Philips 55PFT6510, 50PFT6510, 40PFT6510 User Manual

Register your product and get support at
www.philips.com/welcome
6510 series
User Manual
40PFT6510 50PFT6510
55PFT6510

Contents

1.1 Philips Android TV 4
1.2 Using Apps 4
1.3 Playing Games 4
1.4 Movies and missed programmes 4
1.5 Pause TV and Recordings 4
1.6 Smartphones and Tablets 4
1.7 Social Networks 5
1.8 3D 5
1.9 Ambilight 5
1.10 Ambilight + Hue 5
1.11 Bluetooth Connection 5
2 Setting Up 7
2.1 Read Safety 7
2.2 TV Stand and Wall Mounting 7
2.3 Tips on Placement 7
2.4 Power Cable 8
2.5 Antenna Cable 8
3 Connect your Android TV 9
3.1 Network and Internet 9
3.2 Google Account 12
3.3 Philips App Gallery 12
4 Connect Devices 14
4.1 About Connections 14
4.2 CAM with Smart Card - CI+ 16
4.3 Receiver - Set-Top Box 17
4.4 Home Theatre System - HTS 18
4.5 Smartphones and Tablets 19
4.6 Blu-ray Disc Player 19
4.7 DVD Player 20
4.8 Bluetooth - Speakers and Gamepads 20
4.9 Headphones 21
4.10 Game Console 21
4.11 Gamepad 22
4.12 USB Hard Drive 22
4.13 USB Keyboard 23
4.14 USB Flash Drive 24
4.15 Photo Camera 24
4.16 Camcorder 24
4.17 Computer 24
5 Switching On and Off 26
5.1 On or standby 26
5.2 Philips Logo Brightness 26
5.3 Keys on TV 26
5.4 Sleep Timer 26
5.5 Switch Off Timer 26
6 Remote Control 28
6.1 Key overview 28
6.2 Voice search 29
6.3 Keyboard 30
6.4 Pairing the Remote Control 31
6.5 IR Sensor 31
6.6 Batteries 31
6.7 Cleaning 31
7 Channels 32
7.1 Install Channels 32
7.2 Channel Lists 32
7.3 Watching channels 33
7.4 Favourite Channels 35
7.5 Text / Teletext 36
7.6 Interactive TV 37
8 TV Guide 39
8.1 What You Need 39
8.2 TV Guide Data 39
8.3 Using the TV Guide 39
9 Recording and Pause TV 41
9.1 Recording 41
9.2 Pause TV 42
10 Top Picks 44
10.1 About Top Picks 44
10.2 Now on TV 44
10.3 TV on Demand 44
10.4 Video on Demand 45
11 Home Menu 46
11.1 About the Home Menu 46
11.2 Open the Home Menu 46
11.3 Search and Voice Search 46
11.4 Restricted Profile 46
12 TV Menu 47
12.1 About TV Menu 47
12.2 Open TV Menu 47
13 Netflix 48 14 Sources 49
14.1 Switch to a device 49
14.2 Options for a TV Input 49
14.3 Device Name and Type 49
14.4 Game or Computer 49
14.5 Rescan Connections 50
15 Apps 51
15.1 About Apps 51
15.2 Google Play 51
15.3 App Gallery 52
15.4 Start or Stop an App 52
15.5 Lock Apps 52
15.6 Manage Apps 54
15.7 Storage 54
16 Games 55
16.1 What You Need 55
16.2 Gamepads 55
16.3 Play a Game 55
16.4 Split Screen Gaming 55
16.5 Ideal Game Settings 56
17 Internet 57
17.1 Start Internet 57
17.2 Options on Internet 57
18 Videos, Photos and Music 58
18.1 From a USB Connection 58
18.2 From a Computer or NAS 58
18.3 From a Cloud Storage Service 58
18.4 Play your Videos 58
18.5 View your Photos 59
18.6 Play your Music 59
19 Smartphones and Tablets 61
19.1 Philips TV Remote App 61
19.2 Google Cast 61
2
19.3 Miracast 61
19.4 AirPlay 62
19.5 MHL 62
20 Ambilight 64
20.1 Ambilight Style 64
20.2 Ambilight Off 64
20.3 Ambilight Settings 64
21 3D 65
21.1 What You Need 65
21.2 3D Glasses 65
21.3 Watch 3D 66
21.4 Optimal 3D Viewing 66
21.5 Care of the 3D Glasses 66
21.6 Health Warning 66
22 Multi View 68
22.1 About Multi View 68
22.2 Text and TV 68
22.3 Nettv and TV 68
22.4 HDMI and TV 68
23 Settings 69
23.1 Picture 69
23.2 Sound 74
23.3 Ambilight Settings 77
23.4 Eco Settings 79
23.5 General Settings 80
23.6 Clock, Region and Language 82
23.7 Universal Access 85
24 Wireless and Networks 87
24.1 Network 87
24.2 Bluetooth 87
25 Android Settings 88
31.1 Terms of Use - TV 136
31.2 Terms of Use - Smart TV 136
31.3 Terms of Use - Philips App Gallery 136
32 Copyrights 137
32.1 MHL 137
32.2 HDMI 137
32.3 Dolby Digital Plus 137
32.4 DTS Premium Sound ™ 137
32.5 Microsoft 137
32.6 Wi-Fi Alliance 137
32.7 Kensington 138
32.8 Other Trademarks 138
Index 139
26 Channel Installation 89
26.1 Antenna/Cable Installation 89
26.2 Channel List Copy 91
27 Software 93
27.1 Update Software 93
27.2 Software Version 93
27.3 Open Source Software 93
27.4 Open Source License 94
27.5 Announcements 126
28 Specifications 128
28.1 Environmental 128
28.2 Power 128
28.3 Operating System 129
28.4 Reception 129
28.5 Display Type 129
28.6 Display Input Resolution 129
28.7 Dimensions and Weights 129
28.8 Connectivity 130
28.9 Sound 130
28.10 Multimedia 130
29 Help and Support 131
29.1 Register your TV 131
29.2 Using Help 131
29.3 Troubleshooting 131
29.4 Online Help 133
29.5 Support and Repair 133
30 Safety and Care 134
30.1 Safety 134
30.2 Screen Care 135
31 Terms of Use 136
3
1
TV Tour
For more information, in Help, press the colour key  Keywords and look up Apps.
1.1
Philips Android TV
This a Philips Android TV™. Android TV offers thousands of movies, shows and
games from Google Play, YouTube and your favourite apps.* Voice search and personalised recommendations mean more time being entertained and less time hunting for something good. With Google Cast built in, you can easily cast movies, shows and photos from your Chromebook or Android device to your TV.**
With the Philips TV Remote App on your smartphone or tablet, you have your TV channels at your fingertips. Send a photo to the large TV screen or follow your favourite cooking show on your tablet in the kitchen. From now on your TV is part of your mobile household.
Connect the TV to your home network and the Internet.
* The TV must be connected to the Internet. Subscriptions might be required for certain content providers.
** Casting optimized for selected services only. Streaming quality for other content might vary. Supported operating systems and devices: Android
2.3 and higher, iOS® 7 and higher, Windows® 7 and higher, Mac OS® 10.7 and higher and Chrome OS (version 38 or higher).
1.3
Playing Games
This TV is your big screen for gaming. Big enough for two.
You can play a game from a connected Game Console, a game from an installed App or simply an online game on a website. You can set the TV to the ideal settings for gaming, to allow quick and responsive action. If you play a multi-player game with split screens, you can set the TV to show each screen as a full screen simultaneously. Each player can focus on his own game to play.
1.4
Movies and missed programmes
To get a rental video, you don't need to leave the house.
Open Video on Demand and get that latest movie streamed to your TV directly. Open the video store App, create your personal account, select the movie and press play.
Video on Demand is available in selected countries. For more information, in Help, press the colour
key  Keywords and look up Video on Demand.
Google, Android, Google Play and other marks are trademarks of Google Inc. The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License.
http://creativecommons.org/licenses/by/3.0/legalco de
1.2
Using Apps
To get you started, some practical Apps are pre­installed on your TV.
The Apps pages show the collection of Apps (Applications) on your TV. Like Apps on your smartphone or tablet, the Apps on your TV offer specific functions for an enriched TV experience. Apps like TV games or weather forecasts (a.o.). Or start an Internet Browser App, like Google Chrome, to surf the Internet.
1.5
Pause TV and Recordings
If you connect a USB Hard Drive, you can pause and record a broadcast from a digital TV channel.
Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can watch it again later. With a USB Hard Drive connected, you can also record digital broadcasts. You can record while you are watching a programme or schedule a recording of an upcoming programme.
For more information, in Help, press the colour key  Keywords and look up Pause TV or Recording.
4
1.6
1.9
Smartphones and Tablets
The new Philips TV Remote App is your new TV buddy.
With the TV Remote App on your smartphone or tablet, you master your media around you. Send photos, music or videos to your big TV screen or watch any of your TV channels live on your tablet or phone. Open the TV Guide and schedule a recording for tomorrow. Your TV at home will do the job. Switch on Ambilight+hue and set the coziest colour effects in your living room. With the TV Remote App you are in control. You might consider to simply lower the TV volume.
Download the Philips TV Remote App from your favourite app store today.
It's free. The Philips TV Remote App is available for iOS and
Android.
1.7
Social Networks
No need to get up to check your friend's messages on your computer.
On this TV you get the messages from your social network on your TV screen. You can send a return message from your couch.
Ambilight
Ambilight is the most elegant and exclusive feature
of your new Philips TV. A subtle glow of coloured light that shines from
behind the screen - expanding your visual experience. With Ambilight your eyes relax but your mind is fully taken up by what you see.
With Ambilight+hue you even expand Ambilight further. Bringing in the wireless controlled bulbs of Philips Hue*. All of them setup to fill your room with colours that fit what's on TV.
You will miss Ambilight when you switch it off. * Separately available.
1.10
Ambilight + Hue
Your Ambilight TV
Philips' unique Ambilight technology goes beyond the ordinary. It not only makes your screen seem much wider, it also makes your viewing experience more immersive by projecting an extra-wide glow from the sides of your TV screen onto the surrounding wall. Colour, vibrancy and excitement move beyond the screen and into your living room, bringing with them a more thrilling, intense and immersive viewing experience.
For more information, in Help, press the colour key  Keywords and look up Apps.
1.8
3D
Your new TV is a 3D TV. Enjoy the immersive experience of watching a movie
in 3D. Play a movie in 3D on your Blu-ray Player or rent a 3D movie from a Video Store from the Home menu, Video on Demand.
The TV uses the Active 3D technology to watch 3D in its full resolution.
For more information, in Help, press the colour key  Keywords and look up 3D.
Ambilight + Hue Fill your space and your life with the wonder of
Ambilight. Ambilight + hue* allows you to extend the Ambilight experience throughout your room.
With Ambilight+hue you even expand Ambilight further. Bringing in the wireless controlled bulbs of Philips Hue*. All of them setup to fill your room with colours that fit what's on TV.
Your Ambilight TV and hue bulbs ‘talk’ wirelessly to each other, surrounding you in the emotion, power and colour of Ambilight.
*Hue kit available separately.
1.11
Bluetooth Connection
Your TV has Bluetooth technology inside. You can connect extra wireless speakers or a wireless
headphone. Forget connecting cables, pairing your device with the TV is enough.
For more information, in Help, press the colour key  Keywords and look
5
up Bluetooth or Wireless Speakers.
6
2
Setting Up
threaded bushes on the back of the TV. Make sure that the metal screws, to mount the TV to the VESA-compliant bracket, go about 10mm deep inside the threaded bushes of the TV.
2.1
Read Safety
Read the safety instructions first before you use the TV.
To read the instructions, in Help, press the colour key  Keywords and look up Safety Instructions.
2.2
TV Stand and Wall Mounting
TV Stand
You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from www.philips.com.
Use the product type number of the TV to look for the Quick Start Guide to download.
Caution
Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.
Wall Mounting
Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .
Wall Mounting
Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . .
• 32PFx6500
VESA MIS-F 100x100, M4
• 40PFx6510, 40PFx6540, 40PFx6550, 40PFx6560, 40PFx6580
VESA MIS-F 200x200, M4
• 50PFx6510, 50PFx6540, 50PFx6550, 50PFx6560, 50PFx6580
VESA MIS-F 400x200, M6
• 55PFx6510, 55PFx6540, 55PFx6550, 55PFx6560, 55PFx6580
VESA MIS-F 400x200, M6
• 65PFx6520
VESA MIS-F 400x400, M6 Preparation
• 50PUT6800, 55PUT6800
VESA MIS-F 400x200, M6
• 65PUT6800
VESA MIS-F 400x400, M6 Preparation
First remove the 4 plastic screw caps out of the threaded bushes on the back of the TV. Make sure that the metal screws, to mount the TV to the VESA-compliant bracket, go about 10mm deep inside the threaded bushes of the TV.
Caution
Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TVs weight. Also read the safety precautions before positioning the TV. TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.
First remove the 4 plastic screw caps out of the
7
2.3
Tips on Placement
• Position the TV where light does not shine directly on the screen.
• Dim lighting conditions in the room for best Ambilight effect.
• Position the TV up to 15 cm away from the wall.
• The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.
2.4
Power Cable
Use this antenna connection for DVB-T and DVB-C input signals.
• Insert the power cable into the POWER connector on the back of the TV.
• Make sure the power cable is securely inserted in the connector.
• Make sure that the power plug, in the wall socket, is accessible at all times.
• When you unplug the power cable, always pull the plug, never pull the cable.
Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.
For more information, in Help, press the colour key  Keywords and look up Switching On for more information on switching the TV on or off.
2.5
Antenna Cable
Insert the antenna plug firmly into the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.
8
3
Connect your Android TV
3.1
Network and Internet
Home Network
To enjoy the full capabilities of your Philips Android TV, your TV must be connected to the Internet.
Connect the TV to a home network with a high-speed Internet connection. You can connect your TV wirelessly or wired to your network router.
Connect to Network
Wireless Connection
What You Need
6 - Depending on the type of router, enter your encryption key - WEP, WPA or WPA2. If you entered the encryption key for this network before, you can select OK to make the connection immediately. 7 - A message will be shown when the connection is successful.
WPS
If your router has WPS, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Connect to Network and press OK.
4 - Select WPS then press OK. 5 - Go to the router, press the WPS button and return
to the TV within 2 minutes.
6 - Select Connect to make the connection. 7 - A message will be shown when the connection is
successful.
To connect the TV to the Internet wirelessly, you need a Wi-Fi router with a connection to the Internet.
Use a high-speed (broadband) connection to the Internet.
Make the Connection
Wireless
To make a wireless connection…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and press
(right) to enter the menu.
3 - Select Wired or Wi-Fi > Connect to Network and press OK.
4 - Select Wireless and press OK. 5 - In the list of found networks, select on your
wireless network. If your network is not in the list because the network name is hidden (you switched off the SSID broadcast of the router), select Add New Network to enter the network name yourself.
WPS with PIN Code
If your router has WPS with a PIN code, you can directly connect to the router without scanning for networks. If you have devices in your wireless network that use the WEP security encryption system, you cannot use WPS.
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Connect to Network and press OK.
4 - Select WPS with PIN code and press OK. 5 - Write down the 8-digit PIN code shown on
screen and enter it in the router software on your PC. Consult the router manual on where to enter the PIN code in the router software.
6 - Select Connect to make the connection. 7 - A message will be shown when the connection is
successful.
Problems Wireless network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi
802.11b/g/n devices in your proximity might disturb the wireless network.
• Make sure that the firewalls in your network allow access to the TV's wireless connection.
• If the wireless network does not work properly in your home, try the wired network installation.
9
Internet does not work
• If the connection to the router is OK, check the router connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for information on indoor range, transfer rate and other factors of signal quality.
• Use a high-speed (broadband) Internet connection for your router.
DHCP
• If the connection fails, you can check the DHCP (Dynamic Host Configuration Protocol) setting of the router. DHCP should be switched on.
Wired Connection
What You Need
To connect the TV to the Internet, you need a network router with a connection to the Internet. Use a high-speed (broadband) connection to the Internet.
Network Settings
View Network Settings
You can view all current network settings here. The IP and MAC address, signal strength, speed, encryption method, etc.
To view the current network settings…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > View Network Settings and press OK.
4 - Press  (left) repeatedly if necessary, to close the menu.
Network Configuration
If you are an advanced user and want to install your network with Static IP addressing, set the TV to Static IP.
To set the TV to Static IP…
Make the Connection
To make a wired connection… 1 - Connect the router to the TV with a network cable
(Ethernet cable**).
2 - Make sure that the router is switched on. 3 - Press , select All Settings and press OK. 4 - Select Wireless and Networks and
press  (right) to enter the menu.
5 - Select Wired or Wi-Fi > Connect to Network and press OK.
6 - Select Wired and press OK. The TV constantly searches for the network connection. 7 - A message will be shown when the connection is successful.
If the connection fails, you can check the DHCP setting of the router. DHCP should be switched on.
**To fulfill EMC regulations, use a shielded FTP Cat. 5E Ethernet cable.
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Network Configuration and press OK. 4 - Select Static IP and press OK to enable Static IP Configuration.
5 - Select Static IP Configuration and configure the connection.
6 - You can set the number for IP Address, Netmask, Gateway, DNS 1, or DNS 2.
7 - Press  (left) repeatedly if necessary, to close the menu.
Switch On with Wi-Fi (WoWLAN)
You can switch this TV on from your smartphone or tablet if the TV is in Standby. The setting Switch On with Wi-Fi (WoWLAN) must be switched on.
To switch on WoWLAN…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Switch On with Wi-Fi (WoWLAN) and press OK.
4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu.
10
Switch on Wi-Fi connection
You can switch on or off Wi-Fi connection on your TV.
To switch on Wi-Fi…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > Wi-Fi On/Off and press OK.
4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu.
Digital Media Renderer - DMR
If your media files do not play on your TV, make sure that the Digitial Media Renderer is switched on. As a factory setting, DMR is switched on.
To switch on DMR…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Digital Media Renderer
- DMR and press OK.
4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu.
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Wi-Fi Miracast Connections and press OK.
4 - Select Clear All and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu.
Wi-Fi Smart Screen
To watch digital TV channels on your smartphone or tablet with the Philips TV Remote App, you must switch on Wi-Fi Smart Screen. Some scrambled channels might not be available on your mobile device.
To switch on Wi-Fi Smart Screen…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Wi-Fi Smart Screen and press OK.
4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu.
TV Network Name
If you have more than one TV in your home network, you can give the TV a unique name.
Switch on Wi-Fi Miracast
Switch on Wi-Fi Miracast to share the screen of your smartphone, tablet or computer on the TV.
To switch on Miracast…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > Wi-Fi Miracast and press OK.
4 - Select On and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu. For more information, in Help, press the colour
key  Keywords and look up Miracast™, switch
on.
Clear Wi-Fi Miracast connection
Clear the list of connected and blocked devices that are used with Miracast.
To clear Miracast connections…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
To change the TV name…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu. 3 - Select Wired or Wi-Fi > TV Network Name and press OK. 4 - Enter the name with the on-screen keyboard or the remote control keyboard (if available).
5 - Select  to confirm the change. 6 - Press  (left) repeatedly if necessary, to close
the menu.
Clear Internet Memory
With Clear Internet Memory, you can clear all Internet files and logins stored on your TV, such as passwords, cookies, and history.
To clear the Internet memory…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Clear Internet Memory and press OK.
4 - Select OK to confirm. 5 - Press  (left) repeatedly if necessary, to close
the menu.
11
File Sharing
Android Settings
The TV can connect to other devices in your wireless network, like your computer or smartphone. You can use a computer with Microsoft Windows or Apple OS X.
On this TV, you can open photos, music and videos stored on your computer.
3.2
Google Account
Sign In
To enjoy the full capabilities of your Philips Android TV, you can sign in to Google with your Google Account.
By signing in you'll be able to play your favourite games across phone, tablet and TV. You'll also get customised video and music recommendations on your TV home screen as well as access to YouTube, Google Play and other apps.
Sign In
Use your existing Google Account to sign in to Google on your TV. A Google Account consists of an email address and a password. If you don't have an Google Account yet, use your computer or tablet to create one (accounts.google.com). To play games with Google Play, you need a Google+ profile. If you did not sign in during the first TV installation, you can always sign in later.
To sign in after you did the TV installation…
1 - Press , select All Settings and press OK. 2 - Select Android Settings and press OK. 3 - Press  (down) and select Personal > Add
account and press OK.
4 - Press OK on SIGN IN. 5 - With the remote control keyboard, enter your
email address and press the small OK key at the right of the keyboard. 6 - Enter your password and press the same small OK key to sign in. 7 - Press  (left) repeatedly if necessary, to close the menu.
If you want to sign in with another Google Account, first sign out and sign in with the other account.
You can set or view several Android specific settings or information. You can find the list of apps installed on your TV and the storage space they need. You can set the language you like to use with Voice Search. You can configure the onscreen keyboard or allow apps to use your location. Explore the different Android settings. You can go to www.support.google.com/androidtv for more information on these settings.
To open these settings…
1 - Press , select All Settings and press OK. 2 - Select Android Settings, and press OK. 3 - Explore the different Android settings. 4 - Press BACK if necessary, to close the menu.
3.3
Philips App Gallery
Philips Apps
Connect the TV to the Internet to enjoy apps selected by Philips. These apps are made specially for TV. The Philips App Gallery offers a wide diversity of apps. For some countries, you can install apps of a local Videostore or apps from TV broadcasters in your country. The latter can offer Catch-Up TV services.
The Philips App Gallery collection of apps can differ per country or region.
Some App Gallery apps are pre-installed on your TV. To install other apps from the App Gallery, you will be asked to agree to the Terms of Use. You can set the Privacy Settings according to your preference.
Terms of Use
To install and use the Philips App Gallery apps, you must agree to the Terms of Use. If you did not agree to these terms during the first TV installation, you can always agree to them later. The moment you agree to the Terms of Use, some apps will be available immediately and you can browse the Philips App Gallery to install other apps.
To agree on the Terms of Use after you did the TV installation…
1 - Press HOME and select Philips Collection > App Gallery and press OK to open the App Gallery.
2 - You can select Terms of Use, then press OK to read. 3 - Select Accept and press OK. You cannot undo this approval. 4 - Press BACK to close the menu.
12
Privacy Settings
You can set some privacy settings for the Philips App Gallery apps.
• You can allow technical statistics to be send to Philips.
• You can allow personal recommendations.
• You can allow cookies.
• You can switch on the Child Lock for 18+ rated apps. To set the Philips App Gallery privacy settings…
1 - Press HOME and select Philips Collection > App Gallery and press OK to open
the App Gallery. 2 - You can select Privacy Policy, then press OK to read. 3 - Select Accept and press OK. You cannot undo this approval. 4 - Press BACK to close the menu.
13
4
Connect Devices
4.1
About Connections
Connectivity Guide
Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.
When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.
If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.
HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu­ray Disc. Also referred to as DRM (Digital Rights Management).
HDMI ARC
All of the HDMI connections on the TV have HDMI ARC (Audio Return Channel).
If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to any of the HDMI connections on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.
You can use any HDMI connection on this TV to connect the HTS but ARC is only available for 1 device/connection at a time.
HDMI MHL
Go to www.connectivityguide.philips.com
Antenna port
If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.
HDMI ports
HDMI Quality
An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for TV signal.
For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.
With HDMI MHL, you can send what you see on your Android smartphone or tablet to a TV screen.
The HDMI 4 connection on this TV incorporates MHL 2.0 (Mobile High-Definition Link).
This wired connection offers great stability and bandwidth, low latency, no wireless interference and good quality sound reproduction. On top of that, the MHL connection will charge the battery of your smartphone or tablet. Although connected, your mobile device will not be charging when the TV is on standby.
Inform yourself about what passive MHL cable is suited for your mobile device. In particular, with the HDMI connector for the TV on one side, the type of connector you need to connect to your smartphone or tablet.
MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.
HDMI CEC - EasyLink
Copy protection
EasyLink
An HDMI connection has the best picture and sound quality. One HDMI cable combines video and audio signals. Use an HDMI cable for High Definition (HD) TV signals. For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.
14
control.
EasyLink On or Off
You can switch EasyLink on or off. The TV comes with the EasyLink settings switched on.
To switch off EasyLink completely…
EasyLink HDMI CEC
If your devices are connected with HDMI and have EasyLink, you can operate them with the TV remote control. EasyLink HDMI CEC must be switched On on the TV and the connected device.
With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.
EasyLink setup
The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.
HDMI CEC on other brands
The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully compatible with EasyLink.
1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to
enter the menu. 3 - Select EasyLink, press  (right) and select EasyLink one step further.
4 - Select Off. 5 - Press  (left) repeatedly if necessary, to close
the menu.
EasyLink Remote Control
If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink Remote Control separately.
To switch EasyLink Remote Control on or off…
1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to
enter the menu.
3 - Select EasyLink > EasyLink Remote Control and press OK.
4 - Select On or Off and press OK. 5 - Press  (left) repeatedly if necessary, to close
the menu.
Example HDMI CEC branding names are property of their respective owners.
Operate Devices
To operate a device connected to HDMI and set up with EasyLink, select the device or its activity in the list of TV connections. Press  SOURCES , select a device connected to an HDMI connection and press OK.
Once the device is selected, the TV remote control can control the device. However the keys  HOME and  OPTIONS and some other TV keys, are not forwarded to the device.
If the key you need is not on the TV remote control, you can select the key in the Options menu. Press  OPTIONS and select Controls in the menu bar. On the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.
DVI to HDMI
If you still own a device that only has a DVI connection, you can connect the device to any of the HDMI connection with a DVI to HDMI adapter.
Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.
Only devices that support EasyLink Remote Control function will respond to the TV remote
15
Copy protection
Audio Out - Optical
DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).
Y Pb Pr - Component
Y Pb Pr - Component Video is a high quality connection.
The YPbPr connection can be used for High Definition (HD) TV signals. Next to the Y, Pb and Pr signals add the Audio Left and Right signals for sound.
Match the YPbPr (green, blue, red) connector colours with the cable plugs when you connect. Use an Audio L/R cinch cable if your device also has sound.
Audio Out - Optical is a high quality sound connection.
This optical connection can carry 5.1 audio channels. If your device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In - Optical connection on the HTS. The Audio Out - Optical connection sends the sound from the TV to the HTS.
You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System. For more information, in Help, press the colour key  Keywords and look up Audio Out Settings.
If the sound does not match the video on screen, you can adjust the audio to video synchronisation. For more information, in Help, press the colour key  Keywords and look up Audio to Video
Sync.
Scart
SCART is a good quality connection. The SCART connection can be used for CVBS and
RGB video signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals. The SCART connection also supports NTSC playback.
4.2
CAM with Smart Card - CI+
CI+
This TV is ready for the CI+ Conditional Access. With CI+ you can watch premium HD programmes,
like movies and sports, offered by digital TV operators in your region. These programmes are scrambled by the TV operator and descrambled with a prepaid CI+ module. Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes. These programmes have a high level of copy protection.
Contact a digital TV operator for more information on terms & conditions.
16
Smart Card
Digital TV operators provide a CI+ module (Conditional Access Module - CAM) and an accompanying smart card, when you subscribe to their premium programmes.
Insert the smart card into the CAM module. See the instruction you received from the operator.
To insert the CAM in the TV… 1 - Look on the CAM for the correct method of
insertion. Incorrect insertion can damage the CAM and TV. 2 - While looking at the back of the TV, with the front of the CAM facing towards you, gently insert the CAM into the slot COMMON INTERFACE. 3 - Push the CAM in as far as it will go. Leave it in the slot permanently.
When you switch on the TV, it may take a few minutes before the CAM is activated. If a CAM is inserted and subscription fees are paid (subscription methods can differ), you can watch the scrambled channels supported by the CAM smart card.
4.3
Receiver - Set-Top Box
Cable Box
Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.
Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV. Alternatively, you can use a SCART cable if the Set­top box has no HDMI connection.
The CAM and smart card are exclusively for your TV. If you remove the CAM, you will no longer be able to watch the scrambled channels supported by the CAM.
Passwords and PIN codes
For some CAMs, you must enter a PIN code to watch its channels. When you set the PIN code for the CAM, we recommend you to use the same code you are using to unlock the TV.
To set the PIN code for the CAM…
1 - Press  SOURCES . 2 - Select the channel type you are using the CAM
for. 3 - Press  OPTIONS and select Common Interface. 4 - Select the TV operator of the CAM. The following screens come from the TV operator. Follow the on­screen instruction to look up the PIN code setting.
Switch Off Timer
Switch off this automatic timer, if you only use the remote control of the Set-top box. Switch this timer off to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.
For more information, in Help, press the colour key  Keywords and look up Switch Off
Timer for more information.
Satellite Tuner
Connect the dish antenna cable to the Satellite receiver.
Next to the antenna connection, add an HDMI cable to connect the device to the TV. Alternatively, you can use a SCART cable if the device has no HDMI connection.
17
Switch Off Timer
Switch off this automatic timer, if you only use the remote control of the Set-top box. Switch this timer off to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.
For more information, in Help, press the colour key  Keywords and look up Switch Off Timer for more information.
4.4
Home Theatre System - HTS
Connect with HDMI
Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.
If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to send the sound of the TV picture to the Home Theatre System.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.
Connect with HDMI ARC
Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.
HDMI ARC
If your Home Theatre System has an HDMI ARC connection, you can use any HDMI connection on the TV to connect. With HDMI ARC, you do not need to connect the extra audio cable. The HDMI ARC connection combines both signals. All HDMI connections on the TV can offer the Audio Return Channel (ARC) signal. But once you have connected the Home Theatre System, the TV can only send the ARC signal to this HDMI connection.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.
For more information, in Help, press the colour key  Keywords and look up Audio to Video Sync.
For more information, in Help, press the colour key  Keywords and look up Audio to Video
Sync.
Audio Out Settings
Audio Out Delay
With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.
Automatic audio to video sync
With recent Philips Home Theatre Systems, the audio to video sync is done automatically and always correct.
Audio sync delay
For some Home Theatre Systems you might need to adjust the audio sync delay to synchronise the audio to the video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio Out Delay on the TV.
To switch off Audio Out Delay…
1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the
menu. 3 - Select Advanced > Audio Out Delay and press OK.
18
4 - Select Off. 5 - Press  (left) repeatedly if necessary, to close
the menu.
Audio Out Offset
If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates for the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 5ms. Maximum setting is -60ms.
The Audio Out Delay setting should be switched on.
2 - Select Sound and press  (right) to enter the menu. 3 - Select Advanced > Audio Out Levelling and press OK.
4 - Select More, Medium, or Less, then press OK.
5 - If the volume difference is large, select More. If
the volume difference is small, select Less. 6 - Press  (left) repeatedly if necessary, to close the menu.
Audio Out Levelling affects both the Audio Out ­Optical and HDMI ARC sound signals.
To synchronise the sound on the TV…
1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the
menu. 3 - Select Advanced > Audio Out Offset and press OK. 4 - Use the slider bar to set the sound offset and press OK. 5 - Press  (left) repeatedly if necessary, to close the menu.
Audio Out Format
If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio Out Format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.
To set Audio Out Format
1 - Press , select All Settings and press OK. 2 - Select Sound and press  (right) to enter the
menu. 3 - Select Advanced > Audio Out Format and press OK. 4 - Select Multichannel or Stereo (uncompressed), then press OK. 5 - Press  (left) repeatedly if necessary, to close the menu.
Problems with HTS sound
Sound with loud noise
If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted. This noise is heard when the audio or video file has DTS sound but the Home Theatre System has no DTS sound processing. You can fix this by setting the Audio Out Format of the TV to Stereo (uncompressed).
Press  for All
Settings > Sound > Advanced > Audio Out Format.
No sound
If you cannot hear the sound from the TV on your Home Theatre System, check if you connected the HDMI cable to an HDMI ARC connection on the Home Theatre System. All HDMI connections on the TV are HDMI ARC connections.
4.5
Smartphones and Tablets
To connect a smartphone or tablet to the TV, you can use a wireless or wired connection.
Wireless
For a wireless connection, on your smartphone or tablet download the Philips TV Remote App from your favourite app store.
Audio Out Levelling
Use the Audio Out Levelling setting to level the volume (loudness) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.
To level the difference in volume…
1 - Press , select All Settings and press OK.
Wired
For a wired connection, use the HDMI 4 MHL connection on the back of the TV. In Help, press the colour key  Keywords and look up HDMI MHL for more information.
19
4.6
Blu-ray Disc Player
Use a High speed HDMI cable to connect the Blu­ray Disc player to the TV.
What You Need
You can connect a wireless device with Bluetooth® to this TV – a wireless speaker, a subwoofer, a sound bar or headphones. You can also connect a wireless gamepad with Bluetooth LE.
To play the TV sound on a wireless speaker, you must pair the wireless speaker with the TV. You can pair some wireless speakers and a maximum of 4 Bluetooth LE (low energy) devices. The TV can only play the sound on one speaker at a time. If you connect a subwoofer, the sound is played on the TV and the subwoofer. If you connect a sound bar the sound is played on the sound bar only.
If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.
4.7
DVD Player
Use an HDMI cable to connect the DVD player to the TV. Alternatively, you can use a SCART cable, if the device has no HDMI connection.
If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.
For more information on EasyLink, in Help, press the colour key  Keywords and look up EasyLink HDMI CEC.
4.8
Bluetooth - Speakers and Gamepads
Attention - Audio to Video syncronisation
Many Bluetooth speaker systems have a high, so called, 'latency'. High latency means that the audio lags behind the video, causing unsynchronised 'lip sync'. Before you purchase a wireless Bluetooth speaker system, inform yourself about the newest models and look for a device with a low latency rating. Ask your dealer for advice.
For more information on how to pair a wireless speaker, in Help, press the colour key  Keywords and look up Bluetooth, Pairing.
Pairing a Device
Position the wireless speaker within a distance of 5 meters from the TV. Read the user manual of the device for specific information on pairing and on wireless range. Make sure the Bluetooth setting on TV is switched on.
Once a wireless gamepad is paired, you can use it. When a wireless speaker is paired, you can select it to play the TV sound. When a device is paired, you do not need to pair it again unless you remove the device.
To pair a wireless speaker with the TV… 1 - Switch on the wireless speaker and place it within
range of the TV.
2 - Press , select All Settings and press OK. 3 - Select Wireless and Networks and
press  (right) to enter the menu. 4 - Select Bluetooth > Search Bluetooth Device, and press OK. 5 - Select Search and press OK. Follow the instuctions on screen. You will pair the device with the TV and the TV will store the connection. 6 - Select the type of device (headphone, subwoofer, …), select Next and press OK. 7 - Press  (left) repeatedly if necessary, to close the menu.
For more information on how to select the wireless
20
speaker, in Help, press the colour key  Keywords and look up Speakers, Select.
For more information on the Bluetooth On or Off setting, in Help, press the colour key  Keywords and look up Bluetooth, On or Off.
To adjust the volume… 1 - Press , select Headphone Volume and
press OK. 2 - Press the arrows  (up) or  (down) to adjust the value. 3 - Press  (left) repeatedly if necessary, to close the menu.
Select a Device
Once a wireless Bluetooth speaker is paired, you can select it to play the TV sound.
To select a speaker to play the TV sound…
1 - Press , select Speakers and press OK. 2 - Select the loudspeaker system you want and
press OK. 3 - Press  (left) repeatedly if necessary, to close the menu.
Remove a Device
You can connect or disconnect a wireless Bluetooth device. When a Bluetooth device is connected, you can use the gamepad or hear the TV sound through the wireless speaker. You can also remove a wireless Bluetooth device. If you remove a Bluetooth device, the device will be unpaired.
To remove or disconnect a wireless device…
1 - Press , select All Settings and press OK. 2 - Select Wireless and Networks and press OK. 3 - Select Bluetooth > Remove Device and
press OK. 4 - In the list, select the wireless device and press OK.
5 - Select Disconnect or Remove and press OK. 6 - Select OK and press OK to confirm. 7 - Press  (left) repeatedly if necessary, to close
the menu.
4.10
Game Console
HDMI
For best quality, connect the game console with a High speed HDMI cable to the TV.
Y Pb Pr
Connect the game console with a component video cable (Y Pb Pr) and an audio L/R cable to the TV.
4.9
Headphones
You can connect a set of headphones to the  connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the volume of the headphones separately.
Scart
Connect the game console to the TV with a composite cable (CVBS) and an audio L/R cable to the TV.
If your game console only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.
21
Best Setting
Before you start playing a game from a connected game console, we advice you to set the TV in the ideal setting Game.
Suitable Gamepads
A selected range of wireless Gamepads are suited and tested for use on this TV. Other Gamepads might not be fully compatible.
The suited Gamepads are…
• Logitech F710
• Logitech F510
• Xbox 360 Wireless Controller for Windows
• Speedlink Strike FX Wireless Gamepad
• Sony Play Station wired
• Mad Catz C.T.R.L. Mobile Gamepad for Android
• Ipega, PG-9023
• Ipega, PG-9025
• PhoneJoy gamepad
When you finish playing a game and start watching TV again, remember to switch the Game or Computer setting back to Off.
To set the TV to the ideal setting…
1 - Press , select All Settings and press OK. 2 - Select Picture and press  (right) to enter the
menu. 3 - Select Advanced > Game or Computer, and select the device type you want to use. To switch back to TV, select Off. 4 - Press  (left) repeatedly if necessary, to close the menu.
4.11
Gamepad
Connect a Gamepad
To play games from the Internet on this TV, you can connect a selected range of wireless Gamepads. You can use Gamepads with a USB nano receiver or gamepads with Bluetooth.
To connect a Gamepad with a USB nano receiver… 1 - Plug in the small nano receiver in one of the USB
connections on the side of the TV. The wireless nano receiver comes with the Gamepad. 2 - If the Gamepad is switched on, you can use the Gamepad.
You can connect a second Gamepad in the second USB connection on the side of the TV.
Bluetooth
To connect a wireless gamepad with Bluetooth, in Help, press the colour key  Keywords and look up Bluetooth, Pairing.
Problems
To solve possible interference with other wireless devices on TV…
• Use a USB extension cord and move the nano receiver about 1 meter away from the TV.
• Alternatively, you can use a powered USB hub connected to the TV and plug in the nano receivers in the USB hub.
4.12
USB Hard Drive
What You Need
If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).
To Pause
To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 4GB disk space.
To Record
To pause and record a broadcast, you need a minimum of 250GB disk space. If you want to record a broadcast with TV guide data from the Internet, you need to have the Internet connection installed on your TV before you install the USB Hard Drive.
For more information on how to install a USB Hard Drive, in Help, press the colour key  Keywords and look up USB Hard Drive, installation.
22
Installation
Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.
1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.
2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,
press  (Pause). Trying to pause will start the formatting.
Follow the instructions on screen. When the USB Hard Drive is formatted, leave it
connected permanently.
1 - Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.
2 - Switch on the USB Hard Drive and the TV. 3 - When the TV is tuned to a digital TV channel,
press  (Pause). Trying to pause will start the formatting. Follow the instructions on screen. 4 - The TV will ask if you want to use the USB Hard Drive to store apps, agree to the question if you do. 5 - When the USB Hard Drive is formatted, leave it connected permanently.
4.13
Warning
The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.
Formatting
Before you can pause or record a broadcast, or store apps, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive. If you want to record broadcasts with TV Guide data from the Internet, you must setup the Internet connection first before you install the USB Hard Drive.
Warning
The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.
To format a USB Hard Drive…
USB Keyboard
Connect
Connect a USB keyboard (USB-HID type) to enter text on your TV.
Use one of the USB connections to connect.
Configure
To install the USB keyboard, switch on the TV and connect the USB keyboard to one of the USB connections on the TV. When the TV detects the keyboard for the first time, you can select your keyboard lay-out and test your selection. If you select a Cyrillic or Greek keyboard layout first, you can select a secondary Latin keyboard layout.
To change the keyboard layout setting when a layout was selected…
1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to
enter the menu. 3 - Select USB Keyboard Settings, and press OK to
23
start the keyboard setup.
4.15
Photo Camera
Special Keys
Keys for entering text
• Enter key = OK
• Backspace = delete character before cursor
• Arrow keys = navigate within a text field
• To switch between keyboard layouts, if a secondary layout is set, press the Ctrl + Spacebar keys simultaneously.
Keys for apps and Internet pages
• Tab and Shift + Tab = Next and Previous
• Home = scroll to the top of the page
• End = scroll to the bottom of the page
• Page Up = jump one page up
• Page Down = jump one page down
• + = zoom in one step
• - = zoom out one step
• * = fit the web page to the screen width
4.14
USB Flash Drive
You can view photos or play your music and videos from a connected USB flash drive.
To view photos stored on your digital photo camera, you can connect the camera directly to the TV.
Use one of the USB connections on the TV to connect. Switch on the camera after you made the connection.
If the contents list does not appear automatically, press  SOURCES , and select USB. Your camera might need to be set to transfer its content with PTP (Picture Transfer Protocol). Read the user manual of the digital photo camera.
For more information on viewing photos, in Help, press the colour key  Keywords and look up Photos, Videos and Music.
4.16
Camcorder
HDMI
For best quality, use an HDMI cable to connect the camcorder to the TV.
Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.
The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press  SOURCES and select USB.
To stop watching the USB flash drive content, press  EXIT or select another activity. To disconnect the USB flash drive, you can pull out the flash drive anytime.
For more information on watching or playing content from a USB flash drive, in Help, press the colour key  Keywords and look up Photos, Videos and
Music.
Audio Video LR / Scart
You can use an HDMI, YPbPr or SCART connection to connect your camcorder. If your camcorder only has Video (CVBS) and Audio L/R output, use a Video Audio L/R to SCART adapter (sold separately) to connect to the SCART connection.
24
4.17
Computer
Connect
You can connect your computer to the TV and use the TV as a PC monitor.
2 - Select Picture and press  (right) to enter the menu. 3 - Select Advanced > Game or Computer, and press OK. 4 - Select Game (for gaming) or select Computer (for watching a movie). 5 - Press  (left) repeatedly if necessary, to close the menu.
With HDMI
Use an HDMI cable to connect the computer to the TV.
With DVI to HDMI
Alternatively, you can use a DVI to HDMI adapter (sold separately) to connect the PC to HDMI and an audio L/R cable (mini-jack 3.5mm) to AUDIO IN L/R on the back of the TV.
Remember to set Game or Computer setting to Off when you stop playing the game.
Ideal Setting
If you connect a computer, we advice you to give the connection, on which the computer is connected, the correct device type name in the Source menu. If you then switch to Computer in the Source menu, the TV is set to the ideal Computer setting automatically.
You can manually switch the ideal setting to Off for watching TV or Game for playing a game from a connected game console (remember to switch back to Off when you stop playing a game).
If you switch to a source and change the Game or Computer setting, it will be stored for this selected source.
To set the TV to the ideal setting… 1 - Press , select All Settings and press OK.
25
5
Switching On and Off
5.1
On or standby
the menu.
Make sure the TV is connected to the mains AC power. Connect the supplied power cord to the AC in connector at the back of the TV. The indicator light at the bottom of the TV lights up.
Switch on
Press  on the remote control to switch the TV on. Alternatively, press  HOME. You can also press the small joystick key on the back of the TV to switch the TV on in case you can't find the remote control or its batteries are empty.
Switch to standby
To switch the TV to standby, press  on the remote control. You can also press the small joystick key on the back of the TV.
In standby mode, the TV is still connected to the mains power but consumes very little energy.
5.3
Keys on TV
If you lost the remote control or its batteries are empty, you can still do some basic TV operations.
To open the basic menu… 1 - With the TV switched on, press the joystick key on
the back of the TV to bring up the basic menu. 2 - Press left or right to select  Volume, Channel or  Sources. Select  Demo, to start a demo movie. 3 - Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection. Press the joystick key to start the demo movie. 4 - The menu will disappear automatically.
To switch the TV on standby, select  and press the joystick key.
To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.
5.2
Philips Logo Brightness
You can switch off or adjust the brightness of the Philips logo on the front of the TV.
To adjust or switch off…
1 - Press , select All Settings and press OK. 2 - Select General Settings and press  (right) to
enter the menu. 3 - Select Philips Logo Brightness, and press  (right) to enter the menu. 4 - Select Minimum, Medium, Maximum, or Off to switch off the lighting of the logo, then press OK. 5 - Press  (left) repeatedly if necessary, to close
5.4
Sleep Timer
With the Sleep Timer, you can set the TV to switch to Standby automatically after a preset time.
To set the Sleep Timer…
1 - Press , select Sleep Timer and press OK. 2 - With the slider bar you can set the time to up to
180 minutes in increments of 5 minutes. If set to 0 minutes, the Sleep Timer is switched off. You can always switch off your TV earlier or reset the time during the countdown. 3 - Press BACK to close the menu.
26
5.5
Switch Off Timer
If the TV receives a TV signal but you don't press a key on the remote control during a 4 hour period, the TV switches off automatically to save energy. Also, if the TV does not receive a TV signal nor a remote control command for 10 minutes, the TV switches off automatically.
If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.
To deactivate the Switch Off Timer …
1 - Press , select All Settings and press OK. 2 - Select Eco Settings and press  (right) to enter
the menu.
3 - Select Switch Off Timer and press OK. 4 - Press the arrows  (up) or  (down) to adjust
the value. The value 0 deactivates the automatic switch off. 5 - Press  (left) repeatedly if necessary, to close the menu.
For more information on environmentally friendly TV settings, in Help, press the colour key  Keywords and look up Eco Settings.
27
6
Remote Control
6.1
Key overview
Top
1 - 
To open the TV Menu with typical TV functions. 2 - SOURCES
To open or close the Sources menu.
1 - Standby / On To switch the TV on or back to Standby.
2 - Playback and Record
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to go fast forward
• Record , to start recording 3 -
To select one of the Ambilight style. 4 -  TV GUIDE
To open or close the TV Guide. 5 -
To open the Netflix App directly. With the TV switched on or from standby.
6 - Settings To open the Frequent Settings menu and All Settings.
Ambilight
3 -
Direct selection of options. Blue key , opens Help. 4 -  INFO
To open or close programme info. 5 -  BACK
To switch back to the previous channel you selected. To close a menu without changing a setting. To go back to the previous App/Internet page.
6 -  EXIT
To switch back to watching TV. To leave an interactive TV application.
7 -  OPTIONS To open or close the Options menu.
8 - OK key To confirm a selection or setting.
9 - Arrow / navigation keys To navigate up, down, left or right.
10 -  HOME To open the Home menu.
Colour keys
7 ­To open the menu with recommended programmes, Video on Demand (Rental Videos) or Online TV (Catch Up TV).
8 -  SEARCH To open the searches page.
TOP PICKS
Middle
Bottom
28
1 -  MULTIVIEW To open a small screen in the big screen.
2 ­To adjust the volume level.
3 - Number keys To select a channel directly.
4 - SUBTITLE To switch subtitles on, off or to show automatically.
5 -  Channel To switch to the next or previous channel in the channel list. To open the next or previous page in Text/Teletext. To start the next or previous chapter on a disc.
Volume
Voice Search
Pairing with your TV
There is no microphone on your remote control, if you want to use voice search, you must install Android TV Remote Control app on your Android smartphone or tablet first.
1 - On your Android smartphone or tablet, search "Android TV Remote Control" in Google Play store.
2 - Download and install Android TV Remote Control app* on your Android smartphone or
tablet . 3 - Connect your Android smartphone or tablet to the same network as your Android TV device. 4 - Select "PhilipsTv"** on your Android smartphone or tablet, then your Android TV will show a code on the screen. 5 - Enter the code on your Android smartphone or tablet to pair to your Android TV.
*You need an Android phone or tablet running Android 4.3 or higher to use the Android TV Remote Control app.
**The name of your Android TV is depends on the name you set in TV Network Name. The pre-set name is model name of this TV.
For more information, in Help, press the colour key  Keywords and look up Network, TV
Network Name.
6 -
To mute the sound or to restore it. 7 - TEXT
To open or close Text/Teletext.
6.2
Mute
Voice search
Download App from Google play
Use your Android smartphone or tablet as a remote for your Android TV. Easily switch between d-pad, touchpad, and gamepad modes to navigate content and play games on your Android TV device. Tap the microphone to start a voice search, or use the keyboard to input text on Android TV.
To get started, connect your Android phone or tablet to the same network as your Android TV device or find your Android TV via bluetooth.
Works with all Android TV devices. *You need an Android phone or tablet running
Android 4.3 or higher to use the Android TV Remote Control app.
Using Voice search
You can search for videos, music or anything else on the Internet with the  icon at the top of the Home menu. You can start using Voice Search any time. Alternatively, you can use the remote control keyboard to enter text.
To use Voice Search… 1 - Tap  icon on your smartphone to start a voice
search. 2 - The  icon is red on screen, the microphone is active. 3 - Speak out clearly what you are looking for. It might take some time for the results to appear. 4 - In the screen with search results, you can select the item you want.
See also www.support.google.com/androidtv
Voice Search settings
You can set the language you like to use with Voice Search.
To set the language for Voice Search…
29
1 - Press , select All Settings and press OK. 2 - Select Android Settings and press OK. 3 - Select Preferences >  Speech and
press OK. 4 - Select the language you want to use and press OK. 5 - Press BACK to go back one step or press  EXIT to close the menu.
6.3
Keyboard
Overview
To write text…
1 - Select a text field if it is not yet selected. 2 - Turn the remote control keyboard facing upwards
to activate the keyboard keys. Hold the remote control with two hands and type with both thumbs. 3 - To hide the on screen keyboard, press BACK. Press OK to confirm the text.
Onscreen Keyboard
Qwerty and Azerty
Overview of a Qwerty/Azerty keyboard.*
1 - Azerty character Character position if the keyboard layout is set to Azerty.
2 ­To type uppercase characters.
3 - Fn key To type a number or punctuation character.
4 -  Spacebar 5 - Navigation and OK 6 -  Share this
To share online what you are watching at the moment.
* Your remote control has a Qwerty / Azerty or a Qwerty / Cyrillic keyboard, depending on your region.
Shift
If you use the onscreen keyboard to enter text, you can configure the keyboard layout to a layout you are used to.
To open these settings… Press  HOME, select All Settings and press OK.
5 - Select Android Settings and press OK. 6 - Select Preferences >  Keyboard and
press OK. 7 - Select Configure > Language and press OK. You can set your language keyboard layout here. 8 - Press BACK to close the menu to go back one step.
Uppercase and Lowercase
To type an uppercase character, press the  (Shift) key just before you type the character. To type several uppercase characters consecutively, press and hold the  key while typing. To type uppercase constantly, press the  key for 2 seconds to switch the keyboard in uppercase mode. To switch out of uppercase mode, press the  key again. If no keys are pressed for 20 seconds, the uppercase mode switches off automatically. Also, if you press another modifier key, like Fn or , you switch out of uppercase mode.
Writing Text
With the keyboard on the back of the remote control, you can write text in any text field on screen. Turn the keyboard facing upwards to activate the keyboard keys. Hold the remote control with two hands and type with both thumbs.
Numbers and Punctuation Characters
To type a number or punctuation character, press the Fn key just before you type the number or punctuation character you need. You can switch the Fn mode on or off as you do for the uppercase mode.
Internet You can use the Fn key to enter www. or .com.
30
Loading...
+ 112 hidden pages
