Philips 55PUG7100/78, 49PUG7100/78 instructions for use

www.philips.com/welcome

7100 series

User Manual

49PUG7100

55PUG7100

1 TV Tour 4

1.1 Ultra HD TV 4

1.2 Philips Android TV 4

1.3 Using Apps 4

1.4 Playing Games 4

1.5 Pause TV and Recordings 4

1.6 Smartphones and Tablets 5

1.7 Social Networks 5

1.8 3D 5

1.9 Ambilight 5

1.10 Ambilight + Hue 5

1.11 Bluetooth Connection 5

2 Setting Up 7

2.1 Read Safety 7

2.2 TV Stand and Wall Mounting 7

2.3 Tips on Placement 7

2.4 Power Cable 7

2.5 Antenna Cable 7

3 Connect your Android TV 9

3.1 Network and Internet 9

3.2 Google Account 12

3.3 Philips App Gallery 12

4 Connect Devices 14

4.1 About Connections 14

4.2 Receiver - Set-Top Box 16

4.3 Home Theater System - HTS 16

4.4 Smartphones and Tablets 18

4.5 Blu-ray Disc Player 18

4.6 DVD Player 19

4.7 Bluetooth - Speakers and Gamepads 19

4.8 Headphones 20

4.9 Game Consoles 20

4.10 Gamepad 20

4.11 USB Hard Drive 21

4.12 USB Keyboard 22

4.13 USB Flash Drive 22

4.14 Photo Camera 23

4.15 Camcorder 23

4.16 Computer 23

5 Switching On and Off 25

5.1 On or Standby 25

5.2 Philips Logo Brightness 25

5.3 Keys on TV 25

5.4 Sleep Timer 25

5.5 Switch Off Timer 25

6 Remote Control 27

6.1 Key overview 27

6.2 Voice 28

6.3 Keyboard 28

6.4 Pairing the Remote Control 29

6.5 IR Sensor 29

6.6 Batteries 29

6.7 Cleaning 30

7 Channels 31

7.1 Channel Lists 31

7.2 Watching TV Channels 31

7.3 Favorite Channels 33

7.4 Closed captioning (CC) and language 34

7.5 Interactive TV 34

8 TV guide 36

8.1 What You Need 36

8.2 TV Guide Data 36

8.3 Using the TV Guide 36

9 Recording and Pause TV 38

9.1 Recording 38

9.2 Pause TV 39

10 Top Picks 41

10.1 About Top Picks 41

10.2 TV on Demand 41

11 Home Menu 42

11.1 About the Home Menu 42

11.2 Open the Home Menu 42

11.3 Search and Voice Search 42

11.4 Restricted Profile 42

12 TV Menu 43

12.1 About TV Menu 43

12.2 Open TV Menu 43

13 Netflix 44 14 Sources 45

14.1 Switch to a device 45

14.2 Options for TV Input 45

14.3 Device Name and Type 45

14.4 Game or Computer 45

14.5 Rescan Connections 46

15 Apps 47

15.1 About Apps 47

15.2 Google Play 47

15.3 App Gallery 48

15.4 Start or Stop an App 48

15.5 Lock Apps 48

15.6 Manage Apps 49

15.7 Storage 50

16 Games 51

16.1 What You Need 51

16.2 Gamepads 51

16.3 Play a Game 51

16.4 Split Screen Gaming 51

16.5 Ideal Game Settings 52

17 Internet 53

17.1 Start Internet 53

17.2 Internet Options 53

18 Videos, Photos and Music 54

18.1 From a USB Connection 54

18.2 From a Computer or NAS 54

18.3 From a Cloud Storage Service 54

18.4 Play your Videos 54

18.5 View your Photos 55

18.6 Play your Music 55

19 Smartphones and Tablets 57

19.1 Philips TV Remote App 57

19.2 Google Cast 57

19.3 Miracast 57

19.4 AirPlay 58

19.5 MHL 58

20 Ambilight 60

20.1 Ambilight Style 60

20.2 Ambilight Off 60

20.3 Ambilight Settings 60

21 3D 61

21.1 What You Need 61

21.2 3D Glasses 61

21.3 Watch 3D 61

21.4 Optimal 3D Viewing 61

21.5 Care of the 3D Glasses 61

21.6 Health Warning 62

22 Multi View 63

22.1 Text and TV 63

22.2 App Gallery and TV 63

22.3 HDMI and TV 63

23 Settings 64

23.1 Picture 64

23.2 Sound 68

23.3 Ambilight 71

23.4 Eco Settings 73

23.5 General Settings 73

23.6 Clock, Region and Language 76

23.7 Universal Access 76

24 Wireless and Networks 79

24.1 Network 79

24.2 Bluetooth 79

25 Android Settings 80

32.2 Ultra HD 127

32.3 HDMI 127

32.4 Dolby Digital Plus 127

32.5 DTS Premium Sound ™ 127

32.6 ANATEL 127

32.7 Microsoft 127

32.8 Wi-Fi Alliance 128

32.9 Kensington 128

32.10 Other Trademarks 128

Index 129

26 Channel Installation 81

26.1 Antenna/Cable Installation 81

26.2 Channel List Copy 81

26.3 Digital Channel Installation 82

27 Software 83

27.1 Update Software 83

27.2 Software Version 83

27.3 Open Source Software 83

27.4 Open Source License 83

27.5 Open Source 84

28 Specifications 117

28.1 Environmental 117

28.2 Power 117

28.3 Operating System 117

28.4 Reception 117

28.5 Display Type 117

28.6 Display Input Resolution 118

28.7 Dimensions and Weights 118

28.8 Connectivity 118

28.9 Multimedia 118

29 Help and Support 120

29.1 Register your TV 120

29.2 Using Help 120

29.3 Troubleshooting 120

29.4 Online Help 122

29.5 Support and Repair 122

30 Safety and Care 124

30.1 Safety 124

30.2 Screen Care 125

31 Terms of Use 126

31.1 Terms of Use - TV 126

31.2 Terms of Use - Smart TV 126

31.3 Terms of Use - Philips App Gallery 126

32 Copyrights 127

32.1 MHL 127

TV Tour

1.1

Ultra HD TV

This TV has an Ultra HD display. Its resolution is four times higher than normal HD displays. Ultra HD means 8 million pixels for the most refined and lifelike picture on a TV.

On top of this, the new Ultra Pixel HD Engine continuously converts any incoming TV signal into Ultra HD resolution. So you can enjoy this stunning picture quality the moment you switch on the TV. Or you can watch native Ultra HD videos through an HDMI connection. Ultra HD offers TV viewing that is crisp and sharp even on a big screen.

1.2

Philips Android TV

Streaming quality for other content might vary. Supported operating systems and devices: Android

2.3 and higher, iOS® 7 and higher, Windows® 7 and higher, Mac OS® 10.7 and higher and Chrome OS (version 38 or higher).

Android, Google Play and other brands are trademarks of Google Inc. The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License.

http://creativecommons.org/licenses/by/3.0/legalco de

1.3

Using Apps

To get you started, some practical Apps are preinstalled on your TV.

The Apps pages show the collection of Apps (Applications) on your TV. Like Apps on your smartphone or tablet, the Apps on your TV offer specific functions for an enriched TV experience. Apps like YouTube, Twitter, TV games or weather forecasts. Or start an Internet Browser App, like Google Chrome, to surf the Internet.

For more information, in Help, press the color key  Keywords and look up Apps.

This a Philips Android TV™ with UHD. Android TV offers thousands of movies, shows and

games from Google Play, YouTube and your favorite apps.* Voice search and personalized recommendations mean more time being entertained and less time hunting for something good. With Google Cast built in, you can easily cast movies, shows and photos from your Chromebook or Android device to your TV.**

With the Philips TV Remote App on your smartphone or tablet, you have your TV channels at your fingertips. Send a photo to the large TV screen or follow your favorite cooking show on your tablet in the kitchen. From now on, your TV is part of your mobile household.

Connect the TV to your home network and the Internet.

* The TV must be connected to the Internet. Subscriptions might be required for certain content providers.

** Casting optimized for selected services only.

1.4

Playing Games

This TV is your big screen for gaming. Big enough for two.

You can play a game from a connected Game Console, a game from an installed App or simply an online game on a website. You can set the TV to the ideal settings for gaming, to allow quick and responsive action. If you play a multi-player game with split screens, you can set the TV to show each screen as a full screen simultaneously. Each player can focus on playing their own game.

1.5

Pause TV and Recordings

If you connect a USB Hard Drive, you can pause and record a broadcast from a digital TV channel.

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can watch it again later. With a USB Hard Drive connected, you can also

record digital broadcasts. You can record while you are watching a program or schedule a recording of an upcoming program.

1.9

Ambilight

For more information, in Help, press the color key  Keywords and look up Pause TV or Recording.

1.6

Smartphones and Tablets

The new Philips TV Remote App is your new TV buddy.

With the TV Remote App on your smartphone or tablet, you master your media around you. Send photos, music or videos to your big TV screen or watch any of your TV channels live on your tablet or phone. Open the TV Guide and schedule a recording for tomorrow. Your TV at home will do the job. Switch on Ambilight+hue and set the coziest color effects in your living room. With the TV Remote App you are in control. You might consider simply lowering the TV volume.

Download the Philips TV Remote App from your favorite app store today.

It's free. The Philips TV Remote App is available for iOS and

Android.

1.7

Social Networks

No need to get up to check your friend's messages on your computer.

Ambilight is the most elegant and exclusive feature of your new Philips TV.

A subtle glow of colored light shines from behind the screen, expanding your visual experience. With Ambilight your eyes relax, but your mind is fully taken up by what you see.

With Ambilight+hue you can expand Ambilight even further, bringing in the wireless controlled bulbs of Philips Hue*. All of them set up to fill your room with colors that fit what's on TV.

You will miss Ambilight when you switch it off. * Separately available.

1.10

Ambilight + Hue

Your Ambilight TV

Philips' unique Ambilight technology goes beyond the ordinary. It not only makes your screen seem much wider, it also makes your viewing experience more immersive by projecting an extra-wide glow from the sides of your TV screen onto the surrounding wall. Color, vibrancy and excitement move beyond the screen and into your living room, bringing with them a more thrilling, intense and immersive viewing experience.

Ambilight + Hue Fill your space – and your life – with the wonder of

Ambilight. Ambilight + hue* allows you to extend the Ambilight experience throughout the room.

On this TV, you get the messages from your social networks on your TV screen. You can send a return message from your couch.

For more information, in Help, press the color key  Keywords and look up Apps.

1.8

Your new TV is a 3D TV. Enjoy the immersive experience of watching a movie

in 3D. Play a movie in 3D on your Blu-ray Player or rent a 3D movie from a Video Store from the Home menu, Video on Demand.

For more information, in Help, press the color key  Keywords and look up 3D.

With Ambilight+hue you can expand Ambilight even further, bringing in the wireless controlled bulbs of Philips Hue*. All of them set up to fill your room with colors that fit what's on TV.

Your Ambilight TV and hue bulbs ‘talk’ to each other via wireless connection, surrounding you in the emotion, power and color of Ambilight.

*Hue kit available separately.

1.11

Bluetooth Connection

Your TV comes with Bluetooth technology. You can connect extra wireless speakers or a wireless

headphone. Forget connecting cables, pairing your device with the TV is enough.

For more information, in Help, press the color key  Keywords and look

up Bluetooth or Wireless Speakers.

Setting Up

2.1

Read Safety

Read the safety instructions first before you use the TV.

should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

2.3

To read the instructions, in Help, press the color key  Keywords and look up Safety instructions.

2.2

TV Stand and Wall Mounting

TV Stand

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com.

Use the product type number of the TV to look for the Quick Start Guide to download.

Wall Mounting

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .

Tips on Placement

• Position the TV where light does not shine directly on the screen.

• Dim lighting conditions in the room for best Ambilight effect.

• Position the TV up to 6 inches away from the wall.

• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the center of the screen.

2.4

Power Cable

• Insert the power cable into the POWER connector on the back of the TV.

• Make sure the power cable is securely inserted in the connector.

• Make sure that the power plug, in the wall socket, is accessible at all times.

• When you unplug the power cable, always pull the plug, never pull the cable.

• 43PUG7100

VESA MIS-F 300x200, M6

• 49PUG7100, 55PUG7100

VESA MIS-F 300x300, M6

• 65PUG7100

VESA MIS-F 400x400, M6 Preparation

First remove the 4 plastic screw caps out of the threaded insert on the back of the TV. Make sure that the metal screws to mount the TV to the VESA-compliant bracket go about 0.4 inches deep inside the threaded insert.

Caution

Wall mounting the TV requires special skills and

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

For more information, in Help, press the color key  Keywords and look up Switching On for more information on switching the TV on or off.

2.5

Antenna Cable

Insert the antenna plug firmly into the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Connect your Android TV

encryption key - WEP, WPA or WPA2. If you entered the encryption key for this network before, you can select OK to connect immediately. 7 - A message will be shown when the connection is successful.

Wi-Fi On/Off

3.1

Network and Internet

Home Network

To enjoy the full capabilities of your Philips Android TV, your TV must be connected to the Internet.

Connect the TV to a home network with a high-speed Internet connection. You can connect your TV wirelessly or wired to your network router.

Connect to Network

Wireless Connection

What You Need

To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.

Use a high-speed (broadband) Internet connection.

Make sure Wi-Fi is switched on before you try to make the connection…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right). 3 - Select Wired or Wi-Fi > Wi-Fi On/Off and press OK.

4 - If it is switched off, select On and press OK.

WPS

If your router has WPS, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Connect to Network and press OK.

4 - Select WPS then press OK. 5 - Go to the router, press the WPS button and return

to the TV within 2 minutes.

6 - Select Connect to make the connection. 7 - A message will be shown when the connection is

successful.

Make the Connection

Wireless

To make a wireless connection…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and press

(right) to enter the menu.

3 - Select Wired or Wi-Fi > Connect to Network and press OK.

4 - Select Wireless and press OK. 5 - In the list of found networks, select your wireless

network. If your network is not in the list because the network name is hidden (you switched off the router's SSID broadcast), select Add New Network to enter the network name yourself. 6 - Depending on the type of router, enter your



WPS with PIN Code

If your router has WPS with a PIN code, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Connect to Network and press OK.

4 - Select WPS with PIN code and press OK. 5 - Write down the 8-digit PIN code shown on

screen and enter it in the router software on your PC. Consult the router manual on where to enter the PIN code in the router software.

6 - Select Connect to make the connection. 7 - A message will be shown when the connection is

successful.

Problems Wireless network not found or distorted

• Microwave ovens, DECT phones or other Wi-Fi

802.11b/g/n devices in your proximity might disturb the wireless network.

• Make sure that the firewalls in your network allow access to the TV's wireless connection.

• If the wireless network does not work properly in your home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.

• Use a high-speed (broadband) Internet connection for your router.

DHCP

• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.

7 - A message will be shown when the connection is successful.

If the connection fails, you can check the DHCP setting of the router. DHCP should be switched on.

**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.

Network settings

View Network Settings

You can view all current network settings here. The IP and MAC address, signal strength, speed, encryption method, etc.

To view the current network settings…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > View Network Settings and press OK.

4 - Press  (left) repeatedly if necessary, to close the menu.

Wired Connection

What You Need

To connect the TV to the Internet, you need a network router with a connection to the Internet. Use a high-speed (broadband) connection to the Internet.

Make the Connection

To make a wired connection… 1 - Connect the router to the TV with a network cable

(Ethernet cable**).

2 - Make sure that the router is turned on. 3 - Press , select All Settings and press OK. 4 - Select Wireless and Networks and

press  (right) to enter the menu.

5 - Select Wired or Wi-Fi > Connect to Network and press OK.

6 - Select Wired and press OK. The TV constantly searches for the network connection.

Network Configuration

If you are an advanced user and want to install your network with Static IP addressing, set the TV to Static IP.

To set the TV to Static IP…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Network Configuration and press OK. 4 - Select Static IP and press OK to enable Static IP Configuration.

5 - Select Static IP Configuration and configure the connection.

6 - You can set the number for the IP Address, Netmask, Gateway, DNS 1, or DNS 2.

7 - Press  (left) repeatedly if necessary, to close the menu.

Switch On with Wi-Fi (WoWLAN)

You can switch this TV on from your smartphone or tablet if the TV is on Standby. The setting Switch On with Wi-Fi (WoWLAN) must be switched on.

To switch on WoWLAN…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > Switch On with Wi-Fi

(WoWLAN) and press OK.

4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Clear Wi-Fi Miracast Connection

Clear the list of connected and blocked devices that are used with Miracast.

To clear Miracast connections…

Switch on Wi-Fi Connection

You can switch the Wi-Fi connection on your TV on or off.

To switch on Wi-Fi…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > Wi-Fi On/Off and press OK.

4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Digital Media Renderer - DMR

If your media files do not play on your TV, make sure that the Digital Media Renderer is turned on. As a factory setting, DMR is turned on.

To switch on DMR…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Digital Media Renderer

- DMR and press OK.

4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Switch on Wi-Fi Miracast

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Wi-Fi Miracast Connections and press OK.

4 - Select Clear All and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Wi-Fi Smart Screen

To watch digital TV channels on your smartphone or tablet with the Philips TV Remote App, you must switch on the Wi-Fi Smart Screen. Some scrambled channels might not be available on your mobile device.

To switch on the Wi-Fi Smart Screen…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Wi-Fi Smart Screen and press OK.

4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

TV Network Name

If you have more than one TV in your home network, you can give the TV a unique name.

To change the TV name…

Enable Wi-Fi Miracast to share the screen of your smartphone, tablet, or computer on the TV.

To switch on Miracast…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > Wi-Fi Miracast and press OK.

4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu. For more information, in Help, press the color

key  Keywords and look up Miracast™, switch on.

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > TV Network Name and press OK. 4 - Enter the name with the on-screen keyboard or the remote control keyboard (if available).

5 - Select  to confirm the change. 6 - Press  (left) repeatedly if necessary, to close

the menu.

Clear Internet Memory

With Clear Internet Memory, you can clear all Internet files and logins stored on your TV, such as passwords, cookies, and history.

To clear the Internet memory…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and

press  (right) to enter the menu.

3 - Select Wired or Wi-Fi > Clear Internet Memory and press OK.

4 - Select OK to confirm. 5 - Press  (left) repeatedly if necessary, to close

the menu.

email address and press the small OK button to the right of the keyboard. 6 - Enter your password and press the same small OK button to sign in. 7 - Press  (left) repeatedly if necessary, to close the menu.

If you want to sign in with another Google Account, first sign out, and then sign in with the other account.

File Sharing

The TV can connect to other devices in your wireless network, like your computer or smartphone. You can use a computer with Microsoft Windows or Apple OS X.

On this TV, you can open photos, music, and videos stored on your computer. Use any recent DLNA certified media server software.

Install the media server software on your computer and set it up to share your media files with the TV. Read the manual of the media server software for more information. This software must be running on your computer to view or play your files on TV.

3.2

Google Account

To enjoy the full capabilities of your Philips Android TV, you can sign in to Google with your Google Account.

By signing in you'll be able to play your favorite games across phone, tablet and TV. You'll also get customized video and music recommendations on your TV home screen as well as access to YouTube, Google Play and other apps.

Use your existing Google Account to sign in to Google on your TV. A Google Account consists of an email address and a password. If you don't have an Google Account yet, use your computer or tablet to create one (accounts.google.com). To play games with Google Play, you need a Google+ profile. If you did not sign in during the first TV installation, you can always sign in later.

To sign in after completing the TV installation…

Android Settings

You can set or view several Android specific settings or information. You can find the list of apps installed on your TV and the storage space they need. You can set the language you would like to use with Voice Search. You can configure the on-screen keyboard or allow apps to use your location. Explore the different Android settings. You can go to www.support.google.com/androidtv for more information on these settings.

To open these settings…

1 - Press , select All Settings and press OK. 2 - Select Android Settings, and press OK. 3 - Explore the different Android settings. 4 - Press  BACK if necessary, to close the menu.

3.3

Philips App Gallery

Philips Apps

Connect the TV to the Internet to enjoy apps selected by Philips. These apps are made specially for TVs. The Philips App Gallery offers a wide diversity of apps. For some countries, you can install apps of a local Video Store or apps from TV broadcasters in your country. The latter may offer Catch-Up TV services.

The Philips App Gallery collection of apps may differ by country or region.

Some App Gallery apps are pre-installed on your TV. To install other apps from the App Gallery, you will be asked to agree to the Terms of Use. You can set the Privacy Settings according to your preferences.

1 - Press , select All Settings and press OK. 2 - Select Android Settings and press OK. 3 - Press  (down) and select Personal > Add

account and press OK.

4 - Select SIGN IN and press OK. 5 - With the remote control keyboard, enter your

To install and use the Philips App Gallery apps, you must agree to the Terms of Use. If you did not agree to these terms during the first TV installation, you can always agree to them later. The moment you agree to the Terms of Use, some apps will be available immediately and you can browse the Philips App

Gallery to install other apps. To agree to the Terms of Use after TV installation…

1 - Press  HOME and select Philips Collection > App Gallery and press OK to open the App Gallery.

2 - Select Terms of Use, then press OK to read. 3 - Select Accept and press OK. You cannot undo

this approval.

4 - Press  BACK to close the menu.

Privacy Settings

You can set some privacy settings for the Philips App Gallery apps.

• You can allow technical statistics to be send to Philips.

• You can allow personal recommendations.

• You can allow cookies.

• You can switch on the Child Lock for 18+ rated apps. To set the Philips App Gallery privacy settings…

1 - Press  HOME and select Philips Collection > App Gallery and press OK to open

the App Gallery.

2 - Select Privacy Policy, then press OK to read. 3 - Select Accept and press OK. You cannot undo

this approval. 4 - Press  BACK to close the menu.

Connect Devices

4.1

About Connections

Connectivity Guide

Always connect a device to the TV with the highest quality connection available. Also, use high quality cables to ensure good transfer of picture and sound.

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to www.connectivityguide.philips.com

Antenna port

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

Copy protection

HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

Typically a Home Theater System (HTS) has an HDMI ARC connection. Connect it to HDMI 1, HDMI 2, or HDMI 3 on this TV. With an HDMI ARC connection, you do not need to connect an extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

You can use any of HDMI 1, HDMI 2, or HDMI 3 connection on this TV to connect the HTS, but ARC is only available for 1 device/connection at a time.

HDMI MHL

With HDMI MHL, you can send what you see on your Android smartphone or tablet to a TV screen.

The HDMI 1 connection on this TV incorporates MHL 2.0 (Mobile High-Definition Link).

HDMI ports

HDMI Quality

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) or Ultra HD (UHD) TV signals.

For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

This wired connection offers great stability and bandwidth, low latency, no wireless interference and good quality sound reproduction. On top of that, the MHL connection will charge the battery of your smartphone or tablet. Although connected, your mobile device will not be charging when the TV is on standby.

Inform yourself regarding which passive MHL cable is suited for your mobile device. In particular, with the HDMI connector for the TV on one side, the type of connector you need to connect to your smartphone or tablet.

MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

HDMI CEC - EasyLink

EasyLink

An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) or Ultra HD (UHD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

EasyLink HDMI CEC

If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device.

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

EasyLink setup

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theater Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.

TV keys are not forwarded to the device. If the key you need is not on the TV remote control,

you can select the key in the Options menu. Press  OPTIONS and select Controls in the menu bar. On the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.

Only devices that support EasyLink Remote Control function will respond to the TV remote control.

EasyLink On or Off

You can switch EasyLink on or off. The TV comes with the EasyLink settings switched on.

To switch off EasyLink completely…

1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to

enter the menu. 3 - Select EasyLink, press  (right) and select EasyLink one step further.

4 - Select Off. 5 - Press  (left) repeatedly if necessary, to close

the menu.

EasyLink Remote Control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink Remote Control separately.

To switch EasyLink Remote Control on or off…

1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to

enter the menu.

3 - Select EasyLink > EasyLink Remote Control and press OK.

4 - Select On or Off and press OK. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Example HDMI CEC branding names are property of their respective owners.

Operate Devices

To operate a device connected to HDMI and set up with EasyLink, select the device - or its activity - in the list of TV connections. Press  SOURCES , select a device connected to an HDMI connection and press OK.

Once the device is selected, the TV remote control can control the device. However the keys  HOME and  OPTIONS and some other

DVI to HDMI

If you still own a device that only has a DVI connection, you can connect the device to any of the HDMI connections with a DVI to HDMI adapter.

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.

Copy protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

can adjust the audio to video synchronization. For more information, in Help, press the color key  Keywords and look up Audio to Video Sync.

4.2

Receiver - Set-Top Box

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

CVBS - Composite

Next to the CVBS signals add the Audio Left and Right signals for sound.

Use an Audio L/R cinch cable if your device also has sound.

Audio Out - Optical

Audio Out - Optical is a high quality sound connection.

This optical connection can carry 5.1 audio channels. If your device, typically a Home Theater System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In - Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV.

Switch Off Timer

Switch off this automatic timer, if you only use the remote control of the Set-top box. Switch this timer off to prevent the TV from switching off automatically after a preset time without a key press on the remote control of the TV.

For more information, in Help, press the color key  Keywords and look up Switch Off Timer for more information.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theater System. For more information, in Help, press the color key  Keywords and look up Audio Out Settings.

If the sound does not match the video on screen, you

4.3

Audio to video synchronization (sync)

Home Theater System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theater System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

HDMI ARC

If your Home Theater System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal, but once you have connected the Home Theater System, the TV can only send the ARC signal to this HDMI connection.

Audio to video synchronization (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theater Systems with a disc player to match the sound with the video.

For more information, in Help, press the color key  Keywords and look up Audio to Video

Sync.

Connect with HDMI

Use an HDMI cable to connect a Home Theater System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the sound does not match the video on screen, you can set a delay on most Home Theater Systems with a disc player to match the sound with the video.

For more information, in Help, press the color key  Keywords and look up Audio to Video

Sync.

Audio Out Settings

Audio Out Delay

With a Home Theater System (HTS) connected to the TV, the picture on the TV and the sound from the HTS should be synchronized.

Automatic audio to video sync

With recent Philips Home Theater Systems, the audio to video sync is done automatically and always correct.

Audio sync delay

For some Home Theater Systems you may need to adjust the audio sync delay to synchronize the audio to the video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio Out delay on the TV.

To switch off Audio Out Delay…

1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the

menu. 3 - Select Advanced > Audio Out Delay and press OK.

4 - Select Off. 5 - Press  (left) repeatedly if necessary, to close

the menu.

Audio Out Offset

If the Home Theater System has no HDMI ARC connection, add an optical audio cable to send the sound of the TV picture to the Home Theater System.

If you cannot set a delay on the Home Theater System, you can set the TV to sync the sound. You can set an offset that compensates for the time necessary for the Home Theater System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms.

The Audio Out Delay setting should be switched on. To synchronize the sound on the TV…

1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the

menu. 3 - Select Advanced > Audio Out Offset and

press OK. 4 - Use the slider bar to set the sound offset and press OK. 5 - Press  (left) repeatedly if necessary, to close the menu.

Audio Out Format

If you have a Home Theater System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio Out Format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theater System. If you have a Home Theater System without multichannel sound processing, select Stereo.

To set Audio Out Format…

1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the

menu. 3 - Select Advanced > Audio Out Format and press OK. 4 - Select Multichannel or Stereo (uncompressed), then press OK. 5 - Press  (left) repeatedly if necessary, to close the menu.

Problems with HTS sound

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theater System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theater System has no DTS sound processing. You can fix this by setting the Audio Out Format of the TV to Stereo.

Press  for All

settings > Sound > advanced > Audio Out Format.

No sound

If you cannot hear the sound from the TV on your Home Theater System, check if you connected the HDMI cable to an HDMI ARC connection on the Home Theater System. All HDMI connections on the TV are HDMI ARC connections.

4.4

Smartphones and Tablets

To connect a smartphone or tablet to the TV, you can use a wireless or wired connection.

Audio Out Leveling

Use the Audio Out Leveling setting to level the volume (loudness) of the TV and the Home Theater System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume…

1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the

menu. 3 - Select Advanced > Audio Out Leveling and press OK.

4 - Select More, Medium, or Less, then press OK.

5 - If the volume difference is large, select More. If

the volume difference is small, select Less. 6 - Press  (left) repeatedly if necessary, to close the menu.

Audio Out Leveling affects both the Audio Out Optical and HDMI ARC sound signals.

Wireless

For a wireless connection on your smartphone or tablet, download the Philips TV Remote App from your favorite app store.

Wired

For a wired connection, use the HDMI 1 MHL connection on the back of the TV. In Help, press the color key  Keywords and look up HDMI MHL for more information.

4.5

Blu-ray Disc Player

Use a High speed HDMI cable to connect the Bluray Disc player to the TV.

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote

control.

Pairing a Device

4.6

DVD Player

Use an HDMI cable to connect the DVD player to the TV.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

For more information on EasyLink, in Help, press the color key  Keywords and look up EasyLink HDMI CEC.

4.7

Bluetooth - Speakers and Gamepads

Position the wireless speaker within a distance of about 16 feet from the TV. Read the user manual of the device for specific information on pairing and on wireless range. Make sure the TV's Bluetooth setting is switched on.

Once a wireless gamepad is paired, you can use it. When a wireless speaker is paired, you can select it to play the TV sound. When a device is paired, you do not need to pair it again unless you remove the device.

To pair a wireless speaker with the TV 1 - Switch on the wireless speaker and place it within

range of the TV.

2 - Press , select All Settings and press OK. 3 - Select Wireless and Networks and

press  (right) to enter the menu. 4 - Select Bluetooth > Search Bluetooth Device, and press OK. 5 - Select Search and press OK. Follow the instructions on screen. You will pair the device with the TV and the TV will store the connection. 6 - Select the type of device (headphones, subwoofer, …), select Next and press OK. 7 - Press  (left) repeatedly if necessary, to close the menu.

For more information on how to select the wireless speaker, in Help, press the color key  Keywords and look up Speakers, Select.

What You Need

You can connect a wireless device with Bluetooth® to this TV: a wireless speaker, a subwoofer, a sound bar, or headphones. You can also connect a wireless gamepad with Bluetooth LE.

To play the TV sound through a wireless speaker, you must pair the wireless speaker with the TV. You can pair up to 4 wireless speakers, but you can only play the sound through one wireless audio speaker at a time. If you connect a subwoofer, the sound is played through the TV and the subwoofer. If you connect a sound bar, the sound is played through the sound bar only.

Attention: Audio to Video syncronization

Many Bluetooth speaker systems have a high, so called, "latency." High latency means that the audio lags behind the video, causing unsynchronized "lip sync." Before you purchase a wireless Bluetooth speaker system, learn about the newest models and look for a device with a low latency rating. Ask your dealer for advice.

For more information on the Bluetooth On or Off setting, in Help, press the color key  Keywords and look up Bluetooth, On or

Off.

Select a Device

Once a wireless Bluetooth speaker is paired, you can select it to play the TV sound.

To select a speaker to play the TV sound…

1 - Press , select Speakers and press OK. 2 - Select the speaker system you want and

press OK. 3 - Press  (left) repeatedly if necessary, to close the menu.

For more information on how to pair a wireless speaker, in Help, press the color key  Keywords and look up Bluetooth, Pairing.

Remove a Device

HDMI

You can connect or disconnect a wireless Bluetooth device. When a Bluetooth device is connected, you can use the gamepad or hear the TV sound through the wireless speaker. You can also remove a wireless Bluetooth device. If you remove a Bluetooth device, the device will be unpaired.

To remove or disconnect a wireless device…

1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and press OK. 3 - Select Bluetooth > Remove Device and

press OK. 4 - In the list, select the wireless device and press OK.

5 - Select Disconnect or Remove and press OK. 6 - Select OK and press OK to confirm. 7 - Press  (left) repeatedly if necessary, to close

the menu.

4.8

Headphones

For best quality, connect the game console with a high-speed HDMI cable to the TV.

Video-Audio L/R

Connect the game console to the TV with a composite cable (CVBS) and an audio L/R cable to the TV.

You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.

To adjust the volume… 1 - Press , select Headphone Volume and

press OK. 2 - Press the arrows  (up) or  (down) to adjust the value. 3 - Press  (left) repeatedly if necessary, to close the menu.

4.9

Game Consoles

Best Setting

Before you start playing a game from a connected game console, we advise you to set the TV in the ideal setting Game.

When you finish playing a game and start watching TV again, remember to switch the Game or Computer setting back to Off.

To set the TV to the ideal setting…

1 - Press , select All Settings and press OK. 2 - Select Picture > Advanced and select Game or

Computer.

3 - Select Off, Game or Computer. 4 - Press  (left) repeatedly if necessary, to close

the menu.

4.10

4.11

Gamepad

Connect a Gamepad

To play games from the Internet on this TV, you can connect a selected range of wireless gamepads. You can use gamepads with a USB nano receiver or gamepads with Bluetooth.

To connect a gamepad with a USB nano receiver… 1 - Plug the small nano receiver into one of the USB

connections on the side of the TV. The wireless nano receiver comes with the gamepad. 2 - If the gamepad is switched on, you can use the gamepad.

You can connect a second gamepad in the second USB connection on the side of the TV.

Bluetooth

To connect a wireless gamepad with Bluetooth, in Help, press the color key  Keywords and look up Bluetooth, Pairing.

USB Hard Drive

What You Need

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

To Pause

To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 4GB of disk space.

To Record

To pause and record a broadcast, you need a minimum of 250GB disk space. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive.

For more information on how to install a USB Hard Drive, in Help, press the color key  Keywords and look up USB Hard Drive,

installation.

Suitable gamepads

A selected range of wireless gamepads are suited and tested for use on this TV. Other gamepads might not be fully compatible.

The suited gamepads are…

• Logitech F710

• Logitech F510

• Xbox 360 Wireless Controller for Windows

• Speedlink Strike FX Wireless Gamepad

• Sony Play Station wired

• Mad Catz C.T.R.L. Mobile Gamepad for Android

• Ipega, PG-9023

• Ipega, PG-9025

• PhoneJoy gamepad

Problems

To solve possible interference with other wireless devices on TV…

• Use a USB extension cord and move the nano receiver about 3 feet away from the TV.

• Alternatively, you can use a powered USB hub connected to the TV and plug the nano receivers into the USB hub.

Installation

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting.

Follow the instructions on screen. When the USB Hard Drive is formatted, leave it

connected permanently.

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on

the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

Formatting

Before you can pause or record a broadcast, or store apps, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive. If you want to record broadcasts with TV Guide data from the Internet, you must setup the Internet connection first before you install the USB Hard Drive.

Warning

Connect

Connect a USB keyboard (USB-HID type) to enter text on your TV.

Use one of the USB connections to connect.

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

To format a USB Hard Drive… 1 - Connect the USB Hard Drive to one of the USB

connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting. Follow the on-screen instructions. 4 - The TV will ask if you want to use the USB Hard Drive to store apps. Select Agree if you do. 5 - When the USB Hard Drive is formatted, leave it connected permanently.

4.12

USB Keyboard

Configure

Install the keyboard

To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.

To change the keyboard layout setting when a layout was selected…

1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to

enter the menu. 3 - Select USB keyboard Settings, and press OK to start the keyboard setup.

Special Keys

Keys for entering text

• Enter key = OK

• Backspace = delete character before cursor

• Arrow keys = navigate within a text field

• To switch between keyboard layouts, if a secondary layout is set, press the Ctrl + Spacebar keys simultaneously.

Keys for Smart TV Apps and Internet pages

• Tab and Shift + Tab = Next and Previous

• Home = scroll to the top of the page

• End = scroll to the bottom of the page

• Page Up = jump one page up

• Page Down = jump one page down

• + = zoom in one step

• - = zoom out one step

• * = fit the web page to the screen width

4.13

USB Flash Drive

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the content list does not appear automatically, press  SOURCES and select USB.

To stop watching the USB flash drive content, press  EXIT or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.

For more information on viewing photos, in Help, press the color key  Keywords and look up Photos, Videos and Music.

4.15

Camcorder

HDMI

For best quality, use an HDMI cable to connect the camcorder to the TV.

Ultra HD on USB

You can view photos in Ultra HD resolution from a connected USB device or flash drive. The TV will downscale the resolution to Ultra HD if the resolution of the photo is higher. You cannot play a native Ultra HD video on any of the USB connections.

For more information on watching or playing content from a USB flash drive, in Help, press the color key  Keywords and look up Photos, Videos and Music.

4.14

Photo Camera

To view photos stored on your digital photo camera, you can connect the camera directly to the TV.

Use one of the USB connections on the TV to connect. switch on the camera after you have made the connection.

If the content list does not appear automatically, press  SOURCES , and click USB. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.

Video-Audio L/R

You can use a Video Audio L/R cable to connect the camcorder to the TV.

4.16

Computer

Connect

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

Ultra HD on USB

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.

Ideal Setting

If you connect a computer, we advise you to give the connection, to which the computer is connected, the correct device type name in the Source menu. If you then switch to Computer in the Source menu, the TV is automatically set to the ideal settings for a computer.

You can manually switch the ideal setting to Off for watching TV or Game for playing a game from a connected game console (remember to switch back to Off when you stop playing a game).

If you switch to a source and change the Game or Computer setting, it will be stored for this selected source.

To set the TV to the ideal setting manually…

1 - Press , select All Settings and press OK. 2 - Select Picture and press  (right) to enter the

menu. 3 - Select Advanced > Game or Computer, and press OK. 4 - Select Game (for gaming) or select Computer (for watching a movie). 5 - Press  (left) repeatedly if necessary, to close the menu.

Remember to set Game or Computer setting to Off when you stop playing the game.

Switching On and Off

5.1

On or Standby

the menu.

Make sure the TV is connected to the mains AC power. Connect the supplied power cord to the AC in connector at the back of the TV. The indicator light at the bottom of the TV lights up.

Switch on

Press  on the remote control to switch the TV on. Alternately, press  HOME. You can also press the small joystick key on the back of the TV to switch the TV on in case you can't find the remote control or its batteries are empty.

Switch to standby

To switch the TV to standby, press  on the remote control. You can also press the small joystick key on the back of the TV.

In standby mode, the TV is still connected to the mains power but consumes very little energy.

5.3

Keys on TV

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu… 1 - With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu. 2 - Press left or right to select  Volume,  Channel, or  Sources. Select  Demo to start a demo movie. 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. Press the joystick key to start the demo movie. 4 - The menu will disappear automatically.

To switch the TV on standby, select  and press the joystick key.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

5.2

Philips Logo Brightness

You can switch off or adjust the brightness of the Philips logo on the front of the TV.

To adjust or switch off…

1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to

enter the menu. 3 - Select Philips Logo Brightness, and press  (right) to enter the menu. 4 - Select Minimum, Medium, Maximum, or Off to switch off the lighting of the logo, then press OK. 5 - Press  (left) repeatedly if necessary, to close

5.4

Sleep Timer

With the Sleep Timer, you can set the TV to switch to Standby automatically after a preset time.

To set the Sleep Timer…

1 - Press , select All Settings and press OK. 2 - Select Region and Language > Clock, and

press OK. 3 - Select Sleep Timer and press  (right). With the slider bar you can set the time to up to 180 minutes in increments of 5 minutes. If set to 0 minutes, the Sleep Timer is switched off. You can always switch off your TV earlier or reset the time during the countdown. 4 - Press  (left) repeatedly if necessary, to close the menu.

5.5

Switch Off Timer

If the TV receives a TV signal but you don't press a key on the remote control during a 4 hour period, the TV switches off automatically to save energy. Also, if the TV does not receive a TV signal or remote control command for 10 minutes, it switches off automatically.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.

To deactivate the Switch Off Timer …

1 - Press , select All Settings and press OK. 2 - Select Eco Settings and press  (right) to enter

the menu.

3 - Select Switch Off Timer and press OK. 4 - Press the arrows  (up) or  (down) to adjust

the value. The value 0 deactivates the automatic switch off. 5 - Press  (left) repeatedly if necessary, to close the menu.

For more information on environmentally friendly TV settings, in Help, press the color key  Keywords and look up Eco Settings.

Remote Control

6.1

Key overview

Top

1 -  Standby / On

To switch the TV On or back to Standby.

2 - VOICE microphone 3 -



To open the Netflix App directly. With the TV switched on or from standby.

4 To select one of the Ambilight styles.

5 -  TV GUIDE To open or close the TV Guide.

6 -  SETTINGS To open the Frequent Settings menu and All

Settings. 7 -

To open the menu with recommended programs. If available.

8 -  VOICE To start a search request with voice input.

AMBILIGHT



TOP PICKS



1 -  To open the TV Menu with typical TV functions.

2 -  SOURCES To open or close the Sources menu.

3 -  INFO To open or close program info.

4 -  BACK To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous App/Internet page.

5 -

   

Direct selection of options. Blue key , opens Help. 6 -  - EXIT

To switch back to watching TV. To leave an interactive TV application.

7 To open or close the Options menu.

8 - OK key To confirm a selection or setting.

9 - Navigation keys To navigate up, down, left or right.

10 -  HOME To open the Home menu.

OPTIONS



Color keys

Middle

Bottom

1 To open an extra small screen.

MULTI VIEW



speaking, even if the TV asks you to retry. The first time you press the  VOICE key and try

Voice, the Help page on using Voice will open. Read how to use Voice. You can press  VOICE again and try it immediately. To close Help, press  BACK.

Alternatively, you can use the remote control keyboard to enter text. In Help, press the color key  Keywords and look up Remote Control Keyboard for more information.

6.3

Keyboard

Overview

Overview of a keyboard.

2 - To adjust the volume level.

3 - Number keys To select a channel directly.

4 - CC To switch Subtitles on, off or on during mute.

5 - Playback and Record

• Play , to playback.

• Pause , to pause playback

• Stop , to stop playback

• Rewind , to rewind

• Forward , to fast forward

• Record , to start recording 6 -  Channel

To switch to the next or previous channel in the channel list. To start the next or previous chapter on a disc.

7 To mute the sound or to restore it.

8 - (Dot) To open digital sub-channels.





Volume

Mute

1 - Character

Character position. 2 -

To type uppercase characters. 3 - Ω Special characters

To open the On-screen keyboard to select accented characters or symbols.

4 - Fn key To type a number or punctuation character.

5 -  Spacebar 6 - Navigation and OK 7 -  Share this

To share online what you are now watching.



Shift

6.2

Voice

Using Voice

The TV must be connected to the Internet. You can use Voice anytime to search for whatever

you are looking for on the Internet. To search with Voice…

1 - Press  VOICE. 2 - Speak out clearly what you are looking for. You

can speak for 10 seconds before the microphone switches off. Always press  VOICE before you start

Writing Text

With the keyboard on the back of the remote control, you can write text in any text field on screen. Turn the keyboard facing upwards to activate the keyboard keys. Hold the remote control with two hands and type with both thumbs.

To write text…

1 - Select a text field if it is not yet selected. 2 - Turn the remote control keyboard facing upwards

to activate the keyboard keys. Hold the remote control with two hands and type with both thumbs. 3 - To hide the on-screen keyboard, press  BACK. Press OK to confirm the text.

On-screen Keyboard

If you use the on-screen keyboard to enter text, you can configure the keyboard layout to a layout you are used to.

To open these settings… Press  HOME, select All Settings and press OK.

5 - Select Android Settings and press OK. 6 - Select Preferences >  Keyboard and

press OK. 7 - Select Configure > Language and press OK. You can set your language keyboard layout here. 8 - Press  BACK to close the menu to go back one step.

Uppercase and Lowercase

To type an uppercase character, press the  (Shift) key just before you type the character. To type several uppercase characters consecutively, press and hold the  key while typing. To type uppercase constantly, press the  key for 2 seconds to switch the keyboard in uppercase mode. To switch out of uppercase mode, press the  key again. If no keys are pressed for 20 seconds, the uppercase mode switches off automatically. Also, if you press another modifier key, like Fn or Ω, you switch out of uppercase mode.

back of remote control. In the on-screen keyboard, you can navigate to the character you need. Switch the keyboard layout with the color keys. Press OK to enter a character. The on-screen keyboard disappears when you press a character on the Remote Control Keyboard.

6.4

Pairing the Remote Control

This remote control uses radio frequency (RF) to send its commands to the TV. Contrary to remote controls using infrared signals, you don't have to point at the TV with RF. For the remote control to communicate with the TV, both TV and remote control should be paired (linked) with each other. Once paired, you cannot use the remote control to control another TV.

Pairing

When you started the initial TV installation, the TV invited you to press the OK key, and by doing so, the pairing was completed. If the TV does not react to any remote control key press, pairing was unsuccessful.

Pair again

If the pairing with the remote control was lost, you can pair the TV with the remote control again.

To start pairing... 1 - On the back of the TV, standing in front of the TV

at the right, press the joystick power key  in for 3 seconds. A message will show that the TV is ready to pair. 2 - Press the Red  and Blue  color keys simultaneously for 1 second. A message appears when the pairing is successful.

Numbers and Punctuation Characters

To type a number or punctuation character, press the Fn key just before you type the number or punctuation character you need. You can switch the Fn mode on or off as you do for the uppercase mode.

Internet You can use the Fn key to enter www. or .com.

Accented Letters and Symbols

Accented characters and symbols are not directly available on the Remote Control Keyboard. To type such a character, you can open the Onscreen keyboard.

To open the on-screen keyboard, press Ω on the

6.5

IR Sensor

The remote control of the TV uses BT (bluetooth) to send its commands to the TV. With BT, you do not need to point the remote control at the TV.

However, the TV can also receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

6.6

Batteries

The TV will notify you when the battery power of the remote control is low.

To replace the batteries, open the battery compartment on the keyboard side of the remote control.

1 - Use a small coin or other small, blunt object and press the rectangular shaped release button to open the battery lid. 2 - Replace the old batteries with 2 type AA-LR6-1.5V alkaline batteries. Make sure the + and the - ends of the batteries line up correctly. 3 - Reposition the battery door and push it down until it clicks.

Put the remote control down for about 15 seconds to calibrate the pointer.

Remove the batteries if you are not using the remote control for a long time. Safely dispose of your old batteries according to the end of use directions.

For more information, press  Keywords and look up End of use.

6.7

Cleaning

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

+ 101 hidden pages

Philips 55PUG7100/78, 49PUG7100/78 instructions for use

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents
