top Box

Cable box

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV. Alternatively, you can use a SCART cable if the Settop box has no HDMI connection.

The CAM and smart card are exclusively for your TV. If you remove the CAM, you will no longer be able to watch the scrambled channels supported by the CAM.

Passwords and PIN codes

For some CAMs, you must enter a PIN code to watch its channels. When you set the PIN code for the CAM, we recommend you to use the same code you are using to unlock the TV.

To set the PIN code for the CAM…

1 - Press  SOURCES . 2 - Select the channel type you are using the CAM

for. 3 - Press  OPTIONS and select Common Interface. 4 - Select the TV operator of the CAM. The following screens come from the TV operator. Follow the onscreen instruction to look up the PIN code setting.

Switch Off Timer

Switch off this automatic timer, if you only use the remote control of the Set-top box. Switch this timer off to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

For more information, in Help, press the colour key  Keywords and look up Switch off timer for more information.

Satellite tuner

Connect the dish antenna cable to the Satellite receiver.

Next to the antenna connection, add an HDMI cable to connect the device to the TV. Alternatively, you can use a SCART cable if the device has no HDMI connection.

Switch Off Timer

For more information, in Help, press the colour key  Keywords and look up Switch off timer for more information.

4.4

Home Theatre System - HTS

Connect with HDMI

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to send the sound of the TV picture to the Home Theatre System.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

HDMI ARC

If your Home Theatre System has an HDMI ARC connection, you can use HDMI 1 on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. HDMI 1 on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

For more information, in Help, press the colour key  Keywords and look up Audio to video sync.

Audio out settings

Audio out delay

With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.

Automatic audio to video sync

With recent Philips Home Theatre Systems, the audio to video sync is done automatically and always correct.

Audio sync delay

For some Home Theatre Systems you might need to adjust the audio sync delay to synchronise the audio to the video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio Out Delay on the TV.

To switch off Audio Out Delay…

1 - Press , select Sound and press  (right) to

enter the menu.

2 - Select Advanced > Audio out delay and press OK.

3 - Select Off. 4 - Press  (left) repeatedly if necessary, to close

the menu.

Audio out offset

If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates for the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms.

The Audio out delay setting should be switched on. To synchronise the sound on the TV…

1 - Press , select Sound and press  (right) to

enter the menu.

2 - Select Advanced > Audio out offset and press OK. 3 - Use the slider bar to set the sound offset and press OK. 4 - Press  (left) repeatedly if necessary, to close the menu.

4 - If the volume difference is large, select More. If the volume difference is small, select Less. 5 - Press  (left) repeatedly if necessary, to close the menu.

Audio Out Levelling affects both the Audio Out Optical and HDMI ARC sound signals.

Problems with HTS sound

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the Audio out format of the TV to Stereo (uncompressed).

Press  for Sound > Advanced > Audio out

format. No sound

Audio out format

If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio Out Format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.

To set Audio out format… 1 - Press , select Sound and press  (right) to

enter the menu. 2 - Select Advanced > Audio out format and press OK. 3 - Select Multichannel or Stereo (uncompressed), then press OK. 4 - Press  (left) repeatedly if necessary, to close the menu.

Audio out levelling

If you cannot hear the sound from the TV on your Home Theatre System, check if you connected the HDMI cable to an HDMI1 ARC connection on the Home Theatre System.

4.5

Smartphones and tablets

To connect a smartphone or tablet to the TV, you can use a wireless or wired connection.

Wireless

For a wireless connection, on your smartphone or tablet download the Philips TV Remote App from your favourite app store.

Wired

For a wired connection, use the HDMI 4 MHL connection on the back of the TV. In Help, press the colour key  Keywords and look up HDMI MHL for more information.

Use the Audio Out Levelling setting to level the volume (loudness) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume…

1 - Press , select Sound and press  (right) to

enter the menu.

2 - Select Advanced > Audio out levelling and press OK. 3 - Select More, Medium, or Less, then press OK.

4.6

Blu-ray disc player

Use a High speed HDMI cable to connect the Bluray Disc player to the TV.

To adjust the volume…

1 - Press , select Sound > Headphone volume and press OK.

2 - Press the arrows  (up) or  (down) to adjust the value. 3 - Press  (left) repeatedly if necessary, to close the menu.

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.

4.7

DVD player

Use an HDMI cable to connect the DVD player to the TV. Alternatively, you can use a SCART cable, if the device has no HDMI connection.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

4.9

Game console

HDMI

For best quality, connect the game console with a High speed HDMI cable to the TV.

Y Pb Pr - Component

Connect the game console with a component video cable (Y Pb Pr) and an audio L/R cable to the TV.

For more information on EasyLink, in Help, press the colour key  Keywords and look up EasyLink HDMI CEC.

4.8

Headphones

You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

CVBS - Audio L R

CVBS - Composite Video is a high quality connection. Next to the CVBS signal adds the Audio Left and Right signals for sound.

• Y shares the same jack with CVBS.

• Component and Composite share audio jacks.

Scart

Installation

Connect the game console to the TV with a composite cable (CVBS) and an audio L/R cable to the TV.

If your game console only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.

Best setting

Before you start playing a game from a connected game console, we advice you to set the TV in the ideal setting Game.

When you finish playing a game and start watching TV again, remember to switch the Game or Computer setting back to Off.

To set the TV to the ideal setting…

1 - Press , select Picture and press  (right) to

enter the menu.

2 - Select Advanced > Game or Computer, and select the device type you want to use. To switch back to TV, select Off. 3 - Press  (left) repeatedly if necessary, to close the menu.

4.10

USB hard drive

What you need

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting.

Follow the instructions on screen. When the USB Hard Drive is formatted, leave it

connected permanently.

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

To Pause

To pause a broadcast, you need a USB compatible Hard Drive with a minimum of 4GB disk space.

To Record

To pause and record a broadcast, you need a minimum of 250GB disk space. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive.

For more information on how to install a USB Hard Drive, in Help, press the colour key  Keywords and look up USB hard drive,

installation.

Formatting

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive. If you want to record broadcasts with TV Guide data from the Internet, you must setup the Internet connection first before you install the USB Hard Drive.

Warning

To format a USB Hard Drive…

1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting. Follow the instructions on screen. 4 - The TV will ask if you want to use the USB Hard Drive to store apps, agree to the question if you do. 5 - When the USB Hard Drive is formatted, leave it connected permanently.

Special keys

Keys for entering text

• Enter key = OK

• Backspace = delete character before cursor

• Arrow keys = navigate within a text field

• To switch between keyboard layouts, if a secondary layout is set, press the Ctrl + Spacebar keys simultaneously.

Keys for apps and Internet pages

• Tab and Shift + Tab = Next and Previous

• Home = scroll to the top of the page

• End = scroll to the bottom of the page

• Page Up = jump one page up

• Page Down = jump one page down

• + = zoom in one step

• - = zoom out one step

• * = fit the web page to the screen width

4.12

4.11

USB keyboard

Connect

Connect a USB keyboard (USB-HID type) to enter text on your TV.

Use one of the USB connections to connect.

Configure

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.

To change the keyboard layout setting when a layout was selected…

1 - Press , select General settings and press  (right) to enter the menu. 2 - Select USB keyboard settings, and press OK to start the keyboard setup.

USB mouse

Connect USB mouse

You can connect a USB mouse (USB-HID type) to navigate pages on the Internet.

On an Internet page, you can select and click on links more easily.

Connect the mouse

Switch the TV on and connect the USB mouse to one of the USB connections on the TV. You can also connect the USB mouse to a connected USB keyboard.

Mouse clicks

• Left click = OK You can use the scroll wheel to scroll pages up and

down.

Mouse speed

To change the keyboard layout setting when a layout was selected…

1 - Press , select General settings and press  (right) to enter the menu. 2 - Select Mouse settings, and press OK to start

the keyboard setup.

4.13

USB flash drive

4.15

Camcorder

HDMI

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press  SOURCES and select USB.

To stop watching the USB flash drive content, press  EXIT or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

Ultra HD on USB

You can view photos in Ultra HD resolution from a connected USB device or flash drive. The TV will downscale the resolution to Ultra HD if the resolution of the photo is higher.

For best quality, use an HDMI cable to connect the camcorder to the TV.

Audio Video LR / Scart

You can use an HDMI, YPbPr or SCART connection to connect your camcorder. If your camcorder only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.

For more information on watching or playing content from a USB flash drive, in Help, press the colour key  Keywords and look up Photos, videos and music.

4.14

Photo camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the USB connections on the TV to connect. Switch on the camera after you made the connection.

If the contents list does not appear automatically, press  SOURCES , and select USB. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

For more information on viewing photos, in Help, press the colour key  Keywords and look up Photos, videos and music.

4.16

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

Ideal setting

If you connect a computer, we advice you to give the connection, on which the computer is connected, the correct device type name in the Source menu. If you then switch to Computer in the Source menu, the TV is set to the ideal Computer setting automatically.

You can manually switch the ideal setting to Off for watching TV or Game for playing a game from a connected game console (remember to switch back to Off when you stop playing a game).

If you switch to a source and change the Game or Computer setting, it will be stored for this selected source.

To set the TV to the ideal setting… 1 - Press , select Picture and press  (right) to

enter the menu. 2 - Select Advanced > Game or computer, and press OK. 3 - Select Game (for gaming) or select Computer (for watching a movie). 4 - Press  (left) repeatedly if necessary, to close the menu.

Remember to set Game or computer setting to Off when you stop playing the game.

Switching On and Off

5.1

On or standby

To switch the TV on standby, select  and press the joystick key.

Before you switch on the TV, make sure you plugged in the mains power in the POWER connector on the back of the TV.

With the TV in Standby, press  on the remote control to switch the TV on. You can also press the small joystick key on the back of the TV to switch the TV on in case you can't find the remote control or its batteries are empty.

Switch to standby

To switch the TV to standby, press  on the remote control. You can also press the small joystick key on the back of the TV.

In standby mode, the TV is still connected to the mains power but consumes very little energy.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

5.2

5.3

Sleep timer

With the Sleep Timer, you can set the TV to switch to Standby automatically after a preset time.

To set the Sleep Timer…

1 - Press , select General settings > Sleep timer and press OK.

2 - With the slider bar you can set the time to up to 180 minutes in increments of 5 minutes. If set to 0 minutes, the Sleep Timer is switched off. You can always switch off your TV earlier or reset the time during the countdown. 3 - Press  BACK to close the menu.

5.4

Switch off timer

If the TV receives a TV signal but you don't press a key on the remote control during a 4 hour period, the TV switches off automatically to save energy. Also, if the TV does not receive a TV signal nor a remote control command for 10 minutes, the TV switches off automatically.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.

Keys on TV

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu… 1 - With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu. 2 - Press left or right to select  Volume, Channel or  Sources. Select  Demo, to start a demo movie. 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. Press the joystick key to start the demo movie. 4 - The menu will disappear automatically.



To deactivate the Switch Off Timer … 1 - Press , select Eco settings and

press  (right) to enter the menu.

2 - Select Switch off timer and press OK. 3 - Press the arrows  (up) or  (down) to adjust

the value. The value 0 deactivates the automatic switch off. 4 - Press  (left) repeatedly if necessary, to close the menu.

For more information on environmentally friendly TV settings, in Help, press the colour key  Keywords and look up Eco settings.

Remote control

6.1

Key overview

Top

1 -  Home

To open the Home menu. 2 -  SMART TV

To open the Smart TV start page.

1 -  Standby / On To switch the TV on or back to Standby.

2 - Playback and Record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Fast forward , to go fast forward

• Record , to start recording 3 -

This function is only available in Ambilight series. 4 -  TV GUIDE

To open or close the TV Guide. 5 -  Search

To open the searches page. 6 -  Settings

To open the Settings menu. 7 -  SOURCES

To open the Sources menu.



Ambilight

3 -

   

Direct selection of options. Blue key , opens Help. 4 -  INFO

To open or close programme info. 5 -  BACK

To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous App/Internet page.

6 -  - EXIT

To switch back to watch TV. To stop an interactive TV application.

7 To open or close the Options menu.

8 - OK key To confirm a selection or setting. To open the channel list while watching TV.

9 - Arrow / navigation keys To navigate up, down, left or right.

10 -  MULTIVIEW To open an extra small screen.

OPTIONS



Colour keys

8 -  LIST To open or close the channel list.

Middle

Bottom

6.3

Batteries

If the TV does not react on a key press on the remote control, the batteries might be empty.

To replace the batteries, open the battery compartment on the back of the remote control.

1 - Slide the battery door in the direction shown by the arrow. 2 - Replace the old batteries with 2 type AAA-R03-1.5V batteries. Make sure the + and the - ends of the batteries line up correctly. 3 - Reposition the battery door and slide it back until it clicks.

1 -



To open the Netflix App directly. With the TV switched on or from standby.

2 To adjust the volume level.

3 - Number keys To select a channel directly.

4 - SUBTITLE To switch subtitles on, off or to show automatically.

5 -  Channel To switch to the next or previous channel in the channel list. To open the next or previous page in Text/Teletext. To start the next or previous chapter on a disc.

6 To mute the sound or to restore it.

7 - TEXT To open or close Text/Teletext.

6.2

Volume



Mute



Remove the batteries if you are not using the remote control for a long time. Safely dispose of your old batteries according to the end of use directions.

For more information, in Help, press the colour key  Keywords and look up End of use.

6.4

Cleaning

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

IR sensor

The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

Warning



Do not put any objects in front of IR sensor of the TV, it may block the IR signal.

Channels

7.1

Install Channels

For more information, in Help, press the colour key  Keywords and look up Channel, Antenna installation or Channel, Cable installation.

7.2

Switch channels

• To watch TV channels, press . The TV tunes to the TV channel you last watched.

• Alternatively, press  Home to open the Home menu and select Channels and press OK.

• To switch channels, press  + or  -. If you know the channel number, type in the number with the number keys. Press OK after you entered the number to switch channels.

• To switch back to the previously tuned channel, press  BACK .

To switch to a channel from a channel list

While watching a TV channel, press  LIST to open the channel lists.

The channel list can have several pages with channels. To view the next or previous page, press  + or  -.

To close the channel lists without switching channels, press  LIST again.

Radio channels

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel.

7.3

4 - The selected channel is marked with a . 5 - To finish, press  BACK . The channels are

added to the Favourites list. To remove a channel from the favourites list, select

the channel with , then press  again to unmark as favourite.

Reorder

You can reorder — reposition — channels in the Favourite channel list.

1 - In the channel list Favourites, highlight the channel you want to reposition.

2 - Press . 3 - Select the channel to reorder and press OK. 4 - Press the Navigation buttons to move the

highlighted channel to another location and press OK. 5 - Once complete, press  EXIT to exit from the Favourite channel list.

You can highlight another channel and do the same.

Channel list views

In the channel lists, you can find all installed TV and radio channels.

Next to the channel list All, which holds all installed channels, you can set up a list of Favourites, view the installed Radio stations separately or discover the newly added channels in New.

Channel logos

In some countries, the TV can show the channel logos. If you do not want these logos to appear, you can switch them off. To switch off Channel logos . . .

1 - Press , select General settings > Channel logos and press OK.

2 - Select Off and press OK. 3 - Press  BACK , repeatedly if necessary, to close

the menu.

Channel lists

Favourite channels

You can create a favourite channel list that only holds the channels you want to watch. With the Favourite channel list selected, you will only see your favourite channels when you switch through channels.

Create your favourite channel list

1 - While watching a TV channel, press open the channel list.

2 - Select All to view all channels. 3 - Select the channel, and press  to mark as

favourite.



LIST to

Rename channels

You can rename channels in the channel list. 1 - Select the channel you want to rename in one of

the channel lists.

2 - Select the channel to rename. 3 - Press .

You can enter text with the remote control keyboard or open the on-screen keyboard.

With the on-screen keyboard

• To open the on-screen keyboard, place the cursor in the name text field and press OK.

• To delete the character in front of the cursor, press  Backspace .

• To enter a character, select the character with the arrow keys and press OK.

• To select uppercase characters, press .

• To select numbers or special characters, press .

• When you are ready, press  BACK to close the on-screen keyboard.

• To finish renaming, select Done and press OK.

6 - Press  (left) to go back one step or press  BACK to close the menu.

If you lock or unlock channels in a channel list, you only have to enter the PIN code just once until you close the channel list.

For more information, in Help, press the colour key  Keywords and look up Child lock for more information.

7.4

Watching channels

Tune to a channel

To start watching TV channels, press . The TV tunes to the channel you last watched.

Switch Channels

To switch channels, press   or  -. If you know the channel number, type in the number with the number keys. Press OK after you entered the number to switch immediately.

Previous channel

To switch back to the previously tuned channel, press  BACK.

Lock a channel

Lock and unlock a channel

To prevent children from watching a channel, you can lock a channel. To watch a locked channel, you must enter the 4 digit Child Lock PIN code first. You cannot lock programmes from connected devices.

To lock a channel…

1 - Press . 2 - Press OK to open the channel list. If necessary

change the channel list.

3 - Select the channel you want to lock. 4 - Press  OPTIONS and select Lock

channel and press OK.

5 - Enter your 4 digit PIN code if the TV asks for it. A locked channel is marked with a  (lock). 6 - Press  (left) to go back one step or press  BACK to close the menu.

To unlock a channel…

1 - Press . 2 - Press OK to open the channel list. If necessary

change the channel list.

3 - Select the channel you want to unlock. 4 - Press  OPTIONS and select Unlock

channel and press OK.

5 - Enter your 4 digit PIN code if the TV asks for it.

Parental rating

To prevent children from watching a programme not suitable for their age, you can set an age rating.

Digital channels can have their programmes age rated. When the age rating of a programme is equal to or higher than the age you have set as age rating for your child, the programme will be locked. To watch a locked programme, you must enter the Parental rating code first.

To set an age rating…

1 - Press , select Child Lock > Parental rating and press OK.

2 - Enter a 4-digit Child lock code. If you did not set a code yet, select Set code in Child lock. Enter a 4-digit Child lock code and confirm. Now you can set an age rating. 3 - Back in Parental rating, select the age and press OK. 4 - Press  (left) repeatedly if necessary, to close the menu.

To switch off the parental age rating, select None. However, in some countries you must set an age rating.

For some broadcasters/operators, the TV only locks programmes with a higher rating. The parental age rating is set for all channels.

Channel options

Open options

While watching a channel, you can set some options. Depending on the type of channel you are watching

(analogue or digital) or depending on the TV settings you made, some options are available.

To open the options menu…

1 - While watching a channel, press  OPTIONS. 2 - Press  OPTIONS again to close.

Universal access

In Help, press  Keywords and look up Universal access for more information.

Video selection

Digital TV channels can offer multi video signals (multifeed broadcast), different camera viewpoints or angles of the same event or different programmes on one TV channel. The TV shows a message if any such TV channels are available.

Subtitles

show the subtitles you selected. To set the primary and secondary subtitle language…

1 - Press , select General settings > Languages > Primary subtitles or Secondary subtitles.

2 - Select the language you need and press OK. 3 - Press  (left) to go back one step or

press  BACK to close the menu.

Select a subtitle language

If none of the preferred subtitle languages are available, you can select another subtitle language if available. If no subtitle languages are available, you cannot select this option.

Switch on

To switch on Subtitles, press SUBTITLE. You can switch subtitles On or Off. Alternatively

you can select Automatic.

Automatic

If language information is part of the digital broadcast and the broadcasted programme is not in your language (the language set on TV), the TV can show subtitles automatically in one of your preferred subtitle languages. One of these subtitle languages must also be part of the broadcast.

You can select your preferred subtitle languages in Subtitle language.

Subtitles from Text

If you tune to an analogue channel, you need to make the subtitles available for each channel manually.

1 - Switch to a channel and press TEXT to open Text.

2 - Enter the page number for subtitles, usually 888. 3 - Press TEXT again, to close Text.

If you select On in the Subtitle menu when watching this analogue channel, subtitles will be shown if available.

To know if a channel is analogue or digital, switch to the channel and press  INFO .

To select a subtitle language when none of your preferred languages are available…

1 - Press  OPTIONS. 2 - Select Subtitle language and select one of the

languages as subtitles temporarily.

Audio language

Preferred audio language

A digital broadcast can offer several audio languages (spoken languages) for a programme. You can set a preferred primary and secondary audio language. If audio in one of these languages is available, the TV will switch to the audio language.

To set the primary and secondary audio language…

1 - Press , select General settings and

select Languages > Primary audio or Secondary

audio.

2 - Select the language you need and press OK. 3 - Press  (left) to go back one step or

press  BACK to close the menu.

Select an audio language

If none of the preferred audio languages are available, you can select another audio language if available. If no audio languages are available, you cannot select this option.

To select an audio language when none of your preferred languages are available…

Subtitle Language

Preferred subtitle languages

A digital broadcast can offer several subtitle languages for a programme. You can set a preferred primary and secondary subtitle language. If subtitles in one of these languages are available, the TV will

1 - Press  OPTIONS. 2 - Select Audio language and select one of the

languages as audio temporarily.

+ 67 hidden pages

Philips 55PUH6101, 49PUH6101, 43PUH6101 User Manual

Contents
